Discovery of 5-(5,5-Dimethylbutenolide-3-ethylidene)-2-amino-imidazolinone Derivatives as Fungicidal Agents

Abstract

The novel fungicidal agents 5-(5,5-dimethylbutenolide-3-ethylidene)-2-amino-imidazolinone derivatives, were designed and synthesized in moderate to excellent yields in four steps by α-hydroxyketone and diketene as raw materials and characterized by HR-ESI-MS and ¹H-NMR. The preliminary bioassay showed that some of these compounds, such as 4a, 4e and 5g exhibit 94.9%, 92.8% and 81.4% inhibition rates against Sclerotinia scleotiorum at the concentration of 50 µg/mL, respectively. The EC₅₀ values of compounds 4e and 4i were 4.14 and 3.27 µM against Alternaria Solani, and 5g had EC₅₀ value of 3.23 µM against S. scleotiorum. Compounds 4d and 4g displayed 98.0% and 97.8% control of spore germination against Botrytis cinerea at the concentration of 100 µg/mL, respectively.

1. Introduction

In recent years, various imidazolinone-containing compounds have been found in nature or synthesized and reported to display a wide range of biological activity such as fenamidone (Scheme 1) having antimicrobial and fungicidal activities [1,2,3,4,5,6,7,8,9]. Several 5-cyclohexylidene-2-aminoimidazolin-4-one derivatives have been prepared in our laboratory and showed significant fungicidal activities against several important phytopathgens [10,11]. Furthermore, the natural and unnatural butenolide derivatives including 3-acetyl-5,5-dimethylbutenolide (Scheme 1) exhibited interesting biological activities [12,13,14,15,16]. Some heterocyclic compounds derived from 3-acetyl-5,5-dimethylbutenolide were also reported, but their biological activities were not disclosed [17,18]. In order to continue our exploration of novel biologically active 2-aminoimidazolin-4-one heterocyclic compounds [10,11,19], butenolide and 2-aminoimidazolin-4-one were combined into a new class of 2-aminoimidazolin-4-one derivatives containing 5,5-dimethylbutenolide heterocycle derivatives as inhibitors of mitochondrial respiration, (Scheme 1 and Scheme 2) to improve their activities against the important agricultural diseases, which had not been published in literatures. In this paper, a series of 5-(5,5-dimethylbutenolide-3-ethylidene)-2-aminoimidazolinone derivatives were designed and synthesized, and their fungicidal activities and the structure-activity relationships were explored.

Scheme 1. The design of target molecules based on the active groups.

Scheme 1. The design of target molecules based on the active groups.

Scheme 2. The synthetic route of 5-(butenolide-3-ethylidene)-2-aminoimidazolinone derivatives.

Scheme 2. The synthetic route of 5-(butenolide-3-ethylidene)-2-aminoimidazolinone derivatives.

2. Results and Discussion

As indicated in the introduction, both imidazolinone and butenolide derivatives displayed a wide range of biological activity [1,2,3,4,5,6,7,8,9,12,13,14,15,16]. Based on these characters, we combined the butenolide and 2-aminoimidazolin-4-one into one molecule (Scheme 1) and synthesized the novel 2-aminoimidazolin-4-one derivatives containing butenolide heterocycles (4, 5). As shown in Scheme 2, the intermediates 1a and 1b were synthesized by the reaction of α-hydroxyketone with diketene in 80% and 84% yields following the literature procedure [20], followed by reacting with thiohydantion catalysed by 2-aminoethanol to afford 2a and 2b in 63% and 67% yields, respectively [10,11]. Then methylations of 2a and 2b with methyl iodide were carried out at ambienent temperature to give the key intermediates 3a and 3b in 90% and 79% yields [19]. Finally, the intermediates 3a and 3b reacted with anilines or benzyl amines under reflux to produce the target compounds 4a–4t and 5a–5l in moderate to excellent yields. Interestingly, if acetic acid was used as solvent, compound 6 was isolated as the byproduct in 10%–40% yield when we first run the preparing reactions of 4a–4t and fully characterized it by ¹H-NMR, ¹³C-NMR and HR-ESI-MS. However, after changing from acetic acid to dioxane and adding oxalic acid to the reaction system, the byproduct was not observed. Moreover, purification of the final products was easier and the yields were also improved. So the preparation of compounds 5a–5l selected the dioxane as solvent and added oxalic acid into the reaction system to effectively avoid the byproduct. In the ¹H-NMR spectrum, the two methyl groups had the same chemical shifts in compounds 1a, 2a, 3a and 4a–4t, while the two methyl groups in compounds 1b, 2b, 3b and 5a–5l had different chemical shifts due to the orientation of phenyl group at 4-position in the butenolide moiety (see Supplementary Materials). The ¹H-NMR spectra of 4a–4t and 5a–5l were similar to those compounds in the literatures [10,19].

Based on the data in Table 1, compounds 4 and 5 showed a broad-spectrum of fungicidal activities against these six tested phytopathgens. They were found to be particularly active against Sclerotinia scleotiorum and Rhizoctonia solani, for example, 4a, 4e and 5g exhibited 94.9%, 92.8% (much higher than the commecialized carbendazim and nearly equal to chlorothalonil and fenamidone) and 81.4% inhibition rates against S. scleotiorum, 4d, 4g, 4i, 4j, 4m and 4t showed 72.9%, 72.9%, 72.1%, 75.7%, 72.0%, and 72.5% inhibition rates against R. solani at the concentration of 50 µg/mL, respectively.

Table 1. The fungicidal activities (inhibition rate, %) of compounds 4 and 5 at 50 µg/mL.

