Single-stage detectors have drawbacks of insufficient accuracy and poor coverage capability. YOLOF (You Only Look One-level Feature) has achieved better performance in this regard, but there is still room for improvement. To enhance the coverage capability for objects of different scales, we propose an improved single-stage object detector: Dq-YOLOF. We have designed an output encoder that employs a series of modules utilizing deformable convolution and SimAM (Simple Attention Module). This module replaces the dilated convolution in YOLOF. This design significantly improves the ability to express details. Simultaneously, we have redefined the sample selection strategy, which optimizes the quality of positive samples based on SimOTA. It can dynamically allocate positive samples according to their quality, reducing computational load and making it more suitable for small objects. Experiments conducted on the COCO 2017 dataset also verify the effectiveness of our method. Dq-YOLOF achieved 38.7 $AP$, 1.5 $AP$ higher than YOLOF. To confirm performance improvements on small objects, our method was tested on urinary sediment and aerial drone datasets for generalization. Notably, it enhances performance while also lowering computational costs. Full article

This paper presents a comprehensive design tutorial for four types of single-stage operational transconductance amplifiers (OTAs): (1) five-transistor OTAs, (2) telescopic cascode OTAs, (3) folded cascode OTAs, and (4) current mirror OTAs. These OTAs serve as fundamental building blocks in analog circuits. The operational principles of each OTA are reviewed, and the key performance metrics are derived through a hand analysis. These performance metrics encompass most crucial parameters, including small-signal parameters, frequency response, input and output swing ranges, rising and falling slew rates, nonidealities, and bias circuit simplicity. All of these metrics are verified and compared using the simulation. Furthermore, the practical applications of each OTA are summarized, and a case study demonstrates the enhancement of a neural recording amplifier’s performance through appropriate OTA selection. A thorough review of the essential building blocks will become a stepping stone to design high-performance analog amplifiers across diverse applications. Full article

In this paper, we propose a novel standard-cell-based OTA architecture based on an improved version of the differential to single-ended converter, previously proposed by the authors, on a novel standard-cell-based basic voltage amplifier block. Due to a replica-bias approach, the basic voltage amplifier exhibits a well-defined output static voltage to allow easy cascadability. Another feature of the basic voltage amplifier is to provide a low output impedance to allow dominant pole compensation at the output of the cascade of several stages. An ultra-low voltage (ULV) standard-cell-based OTA based on the proposed architecture and building blocks has been designed referring to the standard-cell library of a 130-nm CMOS process with a supply voltage of 0.3 V. The layout of the OTA has been implemented by following an automatic layout flow within a commercial tool for the place-and-route of digital circuits. Simulation results have shown a differential gain of 50 dB with a gain–bandwidth product of 10 MHz when driving a 150 pF load capacitance. Good robustness is achieved under PVT variations, in particular for voltage gain, offset voltage, and phase margin. State-of-the-art small signal figures of merit and limited area footprint are key characteristics of the proposed amplifier. Full article

Inverter-based Operational Transconductance Amplifiers (OTAs) are versatile and friendly scalable analog circuit blocks. Especially for the new CMOS technological nodes, several recent applications have been extensively using them, ranging from Analog Front End (AFE) to analog-to-digital converters (ADC). This work tracks down the current advances in inverter-based OTAs design, comparing their basic fully differential structures, such as Nauta (N), Barthelemy (B), Vieru (V) and Mafredini (M) ones, and, in addition, mixing them up to propose new fully differential single-ended and two-stage hybrid versions. The new herein-proposed fully differential hybrid OTAs are the composition of Barthelemy/Nauta (B/N), Barthelemy/Manfredini (B/M), Nauta/Vieru (N/V), and Manfredini/Vieru (M/V) OTAs. All OTAs were designed using the same Global Foundries 180 nm open-source PDK and their performances are compared for post-layout simulations. Full article

The paper describes a single-stage operational transconductance amplifier suitable for very-low-voltage operation in power-constrained applications. The proposed circuit avoids the tail current generator in the differential pair while preventing pseudo-differential operation. Moreover, the adoption of positive feedback allows increasing the stage transconductance while minimizing the current consumption. Experimental measurements on prototypes implemented in a standard CMOS 180-nm technology, show superior performance as compared to the state of the art. Full article

