The accordion honeycomb has unique deformation characteristics in cellular materials. This study develops a three-dimensional equivalent Cauchy continuum model (3D-ECM) based on the variational asymptotic method (VAM) to efficiently predict the mechanical response of the accordion honeycomb. The accuracy of the 3D-ECM is validated via quasi-static compression experiments on 3D-printed specimens and detailed 3D finite element simulations (3D-FEM), showing a strong correlation between simulation and experimental data. Parametric analyses reveal that the re-entrant angle, ligament-to-strut length ratio, and thickness ratios significantly affect the equivalent elastic moduli, providing insights into geometric optimization strategies for targeted mechanical performance. Comparative experiments among honeycomb structures with positive, negative, and zero Poisson’s ratios show that the accordion honeycomb achieves superior dimensional stability and tunable stiffness but exhibits lower energy-absorption efficiency due to discontinuous buckling and recovery processes. Further comparison among different ZPR honeycombs confirms that the accordion design offers the highest equivalent modulus in the re-entrant direction. The findings underscore the accordion honeycomb’s promise in scenarios demanding structural reliability, tunable stiffness, and moderate energy absorption. Full article

Metamaterials, owing to their exceptional properties such as a negative Poisson’s ratio, phonon band gap, and energy absorption, have garnered significant interest in aerospace, automotive transportation, and other domains. The increasing demand for metamaterial structures with diverse specialized attributes requires innovative design approaches. In this study, a novel bi-material triangular curved beam honeycomb metamaterial (BTBM) is designed, which exhibits a tunable Poisson’s ratio (PR), coefficient of thermal expansion (CTE), and band gap characteristics. These properties are intrinsically coupled through the geometric and material design of the bi-material triangular curved beam structure, meaning that adjustments to the unit cell configuration simultaneously influence PR, CTE, and band gap behavior. This dual-mode control offers versatile design strategies for multifunctional metamaterials. The energy band structure is calculated using finite element simulation analysis, and its accuracy is validated by computing the transmission characteristic curve. Numerical simulations were performed to systematically analyze the coupled effects of geometric parameters and material combinations on the PR and CTE. The results demonstrate significant tunability of these mechanical properties through parametric optimization. The results of this study provide valuable insights into the design and optimization of metamaterial structures with tailored properties for various applications. Full article

A novel cross tetrachiral honeycomb metamaterial is proposed, which not only possesses the negative Poisson’s ratio property, but also has a wide-frequency bandgap. The effective elastic parameters of the cross tetrachiral honeycomb are first theoretically analyzed; then, its designable performances for negative Poisson’s ratio and elastic modulus are studied by varying geometric parameters. The dynamic properties of the cross tetrachiral honeycomb metamaterial are investigated by analyzing the band structure. It is shown that without the addition of external mass to the structure, a designable wide bandgap can be generated to isolate the in-plane waves effectively by selecting the ligament angles and the radius of central cylinder. In addition, an effective approach is proposed for tuning the bandwidth without changing the geometric parameters of the structure. Compared to classical negative Poisson’s ratio metamaterials, the proposed cross tetrachiral honeycomb metamaterial is designable and tunable for achieving a specific static or dynamic performance, and has potential applications in engineering practice. Full article

By adjusting the two wall angles of the orthogonal hybrid honeycomb (OHH), the tunable Poisson’s ratio change from negative to positive values and the variation in stiffness can be achieved. To effectively analyze its static and dynamic characteristics, a two-dimensional equivalent Kirchhoff–Love model (2D-EKM) is established based on the variational asymptotic method (VAM).This model aids in effectively addressing the complexity arising from anisotropy. The obtained equivalent orthotropic properties are validated through unit-cell uniaxial compression tests and three-point bending experiments on 3D-printed specimens. The numerical simulation results suggest that the VAM-based 2D-EKM can predict the in-plane and out-of-plane static behaviors of OHH panels, with a maximum error below 10%. Particularly in the dynamic analysis of a four-sided fixed OHH panel, the analysis time required by 2D-EKM is only 0.37% of that needed for the 3D FE model. The OHH-ZPR panel exhibits exceptional resistance to deformation, with a maximum deformation under in-plane tension reaching only 27% of that in the OHH-PPR panel. Moreover, each 1% increase in the height–length ratio results in a respective increase of 275.62% and 281.93% in equivalent bending stiffness along both directions. This highlights that enhancing this ratio effectively boosts the fundamental frequency compared to the elastic modulus ratio, effectively prevents low-frequency resonance occurrences, and offers vital insights for the design and optimization of OHH panels. Full article

