Search Results (21)

This paper presents a novel approach to determine dynamic safety and comfort zones in human–robot interactions (HRIs), with a focus on service robots operating in dynamic environments with people. The proposed proxemic model leverages the golden ratio-based comfort zone distribution and ISO safety standards to define adaptive proxemic boundaries for robots around humans. Unlike traditional fixed-threshold approaches, this novel method proposes a gradual and context-sensitive modulation of robot behaviour based on human position, orientation, and relative velocity. The system was implemented on an NVIDIA Jetson Xavier NX platform using a ZED 2i stereo depth camera Stereolabs, New York, USA and tested on two mobile robotic platforms: Go1 Unitree, Hangzhou, China (quadruped) and Scout Mini Agilex, Dongguan, China (wheeled). The initial verification of proposed proxemic model through experimental comfort validation was conducted using two simple interaction scenarios, and subjective feedback was collected from participants using a modified Godspeed Questionnaire Series. The results show that the participants felt comfortable during the experiments with robots. This acceptance of the proposed methodology plays an initial role in supporting further research of the methodology. The proposed solution also facilitates integration into existing navigation frameworks and opens pathways towards socially aware robotic systems. Full article

Quadruped robots have shown significant potential in disaster relief applications, where they have to navigate complex terrains for search and rescue or reconnaissance operations. However, their deployment is hindered by limited adaptability in highly uncertain environments, especially when relying solely on vision-based sensors like cameras or LiDAR, which are susceptible to occlusions, poor lighting, and environmental interference. To address these limitations, this paper proposes a novel sensor-enhanced hierarchical switching model predictive control (MPC) framework that integrates proprioceptive sensing with a bi-level hybrid dynamic model. Unlike existing methods that either rely on handcrafted controllers or deep learning-based control pipelines, our approach introduces three core innovations: (1) a situation-aware, bi-level hybrid dynamic modeling strategy that hierarchically combines single-body rigid dynamics with distributed multi-body dynamics for modeling agility and scalability; (2) a three-layer hybrid control framework, including a terrain-aware switching MPC layer, a distributed torque controller, and a fast PD control loop for enhanced robustness during contact transitions; and (3) a multi-IMU-based proprioceptive feedback mechanism for terrain classification and adaptive gait control under sensor-occluded or GPS-denied environments. Together, these components form a unified and computationally efficient control scheme that addresses practical challenges such as limited onboard processing, unstructured terrain, and environmental uncertainty. A series of experimental results demonstrate that the proposed method outperforms existing vision- and learning-based controllers in terms of stability, adaptability, and control efficiency during high-speed locomotion over irregular terrain. Full article

Reliable wireless communication is essential for mobile robotic systems operating in dynamic environments, particularly in the context of smart mobility and cloud-integrated urban infrastructures. This article presents an experimental study analyzing the impact of robot motion dynamics on wireless network performance, contributing to the broader discussion on data reliability and communication efficiency in intelligent transportation systems. Measurements were conducted using a quadruped robot equipped with an onboard edge computing device, navigating predefined trajectories in a laboratory setting designed to emulate real-world variability. Key wireless parameters, including signal strength (RSSI), latency, and packet loss, were continuously monitored alongside robot kinematic data such as speed, orientation (roll, pitch, yaw), and movement patterns. The results show a significant correlation between dynamic motion—especially high forward velocities and rotational maneuvers—and degradations in network performance. Increased robot speeds and frequent orientation changes were associated with elevated latency and greater packet loss, while static or low-motion periods exhibited more stable communication. These findings highlight critical challenges for real-time data transmission in mobile IoRT (Internet of Robotic Things) systems, and emphasize the role of network-aware robotic behavior, interoperable communication protocols, and edge-to-cloud data integration in ensuring robust wireless performance within smart city environments. Full article

Quadruped robots have emerged as a prominent field of research due to their exceptional mobility and adaptability in complex terrains. This paper presents an overview of quadruped robots, encompassing their design principles, control mechanisms, perception systems, and applications across various industries. We review the historical evolution and technological milestones that have shaped quadruped robotics. To understand their impact on performance and functionality, key aspects of mechanical design are analyzed, including leg configurations, actuation systems, and material selection. Control strategies for locomotion, balance, and navigation are all examined, highlighting the integration of artificial intelligence and machine learning to enhance adaptability and autonomy. This review also explores perception and sensing technologies that enable environmental interaction and decision-making capabilities. Furthermore, we systematically examine the diverse applications of quadruped robots in sectors including the military, search and rescue, industrial inspection, agriculture, and entertainment. Finally, we address challenges and limitations, including technical hurdles, ethical considerations, and regulatory issues, and propose future research directions to advance the field. By structuring this review as a systematic study, we ensure clarity and a comprehensive understanding of the domain, making it a valuable resource for researchers and engineers in quadruped robotics. Full article