Compd.	n R2 R3	S. scleotiorum	R. solani	A. solani	B. cinerea	P. capsici	F. graminearum
1a		0.0	0.0	0.0	0.0	0.0	0.0
1b		0.0	0.0	0.0	0.0	0.0	0.0
2a		49.7	66.8	42.3	52.2	69.8	31.8
2b		3.3	7.7	1.5	36.2	59.3	3.9
3a		25.4	72.7	51.9	20.0	79.4	34.0
3b		0.0	18.6	0.0	16.8	34.2	10.6
4a	0 H H	94.9	68.4	50.9	60.5	24.0	21.1
4b	0 H 4-CH3	33.1	63.5	60.3	27.2	29.3	31.6
4c	0 H 4-F	19.1	59.6	63.2	31.8	16.7	38.2
4d	0 H 4-OCH3	32.3	72.9	60.8	75.3	15.5	38.6
4e	0 H 4-CF3	92.8	61.2	64.8	32.2	0.0	48.7
4f	0 CH3 H	31.7	57.6	53.9	16.5	36.1	0.0
4g	0 H 3-CF3	65.0	72.9	55.7	69.3	47.7	38.0
4h	0 H 2-CH3	16.5	56.4	37.0	36.2	15.7	0.0
4i	0 H 2-F	38.9	76.1	67.7	40.2	0.0	23.9
4j	0 H 2-OCH3	22.2	75.7	22.0	21.4	33.9	31.5
4k	0 H 2-Cl	18.7	44.6	44.6	45.5	41.8	37.4
4l	0 H 2,6-(CH3)2	30.8	65.3	45.9	29.1	2.1	39.2
4m	1 H H	52.2	72.0	53.9	48.4	23.0	22.9
4n	1 H 4-OCH3	36.9	66.5	39.0	28.6	0.0	51.3
4o	1 H 4-Cl	16.3	68.2	48.1	40.3	5.3	30.7
4p	1 H 4-F	21.5	48.5	45.4	39.2	33.6	38.5
4q	1 H 3-CF3	21.7	64.9	61.2	33.3	56.6	45.1
4r	1 H 2-F	15.4	59.5	41.2	31.6	27.6	23.5
4s	1 H 2-Cl	21.1	60.4	38.5	27.0	21.3	13.0
4t	1 H 2-OCH3	22.2	72.5	42.1	41.5	0.0	10.1
5a	0 H H	67.8	7.6	0.0	21.3	27.7	26.4
5b	0 H 4-CH3	29.4	10.9	11.6	25.1	13.3	22.0
5c	0 H 4-F	44.6	0.0	34.9	25.2	48.0	37.1
5d	0 H 4-OCH3	21.4	6.9	0.0	15.2	20.0	16.7
5e	0 H 4-CF3	58.1	11.4	31.4	38.6	50.4	24.1
5f	0 H 3-CF3	36.8	11.4	65.7	48.6	44.4	32.6
5g	0 H 2-F	81.4	12.9	14.4	26.3	45.1	59.9
5h	0 H 2-Cl	57.8	2.3	37.3	30.3	37.1	40.2
5i	0 H 2-OCH3	31.2	1.5	0.0	6.8	8.7	20.0
5j	1 H H	18.3	9.6	5.2	0.0	2.4	28.3
5k	1 H 4-Cl	29.2	0.0	24.4	12.6	13.3	15.4
5l	1 H 2-OCH3	30.0	6.9	3.0	8.5	0.0	27.7
6		41.7	46.1	70.7	40.9	4.2	31.6
Chlorothalonil		100	99.9	100	100	99.1	95.8
Carbendazim		81.0	100	100	4.2	34.7	100
Fenamidone		97.8	96.4	93.5	57.1	79.8	71.9

Table 1. The fungicidal activities (inhibition rate, %) of compounds 4 and 5 at 50 µg/mL.

Compd.	n R2 R3	S. scleotiorum	R. solani	A. solani	B. cinerea	P. capsici	F. graminearum
1a		0.0	0.0	0.0	0.0	0.0	0.0
1b		0.0	0.0	0.0	0.0	0.0	0.0
2a		49.7	66.8	42.3	52.2	69.8	31.8
2b		3.3	7.7	1.5	36.2	59.3	3.9
3a		25.4	72.7	51.9	20.0	79.4	34.0
3b		0.0	18.6	0.0	16.8	34.2	10.6
4a	0 H H	94.9	68.4	50.9	60.5	24.0	21.1
4b	0 H 4-CH3	33.1	63.5	60.3	27.2	29.3	31.6
4c	0 H 4-F	19.1	59.6	63.2	31.8	16.7	38.2
4d	0 H 4-OCH3	32.3	72.9	60.8	75.3	15.5	38.6
4e	0 H 4-CF3	92.8	61.2	64.8	32.2	0.0	48.7
4f	0 CH3 H	31.7	57.6	53.9	16.5	36.1	0.0
4g	0 H 3-CF3	65.0	72.9	55.7	69.3	47.7	38.0
4h	0 H 2-CH3	16.5	56.4	37.0	36.2	15.7	0.0
4i	0 H 2-F	38.9	76.1	67.7	40.2	0.0	23.9
4j	0 H 2-OCH3	22.2	75.7	22.0	21.4	33.9	31.5
4k	0 H 2-Cl	18.7	44.6	44.6	45.5	41.8	37.4
4l	0 H 2,6-(CH3)2	30.8	65.3	45.9	29.1	2.1	39.2
4m	1 H H	52.2	72.0	53.9	48.4	23.0	22.9
4n	1 H 4-OCH3	36.9	66.5	39.0	28.6	0.0	51.3
4o	1 H 4-Cl	16.3	68.2	48.1	40.3	5.3	30.7
4p	1 H 4-F	21.5	48.5	45.4	39.2	33.6	38.5
4q	1 H 3-CF3	21.7	64.9	61.2	33.3	56.6	45.1
4r	1 H 2-F	15.4	59.5	41.2	31.6	27.6	23.5
4s	1 H 2-Cl	21.1	60.4	38.5	27.0	21.3	13.0
4t	1 H 2-OCH3	22.2	72.5	42.1	41.5	0.0	10.1
5a	0 H H	67.8	7.6	0.0	21.3	27.7	26.4
5b	0 H 4-CH3	29.4	10.9	11.6	25.1	13.3	22.0
5c	0 H 4-F	44.6	0.0	34.9	25.2	48.0	37.1
5d	0 H 4-OCH3	21.4	6.9	0.0	15.2	20.0	16.7
5e	0 H 4-CF3	58.1	11.4	31.4	38.6	50.4	24.1
5f	0 H 3-CF3	36.8	11.4	65.7	48.6	44.4	32.6
5g	0 H 2-F	81.4	12.9	14.4	26.3	45.1	59.9
5h	0 H 2-Cl	57.8	2.3	37.3	30.3	37.1	40.2
5i	0 H 2-OCH3	31.2	1.5	0.0	6.8	8.7	20.0
5j	1 H H	18.3	9.6	5.2	0.0	2.4	28.3
5k	1 H 4-Cl	29.2	0.0	24.4	12.6	13.3	15.4
5l	1 H 2-OCH3	30.0	6.9	3.0	8.5	0.0	27.7
6		41.7	46.1	70.7	40.9	4.2	31.6
Chlorothalonil		100	99.9	100	100	99.1	95.8
Carbendazim		81.0	100	100	4.2	34.7	100
Fenamidone		97.8	96.4	93.5	57.1	79.8	71.9

