The ability to measure vital signs using electromagnetic waves has been extensively investigated as a less intrusive method capable of assessing different biosignal sources while using a single device. On-body antennas, when directly coupled to the human body, offer a comfortable and effective alternative for daily monitoring. Nonetheless, on-body antennas are challenging to design primarily due to the high dielectric constant of body tissues. While the simulation process may often include a body model, a unique model cannot account for inter-individual variability, leading to discrepancies in measured antenna parameters. A potential solution is to increase the antenna’s bandwidth, guaranteeing the antenna’s impedance matching and robustness for all users. This work describes a new on-body microstrip antenna having a stacked structure with parasitic elements, designed and optimized using artificial intelligence (AI). By using an AI-driven design approach, a self-adaptive Bayesian neural network surrogate-model-assisted differential evolution for antenna optimization (SB-SADEA) method to be specific, and a stacked structure having parasitic elements and a defected ground structure with 27 tuneable design parameters, the simulated impedance bandwidth of the on-body antenna was successfully enhanced from 150 MHz to 1.3 GHz, while employing a single and simplified body model in the simulation process. Furthermore, the impact of inter-individual variability on the measured S-parameters was analyzed. The measured results relative to ten subjects revealed that for certain subjects, the SB-SADEA-optimized antenna’s bandwidth reached 1.6 GHz. Full article

Wireless Body Area Networks (WBANs) are human-centric wireless networks, and implantable antennas represent a vital communication component within WBANs. The dielectric properties of human tissue are highly complex, with each layer exhibiting distinct dielectric constants that significantly influence the performance of implanted antennas. It is therefore imperative that a compact broadband implantable antenna be designed in order to address the instability in communication of medical implant devices. The antenna, coated in silicone, is a single-layer structure fed by a coaxial cable, with a volume of just 6 mm × 6 mm× 0.53 mm. A metallic patch is etched on the upper surface of the substrate, and the compact antenna design is enhanced with the introduction of S-shaped, F-shaped, and rectangular slots on the patch. The bottom side of the substrate is etched with rectangular ground planes, which broaden the impedance bandwidth of the antenna. The simulation results demonstrate that the antenna attains an impedance bandwidth of 23.8% (2.08–2.64 GHz), encompassing the entirety of the Industrial, Scientific, and Medical (ISM) band (2.4–2.48 GHz). In order to simulate the working environment of the antenna within the human body, physical tests were conducted on the antenna in pork tissue. The test results demonstrate that the antenna exhibits a measured bandwidth of 28% (2.3–3.03 GHz), with a radiation pattern that displays omnidirectional radiation characteristics. The antenna’s impedance matching and radiation characteristics remain essentially consistent in both bent and unbent states, indicating structural robustness. In comparison to other implantable antennas, this antenna displays a wider impedance bandwidth, a lower Specific Absorption Rate (SAR), and superior implant performance. Full article

Poly(hydroxybutyrate-co-hidroxyvalerate) (PHBV) is a biodegradable polymer, which is a potential substitute for plastics made from fossil resources. Due to its practical interest in the field of tissue engineering, packaging, sensors, and electronic devices, the demand for PHBV with specific thermal, electrical, as well as mechanical requirements is growing. In order to improve these properties, we have developed PHBV blends with two thermoplastic biodegradable polyesters, including poly(caprolactone) (PCL) and poly(lactic acid) (PLA). We analysed the effect of these biopolymers on the morphological, wetting, structural, thermal, mechanical, and electrical characteristics of the materials. Further, the biodegradation of the samples in simulated body fluid conditions was evaluated, as well as the antibacterial activity. The results demonstrate that the blending with PCL and PLA leads to films with a dense morphology, increases the hydrophilic character, and induces a reinforcement of the mechanical characteristics with respect to pristine PHBV. In addition, a decrease in dielectric constant and a.c. electrical conductivity was noticed for PHBV/PLA and PHBV/PCL blends compared to neat PHBV polymer. All neat polymers and blends showed antibacterial properties against S. aureus, with more than 40% bacterial reduction, which increased to 72% in the presence of PCL polymer for a blend ratio of 50/50. Thus, it is demonstrated a suitable way to further tailor a variety of functionalities of PHBV for specific applications, by the development of polymer blends with PLA or PCL. Full article