Acquiring terrain information during robot locomotion is essential for autonomous navigation, gait selection, and trajectory planning. Quadruped robots, due to their biomimetic structures, demonstrate enhanced traversability over complex terrains compared to other robotic platforms. Furthermore, the internal sensors of quadruped robots acquire rich terrain-related data during locomotion across diverse terrains. This study investigates the relationship between terrain characteristics and quadruped robots based on proprioception sensor data, and proposes a simple, efficient, and motion-independent terrain classification method by integrating multiple sensor signals. The sensors referred to in the text only include the IMU sensor and joint encoders, which means that the method has a wide range of applicability while requiring sufficiently low hardware cost. The Convolutional Neural Network will serve as the backbone of the algorithm. In addition, the control command about its own control information will serve as supporting information to eliminate the impact of motion patterns on the results. Employing a multi-label classification algorithm, the complex terrains are classified by multiple physical feature labels like roughness, slippage, softness, and slope, which depict terrain attributes. A feature-labeled terrain dataset is established by abstracting diverse terrain features across various terrains. Unlike semantic labels (e.g., grassland, sand, gravel) that are comprehensible only to humans, feature labels provide a more helpful and precise terrain characterization, including broader terrain attributes. Full article

Radiation mapping is a desirable task to automate because of the inherent risks involved and its tedious nature. A novel system was designed to address this by combining various existing technologies, utilizing behavior-based robotics and Bayesian optimization. The system uses a quadruped robot equipped with a manipulator and gamma detector to take measurements at locations that are selected based on the uncertainty of a surrogate model used to estimate the true radiation field. The robot uses input from the world with depth cameras to avoid collisions with the robot’s body, and unreachable points for the end effector are addressed by both allowing for a soft collision with the environment to occur, prompting the system to abandon that point, and varying the exploration tendency of the optimization based on consecutive collisions. This approach provides unique traversability and adaptability over other strategies in the literature. Experiments were performed by placing a Cesium-137 source on the ground and varying geometric setups and an optimization parameter demonstrating the adaptability to diverse environments and the increased robustness resulting from the designed behavior. The results additionally demonstrate that dynamically adjusting the optimization algorithm’s exploration tendency based on the arm’s collision history improves the system’s ability to navigate cluttered environments and construct accurate radiation maps without getting stuck in unreachable areas. Full article

With the rapid development of robotics technology, quadruped robots have shown significant potential in navigating complex terrains due to their excellent stability and adaptability. This paper proposes an adaptive dynamic programming control method based on policy iteration, aimed at improving the motion performance and autonomous adaptability of parallel quadruped robots in unknown environments. First, the study establishes a kinematic model of the robot and performs inverse kinematics calculations to determine the angular functions for each joint of the robot’s legs. To improve the robot’s mobility on challenging terrains, we design an optimal tracking controller based on Generalized Policy Iteration (GPI). This approach reduces the model’s dependency on strict requirements and is applied to the control of quadruped robots. Finally, kinematic simulations are conducted based on pre-planned robot gaits. In addition, experiments are then conducted based on the simulation results. The results of simulation experiments indicate that the quadruped robot, under the adaptive optimal control algorithm, can achieve smooth walking on complex terrains, verifying the rationality and effectiveness of the parallel quadruped robot in handling such conditions. The experimental results further demonstrate that this strategy significantly improves the stability and robustness of the robot across various terrains. Full article

