Molecular Characterization of Antibiotic Resistance Determinants in Klebsiella pneumoniae Isolates Recovered from Hospital Effluents in the Eastern Cape Province, South Africa

by
Joan U. Okafor
and
Uchechukwu U. Nwodo
*
Patho-Biocatalysis Group (PBG), Department of Biochemistry and Microbiology, University of Fort Hare, Private Bag X1314, Alice 5700, South Africa
*
Author to whom correspondence should be addressed.
Antibiotics 2023, 12(7), 1139; https://doi.org/10.3390/antibiotics12071139
Submission received: 30 May 2023 / Revised: 20 June 2023 / Accepted: 28 June 2023 / Published: 1 July 2023
(This article belongs to the Special Issue Antibiotic Resistant Pathogens in Hospital)
Browse Figures
Versions Notes

Abstract

:
Klebsiella pneumoniae (K. pneumoniae) is an opportunistic bacteria responsible for many nosocomial and community-acquired infections. The emergence and spread of antibiotic resistances have resulted in widespread epidemics and endemic dissemination of multidrug-resistant pathogens. A total of 145 K. pneumoniae isolates were recovered from hospital wastewater effluents and subjected to antibiogram profiling. Furthermore, the antibiotic resistance determinants were assessed among phenotypic resistant isolates using polymerase chain reaction (PCR). The isolates showed a wide range of antibiotic resistance against 21 selected antibiotics under 11 classes, with the most susceptible shown against imipenem (94.5%) and the most resistant shown against ampicillin (86.2%). The isolates also showed susceptibility to piperacillin/tazobactam (89.0%), ertapenem (87.6%), norfloxacin (86.2%), cefoxitin (86.2%), meropenem (76.6%), doripenem (76.6%), gentamicin (76.6%), chloramphenicol (73.1%), nitrofurantoin (71.7%), ciprofloxacin (79.3%), amikacin (60.7%), and amoxicillin/clavulanic acid (70.4%). Conversely, resistance was also recorded against tetracycline (69%), doxycycline (56.6%), cefuroxime (46.2%), cefotaxime (48.3%), ceftazidime (41.4%). Out of the 32 resistance genes tested, 28 were confirmed, with [tetA (58.8%), tetD (47.89%), tetM (25.2%), tetB (5.9%)], [sul1 (68.4%), sul1I (66.6%)], and [aadA (62.3%), strA (26%), aac(3)-IIa(aacC2)a (14.4%)] genes having the highest occurrence. Strong significant associations exist among the resistance determinants screened. About 82.7% of the K. pneumoniae isolates were multidrug-resistant (MDR) with a multiple antibiotics resistance index (MARI) range of 0.24 to 1.0. A dual presence of the resistant genes among K. pneumoniae was also observed to occur more frequently than multiple presences. This study reveals a worrisome presence of multidrug-resistant K. pneumoniae isolates and resistance genes in hospital waste effluent, resulting in higher public health risks using untreated surface water for human consumption. As a result, adequate water treatment and monitoring initiatives designed to monitor antimicrobial resistance patterns in the aquatic ecosystem are required.

1. Introduction

Hospital wastewaters serve as a channel for disseminating antimicrobial resistance determinants (ARDs) into the environment, such as rivers, streams, and lakes and also serve as a hotspot for their proliferation [1]. Environmental conditions serve as a channel for the spread of antibiotic resistance. The hospital environment is a significant factor in antibiotic resistance distribution [2]. The extensive use of antibiotics in a hospital environment is accountable for disseminating bacteria resistance in such an environment [3]. The likelihood of spreading resistant pathogens from hospitals into the surroundings poses a public health risk if not handled correctly [4]. Human and animal antibiotic misuse promotes the spread of resistant bacteria and environmental resistance genes, endangering public health [5].
There is no sanitation enforcement on wastewater treatment prior to discharge in South Africa. Consequently, this jeopardises the current wastewater system by spreading antibiotic-resistant bacteria and resistance genes into the nearby aquatic environment. Releasing antibiotics-resistant bacteria into the marine ecosystem poses a public health risk. In addition, it has been predicted that between 2015 and 2050, nearly 2.4 million people could die worldwide in low, middle, and high-income countries due to antibiotic-resistant disease-causing microorganisms without persistent attempts to solve the problem [6]. This is particularly alarming in South Africa, where considerations such as insufficient infrastructure, poor sanitation, and a significant percentage of the residents being immune impaired and thus highly vulnerable to infectious illnesses, all lead to an increased risk of antibiotic resistance-related mortality [7].
Klebsiella pneumoniae (K. pneumoniae) is a multidrug-resistant (MDR) opportunistic pathogen and a substantial cause of hospital-acquired illness common in the South African environment [8]. Multidrug-resistant pathogenic bacteria significantly impact hospital-acquired infection [9]. Modern medicine faces the challenge of increased antibiotic resistance [10]. The therapeutic action of antibiotics against K. pneumoniae has been proven abortive due to the development of resistance [11]. K. pneumoniae isolated from hospital-acquired infections has high resistance against some commonly used antibiotics such as penicillin, aminoglycosides, tetracyclines, macrolides, lincosamides, folate inhibitors, fluoroquinolones, and phenols. Antibiotic resistance effects, such as infections and death, are thus of great concern.
There are various mechanisms used by K. pneumoniae to evade the action of antibiotics. One of the mechanisms of antibiotic resistance is the possession of antibiotic genes called efflux pumps, which modify membrane porosity, the production of inactive enzymes and the alteration of the target location [12]. Bacteria carrying ARDs release their genes into surface waters. Antimicrobial-resistant pathogens and their resistance genes have emerged as a significant water contamination challenge receiving increased global attention. [13]. Therefore, it is pertinent to determine the resistance profile and genes of K. pneumoniae in environmental samples such as hospital wastewater to curb the spread of genes into the environment [14]. There is limited information on the antibiogram profile of K. pneumoniae isolated from hospital effluents in South Africa. As a result, this study will focus on assessing the resistance patterns and genes of K. pneumoniae obtained from hospital wastewater effluents in the Amathole district municipality of the Eastern Cape province of South Africa.

2. Results

2.1. Confirmation of K. pneumoniae Isolates

Out of 194 presumptive isolates, 168 (86.6%) were confirmed via PCR assay as Klebsiella spp. The previously confirmed Klebsiella spp. were further delineated into species, and 145/168 (86.3%) were confirmed positive for K. pneumoniae. A pictorial representative of K. pneumoniae confirmation via PCR amplification is shown in Figures S1 and S2.

2.2. Antimicrobial Susceptibility Testing

The antibiotics susceptibility profile of 145 K. pneumoniae isolates to 21 antimicrobial agents under 11 different classes was evaluated. Ampicillin had the highest resistance rate at 86%, followed by tetracycline (69%) and doxycycline (57%). Varied resistance to other antibiotics was recorded as follows; cefotaxime (48%), ceftazidime (41%) and trimethoprim-sulfamethoxazole (41%). High sensitivity to imipenem (95%), Piperacillin/tazobactam (89%), Norfloxacin (86%), Ertapenem (88%), Cefoxitin (86%), Ciprofloxacin (79%), Gentamicin (77%), Meropenem (77%), Chloramphenicol (73%), Nitrofurantoin (72%) and Amoxicillin/clavulanic acid (71%) was detected. An isolate (1.45%) was resistant to all antibiotics tested in this study. Figure 1 shows the susceptibility pattern of all K. pneumoniae isolates.

