Micromachines, Volume 13, Issue 11 (November 2022) – 237 articles

Cover Story (view full-size image): Microfluidic concentration gradient generators have been widely applied in chemical and biological fields. In this work, we present a microfluidic concentration gradient generator, with its corresponding manipulation process, to generate an arbitrary concentration gradient. Machine learning techniques and interpolation algorithms were implemented to help researchers instantly analyze the current concentration profile of the gradient generator with different inlet configurations. Our method shows a potential application of the design automation and computer-aided design of microfluidics by leveraging both artificial neural networks and computer science algorithms. View this paper
  • Issues are regarded as officially published after their release is announced to the table of contents alert mailing list.
  • You may sign up for e-mail alerts to receive table of contents of newly released issues.
  • PDF is the official format for papers published in both, html and pdf forms. To view the papers in pdf format, click on the "PDF Full-text" link, and use the free Adobe Reader to open them.
Order results
Result details
Section
Select all
Export citation of selected articles as:
18 pages, 6511 KiB
Article
Design and Feasibility Study of MRG–Based Variable Stiffness Soft Robot
by Luojing Huang, Hongsheng Hu and Qing Ouyang
Micromachines 2022, 13(11), 2036; https://doi.org/10.3390/mi13112036 - 21 Nov 2022
Cited by 10 | Viewed by 2136
Abstract
The conventional pneumatic soft robot has the problem of insufficient stiffness, while in the magnetorheological soft robot, the magnetic field provided by electromagnet has the disadvantage of oversized structure and poor flexibility. This paper presents a variable stiffness pneumatic soft robot based on [...] Read more.
The conventional pneumatic soft robot has the problem of insufficient stiffness, while in the magnetorheological soft robot, the magnetic field provided by electromagnet has the disadvantage of oversized structure and poor flexibility. This paper presents a variable stiffness pneumatic soft robot based on magnetorheological grease (MRG) to solve these problems. Its three soft fingers cooperate with the adjustable gripper to adjust the gripping range for the robot hand, and it is used to provide gripping driving force through the bending drive. The MRG layer is designed on the gripping surface to provide adaptivity and rigid support for the gripped objects. A magnetic-air structure consisting of a Halbach array and Halbach array actuator is designed inside the soft fingers to provide a flexible magnetic field for the MRG layer. Theoretical and simulation analysis is carried out, and the results show that the state of the MRG changes and the stiffness of the clamping surface changes under the working pressure of 30 kPa. Finally, the experiment further proves the variable and high adaptivity of the surface stiffness of the gripping surface to reduce the damage to the gripped objects. Full article
Show Figures

Figure 1

17 pages, 3055 KiB
Article
Thermally Driven Continuous Rolling of a Thick-Walled Cylindrical Rod
by Fayang Zhu, Changshen Du, Yuntong Dai and Kai Li
Micromachines 2022, 13(11), 2035; https://doi.org/10.3390/mi13112035 - 21 Nov 2022
Viewed by 1618
Abstract
Self-sustained motion can take advantage of direct energy extraction from a steady external environment to maintain its own motion, and has potential applications in energy harvesting, robotic motion, and transportation. Recent experiments have found that a thermally responsive rod can perform self-sustained rolling [...] Read more.
Self-sustained motion can take advantage of direct energy extraction from a steady external environment to maintain its own motion, and has potential applications in energy harvesting, robotic motion, and transportation. Recent experiments have found that a thermally responsive rod can perform self-sustained rolling on a flat hot plate with an angular velocity determined by the competition between the thermal driving moment and the friction moment. A rod with a hollow cross section tends to greatly reduce the frictional resistance, while promising improvements in thermal conversion efficiency. In this paper, through deriving the equilibrium equations for steady-state self-sustained rolling of the thick-walled cylindrical rod, estimating the temperature field on the rod cross-section, and solving the analytical solution of the thermally induced driving moment, the dynamic behavior of the thermally driven self-sustained rolling of the thick-walled cylindrical rod is theoretically investigated. In addition, we investigate in detail the effects of radius ratio, heat transfer coefficient, heat flux, contact angle, thermal expansion coefficient, and sliding friction coefficient on the angular velocity of the self-sustained rolling of the thick-walled cylindrical rod to obtain the optimal ratio of internal and external radius. The results are instructive for the application of thick-walled cylindrical rods in the fields of waste heat harvesters and soft robotics. Full article
(This article belongs to the Special Issue Micro/Nano Resonators, Actuators, and Their Applications)
Show Figures

Figure 1

9 pages, 2975 KiB
Article
Design, Fabrication and Measurement of Full-Color Reflective Electrowetting Displays
by Guisong Yang, Benyou Wang, Zhiqiang Chang, Qing Liu and Linwei Liu
Micromachines 2022, 13(11), 2034; https://doi.org/10.3390/mi13112034 - 21 Nov 2022
Cited by 5 | Viewed by 1756
Abstract
We designed, fabricated and measured full-color, reflective electrowetting displays (EWDs). The display system is composed of three-layer cyan, magenta and yellow EWD elements fabricated with standard photolithographic techniques. The EWDs were driven successfully by the proposed control system and the measurement results show [...] Read more.
We designed, fabricated and measured full-color, reflective electrowetting displays (EWDs). The display system is composed of three-layer cyan, magenta and yellow EWD elements fabricated with standard photolithographic techniques. The EWDs were driven successfully by the proposed control system and the measurement results show that the electro-optical performance was improved. The aperture ratio of the EWD element can be tuned from 0 to ∼80% as the applied voltage is changed from 0 to 30 V. The response time and the color gamut were measured to be ∼18 ms and ∼58% NTSC, respectively. This paper makes it possible for large numbers of reflective full-color EWDs to be fabricated directly, with advantages of saving power significantly by 85% and no eye irritation compared with LED displays. Full article
(This article belongs to the Special Issue Micro/Nano-Structure Based Optoelectronics and Photonics Devices)
Show Figures

Figure 1

16 pages, 4503 KiB
Article
Kinetic Model and Experiment for Self-Ignition of Triethylaluminum and Triethylborane Droplets in Air
by Sergey M. Frolov, Valentin Y. Basevich, Andrey A. Belyaev, Igor O. Shamshin, Viktor S. Aksenov, Fedor S. Frolov, Pavel A. Storozhenko and Shirin L. Guseinov
Micromachines 2022, 13(11), 2033; https://doi.org/10.3390/mi13112033 - 21 Nov 2022
Cited by 2 | Viewed by 2223
Abstract
Triethylaluminum Al(C2H5)3, TEA, and triethylborane, B(C2H5)3, TEB, are transparent, colorless, pyrophoric liquids with boiling points of approximately 190 °C and 95 °C, respectively. Upon contact with ambient air, TEA, TEB, as [...] Read more.
Triethylaluminum Al(C2H5)3, TEA, and triethylborane, B(C2H5)3, TEB, are transparent, colorless, pyrophoric liquids with boiling points of approximately 190 °C and 95 °C, respectively. Upon contact with ambient air, TEA, TEB, as well as their mixtures and solutions, in hydrocarbon solvents, ignite. They can also violently react with water. TEA and TEB can be used as hypergolic rocket propellants and incendiary compositions. In this manuscript, a novel scheme of the heterogeneous interaction of gaseous oxygen with liquid TEA/TEB microdroplets accompanied by the release of light hydrocarbon radicals into the gas phase is used for calculating the self-ignition of a spatially homogeneous mixture of fuel microdroplets in ambient air at normal pressure and temperature (NPT) conditions. In the primary initiation step, TEA and TEB react with oxygen, producing an ethyl radical, which can initiate an autoxidation chain. The ignition delay is shown to decrease with the decrease in the droplet size. Preliminary experiments on the self-ignition of pulsed and continuous TEA–TEB sprays in ambient air at NPT conditions are used for estimating the Arrhenius parameters of the rate-limiting reaction. Experiments confirm that the self-ignition delay of TEA–TEB sprays decreases with the injection pressure and provide the data for estimating the activation energy of the rate-limiting reaction, which appears to be close to 2 kcal/mol. Full article
(This article belongs to the Special Issue Droplet-Based Microfluidics: Design, Fabrication and Applications)
Show Figures

