Article

Patellar Dislocation Patients Had Lower Bone Mineral Density and Hounsfield Unit Values in the Knee Joint Compared to Patients with Anterior Cruciate Ligament Ruptures: A Focus on Cortical Bone in the Tibia

by
Yue Wu
1,2,3,4,†,
Yiting Wang
1,2,3,†,
Haijun Wang
1,2,3,
Shaowei Jia
1,2,3,
Yingfang Ao
1,2,3,4,
Xi Gong
1,2,3,* and
Zhenlong Liu
1,2,3,*
1
Department of Sports Medicine, Peking University Third Hospital, Institute of Sports Medicine of Peking University, Beijing 100191, China
2
Beijing Key Laboratory of Sports Injuries, Beijing Municipal Science and Technology Commission, Beijing 100191, China
3
Engineering Research Center of Sports Trauma Treatment Technology and Devices, Ministry of Education, Beijing 100191, China
4
Tianjin Key Laboratory of Exercise Physiology and Sports Medicine, Institute of Sport, Exercise & Health, Tianjin University of Sport, Tianjin 300381, China
*
Authors to whom correspondence should be addressed.
†
These authors contributed to the work equally.
Bioengineering 2025, 12(2), 165; https://doi.org/10.3390/bioengineering12020165
Submission received: 31 December 2024 / Revised: 22 January 2025 / Accepted: 6 February 2025 / Published: 8 February 2025
(This article belongs to the Section Biomedical Engineering and Biomaterials)
Browse Figures
Versions Notes

Abstract

:
Anterior cruciate ligament (ACL) rupture and patellar dislocation (PD) are common knee injuries. Dual-energy X-ray absorptiometry (DXA) and computed tomography (CT) are widely used clinical diagnostic tools. The aim was to investigate the characteristics of knee bone mineral density (BMD) in patients with ACL rupture and PD and to explore the relationship between BMD and Hounsfield unit (HU) values. This prospective cross-sectional study included 32 ACL rupture and 32 PD patients assessed via DXA and CT. BMD and CT measurements were taken from regions of interest in the femoral and tibial condyles. Statistical analyses included t-tests and mixed-effects models. The results showed that BMD in the PD group was significantly lower than in the ACL group (p < 0.05). The HU values of cortical bone in the femur and tibia differed significantly between the ACL group and the PD group (p < 0.05). The BMD of the femur and tibia showed significant correlations with the HU values of cancellous bone and cortical bone (p < 0.05). The conclusion was that PD patients had lower BMD and HU values in the femur and tibia compared to patients with ACL ruptures, particularly in the cortical bone of the tibia, and there was a strong correlation between HU value and BMD.

1. Introduction

Anterior cruciate ligament (ACL) rupture and patellar dislocation (PD) are common knee injuries in the field of sports medicine, particularly among young and active individuals [1,2]. The annual incidence of ACL rupture is approximately five cases per 10,000 people in the general population [3]. In contrast, the incidence of PD is 5.8 per 100,000 individuals, with a higher rate of 29 per 100,000 among young adults [4]. Following ACL rupture and PD, patients often experience symptoms such as knee swelling, limited mobility, and joint instability, which can affect daily activities, physical function, and quality of life, especially for athletes [5,6,7]. As a result, these conditions are frequently associated with misdiagnoses or missed diagnoses in clinical practice.
Although ACL reconstruction (ACLR) is commonly performed after ACL rupture, several studies have reported a decrease in local bone mineral density (BMD) around the knee joint [8,9]. However, the impact of PD on knee joint BMD remains underexplored. Surgical treatment for both ACL rupture and PD is the current standard approach for addressing knee joint instability [10,11]. These procedures both involve the process of drilling bone tunnels, and both face challenges related to ligament-to-bone healing postoperatively. Minimizing the rate of bone tunnel enlargement and promoting tendon–bone healing are closely linked to the local BMD.
Dual-energy X-ray absorptiometry (DXA) is the conventional method for measuring BMD, but it cannot differentiate between cancellous and cortical bone [12,13]. Computed tomography (CT) is a widely used clinical diagnostic tool that can distinguish between trabecular and cortical bone [14]. However, routine CT imaging only reflects signal strength through Hounsfield unit (HU) values and does not directly quantify BMD [15].
The aim of this study is to investigate the characteristics of BMD changes in the knee joints of patients with ACL rupture and PD and to explore the relationship between BMD and HU values obtained from CT. This research can provide a theoretical foundation for improving the clinical treatment and rehabilitation of ACL rupture and PD.

2. Methods

2.1. Study Design

This study is a prospective cross-sectional study with 1:1 ACL rupture patients and PD patients. The Ethics Committee of Peking University Third Hospital approved the study (202303303).
This study was registered at www.clinicaltrials.gov (NCT05924178). IRB approval was granted for this study. Informed consent was obtained from all participants prior to enrollment.

2.2. Participant Involvement

Volunteers were not directly involved in the design of the study but actively participated in the study. A recruitment advertisement was posted in the outpatient department to attract individuals with ACL rupture and PD patients.

