Special Issue Information

Dear Colleagues,

The primary goal of this Special Issue is to present recent trends in surface inspection and description, from both metrological and tribological points of view. Various research problems dedicated to surfaces in different scales will be discussed. An important part of that is the techniques and methods that are and may be used for surface inspection and digitization (including free-form surfaces). These aspects are particularly important for Industry 4.0 and its purely metrological part, Metrology 4.0. Moreover, since we discuss topics related to measurements, uncertainty aspects need to be presented to know how satisfactory the accuracy of measurement is. Another important topic is the separation of different frequencies, i.e., different ideas of filtration and multiscale approach to analysis, including artificial intelligence. This is particularly important for bodies in contact, where tribological behavior and chemical processes on the surface are to be considered. Last but not least, surfaces are important in many different fields of science, often far beyond engineering topics. For this reason, all contributions closely related to applications are also welcome.

We welcome the submission of research papers as well as review articles. The research topics that we would like contributors to address include but are not limited to the following:

Surfaces in different scales: micro, meso, and macro;
Free-form surfaces and digitization;
Description of surfaces;
Modeling of surface topographies and profiles;
Multiscale analysis of surfaces;
Artificial intelligence issues for surfaces;
Techniques and methods of surface inspection;
Uncertainty in evaluation of surface features and parameters;
Tribological behavior of surfaces;
Applications of functional surfaces from engineering and non-engineering disciplines;
Surfaces and Industry 4.0.

Prof. Michal Wieczorowski
Prof. Dr. Maxence Bigerelle
Prof. Chris Brown
Prof. Pawel Pawlus
Prof. Rafał Reizer
Prof. Dr. Alejandro Pereira
Guest Editors

Manuscript Submission Information

Manuscripts should be submitted online at www.mdpi.com by registering and logging in to this website. Once you are registered, click here to go to the submission form. Manuscripts can be submitted until the deadline. All submissions that pass pre-check are peer-reviewed. Accepted papers will be published continuously in the journal (as soon as accepted) and will be listed together on the special issue website. Research articles, review articles as well as short communications are invited. For planned papers, a title and short abstract (about 100 words) can be sent to the Editorial Office for announcement on this website.

Submitted manuscripts should not have been published previously, nor be under consideration for publication elsewhere (except conference proceedings papers). All manuscripts are thoroughly refereed through a single-blind peer-review process. A guide for authors and other relevant information for submission of manuscripts is available on the Instructions for Authors page. Materials is an international peer-reviewed open access semimonthly journal published by MDPI.

Please visit the Instructions for Authors page before submitting a manuscript. The Article Processing Charge (APC) for publication in this open access journal is 2600 CHF (Swiss Francs). Submitted papers should be well formatted and use good English. Authors may use MDPI's English editing service prior to publication or during author revisions.

Keywords

surface metrology
tribology
wear
coordinate measuring techniques
scanning
surface modeling

Related Special Issue

Surface Inspection and Description in Metrology and Tribology (Second Volume) in Materials (12 articles)

Published Papers (13 papers)

Download All Papers

Editorial

Jump to: Research, Review

6 pages, 230 KiB

Open AccessEditorial

Surface Inspection and Description in Metrology and Tribology—Vol.1

by Michal Wieczorowski, Maxence Bigerelle, Chris Brown, Pawel Pawlus, Rafal Reizer and Alejandro Pereira

Materials 2022, 15(16), 5636; https://doi.org/10.3390/ma15165636 - 16 Aug 2022

Cited by 4 | Viewed by 1302

Abstract

The primary goal of this Special Issue was to present recent trends in surface inspection and description, from both metrological and tribological points of view [...] Full article

(This article belongs to the Special Issue Surface Inspection and Description in Metrology and Tribology)

