Effects of Using Thermocomposted Frass from Black Soldier Fly Larvae as a Germination Substrate on the Phytotoxicity, Germination Index, Growth and Antioxidant Contents in Kale (Brassica oleracea)

by
Hugo González-Lara
1,
Benito Parra-Pacheco
1,
Humberto Aguirre-Becerra
2,
Ana A. Feregrino-Perez
2,* and
Juan Fernando Garcia-Trejo
2,*
1
División de Investigación y Posgrado, Facultad de Ingeniería, Universidad Autónoma de Querétaro, Carretera a Chichimequillas Km. 1 s/n, El Marqués, Querétaro 76265, Mexico
2
Cuerpo Académico de Bioingeniería Básica y Aplicada, Facultad de Ingeniería, Universidad Autónoma de Querétaro, Cerro de las Campanas s/n, Las Campanas, Querétaro 76010, Mexico
*
Authors to whom correspondence should be addressed.
Agronomy 2024, 14(7), 1392; https://doi.org/10.3390/agronomy14071392
Submission received: 3 May 2024 / Revised: 22 June 2024 / Accepted: 24 June 2024 / Published: 27 June 2024
(This article belongs to the Special Issue Advances in Fruit Pre-harvest and Postharvest Quality, Physiology and Technology—Volume II)
Browse Figure
Versions Notes

Abstract

:
Frass generated during the production of black soldier fly larvae is attracting the interest of scientists and horticultural producers because it is a material made from the biotransformation of organic waste, it contains several nutrients that can be used by plants, and it has a biostimulant capacity that has become a recent focus. Thermal composting is a stabilization process that improves the physical and chemical properties of treated wastes, allowing better performance in plants compared to the waste in its fresh state. In this research, thermocomposted frass was evaluated as a germination substrate for kale seeds (Brassica oleracea). To achieve this, the phytotoxicity of increasing concentrations of frass was evaluated by examining the germination of kale seeds, and seedlings were grown for 30 days in germination substrates mixed with 20, 40, 60, 80, and 100% frass under greenhouse conditions. The treatment with 20% frass showed the highest values of seedling height, stem diameter, number of leaves, length and width of the first true leaf and length and width of cotyledons, and reduced the contents of phenols, tannins and antioxidants. However, the content of flavonoids increased compared to the control and the rest of the mixtures.

1. Introduction

The most frequently used growing media in soil-less cultivation are peat, coir, soft-wood pine bark, wood fiber and composted organic wastes. These materials must provide physical, chemical and biological properties to support healthy root growth in the environment and must provide the practical requirements of the production system in which they are being used [1]. Peat moss is the substrate most frequently used for plant germination due to its high moisture retention capacity and porosity. However, these properties encourage the proliferation of fungi that are harmful to the proper development of plants [2]. Furthermore, this substrate is derived from moss ecosystems and its extraction destroys areas of ecological importance [3]. The search for new materials for plant germination is considered a means to reduce environmental impact and improve seedling development at the same time. The use of composted waste is a good option, since it offers physical and chemical properties suitable for the development of seedlings in addition to reincorporating waste (for example, livestock waste [4], municipal solid waste [5] and vegetable residues [6]) into the production chain.
Black soldier fly larva frass is a bioresource composed of excrement, undigested food and insect exoskeletons, and it can be used in agriculture for many purposes, including to improve plant growth, increase production and improve soil. This is due to its high organic matter and nitrogen contents [7]. The food or residue used to feed the black soldier fly larvae has an effect on the chemical quality of the frass [8]. However, it has been reported that it is necessary to stabilize the frass through practices such as thermocomposting to improve its chemical properties and provide better uses for plants [9].
Frass post-processing through thermocomposting may be advised to avoid soil nitrogen deficiencies or impaired soil–gas permeability, and thus to improve the use of nutrients by plants [10]. This process reduces the C:N ratio, the pH (to neutral values) and the concentration of phytotoxins, and increases the germination percentage [11]. It also significantly increases the chlorophyll concentration, growth, yield and agronomic nitrogen use efficiency of maize [12].
Fresh frass has been used as a germination substrate for baby leaf lettuce (Lactuca sativa L., cv. Chiara), basil (Ocimum basilicum L., cv. ISI 602) and tomato (Solanum lycopersicum L., cv. Roma V.F.), in a Gainesville-type feeding process, in combination with commercial peat, where 10% frass showed the highest values in plant growth [13]. However, it has been reported that the use of immature composts can cause phytotoxicity in seed germination [9].
The phytotoxicity test is performed to qualitatively determine the delay in seed germination due to the presence of phytotoxins [14]. It has been shown that the application of the thermocomposting process to fresh frass reduces the potential presence of concentrations of phytotoxins such as phenols in the soil [11]. One way to quantify the impact of these compounds is to determine the antioxidant content of plants [15].
Antioxidants are secondary metabolites that plants produce under different types of biotic or abiotic stress, and their quantification is an indirect way of finding out if plants are subjected to any type of stress [16]. It has been reported that a deficiency of nitrogen, phosphorus and potassium generates an increase in flavonoid [17] and phenol [18] contents. The presence of beneficial bacteria from the Rhizobia family favors the production of flavonoids, and these also play an important role in the formation of the nodular meristem in the roots [19]; moreover, the main function of tannins is to provide protection against attack by insects and pathogenic microorganisms [20].
For this reason, the aim of this work was to evaluate the thermocomposted black soldier fly larva frass generated from the treatment of fruit and vegetable waste as a substrate and its effect on phytotoxicity, the germination index, growth and antioxidant content in kale.

2. Materials and Methods

2.1. Obtention of Thermocomposted Black Soldier Fly Larva Frass

Black soldier fly larva frass (BSFLF) was obtained from the biotransformation unit pilot at Universidad Autonoma de Queretaro, Campus Amazcala, Mexico. The feedstock was the organic residue of a mixture of fruits and vegetables from a municipal market which had undergone a biotransformation process. The residue was placed in plastic boxes filled with 20 kg organic residue, and 9000 5-day-old larvae and 500 g of sawdust were added to each box to retain water and reduce the moisture of the residue. Fresh frass was collected using a no. 10 mesh sieve after 14 days. After collection, the fresh frass was placed in a circular tank made of a black geomembrane for thermocomposting using the static heap method, until it reached its maximum temperature, oscillating around 65 °C, and then the ambient temperature, for a total time of 30 days.

