Nowadays, underwater activities are becoming more and more important. As the number of underwater sensing devices grows rapidly, the amount of bandwidth needed also increases very quickly. Apart from underwater communication, direct communication across the water–air interface is also highly desirable. Air-to-water wireless transmission is crucial for sending control information or instructions from unmanned aerial vehicles (UAVs) or ground stations above the sea surface to autonomous underwater vehicles (AUVs). On the other hand, water-to-air wireless transmission is also required to transmit real-time information from AUVs or underwater sensor nodes to UAVs above the water surface. Previously, we successfully demonstrated a water-to-air optical camera-based OWC system, which is also known as optical camera communication (OCC). However, the reverse transmission (i.e., air-to-water) using OCC has not been analyzed. It is worth noting that in the water-to-air OCC system, since the camera is located in the air, the image of the light source is magnified due to diffraction. Hence, the pixel-per-symbol (PPS) decoding of the OCC pattern is easier. In the proposed air-to-water OCC system reported here, since the camera is located in the water, the image of the light source in the air will be diminished in size due to diffraction. Hence, the PPS decoding of the OCC pattern becomes more difficult. In this work, we propose and experimentally demonstrate a wide field-of-view (FOV) air-to-water OCC system using CUDA Deep-Neural-Network Long-Short-Term-Memory (CuDNNLSTM). Due to water turbulence and air turbulence affecting the AUV and UAV, a precise line-of-sight (LOS) between the AUV and the UAV is difficult to achieve. OCC can provide wide FOV without the need for precise optical alignment. Results revealed that the proposed air-to-water OCC system can support a transmission rate of 7.2 kbit/s through a still water surface, and 6.6 kbit/s through a wavy water surface; this satisfies the hard-decision forward error correction (HD-FEC) bit-error-rate (BER). Full article

In order to figure out the wall effect on the propulsive property of an auto-propelled foil, the commercial open-source code ANSYS Fluent was employed to numerically evaluate the fluid dynamics of flexible foil under various wall distances. A virtual model of NACA0015 foil undergoing travelling wavy motion was adopted, and the research object included 2D and 3D models. To capture the foil’s moving boundary, the dynamic grid technique coupled with the overlapping grid was utilized to realize the foil’s positive deformation and passive forward motion. The ground wall effect on fluid dynamics (thrust force, lift force and propulsive efficiency) and the flow structures of travelling wavy foil were analyzed. The numerical results show that the existence of the ground wall is beneficial for the propulsive property of foil. Specifically, the existence of the wall can improve the forward speed and efficiency of foil, with a maximum increase of 13% in moving velocity and a 10.5% increase in propulsive efficiency. The conclusions acquired in the current study are of great significance for the design of bionic UUV. Full article

The mining area in western China is ecologically sensitive. Coal mining can cause the formation of ground fissures, leading to geological disasters and further accelerating the process of land desertification. In this study, the working face of non-coal-pillar mining in the aeolian sand area was considered as the research object. The movement and deformation law of overlying strata were investigated through field measurements, theoretical analysis, and numerical simulation, and the mechanism governing the self-healing characteristics of ground fissures was revealed. The results demonstrated that the surface angular parameters were lower. This implies that the surface movement and the degree of deformation in non-coal-pillar mining in the aeolian sand area are significant, with a large mining influence range and rapid surface subsidence speed. After the mining of the working face, the resulting failure form of the overlying rock was asymmetric. Boundary ground fissures are typically located within the boundary of the working face, and no outward expansion is primarily observed. Dynamic ground fissures have “waviness” morphological characteristics and asymmetric “M” type development characteristics. A location model as well as a development cycle model of dynamic ground fissures were established for the first time, which can be used to predict the location and period of ground fissures. Based on the motion characteristics of hinged rock block structures, the mechanical mechanism of the self-healing phenomenon of dynamic ground fissures was revealed. A partition monitoring mode of working faces without coal pillar mining was proposed for the first time, which can reduce a lot of manpower and material resources. The coal mining subsidence basin is divided into a natural restoration area and an artificial restoration area. The combination of natural restoration and artificial guidance was used to control the ground fissures and reduce the associated costs. The research conclusions can provide a basis for mining damage evaluation and ecological environment protection in the aeolian sand area. Full article