Comparing 2a and 3a with 1a, it seems that the thiohydantoin ring was responsible for higher activity. Change from thione to methylthio made little contribution to the bioactivity against R. solani and Phytophthora capsici. Consequently, methylthio was replaced with phenylamino to obtain compound 4a, which exhibited lower activity than 3a against R. solani and much lower activity against P. capsici. Surprisingly, compound 4a was found to have excellent activity (94.9%) on S. scleotiorum, which is much higher than the commecialized carbendazim and nearly equal to chlorothalonil and fenamidone. These results indicated that the introduction of phenylamino at the 2-position of the imidazolinone changed the activity spectrum. Inspired by this outstanding result, attention was turned to prepartion and evaluation of more analogous of 4a by replacing substituents attached to the phenyl ring. The results indicated that with a strong electron-withdrawing group, such as trifluoromethyl (CF₃) at the 4-positon (4e), almost equal activity against S. scleotiorum was noted. The introduction of CH₃, F and OCH₃ to any position resulted in the remarkable decrease in fungicidal activity. The compounds with substituents of 2-OCH₃, 4-OCH₃, 3-CF₃ and 2-F on phenyl ring, however, exhibited better inhibition against R. solani, but still lower than three known products, which seemed that there was not much correlation between electronic effect and activity. Further optimization by replacing phenyl with benzyl led to much more decreased activities against all treated target phytopathgens.

As for R₁ groups at 4-position of butenolide, the results indicated that the thiohydantoin 2a and 2-methylthioimidazolinone 3a exhibited inhibition against all tested phytopathgens, especially against R. solani and P. capsici. In contrast, 2b and 3b showed a significant decrease in activity against all six phytopathgens, indicating that R₁ groups at 4-position of butenolide play a crucial role for regulating the bioactivity. This is probably due to steric hindrance of the phenyl group compared with methyl group. This conclusion was confirmed by comparison of the inhibition rates of 4a–4t and corresponding 5a–5l.

The results above indicated that the aniline moiety should be optimized around compounds 4a and 4e and R₁ prefers substituent with small size in the structure modification in the future. Based on the above results, the EC₅₀ values were determined for these compounds with more than 65% inhibition rates. The equations for linear relationships of the logarithmic values of inhibition rates and the logarithmic values of concentrations were obtained with good coefficent γ² as indicated in Table 2. The data in Table 2 indicated that 4e, 4i and 5g have EC₅₀ values less than 5.0 µM against S. scleotiorum and A. Solani, close or weaker than carbendazim and fenamidone, and the others have EC₅₀ values more than 5.0 µM against all four phytopathgens. Among these compounds, most compounds did not exhibit the inhibition of spore germination against S. scleotiorum, R. Solani and A. solani, while compounds 4d and 4g demonstrated a siginificant control of spore germination against B. cinerea with 98.0% and 97.8% inhibition rates at the concentration of 100 µg/mL, respectively. The inhibition of spore germination against B. cinerea for 4g was still observed even at a concentration of 10 µg/mL, as shown in Figure 1. The mode of action will be a topic of the future research. These results indicated that there is the possibility to improvement of fungicidal activities by modification of chemical structures.

Table 2. The EC₅₀ values of compounds 4 and 5 against different phytopathgens.

Compd.	Fungi	Equation	Coefficent γ2	EC50 (µM)
4a	S. scleotiorum	Y = 4.151X − 16.812	0.966	268.58
4e	S. scleotiorum	Y = 2.181X − 7.968	0.990	220.54
4g	S. scleotiorum	Y = 2.236X − 9.418	0.950	14.73
5g	S. scleotiorum	Y = 0.902X − 3.382	0.978	3.23
Carbendazim	S. scleotiorum	Y = 1.143X − 4.821	0.981	4.12
2a	R. solani	Y = 2.993X − 12.458	0.949	120.78
3a	R. solani	Y = 2.136X − 8.651	0.972	38.25
4a	R. solani	Y = 3.052X − 12.407	0.956	218.48
4d	R. solani	Y = 2.152X − 8.824	0.953	24.18
4g	R. solani	Y = 2.170X − 8.084	0.971	149.00
4i	R. solani	Y = 1.797X − 6.847	0.963	48.73
4j	R. solani	Y = 8.084X − 36.222	0.972	4425.75
4l	R. solani	Y = 3.608X − 15.344	0.981	146.93
4m	R. solani	Y = 2.80X − 12.685	0.953	6.07
4n	R. solani	Y = 1.440X − 5.298	0.962	21.68
4o	R. solani	Y = 3.995X − 17.315	0.985	122.76
4t	R. solani	Y = 2.538X − 11.106	0.950	10.38
4e	A. solani	Y = 1.283X − 5.263	0.981	4.14
4i	A. solani	Y = 1.459X − 6.242	0.997	3.27
6	A. solani	Y = 1.263X − 4.926	0.978	9.86
Fenamidone	A. solani	Y = 0.802X − 3.709	0.973	0.90
4d	B. cinerea	Y = 2.127X − 8.363	0.957	52.49
4g	B. cinerea	Y = 1.514X − 5.267	0.986	51.02
Fenamidone	B. cinerea	Y = 1.329X − 4.712	0.963	38.92

Table 2. The EC₅₀ values of compounds 4 and 5 against different phytopathgens.