2.3. Participants

Participants with unilateral ACL rupture (ACL group) and age-matched patellar dislocation (PD group) were included in this study.
Inclusion criteria for the ACL group were as follows [16,17,18,19]: (1) Patients were ages 18 to 45 years with a first-time unilateral ACL rupture diagnosed via MRI. (2) Time since injury was greater than 4 weeks. The affected knee joint had passed the acute phase, with no significant swelling, pain, inflammation, or limited joint movement, and had basically regained normal range of motion. (3) There were no concurrent injuries to the Posterior Cruciate Ligament (PCL), Lateral Collateral Ligament (LCL), or Medial Collateral Ligament (MCL).
Inclusion criteria for the PD group were as follows [20,21,22]: (1) physiologic trochlea and Dejour type A or B trochlear dysplasia, (2) patellar dislocations (≥2 times), and (3) MRI evidence of medial patellofemoral ligament (MPFL) lesions.
Data collection was conducted between July 2023 and August 2024.

2.4. Sample Size

Preliminary experimental results indicated that the BMD at the femoral and tibial ends of the knee joint were selected as the primary indicators for observation. A statistically significant difference was considered if either of these two indicators showed variation. The Least Significant Difference (LSD) method was applied to correct for Type I error, denoted by α. Based on the preliminary experimental results, the BMD at the femoral end of the knee joint in patients with ACL rupture was 1.31 ± 0.28 g/cm2, compared to 1.61 ± 0.31 g/cm2 in the contralateral knee. The sample size estimation formula for two independent groups was set at α = 0.05 and β = 0.2, yielding a required sample size of 16 participants per group. Based on the BMD at the tibial end of the knee joint (injured side: 0.94 ± 0.14 g/cm2, contralateral side: 1.09 ± 0.15 g/cm2), the calculations determined that a sample size of 19 cases per group was needed. Taking the larger of these two results, at least 19 patellar dislocation individuals were selected.

2.5. DXA Scan Protocol

BMD was measured using a Lunar iDXA (GE Healthcare, Milwaukee, WI, USA) [23,24]. Lumbar BMD was first assessed to rule out primary osteoporosis, followed by measurement of BMD at the injured knee. All standard clinical scans, including lumbar BMD and knee assessments, were performed and analyzed according to the manufacturer’s guidelines [25].
For knee BMD measurement, regions of interest (ROIs) were manually outlined. A 5 cm vertical line was drawn from the intercondylar pit of the femur, and a 4 cm vertical line was drawn from the lateral intercondylar ridge of the tibia. This allowed the knee joint to be divided into 4 ROIs: the medial femoral condyle (MCF), the lateral femoral condyle (LCF), the medial tibial condyle (MCT), and the lateral tibial condyle (LCT) (Figure 1).

2.6. CT Scan Protocol

2.6.1. Measurement of Femoral HU Values

We selected the layer where the lateral femoral condyle was the most prominent in sagittal plane.
(1)
Cortical Bone HU Value: We measured at the transitional area between the posterior femoral condyle and the shaft (within ± 1 cm above and below this region), taking three points along the anterior cortex of the femur parallel to the posterior femoral surface, as well as three evenly spaced points on the articular surface of the lateral femoral condyle (Figure 2A).
(2)
Lateral Condyle Cancellous Bone HU Value: We drew a 5 cm vertical line upward from the highest point of the intercondylar fossa, avoiding the cortical bone, and measured within the fixed region (Figure 2B).
We identified the coronal plane that corresponded to the sagittal plane of the femur.
(1)
Cortical Bone HU Value: We measured at the transitional area between the lateral femoral condyle and the shaft (within ± 1 cm above and below this region), taking three points along the medial cortex of the femur parallel to the lateral femoral surface as well as three evenly spaced points on the articular surfaces of both the medial and lateral femoral condyles (Figure 2C).
(2)
Lateral Condyle Cancellous Bone HU Value: We drew a 5 cm vertical line upward from the highest point of the intercondylar fossa, avoiding the cortical bone, and measured within the fixed region (Figure 2D).

2.6.2. Measurement of Tibial HU Values

We selected the layer where the tibial intercondylar eminence was the most clearly visible in coronal plane.
(1)
Cortical Bone HU Value: We measured at the transitional area between the medial tibial condyle and the shaft (within ± 1 cm above and below this region), taking three points along the lateral tibial cortex parallel to the medial tibial surface as well as three evenly spaced points on both the medial and lateral tibial plateaus (Figure 2E).
(2)
Medial Condyle Cancellous Bone HU Value: We drew a 4 cm vertical line downward from the lateral intercondylar eminence, avoiding the cortical bone, and measured within the fixed region (Figure 2F).
We identified the sagittal plane that corresponded to the coronal plane of the tibia.
(1)
Cortical Bone HU Value: We measured at the transitional area between the anterior tibial condyle and the shaft (within ± 1 cm above and below this region), taking three points along the posterior cortex of the tibia parallel to the anterior tibial surface as well as three evenly spaced points on the tibial plateau (Figure 2G).
(2)
Medial Condyle Cancellous Bone HU Value: We drew a 4 cm vertical line downward from the tibial plateau, avoiding the cortical bone, and measured within the fixed region (Figure 2H).
For each selected layer of the femur and tibia in both the coronal and sagittal planes, we measured the current layer as well as two adjacent layers on either side, collecting data from a total of five layers. We calculated the average value across these five layers for analysis.

2.7. Statistical Analysis

Statistical analyses were performed using SPSS 21.0 and R 4.3.1. For normally distributed variables, data were expressed as mean ± standard deviation (x ± SD) and analyzed using the t-test and mixed-effects model. For non-normally distributed variables, data were described as the median (P25, P75) and analyzed using non-parametric tests. A p-value of less than 0.05 was considered statistically significant.

