In our investigation, we subjected eleven reinforced concrete beams to a four-point bending system to explore the impact of varying fibre and ferrocement contents on their structural behaviour. These beams, measuring 1.7 m in length, featured a rectangular cross-section with dimensions of 150 mm by 300 mm. Our study focused on three key variables: steel fibre content (at levels of 0.5%, 1%, and 1.5%), glass fibre content (also at 0.5%, 1%, and 1.5%), and ferrocement content (evaluated with one or two layers of welded or expanded wire mesh). Our findings revealed that incorporating fibres with minimal shear reinforcement significantly enhanced the beams’ performance. Specifically: The specimen reinforced with 1.5% steel fibres exhibited the highest ultimate failure load, surpassing the control beam by an impressive 41.87%. The 0.5% glass fibre specimen experienced the least deflection at the ultimate load compared to the control beam. The 1.5% glass fibre specimen demonstrated superior energy absorption compared to the control specimen. Notably, using two layers of welded wire mesh proved most effective in enhancing the ultimate failure load when compared to both the control specimen and other ferrocement-strengthened beams. Full article

Welded resistance slotted screens, also known as slotted screens, are a special type of screen primarily used for the filtration and separation of liquids and dust. They are characterized by slots with parallel geometry and precisely defined sizes. The quality of the side surfaces and edges of welded wires determines the durability of the slotted screens made from them. This article presents the results of tests for four types of wires: two types of working profile wires made from austenitic-ferritic steel (duplex) and two types of supporting cross wires made from ferritic steel. The wire surfaces were characterized using a profilometer and atomic force microscopy. Basic roughness parameters Ra, Rz, and SAD (surface area difference) were determined. Surface observations of the working profiles were conducted using scanning electron microscopy. These studies allowed for the characterization of the working wire surfaces used in the production of slotted screens. At work, the results of surface roughness were analyzed based on three measurement methods for wires used in the production of welded slot screens. These results allowed for the identification of the most reliable method for characterizing the surface condition of such products. Full article

Results of an experimental program of 13 confined masonry walls rehabilitated with different techniques are presented. All specimens were built to full-scale with an aspect ratio (height to length) of 1. Vertical confining elements of one wall were built with 6.4 mm diameter welded wire reinforcing cages. Before rehabilitation, 11 of the 13 walls were initially tested to induce repairable damage; the other 2 were strengthened in an undamaged state. During testing, walls were subjected to a constant vertical load. Initially, damaged walls were rehabilitated using various techniques, such as jacketing made of mortar and welded wire mesh and synthetic or steel fibers. One initially damaged wall was rehabilitated with premixed mortar and fiberglass mesh. After rehabilitation, specimens were tested for failure. The experimental program is discussed, including materials characterization and main test results. Recommendations to practicing engineers involved in rehabilitating earthquake-damaged masonry structures are presented. It was found that the original capacity of the walls, in terms of strength, stiffness, and deformation, was increased considerably using the studied techniques. It is concluded that the techniques evaluated in this project are adequate for the seismic rehabilitation of masonry structures. Full article

Ferrocement panels are thin-section panels that are widely used in lightweight construction. Due to lesser flexural stiffness, they are susceptible to surface cracking. Water may penetrate through these cracks and may cause corrosion of conventional thin steel wire mesh. This corrosion is one of the major factors which affect the load-carrying and durability of ferrocement panels. There is a need to improve the mechanical performance of ferrocement panels either through using some non-corrodible reinforcing mesh or through improving the cracking behavior of the mortar mix. In the present experimental work, PVC plastic wire mesh is employed to address this problem. SBR latex and polypropylene (PP) fibers are also utilized as admixtures to control the micro-cracking and improve the energy absorption capacity. The main idea is to improve the structural performance of ferrocement panels that may be utilized in lightweight, low-cost house construction and sustainable construction. The ultimate flexure strength of ferrocement panels employing PVC plastic wire mesh, welded iron mesh, SBR latex, and PP fibers is the subject of the research. Test variables are the type of mesh layer, the dosage of PP fiber, and SBR latex. Experimental tests are conducted on 16 simply supported panels of size 1000 × 450 mm and subjected to four-point bending test. Results indicate that the addition of latex and PP fibers only controls the initial stiffness and does not have any significant effect on ultimate load. Due to the increased bonding between cement paste and fine aggregates, the addition of SBR latex improves the flexural strength by 12.59% and 11.01% for iron mesh (SI) and PVC plastic mesh (SP), respectively. The results also indicate an improvement in the flexure toughness of specimens with PVC mesh as compared to specimens with iron welded mesh; however, a smaller peak load is observed (i.e., 12.21% for control specimens) compared with the specimen with welded iron mesh. The failure patterns of the specimens with PVC plastic mesh exhibit a smeared cracking pattern that shows that they are more ductile compared to samples with iron mesh. Full article