Compd.	Fungi	Equation	Coefficent γ2	EC50 (µM)
4a	S. scleotiorum	Y = 4.151X − 16.812	0.966	268.58
4e	S. scleotiorum	Y = 2.181X − 7.968	0.990	220.54
4g	S. scleotiorum	Y = 2.236X − 9.418	0.950	14.73
5g	S. scleotiorum	Y = 0.902X − 3.382	0.978	3.23
Carbendazim	S. scleotiorum	Y = 1.143X − 4.821	0.981	4.12
2a	R. solani	Y = 2.993X − 12.458	0.949	120.78
3a	R. solani	Y = 2.136X − 8.651	0.972	38.25
4a	R. solani	Y = 3.052X − 12.407	0.956	218.48
4d	R. solani	Y = 2.152X − 8.824	0.953	24.18
4g	R. solani	Y = 2.170X − 8.084	0.971	149.00
4i	R. solani	Y = 1.797X − 6.847	0.963	48.73
4j	R. solani	Y = 8.084X − 36.222	0.972	4425.75
4l	R. solani	Y = 3.608X − 15.344	0.981	146.93
4m	R. solani	Y = 2.80X − 12.685	0.953	6.07
4n	R. solani	Y = 1.440X − 5.298	0.962	21.68
4o	R. solani	Y = 3.995X − 17.315	0.985	122.76
4t	R. solani	Y = 2.538X − 11.106	0.950	10.38
4e	A. solani	Y = 1.283X − 5.263	0.981	4.14
4i	A. solani	Y = 1.459X − 6.242	0.997	3.27
6	A. solani	Y = 1.263X − 4.926	0.978	9.86
Fenamidone	A. solani	Y = 0.802X − 3.709	0.973	0.90
4d	B. cinerea	Y = 2.127X − 8.363	0.957	52.49
4g	B. cinerea	Y = 1.514X − 5.267	0.986	51.02
Fenamidone	B. cinerea	Y = 1.329X − 4.712	0.963	38.92

Figure 1. Inhibition of compound 4g against spore germination of B. cinerea. The pictures were taken from the fungi growing in the glass plates with a microscope with Scopephoto software (version 3.6, Photoscope Inc., Arlington, VA, USA, 2009) and magnified by 10 × 10 times without stain. The fungi were grown in clear water (CK) or sample solution plus water (treated) at 25 ± 0.5 °C for 24 h. Color is from background.

Figure 1. Inhibition of compound 4g against spore germination of B. cinerea. The pictures were taken from the fungi growing in the glass plates with a microscope with Scopephoto software (version 3.6, Photoscope Inc., Arlington, VA, USA, 2009) and magnified by 10 × 10 times without stain. The fungi were grown in clear water (CK) or sample solution plus water (treated) at 25 ± 0.5 °C for 24 h. Color is from background.

3. Experimental Section

3.1. General Information

All reactions were performed with magnetic stirring. Unless otherwise stated, all reagents were purchased from commercial suppliers and used without further purification. Organic solutions were concentrated under reduced pressure using a rotary evaporator. Melting points were measured on a Yanagimoto apparatus (Yanagimoto MFG Co., Kyoto, Japan) and are uncorrected. ¹H-NMR spectra were obtained on Bruker DPX 300 spectrometer (Bruker Biospin Co., Stuttgart, Germany) with CDCl₃ or DMSO-d₆ as a solvent and TMS as an internal standard. High resolution mass spectral analysis was performed on a LTQ Orbitrap instrument (ThermoFisher scientific Inc., Waltham, MA, USA).

3.2. Synthesis

3.2.1. Synthesis of 3-Acetyl-4-methyl(phenyl)-5,5-dimethylbutenolide (1a and 1b)

The synthesis of the intermediates 1a and 1b were carried out according to the literature protocols and their spectral data were identical with those in the references [18,20]. Compound 1a, colorless solid, yield 80%, m.p. 50–51 °C, ¹H-NMR (CDCl₃, 300 MHz) δ: 2.47 (s, 3H), 2.28 (s, 3H), 1.42 (s, 6H). Compound 1b, colorless solid, yield 84%, m.p. 76–77 °C, ¹H-NMR (CDCl₃, 300 MHz) δ: 7.48–7.46 (m, 3H), 7.25–7.22 (m, 2H), 2.39 (s, 3H), 1.56 (s, 3H).

3.2.2. Synthesis of 4-Methyl(phenyl)-5,5-dimethyl-3-ethylidenebutenolide-5-thiohydantoin (2a and 2b)

The synthesis of the intermediates 2a and 2b were performed following the processes in our previous paper [10,11] by reaction of 1a and 1b with thiohydantoin. Compound 2a, yellow solid, yield 63%, m.p. 218–220 °C, ¹H-NMR (DMSO-d₆, 300 MHz) δ: 12.12 (s, 1H), 11.99 (s, 1H), 2.03 (s, 3H), 1.87 (s, 3H), 1.42 (s, 6H); HR-ESI-MS m/z: calcd for C₁₂H₁₅N₂O₃S [M + H]⁺ 267.0798; found, 267.0798. Compound 2b, yellow solid, yield 67%, m.p. 223–225 °C, ¹H-NMR (DMSO-d₆, 300 MHz) δ: 12.20 (s, 1H), 11.99 (s,1H), 7.51–7.45 (m, 3H), 7.35–7.30 (m, 2H), 1.80 (s, 3H), 1.63 (s, 3H), 1.46 (s, 3H); HR-ESI-MS m/z: calcd for C₁₇H₁₇N₂O₃S [M + H]⁺ 329.0954; found, 329.0944.