2.3. Distribution of Antimicrobial Resistance Genes

Simplex, duplex, and multiplex PCR techniques were used to screen 32 genes in K. pneumoniae isolates for the presence of tetracycline, beta-lactam, carbapenems, cephems, quinolones, aminoglycosides, phenicol, and sulphonamide resistance. The prevalence and distribution of these genes are shown in Table 1, while a typical gel electrophoresis profile of antimicrobial resistance genes is shown in Figures S3–S5.
Of the 119 resistant tetracycline isolates, 59% possessed the tetA gene. Similarly, 48% possessed the tetD gene. However, a 25%, 11%, 6% and 3% reduction was observed in tetM, tetK, tetB and tetC, respectively. In addition, 17% of the isolates did not harbour any resistance genes. Table 2 shows the dual and multiple resistance genes pattern assessed, with tetA-tetD and tetA-tetM having the most significant and lowest incidence of 35% and 13%, respectively.
PCR amplification revealed that 17% and 13% of the 142 Beta-lactam resistant isolates harboured blaTEM and blaSHV respectively. Table 1 shows the varying prevalence rates of other beta-lactam genes. Among the beta-lactam-resistant isolates, 3% had dual blaCTXM-1-blaTEM and blaCTXM-1-blaSHV resistance genes, while 1% had multiple resistance genes blaCTXM-1–blaTEM–blaOXA-1 as seen in Table 2. None of the isolates in this study harboured blaGES, blaPER, blaVEB.
Out of the 57 isolates that showed phenotypic resistance to sulphonamides, 68% harboured sul1, while 67% had sul11 genes. A dual resistance pattern (sul1–sul11) existed in 60% of the isolates.
The 69 K. pneumoniae isolates resistant to aminoglycosides were screened for strA, aadA, aac(3)-IIa(aacC2)a, aph(3)-Ia(aphA1)a. However, aadA was the most commonly detected, followed by strA and aac(3)-IIa(aacC2)a, with a prevalence of 26% and 14%, respectively. None of the isolates harboured aph(3)-Ia(aphA1)a. The most common dual occurrence was strA-aadA (15%), followed by aadA-aac(3)-IIa(aacC2)a (10%). However, multiple resistance pattern strA-aadA-aac(3)-IIa(aacC2)a was observed to have the most negligible percentage of occurrence (4%).
The most common quinolone resistance gene in the 83 resistant K. pneumoniae isolates screened was qnrA (16%), followed by qnrB (12%). In 41% of the isolates, a dual resistance pattern (qnrA-qnrB) was present.
Of the 36 K. pneumoniae isolates resistant to phenicols, 31% possessed the cat11 gene, while 3% possessed the cat1 gene. All isolates were negative for cmlA1 resistance genes. Dual and multiple resistance patterns were not observed in any of the isolates.
Five carbapenem resistance genes were screened among the K. pneumoniae isolates. The percentage distribution is as follows; blaIMP (10%), blaKPC (6%), blaNDM-1 (4%), blaVIM (2%) and blaOXA-48 (2%). The dual resistance patterns blaIMP–blaNDM-1, blaVIM–blaKPC, and blaIMP–blaOXA-48 all had the same occurrence (2%).

2.4. MARI Analysis

Multiple antibiotic resistance indexing (MARI) is one of the most straightforward methods for distinguishing antimicrobial resistance trends among environmental isolates and assessing health hazards. It indicates whether the identified isolates are from a high or low-antibiotic-use region. The MARI obtained in this study range between 0.24 and 1.0, as shown in Table 3. A MARI value greater than 0.2 indicates a high risk of source contamination due to antibiotics misuse. Multidrug resistance was observed in 120 (82.7%) K. pneumoniae isolates resistant to three or more classes of antibiotics.

2.5. Association between the Resistance Genes

The association between resistance genes among K. pneumoniae isolates was evaluated and analyzed statistically using the Pearson correlation test (p < 0.05), as shown in Table 4. Significant associations existed between some resistance genes harboured in the K. pneumoniae isolates.

3. Materials and Methods

3.1. Study Area Description

The sampling location in this study was Victoria Hospital in the Amathole District Municipality (ADM) in the Eastern Cape Province of South Africa. The residents of these municipalities are mostly employees of community service and agriculture. Most residents visit Victoria Hospital, as it is the largest government hospital in Raymond Mhlaba’s local municipality within ADM. The wastewater effluent from Victoria Hospital is directly discharged into nearby surface water, which residents rely on for agricultural and domestic purposes. A map of the sampling site is shown in Figure 2.

3.2. Collection of Samples and Isolation of Presumptive K. pneumoniae

Hospital effluents were aseptically obtained from different sections of Victoria Hospital in triplicates using 1 L sterile glass bottles. The samples were immediately transported to the Applied and Environmental Microbiology Research Group (AEMREG) laboratory at the University of Fort Hare in an ice box for microbiological analyses within 6 h of collection. The wastewater samples were serially diluted 10-fold to 10−6, and 100 mL aliquots of each dilution were filtered through a sterile membrane filter of 0.45 μm pore size (Sartorius, Gottingen, Germany). The filtrate was aseptically placed onto MacConkey agar in triplicates. All plates were incubated at 37 °C for 24 h for enumeration as colony-forming per 100 mL (CFU/mL). Afterwards, pink colonies on Mac-Conkey agar show lactose fermentation as presumptive of Klebsiella spp. The presumptive isolates were subcultured at 37 °C for 24 h on nutrient agar. The phenotypically pure positive Klebsiella spp. colonies were preserved in 20% glycerol stock at −80 °C for further analysis.

3.3. Genomic DNA Extraction

Bacterial DNA of the presumptive Klebsiella spp. was extracted as previously reported, with slight modifications [15]. Cells from the once-grown isolates on nutrient agar were inoculated into Luria Bertani (LB) broth at 37 °C for 24 h. The cultures were placed into sterile Eppendorf tubes (Biologix, Alondra Camarillo, CA, USA) and centrifuged (LASEC, Hong Kong, China) at 13,5000 rpm for 5 min to wash the cells. The supernatant was decanted, after which 500µL of sterile distilled water was included and vortexed for 2 min using VELP, Scientifica Inc., New York, NY, USA. To lyse the cells, the vortexed cells were placed in a heating block set at 100 °C for 10 min (Techne, London, UK) and subsequently cooled for 5 min on ice. The cell suspension was extracted using a mini-spin micro-centrifuge spun at 13,500 rpm for 5 min. A pipette was used to extract the supernatant, which serves as a template DNA, into sterile Eppendorf tubes for subsequent PCR assays and stored at −20 °C.

3.4. Molecular Confirmation of K. pneumoniae

The PCR assay was used to confirm the presumptive isolates using a Mycycler™ Thermal Cycler PCR system (Bio-Rad, T100 thermal cycler, Singapore) under the following conditions: an initial denaturation of 94 °C for 5 min; 35 cycles of 30 s at 94 °C, 45 s annealing at 55 °C, extension at 72 °C for 45 s and a final extension cycle of 72 °C for 10 min. A total reaction mixture of 25 μL consisting of 12.5 μL industrially synthesized master mix (Thermo Scientific, Waltham, MA, USA), 1 μL each of forward and reverse primers (Inqaba Biotech, Mawniya, Nigeria), 5.5 μL PCR grade water,4 μL template DNA. Agarose gel 1.5% and 0.5× TBE buffer, set at 100 V for 45 min, were used to carry out electrophoresis. The gel was stained with 4 μL ethidium bromide. A 100 bp DNA marker (Fermentas, Vilnius, Lithuania) was used to estimate the DNA band, which was then examined with a UV transilluminator (Alliance 4.7, UVITEC, Cambridge, UK). As a positive control, K. pneumoniae ATCC 35657 was used. Table 5 lists primers and reaction protocols used to confirm K. pneumoniae.

