This study analyzed the frequency control challenges within the West Africa Power Pool Interconnected Transmission System (WAPPITS) as it plans to incorporate variable renewable energy (VRE) resources, such as wind and solar energy. Concerns center on the ability of WAPPITS primary frequency control reserves to adapt to high VRE penetration given the synchronization and frequency control problems experienced by the three separate synchronous blocks of WAPPITS. Optimizing solutions requires a better understanding of WAPPITS’ current frequency control approach. This study used questionnaires to understand operators’ practical experience with frequency control and compared these observations to field tests at power plants and frequency response metrics during system events. Eight (8) of ten (10) Transmission System Operators (TSOs) indicated that primary frequency control service was implemented in the TSO, but nine (9) of ten TSOs indicated that the reserves provided were inadequate to meet system needs. Five (5) of ten (10) respondents answered “yes” to the provision of secondary frequency control service, while only one (1) indicated that secondary reserves were adequate. Three (3) TSOs indicated they have AGC (Automatic Generation Control) installed in the control room, but none have implemented it for secondary frequency control. The results indicate a significant deficiency in primary control reserves, resulting in a reliance on under-frequency load shedding for primary frequency control. Additionally, the absence of an AGC system for secondary frequency regulation required manual intervention to restore frequency after events. To ensure the effectiveness of battery energy storage systems (BESSs) and the reliable operation of the WAPPITS with a higher penetration of inverter-based VRE, this paper recommends (a) implementing and enforcing basic primary frequency control structures through regional regulation and (b) establishing an ancillary services market to mobilize secondary frequency control resources. Full article

The gradual replacement of conventional generators with variable renewable energy sources (RES) will reduce their online frequency regulation (FR) resources and degrade their overall frequency control capabilities. Although various inertia emulation methods exist, shaping load consumption is considered a more effective strategy during emergency conditions than under-frequency load shedding. Managing loads following frequency excursions can support grid stability owing to rapid power response. In this context, a Smart Transformer (ST)-based FR framework for a RES-penetrated power system is studied in this paper. The ST, with its distinctive features, effectively shapes the load profile through online load sensitivity identification-based control, aiding in the stabilization of grid frequency. This paper also proposes a tilt integral second-order double derivative (TIDD²) controller for a secondary loop whose parameters are optimized using the Learner Performance-based Behavior (LPB) algorithm. A thorough investigation reveals that the response from ST controlling the voltage-dependent load in the presence of TIDD² controllers can greatly enhance system performance by damping oscillations and peak deviations. In addition, the performance of Proportional–Integral–Derivative and TIDD² considering ST in the primary loop is compared to delineate the robustness of the LPB-based TIDD² controller. It is found that the proposed control scheme offers greater controllability and flexibility, enhancing the system’s dynamic performance. Full article

The data presented in this paper are related to the paper entitled “Optimal Estimation of Under-Frequency Load Shedding Scheme Parameters by Considering Virtual Inertia Injection”, available in the Energies journal. Here, data are included to show the results of an Under-Frequency Load Shedding (UFLS) scheme that considers the injection of virtual inertia by a VSC-HVDC link. The data obtained in six cases which were considered and analyzed are shown. In this paper, each case represents a different frequency response configuration in the event of generation loss, taking into account the presence or absence of a VSC-HVDC link, traditional and optimized UFLS schemes, as well as the injection of virtual inertia by the VSC-HVDC link. Data for each example contain the state of the relay, threshold, position in every delay, load shed, and relay configuration parameters. Data were obtained through Digsilent Power Factory and Python simulations. The purpose of this dataset is so that other researchers can reproduce the results reported in our paper. Full article

With the increasing expansion of power systems, there is a growing trend towards active distribution networks for decentralized power generation and energy management. However, the instability of distributed renewable energy introduces complexity to power system operation. The active symmetry and balance of power systems are becoming increasingly important. This paper focuses on the characteristics of distributed resources and under-frequency load shedding, and a coordinated operation and control strategy based on the rapid adjustment of energy storage power is proposed. The characteristics of various controllable resources are analyzed to explore the rapid response capabilities of energy storage. The energy storage types are categorized based on the support time, and the final decision is achieved with power allocation and adjustment control of the energy storage system. Additionally, a comprehensive control strategy for under-frequency load shedding and hierarchical systems is provided for scenarios with insufficient active support. The feasibility of the proposed model and methods is verified via a multi-energy system case. Full article

Achieving the necessary energy balance entails the capacity to adapt both power supply and demand, which is known as flexible operation. At present, the Ghana National Commission on Culture depends on a combination of well-coordinated measures designed to uphold the system’s integrity when confronted with abnormal system conditions stemming from significant disturbances within the system. The set of coordinated measures comprises manual (controlled load shedding) and automatic (Special Protection Schemes, Under-Frequency Load Shedding, Over-Frequency Control Scheme, scheme against voltage collapse, etc.) steps to control important system parameters to keep the power system stable and cascading effects leading to major blackouts. Ghana’s system suffers from voltage and frequency degradation as a result of a mismatch of power supply and demand; to maintain grid stability and avoid power outages, a flexible operation is required for real-time supply and demand balancing. SMRs, with their load-following capability, can adjust their output to match the change in demand. This research proposes a microgrid-based design for a high-renewable-energy penetration grid in Ghana with the inclusion of an SMR for voltage stability. Full article

