To investigate the impact of various compartment partition plate connection methods within a shield utility tunnel on the mechanics behavior of the connecting nodes and the overall structural integrity, this study examines and simulates three distinct connection approaches in a laboratory. These approaches include a steel corbel and rear expansion anchor bolt connection, an embedded part and steel corbel welding connection, and a reinforced concrete corbel connection. The objective in selecting the above three connection methods was to gain insights into how they influence the mechanical properties of the connections and the tunnel structure itself. The failure criteria of the structure dictate that neither the steel bar nor the steel plate should exceed their respective yield strength. Furthermore, the concrete damage zone surrounding the anchor should not exhibit any connectivity. The findings of our study indicate that: (1) The weak link in the steel truss-rear expansion anchor bolt connection scheme is centered within the connection section. With six rear expansion anchor bolts, the load capacity reached 180 kN. Conversely, when employing nine rear expansion anchor bolts, the reduced spacing between the bolts led to premature concrete breakage, decreasing the bearing capacity to 170 kN. (2) Arranging the six anchor bolts into two rows and three columns enhanced the load-bearing capacity, yet one must be cautious to prevent damage from incorrect bolt spacing. According to the conditions outlined in this study, the ideal bolt spacing fell within the range from 66.7 mm to 100 mm. Additionally, it is worth noting that the bolt deformation was concentrated within 5 cm and 6 cm around the bolt. (3) The connection scheme of the embedded part and steel corbel demonstrated impressive load-bearing capabilities, showing the ability to withstand a load of 220 kN within the elastic stage. Notably, the deformation of the anchor bar was concentrated primarily within a 5 cm radius around the corbel. (4) In the reinforced concrete corbel connection scheme, the load-bearing capacity reached 240 kN. The key factor influencing this capacity was the presence of cracks. Initially, these cracks appeared symmetrically on both sides of the corbel, and gradually extended to the width and height of the corbel structure. Full article

The tension cable-supported power transmission structure (TC-PTS) is a new type of power transmission structure suitable for mountainous terrain, and is sensitive to wind load. In this regard, a nonlinear finite element analysis model of wind-induced vibration is proposed for the TC-PTS, and the wind-induced vibration response of the structure is analyzed. Firstly, the tangent stiffness matrix of the three-dimensional truss element for the supporting suspension cable and transmission line, considering the geometric nonlinearity of structures, is derived through the relationship between the element elastic energy and its displacement. Subsequently, the element mass matrix and damping matrix of the supporting suspension cable and transmission line, as well as the element nodal load vector obtained from wind load equivalence, are given. Then, based on the nonlinear finite element theory, the nonlinear dynamic equation of wind-induced vibration is established for the TC-PTS and solved using the Newmark-β method combined with the Newton–Raphson iterative method. Furthermore, the rain-flow counting method and Miner’s linear fatigue cumulative damage theory were used for wind-induced fatigue damage assessment. Finally, a two-span TC-PTS was selected as an example, and the wind-induced nonlinear vibration and fatigue damage assessment were analyzed through the proposed model. The results show that the proposed model has high computational accuracy and efficiency. The first three order vibration modes of the supporting-conductor part of the two-span TC-PTS were antisymmetric vertical bending, symmetric side bending, and antisymmetric side bending. With the increase in wind speed and wind direction angle, the maximum lateral displacement and tension of the supporting suspension cable and transmission line increased, and their degree of increase showed a nonlinear trend. In terms of the wind-induced fatigue analysis results of TC-PTS, the fatigue damage at the end of the supporting-conductor suspension cable was greater than the fatigue damage at its midpoint. Compared to the fatigue damage at the midpoint of the conductor, the fatigue damage at the end of the conductor was less affected by the wind direction angle, and both were more significantly affected by the wind speed. Full article

To facilitate the first application of the novel concrete-filled built-up K-joints with different brace sections in truss bridges, the present paper aims to determine their practicability through a comparison with integral joints. First, a structural analysis was carried out using the MIDAS CIVIL software to evaluate the loading applied to the structure. Additionally, boundary condition analysis was carried out. After that, the symmetric multi-planar joints were developed, using Abaqus 6.14 for the strength verification and the failure mode identification. These were followed by the multi-planar joints estimate cost. The results indicated that for positive bending, the novel joint deformed by 2.01 mm, compared to 4.83 mm for the integral joint in the serviceability limit state. These deformations were equal to 5.58 mm and 7.68 mm, respectively, in the negative bending. Verification under the ultimate limit state indicated a deformation of 10.43 mm for the novel joint type and 16.59 mm for the integral joint in the positive bending, whereas deformations of 15.89 mm and 16.82 mm were indicated in the negative bending. Moreover, a failure mode analysis showed a buckling of the arc yielding for the novel joint type and a buckling of the gusset plate for the integral joint. Finally, the results showed that the novel type of joint was more expensive by about CNY 111,286.06. Full article