3.5. Antibiotics Susceptibility Testing

The antibiotic susceptibility patterns of all K. pneumonia isolates were evaluated according to the Kirby–Bauer disk diffusion method using Mueller–Hinton agar medium. The Clinical and Laboratory Standards Institute (CLSI) principles were used for this purpose. The K. pneumoniae isolates were subjected to 21 antimicrobial agents under 11 classes commonly used for treating infection caused by K. pneumoniae. The antimicrobial agents and their concentration used in this study are Fluoroquinolones: ciprofloxacin (CIP; 5 μg) and norfloxacin (NOR: 30 μg), Aminoglycoside: gentamicin (GM; 10 μg), amikacin (AK; 30 μg), Beta-lactam: amoxicillin/clavulanic acid (AUG; 30 μg), cefoxitin (FOX; 30 μg), ampicillin (AP; 10 μg), Sulfonamides: trimethoprim-sulfamethoxazole (TS; 25 μg); Beta-lactamase inhibitor: piperacillin/tazobactam (TZP), Nitrofurans: nitrofurantoin (NI; 300 μg); Carbapenem: imipenem (IMI; 10 μg), meropenem (MEM; 10 μg), doripenem (DOR; 10 µg), and ertapenem (ETP; 10 µg), Cephalosporins: ceftazidime (CAZ; 30 μg), cefotaxime (CTX; 30 μg) and cefuroxime (CXM; 30 μg); Quinolones: Nalidixic acid (NA; 30 μg), Phenicols: chloramphenicol (C; 30 μg); Tetracyclines: tetracycline (T; 30 μg) and doxycycline (DXT; 30 μg) (MAST, Merseyside, UK). The plates were incubated at 37 °C for 24 h after being inverted for 15 min. The inhibition zones were measured in millimetres and analyzed following the suggested criteria [18]. The isolates were classified as susceptible (S), intermediate (I), and resistant (R). K. pneumoniae ATCC 35657 was used as a control strain for the antimicrobial susceptibility tests. Multidrug resistance was evaluated as antimicrobial resistance to at least three or more classes.

3.6. Multiple Antibiotics Resistance Index (MARI) Analysis

The MARI was evaluated using the formula: MARI = a/b, where “a” is the number of antibiotics the isolates were resistant to, while “b” is the total number of antibiotics tested [19]. A MARI value greater than 0.2 indicates environmental sources with increased antibiotic misuse [20].

3.7. Molecular Detection of Resistance Genes

The presence of resistance genes in phenotypic antibiotics-resistant K. pneumoniae was evaluated using the conventional PCR technique with specific synthesized primers (Table S1). The targeted resistance genes include aminoglycosides (aph(3)-Ia(aphA1)a, aac(3)-IIa(aacC2)a, strA, aadA); quinolones (qnrA, qnrB, qnrS); tetracycline (tetA, tetB, tetC, tetD, tetK, tetM); carbapenems (blaVIM, blaIMP, blaOXA-48-like, blaNDM-1, blaKPC); beta-lactams (blaGES, blaVEB, PER, blaSHV, blaTEM, blaOXA-1-like, blaCTX-M-9, blaCTX-M-2, blaCTX-M-1), sulphonamides (sul1 and sul2), phenicol (cat1 and cat11). Resistance genes were selected according to their prevalence in phenotypically resistant K. pneumoniae isolates.

3.8. Statistical Analysis

The Statistical Package for Social Sciences (SPSS) IBM version 20 software was used for statistical analysis. Pearson’s correlation test was employed to compare the associations between resistance genes, with p < 0.05 as the statistical significance level.

