In contemporary multi-family housing construction, the structural grid is often influenced or conditionally determined by the dimensional logic of underground parking garages. When transferred to above-ground storeys, it directly defines façade frontage, building depth, and possibilities for apartment organisation. Previous research has mostly examined housing typology, dimensional standards, and structural systems as separate domains, while the influence of parking-derived structural grids has not been systematically analysed within a unified framework. This paper applies an analytical-comparative approach, comparing typical structural grids derived from parking modules with the minimum façade frontages required for different apartment types. The method includes identifying characteristic grid dimensions, defining minimum façade frontages based on normatively prescribed room widths, calculating deviations between required and available dimensions, and analysing individual and combined apartment units according to the criterion of minimal positive deviation, within the Serbian regulatory framework. The results show that the structural grid is a relevant factor in apartment organisation and typological structure. Certain grids enable more rational layouts with minimal spatial adjustments, while others generate dimensional surplus, excessive depth, or typological constraints. The study establishes a link between parking modules, structural grids, and apartment organisation, and proposes an analytical framework for evaluating their dimensional compatibility in multi-family housing design. Full article

Digital mining has become a tangible reality in recent years and the digital revolution enables and requires data exchange for autonomous machines and operational flow management. LoRa technology and its underground propagation behavior can make an important contribution to this digitalization. This paper presents a Data Mule approach that enabled progress in digitalization at refueling stations in active underground mining areas of a mine near Werra, Germany, operated by the K+S Group. This demonstration aimed to automate manual data collection at fuel gauges by using a dynamic LoRa network. We used specially developed LoRa Data Mule modules for operations over many square kilometers. LoRa was chosen for its industrial functionality and long-range capabilities, particularly in underground environments. The Data Mule modules used were in-house-designed units with underground mining-rated casing and connectors, as well as commercial LoRa boards and custom communication protocols. Connectivity between all systems was realized at travel speeds of 20 to 40 km/h, with connection data successfully relayed for 180 to 770 m, despite 90° turns and no line of sight. It was shown that the LoRa Data Mule approach can be used in a network of remote but active data generation points. Full article

Nowadays, most water meters are mechanical and intended to be installed on pipes completely filled with water. But the pipelines of a water supply network may contain air, which poses a metrological problem: if this air flows through the domestic intakes, it can propel the moving part of the meters, resulting in an overestimation of water consumption. By how much? There is a surprising lack of field data on this topic. So, the case of one house is reported: it is located at the top of a steep and sparsely occupied street, with water typically supplied for a few hours per day. The house’s meter (multi-jet) was estimating a huge and erratic consumption: several times more than what would be normally expected on average, and with some daily peaks exceeding the built storage capacity (underground cistern plus roof tank). After one year of monitoring, including the installation of a few devices, it is concluded that: (1) the house’s meter was affected by air in the water supply network (most likely for different reasons, of which three are discussed); (2) a small air-release valve installed just upstream from the meter did not solve the problem; (3) another mechanical meter (single-jet) installed just downstream was also affected by air (although to a lesser extent), and (4) reliable estimates of water consumption were finally obtained with an ultrasonic meter installed at the domestic intake (and with a mechanical meter installed at the roof tank’s outlet). Thus, the case reported emphasizes the need to study more how air in pipelines affects mechanical water meters and to sometimes consider alternatives for measuring domestic water consumption. Full article