This paper focuses on the microstructure and tribological properties of novel hardfacing alloy based on Fe-C-Mn-B doped with Ni, Cr, and Si. The 4 mm-thick coating was deposited on the AISI 1045 carbon steel by the MIG-welding method using flux-cored wires in three passes. The transition zone thickness between the weld layers was ~80 μm, and the width of the substrate-coating interface was 5–10 μm. The following coating constituents were detected: coarser elongated M₂B borides, finer particles of Cr₇C₃ carbides, and an Fe-based matrix consisting of ferrite and austenite. The nanohardness of the matrix was ~5–6 GPa, carbides ~16–19 GPa, and borides 22–23 GPa. A high cooling rate during coating fabrication leads to the formation of a fine mesh of M₇C₃ carbides; borides grow in the direction of heat removal, from the substrate to the friction surface, while in the transition zone, carbides become coarser. The dry sliding friction tests using a tribometer in PoD configuration were carried out at contact pressure 4, 7, 10, and 15 MPa against the AISI 1045 carbon steel (water-quenched and low-tempered, 50–52 HRC). The leading wear phenomenon at 4 and 7 MPa is fatigue, and at 10 and 15 MPa it is oxidation and delamination. Full article

The huge amounts of old and damaged tires spread worldwide has caused many complex environmental risks. The old tires have been converted to crumb rubber (CR) and tire recycled steel fiber (RSF) to facilitate their use. This study used CR to partially replace natural sand in reinforced (RC) columns. Externally bonded (EB) carbon-fiber-reinforced polymer (CFRP) laminates, welded wire mesh (WWM), and RSF were used to enhance the axial behavior of the tested columns to overcome the concrete deficiencies resulting from the inclusion of the CR instead of natural sand. Eighteen columns were prepared and tested to discuss the effects of strengthening type, CR content, RSF, and strengthening area on the axial behavior of the RC columns. Certain columns were internally reinforced with WWM, while others were externally strengthened with EB CFRP laminates. Partially or fully EB CFRP laminates were used to strengthen the columns. Moreover, one column was cast with NC and 0.2% RSF to investigate the role of RSF in confining the column. The results demonstrated a concrete strength reduction for the rubberized concrete (CRC) as the CR content increased. Conversely, the strengthened columns experienced higher load capacities than the corresponding un-strengthened ones cast with the same concrete mix. Moreover, adding 2% RSF to the NC mix could enhance the column capacity, although it decreased the concrete strength. Furthermore, using two CFRP layers increased the load capacity and ductility of the strengthened columns. The strengthened column cast with 50% CR showed the highest load efficiency (334.3% compared to the un-strengthened one). Full article

