Search Results (17)

Considerable progress has been made in predicting nominal NVH behavior in electric drivetrains, but the acoustic scatter observed across manufactured units remains insufficiently understood. In practice, nominally identical drive units may still exhibit noticeably different tonal behavior because small deviations in gears, shafts, bearings, fits, centering features, or assembly phase modify the excitation, transfer, and radiation mechanisms of the system. This review examines how manufacturing and assembly variability influences NVH performance in electric drive units and e-axles, with particular focus on the rotor–shaft–gear–bearing–housing system. Unlike broader EV NVH reviews, the present work focuses specifically on variability-induced acoustic scatter and its propagation along the drivetrain NVH generation and transmission path. To support transparency and consistency, the literature search and selection process followed a structured, PRISMA-inspired approach across Scopus, Web of Science, Google Scholar, and SAE Mobilus for the 2015–2026 period. From 387 identified records, 50 studies were retained after duplicate removal, screening, and full-text assessment. The selected literature was synthesized into eight thematic categories: imbalance; run-out and eccentricity; bearing clearance and preload; spline and pilot centering; thermal effects; phase indexing; transmission error and sidebands; and end-of-line NVH diagnostics. The reviewed literature shows that manufacturing- and assembly-induced deviations can significantly alter transmission error, sideband structure, shaft-order content, and final tonal response, even when individual components remain within nominal tolerance limits. Beyond synthesizing the evidence base, the review organizes existing modeling and diagnostic practices into a structured framework for variability-aware NVH assessment, based on explicit deviation parameterization, hierarchical model fidelity, intermediate excitation metrics, thermal-state awareness, and closer integration with production and measurement data. Overall, the findings support a shift from nominal NVH assessment toward robustness-oriented, production-representative interpretation and future prediction of acoustic scatter in electric drivetrains. Full article

To address the limitations of traditional analytical modeling in capturing complex surface topographies, this paper presents comprehensive research on the error sensitivity mechanism, loaded tooth contact analysis (LTCA), and load-bearing contact characteristics of curved face gears based on high-precision point cloud modeling. The primary objectives are threefold: (1) to establish a high-fidelity topological reconstruction framework using Non-Uniform Rational B-Splines (NURBS) to bridge the gap between discrete data and finite element analysis (FEA); (2) to reveal the inherent mechanical response and sensitivity mechanism to spatial installation misalignments; and (3) to evaluate the contact performance and transmission error fluctuations under operational loads. Specifically, an analytical discretization method is proposed for point cloud generation, followed by a dual-path validation system integrating “rigid tooth contact analysis (TCA)” and “loaded FEA”. The results demonstrate that the proposed reconstruction achieves a superior accuracy with a Root Mean Square Error (RMSE) of 2.2 × 10⁻³ mm. Furthermore, shaft angle error is identified as the dominant sensitivity factor affecting transmission smoothness and edge contact, exerting a more significant influence than offset and axial errors. Compared with existing research on arc-tooth and helical face gears, this work provides a more robust closed-loop verification for curved profiles, revealing that material elastic deformation increases transmission error amplitude by 10.1% to 17.2%. These insights offer a theoretical reference for the high-precision assembly and tolerance allocation of helicopter transmission systems. Full article

Splined assemblies ensure precise torque transmission and alignment in mechanical systems. Three-dimensional printing, especially FDM, enables fast production of customized components with complex geometries, reducing material waste and costs. Optimized printing parameters improve dimensional accuracy and performance. Dimensional accuracy is a critical aspect in the additive manufacturing of mechanical components, especially for splined shafts and hubs, where deviations can impact assembly precision and functionality. This study investigates the influence of key FDM 3D printing parameters—layer thickness, infill density, and nominal diameter—on the dimensional deviations of splined components. A full factorial experimental design was implemented, and measurements were conducted using a high-precision coordinate measuring machine (CMM). To optimize dimensional accuracy, artificial neural networks (ANNs) were trained using experimental data, and a genetic algorithm (GA) was employed for multi-objective optimization. Three ANN models were developed to predict dimensional deviations for different parameters, achieving high correlation coefficients (R² values of 0.961, 0.947, and 0.910). The optimization process resulted in an optimal set of printing conditions that minimize dimensional errors. The findings provide valuable insights into improving precision in FDM-printed splined components, contributing to enhanced design tolerances and manufacturing quality. Full article