Figure 1

12 pages, 3511 KiB
Article
Characterization of a Dual Nonlinear Helmholtz Resonator
by Maher O. Al-Turk, Sajid Ali and Muhammad A. Hawwa
Micromachines 2022, 13(11), 2032; https://doi.org/10.3390/mi13112032 - 20 Nov 2022
Viewed by 2061
Abstract
Resonant elements can generate small amounts of energy that make them pertinent for feeding miniaturized accelerometers with the energy needed. Suitable oscillator candidates are Helmholtz resonators, which have been, for a long time, analyzed and designed within the context of linear vibration. This [...] Read more.
Resonant elements can generate small amounts of energy that make them pertinent for feeding miniaturized accelerometers with the energy needed. Suitable oscillator candidates are Helmholtz resonators, which have been, for a long time, analyzed and designed within the context of linear vibration. This study focuses on extracting nonlinear characteristics of a dual Helmholtz resonator (HR), with a neck-cavity–neck-cavity configuration, mounted on an acoustic waveguide with harmonically oscillating pressure. The mathematical model used for describing the resonator embraces inherent nonlinear air stiffness and the damping nonlinearity of hydrodynamic origin. Numerical solutions for the resonator’s nonlinear oscillations are obtained. Bifurcation diagrams are produced, indicating that the dual HR behaves in a deterministic fashion within the engineering practical limits. Phase portraits are drawn for the system, showing a quasi-periodic motion. Frequency response curves (FRC) are found to shift to the left at the lower resonant frequency indicating a softening behavior. FRC keep generally symmetric curves at the higher resonant frequency indicating a mostly linear behavior. Full article
(This article belongs to the Special Issue MEMS Accelerometers: Design, Applications and Characterization)
Show Figures

Figure 1

12 pages, 4190 KiB
Article
Implementation of the Haptic Tele-Weight Device Using a 10 MHz Smart Torch VLC Link
by Aqeel Farooq and Xiping Wu
Micromachines 2022, 13(11), 2031; https://doi.org/10.3390/mi13112031 - 20 Nov 2022
Viewed by 1997
Abstract
Considering the prerequisite need for a protected e-commerce platform, absence of haptic interaction in head-mounted displays (HMD), and exploitation of faster communication technology, this research work aims to present an amended version of the tele-weight device that utilizes the 6G visible light communication [...] Read more.
Considering the prerequisite need for a protected e-commerce platform, absence of haptic interaction in head-mounted displays (HMD), and exploitation of faster communication technology, this research work aims to present an amended version of the tele-weight device that utilizes the 6G visible light communication (VLC) technology, is faster in performance, and deals with a heavier article. The enhanced version of the device is to be called the ‘VLC tele-weight device’ and the aim for the VLC tele-weight device is to get it affixed over the headset which will allow the user to have the weight-based sensation of the product ordered on the virtual store. The proposed device sending end and receiving end part performs communication over the VLC link. Furthermore, Arduino Nano is used as the microcontroller (MCU) in the project. Sending end circuitry measures the weight using the load cell and HX711 amplifier combination and transmits it via the connected LED. The pre-equalizer circuit is connected between the LED and sending end part to improve the bandwidth. On the receiver side, the post-equalizer circuit improves the shape of the received pulse. The received weight value is then displayed using the motor-gear combination. The sending end device is to be sited at the virtual store, while the receiving end is planned to be positioned over the VR headset. The performance of the device was measured by performing repeated trials and the percentage error was found to be between 0.5–3%. Merging the field of embedded systems, internet of things (IoT), VLC, signal processing, virtual reality (VR), e-commerce, and haptic sensing, the idea proposed in this research work can help introduce the haptic interaction, and sensational realization-based innovation in immersive visualization (IV) and graphical user interface (GUI) domain. Full article
(This article belongs to the Special Issue Embedded System for Smart Sensors/Actuators and IoT Applications)
Show Figures

Figure 1

14 pages, 10973 KiB
Article
An Optimization Design Method of Rigid-Flexible Soft Fingers Based on Dielectric Elastomer Actuators
by Fuhao Ouyang, Yuanlin Guan, Chunyu Yu, Xixin Yang, Qi Cheng, Jiawei Chen, Juan Zhao, Qinghai Zhang and Yang Guo
Micromachines 2022, 13(11), 2030; https://doi.org/10.3390/mi13112030 - 19 Nov 2022
Cited by 4 | Viewed by 1780
Abstract
The soft gripper has received extensive attention, due to its good adaptability and flexibility. The dielectric elastomer (DE) actuator as a flexible electroactive polymer that provides a new approach for soft grippers. However, they have the disadvantage of having a poor rigidity. Therefore, [...] Read more.
The soft gripper has received extensive attention, due to its good adaptability and flexibility. The dielectric elastomer (DE) actuator as a flexible electroactive polymer that provides a new approach for soft grippers. However, they have the disadvantage of having a poor rigidity. Therefore, the optimization design method of a rigid-flexible soft finger is presented to improve the rigidity of the soft finger. We analyzed the interaction of the rigid and soft materials, using the finite element method (FEM), and researched the influence of the parameters (compression of the spring and pre-stretching ratio of the DE) on the bending angle. The optimal parameters were obtained using the FEM. We experimentally verified the accuracy of the proposed method. The maximum bending angle is 19.66°. Compared with the theoretical result, the maximum error is 3.84%. Simultaneously, the soft gripper with three fingers can grasp various objects and the maximum grasping quality is 11.21 g. Full article
(This article belongs to the Special Issue Recent Advance in Piezoelectric Actuators and Motors)
Show Figures

