Special Issue Information

Dear Colleagues,

A large group of materials called ferroics exhibit spontaneous polarization, magnetization, or strain below a certain transition temperature, the Curie point. These materials, being multifunctional in nature, allow for a variety of coupling effects to exist, ranging from magneto capacitance to piezo magnetism. With the advent of novel techniques based on Scanning Probe Microscopy (SPM), it became possible to study ferroelectric, ferromagnetic, and ferroelastic phenomena at the nanoscale with a resolution of a few nanometers. SPM evolved from simple profilometry to a complex tool in order to track various ferroic phenomena (e.g., domain evolution) and it is now indispensable for studying emerging nanoscale materials, ranging from 2D graphene to ferroelectric thin films and nanowires. In this Special Issue, we solicit papers on various aspects of the application of SPM (such as Piezoresponse Force Microscopy, Magnetic Force Microscopy, Electric Force Micoscopy, Kelvin Probe Microscopy, etc.) to ferroic materials and composites on their bases. The coupling between polarization, magnetization, and strain at the nanoscale is an especially hot topic, and papers are welcome in this Special Issue. A priority will be given also to instrumentation methods, which are currently being improved to be used in order to increase both lateral resolution and sensitivity, as applied to ferroic materials.

Dr. Andrei Kholkin
Guest Editor

Manuscript Submission Information

Manuscripts should be submitted online at www.mdpi.com by registering and logging in to this website. Once you are registered, click here to go to the submission form. Manuscripts can be submitted until the deadline. All submissions that pass pre-check are peer-reviewed. Accepted papers will be published continuously in the journal (as soon as accepted) and will be listed together on the special issue website. Research articles, review articles as well as short communications are invited. For planned papers, a title and short abstract (about 100 words) can be sent to the Editorial Office for announcement on this website.

Submitted manuscripts should not have been published previously, nor be under consideration for publication elsewhere (except conference proceedings papers). All manuscripts are thoroughly refereed through a single-blind peer-review process. A guide for authors and other relevant information for submission of manuscripts is available on the Instructions for Authors page. Materials is an international peer-reviewed open access semimonthly journal published by MDPI.

Please visit the Instructions for Authors page before submitting a manuscript. The Article Processing Charge (APC) for publication in this open access journal is 2600 CHF (Swiss Francs). Submitted papers should be well formatted and use good English. Authors may use MDPI's English editing service prior to publication or during author revisions.

Keywords

Scanning Probe Microscopy
Ferroics
Domains

Published Papers (7 papers)

Download All Papers

Research

3431 KiB

Open AccessArticle

Influence of Oxygen Pressure on the Domain Dynamics and Local Electrical Properties of BiFe_0.95Mn_0.05O₃ Thin Films Studied by Piezoresponse Force Microscopy and Conductive Atomic Force Microscopy

by Kunyu Zhao, Huizhu Yu, Jian Zou, Huarong Zeng, Guorong Li and Xiaomin Li

Materials 2017, 10(11), 1258; https://doi.org/10.3390/ma10111258 - 01 Nov 2017

Cited by 3 | Viewed by 4190

Abstract

In this work, we have studied the microstructures, nanodomains, polarization preservation behaviors, and electrical properties of BiFe_0.95Mn_0.05O₃ (BFMO) multiferroic thin films, which have been epitaxially created on the substrates of SrRuO₃, SrTiO₃, and TiN-buffered (001)-oriented Si at different oxygen pressures via piezoresponse force microscopy and conductive atomic force microscopy. We found that the pure phase state, inhomogeneous piezoresponse force microscopy (PFM) response, low leakage current with unidirectional diode-like properties, and orientation-dependent polarization reversal properties were found in BFMO thin films deposited at low oxygen pressure. Meanwhile, these films under high oxygen pressures resulted in impurities in the secondary phase in BFMO films, which caused a greater leakage that hindered the polarization preservation capability. Thus, this shows the important impact of the oxygen pressure on modulating the physical effects of BFMO films. Full article

(This article belongs to the Special Issue Scanning Probe Microscopy of Ferroics)

