Article

Structural and Electrical Parameters of ZnO Thin Films Grown by ALD with either Water or Ozone as Oxygen Precursors

by
Aleksandra Seweryn
*,
Rafal Pietruszka
,
Bartlomiej S. Witkowski
,
Aleksandra Wierzbicka
,
Rafal Jakiela
,
Piotr Sybilski
and
Marek Godlewski
Institute of Physics, Polish Academy of Sciences, Aleja Lotnikow 32/46, PL-02668 Warsaw, Poland
*
Author to whom correspondence should be addressed.
Crystals 2019, 9(11), 554; https://doi.org/10.3390/cryst9110554
Submission received: 30 August 2019 / Revised: 18 October 2019 / Accepted: 22 October 2019 / Published: 24 October 2019
(This article belongs to the Special Issue Preparation, Characterization and Application of Zinc Oxide–Based Nanostructures)
Browse Figures
Versions Notes

Abstract

Low temperature (at 100 °C and below) growth of ZnO thin films by atomic layer deposition (ALD) is demonstrated. Properties of the layers grown with two different oxygen reagents: ozone and water are compared. Diethylzinc (DEZ) was used as metal precursor. Electrical and structural properties of films obtained at several different growth temperatures, ranging from 50 °C to 250 °C were analyzed. It turned out that the film grown in the water-based process at 250 °C and all films grown with ozone have more ordered crystallographic structure with the privileged growth direction (001) perpendicular to the substrate than water-based samples grown in temperatures 100–200 °C. Higher free electron concentration at room temperature was observed for ozone-based samples grown at 100 °C and 150 °C in comparison to water-based samples obtained at the same growth temperature. Low value of resistivity in case of ozone-based samples grown at 100 °C is a promising result, however lower electron mobility requires further optimization.
Keywords: zinc oxide; TCO films; thin layer zinc oxide; TCO films; thin layer
