Search Results (36)

Synthetic aperture radar (SAR) imaging is highly vulnerable to radio-frequency interference (RFI) in complex electromagnetic environments, which can introduce structured artifacts and obscure targets in single-look complex (SLC) products. Most existing suppression methods rely on separability along a single dimension or require interference-specific parameter tuning, limiting robustness under multidimensional coupling and strong scatterers. We propose a range-domain sliding-window local tensorization that rearranges SLC data into localized range–azimuth–block-index tensors to better expose multi-mode correlations. On this representation, an energy-guided tensor CUR low-rank projector is embedded into an alternating-projection scheme that alternates complex-valued soft-thresholding for the sparse scene-plus-noise term and CUR-based projection for the structured RFI term. The cleaned SLC image is obtained by de-tensorizing the estimated RFI component and subtracting it from the input SLC. Experiments on semi-synthetic data, where controlled RFI is superimposed on real SLC scenes, and on real Sentinel-1 SLC data containing RFI demonstrate improved Pearson correlation coefficient (PCC) and perceptual image quality while preserving target signatures and scene textures, particularly under strong interference and strong coupling. The proposed approach provides a practical SLC-domain RFI mitigation tool for post-focusing SAR products without requiring explicit interference parameterization. Full article

This study conducts a landslide deformation assessment in Tianshui, Gansu Province, on the Chinese Loess Plateau, utilizing the Small Baseline Subset InSAR (SBAS-InSAR) method integrated with velocity direction conversion and Z-score clustering. The Chinese Loess Plateau is one of the most landslide-prone regions in China due to frequent rains, strong topographical gradients and severe soil erosion. By constructing subsets of interferograms, SBAS-InSAR can mitigate the influence of decorrelation to a certain extent, making it a highly effective technique for monitoring regional surface deformation and identifying landslides. To overcome the limitations of the satellite’s one-dimensional Line-of-Sight (LOS) measurements and the challenge of distinguishing true landslide signals from noise, two optimization strategies were implemented. First, LOS velocities were projected onto the local steepest slope direction, assuming translational movement parallel to the slope. Second, a Z-score clustering algorithm was employed to aggregate measurement points with consistent kinematic signatures, enhancing identification robustness, with a slight trade-off in spatial completeness. Based on 205 Sentinel-1 Single-Look Complex (SLC) images acquired from 2014 to 2024, the integrated workflow identified 69 “active, very slow” and 63 “active, extremely slow” landslides. These results were validated through high-resolution historical optical imagery. Time series analysis reveals that creep deformation in this region is highly sensitive to seasonal rainfall patterns. This study demonstrates that the SBAS-InSAR post-processing framework provides a cost-effective, millimeter-scale solution for updating landslide inventories and supporting regional risk management and early warning systems in loess-covered terrains, with the exception of densely forested areas. Full article

Synthetic Aperture Radar (SAR) and Interferometric SAR (InSAR) techniques have received rapid advance in recent years, and the Multi-temporal InSAR (MT-InSAR) has been widely applied in various earth observations. Distributed scatterer (DS) InSAR is one of the most advanced MT-InSAR methods, and has overcome the limitation of the lack of enough measurement points in the low coherent regions for traditional methods. While the Joint-Scatterer InSAR (JS-InSAR) is the extension of DS InSAR method, which exploited the overall information of Joint Scatterers to carry out DS identification and phase optimization. And it can avoid the inaccuracy caused by the offset errors between scatterers in complex terrain areas. However, the intensive computation and low efficiency have severely restricted the application of JS-InSAR, especially when dealing with massive and long historical SAR images. As the sequential estimator has proven to successfully improve the efficiency of MT-InAR and obtain near-time deformation time series, in this work, we proposed the sequential-based JS-InSAR (S-JSInSAR) method with flexible batches. This method has adaptively divided large single look complex (SLC) stack into different batches with flexible number and certain overlaps. Then, the JS-InSAR processing is performed on each batch, respectively, and these estimated results are integrated into the final deformation time series based on the connection mode. Thus, S-JSInSAR can efficiently process large InSAR dataset, and mitigate the decorrelation effect caused by long temporal baselines. To demonstrate the effectiveness of the S-JSInSAR, a multi-year of 145 Sentinel-1 ascending SAR images in Tangshan, China, were collected to estimate the long deformation time series. And the results compared with other methods have shown the processing time has substantially decreased without the loss of deformation accuracy, and obtain deformation spatial distribution with more details in local regions, which have well validated the efficiency and reliability of the proposed method. Full article

