Land use/land cover (LULC) change is a key driving factor influencing the dynamics of terrestrial ecosystem carbon storage. In high-groundwater-level coal resource-based cities (HGCRBCs), the interplay of urban expansion, mining disturbances, and land reclamation makes the carbon storage evolution process more complex. This study takes Jining, Zaozhuang, and Heze cities in Shandong Province as the research area and constructs a coupled analytical framework of “mining–reclamation–carbon storage” by integrating the Patch-generating Land Use Simulation (PLUS), Probability Integral Method (PIM), InVEST, and Grey Multi-Objective Programming (GMOP) models. It systematically evaluates the spatiotemporal characteristics of carbon storage changes from 2000 to 2020 and simulates the carbon storage responses under different development scenarios in 2030. The results show that: (1) From 2000 to 2020, the total carbon storage in the region decreased by 31.53 Tg, with cropland conversion to construction land and water bodies being the primary carbon loss pathways, contributing up to 89.86% of the total carbon loss. (2) Among the 16 major LULC transition paths identified, single-process drivers dominated carbon storage changes. Specifically, urban expansion and mining activities individually accounted for nearly 70% and 8.65% of the carbon loss, respectively. Although the reclamation path contributed to a recovery of 1.72 Tg of carbon storage, it could not fully offset the loss caused by mining. (3) Future scenario simulations indicate that the ecological conservation scenario yields the highest carbon storage, while the economic development scenario results in the lowest. Mining activities generally lead to approximately 3.5 Tg of carbon loss, while post-mining reclamation can restore about 72% of the loss. Full article

Illegal mining operations induce cascading ecosystem degradation by causing extensive ground subsidence, necessitating accurate underground goaf localization for effectively induced-hazard mitigation. The conventional locating method applied the synthetic aperture radar interferometry (InSAR) technique to obtain ground deformation to estimate underground goaf parameters, and the locating accuracy was crucially contingent upon the appropriateness of nonlinear deformation function models selection and the precision of geological parameters acquisition. However, conventional model-driven underground goaf locating frameworks often fail to sufficiently integrate prior geological information during the model selection process, potentially leading to increased positioning errors. In order to enhance the operational efficiency and locating accuracy of underground goaf, deformation model selection must be aligned with site-specific geological conditions under varying cases of prior information. To address these challenges, this study categorizes prior geological information into three different hierarchical levels (detailed, moderate, and limited) to systematically investigate the correlations between model selection and prior information. Subsequently, field validation was carried out by applying two different non-linear deformation function models, Probability Integral Model (PIM) and Okada Dislocation Model (ODM), with three different prior geological information conditions. The quantitative performance results indicate that, (1) under a detailed prior information condition, PIM achieves enhanced dimensional parameter estimation accuracy with 6.9% reduction in maximum relative error; (2) in a moderate prior information condition, both models demonstrate comparable estimation performance; and (3) for a limited prior information condition, ODM exhibits superior parameter estimation capability showing 3.4% decrease in maximum relative error. Furthermore, this investigation discusses the influence of deformation spatial resolution, the impacts of azimuth determination methodologies, and performance comparisons between non-hybrid and hybrid optimization algorithms. This study demonstrates that aligning the selection of deformation models with different types of prior geological information significantly improves the accuracy of underground goaf detection. The findings offer practical guidelines for selecting optimal models based on varying information scenarios, thereby enhancing the reliability of disaster evaluation and mitigation strategies related to illegal mining. Full article