Figure 1

19 pages, 2010 KiB
Article
HybriDC: A Resource-Efficient CPU-FPGA Heterogeneous Acceleration System for Lossless Data Compression
by Puguang Liu, Ziling Wei, Chuan Yu and Shuhui Chen
Micromachines 2022, 13(11), 2029; https://doi.org/10.3390/mi13112029 - 19 Nov 2022
Cited by 2 | Viewed by 2237
Abstract
Lossless data compression is a crucial and computing-intensive application in data-centric scenarios. To reduce the CPU overhead, FPGA-based accelerators have been proposed to offload compression workloads. However, most existing schemes have the problem of an imbalanced resource utilization and a poor practicability. In [...] Read more.
Lossless data compression is a crucial and computing-intensive application in data-centric scenarios. To reduce the CPU overhead, FPGA-based accelerators have been proposed to offload compression workloads. However, most existing schemes have the problem of an imbalanced resource utilization and a poor practicability. In this paper, we propose HybriDC, an adaptive resource-efficient CPU-FPGA heterogeneous acceleration system for lossless data compression. Leveraging complementary advantages of the heterogeneous architecture, HybriDC provides a universal end-to-end compression acceleration framework with application compatibility and performance scalability. To optimize the hardware compression kernel design, we build a performance–resource model of the compression algorithm taking into account the design goal, compression performance, available resources, etc. According to the deduced resource-balanced design principle, the compression algorithm parameters are fine-tuned, which reduces 32% of the block RAM usage of the LZ4 kernel. In the parallel compression kernel implementation, a memory-efficient parallel hash table with an extra checksum is proposed, which supports parallel processing and improves the compression ratio without extra memory. We develop an LZ4-based HybriDC system prototype and evaluate it in detail. Our LZ4 compression kernel achieves state-of-the-art memory efficiency, 2.5–4× better than existing designs with comparable compression ratios. The evaluation of total resource utilization and end-to-end throughput demonstrates the excellent scalability of HybriDC. In power efficiency, the four-kernel HybriDC prototype achieves a threefold advantage over the standard LZ4 algorithm. Full article
(This article belongs to the Section E:Engineering and Technology)
Show Figures

Figure 1

14 pages, 1024 KiB
Article
Electromagnetic Actuation for a Micro/Nano Robot in a Three-Dimensional Environment
by Mostafa Abdelaziz and Maki Habib
Micromachines 2022, 13(11), 2028; https://doi.org/10.3390/mi13112028 - 19 Nov 2022
Cited by 6 | Viewed by 2097
Abstract
Micro/nanorobots have several potential biomedical applications, such as drug delivery, minimal invasiveness, and moving within narrow and complex areas. To achieve these desirable applications, precise path tracking and controlling magnetic micro/nanorobots within blood vessels is a crucial but challenging point. In this paper, [...] Read more.
Micro/nanorobots have several potential biomedical applications, such as drug delivery, minimal invasiveness, and moving within narrow and complex areas. To achieve these desirable applications, precise path tracking and controlling magnetic micro/nanorobots within blood vessels is a crucial but challenging point. In this paper, a three-dimensional electromagnetic actuation system composed of three pairs of Helmholtz coils and three pairs of Maxwell coils is proposed. A closed-loop control algorithm is proposed to enhance trajectory tracking of a micro/nanorobot. Different simulation experiments were carried out using Simulink to verify the performance of the proposed algorithm. Different trajectories were tested in tracking two-dimensional and three-dimensional reference trajectories. The results showed that by using the developed algorithm and electromagnetic actuation system, a micro/nanorobot can follow the desired trajectory within a maximum error of 13 μm. Full article
(This article belongs to the Special Issue Recent Advances in Microrobotics)
Show Figures

Figure 1

16 pages, 3392 KiB
Article
A Miniaturized Device Coupled with Digital Image Correlation for Mechanical Testing
by Daniel J. Cruz, Jose Xavier, Rui L. Amaral and Abel D. Santos
Micromachines 2022, 13(11), 2027; https://doi.org/10.3390/mi13112027 - 19 Nov 2022
Cited by 4 | Viewed by 1893
Abstract
Miniaturized mechanical testing based on small sample testing technology is a powerful technique to characterize the mechanical properties of different materials, and it is being used in different application fields. However, the small size of the specimens poses several challenges because the results [...] Read more.
Miniaturized mechanical testing based on small sample testing technology is a powerful technique to characterize the mechanical properties of different materials, and it is being used in different application fields. However, the small size of the specimens poses several challenges because the results are highly sensitive to measurement accuracy and the corresponding mechanical properties can change substantially due to the so-called specimen size effect. In this work, a novel testing device based on miniaturized specimens is presented. The equipment is designed to test materials in tensile and compressive loadings, but it is also capable of performing reverse-loading tests. Buckling of the specimen is an inherent phenomenon in compression loadings, especially for thin materials. Therefore, specimen geometry is properly studied and optimized to mitigate this effect. To evaluate the deformation of the specimen, the digital image correlation (DIC) technique is used to capture the full-field strain in the central gauge section of the sample. A sensitivity analysis of the DIC setting parameters was performed for this application. To evaluate the performance of the developed system, experimental results of monotonic tests and tests with reverse loadings (tension-compression) are presented, considering two high-strength steels (DP500 and DP780). Full article
(This article belongs to the Special Issue Micro/Nanophotonic Devices in Europe)
Show Figures

Figure 1

17 pages, 6212 KiB
Article
Sawing Force Prediction Model and Experimental Study on Vibration-Assisted Diamond Wire Sawing
by Chenpu Zhang, Zhikui Dong, Yanheng Zhao, Ziliang Liu, Shang Wu and Jiahao Yang
Micromachines 2022, 13(11), 2026; https://doi.org/10.3390/mi13112026 - 19 Nov 2022
Cited by 4 | Viewed by 1864
Abstract
Diamond wire sawing is the main machining technology for slicing various brittle materials, such as crystalline silicon, SiC, and NdFeB. Due to their high hardness and high brittleness, as well as the ease with which the surfaces of machined materials are damaged, it [...] Read more.
Diamond wire sawing is the main machining technology for slicing various brittle materials, such as crystalline silicon, SiC, and NdFeB. Due to their high hardness and high brittleness, as well as the ease with which the surfaces of machined materials are damaged, it is difficult to further improve the sawing efficiency and the surface quality based on research conducted on the original machining method. In this paper, a vibration-assisted diamond wire sawing method is proposed. We analyzed the impact of load on the ingot, motion trajectory, and sawing depth of the abrasive particles, and a macroscopic sawing force prediction model for the vibration-assisted sawing method was established and verified via experiments. Based on the single-wire-sawing experiment and prediction model, the influences of the vibration parameters and sawing parameters on the sawing force were determined. The influences of vibration assistance on the surface quality, including the roughness profile, waviness profile, thickness profile, Ra, and Rz, were explored through single-wire-sawing experiments, and the influences of vibration assistance on the geometric parameters of slices, such as the total thickness variation (TTV) and warp, were explored through multi-wire-sawing experiments. It was found that vibration-assisted sawing can reduce sawing force and improve surface quality. Full article
(This article belongs to the Special Issue Advanced Manufacturing Technology and Systems, 2nd Edition)
Show Figures

