This paper presents a method for designing a static output feedback integrated path tracking controller for autonomous vehicles. For path tracking, state–space model-based control methods, such as linear quadratic regulator, H_∞ control, sliding mode control, and model predictive control, have been selected as controller design methodologies. However, these methods adopt full-state feedback. Among the state variables, the lateral velocity, or the side-slip angle, is hard to measure in real vehicles. To cope with this problem, it is desirable to use a state estimator or static output feedback (SOF) control. In this paper, an SOF control is selected as the controller structure. To design the SOF controller, a linear quadratic optimal control and sliding mode control are adopted as controller design methodologies. Front wheel steering (FWS), rear wheel steering (RWS), four-wheel steering (4WS), four-wheel independent braking (4WIB), and driving (4WID) are adopted as actuators for path tracking and integrated as several actuator configurations. For better performance, a lookahead or preview function is introduced into the state–space model built for path tracking. To verify the performance of the SOF path tracking controller, simulations are conducted on vehicle simulation software. From the simulation results, it is shown that the SOF path tracking controller presented in this paper is effective for path tracking with limited sensor outputs. Full article

This paper presents a method to design a path tracking controller with a constraint on tire slip angles under low-friction road conditions. On a low-friction road surface, a lateral tire force is easily saturated and decreases as a tire slip angle increases by a large steering angle. Under this situation, a path tracking controller cannot achieve its maximum performance. To cope with this problem, it is necessary to limit tire slip angles to a value where the maximum lateral tire force is achieved. The most commonly used controllers for path tracking, linear quadratic regulator (LQR) and model predictive control (MPC), are adopted as a controller design methodology. The control inputs of LQR and MPC are front and rear steering angles and control yaw moment, which have been widely used for path tracking. The constraint derived from tire slip angles is imposed on the steering angles of LQR and MPC. To fully verify the performance of the path tracking controller with the constraint on tire slip angles, a simulation is conducted on vehicle simulation software. From the simulation results, it is shown that the path tracking controller with the constraint on tire slip angles presented in this paper is quite effective for path tracking on low-friction road surface. Full article

During a steering manoeuvre in a ground vehicle, both yaw motion and roll motion can occur simultaneously, and their dynamics can be coupled, as the roll motion is generalized directly from the tires’ lateral force under steering. Hence, it is of significance to analyze them as an integrated plant in the vehicle steering stability control problem. Furthermore, the actuator saturation of yaw control cannot be neglected, as vehicles often steer at a high velocity or on low-friction roads. In this paper, an integrated steering dynamics model is established considering the coupling between the roll motion and lateral motion, then a novel nonlinear adaptive controller is proposed to stabilize the steering motion considering the actuator saturation of yaw motion control. Simulation results indicate that the designed integrated controller is effective in improving the performance of both the yaw rate tracking error and ride comfort taking into account vehicle parameter uncertainties and actuator saturation; the steering stability of ground vehicles can consequently be guaranteed. Full article

To enhance vehicle maneuverability and stability, a controller with 4-wheel steering (4WS), electronic stability control (ESC) and a torque vectoring device (TVD) under constraint on the front slip angles is designed in this research. In the controller, the control allocation method is adopted to generate yaw moment via 4WS, ESC and TVD. If the front steering angle is added for generating yaw moment, the steering performance of the vehicle can be further deteriorated. This is because the magnitude of the lateral tire forces are limited and the required yaw moment is insufficient. Constraint is imposed on the magnitude of the front slip angles in order to prevent the lateral tire forces from saturating. The driving simulation is performed by considering the limit of the front slip angle proposed in this study. Compared to the case that uses the existing 4WS, the results of this study are derived from the actuator combination that enhances performance while maintaining stability. Full article

Controllability, maneuverability, fault-tolerance/isolation and safety are significantly enhanced in electric vehicles (EV) equipped with the redundant actuator configuration of four-in-wheel electric motors (4IWM). A highly reconfigurable architecture is proposed and illustrated for the adaptive, nonmodel-based control of 4IWM-EVs. Given the longitudinal force, yaw-moment requests and the reconfiguration matrix, each IWM is given a slip reference according to a Slip Vectoring (SV) allocation strategy, which minimizes the overall slip vector norm. The distributed electric propulsion and the slip vector reference allow for a decentralized online estimation of the four-wheel torque-loads, which are uncertain depending on loading and road conditions. This allows for the allocation of four different torques depending on individual wheel conditions and to determine in which region (linear/nonsaturated or nonlinear/saturated) of the torque/slip characteristics each wheel is operating. Consequently, the 4IWMs can be equalized or reconfigured, including actuator fault-isolation as a special case, so that they are enforced to operate within the linear tire region. The initial driving-mode selection can be automatically adjusted and restored among eighteen configurations to meet the safety requirements of linear torque/slip behavior. Three CarSim realistic simulations illustrate the equalization algorithm, the quick fault-isolation capabilities and the importance of a continuous differential action in a critical double-lane-change maneuver. Full article

