To modernize electrical power systems on isolated islands, countries around the world have increased their interest in combining green energy with conventional power plants. Wind energy (WE) is the most adopted renewable energy source due to its technical readiness, competitive cost, and environmentally friendly characteristics. Despite this, a high penetration of WE in conventional power systems could affect their stability. Moreover, these isolated island power systems face frequency deviation issues when operating in hybrid generation mode. Generally, under contingency or transient conditions for hybrid isolated wind–diesel power systems (WDPSs), it is only the diesel generator that provides inertial support in frequency regulation (FR) because wind turbines are unable to provide inertia themselves. Frequency deviations can exceed the pre-defined grid code limits during severe windy conditions because the diesel generator’s inertial support is not always sufficient. To overcome this issue, we propose a control strategy named emulation inertial and proportional (EI&P) control for Variable-Speed Wind Turbines (VSWTs). VSWTs can also contribute to FR by releasing synthetic inertia during uncertainties. In addition, to enhance the effectiveness and smoothness of the blade pitch angle control of WTs, a pitch compensation (PC) control loop is proposed in this paper. The aim of this study was to provide optimal primary frequency regulations to hybrid wind–diesel power systems (WDPSs). Therefore, the hybrid WDPS on San Cristobal Island was considered in this study. To achieve such goals, we used the above-mentioned proposed controls (EI&P and PC) and optimally tuned them using the Student-Psychology-Based Algorithm (SPBA). The effectiveness of this algorithm is in its ability to provide the best optimum controller gain combinations of the proposed control loops. As a result, the FD in the WDPS on San Cristobal Island was reduced by 1.05 Hz, and other quality indices, such as the integral absolute error (IAE), integral square error (ISE), and controller quality index (Z), were improved by 159.65, 16.75, and 83.80%, respectively. Moreover, the proposed PC control, which was further simplified using exhaustive searches, resulted in a reduction in blade pitch angle control complexity. To validate the results, the proposed approach was tested under different sets of perturbations (sudden loss of wind generator and gradual increase in wind speed and their random behavior). Furthermore, hybrid systems were tested simultaneously under different real-world scenarios, like various sets of load or power imbalances, wind variations, and their combinations. The Simulink results showed a significant improvement in FR support by minimizing frequency deviations during transients. Full article

This paper presents the design of an innovative scalable wind turbine emulator. The system’s hardware and software components are described in detail including test results, demonstrating the research potential of the proposed design. The uniqueness of the proposed solution lies in its scalability, achieved despite the use of physical devices with fixed parameters. This scalability allows for the flexible shaping of the system’s structure and parameters, allowing it to emulate both individual wind turbines with a capacity ranging from kilowatts to megawatts as well as aggregated models of entire wind farms. The emulator was developed using the hardware-in-the loop (HIL) concept and consists of a digital part including aerodynamic and mechanical models (wind, rotor, shaft models, disturbances, etc.) and control systems for mechanical and electrical devices within the wind turbine. The digital component has a modular structure, which allows for the replacement of any module of the native control system with the user’s custom designed one and testing its properties over a broad range of parameters. The test results presented in the article demonstrate a satisfactory level of accuracy of the developed emulator. Full article

This paper presents the design and performance evaluation of an experimental platform that emulates the static and dynamic behavior of a 3 kW Wind Energy Conversion System (WECS). The platform includes a wind turbine emulator (WTE) using a separately excited DC motor (SEDCM) as the prime mover, coupled with a grid-connected doubly-fed induction generator (DFIG). This setup enables comprehensive laboratory studies of a WECS without the need for large-scale field installations. A novel inertia compensation strategy is implemented to ensure the SEDCM accurately replicates the power and torque characteristics of a real wind turbine across various wind profiles. The DFIG was chosen for its high efficiency at variable wind speeds and its reduced power converter requirements compared to other generators. The control strategy for the DFIG is detailed, highlighting its performance and seamless integration within the system. Unlike most studies focusing on generators connected to simple loads, this research considers a grid-connected system, which introduces additional challenges and requirements. This study thoroughly investigates the grid-connected converter, addressing specific demands for grid connection and ensuring compliance with grid standards. Experimental results validate the effectiveness of the emulator, demonstrating its potential as a key tool for optimizing wind turbine control strategies and real-time algorithm validation, and enhancing the performance and reliability of renewable energy systems. Full article