Figure 1

21 pages, 1683 KiB
Review
Temperature-to-Digital Converters’ Evolution, Trends and Techniques across the Last Two Decades: A Review
by Antonio Aprile, Edoardo Bonizzoni and Piero Malcovati
Micromachines 2022, 13(11), 2025; https://doi.org/10.3390/mi13112025 - 19 Nov 2022
Cited by 6 | Viewed by 2635
Abstract
This paper presents an extensive review of the main highlights in the Temperature-to-Digital Converters (TDCs) field, which has gained importance and research interest throughout the last two decades. The key techniques and approaches that have led to the evolution of this kind of [...] Read more.
This paper presents an extensive review of the main highlights in the Temperature-to-Digital Converters (TDCs) field, which has gained importance and research interest throughout the last two decades. The key techniques and approaches that have led to the evolution of this kind of systems are presented and compared; their peculiarities are identified in order to highlight the pros and cons of the different design methods, and the main trade-offs are extracted from this analysis. Finally, the trends that have emerged from the performance evaluation of the large amount of published works in this field are identified with the purpose of providing a directional view of the past, present and future features of these devices. Full article
(This article belongs to the Special Issue Feature Papers of Micromachines in Engineering and Technology 2021)
Show Figures

Figure 1

8 pages, 1555 KiB
Communication
Performance Enhancement for Indium-Free Metal Oxide Thin-Film Transistors with Double-Active-Layers by Magnetron Sputtering at Room Temperature
by Xingzhen Yan, Kaian Song, Bo Li, Yiqiang Zhang, Fan Yang, Yanjie Wang, Chao Wang, Yaodan Chi and Xiaotian Yang
Micromachines 2022, 13(11), 2024; https://doi.org/10.3390/mi13112024 - 19 Nov 2022
Cited by 2 | Viewed by 1681
Abstract
We prepared an indium-free metal oxide thin-film transistor (TFT) using a double-active-layers structure at room temperature. We changed the growth sequence of Al-doped zinc oxide (AZO) and zinc oxide (ZnO) double-active-layers on Si/SiO2 substrates by magnetron sputtering deposition to regulate the field-effect [...] Read more.
We prepared an indium-free metal oxide thin-film transistor (TFT) using a double-active-layers structure at room temperature. We changed the growth sequence of Al-doped zinc oxide (AZO) and zinc oxide (ZnO) double-active-layers on Si/SiO2 substrates by magnetron sputtering deposition to regulate the field-effect performance of TFTs. According to the analysis of field-effect properties before and after annealing in different atmospheres, the performance of TFT devices with ZnO/AZO/SiO2/Si double-active-layers was obviously better than that with single AZO or ZnO active layer and inverted AZO/ZnO/SiO2/Si double-active-layers in the device structure. The active layer with higher carrier concentration (AZO in this case) was closer to the dielectric layer, which was more favorable for carrier regulation in TFT devices. In addition, the annealed device had a lower on/off ratio (Ion/Ioff), easier-to-reach on-state, and higher mobility. Furthermore, the performance of the devices annealed under vacuum condition was obviously better than that annealed under air atmosphere. The Ion/Ioff could reach 6.8 × 105 and the threshold voltage was only 2.9 V. Full article
(This article belongs to the Special Issue Recent Advances in Thin Film Transistors)
Show Figures

Figure 1

8 pages, 2418 KiB
Article
Reprogrammable Metasurface Controlled by 2D Thermal Fields
by Ming Zhang, Fuju Ye, Hongrui Tan, Sisi Luo, Haoyang Cui and Lei Chen
Micromachines 2022, 13(11), 2023; https://doi.org/10.3390/mi13112023 - 19 Nov 2022
Viewed by 1676
Abstract
The combination of thermal field sensing and microwave operation is an innovative topic in metamaterials. Although there exists research on modulating electromagnetic waves by controlling each column of the metasurface elements for programmable metasurfaces, the regulation is not flexible. In view of this, [...] Read more.
The combination of thermal field sensing and microwave operation is an innovative topic in metamaterials. Although there exists research on modulating electromagnetic waves by controlling each column of the metasurface elements for programmable metasurfaces, the regulation is not flexible. In view of this, this paper proposes a metasurface based on distributed thermal sensing that can be independently modulated by each element. In this paper, the metasurface adopts a 1-bit coding metasurface, which is combined with PIN diodes to modulate the phase response. The voltage control circuit feeds back the change in the thermistors to the switching state of the PIN diode. Each metasurface unit contains thermistors, which are used to sense thermal stimulation and can be independently modulated. The metasurface composed of these elements can feel the field generated via heat energy. We can control electromagnetic waves by controlling this field. In order to prove the feasibility of this scheme, a metasurface sample of 8 × 8 elements was designed. Three patterns were used for the design, fabrication, and measurement of the samples. Meanwhile, printed circuit board (PCB) technology was applied. The results show that the simulated results are highly consistent with the experimental results, which verifies that this scheme is practicable. Full article
(This article belongs to the Special Issue Terahertz and Infrared Metamaterial Devices)
Show Figures

Figure 1

17 pages, 5556 KiB
Article
Four-Port Dual-Band Multiple-Input Multiple-Output Dielectric Resonator Antenna for Sub-6 GHz 5G Communication Applications
by Upesh Patel and Trushit Upadhyaya
Micromachines 2022, 13(11), 2022; https://doi.org/10.3390/mi13112022 - 19 Nov 2022
Cited by 13 | Viewed by 1905
Abstract
A four-port dielectric resonator (DR)-based multiple-input multiple-output (MIMO) antenna is presented for sub-6 GHz MIMO communication. The dielectric resonator was fed through aperture feeding to achieve dual-band resonance. The DRA has the operating modes of TE01δ and [...] Read more.
A four-port dielectric resonator (DR)-based multiple-input multiple-output (MIMO) antenna is presented for sub-6 GHz MIMO communication. The dielectric resonator was fed through aperture feeding to achieve dual-band resonance. The DRA has the operating modes of TE01δ and TE10δ at 3.3 GHz and 3.9 GHz, respectively. The engineered antenna has port isolation of higher than 20 dB at the target frequencies without the employment of an extra isolation mechanism. Full-wave high-frequency simulation software was employed for the simulation computation. The antenna has a peak gain of 5.8 dBi and 6.2 dBi, and an efficiency of 88.6% and 90.2% at 3.3 GHz and 3.9 GHz, respectively. The proposed resonator has good MIMO diversity parameters. The optimal envelope correlation coefficient (ECC) is 0.01, channel capacity loss (CCL) is 0.1 bits/sec/Hz, and the total active reflection coefficient (TARC) is −22.46. The DRA elements are aligned orthogonally with adequate displacement for achieving polarization diversity and spatial diversity. The antenna delivers its applications in Sub-6 GHz 5G and WiMAX communications. Full article
(This article belongs to the Special Issue Advanced Antennas for Wireless Communication Systems)
Show Figures