3.2.3. Synthesis of 4-Methyl(phenyl)-5,5-dimethyl-3-ethylidenebutenolide-5-(2-methylthioimidazo-4-one) (3a and 3b)

The synthesis of the intermediates 3a and 3b were performed according to the methods in our previous paper [10,11] by reaction of 2a and 2b with methyl iodide. Compound 3a, yellow solid, yield 90%, m.p. 168–170 °C, ¹H-NMR (CDCl₃, 300 MHz) δ: 10.23 (s, 1H), 2.61 (s, 3H), 2.37(s, 3H), 1.90 (s, 3H), 1.54 (s, 3H), 1.50 (s, 3H); HR-ESI-MS m/z: calcd for C₁₃H₁₇N₂O₃S [M + H]⁺ 281.0954; found, 281.0955. Compound 3b, yellow solid, yield 79%, m.p. 204–206 °C, ¹H-NMR (CDCl₃, 300 MHz) δ: 10.16 (s, 1H), 7.42–7.37 (m, 3H), 7.27–7.23 (m, 2H), 2.57 (s, 3H), 2.08 (s, 3H), 1.68 (s, 3H), 1.59 (s, 3H); HR-ESI-MS m/z: calcd for C₁₇H₁₇N₂O₃S [M + H]⁺ 343.1111; found, 343.1102.

3.2.4. General Procedure for the Synthesis of Compounds 4 and 5

To a stirred solution of 1.0 mmol 3a, or 3b in 20 mL of acetic acid or oxalic acid and dioxane, the amines were added at ambient temperature and heated to reflux for 10–24 h. The reactions were monitored by TLC. After completion, the solvents were removed under reduced pressure. The residues were purified by silica gel chromatography using CH₂Cl₂/acetone as eluents to afford compounds 4 and 5.

5-(4,5,5-Trimethyl-3-ethylidenebutenolide)-2-phenylaminoimidazolinone 4a, white solid, yield 65%, m.p. 203–206 °C, ¹H-NMR (DMSO-d₆, 300 MHz) δ: 10.44–9.68 (m, 2H), 7.71–6.99 (m, 5H), 2.12 (s, 3H), 1.86 (s, 3H), 1.43 (s, 6H); HR-ESI-MS m/z: calcd for C₁₈H₂₀N₃O₃ [M + H]⁺ 326.1499; found, 326.1499.

5-(4,5,5-Trimethyl-3-ethylidenebutenolide)-2-(4-methylphenyl)aminoimidazolinone 4b, white solid, yield 83%, m.p. 208–210 °C, ¹H-NMR (DMSO-d₆, 300 MHz) δ: 10.40–9.52 (m, 2H), 7.59–7.12 (m, 4H), 2.26 (s, 3H), 2.09 (s, 3H), 1.85 (s, 3H), 1.43 (s, 6H); HR-ESI-MS m/z: calcd for C₁₉H₂₂N₃O₃ [M + H]⁺ 340.1656; found, 340.1655.

5-(4,5,5-Trimethyl-3-ethylidenebutenolide)-2-(4-flurophenyl)aminoimidazolinone 4c, white solid, yield 56%, m.p. 194–196 °C, ¹H-NMR (DMSO-d₆, 300 MHz) δ: 10.53–9.66 (m, 2H), 7.71–7.14 (m, 4H), 2.10 (s, 3H), 1.85 (s, 3H), 1.43 (s, 6H); HR-ESI-MS m/z: calcd for C₁₈H₁₉FN₃O₃ [M + H]⁺ 344.1405; found, 344.1405.

5-(4,5,5-Trimethyl-3-ethylidenebutenolide)-2-(4-methoxyphenyl)aminoimidazolinone 4d, yellow solid, yield 87%, m.p. 151–154 °C, ¹H-NMR (DMSO-d₆, 300 MHz) δ: 10.60–9.61 (m, 2H), 7.54 (d, J = 7.5 Hz, 2H), 6.88 (d, J = 7.5 Hz, 2H), 3.74 (s, 3H), 2.31 (s, 3H), 1.91 (s, 3H), 1.44 (s, 6H); HR-ESI-MS m/z: calcd for C₁₉H₂₂N₃O₄ [M + H]⁺ 356.1605; found, 356.1605.

5-(4,5,5-Trimethyl-3-ethylidenebutenolide)-2-(4-trifluromethylphenyl)aminoimidazolinone 4e, yellow solid, yield 59%, m.p. 203–206 °C, ¹H-NMR (DMSO-d₆, 300 MHz) δ: 10.73–10.06 (m, 2H), 8.00–7.66 (m, 4H), 2.12 (s, 3H), 1.86 (s, 3H), 1.43 (s, 6H); HR-ESI-MS m/z: calcd for C₁₉H₁₉F₃N₃O₃ [M + H]⁺ 394.1373; found, 394.1374.

N-Methyl-5-(4,5,5-trimethyl-3-ethylidenebutenolide)-2-phenylaminoimidazolinone 4f, white solid, yield 56%, m.p. 195–198 °C, ¹H-NMR (DMSO-d₆, 300 MHz) δ: 7.54–7.44 (m, 5H), 3.61 (s, 3H), 2.32 (s, 3H), 1.90 (s, 3H), 1.41 (s, 6H); HR-ESI-MS m/z: calcd for C₁₉H₂₂N₃O₃ [M + H]⁺ 340.1656; found, 340.1655.

5-(4,5,5-Trimethyl-3-ethylidenebutenolide)-2-(3-trifluromethylphenyl)aminoimidazolinone 4g, yellow solid, yield 66%, m.p. 148–151 °C, ¹H-NMR (DMSO-d₆, 300 MHz) δ: 10.70–9.82 (m, 2H), 8.20–7.30 (m, 4H), 2.33 (s, 3H), 1.86 (s, 3H), 1.47 (s, 6H); HR-ESI-MS m/z: calcd for C₁₉H₁₉F₃N₃O₃ [M + H]⁺ 394.1373; found, 394.1374.