Structural fault diagnosis is an important subject for ensuring the normal use of structures. More test data will help to improve the accuracy and reliability of structural fault diagnosis. Therefore, a structural fault detection algorithm based on static–dynamic mixed sensitivity analysis is proposed. The vibration parameters used were the vibration modes of some of the nodes in the structure measured by the vibration test system. The static response parameter used was the vertical displacement of the structure under the gravity load measured by the static test system. In particular, the gravity load and the structure were connected rigidly to form a new added-mass system. The vibration mode of the additional-mass system was measured again to obtain more equations for fault evaluation. Based on the static and dynamic measurement data, the failure coefficients of all components in the structure were calculated through the mixed sensitivity of the static displacement and vibration-mode shape. According to the calculated value of the failure coefficient, the failure state of all components in the structure could be finally evaluated. The main innovation of the proposed method was the use of the static load as a part of the new added-mass system to obtain more vibration parameters for the defect diagnosis. The implementation process and effect of this method were verified using a numerical truss structure and an experimental steel beam structure. Moreover, the defect diagnosis results of the proposed hybrid method were compared with those of a pure static algorithm and a pure dynamic algorithm to illustrate the advantages of the hybrid method. The research results showed that this method has the advantages of simple implementation and high diagnosis accuracy. Especially for symmetric structures, the proposed method can successfully avoid the possible missed diagnoses of the pure static algorithm and pure dynamic method. The algorithm provides a simple and feasible method for structural defect identification. Full article

Typically, the upper part of the roof a gymnasium building is a radial inverted triangular truss structure, and the lower part is a cable structure. They are connected by vertical braces to form a self-balancing structural system. The whole roof is supported by a complex, spatial, prestressed structure comprising tilted Y-shaped laced columns. Such structures rely on the integrity of the form and the application of prestress to achieve the best performance; it is in an extremely unstable state during construction. In order to study the mechanical behavior of the structure in this process, finite element software was used to analyze the cumulative slip of the structure and the construction process of cable tension, and the simulation values were compared to the actual monitoring values. The stress and deformation of the structure in different construction stages were investigated, and a reasonable structural unloading scheme was put forward. The study results showed that the stiffness of the long-span space truss suspended dome structure gradually increased with the structural integrity during construction, and the vertical deformation decreased from 25.4 mm to 19.26 mm with the construction process. The location and magnitude of the structure’s maximum internal force and maximum stress varied greatly compared to the static analysis when considering the construction process effects. Hence, conducting a construction process analysis is necessary. The construction technology of symmetrical rotating cumulative slip proposed in this paper has the advantages of a short construction duration, safe and stable construction process, etc., providing technical references for similar engineering constructions. Full article

A space solar power station (SSPS) has become a huge potential candidate to provide abundant and clean electrical energy for terrestrial users by collecting and converting solar power in space. In this paper, an innovative two-layer ring truss-based SSPS is proposed. It consists of the top layer concentrator-based spherical one-time reflection region, the bottom layer space radiator using symmetric or asymmetric cable networks, a ring truss for a supporting structure, a photoelectric conversion system, and transmitting antennas. The construction strategies including the triangular facets modularity of top layer concentrator, area requirement of bottom layer space radiator, two-segment optimization design of generatrix of photoelectric conversion system, and aperture derivation of transmitting antenna are carried out. Then, the performance analysis mainly including the modularization theory error calculation, energy collection and distribution, and thermal characteristics in orbit of this proposed SSPS is presented. Finally, the system parameters are estimated and summarized for a better sense of the proposed SSPS. The results indicate that 100% energy collection can be achieved for an ideal concentrator, and 80% with a modular division layer of 6 and tracking error of no more than 2°. The results demonstrate the feasibility of the proposed SSPS concept and can provide a reference for future space energy harvesting and space exploration projects. Full article

Bars are significant load-carrying components in engineering structures. In particular, L-bars are typical structural components commonly used in truss structures and have typical irregular asymmetric cross-sections. To ensure the safety of load-carrying bars, much research has been done for non-destructive testing (NDT). Ultrasonic guided waves have been widely applied in various NDT techniques for bars as a result of the long-range propagation, low attenuation, and high sensitivity to damages. Though good for inspection of ultrasonic guided waves in symmetric cross-section bar-like structures, the application in asymmetric ones lacks further research. Moreover, traditional damage detection in bars using ultrasonic guided waves usually depends on a single-mode at a lower frequency with lower sensitivity and accuracy. To make full use of all frequencies and modes, a multi-mode characteristic-based damage detection method is presented with the sum of multiple signals (SoM) strategy for L-bars with asymmetric cross-section. To control the desired mode in multi-mode ultrasonic guided waves, excitation optimization and weighted gathering are carried out by the analysis of the semi-analytical finite element (SAFE) method and the normal mode expansion (NME) method. An L-bar example with the asymmetric cross-section of 35 mm × 20 mm × 3 mm is used to specialize the proposed method, and some finite element (FE) models have been simulated to validate the mode control. In addition, one PZT is applied as a contrast in order to validate the multielement mode control. Then, more FE simulations experiments for damage detection have been performed to validate the damage detection method and verify the improvement in detection accuracy and damage sensitivity. Full article