This paper presents the process of manufacturing mechanical joint components using additive manufacturing (AM) techniques such as Material Extrusion (Fused Deposition Modelling (FDM)), Material Jetting (PolyJet), and Vat Photopolymerization (VAT)/Stereolithography (SLA). Using the PolyJet technique and a photopolymer resin, spline and threaded joint components were produced. For comparative analysis, the threaded joint was also fabricated using FDM and SLA techniques. PLA material was used for the FDM technique, while photopolymer resin was utilized for the SLA process. The components produced underwent a surface analysis to evaluate the accuracy of the dimensions in relation to the nominal dimensions. For the spline connection components, the dimensional deviations recorded by a 3D scanner ranged from −0.11 to +0.18 mm for the shaft and up to 0.24 mm for the sleeve. Measurements of screw and nut diameters showed the highest accuracy for screws produced using the PolyJet technique, while the nuts exhibited the best accuracy when fabricated with the SLA method. The profile of the screw threads using a contour gauge revealed the most accurate thread profile on the screw manufactured with the PolyJet technique. Full article

Eccentric meshing reducers are widely used in agriculture, industrial robots, and other fields due to their ability to achieve a high reduction ratio within a compact volume. However, the contact wear problem seriously affects the service performance of the eccentric meshing reducer, thereby limiting their range of applications. To effectively address this issue, this study involved a stress analysis of the contact pairs and a surface wear analysis of a new eccentric meshing reducer. The wear equation for the contact pairs was derived using Archard’s wear theory, incorporating geometric and material parameters from both the reducer gear contact pair and the spline contact pair. In parallel, a wear simulation was conducted by integrating the UMESHMOTION subprogram with ALE adaptive grids. Additionally, the effects of load amplitudes on contact pair stress and surface wear were systematically investigated. It is revealed that the contact pair stress of the reducer gear was higher than that of the spline contact pair. Furthermore, the internal spline exhibited the highest wear rate, followed by the output shaft gear, external spline, and input shaft gear, in that order. This work provides a comprehensive and in-depth understanding of the wear behaviors of general reducers with small teeth differences and offers valuable scientific references for design optimization, fault diagnosis, and maintenance strategy formulation. Full article

Prefabricated reinforced concrete staircases (PC staircases) are prefabricated components that are widely used in prefabricated buildings and are used in large quantities. During the production and construction of a PC staircase, the lifting point setting directly affects the construction safety, construction efficiency, and construction quality. In this paper, we analyze the quality problems and safety risks in the design, production, and construction of PC staircases under the constraints of multidimensional spatial characteristics, clarify the key technical difficulties of prefabricated staircase lifting under the multidimensional spatial and temporal constraints, and analyze the factors that should be considered in the setting of lifting points. In this paper, a prefabricated staircase lifting point setting database is established and a thin-plate spline interpolation algorithm is introduced to expand it. Based on the support vector machine algorithm, the process of optimization is carried out for the kernel function scale parameter and penalty factor, and it is concluded that for every increase of two in the number of cross-validation folds, the percentage reduction in minimum RMSE is 9.4%, 17.8%, and 4.2%, respectively, the percentage increase in the optimization time is 39.7%, 61.8%, and 27.3%, respectively, and a PC staircase lifting point setup method based on the small-sample database is proposed. The number of lifting points and lifting point locations of the PC staircase satisfying the multidimensional spatial feature constraints can be obtained by inputting the five design parameters of the PC staircase, namely, the number of treads, the height of the treads, the width of the treads, the width of the staircase, and the weight of the staircase, into the lifting point setup method proposed in this paper. The reliability of the precast reinforced concrete staircase lifting point setting method proposed in this paper when considering the multidimensional spatial constraint characteristics is verified by the precast staircases in deep shafts for assembly construction at the Chongqing metro station. Full article

Shafts with a stepped shoulder are particularly well known in the field of drive technology. In combination with a form-fit shaft–hub connection, the shaft shoulder fixes the hub on the shaft as well as being responsible for the absorption of the axial forces. With profiled shafts, there is a notch overlay in the shaft shoulder, involving the shaft shoulder and profile. If the hub is also connected with the profiled shaft, the hub edge acts as an additional notch in the shaft shoulder area. The multiple resulting notches have not previously been part of research activities in the field of innovative trochoidal profile connections. Compared to conventional positive-locking connections, such as the keyway connection or the involute splined shaft profile, the favourable features of trochoidal profiles have only been based on connections with stepless shafts without a shoulder in previous studies. Accordingly, this article addresses numerical and experimental investigations of trochoidal profile connections with offset shafts for pure torsional loading. Focusing on a hybrid trochoid with four eccentricities and six drivers, a well-founded numerical and experimental investigation was carried out with numerous fatigue tests. In addition, the influence of a shaft shoulder was also demonstrated on simple epitrochoidal and hypotrochoidal profiles. Full article

