Search Results (21)

A wide-bandgap AgInGaSe₂ (AIGS) thin film was fabricated using molecular beam epitaxy (MBE) via a three-stage method. The influence of Selenium (Se) pressure on the properties of AIGS films and solar cells was studied in detail. It was found that Se pressure played a very important role during the fabrication process, whereby Se pressure was varied from 0.8 × 10⁻³ Torr to 2.5 × 10⁻³ Torr in order to specify the effect of Se pressure. A two-stage mechanism during the production of AIGS solar cells was concluded according to the experimental results. With an increase in Se pressure, the grain size significantly increased due to the supply of the Ag–Se phase; the superficial roughness also increased. When Se pressure was increased to 2.1 × 10⁻³ Torr, the morphology of AIGS changed abruptly and clear grain boundaries were observed with a typical grain size of over 1.5 μm. AIGS films fabricated with a low Se pressure tended to show a higher bandgap due to the formation of anti-site defects such as In and Ga on Ag sites as a result of the insufficient Ag–Se phase. With an increase in Se pressure, the crystallinity of the AIGS film changed from the (220)-orientation to the (112)-orientation. When Se pressure was 2.1 × 10⁻³ Torr, the AIGS solar cell demonstrated its best performance of about 9.6% (Voc: 810.2 mV; Jsc: 16.7 mA/cm²; FF: 71.1%) with an area of 0.2 cm². Full article

The recent focus on wide-bandgap absorbers for tandem solar cell configurations and photovoltaic materials with high absorption coefficients for indoor photovoltaics has prompted a renewed interest in selenium. Over the past few years, the efficiency of Se solar cells has improved significantly, bringing the prospect of industrial production closer to reality. This study presents an innovative vapor transport deposition (VTD) technique for the scalable and cost-effective fabrication of Se thin films. The prepared Se thin films were characterized, and the results show that the VTD method is capable of producing dense and well-crystallized Se thin films. Se solar cells with a structure of glass/FTO/TiO₂/Se/Au were fabricated to evaluate the impact of substrate temperature on device performance. The optimal performance was achieved on the hot side of the substrate during deposition, with a power conversion efficiency (PCE) of 2.56%. This study provides a promising pathway for the low-cost, high-throughput manufacturing of high-performance Se solar cells, facilitating their potential industrial implementation. Full article

Thin-film solar cells (TFSCs) represent a promising frontier in renewable energy technologies due to their potential for cost reduction, material efficiency, and adaptability. This literature review examines the key materials and advancements that make up TFSC technologies, with a focus on Cu(In,Ga)Se₂ (CIGS), cadmium telluride (CdTe), and Cu₂ZnSnS₄ (CZTS) and its sulfo-selenide counterpart Cu₂ZnSn(S,Se)₄ (CZTSSe). Each material’s unique properties—including tuneable bandgaps, high absorption coefficients, and low-cost scalability—make them viable candidates for a wide range of applications, from building-integrated photovoltaics (BIPV) to portable energy solutions. This review explores recent progress in the enhancement of power conversion efficiency (PCE), particularly through bandgap engineering, alkali metal doping, and interface optimization. Key innovations such as silver (Ag) alloying in CIGS, selenium (Se) alloying in CdTe, and sulfur (S) to Se ratio optimization in CZTSSe have driven PCE improvements and expanded the range of practical uses. Additionally, the adaptability of TFSCs for roll-to-roll manufacturing on flexible substrates has further cemented their role in advancing renewable energy adoption. Challenges remain, including environmental concerns, but ongoing research addresses these limitations, paving the way for TFSCs to become a crucial technology for transitioning to sustainable energy systems. Full article

Thieno[3,2-b]thiophenes are used as key components in optoelectronic materials, porous hydrogen-storage hosts, organic solar cells, and polymer semiconductors. A step-efficient synthetic protocol was proposed herein for obtaining multisubstituted thieno[3,2-b]thiophene and selenopheno[3,2-b]selenophenes in moderate to good yields via the bisulfur/biselenium cyclization of alkynyl diols with I₂/Na₂S₂O₃ or selenium. Using this strategy, substitution patterns were obtained for backbone modification in functional materials. Full article