Synthetic aperture radar (SAR) is often affected by other high-power electromagnetic devices during ground observation, which causes unintentional radio frequency interference (RFI) with the acquired echo, bringing adverse effects into data processing and image interpretation. When faced with the task of screening massive SAR data, there is an urgent need for the global perception and detection of interference. The existing RFI detection method usually only uses a single type of data for detection, ignoring the information association between the data at all levels of the real SAR product, resulting in some computational redundancy. Meanwhile, current deep learning-based algorithms are often unable to locate the range of RFI coverage in the azimuth direction. Therefore, a novel RFI processing framework from quick-looks to single-look complex (SLC) data and then to raw echo is proposed. We take the data of Sentinel-1 terrain observation with progressive scan (TOPS) mode as an example. By combining the statistics-assisted network with the sliding-window algorithm and the error-tolerant training strategy, it is possible to accurately detect and locate RFI in the quick looks of an SLC product. Then, through the analysis of the TOPSAR imaging principle, the position of the RFI in the SLC image is preliminarily confirmed. The possible distribution of the RFI in the corresponding raw echo is further inferred, which is one of the first attempts to use spaceborne SAR data to elucidate the RFI location mapping relationship between image data and raw echo. Compared with directly detecting all of the SLC data, the time for the proposed framework to determine the RFI distribution in the SLC data can be shortened by 53.526%. All the research in this paper is conducted on Sentinel-1 real data, which verify the feasibility and effectiveness of the proposed framework for radio frequency signals monitoring in advanced spaceborne SAR systems. Full article

This paper presents an advanced workflow for processing radar imagery stacks using Persistent Scatterer and Distributed Scatterer Interferometry (PSDS) to enhance spatial coherence and improve displacement detection accuracy. The workflow leverages Level 2 Coregistered Single Look Complex (L2-CSLC) images generated by the open-source COMPASS (Coregistered Multi-temporal Sar SLC) framework in combination with the Combined eigenvalue maximum likelihood Phase Linking (CPL) approach implemented in MiaplPy. Starting the analysis directly from Level 2 products offers a significant advantage to end-users, as they simplify processing by being pre-geocoded and ready for immediate analysis. Additionally, the open-source nature of the workflow and the use of L2-CSLC products simplify the processing pipeline, making it easier to distribute directly to users for practical applications in monitoring infrastructure stability in dynamic environments. The ISCE3-MiaplPy workflow is compared against ISCE2-MiaplPy and the European Ground Motion Service (EGMS) to assess its performance in detecting infrastructure deformations in dynamic environments, such as the Algeciras port. The results indicate that ISCE3-MiaplPy delivers denser measurements, albeit with increased noise, compared to its counterparts. This higher resolution enables a more detailed understanding of infrastructure stability and surface dynamics, which is critical for environments with ongoing human activity or natural forces. Full article