Gantry-type dual-axis platforms can be used to move heavy loads or perform precision CNC work. Such gantry systems drive a single axis with two linear motors, and under heavy loads, a high driving force is required. This can generate a pulling force between the drive shafts in the coupling mechanism. In these situations, when a synchronization error becomes too large, mechanisms can become deformed or damaged, leading to damaged equipment, or in industrial settings, an additional power consumption. Effectively and accurately acquiring the synchronized movement of the platform is important to reduce energy consumption and optimize the system. In this study, a fractional-order fuzzy PID controller (FOFPID) using Oustaloup’s recursive filter is used to control a synchronous X–Y gantry-type platform. The optimized controller parameters are obtained by the measurement of control errors in a simulated environment. Four optimization methods are tested and compared: particle swarm optimization, invasive weed optimization, a gray wolf optimizer, and biogeography-based optimization. The systems were tested and compared in order to optimize the control parameters. Each of the four algorithms is simulated on four contour shapes: a circle, bow, heart, and star. The simulations and control scheme of the experiments are implemented using MATLAB, and the reference paths were planned using non-uniform rational B-splines (NURBS). After running the simulations to determine the optimal control parameters, each set of acquired control parameters is also tested and compared in the experiments and the results are recorded. Both the simulations and experiments show good results, and the tracking of the X–Y platform showed improved performance. Two performance indices are used to determine and validate the relative performance of the models and results. Full article

After being processed into a certain shape by a stirrup bending machine, steel bars are used as the skeleton of reinforced concrete in construction. The accuracy of their bending directly affects the bearing capacity of reinforced concrete. In order to improve the accuracy of the springback angle of steel bars after bending, this paper focuses on optimizing the structural parameters of the steel bar bending machine and controlling the springback angle of steel bars. The influence of the support shaft diameter, bending crankshaft diameter, and bending crankshaft radius on the springback angle of steel bars is analyzed using ANSYS explicit dynamic simulation and experimental analysis. By combining orthogonal experimental methods, the bending structural parameters were optimized, including a support shaft diameter of 20 mm, a crankshaft bending diameter of 40 mm, and a crankshaft bending radius of 80 mm. This can effectively reduce the springback angle of the steel bars and improve the accuracy of the bending angle after bending. In addition, in order to improve the control accuracy of the steel bar springback angle, a cubic spline interpolation method was proposed, and the collected steel bar springback angle data were fitted using Matlab. At the same time, comparisons were made between the least squares method, polynomial interpolation method, and cubic spline interpolation method. The results show that the compensation formula obtained by using the cubic spline interpolation method can effectively improve the control accuracy of the steel bar bending springback angle. Full article

This paper presents an analytical method for determining the bending stresses and deformations in prismatic, noncircular profile shafts with trochoidal cross sections. The so-called higher trochoids can be used as form-fit shaft-hub connections. Hybrid (mixed) higher trochoids (M-profiles) were developed for the special application as a profile contour for the form-fit shaft and hub connections in an earlier work by the author. M-profiles combine the advantages of the two standardised polygonal and spline contours, which are used as shaft-hub connections for the transmission of high torques. In this study, the geometric and mechanical properties of the higher hybrid trochoids were investigated using complex functions to simplify the calculations. The pure bending stress and shaft deflection were determined for M-profiles using bending theory based on the theory of mathematical elasticity. The loading cases consisted of static and rotating bends. Analytical, numerical, and experimental results agreed well. The calculation formulas developed in this work enable reliable and low-cost dimensioning with regard to the stresses and elastic deformations of profile shafts subjected to bending loads. Full article

The fuel booster pump is one of the most vulnerable physical assets in an operating engine due to the harsh environmental and operational conditions. However, because of its high structural complexity and extreme operational conditions, the reliability design of the fuel booster pump becomes especially difficult, particularly by means of experiments. Thus, to overcome such a problem, advanced simulation techniques have become adequate solutions for the reliability assessment and analysis of a fuel booster pump at the design stage. In this paper, by considering the effects of the uncertainties of multiple design parameters, fatigue life distributions of the four key components (which are the sealing bolt, spline shaft, graphite ring, and inducer, respectively) in a fuel booster pump were first predicted by PoF-based reliability simulations. Then, through further sensitivity analysis on each key component, the design parameters most sensitive to the component mean fatigue life were detected from a total of 25 candidate parameters. These parameters include the “nominal diameter” and “preload” for the sealing bolt, “major and minor diameters of the small spline” for the spline shaft, “inside diameter” for the graphite ring, and “fuel pressure on the blade front surface” for the inducer, respectively. These sensitivity results were found to be in good agreement with the results from the qualitative cause analysis on each key component. Full article