A compact dual-band, dual-polarized, implantable antenna was designed using the characteristic mode method for operation in the wireless medical telemetry service (WMTS) band (1.4 GHz) and the industrial, scientific, and medical (ISM) band (2.45 GHz). By utilizing slotting techniques and materials with high dielectric constants, the antenna volume was minimized to 47.4 mm³, and circular polarization was gained in the WMTS band by using the characteristic mode method. A three-layer physical model of human tissues was constructed in a simulation, and a biogel and minced pork were used in the measurements. The measured peak gains are −20.85 dBi (1.4 GHz) and −22.15 dBi (2.45 GHz). The measured effective axis ratio bandwidth in the WMTS band is 170 MHz (1.33–1.50 GHz, 12.0%), and the impedance bandwidth in the ISM band is 390 MHz (2.21–2.60 GHz, 16.2%). At 1.4 GHz and 2.45 GHz, the largest 1 g average SAR values are 376 W/Kg and 318 W/Kg, which comply with IEEE C95.1-1999. Moreover, when the communication chain affinity exceeds 20 dB for 1.4 GHz and 2.4 GHz, the transceiver range reaches 8.2 m and 9.7 m. This antenna can be used for implantable wireless telemetry systems. Full article

Bioceramics are used to repair, rebuild, and replace parts of the human body, e.g., bones, joints and teeth, in the form of powder, coatings or prostheses. The synthetic hydroxyapatite [Ca₁₀(PO₄)₆(OH)₂ (HAP)] based on calcium phosphate has been widely used in the medical and dental areas due to the chemical similarity with the inorganic component of human bone tissue. In this work, hydroxyapatite nanocrystalline powders were synthesized by the solid-state reaction method and sintered with a galactomannan and chitosan blend. The bioceramics studied were prepared from 70%, 80% and 90% of hydroxyapatite with 30%, 20% and 10% of galactomannan and chitosan blends, respectively. The influence of the blend content on the bioceramics was investigated through structural, vibrational, thermal, morphological and dielectric characterizations. It was observed that the increase in the blend percentage promoted an increase in the grain size, which was followed by a decrease in the density and hardness of the samples. The sample with a higher amount of polymeric blend also presented a higher dielectric constant and higher losses. Full article

Polymers for implantable devices are desirable for biomedical engineering applications. This study introduces a water-resistant, self-healing fluoroelastomer (SHFE) as an encapsulation material for antennas. The SHFE exhibits a tissue-like modulus (approximately 0.4 MPa), stretchability (at least 450%, even after self-healing in an underwater environment), self-healability, and water resistance (WVTR result: 17.8610 g m⁻² day⁻¹). Further, the SHFE is self-healing in underwater environments via dipole–dipole interactions, such that devices can be protected from the penetration of biofluids and withstand external damage. With the combination of the SHFE and antennas designed to operate inside the body, we fabricated implantable, wireless antennas that can transmit information from inside the body to a reader coil that is outside. For antennas designed considering the dielectric constant, the uniformity of the encapsulation layer is crucial. A uniform and homogeneous interface is formed by simply overlapping two films. This study demonstrated the possibility of wireless communication in vivo through experiments on rodents for 4 weeks, maintaining the maximum communication distance (15 mm) without chemical or physical deformation in the SHFE layer. This study illustrates the applicability of fluoroelastomers in vivo and is expected to contribute to realizing the stable operation of high-performance implantable devices. Full article

Collagen/hydroxyapatite hybrids are promising biomimetic materials that can replace or temporarily substitute bone tissues. The process of biomineralization was carried out through a double diffusion system. The methodological principle consisted in applying an electric field on the incubation medium to promote the opposite migration of ions into collagen membranes to form hydroxyapatite (HA) on the collagen membrane. Two physically separated solutions were used for the incubation medium, one rich in phosphate ions and the other in calcium ions, and their effects were evaluated against the traditional mineralization in Simulated Body Fluid (SBF). Pre-polarization of the organic membranes and the effect of incubation time on the biomineralization process were also assessed by FTIR and Raman spectroscopies.Our results demonstrated that the membrane pre-polarization significantly accelerated the mineralization process on collagen. On the other side, it was found that the application of the electric field influenced the collagen structure and its interactions with the mineral phase. The increment of the mineralization degree enhanced the photoluminescence properties of the collagen/HA materials, while the conductivity and the dielectric constant were reduced. These results might provide a useful approach for future applications in manufacturing biomimetic bone-like materials. Full article

In-body biomedical devices (IBBDs) are receiving significant attention in the discovery of solutions to complex medical conditions. Biomedical devices, which can be ingested, injected or implanted in the human body, have made it viable to screen the physiological signs of a patient wirelessly, without regular hospital appointments and routine check-ups, where the antenna is a mandatory element for transferring bio-data from the IBBDs to the external world. However, the design of an in-body antenna is challenging due to the dispersion of the dielectric constant of the tissues and unpredictability of the organ structures of the human body, which can absorb most of the antenna radiation. Therefore, various factors must be considered for an in-body antenna, such as miniaturization, link budget, patient safety, biocompatibility, low power consumption and the ability to work effectively within acceptable medical frequency bands. This paper presents a comprehensive overview of the major facets associated with the design and challenges of in-body antennas. The review comprises surveying the design specifications and implementation methodology, simulation software and testing of in-body biomedical antennas. This work aims to summarize the recent in-body antenna innovations for biomedical applications and indicates the key research challenges. Full article