4. Discussion

Hospital environments are crucial breeding grounds for antibiotic-resistance microorganisms and resistance genes. Consequently, antimicrobial resistance in hospital effluents is a significant health issue due to the ease of transmission to humans via contaminated water used for many purposes, such as consumption, irrigation, and recreation. Thus, water significantly contributes to the dissemination and consistency of antimicrobial-resistant pathogens and their affiliated potential health threats. Hospital wastewater harbours many bacterial pathogens that are eventually channelled into surface water without proper treatment. The overall prevalence rate of confirmed K. pneumoniae isolates obtained in this study was relatively high (86.3%); this could result from antibiotics consumed by hospitalized patients and their subsequent release into the environment. This study’s high detection of K. pneumoniae reveals the extent of hospital wastewater effluent contamination by this nosocomial pathogen. Another study in South Africa isolated K. pneumoniae from hospital wastewater effluent and recorded a close prevalence rate of 78.8% [21]. Meanwhile, this discovery contradicts other studies with low hospital incidence rates [22,23].
This study observed a high abundance of phenotypic antibiotics-resistant K. pneumoniae, which calls for serious concern. The environment’s high level of resistant bacteria represents the uncontrolled and excessive usage of antibiotics [24]. β-lactams are the primary therapeutic option for treating K. pneumoniae infections. The high resistance rate of 86.2% against ampicillin, a beta-lactam, is similar to other studies that found increased resistance to ampicillin [25,26,27]. The other beta-lactam antibiotics in this study, amoxicillin/clavulanic acid and cefoxitin, had a relatively low resistance of 19.3% and 12.4%, respectively. Aminoglycosides act by binding to bacterial ribosomes to prevent protein production from commencing. The consumption of aminoglycosides has been curtailed due to long-term use associated with kidney and auditory nerve damage, leading to hearing impairment [28]. In agreement with this finding, K. pneumoniae showed a low resistance rate against gentamicin and amikacin compared to previous studies [29,30]. This study’s low resistance to aminoglycosides could be due to its reduced usage. Similar to this study, a resistance rate of 38.6% against amikacin was reported among carbapenem-resistant Klebsiella pneumoniae isolates in China [31].
Chloramphenicol inhibits protein synthesis by binding to the ribosomes. Moreover, chloramphenicol is associated with developing aplastic anaemia in humans, hence the ban on its usage [32]. This study’s resistance rate to chloramphenicol (23.5%), similar to another study’s reported rate in Bangladesh [33], could likewise be due to its prohibition. In this study, K. pneumoniae isolates showed a reduced resistance rate to carbapenems. However, an average percentage of isolates were reported to be resistant to ertapenem (47.6%), imipenem (42.9%), and meropenem (42.9%) in another study [34]. Similar to a study in Saudi Arabia, resistance to imipenem (3.4%) was the weakest [26]. Meanwhile, cephalosporin resistance was discovered in close to half of the isolates in this study, including ceftazidime (41.4%), cefotaxime (48.3%), and cefuroxime (46.2%). This is higher than the findings from another study that isolated K. pneumoniae from cow milk [30]. Rabbani et al. [33] reported a moderate resistance rate against cefotaxime (45%) and ceftazidime (38%), similar to this study. Moreover, Manikandan and Amsath observed a similar resistance rate to ceftazidime (45.8%) [35]. Moderate resistance to tetracycline (69.0%), doxycycline (56.6%), trimethoprim-sulfamethoxazole (40.7%), nalidixic acid (33.8%) were observed in this study. The increased resistance rate of these antibiotics classes in this study could be attributed to common drug abuse in health care.
Carbapenems have the highest susceptibility rate in this study, with varied susceptibility rates against imipenem (94.5%), ertapenem (87.6%), doripenem (76.6%) and meropenem (76.6%). Other studies have also recorded high susceptibility rates of 85.64% against meropenem and 63.61% for imipenem [25,36]. In a similar report, K. pneumoniae isolates showed high susceptibility to imipenem [21,33]. Low resistance rates of 35% and 34% to ertapenem and meropenem, which contradicts our findings, have been reported elsewhere in South Africa [37]. The susceptibility rate against fluoroquinolones (ciprofloxacin 79.3% and norfloxacin 86.2%) and Nitrofurans (Nitrofurantoin 71.7%) is similar to another report [10]. In this study, aminoglycosides (amikacin and gentamicin) exhibited a high susceptibility rate, in line with an earlier study [38].
The widespread usage of antimicrobial agents has resulted in a high incidence of MDR K. pneumoniae strains [39]. The present research reveals multidrug resistance to various antimicrobials ranging between three and ten antibiotics classes in 82.7% of K. pneumoniae isolates with a MARI range of 0.14–1.0. The MARI range indicates a significant environmental source of contamination. The high prevalence of MDR K. pneumoniae in this study also demonstrates the potential dangers of K. pneumoniae spreading from hospital sources. A similar occurrence of MDR was reported in other studies [10,20,26,40,41].
The current study used a PCR-based technique to characterize antimicrobial resistance genes in K. pneumoniae isolates from hospital effluents. Many studies have revealed that antibiotics resistance genes (ARGs) are spread due to polluted environmental sources [42,43]. Some essential resistance genes in clinical and environmental settings have been initially documented in K. pneumoniae [44,45]. Carbapenem was the drug of last resort for treating MDR infections until recently, when its efficacy was diminished due to its widespread misuse. One of the essential antibiotic resistance mechanisms is carbapenemase production. However, our study revealed a low percentage of K. pneumoniae isolates harbouring carbapenem genes, with varied rates as follows; blaIMP (9.8%), blaKPC (5.8%), blaNDM-1 (3.9%), blaVIM (1.9%), blaOXA-48 (1.9%). This study’s low occurrence of carbapenem genes could be due to the earlier report on the decrease in resistance level to carbapenem antibiotics, as shown in Figure 1. Our findings are consistent with other studies that show a low overall prevalence of carbapenem genes [37,46]. However, this study’s observable low incidence of carbapenem genes contradicts a report in another study where blaOXA was abundant in hospital wastewater [47]. Meanwhile, in another study, the rates for blaNDM-1 and blaOXA-48 were 33.3% and 66.7%, respectively [34]. The presence of blaIMP in this study is comparable to research that examined carbapenem genes in clinical samples [48]. Findings on carbapenem genes in Gram-negative strains have been compiled across the globe, such as in Kenya [49], Uganda [50], Egypt [51], South Africa [52], Iraq [53], and the Philippines [54] with varying prevalence.
Sulphonamides inhibit dihydropteroate synthetase, an enzyme that uses para-aminobenzoic acid (PABA) as a substrate to produce folic acid. Sulphonamide genes (sul1 and sul11) were detected, with sulI (68.4%) and sulI1 (66.6%) common in our isolates. In 60% of the isolates, both genes were found, which indicates a possible abuse of the sulphonamides class of antibiotics. This study’s high abundance of sul11 is similar to another study in South Africa [55]. The most commonly used antibiotics are beta-lactams due to their low toxicity and use in treating many infections. Nonetheless, the gravity of their resistance cannot be overemphasized. They have minimal side effects and are utilized to treat various infectious diseases. BlaTEM (16.90%) is the most common beta-lactamase gene in this study, while blaSHV (12.67%) is more common than blaCTXM-1 (9.15%). The least prevalent beta-lactam gene is blaCTXM-2, with an occurrence of 0.7%. Folake et al. reported blaTEM as the most abundant beta-lactam gene [55]. Other studies have noted several beta-lactamase genes and reported them in bacteria isolates [55,56,57].
With the advent of tetracycline, tetracycline-resistant bacteria became widespread in the environment. Out of six tetracycline genes screened, the tetA (58.82%) gene had the highest occurrence, followed by tetD (47.89%) and tetM (25.21%). Other varied resistance rates are as follows; tetK (10.92%), tetB (5.88% and tetC (3.36%). The abundance of these genes in the aquatic ecosystem may be due to effluent influx and uncontrolled sewage discharge. Other studies have reported tetracycline genes in marine ecosystems [55,56,58].
Among the aminoylsocide-resistant K. pneumoniae isolates, the most prevalent resistant gene is aadA (62.3%), while strA and aac(3)-IIa(aacC2)a has resistance rate of 26% and 14.4%, respectively. A higher prevalence rate of 43.1% was reported for aac(3)-IIa(aacC2)a in another study in Spain. The combination of strA-aadA was observed in 15% of isolates, while aadA–aac(3)-11a(aac(2)a was found in 10% of isolates. However, strA–aadA–aac(3)-11a(aac(2)a had the least rate of occurrence at 4%. In this study, qnrA was the most dominant quinolone gene, found in 15.6% of K. pneumoniae isolates with phenotypic resistance to quinolones. In comparison, qnrB was found in 12% of the isolates. No isolate in this study harboured qnrS. Notwithstanding this, in another study, qnrS was the most frequently observed quinolone gene [34].
Numerous phenicol genes are abundant in the environment. In this study, K. pneumoniae isolates resistant to chloramphenicol were screened for cat1, cat11 and cmlA. A similarly low rate of cat11 and cat1 was reported in another study, which could have resulted from the restrictions on the abuse of chloramphenicol [56]. None of the isolated strains harboured the cmla gene, and dual chloramphenicol resistance genes were not recorded in this study. There were strong statistical associations between K. pneumoniae resistance genes, as shown in Table 4. Most of the resistance determinants of K. pneumoniae isolates showed a strong and significant association.
In conclusion, there is an alarming presence of MDR K. pneumoniae isolates in hospital wastewater effluent in the study area. However, our findings indicated a possible link between multidrug resistance development in hospital sewage and the disposal of untreated hospital waste. Nonetheless, an attempt must be made to avert the unhygienic disposal of waste harbouring antibiotics into the environment via hospital drainage channels. This necessitates immediate intervention through a proper surveillance program as well as adequate treatment of wastewater before discharge to surface water and subsequent human consumption. K. pneumoniae isolates showed high sensitivity to carbapenems and harboured few carbapenem resistance genes; thus, carbapenem could be used for treating K. pneumoniae infections. This study revealed a noticeable collaboration of phenotypic resistance with the genotypic expression of resistance genes. Single and multiple resistance genes were also reported among the phenotypic-resistant K. pneumoniae isolates. Future studies should focus on genotypic resistance gene evaluation. We anticipate that this study’s findings will help establish a foundation for future scientific research in South Africa regarding the burden of MDR K. pneumoniae in the environment and its public health consequences.

Supplementary Materials

The following supporting information can be downloaded at: https://www.mdpi.com/article/10.3390/antibiotics12071139/s1, Table S1: Primer sequences of targeted resistance genes with their respective amplicon sizes and PCR cycling conditions. References [59,60,61,62,63,64,65,66] are cited in the supplementary materials; Figure S1: Agarose gel electrophoresis showing confirmed Klebsiella spp. (gyrA). Lane M: 100 bp DNA ladder, lane 1: Positive control (K. pneumonie ATCC 35657), lane 2: Negative control lane 3–10 positive Klebsiella spp. Isolates; Figure S2: Agarose gel electrophoresis showing confirmed Klebsiella pneumonie (magA). Lane M: 100 bp DNA ladder, lane 1: Positive control (K. pneumonie ATCC 35657), lane 2: Negative control, lane 3–11 positive K. pneumonie isolates; Figure S3: A representative gel electrophoresis profile of some antimicrobial resistance genes of K. pneumonie isolates. Lanes M and 12: molecular weight marker (Thermo Scientific 100 bp DNA ladder), lane 1: negative control, lane 2: tetA (201bp), lane 3: tetB, (659bp), lane 4: tetC (418 bp), lane 5: tetD (787 bp), lane 6: tetK (750 bp), lane 7: sul1 (722 bp), lane 8: sul11 (256 bp), lane 9: aac(3)-IIa(aacC2)a (428 bp), lane 10: strA (348 bp), and lane 11: aadA (318 bp); Figure S4: A representative gel electrophoresis profile of some antimicrobial resistance genes of K. pneumonie isolates. Lanes M: molecular weight marker (Thermo Scientific 100 bp DNA ladder), lane 1: negative control, lane 2: blaSHV (713bp), lane 3: blaoxa-1-like (564bp), lane 4: blaIMP (139 bp), lane 5: blaKPC (301 bp), lane 6: blaNDM-1 (251 bp), lane 7: blaOXA-48 (281 bp), lane 8: blaTEM (800 bp), lane 9: blaCTXM-9 (561 bp); Figure S5: A representative gel electrophoresis profile of some antimicrobial resistance genes of K. pneumonie isolates. Lane M: molecular weight marker (Thermo Scientific 100 bp DNA ladder), lanes 1 and 2: blaCTXM-1 (688bp), lanes 3 and 4: qnrB (469bp), lane 5: cat11 (543bp), lane 6: blaVIM (390 bp), lane 7: cat1 (320 bp), lane 8: negative control.