Figure 1

15 pages, 4610 KiB
Article
A Convolutional Dynamic-Jerk-Planning Algorithm for Impedance Control of Variable-Stiffness Cable-Driven Manipulators
by Luyang Zhang, Lihui Jia, Panpan Yang, Zixuan Li, Yuhuan Zhang, Xiang Cheng and Zonggao Mu
Micromachines 2022, 13(11), 2021; https://doi.org/10.3390/mi13112021 - 19 Nov 2022
Cited by 1 | Viewed by 1935
Abstract
Cable-driven manipulators, characterized by slender arms, dexterous motion, and controllable stiffness, have great prospects for application to capture on-orbit satellites. However, it is difficult to achieve effective motion planning and stiffness control of cable-driven manipulators because of the coupled relationships between cable lengths, [...] Read more.
Cable-driven manipulators, characterized by slender arms, dexterous motion, and controllable stiffness, have great prospects for application to capture on-orbit satellites. However, it is difficult to achieve effective motion planning and stiffness control of cable-driven manipulators because of the coupled relationships between cable lengths, joint angles, and reaction forces. Therefore, a convolutional dynamic-jerk-planning algorithm is devised for impedance control of variable-stiffness cable-driven manipulators. First, a variable-stiffness cable-driven manipulator with universal modules and rotary quick-change modules is designed to overcome difficulties related to disassembly, installation, and maintenance. Second, a convolutional dynamic-jerk-planning algorithm is devised to overcome the discontinuity and shock problems of the manipulator’s velocity during intermittent control processes. The algorithm can also make acceleration smooth by setting jerk dynamically, reducing acceleration shock and ensuring the stable movement of the cable-driven manipulator. Third, the stiffness of the cable-driven manipulator is further optimized by compensating for the position and velocity of drive cables by employing position-based impedance control. Finally, the prototype of the variable-stiffness cable-driven manipulator is developed and tested. The convolutional dynamic-jerk-planning algorithm is used to plan the desired velocity curves for velocity control experiments of the cable-driven manipulator. The results verify that the algorithm can improve the acceleration smoothness, thereby making movement smooth and reducing vibrations. Furthermore, stiffness control experiments verify that the cable-driven manipulator has ideal variable stiffness capabilities. Full article
(This article belongs to the Special Issue Micro/Nano Resonators, Actuators, and Their Applications)
Show Figures

Figure 1

13 pages, 3392 KiB
Article
Effect of Polyvinylpolypyrrolidone Surfactant on Characteristics of Iron-Oxide Nanoparticles Synthesized by Using Recycled Waste Permanent Magnets
by Sung-Jei Hong, Ajin Jo, Sang Hyeok Hong, Byeong Jun Kim, Young Sung Kim, Suwon Yang and Jae-Yong Lee
Micromachines 2022, 13(11), 2020; https://doi.org/10.3390/mi13112020 - 19 Nov 2022
Cited by 1 | Viewed by 1293
Abstract
In this study, iron oxide nanoparticles (FeOx NPs) were synthesized by using Fe solution recycled from NdFeB permanent magnet scrap. Furthermore, the effect of polyvinylpolypyrrolidone (PVP) as a surfactant on the characteristics of the FeOx NPs was investigated. Firstly, Fe solution [...] Read more.
In this study, iron oxide nanoparticles (FeOx NPs) were synthesized by using Fe solution recycled from NdFeB permanent magnet scrap. Furthermore, the effect of polyvinylpolypyrrolidone (PVP) as a surfactant on the characteristics of the FeOx NPs was investigated. Firstly, Fe solution was prepared by using 10% H2SO4 solution and Na2SO4 salt. In addition, three reducing agent solutions were prepared by dissolving PVP in 0.5 M NH4OH solution in distilled (D.I.) water with concentrations of 0 wt%, 1 wt%, and 2 wt%, respectively. Each reducing agent solution was added dropwise into the Fe solution to precipitate three precursors of FeOx NPs, and they were heat-treated at 400 °C to prepare three FeOx NPs samples, P0, P1, and P2. In X-ray diffractometer (XRD) analysis, diffraction peaks of P0 sample are consistent with the Fe3O4 with (311) preferred orientation. The XRD peak shifted from Fe3O4 to Fe2O3 structure as PVP concentration increased, and the crystal structure of P2 sample was transformed to Fe2O3 with (104) preferred orientation. Brunauer, Emmett, and Teller (BET) specific surface area increased in proportional to PVP concentration. HRTEM observation also supported the tendency; the particle size of the P0 sample was less than 40 nm, and particle size decreased as PVP concentration increased, leading to the particle size of the P2 sample being less than 20 nm in width. In addition, particle morphology started to be transformed from particle to rod shape as PVP concentration increased and, in the P2 sample, all the morphology of particles was transformed to a rod shape. Magnetic properties analysis revealed that the P0 sample exhibited the highest value of magnetic moment, 65.6 emu/g, and the magnetic moment was lowered in the P1 sample, and the P2 sample exhibited the lowest value of magnetic moment, 2.4 emu/g. Full article
(This article belongs to the Special Issue Micro and Smart Devices and Systems, 2nd Edition)
Show Figures

Figure 1

20 pages, 4483 KiB
Article
Significance of Free Convection Flow over an Oscillating Inclined Plate Induced by Nanofluid with Porous Medium: The Case of the Prabhakar Fractional Approach
by Ali Raza, Umair Khan, Sayed M. Eldin, Abeer M. Alotaibi, Samia Elattar, Ballajja C. Prasannakumara, Nevzat Akkurt and Ahmed M. Abed
Micromachines 2022, 13(11), 2019; https://doi.org/10.3390/mi13112019 - 19 Nov 2022
Cited by 13 | Viewed by 1839
Abstract
Given the importance and use of electrically conducted nanofluids, this work aims to examine an engine-oil-based nanofluid including various nanoparticles. In the current study, a fractional model for inspecting the thermal aspect of a Brinkman-type nanofluid, composed of (molybdenum disulfide (MOS2 [...] Read more.
Given the importance and use of electrically conducted nanofluids, this work aims to examine an engine-oil-based nanofluid including various nanoparticles. In the current study, a fractional model for inspecting the thermal aspect of a Brinkman-type nanofluid, composed of (molybdenum disulfide (MOS2) and graphene oxide (GO) nanoparticles flows on an oscillating infinite inclined plate, which characterizes an asymmetrical fluid flow, heat, and mass transfer. Furthermore, the Newtonian heating effect, magnetic field, and slip boundary conditions were taken into account. The objectives for implementing the Prabhakar-like fractional model are justified because this fractional algorithm has contemporary definitions with no singularity restrictions. Furthermore, the guided fractional model was solved using the Laplace transform and several inverse methods. The obtained symmetrical solutions have been visually analyzed to investigate the physics of several relevant flow parameters on the governed equations. Some exceptional cases for the momentum field are compiled to see the physical analysis of the flowing fluid symmetry. The results show that the thermal enhancement can be progressively improved with the interaction of the molybdenum disulfide-engine oil-based nanofluid suspension, rather than with the graphene oxide mixed nanoparticle fluid. Furthermore, the temperature and momentum profiles enhance due to the factional parameters for molybdenum disulfide and the graphene oxide-engine oil-based nanofluid suspension. This study’s graphical and numerical comparison with the existing literature has shown a very close resemblance with the present work, which provides confidence that the unavailable results are accurate. The results show that an increase improved the heat transmission in the solid nanoparticle volume fractions. In addition, the increment in the mass and heat transfer was analyzed in the numerical evaluation, while the shear stress was enhanced with the enhancement in the Prabhakar fractional parameter α. Full article
(This article belongs to the Special Issue Micro/Nanofluids in Magnetic/Electric Fields)
Show Figures