Auxetic structures, renowned for their unique lateral expansion under longitudinal strain, have attracted significant research interest due to their extraordinary mechanical characteristics, such as enhanced toughness and shear resistance. This study provides a systematic exploration of these structures, constructed from rigid rotating square or rectangular unit cells. Incremental alterations were applied to key geometrical parameters, including the angle ($\theta$) between connected units, the side length (a), the side width (b) of the rotating rigid unit, and the overlap distance (t). This resulted in a broad tunable range of negative Poisson’s ratio values from −0.43 to −1.78. Through comprehensive three-dimensional finite-element analyses, the intricate relationships between the geometric variables and the resulting bulk Poisson’s ratio of the modeled auxetic structure were elucidated. This analysis affirmed the auxetic behavior of all investigated samples, characterized by lateral expansion under tensile force. The study also revealed potential stress concentration points at interconnections between rotating units, which could impact the material’s performance under high load conditions. A detailed investigation of various geometrical parameters yielded fifty unique samples, enabling in-depth observation of the impacts of geometric modifications on the overall behavior of the structures. Notably, an increase in the side width significantly enhanced the Poisson’s ratio, while an increase in the overlap distance notably reduced it. The greatest observable change in the Poisson’s ratio was a remarkable 202.8%, emphasizing the profound influence of geometric parameter manipulation. A cascaded forward propagation–backpropagation neural network model was deployed to determine the Poisson’s ratio for auxetic structures, based on the geometric parameters and material properties of the structure. The model’s architecture consisted of five layers with varying numbers of neurons. The model’s validity was affirmed by comparing its predictions with FEA simulations, with the maximum error observed in the predicted Poisson’s ratio being 8.62%. Full article

Research on auxetic metamaterials is important due to their high performance against impact loadings and their usefulness in actuators, among other applications. These metamaterials offer a negative Poisson’s ratio at the macro level. However, usual auxetic metamaterials face challenges in (1) grading the effect, (2) coupling and combining auxetic metamaterials with non-auxetic materials due to boundary compatibility, (3) obtaining the same auxetic behavior in all directions in the transverse plane, and (4) adapting the regular geometry to the component design boundary and shape. The goal of this paper is to present a novel, recently patented tunable 3D metamaterial created to reproduce a wide spectrum of 3D auxetic and non-auxetic Poisson’s ratios and Young’s moduli. This wide range is obtained using the same basic unit cell geometry and boundary connections with neighboring cells, facilitating designs using functionally graded metamaterials as only the connectivity and position of the cell’s internal nodes are modified. Based on simple spatial triangularization, the metamaterial is easily scalable and better accommodates spatial curvatures or boundaries by changing the locations of nodes and lengths of bars. Full article