5-(4,5,5-Trimethyl-3-ethylidenebutenolide)-2-(2-methylphenyl)aminoimidazolinone 4h, white solid, yield 89%, m.p. 184–187 °C, ¹H-NMR (DMSO-d₆, 300 MHz) δ: 10.38–9.00 (m, 2H), 7.20–6.97 (m, 4H), 2.26 (s, 3H), 2.09 (s, 3H), 1.84 (s, 3H), 1.42 (s, 6H); HR-ESI-MS m/z: calcd for C₁₉H₂₂N₃O₃ [M + H]⁺ 340.1656; found, 340.1654.

5-(4,5,5-Trimethyl-3-ethylidenebutenolide)-2-(2-flurophenyl)aminoimidazolinone 4i, white solid, yield 74%, m.p. 166–169 °C, ¹H-NMR (DMSO-d₆, 300 MHz) δ: 10.54–9.87 (m, 2H), 7.68–7.21 (m, 4H), 2.32 (s, 3H), 2.00 (s, 3H), 1.48 (s, 6H); HR-ESI-MS m/z: calcd for C₁₈H₁₉FN₃O₃ [M + H]⁺ 344.1405; found, 344.1406.

5-(4,5,5-Trimethyl-3-ethylidenebutenolide)-2-(2-methoxyphenyl)aminoimidazolinone 4j, yellow solid, yield 58%, m.p. 154–156 °C, ¹H-NMR (DMSO-d₆, 300 MHz) δ: 10.41–9.65 (m, 2H), 7.07–6.90 (m, 4H), 3.88 (s, 3H), 2.09 (s, 3H), 1.92 (s, 3H), 1.50 (s, 6H); HR-ESI-MS m/z: calcd for C₁₉H₂₂N₃O₄ [M + H]⁺ 356.1605; found, 356.1606.

5-(4,5,5-Trimethyl-3-ethylidenebutenolide)-2-(2-chlororophenyl)aminoimidazolinone 4k, white solid, yield 23%, m.p.165–168 °C, ¹H-NMR (DMSO-d₆, 300 MHz) δ: 10.41–9.92 (m, 2H), 7.44–7.00 (m, 4H), 2.09 (s, 3H), 1.85 (s, 3H), 1.41 (s, 6H); HR-ESI-MS m/z: calcd for C₁₈H₁₉C_lN₃O₃ [M + H]⁺ 360.1110; found, 360.1110.

5-(4,5,5-Trimethyl-3-ethylidenebutenolide)-2-(2,6-dimethylphenyl)aminoimidazolinone 4l, white solid, yield 76%, m.p. 240–243 °C, ¹H-NMR (DMSO-d₆, 300 MHz) δ: 10.41–9.19 (m, 2H), 7.12–6.95 (m, 3H), 2.11 (s, 6H), 1.84 (s, 3H), 1.44 (s, 6H); HR-ESI-MS m/z: calcd for C₁₉H₂₂N₃O₃ [M + H]⁺ 340.1656; found, 340.1654.

5-(4,5,5-Trimethyl-3-ethylidenebutenolide)-2-benzylaminoimidazolinone 4m, white solid, yield 30%, m.p. 168–170 °C, ¹H-NMR (DMSO-d₆, 300 MHz) δ: 10.57–9.81 (m, 2H), 7.34–7.25 (m, 5H), 4.51 (brs, 2H), 1.99 (s, 3H), 1.80 (s, 3H), 1.39 (s, 6H); HR-ESI-MS m/z: calcd for C₁₉H₂₂N₃O₃ [M + H]⁺ 340.1656; found, 340.1655.

5-(4,5,5-Trimethyl-3-ethylidenebutenolide)-2-(4-methoxybenzyl)aminoimidazolinone 4n, white solid, yield 56%, m.p. 145–148 °C, ¹H-NMR (DMSO-d₆, 300 MHz) δ: 10.57–9.81 (m, 2H), 7.34–7.25 (m, 5H), 4.51 (brs, 2H), 3.73 (s, 3H), 1.99 (s, 3H), 1.80 (s, 3H), 1.39 (s, 6H); HR-ESI-MS m/z: calcd for C₂₀H₂₄N₃O₄ [M + H]⁺ 370.1761; found, 370.1761.

5-(4,5,5-Trimethyl-3-ethylidenebutenolide)-2-(4-chlrobenzyl)aminoimidazolinone 4o, white solid, yield 54%, m.p. 147–150 °C, ¹H-NMR (DMSO-d₆, 300 MHz) δ: 10.79–9.07 (m, 2H), 7.43–7.34 (m, 4H), 4.48 (brs, 2H), 1.98 (s, 3H), 1.81 (s, 3H), 1.40 (s, 6H); HR-ESI-MS m/z: calcd for C₁₉H₂₁C_lN₃O₃ [M + H]⁺ 374.1266; found, 374.1267.

5-(4,5,5-Trimethyl-3-ethylidenebutenolide)-2-(4-flurobenzyl)aminoimidazolinone 4p, yellow solid, yield 59%, m.p. 140–143 °C, ¹H-NMR (DMSO-d₆, 300 MHz) δ: 10.57–8.32 (m, 2H), 7.62–6.77 (m, 4H), 4.47 (brs, 2H), 1.99 (s, 3H), 1.81 (s, 3H), 1.40 (s, 6H); HR-ESI-MS m/z: calcd for C₁₉H₂₁FN₃O₃ [M + H]⁺ 358.1562; found, 358.1561.

5-(4,5,5-Trimethyl-3-ethylidenebutenolide)-2-(3-trifluromethylbenzyl)aminoimidazolinone 4q, yellow solid, yield 48%, m.p. 127–130 °C, ¹H-NMR (DMSO-d₆, 300 MHz) δ: 10.84–9.15 (m, 2H), 7.72–7.48 (m, 4H), 4.58 (brs, 2H), 1.97 (s, 3H), 1.81 (s, 3H), 1.44 (s, 6H); HR-ESI-MS m/z: calcd for C₂₀H₂₁F₃N₃O₃ [M + H]⁺ 408.1530; found, 408.1528.