2.2. Laboratory Analysis Methods of Thermocomposted BSFLF (TBSFLF)

After thermocomposting, frass was sieved to obtain 2 mm particles and then air dried. The Mexican guideline NMX-FF-109-SCFI-2008 [21] was followed to determine the pH, electrical conductivity, moisture content, organic matter, organic carbon, total nitrogen, carbon-to-nitrogen ratio, cation exchange capacity, apparent density and carbon-to-phosphorus ratio. Nitrate nitrogen was calculated according to Cataldo et al. [22]; phosphorus was determined following the Mexican guideline NMX-DGN-AA-32-1976 [23]; potassium, calcium and sodium concentrations were determined by flamometry; magnesium concentration was determined according to Harris [24]; and humic and fulvic acids were quantified following the Kononova–Belchikovas method [25].

2.3. Phytotoxicity Test of Thermocomposted Frass and Germination Index

The plant bioassay method was used [26] to determine phytotoxicity, and the seed germination index and plant growth were also examined. The black soldier fly larva frass was hand-sieved at a diameter of 2 mm, and then the extract was obtained by diluting 5 g of frass with 50 mL of distilled water (1:10 w/v) and shaking for one hour using a Thermo Scientific (Dubuque, IA, USA) maxQ 2506 reciprocating shaker. The extract was diluted in the same series as in the seedling experiment (described below), at 20%, 40%, 60%, 80% and 100%, with distilled water as a positive control, to determine the effect of the concentration of frass extract on germination, of which there are currently no reports. Next, 5 mL of each dilution factor was taken and placed in a Petri dish. Seeds of kale cv Blue ridge (SAKATA® Seed America, Inc., Morgan Hill, CA, USA) (Brassica oleracea) were used as a test crop, and 10 seeds were placed in the Petri dish in triplicate, laid on filter paper and then moistened with 5 mL of black soldier fly larva frass extract. The Petri dishes were kept in an incubator (Memmert model IN30 Eagle, WI, USA) under a controlled environment at 25 °C. The germinated seeds were counted after 72 h, and their root lengths were measured after 72 h. The germination index (GI) was calculated using the following equation [27]:
G I ( % ) = ( R S G % × R R G % ) 100
Here, RSG is the relative seed germination and RRG represents the relative root growth. RSG and RRG are calculated as follows:
R S G ( % ) = S G C E S G D W × 100
Here, SGCE is the number of seeds germinated in thermocompost extracts and SGDW is the number of seeds germinated in distilled water.
R R G ( % ) = M R L C E M R L D W × 100
Here, MRLCE is the mean root length in the thermocompost extract and MRLDW is the mean root length in distilled water. To evaluate the phytotoxicity of frass, the GI value is calculated; GI values below 50% are considered highly phytotoxic, values between 50% and 80% are moderately phytotoxic and values above 80% indicate no phytotoxicity. When the value exceeds 100%, the frass can be considered a phytonutrient or phytostimulant [27].

2.4. Germination Substrate Preparation

To assess the ability of TBSFLF as a growing media, six different germinations substrates were composed as follows (% volume): commercial peat moss (PM), PREMIER ® Sphagnum Peat Moss Premier Horticulture, Inc., (Quakertown, PA, USA), PM 100% (GS1); PM 80% + TBSFLF 20% (GS2); PM 60% + TBSFLF 40% (GS3); PM 40% + TBSFLF 60% (GS4); PM 20% + TBSFLF 80% (GS5); and TBSFLF 100% (GS6).

2.5. Germination Test

A germination test with the prepared substrates was carried out under greenhouse conditions with temperatures ranging from 8.1 to 38.2 °C, relative humidity ranging from 16.6 to 76.8% and a solar photoperiod (maximum intensity 2448 μM/m2s). Kale cv Blue ridge (SAKATA ® Seed America, Inc., Morgan Hill, CA, USA) was sown manually, with 1 seed per pot. Styrofoam pots were used (diameter 8 cm and height 9 cm, 0.236 L) and filled with the different germination substrates. Each treatment contained 33 pots arranged in a completely randomized design with no repetition. Each pot was manually irrigated every day. The number of emerged plants was recorded every day, and the accumulative percentage is reported.

2.6. Agronomic Performance of Seedlings

The experiment was carried out with the same conditions as the germination test. Each treatment (PM, GS1, GS2, GS3, GS4, GS5 and GS6) contained 11 pots with three repetitions arranged in a completely randomized design. Kale cv Blue ridge (SAKATA ® Seed America, Inc.) was sown manually, with 1 seed per pot. Thirty days after sowing, the following variables were measured on each plant: height of the plant (mm), stem diameter (mm), total number of true leaves, true leave length (mm), true leave width (mm), cotyledon length (mm) and cotyledon width (mm).

2.7. Antioxidant Content

Extraction was carried out according to Cardador et al. [28]; a 25 mg dry sample and 200 mg wet sample of kale were taken, and then 2.5 mL of methanol was added. The samples were kept in the dark and shaken, and after 24 h they were centrifuged at 5000 rpm for 10 min at 4 °C; only the supernatant was taken.

2.7.1. Total Contents of Phenols, Flavonoids and Tannins

The total phenol contents of roots and leaves were determined using the Folin–Ciocalteu method according to Singleton et al. [29], modified to a 96-well microplate. Briefly, 4 μL equivalent to 0.01 g of the extract was mixed with 250 μL of Folin–Ciocalteu reagent and 1250 μL of Na2CO3 solution (20%), and incubated at room temperature for 2 h. Absorbance was measured at 760 nm using a spectrophotometer (Thermo Scientific TM model MULTISKAN TM GO, Dubuque, IA, USA). Gallic acid was used for the calibration curve (0 to 20 mg) and the results are expressed as gallic acid equivalents per gram of sample.
The spectrophotometric method was used to determine the total flavonoid contents in methanolic extracts according to Oomah et al. [30]. First, 50 μL of methanolic extract was mixed with 180 μL of distilled water and 20 μL of 2-aminoethyl diphenylborinate at 1% in a 96-well microplate. Absorbance was measured at 404 nm using a spectrophotometer, MULTISKAN GO. Extract absorption was compared with that of a rutin standard curve (up to 2 μg/mL). The results are expressed as rutin equivalents per gram of sample.
Total tannin content was determined following Feregrino-Perez [31]’s method, modified for a 96-well microplate: 50 μL of methanolic extract and 200 μL of solution 1:1 (v/v) of vanillin at 1% and HCl at 8% were deposited in 96-well microplate, along with 50 μL of methanol and 200 μL of HCl. Absorbance was measured at 492 nm using a spectrophotometer (Thermo Scientific TM model MULTISKAN TM GO), using (+) catequin (up to 0.1 mg/mL) as a reference standard. The results are expressed as catechin equivalents per gram of sample.