Figure 1

12 pages, 3013 KiB
Article
A Robust Tracking Method for Multiple Moving Targets Based on Equivalent Magnetic Force
by Ying Wang, Qiang Fu and Yangyi Sui
Micromachines 2022, 13(11), 2018; https://doi.org/10.3390/mi13112018 - 18 Nov 2022
Cited by 7 | Viewed by 1537
Abstract
A ferromagnetic vehicle, such as a submarine, magnetized by the Earth’s magnetic field produces a magnetic anomaly field, and the tracking of moving targets can be realized through real-time analysis of magnetic data. At present, there are few tracking methods based on magnetic [...] Read more.
A ferromagnetic vehicle, such as a submarine, magnetized by the Earth’s magnetic field produces a magnetic anomaly field, and the tracking of moving targets can be realized through real-time analysis of magnetic data. At present, there are few tracking methods based on magnetic field vectors and their gradient tensor. In this paper, the magnetic field vector and its gradient tensor are used to calculate equivalent magnetic force. It shows the direction of the vector between the detector and the tracking targets for controlling the direction of motion of the detector and achieving the purpose of tracking. Compared with existing positioning methods, the proposed method is relatively less affected by instrument resolution and noise and maintains robustness when the velocity vectors of multiple magnetic targets change randomly. Full article
(This article belongs to the Special Issue Accelerometer and Magnetometer: From Fundamentals to Applications)
Show Figures

Figure 1

6 pages, 2961 KiB
Article
Fabrication of LuAG:Ce3+ Ceramic Phosphors Prepared with Nanophosphors Synthesized by a Sol-Gel-Combustion Method
by Seok Bin Kwon, Seung Hee Choi, Jung Hyeon Yoo, Seon Yeong Lee, Bo Young Kim, Ho Jung Jeong, Wan Ho Kim, Jae Pil Kim, Bong Kyun Kang, Dae Ho Yoon and Young Hyun Song
Micromachines 2022, 13(11), 2017; https://doi.org/10.3390/mi13112017 - 18 Nov 2022
Cited by 2 | Viewed by 1729
Abstract
The aim of this study was to investigate properties of ceramic phosphors fabricated using nano Lu3Al5O12:Ce3+ phosphors produced with a sol-gel-combustion method. These nano Lu3Al5O12:Ce3+ phosphors had a size [...] Read more.
The aim of this study was to investigate properties of ceramic phosphors fabricated using nano Lu3Al5O12:Ce3+ phosphors produced with a sol-gel-combustion method. These nano Lu3Al5O12:Ce3+ phosphors had a size of about 200 nm, leading to high density when fabricated as a ceramic phosphor. We manufactured ceramic phosphors through vacuum sintering. Alumina powder was added to improve properties. We mounted the manufactured ceramic phosphor in a high-power laser beam projector and drove it to determine its optical performance. Ceramic phosphor manufactured according to our route will have a significant impact on the laser-driven lighting industry. Full article
(This article belongs to the Special Issue Advanced Technologies in Electronic Packaging)
Show Figures

Figure 1

3 pages, 252 KiB
Editorial
Imaging-Guided Micromachines: Towards Intelligent Systems
by Qianqian Wang
Micromachines 2022, 13(11), 2016; https://doi.org/10.3390/mi13112016 - 18 Nov 2022
Viewed by 1237
Abstract
Micromachines with controllable motion, deformation, and collective behaviors provide advanced methods for performing tasks that traditional machines have difficulty completing thanks to the development of small-scale robotics, nanotechnology, biocompatible materials, and imaging techniques [...] Full article
(This article belongs to the Special Issue Imaging-Guided Intelligent Micromachines)
Show Figures

Figure 1

14 pages, 3681 KiB
Article
Research of Frequency Splitting Caused by Uneven Mass of Micro-Hemispherical Resonator Gyro
by Lijun Song, Qingru Li, Wanliang Zhao, Tianxiang Zhang and Xing He
Micromachines 2022, 13(11), 2015; https://doi.org/10.3390/mi13112015 - 18 Nov 2022
Cited by 5 | Viewed by 1619
Abstract
In practical engineering, the frequency splitting of Hemispherical Resonator Gyro (HRG) caused by uneven mass distribution seriously affects the precision of HRG. So, the inherent frequency is an important parameter of micro-Hemispherical Resonator Gyro (m-HRG). In the processing of hemispherical resonator, there are [...] Read more.
In practical engineering, the frequency splitting of Hemispherical Resonator Gyro (HRG) caused by uneven mass distribution seriously affects the precision of HRG. So, the inherent frequency is an important parameter of micro-Hemispherical Resonator Gyro (m-HRG). In the processing of hemispherical resonator, there are some morphological errors and internal defects in the hemispherical resonator, which affect the inherent frequency and the working mode of m-HRG, and reduce the precision and performance of m-HRG. In order to improve the precision and performance of m-HRG, the partial differential equation of the hemispherical resonator is solved, and the three-dimensional model using ANSYS software accurately reflected the actual shape is established in this paper. Then, the mode of hemispherical resonator in ideal state and uneven mass distribution state are simulated and analyzed. The frequency splitting mechanism of the hemispherical resonator is determined by calculation and demonstration, and the frequency splitting of the hemispherical resonator is suppressed by partial mass elimination. The results show that the absolute balance of energy can ensure the high-quality factor and the minimum frequency splitting of the hemispherical resonator. Therefore, during the processing of hemispherical resonator, the balance of mass should be achieved as much as possible to avoid various surface damage, internal defects and uneven mass distribution to guarantee the high-quality factor Q and minimum frequency splitting of hemispherical resonator. Full article
(This article belongs to the Special Issue New Advances, Methods, and Applications for Micro Inertial Sensors)
Show Figures

Figure 1

14 pages, 1207 KiB
Article
A Heterogeneity-Aware Replacement Policy for the Partitioned Cache on Asymmetric Multi-Core Architectures
by Juan Fang, Han Kong, Huijing Yang, Yixiang Xu and Min Cai
Micromachines 2022, 13(11), 2014; https://doi.org/10.3390/mi13112014 - 18 Nov 2022
Cited by 3 | Viewed by 1476
Abstract
In an asymmetric multi-core architecture, multiple heterogeneous cores share the last-level cache (LLC). Due to the different memory access requirements among heterogeneous cores, the LLC competition is more intense. In the current work, we propose a heterogeneity-aware replacement policy for the partitioned cache [...] Read more.
In an asymmetric multi-core architecture, multiple heterogeneous cores share the last-level cache (LLC). Due to the different memory access requirements among heterogeneous cores, the LLC competition is more intense. In the current work, we propose a heterogeneity-aware replacement policy for the partitioned cache (HAPC), which reduces the mutual interference between cores through cache partitioning, and tracks the shared reuse state of each cache block within the partition at runtime to guide the replacement policy to keep cache blocks shared by multiple cores in multithreaded programs. In the process of updating the reuse state, considering the difference of memory accesses to LLC by heterogeneous cores, the cache replacement policy tends to keep cache blocks required by big cores, to better improve the LLC access efficiency of big cores. Compared with LRU and the SRCP, which are the state-of-the-art cache replacement algorithms, the performance of big cores can be significantly improved by HAPC when running multithreaded programs, while the impact on little cores is almost negligible, thus improving the overall performance of the system. Full article
(This article belongs to the Special Issue Microcontrollers and Microprocessors: The Advanced System on the Chip)
Show Figures

