Phylogenetic Insights Reveal New Taxa in Thyridariaceae and Massarinaceae

Abstract

Pleosporales is a highly diverse (and the largest) order in Dothideomycetes, and it is widespread in decaying plants in various environments around the world. During a survey of fungal diversity in Sichuan Province, China, specimens of hyphomycetous and Thyridaria-like fungi were collected from dead branches of pine trees and cherry trees. These taxa were initially identified as members of Massarinaceae and Thyridariaceae through morphological examination. Phylogenetic analyses of the Thyridariaceae, combining ITS, SSU, LSU, RPB2, and TEF1 sequence data, indicated a distinct clade sister to Pseudothyridariella and Thyridariella, distinct from any genus in the family. Thus, a new genus, Vaginospora, is proposed to accommodate the type species Vaginospora sichuanensis, which is characterized by semi-immersed globose to oblong ascomata with an ostiolar neck, cylindrical to clavate asci with an ocular chamber, and hyaline to dark brown, fusiform, 3–5-transversely septate ascospores with an inconspicuous mucilaginous sheath. Based on the morphological comparisons and multi-locus phylogenetic analyses (ITS, SSU, LSU, RPB2, and TEF1) of the Massarinaceae, we have identified three collections belonging to the genus Helminthosporium, leading us to propose H. filamentosa sp. nov., H. pini sp. nov., and H. velutinum as a new host record. According to Phylogenetic analysis, H. pini formed an independent clade sister to H. austriacum and H. yunnanense, and H. filamentosa represents the closest sister clade to H. quercinum. Helminthosporium pini is distinct from H. austriacum by the shorter conidiophores and H. yunnanense by the longer and wider conidia. The H. filamentosa differs from H. quercinum in having longer conidiophores and smaller conidia. This study extends our understanding of diversity within Thyridariaceae and Helminthosporium. Our findings underscore the rich biodiversity and potential for discovering novel fungal taxa within these groups.

1. Introduction

Pleosporales is the largest order in the Dothideomycetes and is primarily characterized by flask-shaped pseudothecia [1,2]. The diversity of species in Pleosporales is high, and most species are saprobes on decaying plant material in freshwater, marine, or terrestrial environments [3,4,5,6]. The members of Pleosporales can also be epiphytes, endophytes, or parasites on living leaves or stems, as well as hyperparasites on fungi or insects [7,8,9].

The family Thyridariaceae was proposed by Hyde et al. [10] to accommodate the genus Thyridaria Sacc. There are eight genera accommodated in Thyridariaceae: Chromolaenomyces Mapook & K.D. Hyde, Cycasicola Wanas., E.B.G. Jones & K.D. Hyde, Liua Phookamsak & K.D. Hyde, Parathyridaria Jaklitsch & Voglmayr, Parathyridariella Prigione, A. Poli, E. Bovio & Varese, Pseudothyridariella Mapook & K.D. Hyde, Thyridaria Sacc., and Thyridariella Devadatha, V.V. Sarma, K.D. Hyde, Wanas. & E.B.G. Jones [1,11]. The members of this family are mostly sexually morphic, characterized by having immersed or semi-immersed, globose, coriaceous, and black ascomata; peridium composed of two layers of textura angularis cells; 8-spored, bitunicate, cylindrical to subclavate, apically rounded with ocular chamber asci; ellipsoid to fusiform, brown, 2–3-septate ascospores [10]. The asexual morphs of Thyridariaceae are coelomycetous [12]. Species of this family saprobes on leaves and branches of woody plants and sometimes infect humans [12,13].

Helminthosporium Link was introduced by Link with H. velutinum Link as the type species [14]. It is an old and species-rich genus in the family Massarinaceae (Pleosporales). Several studies showed that Helminthosporium is polyphyletic, whose members are intermixed with taxa of Byssothecium Fuckel, Haplohelminthosporium Konta & K.D. Hyde, Helminthosporiella (Hern.-Restr., Sarria & Crous) Konta & K.D. Hyde, Pseudosplanchnonema Chethana & K.D. Hyde, and Synhelminthosporium Y.P. Chen & Maharachch. [15,16]. Many species of Helminthosporium have been identified through morphological studies, and the taxonomic history of the genus is complex and in a state of flux [17]. While many species are not congeneric with the generic type, they were reclassified into the other genera such as Bipolaris Shoemaker, Curvularia Boedijn, Drechslera S. Ito, and Exserohilum K.J. Leonard & Suggs [18,19,20]. In addition, some lignicolous species were transferred to Ellismarsporium R.F. Castañeda & X.G. Zhang, Mirohelminthosporium K. Zhang, D.W. Li & R.F. Castañeda, Stanhughesiella R.F. Castañeda & D.W. Li, Varioseptispora L. Qiu, Jian Ma, R.F. Castañeda & X.G. Zhang, and several other genera [21,22,23]. Based on phylogenetic analysis, four Corynespora Güssow species were transferred to the genus Helminthosporium [24]. Corynespora shares overlapping characteristics with Helminthosporium, such as determinate or percurrently extending conidiophores and integrated, terminal conidiogenous cells that produce distoseptate conidia, making it more difficult to distinguish the two genera based on morphology alone [25]. Most Helminthosporium species are established based on their asexual morph, which is characterized by porogenous, distoseptate conidia with a flat, ringed pore scar at the base, conidia that are acropleurogenously borne on septate, and erect conidiophores, which cease growth after the formation of terminal conidia [24,26,27,28].