► Show Figures

Figure 1

2575 KiB

Open AccessArticle

Application of Magnetic Force Microscopy for Investigation of Epitaxial Ferro- and Antiferromagnetic Structures

by Gennady M. Mikhailov, Anatoliy V. Chernykh and Lev A. Fomin

Materials 2017, 10(10), 1156; https://doi.org/10.3390/ma10101156 - 04 Oct 2017

Cited by 5 | Viewed by 3566

Abstract

Growing of epitaxial Fe₅₀Mn₅₀/Fe/Mo/R-sapphire films was performed with a new configuration of two in-plane easy axes of Fe(001)-layer magnetization in which application of annealing in a magnetic field forms an unidirectional anisotropy. The microstructures made from these films exhibited an exchange bias 25–35 G along an exchange field generated at antiferromagnet/ferromagnet (AFM/FM) interface. Magnetic force microscopy (MFM) experiments supported by micromagnetic calculations and magneto-resistive measurements allowed interpretation of the magnetic states of the Fe layer in these microstructures. The magnetic states of the iron layer are influenced more by crystallographic anisotropy of the Fe-layer than by unidirectional exchange anisotropy. Full article

(This article belongs to the Special Issue Scanning Probe Microscopy of Ferroics)

► Show Figures

Figure 1

4566 KiB

Open AccessFeature PaperArticle

The Formation of Self-Organized Domain Structures at Non-Polar Cuts of Lithium Niobate as a Result of Local Switching by an SPM Tip

by Anton Turygin, Denis Alikin, Yury Alikin and Vladimir Shur

Materials 2017, 10(10), 1143; https://doi.org/10.3390/ma10101143 - 28 Sep 2017

Cited by 15 | Viewed by 3527

Abstract

We have studied experimentally the interaction of isolated needle-like domains created in an array via local switching using a biased scanning probe microscope (SPM) tip and visualized via piezoelectric force microscopy (PFM) at the non-polar cuts of MgO-doped lithium niobate (MgOLN) crystals. It has been found that the domain interaction leads to the intermittent quasiperiodic and chaotic behavior of the domain length in the array in a manner similar to that of polar cuts, but with greater spacing between the points of bias application and voltage amplitudes. It has also been found that the polarization reversal at the non-polar cuts and domain interaction significantly depend on humidity. The spatial distribution of the surface potential measured by Kelvin probe force microscopy in the vicinity of the charged domain walls revealed the decrease of the domain length as a result of the partial backswitching after pulse termination. The phase diagram of switching behavior as a function of tip voltage and spacing between the points of bias application has been plotted. The obtained results provide new insight into the problem of the domain interaction during forward growth and can provide a basis for useful application in nanodomain engineering and development of non-linear optical frequency converters, data storage, and computing devices. Full article

(This article belongs to the Special Issue Scanning Probe Microscopy of Ferroics)

► Show Figures

Figure 1

6498 KiB

Open AccessArticle

Giant Strain and Induced Ferroelectricity in Amorphous BaTiO₃ Films under Poling

by Pegah Mirzadeh Vaghefi, Ali Baghizadeh, Armando A.C.S. Lourenço, Vitor S. Amaral and Andre L. Kholkin

Materials 2017, 10(9), 1107; https://doi.org/10.3390/ma10091107 - 20 Sep 2017

Cited by 1 | Viewed by 4013

Abstract

We report an effect of giant surface modification of a 5.6 nm thick BaTiO₃ film grown on Si (100) substrate under poling by conductive tip of a scanning probe microscope (SPM). The surface can be locally elevated by about 9 nm under −20 V applied during scanning, resulting in the maximum strain of 160%. The threshold voltage for the surface modification is about 12 V. The modified topography is stable enough with time and slowly decays after poling with the rate ~0.02 nm/min. Strong vertical piezoresponse after poling is observed, too. Combined measurements by SPM and piezoresponse force microscopy (PFM) prove that the poled material develops high ferroelectric polarization that cannot be switched back even under an oppositely oriented electric field. The topography modification is hypothesized to be due to a strong Joule heating and concomitant interface reaction between underlying Si and BaTiO₃. The top layer is supposed to become ferroelectric as a result of local crystallization of amorphous BaTiO₃. This work opens up new possibilities to form nanoscale ferroelectric structures useful for various applications. Full article