2.7.2. Antioxidant Capacity Determination: DPPH and ABTS

DPPH quantification was determined according to Zenil et al. [32]: 20 μL of methanolic extract and 200 μL of DPPH were deposited in a 96-well microplate. Absorbance was measured at 520 nm at different times (0, 10, 30, 60 and 90 min), using a spectrophotometer (Thermo Scientific TM model MULTISKAN TM GO), and the results were expressed as Trolox equivalents per gram of sample.
The spectrophotometric method for antioxidant capacity quantification by ABTS was used, following Pellegrini et al. [33]: 230 μL of ABTS and 20 μL of sample were deposited in a 96-well microplate. Absorbance was measured at 734 nm using a spectrophotometer (Thermo Scientific TM model MULTISKAN TM GO), and the results were expressed as Trolox equivalents per gram of sample.

2.8. Statistical Analysis

Data were analyzed using STATGRAPHICS Centurion software (version XVI). An ANOVA test was used for height, stem diameter, number of true leaves, first true leaf length, true leaf width, cotyledon length and cotyledon width of kale seedlings; for significant differences, a Fisher’s LSD test was used to make a multiple comparison between treatments with parametric data. In addition, a significant difference was determined by Dunnett’s pairwise comparison for germination, the germination index, antioxidant content, and antioxidant capacity to make a multiple comparison with the control because the data were nonparametric. The significance value of the data was p < 0.05 in all analyses. For percent emergence, the total number of plants is indicated.

3. Results

3.1. Chemical Composition of Thermocomposted BSFLF

The chemical composition of peatmoss and frass are reported in Table 1.

3.2. Phytotoxicity of Thermocomposted BSFLF and Germination Index of Kale

All the treatments showed a germination of 80 ± 26.46%, with no significant difference; however, the 80% and 100% composted frass doses showed moderate and high phytotoxicity, respectively, and the 20% and 40% treatments had values greater than 100%, which means that they had phytostimulant properties according to [27]. All values are shown in Table 2.

3.3. Effect of Thermocomposted BSFLF as a Germination Substrate on Kale Seedlings’ Growth

The percentage of the emergence of kale was affected by the percentage of inclusion of composted frass as a germination substrate; the results are shown in Table 3. Treatments GS2, GS4 and GS5 were the first to emerge, and treatments GS5 and GS6 reached their highest emergence percentage on the 7th day, and then the plants died. The moderate and high phytotoxicity obtained for these treatments in the previous test was reaffirmed in this test. After the 12th day, only treatments GS1, GS2, GS3 and GS4 survived, so the remaining analyses were for these treatments.
The growth of the kale seedlings was recorded with the variables of height, stem diameter, number of true leaves and length and width of first true leaf and cotyledons. In Table 4 and Table 5, mean values of these variables are shown for 12 days after the seeds were sown and on day 30, when the seedlings were harvested. The greatest vegetative growth was seen with the GS2 substrate, a mixture of 80% peatmoss and 20% composted frass. At the end of the experiment, the GS2 treatment showed the best results compared to the GS1 control treatment, increasing the height and stem diameter by 32.7%; the number of true leaves by 51.6%; the length and width of the first true leaf by 38.7% and 17.9%, respectively; and the cotyledon length and width by 25% and 33.7%, respectively (Figure 1).

3.4. Antioxidant Content

In Table 6, the phenol content in kale leaf samples is expressed in milligram equivalents of gallic acid, tannins in milligrams equivalent of catechin and flavonoids in milligrams equivalent of rutin. The GS1 treatment (control treatment) shows the highest phenol and tannin contents, and the GS2 treatment was the one with the lowest amount of those phenolic compounds.
For flavonoid content, the GS4 treatment showed the highest amount and the GS1 treatment showed the lowest.
Antioxidant capacity is expressed in ABTS and DPPH percentages in Table 7; only the GS1 treatment showed a significantly higher percentage of ABTS compared to the GS2 treatment. The GS1, GS2 and GS3 treatments showed a significantly higher percentage of DPPH compared to the GS4 treatment.