5-(4,5,5-Trimethyl-3-ethylidenebutenolide)-2-(2-flurobenzyl)aminoimidazolinone 4r, yellow solid, yield 81%, m.p. 227–230 °C, ¹H-NMR (DMSO-d₆, 300 MHz) δ: 10.51–9.84 (m, 2H), 7.45–7.18 (m, 4H), 4.52 (brs, 2H), 1.99 (s, 3H), 1.82 (s, 3H), 1.41 (s, 6H); HR-ESI-MS m/z: calcd for C₁₉H₂₁FN₃O₃ [M + H]⁺ 358.1562; found, 358.1562.

5-(4,5,5-Trimethyl-3-ethylidenebutenolide)-2-(2-chlorobenzyl)aminoimidazolinone 4s, white solid, yield 70%, m.p. 164–166 °C, ¹H-NMR (DMSO-d₆, 300 MHz) δ: 10.41–9.92 (m, 2H), 7.53–7.38 (m, 4H), 4.71 (brs, 2H), 2.32 (s, 3H), 2.01 (s, 3H), 1.44 (s, 6H); HR-ESI-MS m/z: calcd for C₁₉H₂₁C_lN₃O₃ [M + H]⁺ 374.1266; found, 374.1267.

5-(4,5,5-Trimethyl-3-ethylidenebutenolide)-2-(2-methoxybenzyl)aminoimidazolinone 4t, yellow solid, yield 34%, m.p. 120–123 °C, ¹H-NMR (DMSO-d₆, 300 MHz) δ: 10.40–8.83 (m, 2H), 7.30–6.91 (m, 4H), 4.46 (brs, 2H), 3.83 (s, 3H), 1.96 (s, 3H), 1.81 (s, 3H), 1.44 (s, 6H); HR-ESI-MS m/z: calcd for C₂₀H₂₄N₃O₄ [M + H]⁺ 370.1761; found, 370.1758.

5-(4-Phenyl-5,5-dimethyl-3-ethylidenebutenolide)-2-phenylaminoimidazolinone 5a, yellow solid, yield 44%, m.p. 167–170 °C, ¹H-NMR (DMSO-d₆, 300 MHz) δ: 10.52–9.34 (m, 2H), 7.68–6.99 (m, 10H), 1.88 (s, 3H), 1.69 (s, 3H), 1.48 (s, 3H); HR-ESI-MS m/z: calcd for C₂₃H₂₂N₃O₃ [M + H]⁺ 388.1656; found, 388.1644.

5-(4-Phenyl-5,5-dimethyl-3-ethylidenebutenolide)-2-(4-methylphenyl)aminoimidazolinone 5b, yellow solid, yield 60%, m.p. 185–188 °C, ¹H-NMR (DMSO-d₆, 300 MHz) δ: 10.47–9.32 (m, 2H), 7.47–7.04 (m, 9H), 2.25 (s, 3H), 1.87 (s, 3H), 1.61 (s, 3H), 1.47 (s, 3H); HR-ESI-MS m/z: calcd for C₂₄H₂₄N₃O₃ [M + H]⁺ 402.1812; found, 402.1801.

5-(4-Phenyl-5,5-dimethyl-3-ethylidenebutenolide)-2-(4-flurophenyl)aminoimidazolinone 5c, yellow solid, yield 47%, m.p. 164–167 °C, ¹H-NMR (DMSO-d₆, 300 MHz) δ: 10.61–9.37 (m, 2H), 7.71–7.08 (m, 9H), 1.87 (s, 3H), 1.61 (s, 3H), 1.48 (s, 3H); HR-ESI-MS m/z: calcd for C₂₃H₂₁FN₃O₃ [M + H]⁺ 406.1561; found, 406.1549.

5-(4-Phenyl-5,5-dimethyl-3-ethylidenebutenolide)-2-(4-methoxyphenyl)aminoimidazolinone 5d, yellow solid, yield 82%, m.p. 217–219 °C, ¹H-NMR (DMSO-d₆, 300 MHz) δ: 10.44–9.21 (m, 2H), 7.58–6.85 (m, 9H), 3.74 (s, 3H), 1.85 (s, 3H), 1.61 (s, 3H), 1.47 (s, 3H); HR-ESI-MS m/z: calcd for C₂₄H₂₄N₃O₄ [M + H]⁺ 418.1761; found, 418.1749.

5-(4-Phenyl-5,5-dimethyl-3-ethylidenebutenolide)-2-(4-trifluromethylphenyl)aminoimidazolinone 5e, white solid, yield 86%, m.p. 190–193 °C, ¹H-NMR (DMSO-d₆, 300 MHz) δ: 10.45–9.35 (m, 2H), 7.97–7.30 (m, 9H), 1.89 (s, 3H), 1.62 (s, 3H), 1.48 (s, 3H); HR-ESI-MS m/z: calcd for C₂₄H₂₁F₃N₃O₃ [M + H]⁺ 456.1530; found, 456.1518.

5-(4-Phenyl-5,5-dimethyl-3-ethylidenebutenolide)-2-(3-trifluromethylphenyl)aminoimidazolinone 5f, white solid, yield 77%, m.p. 169–172 °C, ¹H-NMR (DMSO-d₆, 300 MHz) δ: 10.77–9.57 (m, 2H), 8.23–7.32 (m, 9H), 1.90 (s, 3H), 1.59 (s, 3H), 1.49 (s, 3H); HR-ESI-MS m/z: calcd for C₂₄H₂₁F₃N₃O₃ [M + H]⁺ 456.1530; found, 456.1517.