Perovskite solar cells (PSCs) have been on the forefront of advanced research for over a decade, achieving constantly increasing power conversion efficiencies (PCEs), while their route towards commercialization is currently under intensive progress. Towards this target, there has been a turn to PSCs that employ a carbon electrode (C-PSCs) for the elimination of metal back contacts, which increase the cost of corresponding devices while at the same time have a severe impact on their stability. Chalcogenides are chemical compounds that contain at least one chalcogen element, typically sulfur (S), selenium (Se), or tellurium (Te), combined with one metallic element. They possess semiconducting properties and have been proven to have beneficial effects when incorporated in a variety of solar cell types, including dye sensitized solar cells (DSSCs), quantum dot sensitized solar cells (QDSSCs), and Organic Solar Cells (OSCs), either as interlayers or added in the active layers. Currently, an increasing number of studies have highlighted their potential for achieving high-performing and stable PSCs. In this review, the most promising results of the latest studies regarding the implementation of chalcogenides in PSCs with a carbon electrode are presented and discussed, merging two research trends that are currently on the spotlight of solar cell technology. Full article

Femtosecond-laser-fabricated black silicon has been widely used in the fields of solar cells, photodetectors, semiconductor devices, optical coatings, and quantum computing. However, the responsive spectral range limits its application in the near- to mid-infrared wavelengths. To further increase the optical responsivity in longer wavelengths, in this work, silicon (Si) was co-hyperdoped with nitrogen (N) and selenium (Se) through the deposition of Se films on Si followed by femtosecond (fs)-laser irradiation in an atmosphere of NF₃. The optical and crystalline properties of the Si:N/Se were found to be influenced by the precursor Se film and laser fluence. The resulting photodetector, a product of this innovative approach, exhibited an impressive responsivity of 24.8 A/W at 840 nm and 19.8 A/W at 1060 nm, surpassing photodetectors made from Si:N, Si:S, and Si:S/Se (the latter two fabricated in SF6). These findings underscore the co-hyperdoping method’s potential in significantly improving optoelectronic device performance. Full article

The development of kesterite (Cu₂ZnSn(S,Se)₄, CZTSSe) thin films for photovoltaic applications is highly necessary, given their composition of Earth-abundant, environmentally friendly elements and their compatibility with established photovoltaic technologies. This study presents a novel synthesis approach for CZTSSe films with varied S/(S+Se) ratios, ranging from 0.83 to 0.44, by a two-step magnetron sputtering deposition/annealing process. The first step consists in an initial deposition of stacked Mo/SnS₂/Cu layers, which, upon thermal treatment in a sulfur atmosphere, were transformed into Cu₂SnS₃ (CTS) films. In the second step, further deposition of ZnSe and subsequent annealing in a tin and selenium atmosphere resulted in the formation of a CZTSSe phase. These processes were optimized to fabricate high-quality and single-phase CZTSSe films, thereby mitigating the formation of secondary phases. Characterization techniques, including scanning electron microscopy, demonstrated a clear correlation between decreased S/(S+Se) ratios and enhanced film densification and grain size. Moreover, grazing incidence X-ray diffraction and Raman spectroscopy confirmed a compositional and structural transition from close to CZTS to nearly a CZTSe phase as the S/(S+Se) ratios decreased. This study advances kesterite-based solar cell technology by enhancing the structural properties and crystallinity of the absorber layer, necessary for improving photovoltaic performance. Full article

In this study, a feasible strategy is proposed for directly depositing high-quality Cu(In,Ga)Se₂ (CIGS) films using Na-doped targets in a selenium-free atmosphere to boost the power conversion efficiency (PCE) of CIGS solar cells. Introducing a small amount of sodium dopant effectively promoted the textured growth of CIGS crystals in the prepared films, resulting in larger grain sizes and a smoother interface. The higher MoSe₂ content at the CIGS/Mo interface increased the carrier lifetime in the films. In addition, sodium doping increased the proportion of Se atoms on the film surface and reduced the concentration of defects caused by the direct sputtering of the films in the selenium-free atmosphere. Therefore, the separation and transportation of photo-generated carriers in the devices were effectively enhanced. Using the optimized parameters, a record-high PCE of 17.26% was achieved for the 7.5% Na-doped devices, which represents an improvement of nearly 63%. Full article

