Due to the limitations of wind tunnel speed and size, achieving a model’s Reynolds number equal to the actual Reynolds number is challenging and may lead to discrepancies between experimental and actual results. To investigate the effects of the Reynolds number on the aerodynamic forces and vortex-induced vibration (VIV) characteristics of a streamlined box girder, wind tunnel tests were conducted to study the variations in aerodynamic forces and surface pressures on the static main beam, as well as the VIV response and time–frequency characteristics of the aerodynamic forces on the dynamic main beam, as the Reynolds number varied. The results indicate that in static tests, as the Reynolds number increases, the drag coefficient of the main beam decreases, the lift coefficient slightly increases, and the pitching moment coefficient remains almost unchanged. The root mean square (RMS) values of the wind pressure coefficients show a significant Reynolds number effect, with values generally decreasing as the Reynolds number increases. In free vibration tests, as the Reynolds number increases, the onset wind speed of VIV increases from 14.35 m/s to 16.03 m/s, the maximum amplitude decreases from 0.076 to 0.004, and the VIV lock-in range narrows. The dynamic pressure results indicate that as the Reynolds number increases, the RMS values of the wind pressure coefficients decrease. At some measurement points, the dominant frequencies of the fluctuating pressure amplitude spectra deviate from the corresponding VIV frequency, and the correlation and contribution coefficients between the local aerodynamic forces and the overall vortex-induced force (VIF) decrease. These changes may explain the reduction in the VIV amplitude with an increasing Reynolds number. The motion state of the main beam has a minimal effect on the mean wind pressure coefficients and their Reynolds number effect, whereas it has a more significant effect on the RMS values of the pressure coefficients. Full article

Suspension bridges’ in-plane extended configuration makes them vulnerable to wind-induced vibrations. Vortex shedding is a kind of aerodynamic phenomenon causing a bridge to vibrate in vertical and torsional modes. Vortex-induced vibrations disturb the bridge’s serviceability limit, which is not favorable, and in the long run, they can cause fatigue damage. In this condition, vibration control strategies seem to be essential. In this paper, the performance of a tuned mass damper (TMD) is investigated under the torsional vortex phenomenon for an ultra-span streamlined twin-box girder suspension bridge. In this regard, the sensitivity of TMD parameters was addressed according to the torsional responses of the suspension bridge, and the reached appropriate ranges are compared with the outputs provided by genetic algorithm. The results indicated that the installation of three TMDs could control all the vulnerable modes and reduce the torsional rotation by up to 34%. Full article

This paper is a contribution to analyzing the aerodynamic forces on a streamlined box girder (SBG) with coupled vibration in a potential flow. The key enabling step was to assume that the normal velocity of the airflow at an arbitrary point on the surface of the SBG was equal to the normal velocity of the surface motion. The aerodynamic drag force, lift force, and pitching moment were expressed as functions of the motion state of the SBG and the SBG’s shape-related parameters. To investigate the applicability of this force model, the analytical solution at various angles of attack was compared with a numerical simulation in a viscous flow. The results imply that the amplitude of the analytical lift force and pitching moment agree well with the numerical results under the angles of attack of 0° and ±3°. Furthermore, the analytical drag force effectively predicts the second-order phenomenon resulting from the multiplication of the vertical and torsional vibration velocities. As a consequence, the present analytical solution provides an effective method for analyzing the aerodynamic forces acting on SBGs with coupled vibration. Full article

This study proposes a novel reduced-order model (ROM), based on the Volterra series, for the aerodynamic force of the bridge deck section. Moreover, the ROM of the aerodynamic force of the streamlined box girder section of the Great Belt East Bridge (GBEB) is identified with computational fluid dynamic (CFD) simulations. Furthermore, an analysis method combining ROM aerodynamic force and Newmark-β integration is established to simulate the aeroelastic responses of the bridge deck section. Finally, the wind-induced vibration responses of the GBEB section are calculated near the flutter critical wind speed based on the Volterra series-based aeroelastic analysis and the fluid–structure interaction (FSI) numerical simulations in ANSYS Fluent, respectively. Moreover, to verify the applicability of the proposed method, the aeroelastic responses of the main deck section with the crash barriers of Lingdingyang Bridge (LDYB) are also simulated via the Volterra model and Newmark-β integration near the flutter critical wind speed. The results show that the first-order truncated Volterra model established in this study can accurately capture the aerodynamic response of the main girder, and the results are in good agreement with those of the CFD numerical simulation under forced vibration. Furthermore, the proposed method combined with ROM aerodynamic force and Newmark-β integration can effectively calculate the FSI of the bridge girder. The numerical results of the flutter critical wind speed and flutter frequency of GBEB and LDYB are consistent with the numerical results by the FSI method based on ANSYS Fluent and the existing numerical and experimental results, respectively. Full article

This study systematically investigated the aerodynamic characteristics of a closed box girder in sinusoidal oscillating flow fields based on experimental and numerical approaches. The numerical method was validated through comparison with experimental results. The effects of the oscillating frequencies (KC = 0.25~12) and amplitudes (U_m = 0.5~2.0 m/s) on the pressure distributions, total forces, and wake characteristics were investigated. The results show that the mean pressure coefficients and time-averaged streamline distributions are insensitive to the oscillating frequency and amplitude. However, the characteristics of the sinusoidal oscillating inflow significantly influence the fluctuating aerodynamic forces and the fluctuating drag forces increase linearly with the oscillating frequency. In particular, for the wake flow, the larger oscillating frequency and amplitude of the inflow led to more obvious wake vortex shedding. Full article

The main goal of this paper is to explore the mechanism of vortex-induced vibration (VIV) of a streamlined box girder from the perspective of flow field and pressure distribution. In this paper, using the computational fluid dynamic method, the VIV performance of fluid under specific working conditions is simulated and analyzed, especially the distribution and evolution laws of vortex structures in the whole process of VIV are studied in depth. Based on the analysis of the flow field distribution, the corresponding relationship between vortex structures and vortex-induced pressures (VIPs) is discussed. The results demonstrate that the primary cause of VIV for streamlined box girders at large attack angles is the circulation process of the massive vortex structures production and dissipation on the upper surface, rather than the alternate shedding of symmetrical vortex pairs. When vortex structures remain stable, negative VIPs rise in absolute value, negative VIPs occur when vortex structures move backward, and positive VIPs increase when vortex structures fall off. Full article