The article reports the results of experimental study of vibratory surface grinding in the range of low excitation frequencies and variable directions of excited vibrations in the plane of the table, and investigates the effect of these directions on the roughness and waviness of the ground surface. The tests were conducted on a production surface grinder with a vibrating table on which the samples were mounted. The table made it possible to change the direction for the introduction of vibrations to the workpiece (longitudinally, transversely, and obliquely to the longitudinal feed of the table) and the parameters of the introduced vibrations, frequency and amplitude. In the course of the study, selected parameters of surface roughness and waviness of samples ground conventionally and with vibrations introduced on the workpiece were compared. The results show an improvement in the roughness and waviness parameters of the vibration-ground surfaces compared to surfaces ground without vibration (conventionally). The profile of the ground surface was subjected to Fourier analysis and the harmonic components of the surface shape of the ground samples were determined to characterize the effect of the introduced vibrations on the surface roughness. It was determined that the direction of vibration introduction, which is most favorable in terms of the parameters of the geometric structure of the ground surface, is the direction perpendicular to the longitudinal feed of the grinding table. In other directions of vibration introduction, the simultaneous effect of improving both parameters of the geometric structure of the ground surface profile was not obtained. Full article

In this paper, the validity of the application of an autocorrelation function for resolving some surface topography measurement problems was presented. Various types of surfaces were considered: plateau-honed, honed with burnished dimples, ground, turned, milled, laser-textured, or isotropic. They were measured with stylus and non-contact (optical) methods. Extraction of selected features, such as form and waviness (defined as an L-surface) and high-frequency measurement noise (S-surface) from raw measured data, was supported with an autocorrelation function. It was proposed to select the analysis procedures with an application of the autocorrelation function for both profile (2D) and areal (3D) analysis. Moreover, applications of various types of regular (available in the commercial software) analysis methods, such as least-square-fitted polynomial planes, selected Gaussian (regression and robust) functions, median filter, spline approach, and fast Fourier transform scheme, were proposed for the evaluation of surface topography parameters from ISO 25178 standards. Full article

In this paper, a pitching airfoil near flat and wavy ground is studied by numerical simulations. The kinematic features of the airfoil and the flow field around it are analyzed to reveal unsteady vorticity dynamics of the self-propelled airfoil in ground effect. The optimal pitching periods at different initial heights above flat ground are obtained, which make the pitching airfoil achieve the maximum lift-to-drag ratio. Compared with flat ground, at the same initial height, the optimal pitching periods vary with the shape of ground. The structure and the strength of the wake vortices shedding from the airfoil are adjusted by the wavelength of ground. This leads to the changes of amplitude and occurrence times of the peak and valley of lift and drag force. The results obtained in this study can provide some inspiration for the design of underwater vehicles in the ground effect. Full article

Bio-inspired Dielectric Resonator Antennas (DRAs) are engaging more and more attention from the scientific community due to their exceptional wideband characteristic, which is especially desirable for the implementation of 5G communications. Nonetheless, since these antennas exhibit peculiar geometries in their micro-features, high dimensional accuracy must be accomplished via the selection of the most suitable fabrication process. In this study, the challenges to the manufacturing process presented by the wideband Spiral shell Dielectric Resonator Antenna (SsDRA), based on the Gielis superformula, are addressed. Three prototypes, made of three different photopolymer resins, were manufactured by bottom-up micro-Stereolithography (SLA). This process allows to cope with SsDRA’s fabrication criticalities, especially concerning the wavy features characterizing the thin spiral surface and the micro-features located in close proximity to the spiral origin. The assembly of the SsDRAs with a ground plane and feed probe was also accurately managed in order to guarantee reliable and repeatable measurements. The scattering parameter S₁₁ trends were then measured by means of a Vector Network Analyzer, while the realized gains and 3D radiation diagrams were measured in the anechoic chamber. The experimental results show that all SsDRAs display relevant wideband behavior of 2 GHz at −10 dB in the sub-6 GHz range. Full article