Under-frequency load shedding (UFLS) schemes are the latest safety measures applied for safeguarding the integrity of the grid against abrupt frequency imbalances. The overall inertia of electrical power systems is expected to decrease with an increased penetration of renewable energy as well as elements connected through power electronic interfaces. However, voltage source converter-based high voltage direct current (VSC-HVDC) links can provide virtual inertia through a control loop that allows for a reaction to occur at certain frequency fluctuations. This paper evaluates a UFLS scheme that considers the injection of virtual inertia through a VSC-HVDC link. A genetic algorithm (GA) is used to determine the location of the UFLS relays, the activation threshold of each stage, the delay time and the percentage of load shedding at each stage. It was found that the virtual inertia causes the nadir to delay and sometimes reach a greater depth. Furthermore, the implemented GA approximates the frequency response to the limits set with the constraints, reducing the load shedding but achieving a steeper nadir and a lower steady-state frequency level than traditional UFLS. The simulations were performed using the IEEE 39-bus test system. Full article

With the high penetration of renewable energy into power grids, frequency stability and oscillation have become big concerns due to the reduced system inertia. The application of the Battery Energy Storage System (BESS) is considered one of the options to deal with frequency stability and oscillation. This paper presents a strategy to size, locate, and operate the BESS within the power grid and, therefore, investigate how sizing capacity is related to renewable energy penetration levels. This paper proposes an identification method to determine the best location of the BESS using the Prony method based on system oscillation analysis, which is easy to implement based on measurements while actual physical system models are not required. The proposed methods for BESS size and location are applied using MATLAB/Simulink simulation software (version: R2023a) on the Kundur 2-area 11-bus test system with different renewable energy penetration levels, and the effectiveness of the applied method in enhancing frequency stability is illustrated in the study cases. The case studies showed a significant improvement in steady-state frequency deviation, frequency nadir, and Rate of Change of Frequency (ROCOF) after implementing BESS at the selected bus. The integration of BESS can help to avoid Under-frequency Load Shedding (UFLS) by proper selections of size, location, and operating strategy of the BESS within the power grid. Full article

An Electric Power System (EPS) is a dynamic system that, due to continuous variations in the load, the presence of disturbances, switching operations, and/or the operation of the protection system, is never in a steady state. A deficit in generation causes a drop in the system’s frequency that, if not controlled, could result in the loss of synchronism between generators or areas and, in the worst-case scenario, a total or partial system collapse. This article presents a methodology to identify a subset of representative events that generalizes the N-1 generation contingency space; this subset can later be applied in the development of Under-Frequency Load-Shedding (UFLS) schemes based on the Rate of Change of Frequency (ROCOF). Full article

This study proposes an under-frequency load-shedding (UFLS) scheme based on a binary Archimedes Optimization Algorithm (BAOA) and the Weighted Sum Method (WSM) to maintain the stability of an islanded distribution system. These methods consider stability indices and load priorities to ensure effective load shedding during frequency deviations. The BAOA determines the optimal load shedding based on the stability index and power mismatch that minimizes the impact on critical loads while maintaining system stability in an islanded distribution system. The WSM determines the rank of the load to be shed based on four criteria: the load priority, the load category, the stability index, and the load size. Each load is assigned a weight based on its priority. These weight variables determine the order in which loads are shed during frequency deviations. The effectiveness of the proposed UFLS was tested on an 11 kV Malaysian distribution network with two mini hydro distributed generation systems. A comparative study was conducted based on five result outputs, including the number of loads shed, the size of the loads shed, the frequency undershoot, the frequency overshoot, and the time taken to achieve a stable frequency in three cases: base load, peak load, and peak load with photovoltaics (PV). The proposed UFLS showed the best results for 11 of 15 outputs (73.3%) for islanding events and 9 of 15 outputs (60%) for overloading events. The voltage profile and stability index, also, were improved after the proposed UFLS was applied. Full article

At complex industrial sites, the high number of large consumers that make the technological process chain requires direct supply from the main high-voltage grid. Often, for operational flexibility and redundancy, the main external supply is complemented with small local generation units. When a contingency occurs in the grid and the main supply is cut off, the local generators are used to keep in operation the critical consumers until the safe shutdown of the entire process can be achieved. In these scenarios, in order to keep the balance between local generation and consumption, the classic approach is to use under-frequency load-shedding schemes. This paper proposes a new load-shedding algorithm that uses particle swarm optimization and forecasted load data to provide a low-cost alternative to under-frequency methods. The algorithm is built using the requirements and input data provided by a real industrial site from Romania. The results show that local generation and critical consumption can be kept in stable operation for the time interval required for the safe shutdown of the running processes. Full article