4. Discussion

The thermocomposted frass showed an alkaline pH (8.5), and a higher value compared to previous works: 7.26 from brewery residue [34], 7.3 from brewery residue [12,35], 7.5 from a mixture of okara and wheat bran [11], 7.6 from brewery residue amended with sawdust [36], 7.7 from brewery residue [37] and 7.8 from brewery residue [27]. The other physical and chemical characteristics of the thermocomposted frass used in this research differed from those reported in other works because the origin of the waste with which the fly larvae were fed directly affects the physical quality and quantity of frass nutrients [10].
Other experiments with radish and lettuce seeds showed a similar trend with fresh frass, where decreasing the percentage of frass in the aqueous medium increased the GI value due to high phytotoxicity [38]. However, the GI was higher in this work, indicating that a thermocomposted frass has a low phytotoxicity and inhibition effect. Another study with fresh frass showed GI values greater than 100%, indicating zero phytotoxicity on garden cress seeds, but considering a 1:20 dilution [13], a highly diluted extract.
A study of thermocomposted frass from brewers’ spent grain biotransformation used a 1:10 dilution, obtaining GI values from 22.9 to 101.9 [36], a broad range compared to the present work. Another study used a 1:10 dilution with a thermocomposted okara and wheat bran frass mixture, obtaining GI results lower than 25% and showing that even after a thermocomposting stabilization treatment, the frass had a high percentage of phytotoxicity that may be due to the presence of phenols, chitin, and an excess of nutrients [11]. According to Teresa Barral [14], substrates derived from thermocomposting contain some compounds that can cause phytotoxicity, such as ammonia, ethylene oxide, organic acids, phenols, salts and heavy metals.
The plants demonstrated inhibition in their shoot and root growth at a higher percentage of inclusion as a germination substrate. Macro- and micronutrients are essential for plant development and growth because they play important roles in plant physiology [39]. Additionally, the most significant importance of frass is not due to its mineral nutrients but rather the rhizobacteria and phytohormones present in the frass [40]. Song et al. [11] reported the highest number of leaves in pak choi (Brassica rapa) using 10% composted frass, an increase of 41.67% compared to the control. In this study, the highest kale growth was with 20% composted frass, an increase of 51.61% in the number of leaves compared to the control. The substrate pH is essential in determining nutrient availability to the plant [41]. In contrast, in seed germination, an acidic pH can inhibit the action of enzymes necessary for germination and can have a direct effect by dissolving the seed coat [42]. Some authors have reported pH values between 5.5 and 6.9 and EC between 1.2 and 1.9 mS/cm (=dS/m) as suitable for kale germination [43,44,45]. However, in this study, the alkaline pH of the thermocomposted frass (8.5) and high electrical conductivity (7.476 dS/m) could have reduced the germination of kale as the percentage of composted frass increased in the substrate.
Flavonoids have protective functions in plants, including defenses against phytopathogens and herbivores [46]. They influence the transport of auxins, plant hormones that protect plants from microbes and insects. Flavonoids play an essential role in the roots during nodule meristem formation and as a defense against attack by rhizobia soil bacteria [47]. In this way, the increase in flavonoid content as the percentage of composted frass in the substrate increased may have been a defense response to the microorganisms in the frass, such as Azospirillum, Rhizobium, Azotobacter, and the genera Bacillus [48].
The difference between the obtained DPPH values can be attributed to the nitrogen content in the composted frass. A high amount of nitrogen applied to the plant decreases the percentages of ABTS and DPPH, which measure the activity of water-soluble antioxidants [49]. In this experiment, no differences in these variables were detected in accordance with Biesiada et al. [50] and Romano et al. [51], who reported no significant difference in the total phenol content or antioxidant capacity using fresh frass.

5. Conclusions

The addition of thermocomposted frass at 20% generates the appropriate physicochemical conditions for the generation of a substrate for improving the agronomic performance of kale, showing an alternative material for germination.
More research is needed on the content of other components in frass, such as phytohormones. It is important to know the appropriate doses of thermocomposted BSFL in the phenological stages of germination, development and production in different species of vegetables and fruits. Likewise, it is necessary to improve the thermal stabilization process or even add another, like vermicomposting.

Author Contributions

Writing—original draft, conceptualization, investigation, H.G.-L.; investigation, conceptualization, B.P.-P.; writing—original draft preparation, H.G.-L. and A.A.F.-P.; investigation, H.G.-L. and H.A.-B.; writing—review and editing, A.A.F.-P., H.A.-B. and J.F.G.-T.; visualization, A.A.F.-P., J.F.G.-T., H.A.-B. and H.G.-L.; supervision, A.A.F.-P., H.A.-B. and J.F.G.-T. All authors have read and agreed to the published version of the manuscript.

Funding

The authors are grateful for the financial support provided by CONAHCyT (Consejo Nacional de Humanidades, Ciencia y Tecnología) through the Hugo González-Lara grant (663475) to carry out doctoral studies. Financial support was provided by FONFIVE2024 for the realization of the project, with support from the Autonomous University of Queretaro.

Data Availability Statement

The original contributions presented in the study are included in the article, further inquiries can be directed to the corresponding authors.

Conflicts of Interest

The authors declare no conflicts of interest.