Solar cells can be designed for indoor applications to provide a feasible solution for harnessing photon energy from indoor lighting. In this paper, we analyze the suitability of a selenium-based solar cell for gathering photon energy emitted by indoor light-emitting diodes (LEDs). The absorption band of selenium (Se) is found to be aligned with the LED spectrum, making it a promising contender for efficient indoor applications. In order to simulate the Se-based photovoltaic (PV) device, we started by calibrating the simulation model against a fabricated Se cell that was tested under AM1.5G. After the verification of the physical models and the technological key factors of the different layers incorporated in cell design, a systematic approach was performed to assess the operation of the Se solar cell under an LED light environment. We show an optimized power conversion efficiency (PCE) of 26.93% for the Se-based cell under LED illumination (311 μW/cm²). This is achieved by providing an effective design that incorporates a double-ETL structure, which can significantly improve the band alignment between the different layers of the cell device. The simulation results presented in this work serve to judge the potential of Se solar cells as indoor PVs and offer an approach for providing indoor use specifically designed for internet-of-things (IoT) devices. Full article

Due to the low cost, light weight, semitransparency, good flexibility, and large manufacturing area of organic solar cells (OSCs), OSCs have the opportunity to become the next generation of solar cells in some specific applications. So far, the efficiency of the OSC device has been improved by more than 20%. The optical band gap between the lowest unoccupied molecular orbital (LUMO) level and the highest occupied molecular orbital (HOMO) level is an important factor affecting the performance of the device. Selenophene, a derivative of aromatic pentacyclic thiophene, is easy to polarize, its LUMO energy level is very low, and hence the optical band gap can be reduced. In addition, the selenium atoms in selenophene and other oxygen atoms or sulfur atoms can form an intermolecular interaction, so as to improve the stacking order of the active layer blend film and improve the carrier transport efficiency. This paper introduces the organic solar active layer materials containing selenium benzene in recent years, which can be simply divided into donor materials and acceptor materials. Replacing sulfur atoms with selenium atoms in these materials can effectively reduce the corresponding optical band gap of materials, improve the mutual solubility of donor recipient materials, and ultimately improve the device efficiency. Therefore, the sulfur in thiophene can be completely replaced by selenium or oxygen of the same family, which can be used in the active layer materials of organic solar cells. This article mainly describes the application of selenium instead of sulfur in OSCs. Full article

Solar energy applications rely heavily on p-block elements and transition metals. Silicon is, by far, the most commonly used material in photovoltaic cells and accounts for about 85% of modules sold presently. Of late, thin film photovoltaic cells have gained momentum because of their higher efficiencies. Most of these thin film devices are made out of just five elements, namely, cadmium, tellurium, selenium, indium, gallium and copper. The present manuscript describes an elegant and inexpensive molten salt-based electrolytic process for fabricating a tellurium-coated metallic substrate. A three-electrode set up was employed to coat iridium with tellurium from a molten bath containing lithium chloride, lithium oxide and tellurium tetrachloride (LiCl-Li₂O-TeCl₄) at 650 °C for a duration ranging from 30 to 120 min under a galvanostatic mode. The tellurium coating was observed to be thick, uniform, smooth and homogeneous. Additionally, the deposited tellurium did not chemically react with the iridium substrate to form intermetallic compounds, which is a good feature from the standpoint of the device’s performance characteristics. The present process, being generic in nature, shows the potential for the manufacture of both the coated substates and high-purity elements not just for tellurium but also for other p-block elements. Full article

Organic photovoltaic (OPV) solar cells represent an emerging and promising solution for low-cost clean energy production. Being flexible and semi-transparent and having significant advantages over conventional PV technologies, OPV modules represent an innovative solution even in applications that cannot be based on traditional PV systems. However, relatively low efficiencies, poor long-term stability, and thermal issues have so far prevented the commercialization of this technology. This paper describes two outdoor experimental campaigns that compared the operation of OPV modules with traditional PV modules—in particular crystalline silicon and copper–indium–selenium (CIS)—and assessed the OPV modules’ power generation potential in vertical installation and facing towards the cardinal directions. Full article