This article delineates the enhancement of an autonomous navigation and obstacle avoidance system for a quadruped robot dog. Part one of this paper presents the integration of a sophisticated multi-level dynamic control framework, utilizing Model Predictive Control (MPC) and Whole-Body Control (WBC) from MIT Cheetah. The system employs an Intel RealSense D435i depth camera for depth vision-based navigation, which enables high-fidelity 3D environmental mapping and real-time path planning. A significant innovation is the customization of the EGO-Planner to optimize trajectory planning in dynamically changing terrains, coupled with the implementation of a multi-body dynamics model that significantly improves the robot’s stability and maneuverability across various surfaces. The experimental results show that the RGB-D system exhibits superior velocity stability and trajectory accuracy to the SLAM system, with a 20% reduction in the cumulative velocity error and a 10% improvement in path tracking precision. The experimental results also show that the RGB-D system achieves smoother navigation, requiring 15% fewer iterations for path planning, and a 30% faster success rate recovery in challenging environments. The successful application of these technologies in simulated urban disaster scenarios suggests promising future applications in emergency response and complex urban environments. Part two of this paper presents the development of a robust path planning algorithm for a robot dog on a rough terrain based on attached binocular vision navigation. We use a commercial-of-the-shelf (COTS) robot dog. An optical CCD binocular vision dynamic tracking system is used to provide environment information. Likewise, the pose and posture of the robot dog are obtained from the robot’s own sensors, and a kinematics model is established. Then, a binocular vision tracking method is developed to determine the optimal path, provide a proposal (commands to actuators) of the position and posture of the bionic robot, and achieve stable motion on tough terrains. The terrain is assumed to be a gentle uneven terrain to begin with and subsequently proceeds to a more rough surface. This work consists of four steps: (1) pose and position data are acquired from the robot dog’s own inertial sensors, (2) terrain and environment information is input from onboard cameras, (3) information is fused (integrated), and (4) path planning and motion control proposals are made. Ultimately, this work provides a robust framework for future developments in the vision-based navigation and control of quadruped robots, offering potential solutions for navigating complex and dynamic terrains. Full article

Continuous accurate positioning in global navigation satellite system (GNSS)-denied environments is essential for robot navigation. Significant advances have been made with light detection and ranging (LiDAR)-inertial measurement unit (IMU) techniques, especially in challenging environments with varying lighting and other complexities. However, the LiDAR/IMU method relies on a recursive positioning principle, resulting in the gradual accumulation and dispersion of errors over time. To address these challenges, this study proposes a tightly coupled LiDAR/IMU/UWB fusion approach that integrates an ultra-wideband (UWB) positioning technique. First, a lightweight point cloud segmentation and constraint algorithm is designed to minimize elevation errors and reduce computational demands. Second, a multi-decision non-line-of-sight (NLOS) recognition module using information entropy is employed to mitigate NLOS errors. Finally, a tightly coupled framework via a resilient mechanism is proposed to achieve reliable position estimation for quadruped robots. Experimental results demonstrate that our system provides robust positioning results even in LiDAR-limited and NLOS conditions, maintaining low time costs. Full article

Walking robots have been widely applied in complex terrains due to their good terrain adaptability and trafficability. However, in some environments (such as disaster relief, field navigation, etc.), although a single strategy can adapt to various environments, it is unable to strike a balance between speed and stability. Existing control schemes like model predictive control (MPC) and traditional incremental control can manage certain environments. However, they often cannot balance speed and stability well. These methods usually rely on a single strategy and lack adaptability for dynamic adjustment to different terrains. To address this limitation, this paper proposes an innovative double-layer reinforcement learning algorithm. This algorithm combines Deep Double Q-Network (DDQN) and Proximal Policy Optimization (PPO), leveraging their complementary strengths to achieve both fast adaptation and high stability in complex terrains. This algorithm utilizes terrain information and the robot’s state as observations, determines the walking speed command of the quadruped robot Unitree Go1 through DDQN, and dynamically adjusts the current walking speed in complex terrains based on the robot action control system of PPO. The speed command serves as a crucial link between the robot’s perception and movement, guiding how fast the robot should walk depending on the environment and its internal state. By using DDQN, the algorithm ensures that the robot can set an appropriate speed based on what it observes, such as changes in terrain or obstacles. PPO then executes this speed, allowing the robot to navigate in real time over difficult or uneven surfaces, ensuring smooth and stable movement. Then, the proposed model is verified in detail in Isaac Gym. Wecompare the distances walked by the robot using six different control methods within 10 s. The experimental results indicate that the method proposed in this paper demonstrates excellent speed adjustment ability in complex terrains. On the designed test route, the quadruped robot Unitree Go1 can not only maintain a high walking speed but also maintain a high degree of stability when switching between different terrains. Ouralgorithm helps the robot walk 25.5 m in 10 s, outperforming other methods. Full article