References

  1. Sachin, T.M.; Thakur, N.; Sharma, P. Use of alternative growing media in ornamental plants. Int. J. Chem. Res. 2020, 8, 2349–8528. [Google Scholar] [CrossRef]
  2. Limpens, J.; Berendse, F.; Blodau, C.; Canadell, J.G.; Freeman, C.; Holden, J.; Roulet, N.; Rydin, H.; Schaepman-Strub, G. Peatlands and the carbon cycle: From local processes to global implications—A synthesis. Biogeosciences 2008, 5, 1475–1491. [Google Scholar] [CrossRef]
  3. Giménez, A.; Fernández, J.A.; Pascual, J.A.; Ros, M.; Saez-Tovar, J.; Martinez-Sabater, E.; Gruda, N.S.; Egea-Gilabert, C. Promising Composts as Growing Media for the Production of Baby Leaf Lettuce in a Floating System. Agronomy 2020, 10, 1540. [Google Scholar] [CrossRef]
  4. Bustamante, M.A.; Gomis, M.P.; Pérez-Murcia, M.D.; Gangi, D.; Ceglie, F.G.; Paredes, C.; Pérez-Espinosa, A.; Bernal, M.P.; Moral, R. Use of livestock waste composts as nursery growing media: Effect of a washing pre-treatment. Sci. Hortic. 2021, 281, 109954. [Google Scholar] [CrossRef]
  5. Cesaro, A.; Belgiorno, V.; Guida, M. Compost from organic solid waste: Quality assessment and European regulations for its sustainable use. Resources. Conserv. Recycl. 2015, 94, 72–79. [Google Scholar] [CrossRef]
  6. Huang, D.; Qin, X.; Xu, P.; Zeng, G.; Peng, Z.; Wang, R.; Wan, J.; Gong, X.; Xue, W. Composting of 4-nonylphenol-contaminated river sediment with inocula of Phanerochaete chrysosporium. Bioresour. Technol. 2016, 221, 47–54. [Google Scholar] [CrossRef]
  7. Choi, S.; Hassanzadeh, N. BSFL Frass: A Novel Biofertilizer for Improving Plant Health While Minimizing Environmental Impact. Candian Sci. Fair 2019, 2, 41–46. [Google Scholar] [CrossRef]
  8. Gärttling, D.; Schulz, H. Compilation of Black Soldier Fly Frass Analyses. J. Soil. Sci. Plant Nutr. 2022, 22, 937–943. [Google Scholar] [CrossRef]
  9. Basri, N.E.A.; Azman, N.A.; Ahmad, I.K.; Suja, F.; Jalil, N.A.A.; Amrul, N.F. Potential Applications of Frass Derived from Black Soldier Fly Larvae Treatment of Food Waste: A Review. Foods 2022, 11, 2664. [Google Scholar] [CrossRef]
  10. Klammsteiner, T.; Turan, V.; Juárez, M.F.-D.; Oberegger, S.; Insam, H. Suitability of Black Soldier Fly Frass as Soil Amendment and Implication for Organic Waste Hygienization. Agronomy 2020, 10, 1578. [Google Scholar] [CrossRef]
  11. Song, S.; Ee, A.W.L.; Tan, J.K.N.; Cheong, J.C.; Chiam, Z.; Arora, S.; Lam, W.N.; Tan, H.T.W. Upcycling food waste using black soldier fly larvae: Effects of further composting on frass quality, fertilising effect and its global warming potential. J. Clean. Prod. 2021, 288, 125664. [Google Scholar] [CrossRef]
  12. Tanga, C.M.; Beesigamukama, D.; Kassie, M.; Egonyu, P.J.; Ghemoh, C.J.; Nkoba, K.; Subramanian, S.; Anyega, A.O.; Ekesi, S. Performance of black soldier fly frass fertiliser on maize (Zea mays L.) growth, yield, nutritional quality, and economic returns. J. Insects Food Feed. 2022, 8, 185–196. (In English) [Google Scholar] [CrossRef]
  13. Setti, L.; Francia, E.; Pulvirenti, A.; Gigliano, S.; Zaccardelli, M.; Pane, C.; Caradonia, F.; Bortolini, S.; Maistrello, L.; Ronga, D. Use of black soldier fly (Hermetia illucens (L.), Diptera: Stratiomyidae) larvae processing residue in peat-based growing media. Waste Manag. 2019, 95, 278–288. [Google Scholar] [CrossRef] [PubMed]
  14. Núñez, R.P.; Barral, M.T. A Review on the Use of Phytotoxicity as a Compost Quality Indicator. vol. Dynamic Soil. Dyn. Plant Print 2011, 5, 36–44. [Google Scholar]
  15. Goncharuk, E.A.; Zagoskina, N.V. Heavy Metals, Their Phytotoxicity, and the Role of Phenolic Antioxidants in Plant Stress Responses with Focus on Cadmium: Review. Molecules 2023, 28, 3921. [Google Scholar] [CrossRef] [PubMed]
  16. Hunyadi, A. The mechanism(s) of action of antioxidants: From scavenging reactive oxygen/nitrogen species to redox signaling and the generation of bioactive secondary metabolites. Med. Res. Rev. 2019, 39, 2505–2533. [Google Scholar] [CrossRef] [PubMed]
  17. Shah, A.; Smith, D.L. Flavonoids in Agriculture: Chemistry and Roles in, Biotic and Abiotic Stress Responses, and Microbial Associations. Agronomy 2020, 10, 1209. [Google Scholar] [CrossRef]
  18. Ramakrishna, A.; Ravishankar, G.A. Influence of abiotic stress signals on secondary metabolites in plants. Plant Signal Behav. 2011, 6, 1720–1731. (In English) [Google Scholar] [CrossRef]
  19. Begum, A.A.; Leibovitch, S.; Migner, P.; Zhang, F. Specific flavonoids induced nod gene expression and pre-activated nod genes of Rhizobium leguminosarum increased pea (Pisum sativum L.) and lentil (Lens culinaris L.) nodulation in controlled growth chamber environments. J. Exp. Bot. 2001, 52, 1537–1543. (In English) [Google Scholar] [CrossRef]
  20. Furlan, C.M.; Motta, L.; Santos, D. Tannins: What Do They Represent in Plant Life? Nova Science Publishers: Hauppauge, NY, USA, 2011; pp. 251–263. [Google Scholar]
  21. NMX-FF-109-SCFI-2008; Humus de Lombriz (Lombricomposta)—Especificaciones Y Métodos de Prueba. Diario Oficial de la Federación: Cuauhtemoc, Maxico, 2008.
  22. Cataldo, D.A.; Maroon, M.; Schrader, L.E.; Youngs, V.L. Rapid colorimetric determination of nitrate in plant tissue by nitration of salicylic acid. Commun. Soil. Sci. Plant Anal. 1975, 6, 71–80. [Google Scholar] [CrossRef]
  23. NMX-DGN-AA-32-1976; Determinación de Fósforo Total en Desechos Sólidos (Método del Fosfovanadomolibdato). Centro de Calidad Ambiental: Chihuahua, Mexico, 1976.
  24. Harris, D.C. Análisis Químico Cuantitativo; Reverté: Barcelona, Spain, 2003. [Google Scholar]
  25. Banov, M.; Tsolova, V.; Kirilov, I. Reclamation of heaps and industrial sites built in the region of Madjarovo mine (Bulgaria). Bulg. J. Agric. Sci. 2020, 26, 192–197. [Google Scholar]
  26. Visvini, L.; Latifah, O.; Ahmed, O.H.; Kurk, W.J. Frass Production from Black Soldier Fly Larvae Reared on Palm Oil Wastes. IOP Conf. Ser. Earth Environ. Sci. 2022, 995, 012012. [Google Scholar] [CrossRef]
  27. Beesigamukama, D.; Mochoge, B.; Korir, N.K.; Fiaboe, K.K.; Nakimbugwe, D.; Khamis, F.M.; Dubois, T.; Subramanian, S.; Wangu, M.M.; Ekesi, S.; et al. Biochar and gypsum amendment of agro-industrial waste for enhanced black soldier fly larval biomass and quality frass fertilizer. PLoS ONE 2020, 15, e0238154. (In English) [Google Scholar] [CrossRef] [PubMed]