The objective of this paper is to develop a wearable circular UWB MIMO antenna array, consisting of four elements, that is capable of detecting and locating tumor cells within a heterogeneous breast phantom. The antenna element operates within a bandwidth from 2.4 GHz to 10.6 GHz when FR4 is used as the substrate, and extends from 2.57 GHz to 12.6 GHz when a Dacron fabric is used instead. The antenna is fabricated and measured, yielding highly similar results to the simulated outcomes. In the suggested detection system, one antenna is used for transmission, while the other antennas receive the transmitted signal. The employed antenna demonstrates gains of 5.49 dBi, 9.87 dBi, 11.9 dBi, and 14.7 dBi at resonant frequencies of 2.84 GHz, 3.87 GHz, 5.83 GHz, and 8.24 GHz, respectively, when a Dacron fabric is used as the substrate. Moreover, the proposed antenna exhibits a flexible shape with minimal vertical and horizontal bending effects across the entire operating frequency band. The antenna has a compact size of 42.85 × 42.85 mm² and is printed on an FR4 substrate with a dielectric constant of 4.5 and a thickness of 1.6 mm for testing purposes. The S-parameters of the suggested system can effectively identify and precisely locate small tumors. Furthermore, the SAR findings indicate that the amount of power absorbed by the breast phantom tissues complies with the IEEE standards, thus confirming the suitability of the recommended antenna for the early detection and localization of breast cancer. Full article

Background: In our previous randomized controlled trial (RCT), the progression/no progression of mild breast cancer-related arm lymphedema (BCRL) was examined among women randomized to a compression group (CG) with a compression sleeve (compression class (ccl) 1) or not (NCG) for 6 months. In the present prospective study, BCRL in the CG and NCG was followed for 12 months. Methods: At the end of the RCT, 33 women with mild BCRL were eligible in the CG and 37 in the NCG. The proportional differences in no progression/progression of BCRL were defined as a >2% increase from start of RCT or exceeding 10% in the lymphedema relative volume as measured by the water displacement method. In addition, changes in the lymphedema relative volume and tissue dielectric constant ratio, which measures local tissue water, were examined. At the end of the RCT (i.e., after 6 months), a one-month break of the compression treatment was made in the CG. If the lymphedema relative volume progressed by definition, the compression treatment was resumed and continued, with follow-up of all women at 9 and 12 months. Results: A larger proportion of women in the NCG showed progression (57%, 61%, 67%) compared to the CG (16%, 22%, 31%) at 6, 9, and 12 months (p < 0.001, 0.005, 0.012), respectively. Twelve (33%) women in the NCG did not progress at all. No changes of the lymphedema relative volume and local tissue water were found over time at any follow-ups, but were stable on a low level. Conclusions: To avoid the progression of mild BCRL into a chronic issue in the long-term, compression sleeve ccl 1 may be applied immediately after early diagnosis of mild BCRL. Full article

Lymphedema can develop after treatment for breast cancer (BCRL). Lymphedema of the breast is not well studied. Currently, the main techniques used to diagnose and monitor the effectiveness of treatment are subjective clinician assessment and patient reports. Eighty-nine women who had undergone breast cancer treatment were recruited with and without breast lymphedema. Blinded clinical assessment determined the presence or absence of breast lymphedema. Measurement of skin thickness by ultrasound scanning, local tissue water by tissue dielectric constant (TDC) and tissue indentation by tonometry was recorded. Breast cancer treatment and demographic details were documented. Descriptive statistics were undertaken to compare sample characteristics, including the Chi-squared test, Odds Ratio (OR) and Relative Risks (RR) calculated. Increased body mass index (BMI), larger bra size, increased number of positive lymph nodes, axillary surgery, chemotherapy and increased Nottingham Prognostic Index (NPI) were all associated with breast lymphedema (p < 0.05). Ultrasound and TDC measurements were significantly higher in the lymphedema group (p < 0.05). Receiver Operator Characteristic (ROC) curves demonstrated that ultrasound and TDC measurements could distinguish between edematous and non-edematous breasts. Threshold levels were produced, which demonstrated good levels of sensitivity and specificity. These findings have the potential to improve the diagnosis of breast lymphedema. Full article