The additive manufacturing (AM) of innovative lattice structures with unique mechanical properties has received widespread attention due to the capability of AM processes to fabricate freeform and intricate structures. The most common way to characterize the additively manufactured lattice structures is via the uniaxial compression test. However, although there are many applications for which lattice structures are designed for bending (e.g., sandwich panels cores and some medical implants), limited attention has been paid toward investigating the flexural behavior of metallic AM lattice structures with tunable internal architectures. The purpose of this study was to experimentally investigate the flexural behavior of AM Ti-6Al-4V lattice structures with graded density and hybrid Poisson’s ratio (PR). Four configurations of lattice structure beams with positive, negative, hybrid PR, and a novel hybrid PR with graded density were manufactured via the laser powder bed fusion (LPBF) AM process and tested under four-point bending. The manufacturability, microstructure, micro-hardness, and flexural properties of the lattices were evaluated. During the bending tests, different failure mechanisms were observed, which were highly dependent on the type of lattice geometry. The best response in terms of absorbed energy was obtained for the functionally graded hybrid PR (FGHPR) structure. Both the FGHPR and hybrid PR (HPR) structured showed a 78.7% and 62.9% increase in the absorbed energy, respectively, compared to the positive PR (PPR) structure. This highlights the great potential for FGHPR lattices to be used in protective devices, load-bearing medical implants, and energy-absorbing applications. Full article

Myocardial infarction is one of the largest contributors to cardiovascular disease and reduces the ability of the heart to pump blood. One promising therapeutic approach to address the diminished function is the use of cardiac patches composed of biomaterial substrates and cardiac cells. These patches can be enhanced with the application of an auxetic design, which has a negative Poisson’s ratio and can be modified to suit the mechanics of the infarct and surrounding cardiac tissue. Here, we examined multiple auxetic models (orthogonal missing rib and re-entrant honeycomb in two orientations) with tunable mechanical properties as a cardiac patch substrate. Further, we demonstrated that 3D printing based auxetic cardiac patches of varying thicknesses (0.2, 0.4, and 0.6 mm) composed of polycaprolactone and gelatin methacrylate can support induced pluripotent stem cell-derived cardiomyocyte function for 14-day culture. Taken together, this work shows the potential of cellularized auxetic cardiac patches as a suitable tissue engineering approach to treating cardiovascular disease. Full article

Using first-principles calculations, we predict highly stable cubic bialkali bismuthides Cs(Na, K)₂Bi with several technologically important mechanical and anisotropic elastic properties. We investigate the mechanical and anisotropic elastic properties under hydrostatic tension and compression. At zero pressure, CsK₂Bi is characterized by elastic anisotropy with maximum and minimum stiffness along the directions of [111] and [100], respectively. Unlike CsK₂Bi, CsNa₂Bi exhibits almost isotropic elastic behavior at zero pressure. We found that hydrostatic tension and compression change the isotropic and anisotropic mechanical responses of these compounds. Moreover, the auxetic nature of the CsK₂Bi compound is tunable under pressure. This compound transforms into a material with a positive Poisson’s ratio under hydrostatic compression, while it holds a large negative Poisson’s ratio of about −0.45 along the [111] direction under hydrostatic tension. An auxetic nature is not observed in CsNa₂Bi, and Poisson’s ratio shows completely isotropic behavior under hydrostatic compression. A directional elastic wave velocity analysis shows that hydrostatic pressure effectively changes the propagation pattern of the elastic waves of both compounds and switches the directions of propagation. Cohesive energy, phonon dispersion, and Born–Huang conditions show that these compounds are thermodynamically, mechanically, and dynamically stable, confirming the practical feasibility of their synthesis. The identified mechanisms for controlling the auxetic and anisotropic elastic behavior of these compounds offer a vital feature for designing and developing high-performance nanoscale electromechanical devices. Full article

The synthesized understanding of the mechanical properties of negative Poisson’s ratio (NPR) convex–concave honeycomb tubes (CCHTs) under quasi-static and dynamic compression loads is of great significance for their multifunctional applications in mechanical, aerospace, aircraft, and biomedical fields. In this paper, the quasi-static and dynamic compression tests of three kinds of 3D-printed NPR convex–concave honeycomb tubes are carried out. The sinusoidal honeycomb wall with equal mass is used to replace the cell wall structure of the conventional square honeycomb tube (CSHT). The influence of geometric morphology on the elastic modulus, peak force, energy absorption, and damage mode of the tube was discussed. The experimental results show that the NPR, peak force, failure mode, and energy absorption of CCHTs can be adjusted by changing the geometric topology of the sinusoidal element. Through the reasonable design of NPR, compared with the equal mass CSHTs, CCHTs could have the comprehensive advantages of relatively high stiffness and strength, enhanced energy absorption, and damage resistance. The results of this paper are expected to be meaningful for the optimization design of tubular structures widely used in mechanical, aerospace, vehicle, biomedical engineering, etc. Full article