  28. Cardador-Martínez, A.; Loarca-Piña, G.; Oomah, B.D. Antioxidant activity in common beans (Phaseolus vulgaris L.). J. Agric. Food Chem. 2002, 50, 6975–6980. [Google Scholar] [CrossRef] [PubMed]
  29. Singleton, V.L.; Orthofer, R.; Lamuela-Raventós, R.M. [14] Analysis of total phenols and other oxidation substrates and antioxidants by means of folin-ciocalteu reagent. In Methods in Enzymology; Academic Press: Cambridge, MA, USA, 1999; Volume 299, pp. 152–178. [Google Scholar]
  30. Oomah, B.D.; Cardador-Martínez, A.; Loarca-Piña, G. Phenolics and antioxidative activities in common beans (Phaseolus vulgaris L.). J. Sci. Food Agric. 2005, 85, 935–942. [Google Scholar] [CrossRef]
  31. Feregrino-Pérez, A.A.; Berumen, L.C.; García-Alcocer, G.; Guevara-Gonzalez, R.G.; Ramos-Gomez, M.; Reynoso-Camacho, R.; Acosta-Gallegos, J.A.; Loarca-Piña, G. Composition and chemopreventive effect of polysaccharides from common beans (Phaseolus vulgaris L.) on azoxymethane-induced colon cancer. J. Agric. Food Chem. 2008, 56, 8737–8744. (In English) [Google Scholar] [CrossRef] [PubMed]
  32. Zenil Lugo, N.; Colinas León, M.T.; Bautista Bañuelos, C.; Vázquez Rojas, T.R.; Lozoya Saldaña, H.; Martínez Damián, M.T. Total phenols and antioxidant capacity estimated with DPPH/ABTS assays in roses on preservative solutions. Rev. Mex. Cienc. Agrícolas 2014, 5, 1029–1039. [Google Scholar]
  33. Re, R.; Pellegrini, N.; Proteggente, A.; Pannala, A.; Yang, M.; Rice-Evans, C. Antioxidant activity applying an improved ABTS radical cation decolorization assay. Free Radic. Biol. Med. 1999, 26, 1231–1237. (In English) [Google Scholar] [CrossRef]
  34. Anyega, A.O.; Korir, N.K.; Beesigamukama, D.; Changeh, G.J.; Nkoba, K.; Subramanian, S.; van Loon, J.J.A.; Dicke, M.; Tanga, C.M. Black Soldier Fly-Composted Organic Fertilizer Enhances Growth, Yield, and Nutrient Quality of Three Key Vegetable Crops in Sub-Saharan Africa. Front. Plant Sci. 2021, 12, 680312. [Google Scholar] [CrossRef]
  35. Wu, N.; Yu, X.; Liang, J.; Mao, Z.; Ma, Y.; Wang, Z.; Wang, X.; Liu, X.; Xu, X. A full recycling chain of food waste with straw addition mediated by black soldier fly larvae: Focus on fresh frass quality, secondary composting, and its fertilizing effect on maize. Sci. Total Environ. 2023, 885, 163386. [Google Scholar] [CrossRef]
  36. Beesigamukama, D.; Mochoge, B.; Korir, N.K.; Fiaboe, K.K.; Nakimbugwe, D.; Khamis, F.M.; Subramanian, S.; Wangu, M.M.; Dubois, T.; Ekesi, S.; et al. Low-cost technology for recycling agro-industrial waste into nutrient-rich organic fertilizer using black soldier fly. Waste Manag. 2021, 119, 183–194. [Google Scholar] [CrossRef] [PubMed]
  37. Beesigamukama, D.; Mochoge, B.; Korir, N.K.; Fiaboe, K.K.M.; Nakimbugwe, D.; Khamis, F.M.; Subramanian, S.; Dubois, T.; Musyoka, M.W.; Ekesi, S.; et al. Exploring Black Soldier Fly Frass as Novel Fertilizer for Improved Growth, Yield, and Nitrogen Use Efficiency of Maize Under Field Conditions. Front. Plant Sci. 2020, 11, 574592. [Google Scholar] [CrossRef] [PubMed]
  38. Bohm, K.; Hatley, G.A.; Robinson, B.H.; Gutiérrez-Ginés, M.J. Analysis of Chemical and Phytotoxic Properties of Frass Derived from Black Soldier Fly-Based Bioconversion of Biosolids. Sustainability 2023, 15, 11526. [Google Scholar] [CrossRef]
  39. Maathuis, F.J.M. Physiological functions of mineral macronutrients. Curr. Opin. Plant Biol. 2009, 12, 250–258. [Google Scholar] [CrossRef] [PubMed]
  40. Green, T. A biochemical analysis of Black Soldier fly (Hermetia illucens) larval frass plant growth promoting activity. PLoS ONE 2023, 18, e0288913. [Google Scholar] [CrossRef] [PubMed]
  41. Silber, A.; Bar-Tal, A. Nutrition of substrate-grown plants. In Soilless Culture: Theory and Practice Theory and Practice; Elsevier: Amsterdam, The Netherlands, 2019; pp. 197–257. [Google Scholar] [CrossRef]
  42. Laghmouchi, Y.; Belmehdi, O.; Bouyahya, A.; Senhaji, N.S.; Abrini, J. Effect of temperature, salt stress and pH on seed germination of medicinal plant Origanum compactum. Biocatal. Agric. Biotechnol. 2017, 10, 156–160. [Google Scholar] [CrossRef]
  43. Othman, A.J.; Eliseeva, L.G.; Molodkina, P.G.; Ibragimova, N.A.; Duksi, F.M. Dataset on the effect of soaking Kale (Brassica oleraceae L. var. acephala DC.) seeds in solution based on amorphous silicon diox-ide on the bioactive components and physiological growth parameters. Data Brief. 2022, 40, 107789. [Google Scholar] [CrossRef] [PubMed]
  44. Chowdhury, M.; Kiraga, S.; Islam, N.; Ali, M.; Reza, N.; Lee, W.-H.; Chung, S.-O. Effects of temperature, relative humidity, and carbon dioxide concentration on growth and glu-cosinolate content of kale grown in a plant factory. Foods 2021, 10, 1524. [Google Scholar] [CrossRef] [PubMed]
  45. Qin, D.; He, Q.; Mousavi, S.M.N.; Abbey, L. Evaluation of Aging Methods on the Surface Characteristics of Hy-drochar and Germination Indices for Kale Seeds. Horticulturae 2023, 9, 545. [Google Scholar] [CrossRef]
  46. Yahia, E.; Carrillo-Lopez, A. Postharvest Physiology and Biochemistry of Fruits and Vegetables; Elsevier: Amsterdam, The Netherlands, 2018. [Google Scholar]
  47. Samanta, A.; Das, G.; Das, S. Roles of flavonoids in Plants. Int. J. Pharm. Sci. Technol. 2011, 6, 12–35. [Google Scholar]
  48. Susanto, M.; Kurniawan, S.; Dep, R.; Rianne, W.; Hersade, D. Bio-Conversion and Decomposing with Black Soldier Fly to Promote Plant Growth. KnE Life Sci. 2022, 7, 681–692. [Google Scholar] [CrossRef]
  49. Ibrahim, M.H.; Jaafar, H.Z.E.; Karimi, E.; Ghasemzadeh, A. Impact of organic and inorganic fertilizers application on the phytochemical and antioxidant activity of Kacip Fatimah (Labisia pumila Benth). Molecules 2013, 18, 10973–10988. [Google Scholar] [CrossRef] [PubMed]
  50. Biesiada, A.; Nawirska-Olszańska, A.; Kucharska, A.; Sokół-Łętowska, A.; Kędra, K. The effect of nitrogen fertilization on nutritive value and antioxidative activity of red cabbage. Acta Sci. Pol. Hortorum Cultus 2010, 9, 13–21. [Google Scholar]
  51. Romano, N.; Fischer, H.; Powell, A.; Sinha, A.K.; Islam, S.; Deb, U.; Francis, S. Applications of Black Solider Fly (Hermetia illucens) Larvae Frass on Sweetpotato Slip Production, Mineral Content and Benefit-Cost Analysis. Agronomy 2022, 12, 928. [Google Scholar] [CrossRef]
Agronomy 14 01392 g001
Figure 1. Representative kale seedlings harvested at day 40 and grown in different germination substrates: (a) GS1 = 100% peatmoss (PM); (b) GS2 = 20% TBSFLF + 80% PM; (c) GS3 = 40% TBSFLF + 60% PM; and (d) GS4 = 60% TBSFLF + 40% PM.