This study uses the Shangwan coal mine in Shendong Mine as its research area and evaluates the vegetation net primary productivity (NPP)’s impact in the mining area based on the multi-scale research unit of working face. The probability integral model (PIM) was employed to analyze the characteristics of spatiotemporal variation and mining impact laws of surface vegetation NPP in the entire Shangwan coal mine and working face impact zone. We proposed vegetation NPP impact assessment scheme based on working face and annual mining impact spatiotemporal scales, as well as impact distance and duration evaluation parameters, and multi-scale evaluation results of NPP in the mining area were calculated. (1) The vegetation NPP of the Shangwan coal mine has shown a fluctuating growth trend from 2000 to 2023. The annual average NPP variation value is 98.5–280.7 gC/m², and the average annual value is 198.8 gC/m². (2) By analyzing the fourth district impact zone, the impact patterns of the underground mining area, subsidence area, and vegetation NPP above the mining area were revealed for each mining year. (3) From the impact of mining on the 12401 working face in 2018, the mining impact distance on surface vegetation NPP is 300–400 m, and the impact duration is 3–4 years. It reveals that the impact of underground mining on surface vegetation NPP in the entire coal mining area is not significant. The NPP in mining area shows a temporal variation pattern of fluctuating growth and stabilizing trends. The research results have comprehensively revealed the degree and characteristics of underground mining’s impact on surface vegetation from different evaluation scales, providing a basis for effective management of the mining area environment. Full article

Constructing high-precision subsidence basins is of paramount importance for mining subsidence monitoring. Traditional unmanned aerial vehicle (UAV) photogrammetry techniques typically construct subsidence basins by directly differencing digital elevation models (DEMs) from different monitoring periods. However, this method often neglects the influence of horizontal displacement on the accuracy of the subsidence basin. Taking a mining area in Ordos, Inner Mongolia, as an example, this study employed the normalized cross-correlation (NCC) matching algorithm to extract horizontal displacement information between two epochs of a digital orthophoto map (DOM) and subsequently corrected the horizontal position of the second-epoch DEM. This ensured that the planar positions of ground feature points remained consistent in the DEM before and after subsidence. Based on this, the vertical displacement in the subsidence area (the subsidence basin) was obtained via DEM differencing, and the parameters of the post-correction subsidence basin were inverted using the probability integral method (PIM). The experimental results indicate that (1) the horizontal displacement was influenced by the gully topography, causing the displacement within the working face to be segmented on both sides of the gully; (2) the influence of the terrain on the subsidence basin was significantly reduced after correction; (3) the post-correction surface subsidence curve was smoother than the pre-correction curve, with abrupt error effects markedly diminished; (4) the accuracy of the post-correction subsidence basin increased by 43.12% compared with the total station data; and (5) comparing the measured horizontal displacement curve with that derived using the probability integral method revealed that the horizontal displacement on the side of an old goaf adjacent to the newly excavated working face shifted toward the advancing direction of the new working face as mining progressed. This study provides a novel approach and insights for using low-cost UAVs to construct high-precision subsidence basins. Full article

Illegal coal mining is prevalent worldwide, leading to extensive ground subsidence and land collapse. It is crucial to define the location and spatial dimensions of these areas for the efficient prevention of the induced hazards. Conventional methods for goaf locating using the InSAR technique are mostly based on the probability integral model (PIM). However, The PIM requires detailed mining information to preset model parameters and does not account for the layered structure of the coal overburden, making it challenging to detect underground goaves in cases of illegal mining. In response, a novel method based on the InSAR technique and the Stratified Optimal Okada Dislocation Model, named S-ODM, is proposed for locating goaves with basic geological information. Firstly, the S-ODM employs a numerical model to establish a nonlinear function between the goaf parameters and InSAR-derived ground deformation. Then, in order to mitigate the influence of nearby mining activities, the goaf azimuth angle is estimated using the textures and trends of the InSAR-derived deformation time series. Finally, the goaf’s dimensions and location are estimated by the genetic algorithm–particle swarm optimization (GA-PSO). The effectiveness of the proposed method is validated using both simulation and real data, demonstrating average relative errors of 6.29% and 7.37%, respectively. Compared with the PIM and ODM, the proposed S-ODM shows improvements of 19.48% and 52.46% in geometric parameters. Additionally, the errors introduced by GA-PSO and the influence of ground deformation monitoring errors are discussed in this study. Full article