3. Results

3.1. Patient Information

From April 2023 to August 2024, a total of 40 ACL rupture patients were screened. Of these, eight participants were excluded: four had injuries lasting less than 4 weeks, one had a severe MCL injury, and three had injuries on the contralateral side. As a result, 32 patients with ACL rupture (ACL group) were eligible for inclusion. An additional 32 participants with patellar dislocation (PD group) were also included in the study (Figure 3).
The time from injury was significantly longer in the PD group compared to the ACL rupture group (p < 0.01). No significant differences were observed for other participant characteristics (Table 1).

3.2. BMD of DXA

The results of BMD measurements by DXA are shown in Table 2. None of the patients were diagnosed with primary osteoporosis. However, BMD at the MCF, MCT, and LCT in the PD group were significantly lower than in the ACL group (p = 0.000, 0.0003, 0.017, all <0.05).

3.3. HU Value of CT

The HU values of cortical bone in the femur and tibia differed significantly between the ACL rupture group and the PD group, whereas the HU values of cancellous bone in both the femur and tibia showed no significant difference (Table 3).
For cortical bone, the HU values in the PD group were significantly lower than those in the ACL rupture group at the posterior femur in the SP, medial tibial plateau in the CP, medial condyle and shaft transition in the CP, lateral condyle and shaft transition in the CP, and posterior tibia in the SP (p < 0.05). In contrast, at the lateral condyle articular surface and lateral tibial plateau in the CP, the HU values in the ACL rupture group were significantly lower than those in the PD group (p < 0.05).

3.4. The Relationship Between BMD and HU Value

A linear mixed model analysis was conducted on the BMD and HU values of ACL and PD patients, with the results presented in Table 4. In our model, the fixed effects included HU values measured at different sites, while the random effects accounted for variations among individual patients and different groups, with random intercepts to account for inter-individual and inter-group differences.
The relationship between BMD and CT can be expressed as “BMDij = β0 + β1 ✖HUij + (1|Patient Group) + ϵij”, where β0 is the fixed intercept, β1 is the fixed effect of the HU value, and (1|Patient Group) represents the random intercepts for patient grouping.
The BMD of the MCF was significantly correlated with the HU value of the medial condyle in the CP (p < 0.01). The BMD of the LCF showed significant correlations with the HU values of cancellous bone in the SP of the lateral femoral condyle, cortical bone of the lateral condyle articular surface, and both the anterior and posterior femur in the SP (p < 0.05).
The BMD of the MCT was significantly correlated with the HU values of cancellous bone in the CP of the medial condyle, cortical bone of the tibial plateau, and posterior tibia in the SP (p < 0.05). Additionally, the BMD of the LCF was significantly correlated with the cortical bone HU value of the lateral tibial plateau in the CP (p < 0.05).

