Search Results (23)

This study analyzes the thermodynamic and economic viability of modified high-temperature gas-cooled reactor (HTGR) gas-steam combined heat and power (CHP) systems compared to conventional CHP plants. The research addresses the critical need for efficient and sustainable energy production methods. Using comprehensive thermodynamic modeling and economic analysis, the study evaluates system performance under various operating conditions. Key findings reveal that modified CHP plants with HTGR and turboexpanders (TEs) demonstrate significantly higher efficiency and lower heat generation costs compared to conventional gas turbine (GT) CHP plants, despite higher initial capital investments. The modified systems achieve electricity generation efficiencies up to 48%, surpassing traditional nuclear power plants. The absence of CO₂ emissions and lower fuel costs in HTGR systems contribute to their economic advantage. This research provides novel insights into the potential of HTGR technology in CHP applications, offering a promising solution for future energy systems. The study’s originality lies in its comprehensive comparison of conventional and modified CHP systems, considering both thermodynamic and economic aspects, which has not been extensively explored in existing literature. Full article

Increasing the share of renewable energy sources (RESs) in the energy mix of countries is one of the main objectives of the energy transition in national economies, which must be established on circular economy principles. In the natural gas storage in geological structures (UGSs), natural gas is stored in a gas reservoir at high reservoir pressure. During a withdrawal cycle, the energy of the stored pressurised gas is irreversibly lost at the reduction station chokes. At the same time, there is a huge amount of produced reservoir water, which is waste and requires energy for underground disposal. The manuscript explores harnessing the exergy of the conventional UGS reduction process to generate electricity and produce hydrogen via electrolysis using reservoir-produced water. Such a model, which utilises sustainable energy sources within a circular economy framework, is the optimal approach to achieve a clean energy transition. Using an innovative integrated mathematical model based on real UGS production data, the study evaluated the application of a turboexpander (TE) for electricity generation and hydrogen production during a single gas withdrawal cycle. The simulation results showed potential to produce 70 tonnes of hydrogen per UGS withdrawal cycle utilising 700 m³ of produced field water. The analysis showed that hydrogen production was sensitive to gas flow changes through the pressure reduction station, underscoring the need for process optimisation to maximise hydrogen production. Furthermore, the paper considered the categorisation of this hydrogen as “green” as it was produced from the energy of pressurised gas, a carbon-free process. Full article

With the in-depth research on hypersonic aerodynamics and hypersonic propulsion technology, humans are growing closer to space travel. Recent studies have shown that the pre-cooled air-turborocket (ATR) or turboexpander engines are some of the potential propulsion methods for reusable space vehicles and single stage-to-orbit (SSTO) missions because they have a high specific impulse at low Mach numbers, which can overcome the problem of the “thrust gap” in turbine-based combined-cycle (TBCC) engines. The ATR engine needs an additional oxidizing agent and the turboexpander engine usually uses hydrogen as fuel, which has low energy density and poor safety. To address this problem, this paper proposed a high-energy-density (HED) hydrocarbon-fueled turboexpander engine, and its feasibility has been proven through a simplified thermodynamic model. Through detailed thermodynamic analysis based on the energy and pressure balance, this paper analyzed the performance characteristics of the engine to evaluate its capacity to work in a wide speed range at low Mach numbers. The results show that the endothermic hydrocarbon-fueled turboexpander engine has good specific impulse in Mach 0∼4 at an equivalence ratio of 0.7∼1.3, and the turboexpander engine can be combined with the dual-mode scramjet and become an efficient acceleration method for SSTO missions and the reusable spacecraft. Full article

The hydrogen hydrostatic thrust bearing (HHTB) is a key component of hydrogen liquefaction that impacts turbo-expander characteristics. To analyze the feasibility of using the HHTB in this application, characteristics of HHTBs were calculated using a CFD model. To upgrade the performance of the HHTB, the impacts of bearing structure and operating parameters on static performance were investigated. Dynamic characteristics of the HHTB were studied using the dynamic grid method. It was found that the load capacity of the HHTB is less than that of helium-lubricated bearings but higher than that of air- and methane-lubricated bearings. The turbulent kinetic energy of hydrogen is higher than that of other gases. Load capacity can be enhanced through boosting supplied pressure, expanding the diameter of supply orifices, reducing gas film clearance, increasing the orifices quantity and setting a circumferential groove. A reduction in disturbance amplitude slightly increased the bearing’s dynamic stiffness. The dynamic stability of the HHTB was improved by a small film clearance in response to disturbance. Full article