Flint Hall Farm in Godstone, Surrey, UK, is situated adjacent to the London Orbital Motorway, or M25, and contains several landslide systems which pose a significant geohazard risk to this critical infrastructure. The site has been routinely monitored by geotechnical engineers following a landslide that encroached onto the hard shoulder in December 2000; current in situ instrumentation includes inclinometers and piezoelectric sensors. Interferometric Synthetic Aperture Radar (InSAR) is an active remote sensing technique that can quantify millimetric rates of Earth surface and structural deformation, typically utilising satellite data, and is ideal for monitoring landslide movements. We have developed the hardware and software for an Unmanned Aerial Vehicle (UAV), or drone radar system, for improved operational flexibility and spatial–temporal resolutions in the InSAR data. The hardware payload includes an industrial-grade DJI drone, a high-performance Ettus Software Defined Radar (SDR), and custom Copper Clad Laminate (CCL) radar horn antennas. The software utilises Frequency Modulated Continuous Wave (FMCW) radar at 5.4 GHz for raw data collection and a Range Migration Algorithm (RMA) for focusing the data into a Single Look Complex (SLC) Synthetic Aperture Radar (SAR) image. We present the first SAR image acquired using the drone radar system at Flint Hall Farm, which provides an improved spatial resolution compared to satellite SAR. Discrete targets on the landslide slope, such as corner reflectors and the in situ instrumentation, are visible as bright pixels, with their size and positioning as expected; the surrounding grass and vegetation appear as natural speckles. Drone SAR imaging is an emerging field of research, given the necessary and recent technological advancements in drones and SDR processing power; as such, this is a novel achievement, with few authors demonstrating similar systems. Ongoing and future work includes repeat-pass SAR data collection and developing the InSAR processing chain for drone SAR data to provide meaningful deformation outputs for the landslides and other geotechnical hazards and infrastructure. Full article

With the flourishing development of deep learning, synthetic aperture radar (SAR) ship detection based on this method has been widely applied across various domains. However, most deep-learning-based detection methods currently only use the amplitude information from SAR images. In fact, phase information and time-frequency features can also play a role in ship detection. Additionally, the background noise and the small size of ships also pose challenges to detection. Finally, satellite-based detection requires the model to be lightweight and capable of real-time processing. To address these difficulties, we propose a multi-domain joint SAR ship detection method that integrates complex information with deep learning. Based on the imaging mechanism of line-by-line scanning, we can first confirm the presence of ships within echo returns in the eigen-subspace domain, which can reduce detection time. Benefiting from the complex information of single-look complex (SLC) SAR images, we transform the echo returns containing ships into the time-frequency domain. In the time-frequency domain, ships exhibit distinctive features that are different from noise, without the limitation of size, which is highly advantageous for detection. Therefore, we constructed a time-frequency SAR image dataset (TFSID) using the images in the time-frequency domain, and utilizing the advantages of this dataset, we combined space-to-depth convolution (SPDConv) and Inception depthwise convolution (InceptionDWConv) to propose Efficient SPD-InceptionDWConv (ESIDConv). Using this module as the core, we proposed a lightweight SAR ship detector (LSDet) based on YOLOv5n. The detector achieves a detection accuracy of 99.5 with only 0.3 M parameters and 1.2 G operations on the dataset. Extensive experiments on different datasets demonstrated the superiority and effectiveness of our proposed method. Full article

In this study, we investigate the usefulness of the spectral whitening procedure, devised by one of the authors as a preprocessing stage of envelope-detected single-look synthetic aperture radar (SAR) images, in application contexts where phase information is relevant. In the first experiment, each of the raw datasets of an interferometric pair of COSMO-SkyMed images, representing industrial buildings amidst vegetated areas, was individually (1) synthesized by the SAR processor without Fourier-domain Hamming windowing; (2) synthesized with Hamming windowing, used to improve the focalization of targets, with the drawback of spatially correlating speckle; and (3) processed for the whitening of complex speckle, using the data obtained in (2). The interferograms were produced in the three cases, and interferometric coherence and phase maps were calculated through 3 × 3 boxcar filtering. In (1), coherence is low on vegetation; the presence of high sidelobes in the system’s point-spread function (PSF) causes the spread of areas featuring high backscattering. In (2), point targets and buildings are better defined, thanks to the sidelobe suppression achieved by the frequency windowing, but the background coherence is abnormally increased because of the spatial correlation introduced by the Hamming window. Case (3) is the most favorable because the whitening operation results in low coherence in vegetation and high coherence in buildings, where the effects of windowing are preserved. An analysis of the phase map reveals that (3) is likely to be facilitated also in terms of unwrapping. Results are presented on a TerraSAR-X/TanDEM-X (TSX-TDX) image pair by processing the interferograms of original and whitened data using a non-local filter. The main results are as follows: (1) with autocorrelated speckle, the estimation error of coherence may attain 16% and inversely depends on the heterogeneity of the scene; and (2) the cleanness and accuracy of the phase are increased by the preliminary whitening stage, as witnessed by the number of residues, reduced by 24%. Benefits are also expected not only for differential InSAR (DInSAR) but also for any coherent analysis and processing carried out performed on SLC data. Full article