The reactive nature of traditional under-frequency load shedding schemes can lead to delayed response and unnecessary loss of load. This work presents a proactive framework for power system frequency stability. Bayesian filters and synchrophasors are leveraged to produce predictions after disturbances are detected. By being able to estimate the future state of frequency corrective actions can be taken before the system reaches a critical condition. This proactive approach makes it possible to optimize the response to a disturbance, which results in a decrease in the amount of compensation utilized. The framework is tested via Matlab simulations based on Kundur’s Two-Area System, and the IEEE 14-Bus System. Performance metrics are provided and evaluated against other contemporary solutions found in literature. During testing this framework outperformed other solutions by drastically reducing the amount of load dropped during compensation. Full article

The present paper proposes the implementation of a new algorithm for the control of the speed regulators of Pelton wheel turbines, used in many of the pumped hydroelectric energy storage systems that operate in isolated electrical systems with high renewable energy participation. This algorithm differs substantially from the standard developments which use PID or PI governors in that, in addition to acting on the nozzle needles and deflectors, it incorporates a new inner-loop pressure stabilization circuit to improve frequency regulation and dampen the effects of the pressure waves that are generated when regulating needle position. The proposed algorithm has been implemented in the Gorona del Viento wind–hydro power plant, an installation which supplies the primary energy needs of the island of El Hierro (Canary Islands, Spain). Although, as well as its wind and hydro generation systems, the plant also has a diesel engine based generation system, the validation of the results of the study presented here focuses on situations in which frequency control is provided exclusively by the hydroelectric plant. It is shown that implementation of the proposed algorithm, which replaces the previous control system based on a classical PI governor, is able to damp the pressure wave that originates in the long penstock of the plant in the face of variations in non-dispatchable renewable generation, a situation which occurred with a high degree of relative frequency in the case study. The damper has enabled a substantial reduction in the cumulative time and the number of times that frequency exceeded different safety margins. Damper incorporation also reduced the number of under-frequency pump unit load shedding events by 93%. Full article

Replacing the traditional rotating generators with renewable energy will reduce the grid’s inertia and with it the minimum frequency when N-1 contingency occurs triggering an Under-Frequency Load Shedding (UFLS). This study proposes a method for the energy storage system (ESS) to simultaneously provide energy arbitrage, reserve capacity, and assist N-1 contingency, by modifying the restriction formula of economic dispatch (ED) and limiting the SOC range of the ESS. Let the ESS join the Spinning Reserve. Through the PSS^®E iterative ESS charging power required at moments when the frequency of contingency is too low in the ED. Let the ESS act as a N-1 contingency extra frequency reserve. This would prevent UFLS and still maintain the demand. The proposed method is applicable to different types of ESS. The method allows energy storages, originally designed for energy arbitrage, to participate in frequency support and spinning reserve. Full article

Power reserves are usually scheduled in day-ahead unit commitment (UC) to minimize operating costs while maintaining system security. In applying basic UC (bUC) after a contingency, the system frequency may fall upon the activation of the load-shedding global control (under-frequency load-shedding or UFLS) limits. Small isolated microgrids are more sensitive to this issue due to their lack of inertia. Including dynamic considerations into the bUC problem can minimize UFLS activation and also avoid the need for the operator to later check the short-term feasibility of a bUC solution. These proposals are known as Frequency-Constrained UC (FCUC), although the implementation are very time-consuming. FCUC implementation will increase the system’s operational costs, which should be calculated to estimate remuneration to the safety service based on the additional reserve provision. The electrical system of Gran Canaria island has suffered several episodes of greater blackouts in recent years. Shortly, there will be 242 MW of wind generation installed (26% of the thermal power installed on Gran Canaria). The main objective of this work is to improve the island system reliability by means of an FCUC formulation applied by the system operator in practice, including renewable sources. The results show that the frequency values remained within the admissible boundaries, but the system’s operational costs increased by around 13%. Full article

Under-frequency load shedding (UFLS) prevents a power grid from a blackout when a severe contingency occurs. UFLS schemes can be classified into two categories—event-based and response-driven. A response-driven scheme utilizes 81L relays with pre-determined settings while an event-based scheme develops a pre-specified look-up table. In this work, an event-based UFLS scheme is presented for use in an offshore standalone power grid with renewables to avoid cascading outages due to low frequency protection of wind power generators and photovoltaic arrays. Possible “N-1” and “N-2” forced outages for peak and off-peak load scenarios in summer and winter are investigated. For each forced outage event, the total shed load is minimized and the frequency nadir is maximized using particle swarm optimization (PSO). In order to reduce the computation time, initialization and parallel computing are implemented using MATLAB/Simulink because all forced outage events and all particles in PSO are mutually independent. A standalone 38-bus power grid with two wind turbines of 2 × 2 MW and photovoltaics of 7.563 MW was studied. For each event, the proposed method generally obtains a result with a smaller shed load and a smaller overshoot frequency than the utility and existing methods. These simulation results verify that the proposed method is practically applicable in a standalone power system with penetration of renewables. Full article