Sichuan Province is located in a subtropical zone, where tropical and temperate flora coexist [29]. The diverse climatic environment and complex terrain provide highly favorable conditions for the development of biodiversity. Sichuan Province contains many rare plants and a huge fungal diversity that is waiting to be explored [30,31,32,33,34]. We regularly conduct fungal diversity surveys in Sichuan Province and investigate the taxonomy of fungi associated with specific plants, such as gymnosperms and cherries. During the study, a Thyridaria-like fungus and four hyphomycetous fungi were collected from Pinus spp. and Prunus spp. Based on morphological characteristics and multi-locus phylogenetic analysis, we identified these four collections as a new genus, Vaginospora, in the Thyridariaceae, along with two new species and a new host record of Helminthosporium.

2. Materials and Methods

2.1. Sample Collection, Morphological Examination, and Isolation

We surveyed the fungal diversity of Ascomycota on gymnosperms and cherries in Sichuan Province, China, from April 2023 to April 2024. The specimens were taken into the laboratory in paper envelopes for examination. Microscopic characters were observed and recorded using a Nikon SMZ800N stereo microscope equipped with a Nikon DS-Fi3 camera (Nikon Corporation, Tokyo, Japan) and a Nikon ECLIPSE Ni-U microscope (Nikon Corporation, Tokyo, Japan) fitted with a Nikon DS-Ri2 microscope (Nikon Corporation, Tokyo, Japan) camera. Measurements were conducted using the Nikon NIS-Elements Documentation Imaging Version 5.21.00 (Nikon Corporation, Tokyo, Japan). All photographs were processed using Adobe Photoshop version 22.0 (Adobe Inc., San Jose, SA, USA). Single ascospore or conidium isolation was performed following the method described by Senanayake et al. [35]. Germinated ascospore or conidia were individually transferred to potato dextrose agar (PDA) media plates and incubated in the dark at 25 °C. Culture characteristics were examined and recorded regularly after 1–3 weeks.

The holotype specimens were deposited in the Herbarium of Cryptogams Kunming Institute of Botany Academia Sinica (HKAS), Kunming, China, and all specimens were deposited in the Herbarium of the University of Electronic Science and Technology (HUEST), Chengdu, China. The living ex-type cultures were deposited in the China General Microbiological Culture Collection Center (CGMCC) in Beijing, China, and all living cultures were deposited in the University of Electronic Science and Technology Culture Collection (UESTCC), Chengdu, China. The taxonomic descriptions of the new taxa have been deposited in MycoBank.

2.2. DNA Extraction, PCR Amplification, and Sequencing

Fungal genomic DNA was extracted from mycelia using the Trelief^TM Plant Genomic DNA Kit (TSINGKE Biotech, Shanghai, China) according to the manufacturer’s protocol. For H. pini specimens, obtaining a culture was not feasible, necessitating the direct extraction of DNA from fruiting structures using the method used by Wanasinghe et al. [36]. Five loci—the nuclear ribosomal internal transcribed spacer (ITS: ITS1-5.8S-ITS2), the nuclear ribosomal small subunit rRNA (SSU), the nuclear ribosomal large subunit rRNA (LSU), the partial translation elongation factor 1-alpha (TEF1), and the partial second largest subunit of RNA polymerase II (RPB2)—were amplified by polymerase chain reaction (PCR). The primers used were ITS9mun/ITS4_KYO1 [37,38] for ITS, LR0R/LR5 [39,40] for LSU, PNS1/NS41 [41] for SSU, EF1-728F/EF1-2218R [42,43] for TEF1, and fRPB2-5F/fRPB2-7cR [44,45] for RPB2. The final reaction volume of the PCR reagent was 25 µL, containing 2 µL of the DNA template, 1 µL each of the forward and reverse primers, 8.5 µL of double-distilled water (ddH₂O), and 12.5 µL of 2× Flash PCR MasterMix (mixture of DNA Polymerase, dNTPs, Mg²⁺, and optimized buffer; CoWin Biosciences, Nanjing, China). The amplification conditions for all five loci consisted of initial denaturation at 94 °C for 3 min, followed by 35 cycles of 30 s at 94 °C, 30 s at 56 °C, and 1 min at 72 °C, and a final extension period of 10 min at 72 °C. The PCR products were visualized by 1% agarose gel electrophoresis. Sanger sequencing was conducted by Tsingke Biological Technology (Beijing, China). Newly generated sequences were deposited in GenBank, and the accession numbers are listed in

Table 1. Species details and their GenBank accession numbers used in phylogenetic analyses of Massarinaceae. Type isolates are in bold, and newly generated sequences are in red.