In this study, nanocellulose aerogels with a tunable Poisson’s ratio were fabricated. Tissue engineering scaffolds with a tunable Poisson’s ratio may be better able to simulate the mechanical behavior of natural tissues. A mixture of cellulose nanofibers (CNFs) and polyethylene glycol diacrylate (PEGDA) was used as the raw material to prepare CNF/PEGDA aerogels with a multiscale pore structure through a combination of stereolithography (SLA) and freeze-drying. The aerogels were fabricated with a regular macropore network structure and a random and homogeneous distribution of micropores. The macropore structure of the scaffolds could be customized through SLA, which resulted in scaffolds that exhibited one of three different mechanical behaviors: positive Poisson’s ratio (PPR), negative Poisson’s ratio (NPR) or zero Poisson’s ratio (ZPR). Then, the hydrogel scaffolds were transformed into aerogel scaffolds through the freeze-drying method, which endowed the scaffolds with homogeneously distributed micropores. The material ratio and exposure were adjusted to obtain scaffolds with a clear pore structure. Then, the CNF/PEGDA scaffolds with different Poisson’s ratios were subjected to mechanical tests, and their chondrogenic induction characteristics were determined. The NPR scaffold not only provided a good environment for cell growth but also affected mouse bone marrow mesenchymal stem cell (mBMSC) proliferation and chondrogenic induction. Thus, we provide a feasible scheme for the preparation of three-dimensional scaffolds with a multiscale pore structure and tunable Poisson’s ratio, which contributes to cartilage repair in tissue engineering. Full article

A novel hierarchical metamaterial with tunable negative Poisson’s ratio is designed by a re-entrant representative unit cell (RUC), which consists of star-shaped subordinate cells. The in-plane mechanical behaviors of star-re-entrant hierarchical metamaterial are studied thoroughly by finite element method, non-dimensional effective moduli and effective Poisson’s ratios (PR) are obtained, then parameters of cell length, inclined angle, thickness for star subordinate cell as well as the amount of subordinate cell along x, y directions for re-entrant RUC are applied as adjustable design variables to explore structure-property relations. Finally, the effects of the design parameters on mechanical behavior and relative density are systematically investigated, which indicate that high specific stiffness and large auxetic deformation can be remarkably enhanced and manipulated through combining parameters of both subordinate cell and parent RUC. It is believed that the new hierarchical metamaterial reported here will provide more opportunities to design multifunctional lightweight materials that are promising for various engineering applications. Full article

Systematic and deep understanding of mechanical properties of the negative Poisson’s ratio convex-concave foams plays a very important role for their practical engineering applications. However, in the open literature, only a negative Poisson’s ratio effect of the metamaterials convex-concave foams is simply mentioned. In this paper, through the experimental and finite element methods, effects of geometrical morphology on elastic moduli, energy absorption, and damage properties of the convex-concave foams are systematically studied. Results show that negative Poisson’s ratio, energy absorption, and damage properties of the convex-concave foams could be tuned simultaneously through adjusting the chord height to span ratio of the sine-shaped cell edges. By the rational design of the negative Poisson’s ratio, when compared to the conventional open-cell foams of equal mass, convex-concave foams could have the combined advantages of relative high stiffness and strength, enhanced energy absorption and damage resistance. The research of this paper provides theoretical foundations for optimization design of the mechanical properties of the convex-concave foams and thus could facilitate their practical applications in the engineering fields. Full article