Time series dynamic prediction of surface deformation in mining areas can provide reference data for coal mine safety and production, which has important impacts. The combination of interferometric synthetic aperture radar (InSAR) technology and the probability integral method (PIM) is commonly used for predicting deformation. However, most surface subsidence prediction in mining areas is based on the static PIM parameters, failing to achieve the three-dimensional (3D) dynamic deformation prediction. This paper proposed a 3D deformation dynamic prediction model (InSAR-3D-CTPIM) between InSAR deformation observations and dynamic coordinate-time PIM (CTPIM) parameters, which can realize the prediction of east–west, north–south, and vertical series deformation caused by mining. The method has been validated by simulation experiments and real experiments in the mining area of Jiansheng Coal Mine in Baisha Reservoir, Henan Province, China. The results showed that the modeling accuracy was improved by 34.3% compared to the traditional multi-rate model, and the accuracy was improved by 28.5% compared to the vertical deformation obtained by the traditional static PIM method. The InSAR-3D-CTPIM model can be used to predict the evolutionary history of basin-wide surface deformation dynamics in coal mining areas, and provide a reference for the early warning and prediction of geological hazards in coal mining areas. Full article

The fundamental model for dynamically predicting surface subsidence is the time influence function. However, current research and the application of time functions often neglect the comprehensive characteristics of the entire surface deformation process, leading to a less systematic representation of the actual deformation law. To rectify this, we explore ground point deformation along the strike line from two perspectives: dynamic subsidence and dynamic horizontal movement. Moreover, we develop prediction models for dynamic subsidence and dynamic horizontal movement at any point along the strike line, utilizing the probability integral method (PIM) and considering the surface deformation features. We then use characteristic constraints based on the prediction models to constrain the time influence function. For this purpose, we employ the Richards time function which has strong universality to establish the time functions for dynamic subsidence and horizontal movement under these constraints. We provide an illustrative example of its application in the 12,401 working face. Additionally, we explore the suitability of interferometric synthetic aperture radar (InSAR) technology for acquiring dynamic subsidence data on the surface. The experimental findings reveal the following key observations: the Richards model, when applied for dynamic subsidence prediction under constraints, exhibits high accuracy with an R-squared (R²) value of 0.997 and a root mean squared error (RMSE) of 94.6 mm, along with a relative mean square error of 1.9%. Meanwhile, the dynamic horizontal movement prediction model exhibits an accuracy in fully mined areas with an R² of 0.986, an RMSE of 46.2 mm, and a relative mean square error of 2.6%. Full article

The accurate calculation of mining-induced surface deformation has important guiding significance for efficient and safe production in mining areas. The probability integral method (PIM) is a main prediction method in China, and the selection of its parameters is directly related to the prediction accuracy of surface deformation in mining areas. To overcome shortcomings of PIM and other methods, this paper proposed a prediction model of the parameters of PIM combining a multiple regression model and an extreme learning machine. In this paper, the Huainan mining area was selected as the research object, the influence factors of PIM parameters were analyzed and the accuracy of the model was verified. The influence of the number of hidden layer nodes, the selection of activation function and the proportion of training set and test set in the model were analyzed. The conclusions suggest that the PIM parameters calculated in this paper could be used to predict mining subsidence and obtain surface movement and deformation data. The research results provide an effective method for the selection of surface deformation prediction parameters of new working faces or faces lacking measured data. Full article

The current three-dimensional (3D) deformation monitoring methods, based on the single line-of-sight (LOS) interferometric synthetic aperture radar (InSAR) technology, are constructed by combining the deformation characteristics of mining subsidence basins, which are incompletely suitable in the edge area of the subsidence basin and some large deformation gradient mines with surface uplift in the LOS direction.The 3D deformation monitoring method of InSAR combined with the surface displacement vector depression angle model (InSAR+ depression angle model) is proposed to obtain more detailed and accurate deformation information of the entire basin. This method first establishes a surface displacement vector depression angle model based on the probability integral method (PIM). The magnitude of the surface displacement vector—owing to the spatial relationship between the LOS direction and the surface displacement vector—is obtained because the horizontal movement direction field and the displacement vector depression angle field of the mining area determine the 3D directions of the surface displacement vector. Then, the PIM model is used to obtain the settlement information of the central area with a large deformation gradient. A complete subsidence basin of the mining area is received by combining the proposed method and the PIM. A total of 35 Sentinel-1A data from 31 March 2018 to 13 May 2019 and the leveling data were used to apply and analyze the accuracy of this method. The experimental results show that this method can obtain more accurate information on surface subsidence around the mining area. Moreover, the overall settlement is more consistent with the actual situation, and the monitoring ability is significantly improved compared with the InSAR and PIM. Full article