Species	Culture/Specimen No.	GenBank Accession Numbers
		SSU	LSU	ITS	RPB2	TEF1
Byssothecium circinans	CBS 675.92	GU205235	GU205217	OM337536	DQ767646	GU349061
Haplohelminthosporium calami	MFLUCC 18-0074	MT928160	MT928156	MT928158	–	–
Helminthosporiella stilbacea	COAD 2126	–	–	MG668862	–	MG682500
H. stilbacea	CPHmZC-01	–	KX228355	KX228298	–	–
H. stilbacea	MFLUCC 15-0813	MT928161	MT928157	MT928159	–	MT928151
Helminthosporium aquaticum	MFLUCC 15-0357	KU697310	KU697306	KU697302	–	–
H. austriacum	CBS 139924	KY984420	KY984301	KY984301	KY984365	KY984437
H. austriacum	CBS 14238	–	KY984303	KY984303	KY984367	KY984439
H. austriacum	L137	–	KY984302	KY984302	KY984366	KY984438
H. cespitosum	CBS 484.77	KY984421	JQ044448	JQ044429	KY984370	KY984440
H. cespitosum	L141	–	KY984305	KY984305	KY984368	–
H. cespitosum	L151	–	KY984306	KY984306	KY984369	–
H. chengduense	CGMCC 3.23575	ON557757	ON557745	ON557751	ON563073	ON600598
H. chengduense	UESTC 22.0025	ON557756	ON557744	ON557750	ON563072	ON600597
H. chiangraiense	MFLUCC 21-0087	–	MZ538538	MZ538504	–	–
H. chinense	CGMCC 3.23570	ON557760	ON557748	ON557754	–	ON600601
H. chlorophorae	BRIP 14521	–	–	AF120259	–	–
H. dalbergiae	MAFF 243853	AB797231	AB807521	LC014555	–	AB808497
H. endiandrae	CBS 138902	–	KP004478	KP004450	–	–
H. erythrinicola	CBS 145569	–	MK876432	NR_165563	MK876486	–
H. filamentosa	UESTCC 24.0132	PP835319	PP835316	PP835322	PP844886	PP844888
H. genistae	CBS 142597	–	KY984310	KY984310	KY984374	–
H. genistae	CBS 139922	KY984423	KY984309	KY984309	KY984373	–
H. genistae	CBS 139921	KY984422	KY984308	KY984308	KY984372	–
H. guanshanense	HJAUP C1022	OQ172247	OQ172239	OQ172249	OQ234978	OQ256247
H. hispanicum	CBS 136917	KY984424	KY984318	KY984318	KY984381	KY984441
H. jiulianshanense	HJAUP C1057	–	OQ172253	OQ172245	OQ234979	–
H. juglandinum	CBS 136922	–	KY984321	KY984321	KY984384	KY984444
H. juglandinum	CBS 136911	KY984425	KY984322	KY984322	KY984385	KY984445
H. juglandinum	CBS 136912	–	KY984319	KY984319	KY984382	KY984442
H. juglandinum	CBS 136913	–	KY984320	KY984320	KY984383	KY984443
H. leucadendri	CBS 135133	–	KF251654	KF251150	KF252159	KF253110
H. lignicola	MFLUCC 22-0118	OP740253	OP740252	ON329811	OP757656	OP757657
H. livistonae	CPC 32158	–	NG_064539	NR_160348	–	–
H. magnisporum	MAFF 239278	AB797232	AB807522	AB811452	–	AB808498
H. massarinum	CBS 139690	AB797234	AB807524	AB809629	–	AB808500
H. massarinum	JCM 13094	AB797233	AB807523	AB809628	–	AB808499
H. meilingense	HJAUP C1076	OQ172246	OQ172238	OQ172244	OQ234980	OQ234981
H. microsorum	CBS 136910	KY984427	KY984329	KY984329	KY984390	KY984448
H. microsorum	L94	KY984426	KY984327	KY984327	KY984388	KY984446
H. microsorum	CBS 136916	–	KY984323	KY984323	KY984386	–
H. microsorum	L95	–	KY984328	KY984328	KY984389	KY984447
H. nabanhense	HJAUP C2054	OP555400	OP555398	OP555394	–	OP961931
H. nanjingensis	HHAUF020380	–	–	KF192322	–	–
H. oligosporum	CBS 136909	–	KY984333	KY984333	KY984394	KY984451
H. oligosporum	CBS 136908	KY984428	KY984332	KY984332	KY984393	KY984450
H. oligosporum	L106	–	KY984330	KY984330	KY984391	KY984449
H. paraoligosporum	EI-102	–	OM971069	OM971061	–	–
H. pini	HKAS 135177	PP835320	PP835317	PP835323	PP844887	PP844889