Author Contributions

J.U.O. and U.U.N. planned and designed the experiments; J.U.O. performed the experiments; U.U.N. analysed the data. All authors contributed to the writing and editing of the manuscript. All authors have read and agreed to the published version of the manuscript.

Funding

The research was supported by the NRF-TWAS bursary support (Grant Number: 139049) and the Medical Research Council research grant.

Institutional Review Board Statement

Not applicable.

Informed Consent Statement

Not applicable.

Data Availability Statement

Further information will be provided on request.

Acknowledgments

We would like to thank the University of Fort Hare and the Patho-Biocatalysis Group (PBG).

Conflicts of Interest

The authors declare no conflict of interest.

References

  1. Initiatives for Addressing Antimicrobial Resistance in the Environment: Current Situation and Challenges. 2018. Available online: https://wellcome.ac.uk/sites/default/files/antimicrobial-resistance-environment-report.pdf (accessed on 11 June 2023).
  2. Adekanmbi, A.O.; Akinpelu, M.O.; Olaposi, V.; Oyelade, A.A. Extended spectrum beta-lactamase encoding gene-fingerprints in multidrug resistant Escherichia coli isolated from wastewater and sludge of a hospital treatment plant in Nigeria. Int. J. Environ. Stud. 2020, 78, 140–150. [Google Scholar] [CrossRef]
  3. Olufemi, O.; Id, A.; Ikhimiukor, O.O.; Knecht, C. A survey of extended-spectrum beta-lactamase-producing Enterobacteriaceae in urban wetlands in southwestern Nigeria as a step towards generating prevalence maps of antimicrobial resistance. PLoS ONE 2020, 15, e0229451. [Google Scholar] [CrossRef]
  4. Banjo, O.A.; Adekanmbi, A.O.; Oyelade, A.A. Occurrence of CTX-M, SHV and TEM β-lactamase genes in Extended Spectrum Beta-Lactamase (ESBL)-producing baacccteria recovered from wastewater of a privately-owned hospital in Nigeria and a hand-dug well within its vicinity. Gene Rep. 2020, 21, 100970. [Google Scholar] [CrossRef]
  5. Malik, B.; Bhattacharyya, S. Antibiotic drug-resistance as a complex system driven by socio-economic growth and antibiotic misuse. Sci. Rep. 2019, 9, 9788. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  6. WHO. WHO|Antimicrobial Resistance: Global Report on Surveillance 2014. WHO [Internet]. 2016. Available online: http://www.who.int/drugresistance/documents/surveillancereport/en/ (accessed on 2 November 2020).
  7. Department of Health Republic of South Africa. South Africa Antimicrobial Resistance National Strategy Framework 2017–2024; Department of Health: Pretoria, South Africa; Department of Agriculture, Forestry and Fisheries: Pretoria, South Africa, 2018; pp. 1–23.
  8. Mirzaie, A.; Ranjbar, R. Antibiotic resistance, virulence-associated genes analysis and molecular typing of Klebsiella pneumoniae strains recovered from clinical samples. AMB Express 2021, 11, 122. [Google Scholar] [CrossRef]
  9. Reed, D.; Kemmerly, S.A. Infection Control and prevention: A review of hospital-acquired infections and the economic implications. Ochsner J. 2009, 9, 27–31. [Google Scholar]
  10. Hasan, M.; Hossain, M.K.; Rumi, N.A.; Rahman, M.S.; Hosen, M.A. Isolation and characterization of multiple drug-resistant bacteria from the waste of hospital and non-hospital environment. Asian J. Med. Biol. Res. 2020, 6, 460–468. [Google Scholar] [CrossRef]
  11. Weiss, A.; Dym, H. Review of Antibiotics and Indications for Prophylaxis. Dent. Clin. N. Am. 2012, 56, 235–244. Available online: https://linkinghub.elsevier.com/retrieve/pii/S0011853211001091 (accessed on 28 September 2020). [CrossRef]
  12. Sato, S.; Aoyama, T.; Uejima, Y.; Furuichi, M.; Suganuma, E.; Takano, T.; Ikeda, M.; Mizoguchi, M.; Okugawa, S.; Moriya, K.; et al. Pyogenic liver abscess due to hypervirulent Klebsiella pneumoniae in a 14-year-old boy. J. Infect. Chemother. 2019, 25, 137–140. [Google Scholar] [CrossRef]
  13. Sapkota, A.R.; Curriero, F.C.; Gibson, K.E.; Schwab, K.J. Antibiotic-resistant enterococci and fecal indicators in surface water and groundwater impacted by a concentrated swine feeding operation. Environ. Health Perspect. 2007, 115, 1040–1045. [Google Scholar] [CrossRef] [Green Version]
  14. Hosu, M.C.; Vasaikar, S.; Okuthe, G.E.; Apalata, T. Molecular Detection of Antibiotic-Resistant Genes in Pseudomonas aeruginosa from Nonclinical Environment: Public Health Implications in Mthatha, Eastern Cape Province, South Africa. Int. J. Microbiol. 2021, 2021, 8861074. [Google Scholar] [CrossRef] [PubMed]
  15. Mapipa, Q.; Digban, T.O.; Nnolim, N.E.; Nwodo, U.U. Antibiogram profile and virulence signatures of Pseudomonas aeruginosa isolates recovered from selected agrestic hospital effluents. Sci. Rep. 2021, 11, 11800. [Google Scholar] [CrossRef] [PubMed]
  16. Brisse, S.; Verhoef, J. Phylogenetic diversity of Klebsiella pneumoniae and Klebsiella oxytoca clinical isolates revealed by randomly amplified polymorphic DNA, gyrA and parC genes sequencing and automated ribotyping. Int. J. Syst. Evol. Microbiol. 2001, 51, 915–924. [Google Scholar] [CrossRef] [PubMed]
  17. Liu, Y.; Liu, C.; Zheng, W.; Zhang, X.; Yu, J.; Gao, Q.; Hou, Y.; Huang, X. PCR detection of Klebsiella pneumoniae in infant formula based on 16S-23S internal transcribed spacer. Int. J. Food Microbiol. 2008, 125, 230–235. [Google Scholar] [CrossRef]
  18. CLSI. Performance Standards for Antimicrobial Susceptibility Testing, 30th ed.; CLSI Standard M100; Clinical and Laboratory Standards Institute: Wayne, PA, USA, 2020; Volume 40, pp. 50–51. [Google Scholar]
  19. Blasco, M.D.; Esteve, C.; Alcaide, E. Multiresistant waterborne pathogens isolated from water reservoirs and cooling systems. J. Appl. Microbiol. 2008, 105, 469–475. [Google Scholar] [CrossRef] [PubMed]
  20. Osundiya, O.O.; Oladele, R.O.; Oduyebo, O.O. Multiple Antibiotic Resistance (MAR) Indices of Pseudomonas and Klebsiella species Isolates in Lagos University Teaching Hospital. Afr. J. Clin. Exp. Microbiol. 2013, 14, 164–168. [Google Scholar] [CrossRef] [Green Version]
  21. Mapipa, Q.; Digban, T.O.; Nwodo, U.U. Antibiogram and detection of virulence genes among Klebsiella pneumoniae isolates from rustic hospital drains. Gene Rep. 2022, 26, 101440. [Google Scholar] [CrossRef]