Grid-forming wind turbines (GFM-WTs) based on virtual synchronous control can support the voltage and frequency of power system by emulating the synchronous generator. The dynamic characteristics of a GFM-WT decided by virtual synchronous control, dq-axis voltage, and current control is significant for small-signal stability analysis. This paper builds a small-signal model of a GFM-WT in active power control (APC) and DC voltage control (DVC) timescale from the perspective of internal voltage. The proposed model describes how the magnitude and phase of the internal voltage are excited by the unbalanced active and reactive power when small disturbances occur. Interactions in different control loops can be identified by the reduced order model. We verify the accuracy of the proposed model in APC and DVC timescales by time domain simulations based on MATLAB/Simulink. Case studies show how the control parameters interact with each other in the two timescales. Full article

There is an urgent need to develop accurate predictions of power production, wake losses and array–array interactions from multi-GW offshore wind farms in order to enable developments that maximize power benefits, minimize levelized cost of energy and reduce investment uncertainty. New, climatologically representative simulations with the Weather Research and Forecasting (WRF) model are presented and analyzed to address these research needs with a specific focus on offshore wind energy lease areas along the U.S. east coast. These, uniquely detailed, simulations are designed to quantify important sources of wake-loss projection uncertainty. They sample across different wind turbine deployment scenarios and thus span the range of plausible installed capacity densities (ICDs) and also include two wind farm parameterizations (WFPs; Fitch and explicit wake parameterization (EWP)) and consider the precise WRF model release used. System-wide mean capacity factors for ICDs of 3.5 to 6.0 MWkm⁻² range from 39 to 45% based on output from Fitch and 50 to 55% from EWP. Wake losses are 27–37% (Fitch) and 11–19% (EWP). The discrepancy in CF and wake losses from the two WFPs derives from two linked effects. First, EWP generates a weaker ‘deep array effect’ within the largest wind farm cluster (area of 3675 km²), though both parameterizations indicate substantial within-array wake losses. If 15 MW wind turbines are deployed at an ICD of 6 MWkm⁻² the most heavily waked wind turbines generate an average of only 32–35% of the power of those that experience the freestream (undisturbed) flow. Nevertheless, there is no evidence for saturation of the resource. The wind power density (electrical power generation per unit of surface area) increases with ICD and lies between 2 and 3 Wm⁻². Second, EWP also systematically generates smaller whole wind farm wakes. Sampling across all offshore wind energy lease areas and the range of ICD considered, the whole wind farm wake extent for a velocity deficit of 5% is 1.18 to 1.38 times larger in simulations with Fitch. Over three-quarters of the variability in normalized wake extents is attributable to variations in freestream wind speeds, turbulent kinetic energy and boundary layer depth. These dependencies on meteorological parameters allow for the development of computationally efficient emulators of wake extents from Fitch and EWP. Full article

The future of wind power systems deployment is in the form of wind farms comprised of scores of such large turbines, most likely at offshore locations. Individual turbines have grown in span from a few tens of meters to today’s large turbines with rotor diameters that dwarf even the largest commercial aircraft. These massive dynamical systems present unique challenges at scales unparalleled in prior applications of wind science research. Fundamental to this effort is the understanding of the wind turbine wake and its evolution. Furthermore, the optimization of the entire wind farm depends on the evolution of the wakes of different turbines and their interactions within the wind farm. In this article, we use the capabilities of the Common ODE Framework (CODEF) model for the analysis of the effects of wake–rotor and wake-to-wake interactions between two turbines situated in a tandem layout fully and partially aligned with the incoming wind. These experiments were conducted in the context of a research project supported by the National Rotor Testbed (NRT) program of Sandia National Labs (SNL). Results are presented for a layout which emulates the turbine interspace and relative turbine emplacement found at SNL’s Scaled Wind Technologies Facility (SWiFT), located in Lubbock, Texas. The evolution of the twin-wake interaction generates a very rich series of secondary transitions in the vortex structure of the combined wake. These ultimately affect the wake’s axial velocity patterns, altering the position, number, intensity, and shape of localized velocity-deficit zones in the wake’s cross-section. This complex distribution of axial velocity patterns has the capacity to substantially affect the power output, peak loads, fatigue damage, and aeroelastic stability of turbines located in subsequent rows downstream on the farm. Full article