4. Discussion

Our study found that both ACL rupture and PD led to a reduction in knee joint BMD. Surgery is an effective method for addressing joint instability. However, BMD continues to decline postoperatively, which can hinder the healing of the graft-tendon-bone junction. Therefore, understanding the characteristics of post-injury joint BMD in a more convenient and comprehensive way is crucial for guiding surgery and precision rehabilitation. However, there is currently a lack of research on the use of CT for assessing knee joint BMD as well as a lack of studies exploring the changes in knee joint BMD following ACL rupture and PD. This is the first study to explore the BMD changes in patients after ACL rupture and PD using both DXA and CT and to compare these changes between the two groups. The level of evidence in our study is relatively high. The significance of our research lies in the finding that the knee joint BMD and HU values of PD patients were lower than those of ACL rupture patients, with HU values providing a more convenient method for reflecting joint bone content compared to DXA. This information can help guide surgery and precision rehabilitation, ultimately promoting tendon–bone healing after surgery.
The results indicate that the degree of bone loss in the knee joint is greater in PD patients compared to ACL rupture patients. Additionally, we found that bone loss predominantly involved cortical bone, particularly in the tibia. Possible explanations for this finding include the following: First, PD patients generally have a longer duration of injury compared to ACL rupture patients. A longer injury duration can lead to a more prolonged period of limited physical activity, reducing the amount of movement compared to pre-injury levels, which may contribute to the reduction in joint bone mass. This finding aligns with the IKDC score results, which showed that ACL rupture patients had significantly higher IKDC scores than PD patients. Furthermore, all the PD patients included in this study had experienced two or more patellar dislocations, and many of these patients exhibited a significant fear of reinjury. This fear likely further limited the intensity of their physical activity. Recent studies support our findings, indicating a decrease in BMD in the knee joint following ACL rupture and ACL reconstruction (ACLR). A reduction in BMD of the medial femoral condyle was observed within the first 4 weeks post-ACL rupture, with a more pronounced decline in overall knee joint BMD by the 10th week [26]. Additionally, BMD in the injured leg was significantly reduced compare to the uninjured leg following ACLR. Even 26 months after reconstruction, BMD in the affected knee remained 16% lower than preoperative levels [8], and this decline may persist for over 10 years post-ACLR [9]. During reconstruction, the local BMD in the knee decreases, leading to loosening of the bone tunnel, weakening bone strength at the tendon–bone attachment site, and impairing the organization of transitional tissue at the tendon–bone interface. This process enlarges the bone tunnel, which hinders the healing of the reconstructed ligament and tendon–bone junction [27]. Studies have confirmed that in an osteoporotic ovine model, a decrease in BMD following rotator cuff reconstruction surgery can reduce the tendon modulus of the reconstructed ligament [28]. Following PD, patients may experience a fear of movement, which leads to reduced physical activity. Previous studies have shown that exercise can promote the expression of osteogenic factors, both at the gene and protein levels, accelerating osteoblast proliferation and differentiation, while also reducing osteocyte apoptosis, thereby strengthening bone quality [29]. However, current research has not yet focused on the changes in knee joint BMD following PD nor on how to intervene in response to the BMD decline caused by joint instability. Furthermore, studies exploring appropriate interventions and their impacts on BMD after such injuries are lacking. The results of our study suggest that PD patients may require more targeted interventions for knee joint BMD, such as early and precise rehabilitation exercises, which may also promote tendon–bone healing post-surgery.
The results of our study showing the correlation between BMD and HU values indicate a high degree of association between these two measures, with CT providing a more precise, comprehensive, and convenient reflection of knee joint BMD compared to DXA. Unlike DXA, which measures BMD in two dimensions, CT can distinguish between cancellous and cortical bone and perform three-dimensional measurements. This distinction is particularly important, as factors such as osteophyte formation or calcification at the joint margins can affect the accuracy of DXA measurements [30,31]. CT has a higher resolution and sensitivity, allowing for a more comprehensive assessment of BMD [32,33]. Clinically, when a patient is injured, CT not only allows for the assessment of BMD but is also more commonly used to diagnose bone continuity issues [34,35]. With a single scan, multiple concerns can be addressed, making it more convenient. Previous studies have shown that quantitative CT (QCT) measurements of cancellous BMD are closer to the standard value of grayscale BMD and are better and more accurately able to reflect bone metabolism changes compared to DXA when diagnosing osteoporosis [36]. However, research on QCT for knee joints is still limited. This study demonstrates that CT and DXA are highly correlated when assessing knee joint BMD in cases of ACL rupture and PD, with CT outperforming DXA in terms of accuracy, reliability, and comprehensiveness. Furthermore, this study provides a foundation for future research on QCT for knee joints.
In conclusion, this study reveals that both ACL rupture and PD lead to a decrease in knee joint BMD, with a more significant reduction observed in PD patients. Additionally, CT offers a more precise assessment of BMD compared to DXA. These findings not only support surgical decision making but also provide a basis for developing more accurate rehabilitation plans, ultimately promoting tendon–bone healing after surgery.

5. Conclusions

PD patients had lower BMD and HU values in the femur and tibia compared to patients with ACL ruptures, particularly in the cortical bone of the tibia. There is a strong correlation between HU value and BMD. CT provides a more precise assessment of BMD changes and may serve as a valuable tool for monitoring joint health and guiding rehabilitation strategies post-injury.

Author Contributions

Study Design: Z.L., X.G., Y.A. and Y.W. (Yue Wu). Manuscript Writing: Y.W. (Yue Wu) and Y.W. (Yiting Wang). Data Collection: Y.W. (Yue Wu) and Y.W. (Yiting Wang). Data Analysis and Statistical Analysis: Y.W. (Yue Wu), Y.W. (Yiting Wang), H.W. and S.J. Final Approval of Manuscript: All authors. All authors have read and agreed to the published version of the manuscript.

Funding

Funding for this study was provided by the Joint Fund for Regional Innovation and Development (U23A20471) and Beijing Natural Science Foundation (L242161).

Institutional Review Board Statement

The study was conducted according to the guidelines of the Declaration of Helsinki and approved by the Ethics Committee of Peking University Third Hospital, with the assigned approval number 202303303.

Informed Consent Statement

This study was registered at www.clinicaltrials.gov (NCT05924178). Informed consent was obtained from all subjects involved in the study.

Data Availability Statement

All relevant data are within the paper.

Acknowledgments

The authors extend their heartfelt thanks to the participants for their invaluable contributions to this study.

Conflicts of Interest

The authors declare no conflicts of interest.