In the development process of intelligent construction, the safety assessment of prestressed steel structures as an important research direction has become more and more attractive in academia. Digital twins (DTs) is the key technology to realize intelligent construction. The virtual and real interaction of the DTs can provide an efficient management and control mechanism for the construction process. This research proposes an intelligent safety assessment method of prestressed steel structures based on DTs. In this research method, the structural safety assessment is divided into two aspects: performance analysis and maintenance. By analyzing the characteristics of the construction safety assessment, a DTs framework for construction safety assessment is built. Driven by the DTs framework, a physical space model and a virtual space model are constructed. On the basis of virtual and actual interaction, multidimensional information fusion of time and space is carried out to realize the analysis of structural safety performance. On this basis, the paper establishes a Bow-tie model for the maintenance modeling of unsafe construction events. Moreover, the theoretical method formed is applied to the construction of a symmetrical structure (wheel–spoke cable truss). The validity of the method is verified by comparing the cable force calculated by the theoretical method and measured on site. The assessment method driven by the DTs ensures the structural safety and improves the intelligence level of safety management and control of the structure construction. Full article

A structure does not reach a stable state during the construction process, and hence its structural reliability is low. In order to ensure the safety of the construction process and final structural quality, it is necessary to analyze the safety and structural mechanical properties of large-span space steel structures during the construction process. Based on the engineering background of the polyline symmetrical large-span steel structure construction process, this research established a finite element model of the large-span steel structure on an ANSYS platform. The correctness of the model was verified by comparing the measured frequency of the large-span steel structure with the frequency calculated in the finite element model. Based on the life-death element method, the internal force and deformation response characteristics of the large-span steel structure in the construction process were analyzed, and the different effects of the on-time completion and step-by-step construction on the performance of the broken-line large-span steel structure were compared and analyzed. The study found that the long-span steel truss structure is more sensitive to the construction process, and the final forming state is greatly affected by the construction process. The construction sequence is different, and the structure process and size and distribution of the final stress and deformation are also different. The analysis result of the construction process is closer to that of the actual project. Therefore, appropriate construction paths should be used in the construction process to reduce the impact of path effects on structural performance. It is recommended to pay more attention to the displacement and stress response of the truss when it encounters similar a symmetrical long-span steel structure truss in-place of the forming construction. Full article

Tessellating a periodic unit cell of lattice material to fill a design space in complex geometries has many challenges arising from their computer-aided design (CAD) modeling intricacy. A solution to this difficulty is the use of trimmed micro-truss lattice structures with a conformal net. This paper presents a novel algorithm for constructing conformal lattice net as wireframe of one-dimensional line segments suitable for Bravais cubic symmetric truss-based topologies. The novel algorithm is an excellent candidate when dealing with lattice structures using cubic, body-centered cubic (BCC), face-centered cubic (FCC), and/or diamond unit cell configurations. The wireframe structure is easily transferred into one-dimensional beam elements for microscale optimizations to obtain a functionally graded lattice material. It is shown that introduction of the lattice net resulted in a significant reduction in the mass of the optimized design. Full article

In recent years, the topic of progressive structural collapse has received more attention around the world, and the study of element importance is the key to studying progressive collapse resistance. However, there are many elements in truss structures, making it difficult to predict their importance. The global stiffness matrix contains the specific information of the structure and singularity of the matrix can reflect the safety status of the structure, so it is useful to evaluate the key elements based on the global stiffness matrix for truss structures. In this paper, according to the tangent stiffness-based method for the element importance, the square pyramid grid was chosen as an example, and the distribution rules of key elements under different support conditions, stiffness distributions, and geometric parameters were studied. Then, three common symmetric grid forms, i.e., diagonal square pyramid grids, biorthogonal lattice grids, and biorthogonal diagonal lattice grids, were selected to investigate their importance indices of elements. The principle in this work can be utilized in progressive collapse analysis and safety assessment for spatial truss structures. Full article

With increasing of the size of spatial truss structures, the beam component will be subjected to the overall motion with large deformation. Based on the local frame approach and the geometrically exact beam theory, a beam finite element, which can effectively reduce the rotational nonlinearity and is appropriate for finite motion and deformation issues, is developed. Dynamic equations are derived in the Lie group framework. To obtain the symmetric Jacobian matrix of internal forces, the linearization operation is conducted based on the previously converged configuration. The iteration matrix corresponding to the rotational parameters, including the Jacobian matrix of inertial and internal forces in the initial configuration, can be maintained in the simulation, which drastically improves the computational efficiency. Based on the Lagrangian multiplier method, the constraint equation and its Jacobian matrix of sliding joint are derived. Furthermore, the isogeometric analysis (IGA) based on the non-uniform rational B-splines (NURBS) basis functions, is adopted to interpolate the displacement and rotation fields separately. Finally, three dynamic numerical examples including a deployment dynamic analysis of spatial truss structure are conducted to verify the availability and the applicability of the proposed formulation. Full article