In this paper, GNSS interferometric reflectometry (GNSS-IR) is firstly proposed to estimate ground surface subsidence caused by underground coal mining. Ground subsidence on the main direction of a coal seam is described by using the probability integral model (PIM) with unknown parameters. Based on the laws of reflection in geometric optics, model of GNSS signal-to-noise (SNR) observation for the tilt surface, which results from differential subsidence of ground points, is derived. Semi-cycle SNR observations fitting method is used to determine the phase of the SNR series. Phase variation of the SNR series is used to calculate reflector height of ground specular reflection point. Based on the reflector height and ground tilt angle, an iterative algorithm is proposed to determine coefficients of PIM, and thus subsidence of the ground reflection point. By using the low-cost navigational GNSS receiver and antenna, an experimental campaign was conducted to validate the proposed method. The results show that, when the maximum subsidence is 3076 mm, the maximum relative error of the proposed method-based subsidence estimation is 5.5%. This study also suggests that, based on the proposed method, the navigational GNSS instrument can be treated as a new type of sensor for continuously measuring ground subsidence deformation in a cost-effective way. Full article

Carbon sequestration in terrestrial ecosystems plays an essential role in coping with global climate change and achieving regional carbon neutrality. In mining areas with high groundwater levels in eastern China, underground coal mining has caused severe damage to surface ecology. It is of practical significance to evaluate and predict the positive and negative effects of coal mining and land reclamation on carbon pools. This study set up three scenarios for the development of the Yanzhou coalfield (YZC) in 2030, including: (1) no mining activities (NMA); (2) no reclamation after mining (NRM); (3) mining and reclamation (MR). The probability integral model (PIM) was used to predict the subsidence caused by mining in YZC in 2030, and land use and land cover (LULC) of 2010 and 2020 were interpreted by remote sensing images. Based on the classification of land damage, the LULC of different scenarios in the future was simulated by integrating various social and natural factors. Under different scenarios, the InVEST model evaluated carbon storage and its temporal and spatial distribution characteristics. The results indicated that: (1) By 2030, YZC would have 4341.13 ha of land disturbed by coal mining activities. (2) Carbon storage in the NRM scenario would be 37,647.11 Mg lower than that in the NMA scenario, while carbon storage in the MR scenario would be 18,151.03 Mg higher than that in the NRM scenario. Significantly, the Nantun mine would reduce carbon sequestration loss by 72.29% due to reclamation measures. (3) Carbon storage has a significant positive spatial correlation, and coal mining would lead to the fragmentation of the carbon sink. The method of accounting for and predicting carbon storage proposed in this study can provide data support for mining and reclamation planning of coal mine enterprises and carbon-neutral planning of government departments. Full article

Deformation prediction for a salt solution mining area is essential to mining environmental protection. The combination of Synthetic Aperture Radar Interferometry (InSAR) technique with Probability Integral Method (PIM) has proven to be powerful in predicting mining-induced subsidence. However, traditional mathematical empirical models (such as linear model or linear model combined with periodical function) are mostly used in InSAR approaches, ignoring the underground mining mechanisms, which may limit the accuracy of the retrieved deformations. Inaccurate InSAR deformations will transmit an unavoidable error to the estimated PIM parameters and the forward predicted subsidence, which may induce more significant errors. Besides, theoretical contradictory and non-consistency between InSAR deformation model and future prediction model is another limitation. This paper introduces the Coordinate-Time (CT) function into InSAR deformation modeling. A novel time-series InSAR model (namely, CT-PIM) is proposed as a substitute for traditional InSAR mathematical empirical models and directly applied for future dynamic prediction. The unknown CT-PIM parameters can be estimated directly via InSAR phase observations, which can avoid the error propagation from the InSAR-generated deformations. The new approach has been tested by both simulated and real data experiments over a salt mine in China. The root mean square error (RMSE) is determined as ±10.9 mm, with an improvement of 37.2% compared to traditional static PIM prediction method. The new approach provides a more robust tool for the forecasting of mining-induced hazards in salt solution mining areas, as well as a reference for ensuring the environment protection and safety management. Full article