Figure 1. Representative kale seedlings harvested at day 40 and grown in different germination substrates: (a) GS1 = 100% peatmoss (PM); (b) GS2 = 20% TBSFLF + 80% PM; (c) GS3 = 40% TBSFLF + 60% PM; and (d) GS4 = 60% TBSFLF + 40% PM.
Agronomy 14 01392 g001
Table 1. Chemical composition of peatmoss and thermocomposted frass expressed in dry matter.
Table 1. Chemical composition of peatmoss and thermocomposted frass expressed in dry matter.
ParameterPeatmossThermocomposted Frass
Moisture (%)64.70 ± 0.02546.46 ± 0.615
pH4.435 ± 0.0178.506 ± 0.093
EC (dS/m)0.6735 ± 0.0197.476 ± 0.475
OOM (%)91.735 ± 0.03978.63 ± 0.750
OOC (%)53.21 ± 0.02145.61 ± 0.438
Total N (%)1.08 ± 0.0181.98 ± 0.049
N-NO3 (mg/kg)308.99 ± 4.45896.50 ± 2.708
C/N49.525 ± 0.72523.13 ± 0.368
C/P1263.135 ± 3.44729.27 ± 0.453
CEC (Cmol/kg)117.69 ± 0.64755.57 ± 0.163
AD (g/mL)0.1210 ± 0.0070.2622 ± 0.017
P2O5 (%)0.1 ± 03.57 ± 0.014
K2O (%)0.05 ± 01.71 ± 0.014
Ca (%)0.62 ± 0.0070.70 ± 0.035
Mg (%)0.085 ± 0.0040.24 ± 0.071
Na (%)0.03 ± 00.11 ± 0
HA (%)1.6455 ± 0.0121.629 ± 0.144
FA (%)2.613 ± 0.0181.731 ± 0.144
Mean values ± standard deviation (n = 3) of electrical conductivity (EC), oxidizable organic matter (OOM), oxidizable organic carbon (OOC), cation exchange capacity (CEC), apparent density (AD), humic acid (HA) and fulvic acid (FA).
Table 2. Mean values of germination and germination index (GI) and phytotoxicity of different treatments in kale seed.
Table 2. Mean values of germination and germination index (GI) and phytotoxicity of different treatments in kale seed.
TreatmentGermination (%)GI (%)Phytotoxicity
Control96.67 ± 7.07 a100 ± 6.58 aNo
20%96.67 ± 7.07 a108.54 ± 6.58 aNo
40%90 ± 7.07 a106.46 ± 6.58 aNo
60%80 ± 7.07 a69.70 ± 6.58 bModerate
80%90 ± 7.07 a51.17 ± 6.58 bModerate
100%96.67 ± 7.07 a49.63 ± 6.58 bHigh
Mean values ± standard error (n = 3) with superscript letters indicating significant difference at p < 0.05 according to Dunnett’s test.
Table 3. Emergence (%) of kale seeds in different germination substrates after different days of sowing.
Table 3. Emergence (%) of kale seeds in different germination substrates after different days of sowing.
Emergence (%)
Germination Substrate3rd Day5th Day7th Day9th Day12th Day
GS1081.8281.8281.8284.85
GS212.12100100100100
GS30.0072.7387.8887.8890.91
GS412.1269.7090.9190.9190.91
GS53.0321.2124.2415.159.09
GS6006.0600
Mean values (n = 33) of accumulative percentage of total number of emerged plants are reported.
Table 4. Mean values of height, stem diameter, number of true leaves, length of first true leaf, width of true leaf, cotyledon length and cotyledon width of kale seedlings in different germination substrates at the initial measurement on day 12.
Table 4. Mean values of height, stem diameter, number of true leaves, length of first true leaf, width of true leaf, cotyledon length and cotyledon width of kale seedlings in different germination substrates at the initial measurement on day 12.
Germination SubstrateHeight (cm)Stem Diameter (mm)Number of True LeavesLength of First True Leaf (mm)Width of First True Leaf (mm)Cotyledon Length (mm)Cotyledon Width (mm)
GS11.69 ± 0.07 b1.07 ± 0.02 b1.06 ± 0.05 b6.78 ± 0.56 b3.43 ± 0.31 b6.43 ± 0.24 b10.10 ± 0.39 b
GS22.26 ± 0.10 a1.21 ± 0.02 a1.57 ± 0.09 a9.29 ± 0.64 a5.51 ± 0.47 a7.95 ± 0.29 a13.82 ± 0.53 a
GS31.44 ± 0.04 b1.09 ± 0.03 b1.00 ± 0.00 b4.40 ± 0.77 c2.53 ± 0.58 c5.10 ± 0.12 b8.41 ± 0.26 b
GS41.43 ± 0.05 b1.07 ± 0.02 b0.00 c0.00 d0.00 d5.24 ± 0.17 b8.11 ± 0.27 b
Mean values (n = 33) ± standard error with superscript letters indicating significant difference at p < 0.05 according to Fisher’s LSD test.
Table 5. Mean values of height, stem diameter, number of true leaves, length of first true leaf, width of true leaf, cotyledon length and cotyledon width of kale seedlings in different germination substrates at the initial measurement on day 30.
Table 5. Mean values of height, stem diameter, number of true leaves, length of first true leaf, width of true leaf, cotyledon length and cotyledon width of kale seedlings in different germination substrates at the initial measurement on day 30.
Germination SubstrateHeight (cm)Stem Diameter (mm)Number of True LeavesLength of First True Leaf (mm)Width of First True Leaf (mm)Cotyledon Length (mm)Cotyledon Width (mm)
GS13.33 ± 0.11 b1.07 ± 0.03 b2.48 ± 0.09 b16.67 ± 0.61 b7.74 ± 0.40 b6.12 ± 0.17 b9.92 ± 0.39 b
GS24.42 ± 0.17 a1.42 ± 0.04 a3.76 a ± 0.1123.13 ± 1.17 a9.13 ± 0.41 a7.65 ± 0.25 a13.27 ± 0.42 a
GS32.16 ± 0.09 c0.94 ± 0.03 c2.06 ± 0.06 c10.82 ± 0.54 c4.78 ± 0.21 c5.89 ± 0.18 b8.63 ± 0.30 b
GS42.06 c ± 0.050.90 ± 0.02 c1.97 ± 0.06 c9.09 ± 0.32 c4.44 ± 0.17 c6.33 ± 0.21 b8.07 ± 0.32 b
Mean values (n = 33) ± standard error with superscript letters indicating significant difference at p < 0.05 according to Fisher´s LSD test.
Table 6. Total phenol, tannin, and flavonoid contents in leaves of kale seedlings with different germination substrates.
Table 6. Total phenol, tannin, and flavonoid contents in leaves of kale seedlings with different germination substrates.
TreatmentPhenols (mg Eq. of Gallic Acid/g)Tannins (mg Eq. of Catechin/g)Flavonoids (mg Eq. of Rutin/g)
GS1354.054 ± 0.19 a10.972 ± 0.45 a0.1045 ± 0.28 b
GS2170.954 ± 0.05 c7.985 ± 0.21 c0.0713 ± 0.11 b
GS3263.993 ± 0.10 b4.437 ± 0.09 b0.2177 ± 0.18 a
GS4244.744 ± 0.04 b5.115 ± 0.17 b0.2516 ± 0.3 a
Mean values (n = 3) with superscript letters indicating significant difference at p < 0.05 according to Dunnett’s test.
Table 7. ABTS and DPPH percentages in leaves of kale seedlings with different germination substrates.
Table 7. ABTS and DPPH percentages in leaves of kale seedlings with different germination substrates.
TreatmentABTS (%)DPPH (%)
GS199.1718 ± 0.58 a91.6772 ± 1.11 a
GS297.1877 ± 0.58 a89.7525 ± 1.11 a
GS399.0338 ± 0.58 a88.5828 ± 1.11 a
GS498.1481 ± 0.58 a76.7695 ± 1.11 b
Mean values (n = 3) ± standard error with superscript letters indicating significant difference at p < 0.05 according to Dunnett’s test.
Disclaimer/Publisher’s Note: The statements, opinions and data contained in all publications are solely those of the individual author(s) and contributor(s) and not of MDPI and/or the editor(s). MDPI and/or the editor(s) disclaim responsibility for any injury to people or property resulting from any ideas, methods, instructions or products referred to in the content.