Reinforced concrete structures, particularly in cold areas, experience early deterioration due to steel corrosion. Fiber-Reinforced Concrete (FRC) is an emerging construction material and cost-effective substitute for conventional concrete to enhance the durability and resistance against crack development. This article examines the structural performance of hybrid ferro fiber reinforced concrete slabs (mix ratio of mortar 1:2) comprising silica fume, layers of spot-welded mesh and different ratios of polypropylene fibers. The ferrocement slabs are compared with a conventional Reinforced Cement Concrete (RCC) slab (mix ratio of 1:2:4). The experimental work comprised a total of 13 one-way slabs, one control specimen and three groups of ferrocement slabs divided based on different percentages of Poly Propylene Fibers (PPF) corresponding to 0.10%, 0.30% and 0.50% dosage in each group. Furthermore, in each group, the percentage of steel ratio in ferrocement slabs varied between 25% and 100% of the steel area in the reinforced concrete control slab specimen. For evaluating the structural performance, the observation of deflection, stress-strain behavior, cracking load and energy absorption are critical parameters assessed using LVDTs and strain gauges. At the same time, the slabs were tested in flexure mode with third point loading. The experimental results showed that the first cracking load and ultimate deflection for fibrous specimens with 0.5% fiber and 10% silica fume increased by 15.25% and 13.2% compared with the reference RCC control slab. Therefore, by increasing the percentage of PPF and steel wire mesh reinforcement in the ferrocement slab, the post-cracking behavior in terms of deflection properties and energy absorption capacity was substantially enhanced compared to the RCC control slab. Full article

Lightweight clay aggregate (LECA) is manufactured by heating clay with no lime content in the kiln; as a result, the water evaporates and angular clay balls with pore structures are obtained. LECA possess internal curing properties as any other lightweight aggregate due to their pore structure and higher water absorption capacity. In this work, experimental and analytical behaviour using LECA as a 100% replacement for coarse aggregate to make lightweight concrete (LWC) beams was studied. The LWC beams were compared to the conventional concrete beams in load-deflection, energy absorption capacity, and ductility index. Internal mesh reinforcement using welded wire mesh (WWM) of (4 layers of 15 mm square spacing, 4 layers of 10 mm square spacing, and 4 layers of 15 mm and 10 mm mesh placed alternatively) was provided to enhance the load-carrying capacity of the LWC beam without increasing the dimensions and self-weight of the beams. The beam internally reinforced with WWM exhibited higher load carrying capacity and withstood more significant deflection without sudden failure. The internal reinforcement of WWM is provided to make steel rebars, and WWM works monolithically while loading; this will reduce the stress on tension bars and increase load-carrying capacity. Finally, the generated analytical findings agreed well with the experimental data, demonstrating that the analytical model could mimic the behaviour of LWC beams with WWM. Full article

To realize automatic wire arc additive manufacturing (WAAM) of a large aviation die with a complex gradient structure, a new contour-parallel path generation strategy was proposed and practically applied. First, the planar curve was defined as a vertical slice of a higher-dimensional surface and a partial differential equation describing boundary evolution was derived to calculate the surface. The improved Finite Element Method (FEM) and Finite Difference Method (FDM) were used to solve this partial differential equation. Second, a cross section of a large aviation die was used to test the path-generation algorithms. The results show that FEM has a faster solving speed than FDM under the same solving accuracy because the solving domain of FEM mesh was greatly reduced and the boundary mesh could be refined. Third, the die was divided into three layers: base layer, transition layer (Fe-based material) and strengthening layer (Co-based material) according to the difference of the temperature and stress field, and corresponding WAAM process parameters has been discussed. The optimum welding parameters are obtained as follows: voltage is 28 V, wire feeding speed is 8000 mm/min and welding speed is 450 mm/min. Finally, the path generation strategy was practically applied to the remanufacture of the large aircraft landing gear die with a three-layer structure. The application test on aircraft landing gear dies justified the effectiveness of the algorithms and strategy proposed in this paper, which significantly improved the efficiency of the WAAM process and the service life of large aviation dies with complex gradient structures. The microstructure of the fusion zone shows that the base metal and welding material can be fully integrated into the welding process. Full article