Bioenergy with Carbon Capture and Storage (BECCS) technologies are fundamental to reach negative CO₂ emissions by removing it from the atmosphere and storing it underground. A promising solution to implement BECCS is pressurized Chemical Looping Combustion (CLC), which involves coupling a pressurized CLC reactor system to a turboexpander. The typical configuration chosen is to have an air reactor and a fuel reactor based on coupled circulating fluidized beds. The fluidization regime in both reactors is preferred to be fast fluidization to enhance gas particle contact and solids circulation among reactors. To design the two reactors, Aspen Plus software was used, given that the new version has a module for fluidized bed modeling. At first, the oxygen carrier was designed ex novo, but given that it is a composite compound mainly made by nickel oxide freeze-granulated on alumina (Ni40Al-FG), the molecular structure has been inserted in Aspen Plus. Then, based on the power of the gas turbine, the power output per kg of evolving fluid (in this case, depleted air) is calculated using Aspen Plus. Once the nitrogen content in the depleted air is known, the total air at the inlet of the air reactor is calculated. The fuel reactor is modeled by inserting the reduction reactions for nickel-based oxygen carriers. The paper presents a useful methodology for developing pressurized Chemical Looping Combustors to be coupled to gas turbines for power generation. The provided data will be cross-validated with 0D-models and experimental results. Full article

The annual increase in demand for electrical power is accompanied by a significant combustion of hydrocarbon fuels and, accordingly, significant CO₂ emissions into the atmosphere, which, in turn, result in increasing the surface temperature of our planet. In addition, hydrocarbon fuel reserves are also depleted every year, which raises the question of the efficient use of fossil fuels. One of the promising solutions to this problem is introducing a technology that allows using the excess gas pressure at gas distribution points in order to generate additional electrical energy. As a rule, a radial turboexpander is used to convert the kinetic energy of natural gas at low power. In this paper, we study a method to reduce losses in a volute inlet of a radial expander. Based on our research, we could find that the use of two symmetrical fins in the volute inlet pipe makes it possible to decrease the turbulent kinetic energy by 1.29% and to reduce the energy losses in the inlet pipe by 2.18%. Full article

The application of expansion turbines at natural gas pressure reduction stations (PRS) is considered in order to recover energy contained in the natural gas. This energy is irretrievably lost at the reduction stations which use the traditional pressure reducer. Expanders allow for the electricity production for PRS own needs and for resale. The paper presents an analysis of the possibility of using turboexpanders at PRS in Poland. Authors performed static simulations for the assumed data sets and dynamic simulations for annual data from selected representative natural gas reduction and measurement stations. Energy balances are presented for the discussed scenarios that compare the energy requirements of natural gas pressure reduction stations which use a classic pressure reducer or turboexpander (TE). Using static simulations, authors investigated whether the use of a turboexpander is economically justified for the case if it is used only to supply the reduction station with electricity. Dynamic analyses were carried out using real data. In addition, static analyses were performed for a natural gas reduction and measurement station using a PEM fuel cell for the production of electricity in a combined gas heating system. At higher inlet temperatures and pressures, the expansion process was more economical due to the lower heat power requirement and the greater amount of produced electricity. The PRS with the turboexpander compared to the PRS with the reducer required the supply of thermal energy which did not allow the PRS to lower operating costs for the assumed prices of heat and electricity. The reduction system with the PEM fuel cell in the combined heating system positively achieved lower operating costs of the PRS (without taking into account the investment costs). Total annual costs for PRS with a reducer was PLN 1,593,167.04, and for PRS with TE + PEM PLN 1,430,595.60—the difference was PLN 108,571.44 in favor of the arrangement with TE and PEM. The payback time should be investigated, although the use of such a system gives the impression of oversizing. An increase in the electricity purchase price and a decrease in the natural gas purchase price may contribute to the investment in the future. Full article