H. quercinum	CBS 136921	KY984429	KY984339	KY984339	KY984400	KY984453
H. quercinum	CBS 112393	–	KY984334	KY984334	KY984395	KY984452
H. quercinum	CBS 136915	–	KY984336	KY984336	KY984397	–
H. shangrilaense	KUNCC22-12540	OP767127	OP767126	OP767128	–	OQ186449
H. sinense	HJAUP C2121	OP555399	OP555397	OP555393	–	OP961932
H. solani	CBS 365.75	KY984430	KY984341	KY984341	KY984402	KY984455
H. solani	CBS 640.85	–	KY984342	KY984342	KY984403	–
H. submersum	MFLUCC 16-1360	MG098796	MG098787	–	–	MG098586
H. submersum	MFLUCC 16-1290	MG098797	MG098788	MG098780	MG098592	MG098587
H. syzygii	CBS 145570	–	MK876433	NR_165564	MK876487	–
H. tiliae	CBS 136907	KY984431	KY984345	KY984345	KY984406	KY984457
H. tiliae	CBS 136906	–	KY984344	KY984344	KY984405	–
H. tiliae	L171	–	KY984343	KY984343	KY984404	KY984456
H. velutinum	CBS 139923	KY984432	KY984352	KY984352	KY984413	KY984463
H. velutinum	CBS 136924	–	KY984347	KY984347	KY984408	KY984458
H. velutinum	L98	KY984433	KY984359	KY984359	KY984417	KY984466
H. velutinum	L116	–	KY984348	KY984348	KY984409	KY984459
H. velutinum	L117	–	KY984349	KY984349	KY984410	KY984460
H. velutinum	UESTCC 24.0189	PQ046105	PQ038268	PQ038261	PQ057762	PQ050355
H. yunnanense	HJAUP C2071	OP555392	OP555396	OP555395	OP961934	OP961933
Massarina cisti	CBS 266.62	AB521718	AB521735	LC014569	–	AB808517
M. eburnea	CBS 139697	GU296170	GU301840	OM337528	GU371732	GU349040
M. eburnea	CBS 473.64	MG646979	MG646947	MG646958	–	MG646986
M. pandanicola	MFLUCC 17-0596	NG_064850	NG_059396	NR_153490	–	AB808540
Periconia pseudodigitata	CBS 139699	KP325438	KP325436	KP325434	–	–
Pseudodidymosphaeria spartii	MFLUCC 13-0273	KP325439	KP325437	KP325435	–	–
P. spartii	MFLUCC 14-1212	KY984434	KY984360	KY984360	KY984418	KY984467
P. phorcioides	CBS 122935	KM875455	KM875454	–	–	–
P. phorcioides	MFLUCC 13-0533	KP683377	KP683376	KP683375	–	–
P. phorcioides	MFLUCC 13-0611	KP683374	KP683373	KP683372	–	–
P. phorcioides	MFLUCC 14-0618	–	KT950858	KT950846	–	KT950878
Semifissispora natalis	CPC 25383	–	KT950859	KT950847	–	–
S. rotundata	CBS 172.93	–	NG_058526	NR_156674	–	–
S. tooloomensis	CBS 143431	–	KF251758	KF251255	KF252260	KF253205
S. duoseptata	CBS 135093	KY706138	KY706133	KY706143	KY706149	KY706146
S. imperaticola	MFLUCC 15-0026	–	NG_068239	NR_165854	–	–
S. multiseptata	MFLUCC 15-0449	–	KF251760	KF251257	KF252262	KF253207
S. paludosa	CBS 135088	–	KF251761	KF251258	KF252263	–
S. perfecta	CBS 135099	AB797289	AB807579	AB809642	–	AB808555
S. perfecta	MAFF 239609	–	KF251763	KF251259	KF252265	KF253210
S. pseudocaricis	CBS 135132	–	NG_058052	NR_137840	–	–
S. pseudopaludosa	CPC 22654	AB797287	AB807577	AB809641	–	AB808553
S. pseudoperfecta	CBS 120236	AB797290	AB807580	AB809643	–	AB808556
S. tainanensis	MAFF 243860	–	NG_058081	NR_156586	KJ869232	–
S. trichophoricola	CBS 136764	–	KF251767	KF251264	KF252269	–
S. uniseptata	CBS 135090	–	KF251769	KF251266	KF252271	KF253214
S. uniseptata	CPC 22150	–	KF251768	KF251265	KF252270	KF253213
S. uniseptata	CPC 22151	KP842920	KP842917	–	–	–
Suttonomyces clematidis	MFLUCC 14-0240	MG829185	MG829085	MG828973	–	–
S. rosae	MFLUCC 15-0051	ON557758	ON557746	ON557752	ON563074	ON600599
Synhelminthosporium synnematoferum	CGMCC 3.23574	ON557758	ON557746	ON557752	ON563074	ON600599