A maximum power point tracking control strategy for an affine nonlinear constant displacement pump-variable hydraulic motor actuation system with parameter uncertainty, used within an offshore hydraulic wind turbine, is studied in this paper. First, we used the feedback linearization method to solve the affine nonlinear problem in the system. However, offshore hydraulic wind turbines have strong parameter uncertainty characteristics. This conflict was resolved through the further application of RBF neural network adaptive control theory. So, we combined feedback linearization with RBF adaptive control as the control theory, and then two control laws were compared by setting the pump rate and rating as outputs, respectively. It is shown by the MATLABR2016a/Simulink emulation results that power control is smoother than speed and friendlier for electric networks. It is also shown by the emulation results, in terms of the undulatory wind speed condition, that the feedback linearization–RBF neural network adaptive control strategy has perfect robustness. According to the simulation results, the feedback linearization–RBF neural network adaptive control strategy adopts the RBF neural network to approach complex nonlinear models and solve the parameter uncertainty problem. This control law also avoids the use of feedback linearization control alone, which can result in the system becoming out of control. Full article

Airborne wind energy systems (AWES) are more efficient than traditional wind turbines because they can capture higher wind speeds at higher altitudes using connected kite generators. Securing a real wind turbine or a site with favorable wind conditions is not always an assured opportunity for conducting research. Hence, the Research and Development of the Laboratory Scale Airborne Wind Energy Conversion System (LAWECS) require a better understanding of airborne wind turbine dynamics and emulation. Therefore, an airborne wind turbine emulation system was designed, implemented, simulated, and experimentally tested with ground data for the real time simulation. The speed and torque of a permanent magnet synchronous motor (PMSM) connected to a kite are regulated to maximize wind energy harvesting. A field-oriented control technique is then used to control the PMSM’s torque, while a three-phase power inverter is utilized to drive the PMSM with PI controllers in a closed loop. The proposed framework was tested, and the emulated airborne wind energy conversion system results were proven experimentally for different wind speeds and generator loads. Further, the LAWECS emulator simulated a 2 kW, 20 kW, and 60 kW designed with a projected kite area of 5, 25, and 70 square meters, respectively. This system was simulated using the Matlab/Simulink software and tested with the experimental data. Furthermore, the evaluation of the proposed framework is validated using a real-time hardware-in-the-loop environment, which uses the FPGA-based OPAL-RT Simulator. Full article

The robust stabilization of doubly fed induction generators in wind turbines against external disturbances is considered in this study. It is assumed that the angular speeds of wind turbines can only be measured and sent to the controller in a discrete-time fashion over a network. To generate the sampling times, three different triggering schemes were developed: time-triggering, static event-triggering, and dynamic event-triggering mechanisms; moreover, performance comparisons were conducted between such approaches. The design methodology is based on emulation, such that the plant is first stabilized in continuous-time where a robust feedback law is constructed based on the linear quadratic Gaussian regulator (LQG) approach. Then, the impact of the network is taken into account, and an event-triggering mechanism is built so that closed-loop stability is maintained and the Zeno phenomenon is avoided by using temporal regularization. The necessary stability constraints are framed as a linear matrix inequality, and the whole system is modeled as a hybrid dynamical system. A numerical simulation is used to demonstrate the effectiveness of the control strategy. The results show that the event-triggering mechanisms achieve a significant reduction of around 50% in transmissions compared to periodic sampling. Moreover, numerical comparisons with existing approaches show that the proposed approach provides better performance in terms of the stability guarantee and number of transmissions. Full article