References

  1. Liu, H.; Liu, J.; Wu, Y.W.; Ma, Y.H.; Gu, S.J.; Rui, Y.J. Changes in local bone mineral density can guide the treatment plan for patients with rupture of the anterior cruciate ligament. Ann. Palliat. Med. 2021, 10, 6388–6398. [Google Scholar] [CrossRef]
  2. Dai, R.; Wu, Y.; Jiang, Y.; Huang, H.; Meng, Q.; Shi, W.; Ren, S.; Ao, Y. Epidemiology of Lateral Patellar Dislocation Including Bone Bruise Incidence: Five Years of Data from a Trauma Center. Orthop. Surg. 2024, 16, 437–443. [Google Scholar] [CrossRef] [PubMed]
  3. Moses, B.; Orchard, J.; Orchard, J. Systematic Review: Annual Incidence of ACL Injury and Surgery in Various Populations. Res. Sports Med. 2012, 20, 157–179. [Google Scholar] [CrossRef]
  4. Jain, N.P.; Khan, N.; Fithian, D.C. A Treatment Algorithm for Primary Patellar Dislocations. Sports Health Multidiscip. Approach 2011, 3, 170–174. [Google Scholar] [CrossRef] [PubMed]
  5. Kejriwal, R.; Annear, P. Arthroscopic assessment of patella tracking correlates with recurrent patellar instability. Knee Surg. Sports Traumatol. Arthrosc. 2020, 28, 876–880. [Google Scholar] [CrossRef] [PubMed]
  6. Stropnik, D.; Sajovic, M.; Kacin, A.; Pavlič-Založnik, S.; Drobnič, M. Early clinical and neuromuscular properties in patients with normal or sub-normal subjective knee function after anterior cruciate ligament reconstruction. Arch. Orthop. Trauma Surg. 2020, 140, 1231–1239. [Google Scholar] [CrossRef]
  7. Forde, C.; Mortimer, C.; Haddad, M.; Hirani, S.P.; Williams, M.A.; Keene, D.J. Objectively quantified lower limb strength recovery in people treated surgically or non-surgically after patellar dislocation: A systematic review. Phys. Ther. Sport 2021, 51, 110–138. [Google Scholar] [CrossRef]
  8. Ejerhed, L.; Kartus, J.; Nilsen, R.; Nilsson, U.; Kullenberg, R.; Karlsson, J. The effect of anterior cruciate ligament surgery on bone mineral in the calcaneus: A prospective study with a 2-year follow-up evaluation. Arthroscopy 2004, 20, 352–359. [Google Scholar] [CrossRef] [PubMed]
  9. Coggan, A.R.; Coyle, E.F. Reversal of fatigue during prolonged exercise by carbohydrate infusion or ingestion. J. Appl. Physiol. 1987, 63, 2388–2395. [Google Scholar] [CrossRef] [PubMed]
  10. Inclan, P.M.; Brophy, R.H. Revision anterior cruciate ligament reconstruction. Bone Jt. J. 2023, 105-b, 474–480. [Google Scholar] [CrossRef] [PubMed]
  11. Smith, T.O.; Gaukroger, A.; Metcalfe, A.; Hing, C.B. Surgical versus non-surgical interventions for treating patellar dislocation. Cochrane Database Syst. Rev. 2023, 1, Cd008106. [Google Scholar] [CrossRef] [PubMed]
  12. Lee, K.; Al Jumaily, K.; Lin, M.; Siminoski, K.; Ye, C. Dual-energy x-ray absorptiometry scanner mismatch in follow-up bone mineral density testing. Osteoporos. Int. 2022, 33, 1981–1988. [Google Scholar] [CrossRef] [PubMed]
  13. Deshpande, N.; Hadi, M.S.; Lillard, J.C.; Passias, P.G.; Linzey, J.R.; Saadeh, Y.S.; LaBagnara, M.; Park, P. Alternatives to DEXA for the assessment of bone density: A systematic review of the literature and future recommendations. J. Neurosurg. Spine 2023, 38, 436–445. [Google Scholar] [CrossRef]
  14. Hsu, J.T.; Chen, Y.J.; Ho, J.T.; Huang, H.L.; Wang, S.P.; Cheng, F.C.; Wu, J.; Tsai, M.T. A comparison of micro-CT and dental CT in assessing cortical bone morphology and trabecular bone microarchitecture. PLoS ONE 2014, 9, e107545. [Google Scholar] [CrossRef] [PubMed]
  15. Lee, H.; Park, S.; Kwack, K.-S.; Yun, J.S. CT and MR for bone mineral density and trabecular bone score assessment in osteoporosis evaluation. Sci. Rep. 2023, 13, 16574. [Google Scholar] [CrossRef] [PubMed]
  16. de Bakker, C.M.J.; Knowles, N.K.; Walker, R.E.A.; Manske, S.L.; Boyd, S.K. Independent changes in bone mineralized and marrow soft tissues following acute knee injury require dual-energy or high-resolution computed tomography for accurate assessment of bone mineral density and stiffness. J. Mech. Behav. Biomed. Mater. 2022, 127, 105091. [Google Scholar] [CrossRef] [PubMed]
  17. Failla, M.J.; Logerstedt, D.S.; Grindem, H.; Axe, M.J.; Risberg, M.A.; Engebretsen, L.; Huston, L.J.; Spindler, K.P.; Snyder-Mackler, L. Does Extended Preoperative Rehabilitation Influence Outcomes 2 Years After ACL Reconstruction? A Comparative Effectiveness Study Between the MOON and Delaware-Oslo ACL Cohorts. Am. J. Sports Med. 2016, 44, 2608–2614. [Google Scholar] [CrossRef] [PubMed]
  18. Grindem, H.; Granan, L.P.; Risberg, M.A.; Engebretsen, L.; Snyder-Mackler, L.; Eitzen, I. How does a combined preoperative and postoperative rehabilitation programme influence the outcome of ACL reconstruction 2 years after surgery? A comparison between patients in the Delaware-Oslo ACL Cohort and the Norwegian National Knee Ligament Registry. Br. J. Sports Med. 2015, 49, 385–389. [Google Scholar] [CrossRef] [PubMed]
  19. Shi, H.; Ren, S.; Huang, H.; Liu, H.; Liang, Z.; Yu, Y.; Li, H.; Ao, Y. Bilateral Alterations in Isokinetic Strength and Knee Biomechanics During Side-Cutting 1 Year After Unilateral ACL Reconstruction. Am. J. Sports Med. 2022, 50, 2961–2971. [Google Scholar] [CrossRef]
  20. Dejour, H.; Walch, G.; Nove-Josserand, L.; Guier, C. Factors of patellar instability: An anatomic radiographic study. Knee Surg. Sports Traumatol. Arthrosc. 1994, 2, 19–26. [Google Scholar] [CrossRef]
  21. Tian, G.; Yang, G.; Zuo, L.; Li, F.; Wang, F. Femoral derotation osteotomy for recurrent patellar dislocation. Arch. Orthop. Trauma Surg. 2020, 140, 2077–2084. [Google Scholar] [CrossRef]