and

Table 2. Species details and their GenBank accession numbers used in phylogenetic analyses of Thyridariaceae. Type isolates are in bold, and newly generated sequences are in red.

Species	Culture/Specimen No.	GenBank Accession Numbers
		SSU	LSU	ITS	RPB2	TEF1
Chromolaenomyces appendiculatus	MFLUCC 17–1455	MT214394	NG_068705	NR_168862	MT235806	MT235770
Cycasicola goaensis	MFLUCC 17–0754	MG829112	MG829001	MG828885	–	MG829198
C. leucaenae	MFLUCC17–0914	MK347833	MK347942	NR_163322	MK434900	MK360046
Liua muriformis	KUMCC 18–0177	MK433595	MK433598	MK433599	MK426799	MK426798
Parathyridaria clematidis	MFLUCC 17–2160	MT226710	MT214599	MT310643	MT394710	MT394655
P. clematidis	MFLUCC 17–2185	NG_070668	MT214598	MT310642	MT394709	MT394654
P. ellipsoidea	KNU–JJ–1829	–	LC552952	LC552950	–	–
P. flabelliae	MUT 4886	KT587317	KP671720	KR014358	MN605930	MN605910
P. flabelliae	MUT 4859	KT587315	KP671716	KR014355	MN605929	MN605909
P. percutanea	CBS 128203	KF366450	KF366448	KF322117	KF366453	KF407988
P. percutanea	CBS 868.95	KF366451	KF366449	KF322118	KF366452	KF407987
P. philadelphi	CBS 143432	–	NG_063958	MH107905	–	MH108023
P. ramulicola	MUT 4397	MN556311	KF636775	KC339235	MN605933	MN605913
P. ramulicola	CBS 141479	KX650514	KX650565	NR_147657	KX650584	KX650536
P. robiniae	MFLUCC 14–1119	–	KY511141	KY511142	–	KY549682
P. rosae	MFLU 17–0623	–	NG_059873	NR_157530	–	–
P. serratifoliae	MFLUCC 17–2210	NG_070669	MT214602	MT310646	MT394713	MT394658
P. tyrrhenica	MUT 4966	KT587309	KP671740	KR014366	MN605931	MN605911
P. tyrrhenica	MUT 5371	KU314952	MN556329	KU314951	MN605932	MN605912
P. virginianae	MFLUCC 17–2163	NG_070670	NG_073853	MT310647	MT394714	MT394659
Parathyridariella dematiacea	MUT 4419	MN556313	KF636786	KC339245	MN605925	MN605905
P. dematiacea	MUT 4884	KT587329	KP671726	MN556317	MN605926	MN605906
Pseudothyridariella chromolaenae	MFLUCC 17–1472	MT214395	NG_068706	NR_168863	MT235807	MT235771
P. idesiae	CGMCC 3.24439	OR253216	OR253307	OR253148	OR253762	OR251154
P. mahakoshae	NFCCI 4215	MG020441	MG020438	MG020435	MG020446	MG023140
Thyridaria acaciae	CBS 138873	–	KP004497	KP004469	–	–
T. aureobrunnea	MFLUCC 21–0090	–	MZ538562	MZ538528	–	–
T. broussonetiae	CBS 141481	NG_063067	–	NR_147658	–	–
T. broussonetiae	TB	–	–	KX650567	KX650585	KX650538
T. broussonetiae	TB1	KX650515	–	KX650568	KX650586	KX650539
T. jonahhulmei	KUMCC 21–0816	ON007046	ON007037	ON007041	ON009135	ON009131
T. jonahhulmei	KUMCC 21–0817	ON007047	ON007038	ON007042	ON009136	ON009132
Thyridariella mangrovei	NFCCI 4214	MG020442	MG020439	MG020436	MG020447	MG020444
T. mangrovei	NFCCI 4213	MG020440	MG020437	MG020434	MG020445	MG020443
Torula herbarum	CBS 595.96	KF443387	KF443385	KF443408	KF443395	KF443402
Vaginospora sichuanensis	UESTCC 24.0191	PQ046104	PQ038267	PQ038260	PQ050358	PQ050354

.

2.3. Phylogenetic Analyses

According to the corresponding Sanger sequencing chromatograms, misleading data from the ends of raw sequencing fragments were manually trimmed and assembled into consensus sequences using SeqMan Pro version 7.1.0 (DNASTAR, Inc., Madison, WI, USA). Barcode sequences of all species (Table 1 and Table 2) were downloaded from the NCBI nucleotide database using the R package Analysis of Phylogenetics and Evolution 5.0 (APE, http://ape-package.ird.fr, 26 June 2024) [46].