Determining the geographic location and spatial distribution of underground goaf is of great significance for the prevention of mining subsidence hazards and the detection of illegal mining. However, traditional goaf detection techniques mainly focus on geophysical methods that are labor intensive, have low efficiency, and are expensive. Due to the large range and off-site monitoring capability of interferometric synthetic aperture radar (InSAR) techniques, research on goaf location detection based on InSAR measurements has been increasing. This paper proposes a new method for locating underground goaf based on cross-iteration and InSAR measurements. Firstly, the functional relationship between the geometric parameters of the goaf and the line of sight (LOS) deformation retrieved by InSAR techniques is constructed. Then, the three initial model parameters of the probability integration method (PIM) are determined by mining geological conditions. Finally, the cross-iteration method is used to determine the parameters to characterize the spatial location of underground goaf. The experimental results show that the average relative errors of the simulated experiment and the real experiment are 1.5% and 5.1%, respectively, and the inverted goaf parameters are in good agreement with the real values. Moreover, the proposed method only requires the main lithology of the overlying rock in the goaf and does not depend on the accuracy of PIM model parameters. Therefore, this method has engineering application value for the detection of goaf lacking actual measurement data or that caused by illegal mining. Full article

Coal-mining subsidence causes ground fissures and destroys surface structures, which may lead to severe casualties and economic losses. Time series interferometric synthetic aperture radar (TS-InSAR) plays an important role in surface deformation detection and monitoring without the restriction of weather and sunlight conditions. In addition, the probability integral method (PIM) is a surface movement model that is widely used in the field of mining subsidence. In recent years, the integration of TS-InSAR and the PIM has been extensively studied. In this paper, we propose a new method to estimate mining subsidence with the PIM based on TS-InSAR results. This study focuses on the improvement of a boundary constraint and dynamic parameter estimation in the PIM through the inversion of the line-of-sight (LOS) time series deformation derived by TS-InSAR. In addition, 45 Sentinel-1A images from 17 June 2015 to 27 December 2017 of a coal mine in Jiaozuo are utilized to acquire the surface displacement. We apply a time series deformation analysis using small baseline subsets (SBAS) and place the results into an improved PIM to estimate the mining parameters. The simulated mining subsidence is highly consistent with the leveling data, exhibiting an RMSE of 0.0025 m. Compared with the conventional method, the proposed method is more accurate in discovering displacement in mining areas. In the final section of this paper, some sources of error that affect the experiment are discussed. Full article

The determination of the depth and boundary of the goaf is of great significance for the detection of illegal mining. However, determining the current location of unknown goafs mainly relies on low-efficiency, time-consuming, and labor-intensive physical detection methods such as geomagnetic field changes. Due to their large coverage and high degree of automation, research on remote sensing methods has been conducted to locate mining activities by monitoring surface deformation. This paper proposes a method that relies on the principle of the probability integration method (PIM) and on synthetic aperture radar interferometry (InSAR) to retrieve the location of an underground goaf. First, the relationship between ground subsidence and the location of the mined-out area was established according to PIM; then, the location of the mined-out area was obtained by the surface deformation acquired by InSAR. The proposed method does not rely on complex nonlinear models and has complete parameters; therefore, it has higher engineering application value. A test site in the Fengfeng mining area and 11 Radarsat-2 images were used to verify the proposed method. The experimental results showed that the average relative error of the proposed method is 6.35%, which is 27.56% higher than that of similar algorithms based on complex nonlinear models. Compared to algorithms that ignore the coal seam dip, the accuracy is improved to 98.27%. Full article