Wing–in–ground crafts will face waves with different amplitudes when flying over the ocean, and the high amplitude situations are especially lack of exploration. Hence, the aerodynamic characteristics of the NACA 4412 airfoil in proximity to the wavy water surface for various wave amplitudes are inspected in this paper. By solving Navier–Stokes equations, the lift coefficients of the airfoil when the angle of attack ranges from 0° to 4° are obtained. The results show that the fluctuation amplitudes of aerodynamic coefficients increase remarkably with successive increases in the wave amplitude and might threaten flight safety. The flow fields at 0° with low and high wave amplitudes are investigated. It is revealed that the upward movement of the water surface is the critical factor for the change of aerodynamics, and the mechanism varies with different wave amplitudes. Comparison of the flow fields at 0° and 2° further indicates that the influence of high amplitude waves depends on the distance between the leading edge of the airfoil and the water surface. This study discovers the reasons for the different aerodynamic characteristics under various wave amplitudes and angles of attack, and is of great value for the design of wing–in–ground crafts. Full article

The wavy-tilt-dam (WTD) seal is considered to be one of the ideal sealing patterns used in nuclear reactor coolant pumps (RCPs). Grinding such seals with a four-axis grinder had been proposed and six grinding implementation strategies were described in our previous studies. However, another important issue is to determine the positioning accuracy of each servo axis so that the high-precision moving components can be selected properly. In the present paper, the positioning accuracy analysis is carried out to seek a balance between the manufacturing cost and the accuracy requirements. First, a geometric model is established for investigating the error sensitivity of each axis and setting reasonable accuracy allocation of the four axes. Subsequently, the combined influence of all four axes is assessed based on multi-body system (MBS) theory and homogeneous transformation matrix (HTM). According to the results calculated, positioning errors of the X-axis, Z-axis, B-axis, and C-axis within ±10 μm, ±0.1 μm, ±1 arcsec and ±60 arcsec are acceptable, respectively. Meanwhile, the form error calculated of the ground wavy face is no more than 109.74 nm. It is indicated that the accuracy level of the moving components is achievable by modern manufacturing techniques. The present paper is expected to serve as a theoretical basis for the design and development of the four-axis grinder. Full article

Wing-in-ground craft often encounter waves when flying over the sea surface, and the ground effect is more complicated than that of flat ground. Therefore, the aerodynamic characteristics of the NACA 4412 airfoil in proximity to wavy ground for a wide range of angles of attack is studied by solving the Reynolds Averaged Navier–Stokes equations. The validation of the numerical method is carried out by comparing it with the experimental data. The results show that the aerodynamic coefficients will fluctuate periodically when the airfoil moves over wavy ground at a small ride height. Except for the angle of attack of 0°, the fluctuation trend of aerodynamic coefficients at other angles of attack is the same. The analysis of aerodynamic fluctuation amplitude found that the medium angle of attack should be selected as the design cruise angle of attack for wing-in-ground craft. The time-averaged aerodynamic coefficients in the case of wavy ground are almost the same as those of flat ground. Hence, wavy ground mainly causes a fluctuation in aerodynamic coefficients. Considering the difference between aerodynamic coefficients at the angle of attack of 0° and at other angles of attack, the flow field structure at an angle of attack of 0° and 4° is analyzed. The results reveal the aerodynamic characteristics of the airfoil moving over wavy ground, which gives a deeper understanding of the ground effect in the conditions of wavy surface/ground. This has a certain guiding significance for the design of wing-in-ground craft. Full article

This study examines the extent to which above-ground trophic processes such as large carnivore predation on wild ungulates can cause cascading effects through the provision of carrion resources to below-ground ecosystem processes in the boreal forest of southeastern Norway. We measured the levels of 10 parameters in soil samples and 7 parameters in vegetation (wavy hair-grass, Avenella flexuosa, and bilberry, Vaccinium myrtillus) at 0, 0.5 and 2 m distance from 18 roe deer (Capreolus caprelous) carcasses killed by Eurasian lynx (Lynx lynx). We then compared these values to two control sites 20 m away from each carcass. Sampling was conducted 20–29 months after death. Neither soil nor vegetation samples showed a clear gradient in parameters (CN, NH₄⁺, NO₃⁻, P, PO₄⁻, Ca, K, Mg and Na) from the center of a carcass towards the periphery. Similarly, there was no difference in the effect on soil and vegetation between winter- and summer-killed carcasses. Our results contrast with that of other studies that simulate the effect of predation with whole carcasses and which often exclude scavengers through fencing. The lack of detectable effects after about two years is likely due to the small size of roe deer carcasses and the fact that most tissues are consumed by the predator and scavengers before decomposition. Full article