Despite advancements in creating barrier-free environments, many buildings still have stairs, making accessibility a significant concern for wheelchair users, the majority of whom check for accessibility information before venturing out. This paper focuses on developing a transformable quadruped wheelchair to address the mobility challenges posed by stairs and steps for wheelchair users. The wheelchair, inspired by the Unitree B2 quadruped robot, combines wheels for flat surfaces and robotic legs for navigating stairs and is equipped with advanced sensors and force detectors to interact with its surroundings effectively. This research utilized reinforcement learning, specifically curriculum learning, to teach the wheelchair stair-climbing skills, with progressively increasing complexity in a simulated environment crafted in the Unity game engine. The experiments demonstrated high success rates in both stair ascent and descent, showcasing the wheelchair’s potential in overcoming mobility barriers. However, the current model faces limitations in tackling various stair types, like spiral staircases, and requires further enhancements in safety and stability, particularly in the descending phase. The project illustrates a significant step towards enhancing mobility for wheelchair users, aiming to broaden their access to diverse environments. Continued improvements and testing are essential to ensure the wheelchair’s adaptability and safety across different terrains and situations, underlining the ongoing commitment to technological innovation in aiding individuals with mobility impairments. Full article

Autonomous legged navigation in unstructured environments is still an open problem which requires the ability of an intelligent agent to detect and react to potential obstacles found in its area. These obstacles may range from vehicles, pedestrians, or immovable objects in a structured environment, like in highway or city navigation, to unpredictable static and dynamic obstacles in the case of navigating in an unstructured environment, such as a forest road. The latter scenario is usually more difficult to handle, due to the higher unpredictability. In this paper, we propose a vision dynamics approach to the path planning and navigation problem for a quadruped robot, which navigates in an unstructured environment, more specifically on a forest road. Our vision dynamics approach is based on a recurrent neural network that uses an RGB-D sensor as its source of data, constructing sequences of previous depth sensor observations and predicting future observations over a finite time span. We compare our approach with other state-of-the-art methods in obstacle-driven path planning algorithms and perform ablation studies to analyze the impact of architectural changes to our model components, demonstrating that our approach achieves superior performance in terms of successfully generating collision-free trajectories for the intelligent agent. Full article

This paper provides an initial investigation of quadruped rotary galloping gait patterns using data from racing greyhounds as they navigate their way around a constant radius bend. This study reviewed actual race data collected over a five month period from 2986 racing greyhounds. Using numerical dynamics modelling and value range analysis important factors were identified and analysed. By cleaning and synthesising simple X and Y data and also processing data for accuracy greyhound motion path dynamics results were produced for analysis. The results show that the galloping path greyhounds took going into the bend was different from the path coming out of the bend. It also shows that more than 50% of the greyhounds naturally optimised their path for a longer transition while minimising jerk when entering and exiting the bend. This research verified that individual greyhounds naturally chose different path transition lengths for accommodating their dynamic conditions. Finally, it was found that the greyhound galloping path dynamics state is less intense during the second half of the bend. Full article

Quadruped robots have garnered significant attention in recent years due to their ability to navigate through challenging terrains. Among the various environments, agriculture fields are particularly difficult for legged robots, given the variability of soil types and conditions. To address this issue, this study proposes a novel navigation strategy that utilizes ground reaction forces to calculate online artificial potential fields, which are then applied to the robot’s feet to avoid low-traversability regions. The strategy also incorporates the net vector of the attractive potential field towards the goal and the repulsive field to avoid slippery regions, which dynamically adjusts the quadruped’s gait. A realistic simulation environment validates the proposed navigation framework with case studies on randomly generated terrains. A comprehensive comparison with baseline navigation methods is conducted to assess the effectiveness of the proposed approach. Full article

In scenarios with insufficient structural features, LiDAR-based SLAM may suffer from degeneracy, resulting in impaired robot localization and mapping and potentially leading to subsequent deviant navigation tasks. Therefore, it is crucial to develop advanced algorithms and techniques to mitigate the degeneracy issue and ensure the robustness and accuracy of LiDAR-based SLAM. This paper presents a LiDAR–inertial simultaneous localization and mapping (SLAM) method based on a virtual inertial navigation system (VINS) to address the issue of degeneracy. We classified different gaits and match each gait to its corresponding torso inertial measurement unit (IMU) sensor to construct virtual foot inertial navigation components. By combining an inertial navigation system (INS) with zero-velocity updates (ZUPTs), we formed the VINS to achieve real-time estimation and correction. Finally, the corrected pose estimation was input to the IMU odometry calculation procedure to further refine the localization and mapping results. To evaluate the effectiveness of our proposed VINS method in degenerate environments, we conducted experiments in three typical scenarios. The results demonstrate the high suitability and accuracy of the proposed method in degenerate scenes and show an improvement in the point clouds mapping effect. The algorithm’s versatility is emphasized by its wide applicability on GPU platforms, including quadruped robots and human wearable devices. This broader potential range of applications extends to other related fields such as autonomous driving. Full article