Figure 1

15 pages, 7567 KiB
Article
Compact 5G Nonuniform Transmission Line Interdigital Bandpass Filter for 5G/UWB Reconfigurable Antenna
by Sahar Saleh, Mohd Haizal Jamaluddin, Faroq Razzaz and Saud M. Saeed
Micromachines 2022, 13(11), 2013; https://doi.org/10.3390/mi13112013 - 18 Nov 2022
Cited by 3 | Viewed by 2262
Abstract
In this study, at two different fifth generation (5G) low-frequency bands (3.7–4.2 GHz and 5.975–7.125 GHz) and based on nonuniform transmission lines (NTLs) theory, a compact three-quarter-wave resonators interdigital bandpass filter (IBPF) is analyzed, designed, and fabricated. The compact proposed filter is considered [...] Read more.
In this study, at two different fifth generation (5G) low-frequency bands (3.7–4.2 GHz and 5.975–7.125 GHz) and based on nonuniform transmission lines (NTLs) theory, a compact three-quarter-wave resonators interdigital bandpass filter (IBPF) is analyzed, designed, and fabricated. The compact proposed filter is considered as a good candidate for reconfigurable 5G low-frequency bands and ultrawide band (UWB) antenna, which will reduce the size of the final RF communication system. Firstly, a uniform transmission line (UTL) IBPF at these two bands is designed and tested; then the NTL concept is applied for compactness. For both UTL and NTL IBPFs, different parametric studies are performed for optimization. At the first frequency band, size reductions of 16.88% and 16.83% are achieved in the first (symmetrical to the third resonator) and second λ/4 resonator of UTL IBPF, respectively, with up to 36.6% reduction in the total area. However, 16.46% and 16.33% size reductions are obtained in the first (symmetrical to the third resonator) and second λ/4 resonator, respectively, at the second frequency band with a 40.53% reduction in the whole circuit area. The performance of the proposed NTL IBPF is compared with the UTL IBPF. The measured reflection coefficient of the proposed NTL IBPF, S11, appears to be less than −10.53 dB and −11.27 dB through 3.7–4.25 GHz and 5.94–7.67 GHz, respectively. However, the transmission coefficient, S12 is around −0.86 dB and–1.7 dB at the center frequencies, fc = 3.98 GHz and 6.81 GHz, respectively. In this study, simulations are carried out using high-frequency structure simulator (HFSS) software based on the finite element method (FEM). The validity of the proposed theoretical schematic of this filter is proved by design simulations and measured results of its prototype. Full article
(This article belongs to the Special Issue Microwave Antennas: From Fundamental Research to Applications)
Show Figures

Figure 1

13 pages, 3133 KiB
Article
Simulation of Laser-Heating and Energetic Plasma Plume Expansion in Pulsed Laser Deposition of Y3Fe5O12
by Joko Suwardy, Muzakkiy Putra Muhammad Akhir, Robi Kurniawan, Beni Rio Hermanto, Isa Anshori and Mohammad Hamzah Fauzi
Micromachines 2022, 13(11), 2012; https://doi.org/10.3390/mi13112012 - 18 Nov 2022
Cited by 1 | Viewed by 3072
Abstract
In the present study, numerically iterative models are employed to study two processes involved in the pulsed laser deposition of an Y3Fe5O12 target. The 1D conduction heat model is used to evaluate the temperature of the target irradiated [...] Read more.
In the present study, numerically iterative models are employed to study two processes involved in the pulsed laser deposition of an Y3Fe5O12 target. The 1D conduction heat model is used to evaluate the temperature of the target irradiated by a nano-second pulse laser, taking into account the plasma shielding effect. Further, the gas dynamics model is employed to simulate the kinetic of plasma plume expansion. The results may be important in obtaining high-quality Y3Fe5O12 thin films. Full article
(This article belongs to the Special Issue Advanced Manufacturing Technology and Systems, 2nd Edition)
Show Figures

Figure 1

18 pages, 8467 KiB
Article
Evaluation of Three-Dimensional Surface Roughness in Microgroove Based on Bidimensional Empirical Mode Decomposition
by Haiyu Jiang, Wenqin Li, Zhanjiang Yu, Huadong Yu, Jinkai Xu and Lei Feng
Micromachines 2022, 13(11), 2011; https://doi.org/10.3390/mi13112011 - 18 Nov 2022
Cited by 3 | Viewed by 1932
Abstract
Micromilling is an extremely important advanced manufacturing technology in the micromanufacturing industry. Compared with the traditional milling process, micromilling has stricter requirements on the surface roughness of the workpiece, and the roughness of the microcurved surface is not easy to measure. In order [...] Read more.
Micromilling is an extremely important advanced manufacturing technology in the micromanufacturing industry. Compared with the traditional milling process, micromilling has stricter requirements on the surface roughness of the workpiece, and the roughness of the microcurved surface is not easy to measure. In order to more accurately characterize the curved surface morphology of the microgrooves obtained by micromilling, this paper proposes a method to extract the reference plane of the curved surface based on the bidimensional empirical mode decomposition algorithm and characterize the three-dimensional surface roughness of the curved surface. First, we synthesize the morphologies of the microgrooves by simulated non-Gaussian rough surfaces and models of textures. Second, the bidimensional empirical mode decomposition algorithm was used to extract the reference planes of the simulated microgrooves. Third, the three-dimensional roughness parameters suitable for the curved surfaces of microgrooves were selected to establish an evaluation system. The results show that the mean squared errors of the reference planes are below 1%, so bidimensional empirical mode decomposition can effectively extract reference planes, and the evaluation system of three-dimensional surface roughness proposed in this paper reflects morphological characteristics of the curved surfaces of microgrooves more thoroughly than that of two-dimensional surface roughness parameters. Full article
Show Figures