This perspective describes different schemes of power systems integration for various process technology in oil refining and petrochemistry with a focus on distillation. An overview is given of different methods of gas turbines and turboexpanders. Application of the organic Rankine cycle is considered for distillation processes, especially for unconventional schemes, which are integrated into the main process as stand-alone ones, as well when the working fluid of an energy system is a process stream per se. Despite a more complex structure and potential interference with the main process, such schemes are advantageous in terms of more efficient equipment utilization. Integration of turboexpanders in separation processes and in reactor units can improve energy generation efficiency 2–3 fold compared with traditional schemes of energy generation from fossil feedstock. From the economic viewpoint for distillation columns, total annual costs can be decreased by ca. 5–15% with the specific costs of additional generated electricity being very close to the costs of a heating utility. Full article

The liquefaction of hydrogen is considered to be a crucial process in the large-scale utilization of hydrogen energy. In hydrogen liquefaction, hydrogen turbo-expander is a key refrigerating machine for high liquefaction efficiency. Performance of the turbo-expander is directly affected by the hydrogen gas bearings. To obtain a deep understanding of the performance characteristics of hydrogen gas bearings, the static and dynamic characteristics of herringbone grooved journal bearings under hydrogen and other lubricating gases were numerically calculated and compared. The bearing load capacity and critical mass of hydrogen gas bearings were slightly lower than those of helium-, air- and nitrogen-lubricated bearings. To improve the performance of the hydrogen gas bearings used in high-speed turbo-machinery, the influence of working conditions was analyzed. It is found that the load capacity of hydrogen gas bearings can be improved by increasing the ambient pressure, reducing the gas film clearance, and raising the bearing eccentricity ratio. Meanwhile, the critical mass increases, and the bearing dynamic stability is enhanced. Full article

The fuel source of many simple and combined-cycle power plants usually comes from a nearby natural gas transmission pipeline at a pressure from 50 to over 70 bar. The use of a turboexpander instead of throttling equipment offers a promising alternative to regulate the pressure of natural gas introduced to the power plant. Specifically, it helps recover part of the available energy of the compressed gas in the transmission pipeline, increase the power output and efficiency of the gas turbine system, and decrease the fuel use and harmful emissions. In this paper, the addition of such a turboexpander in a gas pressure-reduction station is studied. The recovered power is then used to drive the compression of extra air added to the combustion chamber of a heavy-duty gas turbine. The performance of this configuration is analyzed for a wide range of ambient temperatures using energy and exergy analyses. Fuel energy recovered in this way increases the output power and the efficiency of the gas turbine system by a minimum of 2.5 MW and 0.25%, respectively. The exergy efficiency of the gas turbine system increases by approximately 0.36% and the annual CO₂ emissions decrease by 1.3% per MW. Full article

With the increased commercialization of high-temperature superconducting (HTS) power cables cooled using liquid nitrogen and the use of liquefied natural gas as fuel, the need for large-capacity reverse Brayton cryogenic systems is gradually increasing. In this paper, the thermodynamic design of a reverse Brayton cryogenic system with a cooling capacity of the 2 kW class at 77 K using neon as a refrigerant is described. Unlike conventional reverse Brayton systems, the proposed system uses a cryogenic turbo-expander, scroll compressor, and plate-type heat exchanger. The performance test conducted on the fabricated system is also described. The isentropic efficiency of the cryogenic turbo-expander was measured to be 86%, which is higher than the design specification. The effectiveness of the heat exchanger and the flow rate and operating pressure of the refrigerant were found to be lower than the design specifications. Consequently, the refrigeration capacity of the fabricated reverse Brayton cryogenic system was measured to be 1.23 kW at 77 K. In the future, we expect to achieve the targeted refrigeration capacity through further improvements. In addition, the faster commercialization of HTS power cables and more efficient storage of liquefied natural gas will be realized. Full article

A big amount of the pressure energy content in the natural gas distribution networks is wasted in throttling valves of pressure reduction stations (PRSs). Just a few energy recovery systems are currently installed in PRSs and are mostly composed of radial turboexpanders coupled with cogeneration internal combustion engines or gas-fired heaters providing the necessary preheating. This paper clarifies the reason for the scarce diffusion of energy recovery systems in PRSs and provides guidelines about the most feasible energy recovery technologies. Nine thousand PRSs are monitored and allocated into 12 classes, featuring different expansion ratios and available power. The focus is on PRSs with 1-to-20 expansion ratio and 1-to-500 kW available power. Three kinds of expanders are proposed in combination with different preheating systems based on boilers, heat pumps, or cogeneration engines. The goal is to identify, for each class, the most feasible combination by looking at the minimum payback period and maximum net present value. Results show that small size volumetric expanders with low expansion ratios and coupled with gas-fired heaters have the highest potential for large-scale deployment of energy recovery from PRSs. Moreover, the total recoverable energy using the feasible recovery systems is approximately 15% of the available energy. Full article