  22. Ihle, C.; Maurer, J.; Ziegler, P.; Stöckle, U.; Ateschrang, A.; Ahrend, M.D.; Schröter, S. Sporting activity is reduced following medial reefing performed for patellar dislocation. BMC Musculoskelet. Disord. 2019, 20, 34. [Google Scholar] [CrossRef] [PubMed]
  23. Blaty, T.; Krueger, D.; Illgen, R.; Squire, M.; Heiderscheit, B.; Binkley, N.; Anderson, P. DXA evaluation of femoral bone mineral density and cortical width in patients with prior total knee arthroplasty. Osteoporos. Int. 2019, 30, 383–390. [Google Scholar] [CrossRef] [PubMed]
  24. Choi, K.Y.; Lee, S.W.; In, Y.; Kim, M.S.; Kim, Y.D.; Lee, S.Y.; Lee, J.-W.; Koh, I.J. Dual-Energy CT-Based Bone Mineral Density Has Practical Value for Osteoporosis Screening around the Knee. Medicina 2022, 58, 1085. [Google Scholar] [CrossRef] [PubMed]
  25. Borchardt, G.; Nickel, B.; Andersen, L.; Hetzel, S.; Illgen, R.; Hennessy, D.; Anderson, P.A.; Binkley, N.; Krueger, D. Femur and Tibia BMD Measurement in Elective Total Knee Arthroplasty Candidates. J. Clin. Densitom. 2022, 25, 319–327. [Google Scholar] [CrossRef] [PubMed]
  26. Wohl, G.R.; Shymkiw, R.C.; Matyas, J.R.; Kloiber, R.; Zernicke, R.F. Periarticular cancellous bone changes following anterior cruciate ligament injury. J. Appl. Physiol. 2001, 91, 336–342. [Google Scholar] [CrossRef] [PubMed]
  27. Lui, P.P.; Ho, G.; Shum, W.T.; Lee, Y.W.; Ho, P.Y.; Lo, W.N.; Lo, C.K. Inferior tendon graft to bone tunnel healing at the tibia compared to that at the femur after anterior cruciate ligament reconstruction. J. Orthop. Sci. 2010, 15, 389–401. [Google Scholar] [CrossRef] [PubMed]
  28. Johnson, J.W.; von Stade, D.; Gadomski, B.; Easley, J.; Nelson, B.; Bisazza, K.; Regan, D.; Troyer, K.; Zhou, T.; McGilvray, K. Modified Alendronate Mitigates Mechanical Degradation of the Rotator Cuff in an Osteoporotic Ovine Model. Am. J. Sports Med. 2022, 50, 3649–3659. [Google Scholar] [CrossRef]
  29. Zhang, S.; Huang, X.; Zhao, X.; Li, B.; Cai, Y.; Liang, X.; Wan, Q. Effect of exercise on bone mineral density among patients with osteoporosis and osteopenia: A systematic review and network meta-analysis. J. Clin. Nurs. 2022, 31, 2100–2111. [Google Scholar] [CrossRef] [PubMed]
  30. Watanabe, D.; Takano, H.; Kimura, T.; Yamashita, A.; Minowa, T.; Mizushima, A. The relationship of diffuse idiopathic skeletal hyperostosis, visceral fat accumulation, and other age-related diseases with the prevalent vertebral fractures in elderly men with castration-naïve prostate cancer. Aging Male 2020, 23, 1512–1517. [Google Scholar] [CrossRef]
  31. Hayden, A.C.; Binkley, N.; Krueger, D.; Bernatz, J.T.; Kadri, A.; Anderson, P.A. Effect of degeneration on bone mineral density, trabecular bone score and CT Hounsfield unit measurements in a spine surgery patient population. Osteoporos. Int. 2022, 33, 1775–1782. [Google Scholar] [CrossRef]
  32. Pickhardt, P.J.; Pooler, B.D.; Lauder, T.; del Rio, A.M.; Bruce, R.J.; Binkley, N. Opportunistic screening for osteoporosis using abdominal computed tomography scans obtained for other indications. Ann. Intern. Med. 2013, 158, 588–595. [Google Scholar] [CrossRef] [PubMed]
  33. Berger-Groch, J.; Thiesen, D.M.; Ntalos, D.; Hennes, F.; Hartel, M.J. Assessment of bone quality at the lumbar and sacral spine using CT scans: A retrospective feasibility study in 50 comparing CT and DXA data. Eur. Spine J. 2020, 29, 1098–1104. [Google Scholar] [CrossRef]
  34. Michalski, A.S.; Besler, B.A.; Burt, L.A.; Boyd, S.K. Opportunistic CT screening predicts individuals at risk of major osteoporotic fracture. Osteoporos. Int. 2021, 32, 1639–1649. [Google Scholar] [CrossRef]
  35. Black, D.M.; Bouxsein, M.L.; Marshall, L.M.; Cummings, S.R.; Lang, T.F.; Cauley, J.A.; Ensrud, K.E.; Nielson, C.M.; Orwoll, E.S. Proximal femoral structure and the prediction of hip fracture in men: A large prospective study using QCT. J. Bone Miner. Res. 2008, 23, 1326–1333. [Google Scholar] [CrossRef]
  36. Cheng, X.; Zhao, K.; Zha, X.; Du, X.; Li, Y.; Chen, S.; Wu, Y.; Li, S.; Lu, Y.; Zhang, Y.; et al. Opportunistic Screening Using Low-Dose CT and the Prevalence of Osteoporosis in China: A Nationwide, Multicenter Study. J. Bone Miner. Res. 2021, 36, 427–435. [Google Scholar] [CrossRef] [PubMed]
Bioengineering 12 00165 g001
Figure 1. Custom regions of knee BMD interest. Abbreviations: BMD, bone mineral density; ROIs, regions of interest.
Figure 1. Custom regions of knee BMD interest. Abbreviations: BMD, bone mineral density; ROIs, regions of interest.
Bioengineering 12 00165 g001
Bioengineering 12 00165 g002aBioengineering 12 00165 g002b
Figure 2. CT scan protocol. Abbreviations: HU, Hounsfield units; SP, sagittal plane; CP, coronal plane. (A) Cortical bone HU values in the SP of the femur, (B) lateral condyle cancellous bone HU values in the SP of the femur, (C) cortical bone HU values in the CP of the femur, (D) lateral condyle cancellous bone HU values in the CP of the femur, (E) cortical bone HU values in the CP of the tibia, (F) medial condyle cancellous bone HU values in the CP of the tibia, (G) cortical bone HU values in the SP of the tibia, (H) medial condyle cancellous bone HU values in the SP of the tibia.