  22. Cahill, N.; Connor, L.O.; Mahon, B.; Varley, Á.; Mcgrath, E.; Ryan, P.; Cormican, M.; Brehony, C.; Jolley, K.A.; Maiden, M.C.; et al. Hospital effluent: A reservoir for carbapenemase-producing Enterobacterales? Sci. Total Environ. 2019, 672, 618–624. [Google Scholar] [CrossRef]
  23. King, T.L.B.; Schmidt, S.; Essack, S.Y. Antibiotic resistant Klebsiella spp. from a hospital, hospital effluents and wastewater treatment plants in the uMgungundlovu District, KwaZulu-Natal, South Africa. Sci. Total Environ. 2020, 712, 135550. [Google Scholar] [CrossRef]
  24. Lateef, A. The microbiology of a pharmaceutical effluent and its public health implications. World J. Microbiol. Biotechnol. 2004, 20, 167–171. [Google Scholar] [CrossRef]
  25. Peneş, N.O.; Muntean, A.A.; Moisoiu, A.; Muntean, M.M.; Chirca, A.; Bogdan, M.A.; Popa, M.I. An overview of resistance profiles ESKAPE pathogens from 2010–2015 in a tertiary respiratory center in Romania. Rom. J. Morphol. Embryol. 2017, 58, 909–922. [Google Scholar] [PubMed]
  26. Lagha, R.; Ben Abdallah, F.; ALKhammash, A.A.H.; Amor, N.; Hassan, M.M.; Mabrouk, I.; Alhomrani, M.; Gaber, A. Molecular characterization of multidrug resistant Klebsiella pneumoniae clinical isolates recovered from King Abdulaziz Specialist Hospital at Taif City, Saudi Arabia. J. Infect. Public Health 2021, 14, 143–151. [Google Scholar] [CrossRef] [PubMed]
  27. Ranjbar, R.; Chehelgerdi, A.F.K.M. Molecular characterization, serotypes and phenotypic and genotypic evaluation of antibiotic resistance of the Klebsiella pneumoniae strains isolated from different types of hospital-acquired infections. Infect. Drug Resist. 2019, 12, 603–611. [Google Scholar] [CrossRef] [Green Version]
  28. Goñi-Urriza, M.; Capdepuy, M.; Arpin, C.; Raymond, N.; Pierre Caumette, C.Q. Impact of an urban effluent on antibiotic resistance of riverine Enterobacteriaceae and Aeromonas spp. Appl. Environ. Microbiol. 2000, 66, 125–132. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  29. Fernández-Martínez, M.; Ruiz Del Castillo, B.; Lecea-Cuello, M.J.; Rodríguez-Baño, J.; Pascual, Á.; Martínez-Martínez, L. Prevalence of Aminoglycoside-Modifying Enzymes in Escherichia coli and Klebsiella pneumoniae Producing Extended Spectrum β-Lactamases Collected in Two Multicenter Studies in Spain. Microb. Drug Resist. 2018, 24, 367–376. [Google Scholar] [CrossRef] [PubMed]
  30. Yang, Y.; Peng, Y.; Jiang, J.; Gong, Z.; Zhu, H.; Wang, K.; Zhou, Q.; Tian, Y.; Qin, A.; Yang, Z.; et al. Isolation and characterization of multidrug-resistant Klebsiella pneumoniae from raw cow milk in Jiangsu and Shandong provinces, China. Transbound. Emerg. Dis. 2020, 68, 1033–1039. [Google Scholar] [CrossRef]
  31. Huang, W.; Zhang, J.; Zeng, L.; Yang, C.; Yin, L.; Wang, J.; Li, J.; Li, X.; Hu, K.; Zhang, X.; et al. Carbapenemase Production and Epidemiological Characteristics of Carbapenem-Resistant Klebsiella pneumoniae in Western Chongqing, China. Front. Cell. Infect. Microbiol. 2022, 11, 775740. [Google Scholar] [CrossRef]
  32. Berendsen, B.; Stolker, L.; De Jong, J.; Nielen, M.; Tserendorj, E.; Sodnomdarjaa, R.; Cannavan, A.; Elliott, C. Evidence of natural occurrence of the banned antibiotic chloramphenicol in herbs and grass. Anal. Bioanal. Chem. 2010, 397, 1955–1963. [Google Scholar] [CrossRef] [Green Version]
  33. Rabbani, M.A.G.; Howlader, M.Z.H.; Kabir, Y. Detection of multidrug resistant (MDR) bacteria in untreated waste water disposals of hospitals in Dhaka City, Bangladesh. J. Glob. Antimicrob. Resist. 2017, 10, 120–125. [Google Scholar] [CrossRef]
  34. Al-agamy, M.H.; Aljallal, A.; Radwan, H.H.; Shibl, A.M. Characterization of carbapenemases, ESBLs, and plasmid-mediated quinolone determinants in carbapenem-insensitive Escherichia coli and Klebsiella pneumoniae in Riyadh hospitals. J. Infect. Public Health 2018, 11, 64–68. [Google Scholar] [CrossRef]
  35. Manikandan, C.; Amsath, A. Antibiotic susceptibility pattern of Klebsiella pneumoniae isolated from urine samples. Int. J. Curr. Microbiol. Appl. Sci. 2013, 2, 330–337. [Google Scholar]
  36. Ngoi, S.T.; Teh, C.S.J.; Chong, C.W.; Abdul Jabar, K.; Tan, S.C.; Yu, L.H.; Leong, K.C.; Tee, L.H.; AbuBakar, S. In vitro efficacy of flomoxef against extended-spectrum beta-lactamase-producing Escherichia coli and Klebsiella pneumoniae associated with urinary tract infections in Malaysia. Antibiotics 2021, 10, 181. [Google Scholar] [CrossRef] [PubMed]
  37. Ebomah, K.E.; Okoh, A.I. Detection of carbapenem-resistance genes in Klebsiella species recovered from selected environmental niches in the Eastern Cape Province, South Africa. Antibiotics 2020, 9, 425. [Google Scholar] [CrossRef]
  38. Prado, T.; Pereira, W.C.; Silva, D.M.; Seki, L.M.; Carvalho, A.P.D.A.; Asensi, M.D. Detection of extended-spectrum β-lactamase-producing Klebsiella pneumoniae in effluents and sludge of a hospital sewage treatment plant. Lett. Appl. Microbiol. 2008, 46, 136–141. [Google Scholar] [CrossRef]
  39. Ciccozzi, M.; Cella, E.; Lai, A.; De Florio, L.; Antonelli, F.; Fogolari, M.; Di Matteo, F.M.; Pizzicannella, M.; Colombo, B.; Dicuonzo, G.; et al. Phylogenetic Analysis of Multi-Drug Resistant Klebsiella pneumoniae Strains From Duodenoscope Biofilm: Microbiological Surveillance and Reprocessing Improvements for Infection Prevention. Front. Public Health 2019, 7, 219. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  40. Manjula, N.G.; Math, G.C.; Nagshetty, K.; Patil, S.A.; Gaddad, S.M.; Shivannavar, C.T. Antibiotic Susceptibility Pattern of ESβL Producing Klebsiella pneumoniae Isolated from Urine Samples of Pregnant Women in Karnataka. J. Clin. Diagn. Res. 2014, 8, 8–11. [Google Scholar] [CrossRef]
  41. Sakkas, H.; Bozidis, P.; Ilia, A.; Mpekoulis, G. Antimicrobial Resistance in Bacterial Pathogens and Detection of Carbapenemases in Klebsiella pneumoniae Isolates from Hospital Wastewater. Antibiotics 2019, 8, 85. [Google Scholar] [CrossRef] [Green Version]
  42. Zhang, X.X.; Zhang, T.; Fang, H.H.P. Antibiotic resistance genes in water environment. Appl. Microbiol. Biotechnol. 2009, 82, 397–414. [Google Scholar] [CrossRef]