(This article belongs to the Special Issue Scanning Probe Microscopy of Ferroics)

► Show Figures

Graphical abstract

13571 KiB

Open AccessArticle

Magnetoelectric Force Microscopy on Antiferromagnetic 180^∘ Domains in Cr₂O₃

by Peggy Schoenherr, L. Marcela Giraldo, Martin Lilienblum, Morgan Trassin, Dennis Meier and Manfred Fiebig

Materials 2017, 10(9), 1051; https://doi.org/10.3390/ma10091051 - 07 Sep 2017

Cited by 17 | Viewed by 6638

Abstract

Magnetoelectric force microscopy (MeFM) is characterized as methodical tool for the investigation of antiferromagnetic domain states, in particular of the 180

^{\circ}

variety. As reference compound for this investigation we use Cr

_{2}

_{3}

. Access to the antiferromagnetic order is provided [...] Read more.

Magnetoelectric force microscopy (MeFM) is characterized as methodical tool for the investigation of antiferromagnetic domain states, in particular of the 180

^{\circ}

variety. As reference compound for this investigation we use Cr

_{2}

_{3}

. Access to the antiferromagnetic order is provided by the linear magnetoelectric effect. We resolve the opposite antiferromagnetic 180

^{\circ}

domain states of Cr

_{2}

_{3}

and estimate the sensitivity of the MeFM approach, its inherent advantages in comparison to alternative techniques and its general feasibility for probing antiferromagnetic order. Full article

(This article belongs to the Special Issue Scanning Probe Microscopy of Ferroics)

► Show Figures

Figure 1

3310 KiB

Open AccessArticle

Magnetic Force Microscopy of Nanostructured Co/Pt Multilayer Films with Perpendicular Magnetization

by O. L. Ermolaeva, N. S. Gusev, E. V. Skorohodov, Yu. V. Petrov, M. V. Sapozhnikov and V. L. Mironov

Materials 2017, 10(9), 1034; https://doi.org/10.3390/ma10091034 - 05 Sep 2017

Cited by 12 | Viewed by 6558

Abstract

We present the results of magnetic force microscopy investigations of domain structures in multilayer [Co (0.5 nm)/Pt (1 nm)]₅ thin film structures (denoted hereafter as Co/Pt) modified by additional Co capping layers and by ion irradiation. It is demonstrated that a Co capping layer essentially changes the domain structure and decreases the threshold of magnetization reversal, due to the formation of noncollinear magnetization in Co/Pt. It is shown that local irradiation with a focused He⁺ ion beam enables the formation of regions with decreased easy-axis anisotropy (magnetic bubbles) that have the inverse magnetization direction in the demagnetized state of Co/Pt. The experimental results demonstrate that the magnetic bubbles can be switched using a probe of a magnetic force microscope. The possible application of these effects for the development of magnetic logic and data storage systems is discussed. Full article

(This article belongs to the Special Issue Scanning Probe Microscopy of Ferroics)

► Show Figures

Figure 1

10784 KiB

Open AccessArticle

A Piezoresponse Force Microscopy Study of Ca_xBa_1−xNb₂O₆ Single Crystals

by Vladimir V. Shvartsman, Danka Gobeljic, Jan Dec and Doru C. Lupascu

Materials 2017, 10(9), 1032; https://doi.org/10.3390/ma10091032 - 05 Sep 2017

Cited by 3 | Viewed by 3120

Abstract

Polar structures of Ca_xBa_1−xNb₂O₆ (CBN100x) single crystals were investigated using piezoresponse force microscopy. Increasing Ca content results in decreasing domain size and enhancement of the polar disorder. For the composition with x = 0.32 the characteristic domain size is similar to that reported for relaxor Sr_0.61Ba_0.39Nb₂O₆ (SBN61). However, decay of an artificial macroscopic domain in CBN32 takes place below the macroscopic transition temperature, contrary to SBN61, where random fields stabilize it above the transition temperature. We can conclude that CBN with 0.26 ≤ x ≤ 0.32 does not display classical relaxor behavior and might be considered as a disordered ferroelectric. Full article

(This article belongs to the Special Issue Scanning Probe Microscopy of Ferroics)

► Show Figures

Figure 1