Sandwich beams are preferable for aerostructure and marine structures due to their high mechanical strength, durability, stiffness, and fatigue resistance. This paper presents a study on the flexural behavior of sandwich beams made of self-compacting concrete comprising a polystyrene inner core with wire mesh reinforcement. The effect of the design parameters such as the inner core area, percentage of tension reinforcement, and wire mesh on the moment carrying capacity and failure modes of sandwich beams was analyzed. Ten beams were cast and tested to failure with simply supported end conditions and they were classified into three different groups. The longitudinal section of the inner core area was varied by 0% (control beam), 25%, 50%, and 75% of the gross area. The tension reinforcement ratio varied between 0.6 and 1.5%. In addition, the effect of the wire mesh in shear and flexural resistance was studied. The load-carrying capacity of sandwich beams increased with flexural reinforcement. In addition, the welded wire mesh improved the sandwich beams’ flexural and shear performance. The conventional expressions for the moment of resistance were valid for sandwich beams, whereas the shear strength expressions overestimated the capacity; therefore, modifications were suggested. The refined models had a significant agreement with the experimental results. Full article

Wire mesh is a common material for bolt mesh supporting structures, but its application in engineering has revealed many defects. At the same time, with the development of new materials for civil engineering, the new material mesh performance and cost show outstanding advantages over wire mesh. In this paper, the feasibility of replacing wire mesh with steel-plastic geogrid as an alternative material is carefully studied through indoor tests and field applications. The following conclusions were drawn from a comparative analysis with wire mesh, mainly in terms of mechanical properties, engineering characteristics, and construction techniques: (1) in terms of mesh wire strength, wire mesh is slightly better than steel-plastic geogrid, but in the case of similar tensile strength, the amount of steel used per unit length of steel geogrid bars is only 36.75% of that of steel-plastic geogrid, while the tensile strength of the high-strength steel wire attached to the steel-plastic geogrid belt is about 3.3 times that of steel bars; (2) in terms of junction peel strength, both values are similar, with the injection-moulded junction being 1154.56–1224.38 N and the welded junction of 4 mm mesh being 988.35 N; (3) in terms of the strength of the mesh, steel-plastic geogrid is better than wire mesh, and with the same mesh wire strength, the bearing capacity of steel-plastic geogrid is increased by about 63.17% and the contribution of the mesh wire bearing capacity is increased by 83.66%, with the damage mainly being in the form of wire breakage in the ribbon causing ribbon failure, leading to further damage to the mesh; (4) in terms of the engineering application of steel-plastic geogrid compared to wire mesh, the utilization rate of mesh increases by about 24.99%, the construction efficiency increases by about 14.10%, and the economic benefit increases by about 45.31%. In practical application, the steel-plastic geogrid has good adhesion with surrounding rock and strong corrosion resistance. According to the above research analysis, the steel-plastic geogrid is feasible to replace the wire mesh for bolt mesh supporting. Full article

Geopolymer concrete (GC) is a substantial sort that is created by utilizing metakaolin, ground granulated blast furnace slag (GGBS), silica fumes, fly ash, and other cementitious materials as binding ingredients. The current study concentrated on the structural behavior of the ferrocement geopolymer HSC-columns subjected to axial loading and produced using rice straw ash (RSA). The major goal of this research was to use the unique features of the ferrocement idea to manufacture members that function as columns bearing members. As they are more cost-effective and lower in weight, these designed elements can replace traditional RC members. The study also intended to reduce the cost of producing new parts by utilizing low-cost materials such as light weight expanded and welded wire meshes, polyethylene mesh (Tensar), and fiber glass mesh. For this purpose, an experimental plan was conducted and a finite element prototype with ANSYS2019-R1 was implemented. Nine geopolymer ferrocement columns of dimensions of 150 mm × 150 mm × 1600 mm with different volume-fraction and layers as well as a number of metallic and nonmetallic meshes were examined under axial compression loading until failure. The performance of the geopolymer columns was examined with consideration to the mid-span deflection, ultimate failure load, first crack load with various phases of loading, the cracking patterns, energy absorption and ductility index. Expanded or welded ferrocement geopolymer columns showed greater ultimate failure loads than the control column. Additionally, using expanded or welded columns had a considerable effect on ultimate failure loads, where the welded wire mesh exhibited almost 28.10% compared with the expanded wire mesh. Columns reinforced with one-layer of nonmetallic Tensar-mesh obtained a higher ultimate failure load than all tested columns without concrete cover spalling. The analytical and experimental results were in good agreement. The results displayed an accepted performance of the ferrocement geopolymer HSC-columns. Full article