Professor drivers, including racing drivers, can drive cars to achieve drift motions by taking control of the steering angle in high tire slip ratios, which provides a way to improve the driving safety of autonomous vehicles. The existing studies can be divided into two kinds based on analysis methods, and the theory-based is chosen in this study. Because the recent theory based is most applied for planar models with neglect of the rollover accident risk, the nonlinear vehicle model is established by considering longitudinal, lateral, roll, and yaw motions and rolling safety with the nonlinear tire model UniTire. The drift motion mechanism is analyzed in steady and transient states to obtain drift motion conditions, including the velocity limitation and the relationship between sideslip angle and yaw rate, and vehicle main status parameters including the velocity, side-slip angle and yaw rate in drift conditions. The state-feedback controller is designed based on robust theory and LMI (linear matrix inequation) with uncertain disturbances to realize circle motions in drift conditions. The designed controller in simulations realizes drift circle motions aiming at analyzed status target values by matching the front-wheel steering angle with saturated tire forces, which satisfies the Lyapunov stability with robustness. Robust control in drift conditions solves the problem of how to control vehicles to perform drift motions with uncertain disturbances and improves the driving safety of autonomous vehicles. Full article

Steering has more potential than braking to prevent rear-end collisions at higher relative velocities. A path tracking controller based on multi-input multi-output (MIMO) model predictive control (MPC) is proposed to enhance the handling performance of autonomous emergency steering in this paper. A six-state MIMO bicycle model including actuator dynamics of steering and differential braking is used for model prediction. Two control inputs are front wheel steering angle and direct yaw moment. Two model outputs are lateral displacement and heading angle. According to the work load ratios at four wheels, control allocation is used to determine the optimal braking force distribution to prevent tire force saturation. The performance of a single-input single-output (SISO) MPC that uses only steering angle control to track the lateral displacement of the desired path is employed to benchmark the performance of the proposed algorithm. Simulation results show that both SISO MPC and MIMO MPC can track the path on nominal road surface with high road friction coefficient of 0.9. For a road surface with medium road friction coefficient of 0.7, the SISO MPC is unable to track the path and loses directional stability. However, the MIMO MPC can still track the path and demonstrate robust path tracking and handling enhancement against model uncertainty due to reduced road friction. Full article

The article is dedicated to the control of magnetorheological dampers (MR) included in a semi-active suspension of an all-terrain vehicle moving along a rough road profile. The simulation results of a half-car model and selected feedback vibration control algorithms are presented and analysed with respect to the improvement of driving safety features, such as road holding and vehicle handling. Constant control currents correspond to the passive suspension of different damping parameters. Independent Skyhook control of suspension parts represents the robust and widely used semi-active algorithm. Furthermore, its extension allows for the control of vehicle body heave and pitch vibration modes. Tests of the algorithms are carried out for a vehicle model that is synthesised with particular emphasis on mapping different phenomena occurring in a moving vehicle. The coupling of the vehicle to the road and environment is described by non-linear tire-road friction, rolling resistance, and aerodynamic drag. The pitching behaviour of the vehicle body, as well as the deflection of the suspension, is described by a suspension sub-model that exhibits four degrees of freedom. Further, three degrees of freedom of the complete model describe longitudinal movement of the vehicle and angular motion of its wheels. The MR damper model that is based on hyperbolic tangent function is favoured for describing the key phenomena of the MR damper behaviour, including non-linear shape and force saturation that are represented by force-velocity characteristics. The applied simulation environment is used for the evaluation of different semi-active control algorithms supported by an inverse MR damper model. The vehicle model is subjected to vibration excitation that is induced by road irregularities and road manoeuvres, such as accelerating and braking. The implemented control algorithms and different configurations of passive suspension are compared while using driving-safety-related quality indices. Full article