Fresnel micro-structured lenses are widely used in the field of modern optoelectronic technology. High-precision Fresnel micro-structured mold is the key technology to achieve its large-scale replication production. Focusing on the surface waviness error of Fresnel micro-structured mold machined by parallel grinding process, this paper conducted theoretical modeling and experiment research. Based on the grinding kinematics theory, the simulation models of the surface waviness topography and the circular waviness profiles of the ground Fresnel micro-structured mold were developed, considering the combined influence of the non-integer rotation speed ratio and other grinding parameters. A series of grinding experiments were carried out to verify the proposed simulation models. The influence of a non-integer rotation speed ratio and a wave-shift value upon the surface waviness error of the ground Fresnel micro-structured molds were analyzed. Both the simulation and experimental results proved that choosing the non-integer rotation speed ratio and a proper wave-shift value could greatly reduce the surface waviness error and improve the surface quality and uniformity. Full article

Electron beam welding (EBW) is widely used to weld titanium alloy parts such as aero-engine casing and blades. The surface quality after EBW has a significant influence on the aero-engine performance of those parts. We propose a surface treatment method with grinding on a titanium alloy electron beam weld. We analyze the influence of grinding parameters on the characteristics of the grinding surface. The experiment shows the applicability of ground surface by belt grinding on EBW and its impact on aero-engine performance. After belt grinding, both the welded surface and the surface connected with the substrate are smooth. The extra height of the seam was less than 0.2 mm, and the surface roughness (Ra) of the weld after grinding can be less than 0.98 μm. The microstructure of the weld after grinding was analyzed. Two types of bionic shapes were obtained, a sawtooth shape with a width of 40 μm and a height of 10 μm and a wavy shape with a width of 20 μm and a height of 3 μm. From the analysis above, the bionic surface can be obtained by grinding on the weld with an abrasive belt. Full article

We consider semiflexible chains governed by preferred curvature and twist and their flexural and twist moduli. These filaments possess a helical rather than straight three-dimensional (3D) ground state and we call them helical filaments (H-filament). Depending on the moduli, the helical shape may be smeared by thermal fluctuations. Secondary superhelical structures are expected to form on top of the specific local structure of biofilaments, as is documented for vimentin. We study confinement and adsorption of helical filaments utilizing both a combination of numerical simulations and analytical theory. We investigate overall chain shapes, transverse chain fluctuations, loop and tail distributions, and energy distributions along the chain together with the mean square average height of the monomers $⟨z^2⟩$ . The number fraction of adsorbed monomers serves as an order parameter for adsorption. Signatures of adsorbed helical polymers are the occurrence of 3D helical loops/tails and spiral or wavy quasi-flat shapes. None of these arise for the Worm-Like-Chain, whose straight ground state can be embedded in a plane. Full article

The rational function model (RFM) is widely used in the most advanced Earth observation satellites, replacing the rigorous imaging model. The RFM method achieves the desired calibration performance when image distortion is caused by long-period errors. However, the calibration performance of the RFM method deteriorates when short-period errors—such as attitude jitter error—are present, and the insufficient and uneven ground control points (GCPs) can also lower the calibration precision of the RFM method. Hence, this paper proposes a geometric calibration method using sparse recovery to remove the linear array push-broom sensor bias. The most important issue regarding this method is that the errors related to the imaging process are approximated to the equivalent bias angles. By using the sparse recovery method, the number and distribution of GCPs needed are greatly reduced. Meanwhile, the proposed method effectively removes short-period errors by recognizing periodic wavy patterns in the first step of the process. The image data from Earth Observing 1 (EO-1) and the Advanced Land Observing Satellite (ALOS) are used as experimental data for the verification of the calibration performance of the proposed method. The experimental results indicate that the proposed method is effective for the sensor calibration of both satellites. Full article