Share and Cite

MDPI and ACS Style

González-Lara, H.; Parra-Pacheco, B.; Aguirre-Becerra, H.; Feregrino-Perez, A.A.; Garcia-Trejo, J.F. Effects of Using Thermocomposted Frass from Black Soldier Fly Larvae as a Germination Substrate on the Phytotoxicity, Germination Index, Growth and Antioxidant Contents in Kale (Brassica oleracea). Agronomy 2024, 14, 1392. https://doi.org/10.3390/agronomy14071392

AMA Style

González-Lara H, Parra-Pacheco B, Aguirre-Becerra H, Feregrino-Perez AA, Garcia-Trejo JF. Effects of Using Thermocomposted Frass from Black Soldier Fly Larvae as a Germination Substrate on the Phytotoxicity, Germination Index, Growth and Antioxidant Contents in Kale (Brassica oleracea). Agronomy. 2024; 14(7):1392. https://doi.org/10.3390/agronomy14071392

Chicago/Turabian Style

González-Lara, Hugo, Benito Parra-Pacheco, Humberto Aguirre-Becerra, Ana A. Feregrino-Perez, and Juan Fernando Garcia-Trejo. 2024. "Effects of Using Thermocomposted Frass from Black Soldier Fly Larvae as a Germination Substrate on the Phytotoxicity, Germination Index, Growth and Antioxidant Contents in Kale (Brassica oleracea)" Agronomy 14, no. 7: 1392. https://doi.org/10.3390/agronomy14071392

APA Style

González-Lara, H., Parra-Pacheco, B., Aguirre-Becerra, H., Feregrino-Perez, A. A., & Garcia-Trejo, J. F. (2024). Effects of Using Thermocomposted Frass from Black Soldier Fly Larvae as a Germination Substrate on the Phytotoxicity, Germination Index, Growth and Antioxidant Contents in Kale (Brassica oleracea). Agronomy, 14(7), 1392. https://doi.org/10.3390/agronomy14071392

Note that from the first issue of 2016, this journal uses article numbers instead of page numbers. See further details here.

Article Metrics

Back to TopTop