Figure 1

10 pages, 1704 KiB
Article
CuO Nanowires Fabricated by Thermal Oxidation of Cu Foils towards Electrochemical Detection of Glucose
by Xun Cao
Micromachines 2022, 13(11), 2010; https://doi.org/10.3390/mi13112010 - 18 Nov 2022
Cited by 3 | Viewed by 1891
Abstract
In view of the various stability issues and high cost of enzymatic glucose biosensors, non-enzymatic biosensors have received great attention in recent research and development. Copper oxide (CuO) nanowires (NWs) were fabricated on Cu foil substrate using a simple thermal oxidation method. The [...] Read more.
In view of the various stability issues and high cost of enzymatic glucose biosensors, non-enzymatic biosensors have received great attention in recent research and development. Copper oxide (CuO) nanowires (NWs) were fabricated on Cu foil substrate using a simple thermal oxidation method. The phase and morphology of the CuO NWs could be controlled by synthesis temperature. Variation in oxidation states enables CuO NWs to form Cu (III) species, which is crucial in catalysing the eletro-oxidation of glucose. The Cu-based metal/oxide composite electrode works as a non-enzymatic biosensor that adapts to the fast, dynamic change in glucose concentration, with a low saturation concentration (~0.7 mM) and a lower detection limit of 0.1 mM, making CuO NWs an excellent sensor towards impaired fasting glucose. The simplicity, cost-effectiveness and non-toxicity features of this study might make a way for potentially scalable application in glucose biosensing. Full article
(This article belongs to the Special Issue Miniaturized Chemical Sensors)
Show Figures

Figure 1

15 pages, 6503 KiB
Article
A Study of Nano-Tungsten Colloid Preparing by the Electrical Spark Discharge Method
by Chaur-Yang Chang, Kuo-Hsiung Tseng, Jui-Tsun Chang, Meng-Yun Chung and Zih-Yuan Lin
Micromachines 2022, 13(11), 2009; https://doi.org/10.3390/mi13112009 - 18 Nov 2022
Cited by 2 | Viewed by 1633
Abstract
This study developed an energy-enhanced (ee)-micro-electric discharge machining (EDM) system for preparing nano-tungsten (nano-W) colloids. This system enables spark discharge using tungsten wires immersed in deionized water, to produce nano-W colloids. Compared with the chemical preparation method, the processing environment for preparing colloids [...] Read more.
This study developed an energy-enhanced (ee)-micro-electric discharge machining (EDM) system for preparing nano-tungsten (nano-W) colloids. This system enables spark discharge using tungsten wires immersed in deionized water, to produce nano-W colloids. Compared with the chemical preparation method, the processing environment for preparing colloids in this study prevented nanoparticle escape. Among the nano-W colloids prepared using the ee-micro-EDM system and an industrial EDM system, the colloid prepared by the ee-micro-EDM system exhibited a more favorable absorbance, suspensibility, and particle size. The colloid prepared by the ee-micro-EDM system with a pulse on time and off time of 10–10 μs had an absorbance of 0.277 at a wavelength of 315 nm, ζ potential of −64.9 mV, and an average particle size of 164.9 nm. Transmission electron microscope imaging revealed a minimum particle size of approximately 11 nm, and the X-ray diffractometer spectrum verified that the colloid contained only W2.00 and W nanoparticles. Relative to industrial EDM applications for nano-W colloid preparation, the ee-micro-EDM system boasts a lower cost and smaller size, and produces nano-W colloids with superior performance. These advantages contribute to the competitiveness of the electrical spark discharge method in the preparation of high-quality nano-W colloids. Full article
(This article belongs to the Special Issue Nanoparticles: Optical Properties and Applications)
Show Figures

Figure 1

19 pages, 9728 KiB
Article
A Novel Monopolar Cross-Scale Nanopositioning Stage Based on Dual Piezoelectric Stick-Slip Driving Principle
by Junhui Zhu, Siyuan Meng, Yong Wang, Ming Pang, Zhiping Hu and Changhai Ru
Micromachines 2022, 13(11), 2008; https://doi.org/10.3390/mi13112008 - 18 Nov 2022
Cited by 2 | Viewed by 1979
Abstract
The precise characterization and measurement of new nanomaterials and nano devices require in situ SEM nanorobotic instrumentation systems, which put forward further technical requirements on nanopositioning techniques of compact structure, cross-scale, nanometer accuracy, high vacuum and non-magnetic environment compatibility, etc. In this work, [...] Read more.
The precise characterization and measurement of new nanomaterials and nano devices require in situ SEM nanorobotic instrumentation systems, which put forward further technical requirements on nanopositioning techniques of compact structure, cross-scale, nanometer accuracy, high vacuum and non-magnetic environment compatibility, etc. In this work, a novel cross-scale nanopositioning stage was proposed, which combined the advantages of piezoelectric stick-slip positioner and piezoelectric scanner techniques and adopted the idea of macro/micro positioning. A new structure design of a single flexible hinge shared by a small and large PZT was proposed to effectively reduce the size of the positioning stage and achieve millimeter stroke and nanometer motion positioning accuracy. Then, the cross-scale motion generation mechanism of the dual piezoelectric stick-slip drive was studied, the system-level dynamics model of the proposed positioning stages was constructed, and the mechanism design was optimized. Further, a prototype was manufactured and a series of experiments were carried out to test the performance of the stage. The results show that the proposed positioning stage has a maximum motion range of 20 mm and minimum step length of 70 nm under the small piezoceramic ceramic macro-motion stepping mode, and a maximum scanning range of 4.9 μm and motion resolution of 16 nm under the large piezoceramic ceramic micro-motion scanning mode. Moreover, the proposed stage has a compact structure size of 30 × 17 × 8 mm3, with a maximum motion speed of 10 mm/s and maximum load of 2 kg. The experimental results confirm the feasibility of the proposed stage, and nanometer positioning resolution, high accuracy, high speed, and a large travel range were achieved, which demonstrates that the proposed stage has significant performance and potential for many in situ SEM nanorobotic instrument systems. Full article
Show Figures

Figure 1

12 pages, 2973 KiB
Article
Miniature Mesa Extension for a Planar Submicron AlGaN/GaN HEMT Gate Formation
by Moath Alathbah and Khaled Elgaid
Micromachines 2022, 13(11), 2007; https://doi.org/10.3390/mi13112007 - 18 Nov 2022
Cited by 2 | Viewed by 3032
Abstract
In this letter, a novel approach is presented to overcome issues in AlGaN/GaN high electron mobility transistors (HEMTs), such as metal discontinuity of the gate stemmed from conventional mesa isolation. This usually requires a careful mesa etch process to procure an anisotropic mesa-wall [...] Read more.
In this letter, a novel approach is presented to overcome issues in AlGaN/GaN high electron mobility transistors (HEMTs), such as metal discontinuity of the gate stemmed from conventional mesa isolation. This usually requires a careful mesa etch process to procure an anisotropic mesa-wall profile. An alternative technique is the use of ion implantation for device isolation instead of conventional mesa for a planar device formation. However, ion implantation is a costly process and not always easily accessible. In this work, the proposed method is to simply extend the mesa below the gate just enough to accommodate the gatefeed, thereby ensuring the entire gate is planar in structure up to the gatefeed. The newly developed device exhibited no compromise to the DC (direct current) and RF (radio frequency) performance. Conversely, it produced a planar gate configuration with an enhanced DC transconductance (approximately 20% increase is observed) and a lower gate leakage while the etch process is considerably simplified. Similarly, the RF transconductance of proposed device (device B) increased by 80% leading to considerable improvements in RF performance. Full article
(This article belongs to the Special Issue Gallium Nitride-Based Devices)
Show Figures

Figure 1

Previous Issue
Next Issue
Back to TopTop