This paper investigates the specific positioning accuracies and uncertainties associated with the measurement of acoustic leakage noise correlation (LNC) in underground pressurized water mains, treating them as acoustic waveguides. It begins by identifying three key intrinsic sources of measurement errors: (1) the speed of acoustic waves in the water mains as influenced by pipe material, wall thickness, modulus of elasticity, and bulk modulus; (2) the distance between the two accelerometers used for correlation; (3) the time delay from the point of leakage to the accelerometers. A mathematical uncertainty model was developed to compute sensitivity coefficients, enabling the propagation of measurement errors from these sources. This was validated through seven sets of full-scale experiments conducted at Q-Leak, a 25,000 sq. ft. test site in Hong Kong. This study ultimately quantified and assessed the contributions of individual error sources to the overall uncertainty, allowing for the prioritization of factors that have the most significant impact in various scenarios. The findings reveal that Young’s modulus and pipe wall thickness are the primary factors affecting measurements for both plastic and metal pipes. Additionally, a universal in-house program, “LNC uncertainty calculator,” was developed to provide insights into the buffer ranges for confirming suspected leak locations while considering constraints within the uncertainty budget. This research highlights the critical but often overlooked area of uncertainty modeling in leak detection for pressurized buried water mains, offering valuable insights intended to enhance operational strategies and maintenance practices within the industry. This research provides a robust framework for understanding the accuracy of leak detection. This means operators can better interpret the reliability of their measurements, leading to consistent decision-making across different situations and minimizing the risk of misidentifying the presence or absence of leakage. In addition, the insights gained from prioritizing factors that affect measurement accuracy allow engineers and operators to make informed decisions about where to focus their resources and efforts. This can lead to more effective maintenance strategies that are tailored to specific conditions, thereby optimizing operational efficiency. Full article

The deployment of robotic systems in hazardous and magnetically intense environments requires careful assessment of their performance under external disturbances. In particular, electromagnetic motors used for actuation may interact with strong magnetic fields, potentially impairing their functionality. This study investigates the behaviour of miniature brushed coreless Direct Current (DC) motors for small Unmanned Aerial Vehicle (UAV) applications in magnetically harsh environments, such as underground accelerator facilities like the Large Hadron Collider (LHC) at CERN. Experimental tests were conducted measuring four main physical quantities: the torque components acting along the axes orthogonal to the shaft, the torque about the shaft axis, variations in angular speed, and electrical current consumption. The results showed that the motors were able to operate under external magnetic field intensities up to 0.4 T, although measurable torques acted on the internal permanent magnet and on the ferromagnetic housing material. Some discrepancies and speed fluctuations were observed during operation and were attributed to mobility of the internal permanent magnet. Overall, the findings demonstrate that the tested miniature motors exhibit resilience in high magnetic fields but suffer from manufacturing variability, suggesting that higher-quality motors with more consistent characteristics would be preferable for reliable robotic operation in harsh environments. Full article

To meet safety regulations in underground coal mines, wireless power transfer (WPT) systems must house both the transmitter and receiver within explosion-proof enclosures. However, eddy currents induced on the surfaces of these non-ferromagnetic metal enclosures significantly hinder magnetic flux coupling, thereby reducing transmission efficiency. This paper proposes a slotting technique applied to explosion-proof enclosures to suppress eddy currents, along with the integration of magnetic flux focusing materials into the coils to enhance coupling. Simulations were conducted to compare three system configurations: (i) a WPT system without enclosures, (ii) a system with solid (unslotted) enclosures, and (iii) a system with slotted enclosures. The results show that solid enclosures reduce efficiency to nearly zero, whereas slotted enclosures restore efficiency to 90% of the baseline system without enclosures. Joule heating remains low in the slotted explosion-proof enclosures, with energy losses of 2.552 J for the transmitter enclosure and 2.578 J for the receiver enclosure. A conservative first-order estimation confirms that the corresponding temperature rise in the enclosure surfaces remains below 50 °C, which is well within the 150 °C limit stipulated by the Chinese National Standard GB 3836.1-2021 (Explosive Atmospheres—Part 1: Equipment General Requirements). These findings confirm effective eddy current suppression and efficiency recovery without compromising explosion-proof safety. The core innovation of this work lies not merely in the physical slotting approach, but in the development of a precise equivalent circuit model that fully incorporates all mutual inductance components representing eddy current effects in non-ferromagnetic explosion-proof enclosures, and its integration into the overall MCR-WPT system circuit. Full article