The highly xerotolerant bacterium classified as Exiguobacterium sp. Helios isolated from a solar panel in Spain showed a close relationship to Exiguobacterium sibiricum 255-15 isolated from Siberian permafrost. Xerotolerance has not been previously described as a characteristic of the extremely diverse Exiguobacterium genus, but both strains Helios and 255-15 showed higher xerotolerance than that described in the reference xerotolerant model strain Deinococcus radiodurans. Significant changes observed in the cell morphology after their desiccation suggests that the structure of cellular surface plays an important role in xerotolerance. Apart from its remarkable resistance to desiccation, Exiguobacterium sp. Helios strain shows several polyextremophilic characteristics that make it a promising chassis for biotechnological applications. Exiguobacterium sp. Helios cells produce nanoparticles of selenium in the presence of selenite linked to its resistance mechanism. Using the Lactobacillus plasmid pRCR12 that harbors a cherry marker, we have developed a transformation protocol for Exiguobacterium sp. Helios strain, being the first time that a bacterium of Exiguobacterium genus has been genetically modified. The comparison of Exiguobacterium sp. Helios and E. sibiricum 255-15 genomes revealed several interesting similarities and differences. Both strains contain a complete set of competence-related DNA transformation genes, suggesting that they might have natural competence, and an incomplete set of genes involved in sporulation; moreover, these strains not produce spores, suggesting that these genes might be involved in xerotolerance. Full article

We are reporting on the impact of air annealing temperatures on the physicochemical properties of electrochemically synthesized cadmium selenium telluride (CdSe_0.6Te_0.4) samples for their application in a photoelectrochemical (PEC) solar cell. The CdSe_0.6Te_0.4 samples were characterized with several sophisticated techniques to understand their characteristic properties. The XRD results presented the pure phase formation of the ternary CdSe_0.6Te_0.4 nanocompound with a hexagonal crystal structure, indicating that the annealing temperature influences the XRD peak intensity. The XPS study confirmed the existence of Cd, Se, and Te elements, indicating the formation of ternary CdSe_0.6Te_0.4 compounds. The FE-SEM results showed that the morphological engineering of the CdSe_0.6Te_0.4 samples can be achieved simply by changing the annealing temperatures from 300 to 400 °C with intervals of 50 °C. The efficiencies (ƞ) of the CdSe_0.6Te_0.4 photoelectrodes were found to be 2.0% for the non-annealed and 3.1, 3.6, and 2.5% for the annealed at 300, 350, and 400 °C, respectively. Most interestingly, the PEC cell analysis indicated that the annealing temperatures played an important role in boosting the performance of the photoelectrochemical properties of the solar cells. Full article

Copper indium gallium sulfo-selenide (CIGS) based solar cells show the highest conversion efficiencies among all thin-film photovoltaic competition. However, the absorber material manufacturing is in most cases dependent on vacuum-technology like sputtering and evaporation, and the use of toxic and environmentally harmful substances like H₂Se. In this work, the goal to fabricate dense, coarse grained CuInSe₂ (CISe) thin-films with vacuum-free processing based on nanoparticle (NP) precursors was achieved. Bimetallic copper-indium, elemental selenium and binary selenide (Cu_2−xSe and In₂Se₃) NPs were synthesized by wet-chemical methods and dispersed in nontoxic solvents. Layer-stacks from these inks were printed on molybdenum coated float-glass-substrates via doctor-blading. During the temperature treatment, a face-to-face technique and mechanically applied pressure were used to transform the precursor-stacks into dense CuInSe₂ films. By combining liquid phase sintering and pressure sintering, and using a seeding layer later on, issues like high porosity, oxidation, or selenium- and indium-depletion were overcome. There was no need for external Se atmosphere or H₂Se gas, as all of the Se was directly in the precursor and could not leave the face-to-face sandwich. All thin-films were characterized with scanning electron microscopy (SEM), energy dispersive X-ray spectroscopy (EDX), X-ray diffraction (XRD), and UV/vis spectroscopy. Dense CISe layers with a thickness of about 2–3 µm and low band gap energies of 0.93–0.97 eV were formed in this work, which show potential to be used as a solar cell absorber. Full article