5-(4-Phenyl-5,5-dimethyl-3-ethylidenebutenolide)-2-(2-flurophenyl)aminoimidazolinone 5g, yellow solid, yield 32%, m.p. 158–161 °C, ¹H-NMR (DMSO-d₆, 300 MHz) δ: 10.51–9.22 (m, 2H), 7.62–7.04 (m, 9H), 1.80 (s, 3H), 1.61 (s, 3H), 1.45 (s, 3H); HR-ESI-MS m/z: calcd for C₂₃H₂₁FN₃O₃ [M + H]⁺ 406.1561; found, 406.1549.

5-(4-Phenyl-5,5-dimethyl-3-ethylidenebutenolide)-2-(2-chlorophenyl)aminoimidazolinone 5h, yellow solid, yield 32%, m.p. 158–161 °C, ¹H-NMR (DMSO-d₆, 300 MHz) δ: 10.73–9.48 (m, 2H), 7.50–7.00 (m, 9H), 1.91 (s, 3H), 1.60 (s, 3H), 1.44 (s, 3H); HR-ESI-MS m/z: calcd for C₂₃H₂₁ClN₃O₃ [M + H]⁺ 406.1561; found, 406.1549.

5-(4-Phenyl-5,5-dimethyl-3-ethylidenebutenolide)-2-(2-methoxyphenyl)aminoimidazolinone 5i, yellow solid, yield 84%, m.p. 236–239 °C, ¹H-NMR (DMSO-d₆, 300 MHz) δ: 10.18–9.41 (m, 2H), 7.46–6.94 (m, 9H), 3.88 (s, 3H), 1.89 (s, 3H), 1.61 (s, 3H), 1.47 (s, 3H); HR-ESI-MS m/z: calcd for C₂₄H₂₄N₃O₄ [M + H]⁺ 418.1761; found, 418.1748.

5-(4-Phenyl-5,5-dimethyl-3-ethylidenebutenolide)-2-benzylaminoimidazolinone 5j, white solid, yield 55%, m.p. 128–131 °C, ¹H-NMR (DMSO-d₆, 300 MHz) δ: 10.60–9.33 (m, 2H), 7.45–7.27 (m, 10H), 4.51 (brs, 2H), 1.80 (s, 3H), 1.59 (s, 3H), 1.44 (s, 3H); HR-ESI-MS m/z: calcd for C₂₄H₂₄N₃O₃ [M + H]⁺ 402.1812; found, 402.1801.

5-(4-Phenyl-5,5-dimethyl-3-ethylidenebutenolide)-2-(4-chlorobenzyl)aminoimidazolinone 5k, yellow solid, yield 67%, m.p. 140–143 °C, ¹H-NMR (DMSO-d₆, 300 MHz) δ: 10.67–9.40 (m, 2H), 7.46–7.17 (m, 9H), 4.46 (brs, 2H), 1.74 (s, 3H), 1.59 (s, 3H), 1.44 (s, 3H); HR-ESI-MS m/z: calcd for C₂₄H₂₃ClN₃O₃ [M + H]⁺ 436.1422; found, 436.1412.

5-(4-Phenyl-5,5-dimethyl-3-ethylidenebutenolide)-2-(2-methoxybenzyl)aminoimidazolinone 5l, yellow solid, yield 67%, m.p. 116–119 °C, ¹H-NMR (DMSO-d₆, 300 MHz) δ: 10.18–9.41 (m, 2H), 7.46–6.94 (m, 9H), 3.88 (s, 3H), 1.89 (s, 3H), 1.59 (s, 3H), 1.44 (s, 3H); HR-ESI-MS m/z: calcd for C₂₅H₂₆N₃O₄ [M + H]⁺ 432.1918; found, 432.1916.

4,5,5-Trimethyl-3-ethylidenebutenolide-5-hydantoin 6, white solid, yields 10%–40% isolated from the mixtures of preparing reactions 4a to 4t as byproducts, m.p. 230–232 °C, ¹H-NMR (DMSO-d₆, 300 MHz) δ: 10.98 (s, 1H), 10.26 (s, 1H), 1.90 (s, 3H), 1.85 (s, 3H), 1.41 (s, 6H); ¹³C-NMR (DMSO-d₆, 75 MHz) δ: 170.02, 167.04, 162.88, 154.54, 19.21, 124.00, 117.70, 85.83, 24.19, 24.09, 17.93, 11.73; HR-ESI-MS m/z: calcd for C₁₂H₁₅N₂O₄ [M + H]⁺ 251.1026; found, 251.1026.

3.3. Bioassay of Fungicidal Activity

The preliminary fungicidal activities of compounds 4–6 against S. scleotiorum, R. solani, P. capsici, A. solani, B. cinerea and F. graminearum were evaluated using methods in the references [21,22,23] by the mycelium growth rate and spore germination tests [24,25]. The cultures were incubated at 25 ± 0.5 °C. Three replicates were performed and the mean measurements were calculated from the three replicates. The EC₅₀ values were determined from the inhibition rates of five different concentrations based on the statistics method for the compounds which had more than 65% inhibition rates. Chlorothalonil, carbendazim and fenamidone were used as positive controls in the mycelium growth rate test, while pure water was used as blank control in the spore germination test.

4. Conclusions

The novel 5-(5,5-dimethylbutenolide-3-ethylidene)-2-aminoimidazolinone derivatives were designed and synthesized in moderate to excellent yields in four steps by α-hydroxyketone and diketene as starting materials. The products were characterized by HR-ESI-MS and ¹H-NMR. The preliminary bioassay showed that some of these compounds, such as 4a, 4e and 5g exhibit 94.9%, 92.8% and 81.4% inhibition rates against S. scleotiorum, respectively. The EC₅₀ values of compounds 4e and 4i were 4.14 and 3.27 µM against A. Solani, while 5g had EC₅₀ value of 3.23 µM against S. scleotiorum. Compounds 4d and 4g had 98.0% and 97.8% inhibition rates of spore germination against B. cinerea at the concentration of 100 µg/mL, respectively. Further syntheses and structure optimization studies are in progress in our laboratory.