The article addresses anthropogenic and geological conditions related to the development of soil subsidence in the western zone of Recife (Brazil). Over the past 50 years, human activity has intensified in areas previously affected by soft soils (clay, silt, and sandstone) resulting in subsidence due to additional loads (landfills and constructions). The duration of the settlement process can be significantly influenced by the specific characteristics of the soil composition and geological conditions of the location. This work presents, for the first time, accurate InSAR time series maps that describe the spatial pattern and temporal evolution of the settlement, as well as the correlation with the geological profile, and validation with Global Navigation Satellite System (GNSS) data. Persistent Scatterer Interferometry (PS-InSAR) was employed in the analysis of Single Look Complex (SLC) images generated by 100 ascending COSMO-SkyMed (CSK) and 65 PAZ (32 ascending, and 33 descending) from the X-band, along with 135 descending Sentinel-1 (S1) acquisitions from the C-band. These data were acquired over the period from 2011 to 2023. The occurrence of subsidence was identified in several locations within the western region, with the most significant displacement rates observed in the northern, central, and southern areas. In the northern region, the displacement rates were estimated to be approximately −20 mm/year, with the Várzea and Caxangá neighborhoods exhibiting the highest rates. In the central region, the displacement rates were estimated to be approximately −15 mm/year, with the Engenho do Meio, Cordeiro, Torrões, and San Martin neighborhoods exhibiting the highest rates. Finally, in the southern region, the displacement rates were estimated to be up to −25 mm/year, with the Caçote, Ibura, and Ipsep neighborhoods exhibiting the highest rates. Additionally, east–west movements were observed, with velocities reaching up to −7 mm/year toward the west. These movements are related to the lowering of the land. The study highlights that anthropogenic effects in the western zone of Recife contribute to the region’s vulnerability to soil subsidence. Full article

Operational applications for Synthetic Aperture Radar (SAR) are under development around the world, driven by the free-and-open access of SAR C-band observations that Sentinel-1 of Copernicus has provided since 2014. Radiometric Terrain Correction (RTC) data are key entry-level products for multiple applications ranging from ecosystem to hazard monitoring. Various open-source software packages exist to create RTC products from Single Look Complex (SLC) or Ground Range Detected (GRD) level SAR data, including the Interferometric SAR Computing Environment (ISCE), and the Sentinel-1 Toolbox from the European Space Agency (SNAP 8). Despite the growing availability of RTC software solutions, little work has been performed to identify differences between RTC products generated using different software packages. This work evaluates several Sentinel-1 RTC products and two other Sentinel-1 Analysis Ready Data (ARD) to address the following questions: (1) Which software provides the most accurate RTC product? and (2) how appropriate for analysis are other non-RTC products that are readily available? The RTCs are produced with GAMMA, ISCE-2, and SNAP 8. The other two ARD products evaluated consisted of an angular-based radiometric slope correction produced in Google Earth Engine (GEE) following Vollrath et al., and the Sentinel-1 GRD product. Products are evaluated across 10 sites in a single image approach for (1) radiometric calibration, (2) geometric corrections, and for (3) geolocation quality. In addition, time-series stacks over two sites representing varied terrain and ecosystems are evaluated. The GAMMA-derived RTC product implemented by the Alaska Satellite Facility (ASF) is used as a reference for some of the time-series metrics. The results provide direct guidance and recommendations about the quality of the RTC and ARD products obtained from open source methods. The results indicate that it is not recommended to use the GRD product with no radiometric or geometric corrections for any applications given low performance in multiple metrics. The radiometric calibration and geometric corrections have overall good performance for all open-source solutions, only the non-RTC products (Vollrath et al. and GRD) portray some significant variances in steep terrain. The geolocation assessment indicated that the GRD product has the most significant displacement errors, followed by SNAP 8 with Digital Elevation Model (DEM) matching, and ISCE-2. RTCs created without DEM-matching performed better for both GAMMA and SNAP 8. The time-series results indicate that SNAP 8 products align more closely to GAMMA products than other open-source software in terms of radiometric and geometric quality. This understanding of software performance for SAR image processing is key to designing the affordable and scalable solutions needed for the operational application of SAR Sentinel-1 data. Full article