The multiple sequence alignments were conducted using MAFFT version 7.310 [47] with options “--adjustdirection --auto,” and the alignment files were further trimmed using trimAl version 1.4 [48] with the option “-gapthreshold 0.5”, which only allows 50% of taxa with a gap in each site. The best-fit nucleotide substitution models for each locus were selected using ModelFinder version 2.1.1 [49] under the Corrected Akaike Information Criterion (AICC). All sequence alignments were combined using an in-house Python script.

Maximum Likelihood (ML) and Bayesian analysis (BI) were conducted based on individual and combined datasets. Two phylogenetic trees were constructed by combining the ITS, SSU, LSU, RPB2, and TEF1 gene regions. The first tree represents the phylogenetic analysis of the Massarinaceae, while the second tree represents the phylogenetic analysis of the Thyridariaceae. ML phylogenetic trees were obtained using the IQ-TREE version 2.0.3 [50], and the topology was evaluated using 1000 ultrafast bootstrap replicates. The BI was conducted using parallel MrBayes version 3.2.7a [51]. The ML trees were visualized using ggtree version 2.4.1 [52] and further edited in Adobe Illustrator version 16.0.0.

3. Results

3.1. Phylogenetic Analyses

Sequences of Five loci were successfully obtained for Helminthosporium filamentosa (UESTCC 24.0132), H. pini (HKAS 135177), and H. velutinum (UESTCC 24.0189). A phylogenetic tree of all Helminthosporium species and representative strains from other genera in Massarinaceae was constructed (Figure 1), including 100 taxa, with Periconia pseudodigitata (CBS 139699) as the outgroup. The combined dataset (ITS: 1–564, LSU: 565–1415, SSU: 1416–2440, RPB2: 2441–3555, TEF1: 3556–4781) was composed of 1872 distinct patterns, 1183 parsimony-informative sites, 340 singleton sites, and 3257 constant sites. The best-fit evolution models were GTR+F+I+G4 for the ITS partitions, GTR+F+I+G4 for the LSU partition, K2P+G4 for the SSU partition, HKY+F+I+G4 for the RPB2 partition, and GTR+F+I+G4 for the TEF1 partition. The best-scoring ML tree (lnL = −32012.540) with support values from ML and Bayesian analysis at the node is shown in Figure 1.

According to the multi-locus phylogeny (Figure 1), our collection (HKAS 135177) formed an independent clade sister to H. yunnanense (HJAUP C2071) and strains of H. austriacum. Our collection (UESTCC 24.0132) formed a separate branch, sister to H. dalbergiae (MAFF 243853), H. magnisporum (MAFF 239278), and strains of H. quercinum. Our collection (UESTCC 24.0189) nests with H. velutinum strains with 99% ML, 1.00 PP statistical support. Combining the morphological evidence with phylogeny, we propose two new species, H. filamentosa (UESTCC 24.0132) and H. pini (HKAS 135177), isolated from Pinus sp. and Prunus pseudocerasus, respectively. Additionally, we report our collections (UESTCC 24.0189) as a new host record of H. velutinum from Pinus sp.

Sequences of Five loci were successfully obtained for the Vaginospora sichuanensis (UESTCC 24.0191). A phylogenetic tree of representative strains from other genera in Thyridariaceae was constructed (Figure 2), including 36 taxa, with Torula herbarum (CBS 595.96) as the outgroup. The combined dataset (ITS: 1–516, LSU: 517–1372, RPB2: 1373–2402, SSU: 2403–3422, TEF1: 3423–4307) was composed of 1448 distinct patterns, 824 parsimony-informative sites, 518 singleton sites, and 2965 constant sites. The best-fit evolution models were SYM+G4 for the ITS partitions, SYM+I for the LSU partition, SYM+I+G4 for the RPB2 partition, K2P+G4 for the SSU partition, and GTR+F+I+G4 for the TEF1 partition. The best-scoring ML tree (lnL = − 21563.517) with support values from ML and Bayesian analysis at the node is shown in Figure 2.

According to the multi-locus phylogeny (Figure 1), our collection (UESTCC 24.0191) formed an independent clade sister to Pseudothyridariella chromolaenae (MFLUCC 17–1472), Pseudothyridariella idesiae (CGMCC 3.24439), and strains of Thyridariella mangrovei. Based on the morphological evidence and phylogeny, we propose a new genus, Vaginospora, with the type species Vaginospora sichuanensis.

3.2. Taxonomy

Helminthosporium filamentosa W.H. Tian, Y. Jin & Maharachch., sp. nov. (Figure 3).

MycoBank: MB 854338

Etymology: The epithet refers to the filamentous mycelium, from the Latin “filamentum” for filaments.