This study focuses on implementing a wind turbine emulator based on a permanent magnet synchronous machine with excitation auxiliary windings and thoroughly investigates the space harmonics created by this innovative topology in MATLAB/Simulink. A Hybrid Generator (HG) is a robust generator that does not have slip rings or brushes in its structure. Furthermore, the flux of the hybrid generator HG may be easily adjusted as it is created by direct current excitation coils and permanent magnets. Unfortunately, the space harmonic rate in the HG is relatively high. In other words, the mechanical vibrations caused by the electromagnetic torque ripple threaten the drive train’s behaviour and, ultimately, the wind turbine’s lifespan. This study describes two methods for decreasing the ripple in electromagnetic torque. Both circuit architecture and robust H_∞ control techniques are considered. After simulating the two approaches, a list of requirements is provided for the maximum allowable amplitude of the inductance and the flux harmonics. Full article

In recent years, nacelle test benches for wind turbines have been developed internationally. New standards are currently being developed that explicitly refer to the measurement of the electrical properties of wind turbines on these test benches. Thus, they are suitable for measuring the electrical properties required for certification. Another part of the certification is the creation and validation of suitable models of the wind turbine, which are used for stability analyses of the utility grid. Validation requires a suitable model of grid replication on the test benches, which is not yet covered by any applicable standard. Such models should be as simplified a representation of the artificial grid replication as possible to ensure that they are accessible to certification bodies. A model of the grid emulator installed at the CWD of RWTH Aachen University, which was validated with real measurement data, serves as a reference. A step-by-step reduction of the model’s depth up to the system’s technical representation is followed by a model evaluation with respect to the level of detail and an analysis of time and frequency. The evaluation shows that even a highly simplified model consisting of a reference voltage and an impedance replica meets the requirements for the validation of wind turbine models according to IEC 61400-27-2. Full article

Small-scale wind turbines play an important role in distributed generation since customers can use their houses, farms, and business to produce electric energy. The development of the power electronics system that processes the electric energy from small-scale wind turbines is a concern due to cost, simplicity, efficiency, and performance trade-offs. This paper presents the results of applying a three-phase phase-modular single-ended primary-inductance converter rectifier to processing the energy of a small-scale wind turbine system. The rectifier was designed according to the specifications of a commercial small-scale wind turbine system and tested in an emulator workbench, providing experimental data on the operation of the rectifier in this application. The rectifier can process the energy of a non-sinusoidal three-phase system since the permanent magnet synchronous generator has trapezoidal waveforms. The results show that the rectifier has the advantages of (i) using the inductance of the generator as the input filter inductor of the rectifier, (ii) providing input currents with the same shape as the voltages and in phase without the use of a current control system, (iii) simplicity of control of the DC output voltage and PWM modulation, and (iv) phase-modular characteristics that allow operating with phase fault without any additional control techniques. Due to the operation in discontinuous conduction mode, low efficiency in high power and/or low input voltage specifications are disadvantages. Full article