The interferometric synthetic aperture radar (InSAR) imaging technique computes relative distances or surface maps by measuring the absolute phase differences of returned radar signals. The measured phase difference is wrapped in a 2$\pi$ cycle due to the wave nature of light. Hence, the proper multiple of 2$\pi$ must be added back during restoration and this process is known as phase unwrapping. The noise and discontinuity present in the wrapped signals pose challenges for error-free unwrapping procedures. Separate denoising and unwrapping algorithms lead to the introduction of additional errors from excessive filtering and changes in the statistical nature of the signal. This can be avoided by joint unwrapping and denoising procedures. In recent years, research efforts have been made using deep-learning-based frameworks, which can learn the complex relationship between the wrapped phase, coherence, and amplitude images to perform better unwrapping than traditional signal processing methods. This research falls predominantly into segmentation- and regression-based unwrapping procedures. The regression-based methods have poor performance while segmentation-based frameworks, like the conventional U-Net, rely on a wrap count estimation strategy with very poor noise immunity. In this paper, we present a two-stage phase unwrapping deep neural network framework based on U-Net, which can jointly unwrap and denoise InSAR phase images. The experimental results demonstrate that our approach outperforms related work in the presence of phase noise and discontinuities with a root mean square error (RMSE) of an order of magnitude lower than the others. Our framework exhibits better noise immunity, with a low average RMSE of 0.11. Full article

C-SAR/01 and C-SAR/02 serve as successors to the GF-3 satellite. They are designed to operate in tandem with GF-3, collectively forming a C-band synthetic aperture radar (SAR) satellite constellation. This constellation aims to achieve 1 m resolution imaging with a revisit rate of one day. It can effectively cater to various applications such as marine disaster prevention, monitoring marine dynamic environments, and supporting marine scientific research, disaster mitigation, environmental protection, and agriculture. Geometric correction plays a pivotal role in acquiring highly precise geographic location data for ground targets. The geometric positioning accuracy without control points signifies the SAR satellite’s geometric performance. However, SAR images do not exhibit a straightforward image-point–object-point correspondence, unlike optical images. In this study, we introduce a novel approach employing high-precision automatic trihedral corner reflectors as ground control points (GCPs) to assess the geometric positioning accuracy of SAR images. A series of satellite-ground synchronization experiments was conducted at the Xilinhot SAR satellite calibration and validation site to evaluate the geometric positioning accuracy of different C-SAR image modes. Firstly, we calculated the azimuth and elevation angles of the corner reflectors based on satellite orbit parameters. During satellite transit, these corner reflectors were automatically adjusted to align with the radar-looking direction. We subsequently measured the exact longitude and latitude coordinates of the corner reflector vertex in situ using a high-precision real-time kinematics instrument. Next, we computed the theoretical image coordinates of the corner reflectors using the rational polynomial coefficients (RPC) model. After that, we determined the accurate position of the corner reflector in the Single Look Complex (SLC) SAR image using FFT interpolation and the sliding window method. Finally, we evaluated and validated the geometric positioning accuracy of C-SAR images by comparing the two coordinates. The preliminary results indicate that the positioning accuracy varies based on the satellite, imaging modes, and orbital directions. Nevertheless, for most sample points, the range positioning accuracy was better than 60 m, and the azimuth positioning accuracy was better than 80 m. These findings can serve as a valuable reference for subsequent applications of C-SAR satellites. Full article