Saprobic on dead branch of Prunus pseudocerasus. in terrestrial habitats. Asexual morph: Hyphomycetes. Colonies on the natural substratum effuse, scattered, hairy, black. Mycelium superficial, numerous, hairy, black, scattered, solitary or fasciculate. Conidiophores 210–710 × 8–18 μm ($\overline{\mathrm{x}}$ = 350 × 12.5 μm, n = 30), macronematous, mononematous, erect, simple or sometimes branched, straight to curved, verruculose, septate, black, cylindrical, obtuse at apex. Conidiogenous cells enteroblastic, integrated, terminal, cylindrical, black, verruculose. Conidia 43–73 × 10–16 μm ($\overline{\mathrm{x}}$ = 60 × 13 μm, n = 30), cylindrical, obclavate, phragmoconidia, solitary, acrogenous, 7-distoseptate, obclavate, wide at the middle and lower part, straight or curved, uneven width, rounded at apex, truncate at base, brown, thick-walled, verruculose, secession schizolytic. Sexual morph: Undetermined.

Material examined: CHINA, Sichuan Province, Chengdu City, Pujiang Country, Cherry Mountain 30°16′25″ N, 103°50′9″ E, elevation 546 m, 19 October 2023, decaying branches of Prunus pseudocerasus, Y. Jin YTS21_3 (HKAS 135176, holotype), ex-type CGMCC 3.27591 = UESTCC 24.0132.

Culture characteristics: Colonies on PDA reaching 18.5 mm diam after 10 days at 25 °C, colonies from above: irregularly circular, white, margin entire, dense; reverse: cream at the margin, pale yellow in the center.

Notes: Multi-locus phylogenetic analysis indicated that our isolate (UESTCC 24.0132) constitutes an independent clade sister to H. magnisporum (MAFF 239278), H. dalbergiae (MAFF 243853), and strains of H. quercinum (Figure 1). Based on pairwise nucleotide comparisons, the closest hits to our isolate (UESTCC 24.0132) is H. quercinum (CBS 136921), and comparing the ITS, LSU, SSU, RPB2, and TEF1 of their sequence revealed 96.88% (559/577 bp, gaps: 2/577 bp), 99.34% (754/759 bp, without gaps), 99.8% (1004/1006 bp, without gaps), 97.45% (763/783 bp, without gaps), and 97.44% (838/860 bp, gaps: 2/860 bp) similarity, respectively. Morphologically, our isolate (UESTCC 24.0132) differs from H. quercinum (CBS 136921) by color (black vs. brown to dark brown) and longer conidiophores (210–710 × 8–18 μm vs. 74–199 × 11–18 μm), and shorter and narrower conidia (43–73 × 10–16 μm vs. 78–130 × 15.3–18 μm) [24]. Among Helminthosporium species that lack molecular data, only H. davillae, H. obpyriforme, and H. panici have similar conidial sizes to our collection [15,53,54,55]. However, the conidia of our isolate (UESTCC 24.0132) are wider (10–16 μm vs. 4–6 μm) and more distosepta (7-distoseptate vs. 2–4-distoseptate) than H. davillae [55]. Helminthosporium filamentosa (UESTCC 24.0132) differs from H. obpyriforme in the morphology of the conidiophores (sometimes branched vs. simple; black vs. dark brown); it has relatively longer conidiophores (210–710 μm vs. 225–460 μm) and narrow conidia (10–16 μm vs. 14–19 μm) compared to H. obpyriforme [54]. Helminthosporium filamentosa (UESTCC 24.0132) has a different conidial morphology (obclavate vs. ellipsoidal-elongate) and more distoseptate conidia (7-distoseptate vs. 1–4-distoseptate) than H. panici [53]. Therefore, based on morphological characteristics and phylogenetic analysis results, we identified H. filamentosa as a novel species from Prunus pseudocerasus in China.

Helminthosporium pini W.H. Tian & Maharachch., sp. nov. (Figure 4).

MycoBank: MB 854339

Etymology: Named after the host genus where the fungus was collected.

Saprobic on a dead branch of Pinus sp. in terrestrial habitats. Asexual morph: Hyphomycetes. Colonies on the natural substratum effuse, hairy, black. Mycelium superficial, numerous, hairy, black, scattered, solitary or fasciculate. Conidiophores 170–580 × 8–13 μm ($\overline{\mathrm{x}}$ = 305 × 11 μm, n = 30), cylindrical, macronematous, mononematous, simple, erect, straight to slightly curved, verruculose, septate, dark brown to black, obtuse at apex. Conidiogenous cells holoblastic, integrated, terminal and intercalary, cylindrical, dark brown, verruculose. Conidia 60–100 × 12–18 μm ($\overline{\mathrm{x}}$ = 80 × 16 μm, n = 30), cylindric-obclavate, phragmoconidia, solitary, acrogenous, 5–12-distoseptate, elongated, wide at the middle and lower part, straight or flexuous, uneven width, rounded at apex, obconically truncate at base, dark brown, thick-walled, verruculose, secession schizolytic. Sexual morph: Undetermined.

Material examined: CHINA, Sichuan Province, Neijiang City, Songlin Village, 29°32′19″ N, 105°9′28″ E, elevation 373 m, 1 April 2023, decaying branches of Pinus sp., W.H. Tian SLC11_1 (HKAS 131577, holotype).