Fully differential amplifiers require the use of common-mode feedback (CMFB) circuits to properly set the amplifier’s operating point. Due to scaling trends in CMOS technology, modern amplifiers increasingly rely on cascading more than two stages to achieve sufficient gain. With multiple gain stages, different topologies for implementing CMFB are possible, whether using a single CMFB loop or multiple ones. However, the impact on performance of each CMFB approach has seldom been studied in the literature. The aim of this work is to guide the choice of the CMFB implementation topology evaluating performance in terms of stability, linearity, noise and common-mode rejection. We present a detailed theoretical analysis, comparing the relative performance of two CMFB configurations for 3-stage OTA topologies in an implementation-agnostic manner. Our analysis is then corroborated through a case study with full simulation results comparing the two topologies at the transistor level and confirming the theoretical intuition. An active-RC filter is used as an example of a high-linearity OTA application, highlighting a 6 dB improvement in ${\mathrm{P}}_{1\mathrm{dB}}$ in the multi-loop implementation with respect to the single-loop case. Full article

This paper deals with a single-stage single-ended inverter-based Operational Transconductance Amplifiers (OTA) with improved composite transistors for ultra-low-voltage supplies, while maintaining a small-area, high power-efficiency and low output signal distortion. The improved composite transistor is a combination of the conventional composite transistor and forward-body-biasing to further increase voltage gain. The impact of the proposed technique on performance is demonstrated through post-layout simulations referring to the TSMC 180 nm technology process. The proposed OTA achieves 54 dB differential voltage gain, 210 Hz gain–bandwidth product for a 10 pF capacitive load, with a power consumption of 273 pW with a 0.3 V power supply, and occupies an area of 1026 μm². For a 0.6 V voltage supply, the proposed OTA improves its voltage gain to 73 dB, and achieves a 15 kHz gain–bandwidth product with a power consumption of 41 nW. Full article

Slew-rate enhancement (SRE) techniques assist the charge transfer process in OTA-based switched-capacitor circuits. Parallel-type slew-rate enhancement circuits, i.e., circuits that provide a feed-forward path external to the main OTA, are attractive solutions, since they introduce a further degree of freedom in the speed/power consumption design space without affecting other specifications regarding the main OTA. This technique lends itself to be employed jointly with advanced OTA topologies in order to compose a highly energy efficient OTA/SRE system. However, insights in design choices such as power optimization are still missing for such systems. Here we discuss system level choices with the help of a simple model. Using precise electrical simulations, we demonstrate energy savings greater than 30% for different OTA/SRE systems implemented in a standard 180-nm CMOS technology. Full article

The design of single-stage OTAs for accurate switched-capacitor circuits involves challenging trade-offs between speed and power consumption. The addition of a Slew-Rate Enhancer (SRE) circuit placed in parallel to the main OTA (parallel-type SRE) constitutes a viable solution to reduce the settling time, at the cost of low-power overhead and no modifications of the main OTA. In this work, a practical analytical model has been developed to predict the settling time reduction achievable with OTA/SRE systems and to show the effect of the various design parameters. The model has been applied to a real case, consisting of the combination of a standard folded-cascode OTA with an existing parallel-type SRE solution. Simulations performed on a circuit designed with a commercial 180-nm CMOS technology revealed that the actual settling-time reduction was significantly smaller than predicted by the model. This discrepancy was explained by taking into account the internal delays of the SRE, which is exacerbated when a high output current gain is combined with high power efficiency. To overcome this problem, we propose a simple modification of the original SRE circuit, consisting in the addition of a single capacitor which temporarily boosts the OTA/SRE currents reducing the internal turn-on delay. With the proposed approach a settling-time reduction of 57% has been demonstrated with an SRE that introduces only a 10% power-overhead with respect of the single OTA solution. The robustness of the results have been validated by means of Monte-Carlo simulations. Full article