Figure 2. CT scan protocol. Abbreviations: HU, Hounsfield units; SP, sagittal plane; CP, coronal plane. (A) Cortical bone HU values in the SP of the femur, (B) lateral condyle cancellous bone HU values in the SP of the femur, (C) cortical bone HU values in the CP of the femur, (D) lateral condyle cancellous bone HU values in the CP of the femur, (E) cortical bone HU values in the CP of the tibia, (F) medial condyle cancellous bone HU values in the CP of the tibia, (G) cortical bone HU values in the SP of the tibia, (H) medial condyle cancellous bone HU values in the SP of the tibia.
Bioengineering 12 00165 g002aBioengineering 12 00165 g002b
Bioengineering 12 00165 g003
Figure 3. Flow diagram of eligible and included participants. Abbreviations: ACL, ACL rupture group; PD, patellar dislocation group.
Figure 3. Flow diagram of eligible and included participants. Abbreviations: ACL, ACL rupture group; PD, patellar dislocation group.
Bioengineering 12 00165 g003
Table 1. Participant characteristics.
Table 1. Participant characteristics.
CharacteristicsACL (n = 32) Mean (SD)PD (n = 32) Mean (SD)
Age (years)29.02 (7.59)26.46 (4.55)
Male/Female (n/n)17/1512/20
Height (cm)170.46 (9.37)169.38 (7.92)
Weight (Kg)69.99 (11.64)67.37 (9.59)
BMI (Kg/m2)23.55 (3.13)22.84 (3.26)
Time since injury (months)3.89 (1.66) **12.37 (9.39)
Tegner score2.78 (0.55)3.03 (0.65)
Lysholm score68.67 (12.41)69.76(13.35)
IKDC score69.07 (11.00) *66.59 (9.82)
Abbreviations: ACL, ACL rupture group; PD, patellar dislocation group; IKDC, International Knee Documentation Committee. * Significant difference compared with CON groups p < 0.05, ** p < 0.01.
Table 2. The BMD of the knee (g/cm2).
Table 2. The BMD of the knee (g/cm2).
ACL Mean ± SD (n = 32)PD Mean ± SD (n = 32)p
MCF1.24 ± 0.23 **0.99 ± 0.160.000
LCF1.56 ± 0.341.47 ± 0.290.244
MCT1.03 ± 0.19 **0.89 ± 0.130.003
LCT1.07 ± 0.23 *0.96 ± 0.170.017
Abbreviations: BMD, bone mineral density; ROIs, regions of interest; ACL, ACL rupture group; PD, patellar dislocation group; MCF, medial condyle of femur; LCF, lateral condyle of femur; MCT, medial condyle of tibia; LCT, lateral condyle of tibia. * Significant difference compared with PD groups p < 0.05, ** p < 0.01.
Table 3. The HU value of knee CT.
Table 3. The HU value of knee CT.
ACL Mean ± SD (n = 32)PD Mean ± SD (n = 32)p
FemurCancellous bone in the CPLateral condyle192.96 ± 82.32187.20 ± 59.280.749
Cortical bone in the CPMedial condyle articular surface524.34 ± 111.32494.15 ± 80.840.219
Lateral condyle articular surface466.94 ± 90.41 *507.38 ± 63.690.043
Medial condyle and shaft transition833.58 ± 151.27823.94 ± 207.400.833
Lateral condyle and shaft transition979.28 ± 152.22929.18 ± 198.050.261
Cancellous bone in the SPLateral condyle215.98 ± 72.42200.15 ± 56.600.333
Cortical bone in the SPLateral condyle articular surface539.45 ± 107.14560.52 ± 68.390.352
Anterior femur744.60 ± 132.84733.23 ± 118.910.719
Posterior femur987.99 ± 102.74 **896.95 ± 123.980.002
TibiaCancellous bone in the CPMedial condyle128.85 ± 67.40137.04 ± 47.980.577
Cortical bone in the CPMedial tibial plateau689.86 ± 141.23 *621.30 ± 91.340.024
Lateral tibial plateau447.11 ± 102.14 **529.86 ± 93.880.001
Medial condyle and shaft transition871.17 ± 113.65 **745.16 ± 132.550.000
Lateral condyle and shaft transition758.75 ± 161.59 **632.65 ± 137.970.001
Cancellous bone in the SPMedial condyle116.45 ± 65.24118.37 ± 50.280.896
Cortical bone in the SPTibial plateau554.13 ± 118.41568.31 ± 92.340.595
Anterior tibia627.91 ± 105.42598.45 ± 106.430.270
Posterior tibia1030.18 ± 97.70 **889.99 ± 104.180.000
HU, Hounsfield units; ROIs, regions of interest; ACL, ACL rupture group; PD, patellar dislocation group; CP, coronal plane; SP, sagittal plane. * Significant difference compared with PD groups p < 0.05, ** p < 0.01.
Table 4. The relationship between BMD and HU value.
Table 4. The relationship between BMD and HU value.
BMD SiteHU Value Siteβ ± SDp
MCFCortical bone in the CPMedial condyle articular surface0.000959 ± 0.000244<0.001
Medial condyle and shaft transition0.0000517 ± 0.0001310.694
LCFCancellous bone in the CPLateral condyle−0.000203 ± 0.0007630.790
Cortical bone in the CPLateral condyle articular surface−0.000234 ± 0.0005150.649
Lateral condyle and shaft transition0.000160 ± 0.0001980.419
Cancellous bone in the SPLateral condyle0.00293 ± 0.000807<0.001
Cortical bone in the SPLateral condyle articular surface0.00107 ± 0.0004540.018
Anterior femur−0.000589 ± 0.0003000.049
Posterior femur0.000599 ± 0.0002970.043
MCTCancellous bone in the CPMedial condyle0.00141 ± 0.0004520.002
Cortical bone in the CPMedial tibial plateau0.000173 ± 0.0001050.098
Medial condyle and shaft transition−0.000109 ± 0.00009130.232
Cancellous bone in the SPMedial condyle0.000617 ± 0.0004530.173
Cortical bone in the SPTibial plateau0.000273 ± 0.0001170.020
Anterior tibia0.000108 ± 0.0001090.321
Posterior tibia0.000244 ± 0.0001190.040
LCTCortical bone in the CPLateral tibial plateau0.00121 ± 0.0002130.016
Lateral condyle and shaft transition0.0000144 ± 0.0001390.917
BMD, bone mineral density; HU, Hounsfield units; ACL, ACL rupture group; PD, patellar dislocation group; MCF, medial condyle of femur; LCF, lateral condyle of femur; MCT, medial condyle of tibia; LCT, lateral condyle of tibia; CP, coronal plane; SP, sagittal plane.
Disclaimer/Publisher’s Note: The statements, opinions and data contained in all publications are solely those of the individual author(s) and contributor(s) and not of MDPI and/or the editor(s). MDPI and/or the editor(s) disclaim responsibility for any injury to people or property resulting from any ideas, methods, instructions or products referred to in the content.

