Electronics, Volume 12, Issue 8
April-2 2023 - 202 articles
- Issues are regarded as officially published after their release is announced to the table of contents alert mailing list .
- You may sign up for email alerts to receive table of contents of newly released issues.
- PDF is the official format for papers published in both, html and pdf forms. To view the papers in pdf format, click on the "PDF Full-text" link, and use the free Adobe Reader to open them.
Cover Story: This paper proposes a three-dimensional lattice structure that reduces parasitic inductance through horizontal and vertical magnetic flux cancellations within a printed circuit board (PCB). The relationship between the magnetic flux cancellation and the parasitic inductance is analyzed, and the magnetic flux cancellation in the proposed structure is described. In addition, a practical PCB layout design procedure based on the proposed structure is provided. Simulation results demonstrate a 55.8% reduction in parasitic inductance, and experimental results show reduced overshoot and ringing at the switching transient, resulting in a 26% reduction in switching loss. As a result, the proposed method can improve the efficiency and stability of WBG device-based power converters. View this paper