  43. Tacão, M.; Correia, A.; Henriques, I. Resistance to broad-spectrum antibiotics in aquatic systems: Anthropogenic activities modulate the dissemination of blaCTX-M-like genes. Appl. Environ. Microbiol. 2012, 78, 4134–4140. [Google Scholar] [CrossRef] [Green Version]
  44. Mbelle, N.M.; Feldman, C.; Sekyere, J.O.; Maningi, N.E.; Modipane, L.; Essack, S.Y. Pathogenomics and Evolutionary Epidemiology of Multi-Drug Resistant Clinical Klebsiella pneumoniae Isolated from Pretoria, South Africa. Sci. Rep. 2020, 10, 1232. [Google Scholar] [CrossRef] [Green Version]
  45. Ferreira, R.L.; Da Silva, B.C.M.; Rezende, G.S.; Nakamura-Silva, R.; Pitondo-Silva, A.; Campanini, E.B.; Brito, M.C.A.; Da Silva, E.M.L.; De Melo Freire, C.C.; Da Cunha, A.F.; et al. High prevalence of multidrug-resistant Klebsiella pneumoniae harboring several virulence and β-lactamase encoding genes in a brazilian intensive care unit. Front. Microbiol. 2019, 10, 3198. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  46. Mairi, A.; Pantel, A.; Sotto, A.; Lavigne, J.P.; Touati, A. OXA-48-like carbapenemases producing Enterobacteriaceae in different niches. Eur. J. Clin. Microbiol. Infect. Dis. 2018, 37, 587–604. [Google Scholar] [CrossRef] [PubMed]
  47. Ng, C.; Tay, M.; Tan, B.; Le, T.; Haller, L.; Chen, H.; Koh, T.H.; Barkham, T.M.S.; Thompson, J.R.; Gin, K.Y. Characterization of Metagenomes in Urban Aquatic Compartments Reveals High Prevalence of Clinically Relevant Antibiotic Resistance Genes in Wastewaters. Front. Microbiol. 2017, 8, 2200. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  48. Adam, M.A.; Elhag, W.I. Prevalence of metallo-β-lactamase acquired genes among carbapenems susceptible and resistant Gram-negative clinical isolates using multiplex PCR, Khartoum hospitals, Khartoum Sudan. BMC Infect. Dis. 2018, 18, 4–9. [Google Scholar] [CrossRef]
  49. Poirel, L.; Walsh, T.R.; Cuvillier, V.; Nordmann, P. Multiplex PCR for detection of acquired carbapenemase genes. Diagn. Microbiol. Infect. Dis. 2011, 70, 119–123. [Google Scholar] [CrossRef]
  50. Zafer, M.M.; Al-agamy, M.H.; El-mahallawy, H.A.; Amin, M.A.; Ashour, M.S.E. Antimicrobial Resistance Pattern and Their Beta-Lactamase Encoding Genes among Pseudomonas aeruginosa Strains Isolated from Cancer Patients. Biomed. Res. Int. 2014, 2014, 101635. [Google Scholar] [CrossRef] [Green Version]
  51. Diab, M.; Fam, N.; El-said, M.; Defrawy, E.E.I.E. Occurrence of VIM-2 Metallo-ß-Lactamases in imipenem resistant and susceptible Pseudomonas aeruginosa clinical isolates from Egypt. Afr. J. Microbiol. Res. 2013, 7, 4465–4472. [Google Scholar] [CrossRef]
  52. Singh-moodley, A.; Perovic, O. Antimicrobial susceptibility testing in predicting the presence of carbapenemase genes in Enterobacteriaceae in South Africa. BMC Infect. Dis. 2016, 16, 536. [Google Scholar] [CrossRef] [Green Version]
  53. Ali, S.O.; Ali, F.A.; Anoar, K.A. Detection of Metallo Β-Lactamase Enzyme in Some Gram Negative Bacteria Isolated from Burn Patients in Sulaimani City, IRAQ Khanda Abdulateef Anoar. Eur. Sci. J. 2014, 10, 485–496. [Google Scholar]
  54. Suzuki, Y.; Nazareno, P.J.; Nakano, R.; Mondoy, M.; Nakano, A.; Bugayong, M.P.; Bilar, J.; Perez, M.; Medina, E.J.; Saito-Obata, M.; et al. Environmental Presence and Genetic Characteristics of Carbapenemase-Producing Enterobacteriaceae from Hospital Sewage and River Water in the Philippines. Appl. Environ. Microbiol. 2020, 86, e01906-19. [Google Scholar] [CrossRef] [Green Version]
  55. Fadare, F.T.; Adefisoye, M.A.; Okoh, A.I. Occurrence, identification, and antibiogram signatures of selected Enterobacteriaceae from Tsomo and Tyhume rivers in the Eastern Cape Province, Republic of South Africa. PLoS ONE 2020, 15, e0238084. [Google Scholar] [CrossRef] [PubMed]
  56. Titilawo, Y.; Obi, L.; Okoh, A. Antimicrobial resistance determinants of Escherichia coli isolates recovered from some rivers in Osun State, South-Western Nigeria: Implications for public health. Sci. Total Environ. 2015, 523, 82–94. [Google Scholar] [CrossRef] [PubMed]
  57. Thompson, S.A.; Maani, E.V.; Lindell, A.H.; King, C.J.; McArthur, J.V. Novel tetracycline resistance determinant isolated from an environmental strain of Serratia marcescens. Appl. Environ. Microbiol. 2007, 73, 2199–2206. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  58. Auerbach, E.A.; Seyfried, E.E.; McMahon, K.D. Tetracycline resistance genes in activated sludge wastewater treatment plants. Water Res. 2007, 41, 1143–1151. [Google Scholar] [CrossRef]
  59. Ellington, M.J.; Kistler, J.; Livermore, D.M.; Woodford, N. Multiplex PCR for rapid detection of genes encoding acquired metallo-β-lactamases. J. Antimicrob. Chemother. 2007, 59, 321–322. [Google Scholar] [CrossRef] [Green Version]
  60. Robicsek, A.; Strahilevitz, J.; Sahm, D.F.; Jacoby, G.A.; Hooper, D.C. qnr prevalence in ceftazidime-resistant Enterobacteriaceae isolates from the United States. Antimicrob. Agents Chemother. 2006, 50, 2872–2874. [Google Scholar] [CrossRef] [Green Version]
  61. Maynard, C.; Bekal, S.; Sanschagrin, F.; Levesque, R.C.; Brousseau, R.; Masson, L.; Larivière, S.; Harel, J. Heterogeneity among virulence and antimicrobial resistance gene profiles of extraintestinal Escherichia coli isolates of animal and human origin. J. Clin. Microbiol. 2004, 42, 5444–5452. [Google Scholar] [CrossRef] [Green Version]
  62. Srinivasan, V.; Gillespie, B.E.; Lewis, M.J.; Nguyen, L.T.; Headrick, S.I.; Schukken, Y.H.; Oliver, S.P. Phenotypic and genotypic antimicrobial resistance patterns of Escherichia coli isolated from dairy cows with mastitis. Vet. Microbiol. 2007, 124, 319–328. [Google Scholar] [CrossRef]
  63. Falbo, V.; Carattoli, A.; Tosini, F.; Pezzella, C.; Dionisi, A.M.; Luzzi, I. Antibiotic resistance conferred by a conjugative plasmid and a class I integron in Vibrio cholerae O1 El Tor strains isolated in Albania and Italy. Antimicrob. Agents Chemother. 1999, 43, 693–696. [Google Scholar] [CrossRef] [Green Version]
  64. Post, V.; Hall, R.M. AbaR5, a large multiple-antibiotic resistance region found in Acinetobacter baumannii. Antimicrob. Agents Chemother. 2009, 53, 2667–2671. [Google Scholar] [CrossRef] [Green Version]