Share and Cite

MDPI and ACS Style

Wu, Y.; Wang, Y.; Wang, H.; Jia, S.; Ao, Y.; Gong, X.; Liu, Z. Patellar Dislocation Patients Had Lower Bone Mineral Density and Hounsfield Unit Values in the Knee Joint Compared to Patients with Anterior Cruciate Ligament Ruptures: A Focus on Cortical Bone in the Tibia. Bioengineering 2025, 12, 165. https://doi.org/10.3390/bioengineering12020165

AMA Style

Wu Y, Wang Y, Wang H, Jia S, Ao Y, Gong X, Liu Z. Patellar Dislocation Patients Had Lower Bone Mineral Density and Hounsfield Unit Values in the Knee Joint Compared to Patients with Anterior Cruciate Ligament Ruptures: A Focus on Cortical Bone in the Tibia. Bioengineering. 2025; 12(2):165. https://doi.org/10.3390/bioengineering12020165

Chicago/Turabian Style

Wu, Yue, Yiting Wang, Haijun Wang, Shaowei Jia, Yingfang Ao, Xi Gong, and Zhenlong Liu. 2025. "Patellar Dislocation Patients Had Lower Bone Mineral Density and Hounsfield Unit Values in the Knee Joint Compared to Patients with Anterior Cruciate Ligament Ruptures: A Focus on Cortical Bone in the Tibia" Bioengineering 12, no. 2: 165. https://doi.org/10.3390/bioengineering12020165

APA Style

Wu, Y., Wang, Y., Wang, H., Jia, S., Ao, Y., Gong, X., & Liu, Z. (2025). Patellar Dislocation Patients Had Lower Bone Mineral Density and Hounsfield Unit Values in the Knee Joint Compared to Patients with Anterior Cruciate Ligament Ruptures: A Focus on Cortical Bone in the Tibia. Bioengineering, 12(2), 165. https://doi.org/10.3390/bioengineering12020165

Note that from the first issue of 2016, this journal uses article numbers instead of page numbers. See further details here.

Article Metrics

Back to TopTop