The research on extracellular matrix (ECM) is new and developing area that covers cell proliferation and differentiation and ensures improved cell viability for different biomedical applications. Extracellular matrix not only maintains biological functions but also exhibits properties such as tuned or natural material degradation within a given time period, active cell binding and cellular uptake for tissue engineering applications. The principal objective of this study is classified into two categories. The first phase is optimization of various electrospinning parameters with different concentrations of HAP-HPC/PLA(hydroxyapatite-hydroxypropylcellulose/poly lactic acid). The second phase is in vitro biological evaluation of the optimized mat using MTT (3-(4,5-dimethylthiazol-2-yl)-2,5-diphenyl tetrazolium bromide) assay for bone regeneration applications. Conductivity and dielectric constant were optimized for the production of thin fiber and bead free nanofibrous mat. With this optimization, the mechanical strength of all compositions was found to be enhanced, of which the ratio of 70:30 hit a maximum of 9.53 MPa (megapascal). Cytotoxicity analysis was completed for all the compositions on MG63 cell lines for various durations and showed maximum cell viability on 70:30 composition for more than 48 hrs. Hence, this investigation concludes that the optimized nanofibrous mat can be deployed as an ideal material for bone regenerative applications. In vivo study confirms the HAP-HPC-PLA sample shows more cells and bone formation at 8 weeks than 4 weeks. Full article

A flexible antenna of compact size with a dual band elliptical-shape implantable is designed for biomedical purposes. The suggested antenna has an elliptical shape to be more comfortable for being implanted in human tissue. The implantable antenna is printed on RO3010 substrate with 2 mm as a thickness and 10.2 as a dielectric constant. It consists of an active planar C-shaped element and a parasitic planar inverted C-shaped element. The proposed antenna is designed with a major axis radius of 12 mm and a minor axis radius of 8 mm. It operates in dual bands: The Industrial Scientific and Medical band (ISM) [2.4 GHz–3.5 GHz] and Medical Implant Communications Service band (MICS) [394 MHz–407.61 MHz]. A short-circuited pin is used to minimize the antenna’s overall size and for further size reduction a capacitive load is used between the radiator and the ground plane. For biocompatibility, a thin-thickness layer of Alumina is used as a superstrate. The suggested antenna is tested in a multi-layer tissue model and the Specific Absorption Rate (SAR) value is computed. The proposed antenna was fabricated, and the reflection coefficient is measured and compared with simulated results. Full article

A modified monopole patch antenna for microwave-based hemorrhagic or ischemic stroke recognition is presented in this article. The designed antenna is fabricated on a cost-effective FR-4 lossy material with a 0.02 loss tangent and 4.4 dielectric constant. Its overall dimensions are 0.32 λ × 0.28 λ × 0.007 λ, where λ is the lower bandwidth 1.3 GHz frequency wavelength. An inset feeding approach is utilized to feed the antenna to reduce the input impedance (z = voltage/current). A total bandwidth (below −10 dB) of 2.4 GHz (1.3–3.7 GHz) is achieved with an effective peak gain of over 6 dBi and an efficiency of over 90%. A time-domain analysis confirms that the antenna produces minimal signal distortion. Simulated and experimental findings share a lot of similarities. Brain tissue is penetrated by the antenna to a satisfactory degree, while still exhibiting a safe specific absorption rate (SAR). The maximum SAR value measured for the head model is constrained to be equal to or below 0.1409 W/kg over the entire usable frequency band. Evaluation of theoretical and experimental evidence indicates the intended antenna is appropriate for Microwave Imaging (MWI) applications. Full article

In this paper, absorption phenomena in a hollow waveguide with an inserted graded dielectric layer are studied, for the case of transverse electric (TE) wave propagation. The waveguide model aims to be applicable to a study of a potential cancer treatment by heating of gold nanoparticles (GNPs) inside the cancer cells. In our previous work, general exact analytical fomulas for transmission, reflection, and absorption coefficients were derived. These fomulas are further developed here to be readily applicable to the calculation of the absorption coefficient within the inserted lossy layer only, quantifying the absorption in the GNP-fed cancer tissue. To this end, we define new exact analytic scale factors that eliminate unessential absorption in the surrounding lossy medium. In addition, a numerical model was developed using finite element method software. We compare the numerical results for power transmission, reflection and absorption coefficients to the corresponding results obtained from the new modified exact analytic fomulas. The study includes both a simple example of constant complex permittivities, and a more realistic example where a dispersive model of permittivity is used to describe human tissue and the electrophoretic motion of charged GNPs. The results of the numerical study with both non-dispersive and dispersive permittivities indicate an excellent agreement with the corresponding analytical results. Thus, the model provides a valuable analytical and numerical tool for future research on absorption phenomena in GNP-fed cancer tissue. Full article