Research

Jump to: Editorial, Review

11 pages, 4666 KiB

Open AccessArticle

Changes in Microstructure and Abrasion Resistance during Miller Test of Hadfield High-Manganese Cast Steel after the Formation of Vanadium Carbides in Alloy Matrix

by Grzegorz Tęcza

Materials 2022, 15(3), 1021; https://doi.org/10.3390/ma15031021 - 28 Jan 2022

Cited by 6 | Viewed by 2045

Abstract

Hadfield cast steel is characterized by high wear resistance, but this is only when it is subjected to the effect of dynamic loads. During unloaded abrasion, e.g., sand abrasion, its wear resistance is very low and comparable to the wear of carbon cast steel. To increase the wear resistance of this alloy for operation under the conditions of low pressure or low stress, primary vanadium carbides were produced by the metallurgical process to obtain a two-phase structure after alloy solidification. Compared to samples made of Hadfield cast steel, the primary, very hard carbides, evenly distributed in an austenitic or austenitic-martensitic matrix, increase (at least three times) the wear resistance of samples tested in an abrasive mixture of silicon carbide and water. The changes in microstructure and hardness obtained in alloys after heat treatment (quenching at 1000–1150 °C in water and tempering at 600 °C) are presented. The bulk hardness of the matrix ranged from 370 HV to 660 HV. After heat treatment, the secondary, dispersed vanadium carbides, precipitated in the alloy matrix. Full article

(This article belongs to the Special Issue Surface Inspection and Description in Metrology and Tribology)

► Show Figures

Figure 1

18 pages, 50842 KiB

Open AccessArticle

Effect of Surface Texture on the Structural Adhesive Joining Properties of Aluminum 7075 and TEPEX^®

by Alejandro Pereira, María Fenollera, Teresa Prado and Michal Wieczorowski

Materials 2022, 15(3), 887; https://doi.org/10.3390/ma15030887 - 24 Jan 2022

Cited by 4 | Viewed by 2204

Abstract

In the process of continuous improvement of manufacturing processes, this study was developed within the framework of the Ecovoss project, based on the inclusion of lightweight and new materials parts in the automotive sector. The objective was based on the replacement of aluminum welding operations with the option of adhesive operations with other types of materials such as polyamides or, in this case, a TEPEX^® composite material (Dynalite 202-c200/50% TYP 13). The aim of this work is to test the best texturing of substrate made in 7075 aluminum specimens manufactured by robotic polishing with an ABB 6640 robot. Another substrate is TEPEX composite. A structural adhesive film AF-163-2 from the 3M company (St Paul, MN, USA) is used, which must be applied according to the manufacturing procedure. The tests carried out are based on the topographic measurement of the surfaces to be joined with an Alicona focus variation microscope, and the uniaxial shear tests of adhesive samples have been analyzed. The texture of the surface failure has been analyzed, and the results confirm a significant correlation between the texture parameters of initial surfaces and maximum shear stress. The expected results should provide a better understanding of the surfaces aimed to optimize the adhesion of the studied materials. Full article

(This article belongs to the Special Issue Surface Inspection and Description in Metrology and Tribology)

► Show Figures

Figure 1

13 pages, 6450 KiB

Open AccessArticle

Analysis of the Cutting Abilities of the Multilayer Grinding Wheels—Case of Ti-6Al-4V Alloy Grinding

by Dariusz Lipiński, Kamil Banaszek and Łukasz Rypina

Materials 2022, 15(1), 22; https://doi.org/10.3390/ma15010022 - 21 Dec 2021

Cited by 7 | Viewed by 2233

Abstract

This paper presents an effectiveness analysis of the grinding process with the use of a new multi-layer abrasive tool. The designed abrasive tool consists of external layers with a conventional structure, whose task is to decrease the grinding wheel load and ensure high grinding volumetric efficiency. The inner layer of the grinding wheel contains a 30% addition of abrasive aggregates. The task of the inner layer is to provide lower roughness of the machined surface. The aim of the research presented in this paper was to evaluate the topography of the designed abrasive tool and to analyze the middle layer properties influencing the machined surface roughness. The differentiation of the active surface features of the abrasive tool was determined for the conventional layer and the layer with the addition of abrasive aggregates. The machining potential of the layers was also determined using the Shos parameter. The surface topography of Ti-6Al-4V alloys ground with the use of a multi-layer wheel and a conventional grinding wheel was analyzed. With the application of the bootstrap hypothesis, the set of roughness parameters differentiating the topography of ground surfaces was determined. Full article

(This article belongs to the Special Issue Surface Inspection and Description in Metrology and Tribology)

► Show Figures

Figure 1

14 pages, 42721 KiB