Underground high-voltage transmission cables, especially high-pressure fluid-filled (HPFF) pipe-type cable systems, are critical components of urban power networks. These systems consist of insulated conductor cables housed within steel pipes filled with pressurized fluids that provide essential insulation and cooling. Despite their reliability, HPFF cables experience faults caused by insulation degradation, thermal expansion, and environmental stressors, which, due to their subtle and gradual nature, complicate incipient fault detection and subsequent fault localization. This study presents a novel, proactive, and retrofit-friendly predictive condition monitoring method. It leverages distributed accelerometer sensors non-intrusively mounted on the HPFF steel pipe within existing manholes to continuously monitor vibration signals in real time. A physics-enhanced convolutional neural network–long short-term memory (CNN–LSTM) deep learning architecture analyzes these signals to detect incipient faults before they evolve into critical failures. The CNN–LSTM model captures temporal dependencies in acoustic data streams, applying time-series analysis techniques tailored for the predictive condition monitoring of HPFF cables. Experimental validation uses vibration data from a scaled-down HPFF laboratory test setup, comparing normal operation to incipient fault events. The model reliably identifies subtle changes in sequential acoustic patterns indicative of incipient faults. Laboratory experimental results demonstrate a high accuracy of the physics-enhanced CNN–LSTM architecture for incipient fault detection with effective data feature extraction. This approach aims to support enhanced operational resilience and faster response times without intrusive infrastructure modifications, facilitating early intervention to mitigate service disruptions. Full article

Borehole trajectory control is a fundamental task for directional well engineers. Now that there are inevitable errors about single-stand control in the field situation, it is difficult to deal with the complex underground problems in real time. In order to improve the efficiency of directional operation and the accuracy of wellbore trajectory control, this paper presents an improved Sparrow Search algorithm by integrating the multi-strategy model and Constant-Toolface models to calculate the single-stand control scheme for single-bent-housing motors in directional drilling. To evaluate the performance of the algorithm, the Particle Swarm algorithm, the Sparrow Search algorithm, and the improved Sparrow Search algorithm (LCSSA) are used to optimize the process parameters for each drilling, respectively. Numerical tests based on drilling data show that all three algorithms can predict the drilling parameters. In contrast, the LCSSA exhibits the fastest convergence and the smallest error after optimizing single-stand control, attaining an average convergence time of 0.08 s. It accurately back-calculated theoretical model parameters with high accuracy and met engineering requirements when applied to actual drilling data. In field applications, the LCSSA reduces the deviation from the planned trajectory by over 25%, restricting the deviation to within 0.005 m per stand; additionally the total drilling time was reduced by at least 18% compared to previous methods. The integration of the LCSSA with the drilling system significantly enhances drilling operations by optimizing trajectory accuracy and boosting efficiency and serves as an advanced tool for designing process parameters. Full article

Alcalá de Ebro is located 35 km northwest of the city of Zaragoza, on the right bank of the Ebro River at the outlet of a ravine (Juan Gastón) towards the river, with a catchment area of more than 230 km². Over time, urbanisation and agricultural development have eliminated the last stretch of the drainage channel, and these water inputs have been channelled underground, filtering through the ground. This section of the Ebro Valley rests on a marly tertiary substratum, which promotes dissolution-subbing processes that can lead to sinkholes. The ground tends to sink gradually or suddenly collapse. Many studies have been carried out to understand not only the origin of the phenomenon but also its geometry and the area affected by it in the town of Alcalá de Ebro. In this sense, it has been possible to model an area around the main access road, where numerous collapsing sinkholes have been found, blocking the road and affecting houses. It also affects the embankment that protects the town from the floods of the river Ebro. These studies have provided specific knowledge, enabling us to evaluate and implement underground consolidation measures, which have shown apparent success. Several injection campaigns have been carried out, initially with expansion resins and finally with columnar development, using special low-mobility mortars to fill and consolidate the undermined areas and prevent new subsidence. These technical solutions propose a method of ground treatment that we believe is novel for this type of geological process. The results have been satisfactory, but it is considered necessary to continue monitoring the situation and to extend attention to a wider area to prevent, as far as possible, new problems of subsidence and collapse. In this sense, the objective is to continue the control and monitoring of possible phenomena related to subsidence problems in the affected area and its immediate surroundings, to detect and, if necessary, anticipate subsidence or collapse phenomena that could affect the body of the embankment. Full article