The article is devoted to the substantiation of technological foundations for the restoration of extremely worn-out, metal-consuming, and resource-consuming parts, in a method consisting of applying a compensating metal wear with subsequent plastic deformation. Currently, there are no technologies for their restoration in a repair facility that guarantee the resilience of the factory product. The proposed technological process of repair consists of butt welding onto the end of the spline semi-axle shank, compensating for the wear of the metal, the volume of which takes into account the losses resulting from the wear of the slots, as well as allowances for their machining. In the example of forging the axle shaft of a truck’s driving axle, the regularities of the plastic flow of metal during part deformation in the stamp are revealed. In the process of hot volumetric upsetting of long cylindrical parts with a variable diameter, it is important to know the possible directions of metal movements, as well as the energy-power characteristics of the process at various stages of forging. The evaluation criteria of the level of perfection of the technology were indicators of resource conservation and efficiency of the recovery route. The technological direction of the conducted research was analyzed, step by step, from the standpoint of saving repair materials and energy resources. The results of theoretical studies are crucial in the design of die tooling, for the manufacture of blanks, when restoring the rear axle shafts of trucks with pressure. Production tests carried out on the models, obtained as a result of mathematical processing of experimental data, confirmed the reliability of the experimental information. The introduction of the proposed set of repair equipment for the restoration of semi-axles will allow the formation of additional production in the region for the recycling of worn-out metal-intensive steel parts of agricultural machinery. Full article

The driving performance of an off-road vehicle is closely related to soil strength. A bevameter is used to measure the soil strength, and it usually consists of two independent devices: a pressure–sinkage test device and a shear test device. However, its development and measurement processes have not been standardized; thus, researchers apply it in various fields according to their own discretion. In this study, a new bevameter was developed, and experiments were conducted to clarify the factors that affect the measurement performance of the bevameter. The pressure–sinkage test device was tested with circular plates of different sizes, and the results confirmed that the pressure–sinkage parameters decreased with the plate size. For the shear-test device, normal pressure was applied using a dead load to prevent normal-pressure variation due to displacement and speed. In addition, a spline was installed on top of the shaft connected to the shear ring to measure slip sinkage during the shear test. The results showed that the slip sinkage increased in proportion to the normal pressure and slip displacement, but the increase gradually decreased and converged to a certain point. Full article

Parametric investigations related to shoulder angle on tool geometry for a combined cold extrusion of a drive shaft, which consisted of spur gear and internal spline structures, were conducted through three-dimensional FE (finite element) simulations. The drive shaft was required to be about 92.00 mm for the face width of the top land on the spur gear part and roughly 22.70 mm for the groove depth of the internal spline section. AISI 1035 carbon steel material with a diameter of 50.00 mm and a length of 121.00 mm was spheroidized and annealed, then used as the initial billet material. A preform as an intermediate workpiece was adopted to avoid the excessive accumulation of plastic deformation during the combined cold extrusion. Accordingly, the cold forging process involves two extrusion operations such as a forward extrusion and a combined extrusion for the preform and the drive shaft. As the main geometric parameters influencing the dimensional quality and the deformed configuration of the final product, the two shoulder angles of θ₁ and θ₂ for the preform forging and the combined extrusion were both considered to be appropriate at 30°, 45°, and 60°, respectively. Using nine geometric parameter combinations, three-dimensional finite element simulations were performed, and these were used to evaluate the deformed features and the geometric compatibilities on the spur gear structure and the internal spline feature. Based on these comparative evaluations using the numerically simulated results, it is shown that the dimensional requirements of the target shape can be satisfied with the shoulder angle combination of (45°, 45°) for (θ₁, θ₂). Full article

This study displays the effect of laser surface hardening parameters on the hardness profile (case depth) of a splined shaft made of AISI 4340 steel. The approach is mainly based on experimental tests wherein the hardness profile of laser hardened splines is acquired using micro-hardness measurements. These results are then evaluated with statistical analysis (ANOVA) to determine the principal effect and the contributions of each parameter in the laser hardening process. Using empirical correlations, the case depth of splined shaft at tip and root of spline’s teeth is also estimated and verified with measured data. The obtained results were then used to study the sensitivity of the measured case depths according to the evolution of laser process parameters and geometrical factors. The feasibility and efficiency of the proposed approach lead to a reliable statistical model in which the hardness profile of the spline is estimated with respect to its specific geometry. Full article