The need for energy has significantly increased in the world in recent years. Various research works were presented to develop Renewable Energy Sources (RESs) as green energy Distributed Generations (DGs) to satisfy this demand. In addition, alleviating environmental problems caused by utilizing conventional power plants is diminished by these renewable sources. The optimal location and size of the DG-RESs significantly affect the performance of Radial Distribution Systems (RDSs) through the fine bus voltage profile, senior power quality, low power losses, and high efficiency. This paper investigates the use of PV (photovoltaic) and (Wind Turbine) WT systems as a DG source in RDSs. This investigation is presented via the optimal location and size of the PV and WT systems, which are the most used DG sources. This optimization problem aims to maximize system efficiency by minimizing power losses and improving both voltage profile and power quality using White Shark Optimization (WSO). This algorithm emulates the attitude of great white sharks when foraging using their senses of hearing and smell. It confirms the balance between exploration and exploitation to discover optimization that is considered as the main advantage of this approach in attaining the global minimum. To assess the suggested approach, three common RDSs are utilized, namely, IEEE 33, 69, and 85 node systems. The results prove that the applied WSO approach can find the best location and size of the RESs to reduce power loss, ameliorate the voltage profile, and outlast other recent strategies. Adding more units provides a high percentage of reducing losses by at least 93.52% in case of WTs, rather than 52.267% in the case of PVs. Additionally, the annual saving increased to USD 74,371.97, USD 82,127.257, and USD 86,731.16 with PV penetration, while it reached USD 104,872.96, USD 116,136.57, and USD 155,184.893 with WT penetration for the 33, 69, and 85 nodes, respectively. In addition, a considerable enhancement in the voltage profiles with the growth of PV and WT units was confirmed. The ability of the suggested WSO for feasible implementation was validated and inspected by preserving the restrictions and working constraints. Full article

Although a switched reluctance generator (SRG) is not the mainstream wind generator, it possesses the application potential and is worth developing for its many structural merits and high developed power ability. This paper presents a wind SRG-based bipolar DC microgrid having grid-connected and plug-in energy supporting functions. First, a surface-mounted permanent magnet synchronous motor (SPMSM)-driven wind turbine emulator (WTE) is established. Next, the wind SRG with an asymmetric bridge converter is developed. Good generating characteristics are obtained through proper designs of power circuit, commutation mechanism, external excitation source, voltage and current controllers. Third, a DC/DC boost interface converter and a bipolar voltage balancer are constructed to establish the 500 V microgrid bipolar DC-bus. To preserve the microgrid power supplying quality, a battery energy storage system (BESS) with bidirectional DC/DC interface converter is equipped. A dump load leg is added across the bus to limit the DC-bus voltage under energy surplus condition. In load side, a three-phase bidirectional load inverter is developed, which can be operated as a single-phase three-wire (1P3W) inverter or a three-phase three-wire (3P3W) inverter. Good sinusoidal voltage waveform and regulation characteristics are obtained using the proportional-resonant (PR) control. The microgrid to load and microgrid to grid operations are conductible. Finally, to further improve the powering reliability of microgrid, a three-phase T-type Vienna switch-mode rectifier (SMR) based plug-in energy supporting scheme is developed. When the microgrid energy shortage occurs, the possible harvested energy can be used to supply the microgrid. Full article

Changes in climatic circumstances, as well as intermittency, which has a significant impact on the overall energy system output from renewable energy sources (RESs), require the development of control strategies for extracting the maximum power available from RESs. To accomplish this task, several techniques have been developed. An efficient maximum power point tracking (MPPT) technique should be utilized to guarantee that both wind-generation and PV-generation systems provide their full advantages. In this paper, a new MPPT approach with jellyfish search optimization (JSO) is developed; in addition, a unified power-quality conditioner (UPQC) is utilized to enhance the performance of the microgrid (MG) and to solve the power-quality issues for the sensitive load. The MG, which includes a photovoltaic (PV), a wind turbine, and a fuel cell battery, is examined and modeled for uniform and nonuniform wind speed and solar irradiance. A comparison between the developed algorithm and different maximum power tracking algorithms is presented. Additionally, four case studies are carried out to verify the effectiveness of the introduced UPQC in enhancing power-quality problems. The research outcome shows high performance from the developed algorithm when assessed with additional algorithms. MATLAB/Simulink software is utilized for the simulation of the wind, PV, and FC control systems. However, experiment validation tests are given under the same condition of PV irradiation to validate the simulation results. The experimental validation is executed by utilizing the PV module simulation model, threefold, 23 V/2A CO3208-1A with solar altitude emulator CO3208-1B board, and the results are compared to the simulation results. Full article
