J. Nucl. Eng., Volume 5, Issue 2 (June 2024) – 4 articles

The lifespan of core graphite under neutron irradiation in a commercial molten salt reactor (MSR) has an important influence on its economy. Flattening the fast neutron flux (≥0.05 MeV) distribution in the core is the main method to extend the graphite irradiation lifespan. In this paper, the effects of the key parameters of MSRs on fast neutron flux distribution, including volume fraction (VF) of fuel salt, pitch of hexagonal fuel assembly, core zoning, and layout of control rod assemblies, were studied. The fast neutron flux distribution in a regular hexagon fuel assembly was first analyzed by varying VF and pitch. It was demonstrated that changing VF is more effective in reducing the fast neutron flux in both global and local graphite blocks. Flattening the fast neutron flux distribution of a commercial MSR core was then carried out by zoning the core into two regions under different VFs. Considering both the fast neutron flux distribution and burnup depth, an optimized core was obtained. The fast neutron flux distribution of the optimized core was further flattened by the rational arrangement of control rod channels. The calculation results show that the final optimized core could reduce the maximum fast neutron flux of the graphite blocks by about 30% and result in a more negative temperature reactivity coefficient, while slightly decreasing the burnup and maintaining a fully acceptable core temperature distribution. Full article

When studying hazardous materials such as spent nuclear fuel (SNF), the minimisation of sample volumes is essential, together with the use of chemically-similar surrogates where possible. For example, the bulk behaviour of urania (UO₂) can be mimicked by appropriately-engineered thin films of sufficient thickness, and inactive materials such as ceria (CeO₂) can be used to study the effects within radioactive systems used to fuel nuclear fission. However, thin film properties are sensitive to the preparative method, many of which require the use of highly toxic precursors and specialised apparatus (e.g., chemical vapour deposition). To address this, we present the development of a flexible, tuneable, scalable method for the preparation of thin-film CeO₂ SIMFUEL models with a thickness of ≈5 μm. The effects of γ irradiation (up to 100 kGy) and dopants including trivalent lanthanides (Ln³⁺) and simulant ε-particles on the structure and long-term leaching of these systems under SNF storage conditions were explored, alongside the context of this within further work. It was found that the sensitivity of CeO₂ films to reduction upon irradiation, particularly in the presence of simulant ε-particles, resulted in increased leaching of Ce (as Ce^III), while trivalent lanthanides (Nd³⁺ and Eu³⁺) had a minimal effect on Ce leaching. Full article

Reliability and efficiency of valves are necessary for precise control and sufficient heat-flow to heat application plants for the integrated energy systems of nuclear power plants (NPPs). Strategic Management Analysis Requirement and Technology (SMART) valves’ ability to control flow and assess environmental parameters stands out for these requirements. Their ability to sustain the downstream flow rate, prevent reverse flow, and maintain pressure in the heat transport loop is much more efficient with the integration of sensors and intelligent algorithms. For assessing valve performance and monitoring, mechanical design and operating conditions are two important parameters. In this study, the butterfly valves of three different sizes are simulated with water and steam using STAR-CCM+ in various flow regimes and positions to analyze performance parameters to strategize an automated control system for efficiently balancing the heat–transport network. Also, flow behavior is studied using velocity and pressure fields for valve–body geometry optimization. It can be observed, through performance parameters, that the valves are suitable for operation between 30° and 90° positions with significantly low loss coefficients and high flow coefficients, and the performance parameters follow a certain pattern in both water and steam flow in each scenario. Full article

The development of compact neutron sources for applications is extensive and features many approaches. For ion-based approaches, several projects with different parameters exist. This article focuses on ion-based neutron production below the spallation barrier for proton and deuteron beams with arbitrary energy distributions with kinetic energies from 3 $\mathrm{M}$$\mathrm{e}\mathrm{V}$ to 97 $\mathrm{M}$$\mathrm{e}\mathrm{V}$. This model makes it possible to compare different ion-based neutron source concepts against each other quickly. This contribution derives a predictive model using Monte Carlo simulations (an order of 50,000 simulations) and deep neural networks. It is the first time a model of this kind has been developed. With this model, lengthy Monte Carlo simulations, which individually take a long time to complete, can be circumvented. A prediction of neutron spectra then takes some milliseconds, which enables fast optimization and comparison. The models’ shortcomings for low-energy neutrons (<$0.1 \mathrm{M}\mathrm{e}\mathrm{V}$) and the cut-off prediction uncertainty ($\pm 3 \mathrm{M}\mathrm{e}\mathrm{V}$) are addressed, and mitigation strategies are proposed. Full article