Monitoring agricultural abandonment is essential in understanding the effects on the environment and food security. Polarimetric synthetic aperture radar (PolSAR) is an efficient approach for the monitoring of large-scale agricultural land cover in cloudy and rainy areas. However, previous studies have not taken advantage of the valuable phase information and not fully utilized the spatiotemporal features of farmland parcels, which has seriously limited the abandoned land identification accuracy. In this study, we developed a new method for the mapping of abandoned land based on the spatiotemporal features from PolSAR Single Look Complex (SLC) images via deep learning methods. First, backscattering coefficients (σ⁰VV, σ⁰VH) were derived, and the polarimetric parameters (entropy, anisotropy and mean alpha angle) were obtained based on Cloude–Pottier polarimetric decomposition. Then, the VGG16 deep convolutional network was innovatively used to extract spatial features from both the backscattering coefficients and polarimetric parameters. Next, the separability index was calculated to select the most effective spatial features. Finally, LSTM classifications were conducted based on the time series of backscattering features, the polarimetric parameters, the extracted spatial features and their combinations. The results showed that the introduction of multitemporal polarimetric parameters and spatial features both led to an improvement in the abandoned land identification accuracy. The combination of backscattering features, polarimetric parameters and spatial features yielded the best performance in identifying abandoned land, with producer’s accuracy of 88.29% and user’s accuracy of 84.03%. This study demonstrated the potential of polarimetric parameters and validated the effectiveness of spatiotemporal features in abandoned land identification. It provided a practical method for the production of a highly reliable abandoned land mapping in cloudy and rainy areas. Full article

Airborne array tomographic synthetic aperture radar (TomoSAR) can acquire three-dimensional (3D) information of the observed scene in a single pass. In the process of airborne array TomoSAR data imaging, due to the disturbance of factors such as inconsistent antenna patterns and baseline errors, there are spatially varying amplitude-phase inconsistency errors in the multi-channel Single-Look-Complex (SLC) images. The existence of the errors degrades the quality of the 3D imaging results, which suffer from positioning errors, stray points, and spurious targets. In this paper, a new calibration method based on multiple prominent points is proposed to calibrate the errors of amplitude-phase inconsistency. Firstly, the prominent points are selected from the multi-channel SLC data. Then, the subspace decomposition method and maximum interference spectrum method are used to extract the multi-channel amplitude-phase inconsistency information at each point. The last step is to fit the varying curve and to compensate for the errors. The performance of the method is verified using actual data. The experimental results show that compared with the traditional fixed amplitude-phase inconsistency calibration method, the proposed method can effectively calibrate spatially varying amplitude-phase inconsistency errors, thus improving on the accuracy of 3D reconstruction results for large-scale scenes. Full article

The largest earthquake (Mw 6.4) in northwestern Croatia ruptured the faults near the city of Petrinja on 29 December 2020, at 11:19 UTC. The epicenter was located ~3 km southwest of Petrinja, ~40 km southeast of Zagreb, the capital of the Republic of Croatia. Here we investigated the geometric and kinematic properties of the 2020 Mw 6.4 Petrinja earthquake using a joint inversion of ascending and descending interferograms from three tracks of Sentinel-1 Single-Look Complex (SLC) images. The coseismic and early postseismic surface displacements associated with the Petrinja earthquake were imaged using standard DInSAR and SBAS time-series InSAR methods, respectively. The distributed slip model was inverted based on the ground surface displacements with maximum slip patch in 5 km depth. The early postseismic deformation occurred on the northwestern extent of coseismic slip, and it cannot be well modeled by the coseismic model. We thus suggested that the postseismic deformation was caused by a combined effect of the postseismic afterslips and aftershocks occurring in this area. Based on the inverted slip model, we calculated the Coulomb stress change in the region, and found a good correlation between positive Coulomb failure stress ∆CFS and the distribution of aftershocks. Based on these results, we identified which faults are more active, and then better estimated the seismic hazards in the region. Full article