This study considered the possibility of using steel gabion baskets made of welded mesh for a soil-strengthening function. Examples of such applications are known for meshes made of wires with diameters from 6.3 to 12.7 mm and mesh openings from 125 to 225 mm. In the case of a welded grid, the pulling resistance of fine-grained soil consists of two factors: frictional resistance and bearing resistance. Therefore, for the purposes of this issue, a simplified laboratory pullout test was carried out with four types of welded steel grid (common in Europe) embedded in the fine sand. The geometry of the grid (opening size: 76.2 × 76.2 mm), the type of steel (low carbon steel, tensile strength from 500 to 700 MPa), the diameter of the wire (2.7–4.5 mm) and its cover (ZN + PVC or ZnAl) were taken into account during the analysis. It was unequivocally stated that as the stiffness of the steel grid itself increases, its strength increases during the pullout test, which is not so obvious in the case of popular steel woven meshes. In addition, it has been shown that steel welded meshes with wire diameters less than 6 mm are suitable for soil reinforcement in structures with gabion facing, and the determined apparent friction coefficient (μ_k = 0.39–1.47) takes values similar to the friction coefficient given in references for welded meshes of larger diameters. This is a positive premise for starting further research on the use of wires of smaller diameters for welded mesh production used as soil reinforcement. Full article

Multi-walled carbon nanotubes (MWCNTs) in the form of “forests” were synthesized directly on the surface of stainless steel (SS) mesh from ethanol flame volume. The growth dependence of the MWCNT forests on the porosity of SS mesh substrate and the morphologies and growth mechanism of the MWCNT forests were investigated in detail by a combination of turbulent flow simulation, scanning electron microscopy (SEM), transmission electron microscope (TEM), and Raman and X-ray diffraction (XRD) spectroscopy. The growth height of the MWCNT forests exhibited a strong dependence on the flame gas flow rate controlled by the porosity of SS mesh substrate, and the maximum averaged height of the MWCNT forests reached 34 μm. Most MWCNTs grew perpendicularly on the surface of SS wires, and some branch, welded, and spiral structures were observed by SEM and TEM. The MWCNT-decorated mesh was used as a novel heating element to weld glass-fabric-reinforced polyetherimide (GF/PEI) thermoplastics. We found that the maximum tensile lap-shear strength (LSS) of the welded joints could reach 39.21 MPa, an increase of 41% in comparison with that of conventional SS mesh-based joints. Full article

Industrial pavements are thin slabs on a continuous support subjected to restrained shrinkage and loads. The use of fibers as an alternative reinforcement to steel welded wire mesh and rebars is today an extensive practice for the reinforcement of concrete slabs-on-grade. Despite the widespread use of fiber reinforcement, the corresponding benefits in controlling cracking phenomena due to shrinkage are generally not considered in the design process of Fiber Reinforced Concrete (FRC) slabs-on-grade. The post-cracking performance provided by glass macro-fibers at low crack openings is particularly convenient in structures with a high degree of redundancy. Referring to service conditions, it is well known that concrete shrinkage as well as thermal effects tend to be the principal reasons for the initial crack formation in slabs-on-grade. A numerical study on the risk of cracking due to shrinkage in ground-supported slabs is presented herein. Special attention is devoted to the evaluation of the beneficial effects of glass fibers in controlling cracking phenomena due to shrinkage. The numerical analyses are carried out on jointless pavements of different sizes. Since shrinkage stresses in slabs-on-grade are considerably influenced by external constraints which limit the contractions, different subgrade conditions have been also considered. Full article