The environmental hazards caused by the massive generation and improper disposal of industrial solid wastes (e.g., high calcium desulphurization ash, HCDA) and the growing safety risks posed by the increasing number of underground mine goafs generated by mining activities have become serious environmental and geotechnical challenges. To address the dual issues, this study develops a novel desulfurization ash–slag-based paste backfill (DSPB) material using HCDA and granulated blast furnace slag (GBFS) as primary constituents. The effects of cementitious material ratios, polycarboxylate superplasticizer (PCE), and sodium silicate (SS) on rheological properties of DSPB were investigated through a shear rheology experiment and fitting rheological model to assess the flow conditions in pipeline transportation. In addition, the mechanism was investigated through microanalysis. The results showed that with the decrease in desulfurization ash-to-slag ratio, the initial yield stress and plastic viscosity decreased by up to 88% and 34.9%, respectively; PCE via “card house” structural effects made the rheological parameters increase and then decrease, and a dosage of more than 1.2% significantly improved the rheological properties; and SS initially reduced the rheological parameters, but excessive doping (greater than 1.0%) led to an increase. These findings establish the relationship between DSPB composition and rheological properties, provide a practical solution for waste resource utilization and surface stabilization, and provide a scientific basis for the microstructure–rheology relationship of cementitious systems. Full article

Coal dust seriously affects the underground working environment. The current water-spray dust reduction technology uses a large amount of water and has a poor effect on coal dust with poor wettability. This study proposed a clean and sustainable technology using plasma-activated water (PAW) to alter the wettability of coal dust and improve its dust control effect. The PAW was prepared and its physical and mathematical properties were tested by a device designed in-house. The influence of PAW on the wettability of coal dust was determined by the coal dust contact angle experiments. The effect of PAW on the surface morphology of coal dust was analyzed by a scanning electron microscope. The effect of PAW on the pore structure of coal dust was analyzed through the specific surface area and pore size experiments. The results showed that PAW contained a large number of active substances such as H₂O₂, NO₃⁻, and NO₂⁻, showing strong and stable oxidation. PAW could significantly reduce the instantaneous contact angle of coal dust, and the higher the degree of coal dust metamorphism, the more significant the reduction effect. The surface morphology, pore volume, specific surface area, and fractal dimension of the coal dust were significantly changed after PAW treatment. PAW could transform the non-uniform three-dimensional spatial distribution of the coal dust surface into an approximate two-dimensional planar distribution, thus enhancing the wettability of the coal dust. With the increase in PAW ionization intensity, the contact angle of long-flame coal was negatively correlated with the mesoporous pore volume. The contact angle of gas coal was negatively correlated with the micropore volume and micropore specific surface area, and was positively correlated with the mesopore volume. The contact angle of meager lean coal was positively correlated with the macropore specific surface area. The surface morphology, pore volume, specific surface area, and fractal dimension changes in coal dust treated with PAW can reveal the wettability enhancement mechanism to some extent. The results of the study can provide pre-theoretical guidance for the field application of PAW coal mine dust reduction technology. Full article

The underground power houses of pumped-storage power stations (PSPSs) are highly complex, with interconnected and multidimensional structures, including various tunnels, such as the main and auxiliary power houses (MAPH), main transformer tunnel (MTT), tailrace gate tunnel (TGT), access tunnels (ATs), cable tunnels (CTs) etc. During intensive civil construction and electromechanical installation, fire risk becomes particularly prominent. Current research mainly examines fire incidents within individual tunnels, lacking comprehensive analyses of smoke spread across the entire cavern network. Therefore, in this study, a numerical model of a cavern complex in a PSPS was established to analyze smoke behavior and temperature distribution under various fire scenarios. The results indicated that when a fire occurred in the MAPH, the fire risk was relatively higher compared to fires in other places. Using the example of smoke spread from the MAPH to the MTT, the smoke spread process through key connecting caverns was analyzed. Initially, the temperature and velocity were stable, and the CTs and traffic cable tunnel in the auxiliary powerhouse (TCTAP) were the main smoke paths. After 7 min, the heat release rate (HRR) became stable, and CTs and ATs became the main paths for smoke spread, which could provide a reference for improving fire design in underground cavern systems. Full article