Sustainable development can no longer neglect the growth of those technologies that look at the recovery of any energy waste in industrial processes. For example, in almost every industrial plant it happens that pressure energy is wasted in throttling devices for pressure and flow control needs. Clearly, the recovery of this wasted energy can be considered as an opportunity to reach not only a higher plant energy efficiency, but also the reduction of the plant Operating Expenditures (OpEx). In recent years, it is getting common to replace throttling valves with turbine-based systems (tuboexpander) thus getting both the pressure control and the energy recovery, for instance, producing electricity. However, the wide range of possible operating conditions, technical requirements and design constrains determine highly customized constructions of these turboexpanders. Furthermore, manufacturers are interested in tools enabling them to rapidly get the design of their products. For these reasons, in this work we propose an optimization design procedure, which is able to rapidly come to the design of the turboexpander taking into account all the fluid dynamic and technical requirements, considering the already obtained achievements of the scientific community in terms of theory, experiments and numeric. In order to validate the proposed methodology, the case of a single stage axial impulse turbine is considered. However, the methodology extension to other turbomachines is straightforward. Specifically, the design requirements were expressed in terms of maximum allowable expansion ratio and flow coefficient, while achieving at least a minimum assigned value of the turbine loading factor. Actually, it is an iterative procedure, carried out up to convergence, made of the following steps: (i) the different loss coefficients in the turbine are set-up in order to estimate its main geometric parameters by means of a one dimensional (1D) study; (ii) the 2D blade profiles are designed by means of an optimization algorithm based on a “viscous/inviscid interaction” technique; (iii) 3D Computational Fluid Dynamic (CFD) simulations are then carried out and the loss coefficients are computed and updated. Regarding the CFD simulations, a preliminary model assessment has been performed against a reference case, chosen in the literature. The above-mentioned procedure is implemented in such a way to speed up the convergence, coupling analytical integral models of the 1D/2D approach with accurate local solutions of the finite-volume 3D approach. The method is shown to be able to achieve consistent results, allowing the determination of a turbine design respectful of the requirements more than doubling the minimum required loading factor. Full article

This paper presents the results of analysis of energy and economic efficiency of the hierarchical gas-gas engine, with a note that a trigeneration system was analyzed, in which the production of electricity, heat and cold are combined. This solution significantly increases the energy efficiency of the gas and gas system compared to a system without cold production. The analysis includes a system comprising a compressor chiller which is driven by an electric motor in the system, as well as a system applying the mechanical work that is carried out via a rotating shaft of rotor-based machines, i.e., a gas turbine and a turboexpander. The comfort of the regulation of the refrigerating power rather promotes the use of a solution including an electric motor. Analysis contains also a schematic diagram of the system with a absorption chiller, which is driven by low-temperature enthalpy of exhaust gases extracted from a hierarchical gas-gas engine. Application of turboexpander with heat regeneration in the trigeneration system is also analyzed. Based on the multi-variant economic and thermodynamic calculations, the most favorable system variant was determined using, among others, the specific cost of cold production. Full article

This paper aims to make possible the operation of a turbo-expander (TE) as a renewable resource at the Neka power plant in fault condition in the auxiliary service system (ASS), which is considered one of the fundamental problems in network operation. In this paper, the effect of the failure on the performance of the TE is analyzed whilst the performance of a dynamic voltage restorer (DVR) and static synchronous compensator (STATCOM) to compensate the fault in the ASS network is investigated. To improve the performance of DVR, a novel topology is developed; additionally, the compensatory strategies are assessed, simulated, and validated. In order to optimize the performance of the compensators, their possible presence situations on the ASS in various scenarios under the conditions of severe disturbance, synchronization of fault conditions, and starting of TE are tested. The results of PSCAD/EMTDC software simulation demonstrate that by applying the improved topology and selected compensation strategy of DVR, severe voltage sags are compensated, and the fault ride-through (FRT) capability for the TE is provided. Eventually, it is evident that the proposed solution is technically and economically feasible and the TE can supply the total ASS power consumption in all disturbances. Full article