  65. Ng, L.; Martin, I.; Alfa, M.; Mulvey, M. Multiplex PCR for the detection of tetracycline resistant genes. Mol. Cell. Probes 2001, 15, 209–215. [Google Scholar] [CrossRef] [PubMed]
  66. Strommenger, B.; Kettlitz, C.; Werner, G.; Witte, W. Multiplex PCR assay for simultaneous detection of nine clinically relevant antibiotic resistance genes in Staphylococcus aureus. J. Clin. Microbiol. 2003, 41, 4089–4094. [Google Scholar] [CrossRef] [PubMed] [Green Version]
Antibiotics 12 01139 g001 550
Figure 1. Susceptibility patterns of K. pneumoniae isolates.
Figure 1. Susceptibility patterns of K. pneumoniae isolates.
Antibiotics 12 01139 g001
Antibiotics 12 01139 g002 550
Figure 2. Map of Victoria Hospital sampling point.
Figure 2. Map of Victoria Hospital sampling point.
Antibiotics 12 01139 g002
Table
Table 1. Distribution of antimicrobial resistance genes among K. pneumoniae isolates.
Table 1. Distribution of antimicrobial resistance genes among K. pneumoniae isolates.
Antibiotics Resistance GenesTotal Positive (%)
Beta-Lactam (n = 142 isolates screened)
blaTEM24 (16.90)
blaSHV18 (12.67)
blaOXA-1-like2 (1.40)
blaCTX-M-113 (9.15)
blaCTX-M-21 (0.70)
blaCTX-M-94 (2.8)
Tetracycline (n = 119 isolates screened)
tetA70 (58.82)
tetB7 (5.88)
tetC4 (3.36)
tetD57 (47.89)
tetK13 (10.92)
tetM30 (25.21)
Carbapenem (n = 51 tested)
IMP5 (9.8)
VIM1 (1.9)
KPC3 (5.8)
NDM-12 (3.9)
OXA-481 (1.9)
Aminoglycoside (n = 69 tested)
strA18 (26.0)
aadA43 (62.3)
aac(3)-IIa(aacC2)a10 (14.4)
Sulphonamides (n = 57 tested)
sul139 (68.4)
sul238 (66.6)
Quinolones (n = 83 tested)
qnrA13 (15.6)
qnrB10 (12.0)
Phenicol (n = 36 tested)
cat12 (5.6)
cat1111 (30.5)
Table
Table 2. Patterns of dual and multiple resistance determinants tested in the antimicrobial-resistant K. pneumoniae isolates.
Table 2. Patterns of dual and multiple resistance determinants tested in the antimicrobial-resistant K. pneumoniae isolates.
Antimicrobial ClassAntimicrobial Resistance Determinants PatternTotal (%)
Beta-lactamblaCTXM-1–blaTEM4 (3)
blaCTXM-1–blaTEM–blaOXA-12 (1)
blaCTXM-1–blaSHV4 (3)
CarbapenemblaIMP–blaNDM-11 (2)
blaVIM–blaKPC1 (2)
blaIMP–blaOXA-481 (2)
AminoglycosidesstrA-aadA10 (15)
strA–aadA–aac(3)-11a(aac(2)a3 (4)
aadA–aac(3)-11a(aac(2)a7 (10)
Sulfonamidessul1-sul1134 (60)
QuinolonesqnrA-qnrB34 (41)
TetracyclinetetA-tetC4 (3)
tetA-tetB4 (3)
tetA-tetD41 (35)
tetA-tetK12 (10)
tetA-tetM16 (13)
tetD-tetM7 (6)
tetB-tetD1 (1)
tetA-tetB-tetK1 (1)
tetA-tetD-tetM9 (8)
tetA-tetD-tetK9 (8)
tetA-tetB-tetD1 (1)
tetD-tetK-tetM1 (1)
tetA-tetC-tetM2 (2)
tetA-tetC-tetD1 (1)
tetA-tetD-tetK-tetM4 (3)
Table
Table 3. MARI analysis.
Table 3. MARI analysis.
Number of Antibiotics Frequency (%)MARI
13 (2)0.05
24 (2.8)0.09
318 (12.6)0.14
414 (9.8)0.19
512 (8.5)0.24
618 (12.6)0.29
713 (9.2)0.33
88 (5.6)0.38
915 (10.6)0.43
108 (5.6)0.47
119 (6.3)0.52
129 (6.3)0.57
132 (1.4)0.62
143 (2.1)0.67
153 (2.1)0.71
171 (0.7)0.80
191 (0.7)0.90
201 (0.7)0.95
211 (0.7)1.0
Table
Table 4. Antimicrobial resistance genes association.
Table 4. Antimicrobial resistance genes association.
GenesSHVOXA-1CTXM-1CTXM-2CTXM-9tetAtetBtetCtetDtetKtetMIMPVIMKPCNDMOXA-48strAaadAaaC2sul1sul11qnrAqnrBcat1cat11
TEM−+++−+++++++++++++++++−−+++++++++++++++−++−−−+++++
SHV +++−+++++++++++++−−++++++++++++−++−++++−−+++−
OXA-1 ++−−+++−−++++++++−−−−−++++++++++++++++−+
CTXM-1 ++++++−++++−+−+++++++−+++−+++++−−++−
CTXM-2 −+++−−++++++++−−−−−++++++++++++++++−++
CTXM-9 +++−−+++++++−−−−−+++++−+++++++−−−
tetA ++++++−++++++++++++++++++++++++++++++++++++++++++++
tetB −+++−+++−−−−−++++−++++++−−−−
tetC −++++−−−−−+++++−+++++++−−−
tetD +++++++++++++++++++++++−+++−−++++++++++++
tetK +−+++++++−+++−++++++−−++−
tetM +++++++++++++++−−++−−++++++++
IMP −−−−++++_++++++−−−−
VIM −−−++++++++++++++++−++
KPC −−++++++−+++++++−−−
NDM −++++++++++++++++−+
OXA-48 +++++++++++++++++−++
strA ++−++++ −++−
aadA +++−−++++++++++++
aaC2 ++++++−−+−
sul1 −++++++++++++
sul11 +++++++++++
qnrA −++−
qnrB +−
cat1 ++
The associations of antimicrobial resistance genes at the p < 0.05 level are shown. The levels of significance of the association were as follows: −, p > 0.05; +, 0.05 ≥ p ≥ 0.01; ++, 0.01 ≥ p ≥ 0.001; and +++, 0.001 ≥ p.
Table
Table 5. Primer sequences and PCR cycling conditions.
Table 5. Primer sequences and PCR cycling conditions.
Target StrainTarget GenePrimer Sequence (51–31)PCR Cycling ConditionProduct Size (bp)Reference
Klebsiella genusgyrAF:CGCGTACTATACGCCATGAACGTA
R:ACCGTTGATCACTTCGGTCAGG		‘‘94 °C (5 min), 94 °C (30 s), 55 °C (45 s), 72 °C (45 s), 72 °C (10 min) × 35 cycles”441[16]
K. pneumoniaemagAF:ATTTGAAGAGGTTGCAAACGAT
R: TTCACTCTGAAGTTTTCTTGTGTTC		‘‘94 °C (5 min), 94 °C (30 s), 55 °C (30 s), 72 °C (45 s), 72 °C (10 min) × 30 cycles”130[17]
Disclaimer/Publisher’s Note: The statements, opinions and data contained in all publications are solely those of the individual author(s) and contributor(s) and not of MDPI and/or the editor(s). MDPI and/or the editor(s) disclaim responsibility for any injury to people or property resulting from any ideas, methods, instructions or products referred to in the content.

Share and Cite

MDPI and ACS Style

Okafor, J.U.; Nwodo, U.U. Molecular Characterization of Antibiotic Resistance Determinants in Klebsiella pneumoniae Isolates Recovered from Hospital Effluents in the Eastern Cape Province, South Africa. Antibiotics 2023, 12, 1139. https://doi.org/10.3390/antibiotics12071139

AMA Style

Okafor JU, Nwodo UU. Molecular Characterization of Antibiotic Resistance Determinants in Klebsiella pneumoniae Isolates Recovered from Hospital Effluents in the Eastern Cape Province, South Africa. Antibiotics. 2023; 12(7):1139. https://doi.org/10.3390/antibiotics12071139

Chicago/Turabian Style

Okafor, Joan U., and Uchechukwu U. Nwodo. 2023. "Molecular Characterization of Antibiotic Resistance Determinants in Klebsiella pneumoniae Isolates Recovered from Hospital Effluents in the Eastern Cape Province, South Africa" Antibiotics 12, no. 7: 1139. https://doi.org/10.3390/antibiotics12071139

Note that from the first issue of 2016, this journal uses article numbers instead of page numbers. See further details here.

Article Metrics

Back to TopTop