Splitting grouting is a highly effective technique for reinforcing tunnels and underground structures, ensuring their operational stability and facilitating long-term maintenance. It has been widely adopted in the prevention and remediation of geological hazards. However, the theoretical research on the diffusion mechanisms of split grouting lags behind its practical applications. This study addresses several key scientific challenges in understanding the diffusion behavior of split grouting. By integrating experimental design, numerical simulations, and theoretical analysis, we conduct a systematic investigation into the diffusion process and vein morphology of split grouting in both homogeneous and heterogeneous formations. We first employed a self-developed two-dimensional grouting test system to perform diffusion experiments on cohesive strata, focusing on the influence of various factors such as grout density, water/cement ratio, soil consistency, and fracture characteristics. The results provide insights into the diffusion patterns, morphology, soil pressure distribution, and surface uplift behavior of the grout veins. Subsequently, a numerical simulation program, developed in-house, based on the finite element method (FEM) and the volume of fluid (VOF) approach, was employed to model the entire process of fracturing grouting within clay strata. The experimental and numerical results indicate that grout vein diffusion in layered soil follows a Y-shaped pattern with an inclined deflection. In uniform strata, the surface uplift curve displays both symmetrical and asymmetrical “convex” elevations, while in heterogeneous soft and hard strata, the uplift is characterized by distinct “convex” deformations. Finally, based on these findings and the principles of contact mechanics, we analyze the underlying mechanisms. The results suggest that weak contact zones undergo tensile cracking and horizontal deflection prior to the formation of grout veins. Additionally, local stress rotations in the soil can induce tilting and deflection. The theoretical insights derived from this study provide valuable guidance for practical engineering applications. Full article

Soil CO₂ concentration and flux measurements are important in diverse fields, including geoscience, climate science, soil ecology, and agriculture. However, practitioners in these fields face difficulties with existing soil CO₂ gas probes, which have had problems with high costs and frequent failures when deployed. Confronted with a recent research project’s need for long-term in-soil CO₂ monitoring at a large number of sites in harsh environmental conditions, we developed our own CO₂ logging system to reduce expense and avoid the expected failures of commercial instruments. Our newly developed soil probes overcome the central challenge of soil gas probes—surviving continuous exposure to soil moisture while remaining open to soil gases—via three approaches: a 3D printed housing (economical for small-scale production) following design principles that correct the usual water permeability flaw of 3D printed materials; passive moisture protection via a hydrophobic, CO₂-permeable PTFE membrane; and active moisture protection via a low-power micro-dehumidifier. Our CO₂ instrumentation performed well and yielded a high-quality dataset that includes signals related to a prescribed fire as well as seasonal and diel cycles. We expect our technology to support underground CO₂ monitoring in fields where it is already practiced and stimulate its expansion into diverse new fields. Full article

The criteria on green public procurement of the European Union establish that the economic budgets of building projects must be complemented by their derived environmental and social costs. These criteria are currently being adapted to the requirements related to the circular economy, such as the use of methods to evaluate buildings environmentally. However, most methods available in the European and Spanish markets require prior training, which makes their use difficult. This paper presents an evaluation method, CEACE, for housing construction based on the determination of their footprints (ecological, carbon, and water footprints), also called the footprint family, to which the economic and social evaluation is added, as is the quantification of the construction and demolition waste generated. This method is validated with the assessment of fifteen residential buildings in Andalusia and creates an indicator that will allow technicians, companies, and administrations to evaluate projects in accordance with the criteria of green public procurement. The method is sensitive to changes in the type of building, foundation solution, and underground construction. Full article