Notes: Phylogenetic analysis based on the combined dataset of ITS, LSU, SSU, RPB2, and TEF1 loci revealed that our collection (HKAS 131577) forms a separate branch sister to H. yunnanense (HJAUP C2071) and H. austriacum strains (Figure 1). In the NCBI BLASTn search, the closest matches to our isolate (UESTCC 24.0132) is H. austriacum. Comparing the ITS, LSU, SSU, RPB2, and TEF1 of our collection (HKAS 131577) with the type strain of H. austriacum (CBS 139924) sequence revealed 90.87% (378/416 bp, gaps: 5/416 bp), 96.38% (718/745, gaps: 3/745 bp), 99.60% (985/989, without gaps), 90.24% (703/779, without gaps), and 94.81% (676/713, gaps: 2/713 bp) similarity, respectively. The morphological characteristics of our collection (HKAS 131577) overlap with the species of Helminthosporium in having septate and erect conidiophores and acro-pleurogenous and distoseptate conidia (Figure 3) [16,24]. Our collection differs from the H. austriacum by shorter conidiophores (170–580 μm vs. 270–920 μm [56]. Comparing the morphology of 216 Helminthosporium species reported worldwide, except for species with molecular sequences, only H. gossypii, H. guangxiense, H. meliae, and H. pseudotsugae had similar conidial sizes to our collection [15]. However, the conidiophores of our collection (170–580 × 8–13 μm) are longer and wider than H. gossypii (40–185 × 6.5–8.5 μm); shorter and narrower than H. guangxiense (330–850 × 8–20 μm); and longer and narrower than H. meliae (250–350 × 15–22 μm) [54,57,58,59]. The number of distosepta in conidia in our collection (HKAS 131577) (5–12-distoseptate) is more than H. gossypii (1–8-distoseptate), less than H. guangxiense (9–17-distoseptate), and less than H. pseudotsugae (8–14-distoseptate) [54,57,58,59]. Thus, our collection HKAS 131577 is described as a new species based on morphological observation and phylogenetic evidence.

Helminthosporium velutinum W Link [as ‘Helmisporium’], Mag. Gesell. naturf. Freunde, Berlin 3(1–2): 10 (1809) (Figure 5).

Saprobic on a dead branch of Pinus sp. in terrestrial habitats. Asexual morph: Hyphomycetes. Colonies on the natural substratum effuse, hairy, black. Mycelium superficial, numerous, hairy, black, scattered, solitary. Conidiophores 275–765 × 9–12 μm ($\overline{\mathrm{x}}$ = 525 × 16 μm, n = 30), macronematous, mononematous, unbranched, erect, straight to slightly curved, verruculose, septate, dark brown to black, cylindrical, obtuse at apex. Conidiogenous cells holoblastic, integrated, terminal and intercalary, cylindrical, dark brown, verruculose. Conidia 25.5–70 × 10–14 μm ($\overline{\mathrm{x}}$ = 46.5 × 16 μm, n = 30), cylindric-obclavate, tapering to 4–10 μm ($\overline{\mathrm{x}}$ = 6.5, n = 30) at the distal end, with a blackish-brown 3.5–6.5 μm wide ($\overline{\mathrm{x}}$ = 5, n = 30) scar at the base, phragmoconidia, solitary, acrogenous, 4–10-distoseptate, wide at the middle and lower part, straight or flexuous, uneven width, rounded at apex, obconically truncate at base, brown to dark brown, thick-walled, verruculose, secession schizolytic. Sexual morph: Undetermined.

Material examined: CHINA: Sichuan Province, Chengdu City, Jiudaoguai, 30°30′21″ N, 103°53′47″ E, elevation 502 m, 19 October 2023, within dead branches of Pinus sp., W.H. Tian JDG31 (HUEST 24.0206), living culture UESTCC 24.0189.

Culture characteristics: Colony on PDA reaching 22 mm diam. in 11 days at 25 °C in the dark, colonies from above: irregularly circular, white, uneven entire, raised in center, with denser mycelium at the center; from below: yellowish brown, dark brown in the center, margin undulated.

Notes: Helminthosporium velutinum is the type species of the genus Helminthosporium. It is widely distributed around the world, with 110 known host records, excluding Pinus species [60]. Helminthosporium velutinum has been reported from both freshwater and terrestrial environments in China [16,24]. Multi-locus analyses of combined ITS, LSU, SSU, RPB2, and TEF1 sequence data showed that our collection (UESTCC 24.0189) nests with H. velutinum strains with 99% ML, 1.00 PP statistical support (Figure 1). In addition, the morphological characteristics examined largely overlapped with H. velutinum [16]. Thus, based on morphological comparison and phylogenetic analyses, we report our collections (UESTCC 24.0189) as a new host record of H. velutinum from Pinus sp.

Vaginospora W.H. Tian, Y. Jin & Maharachch., gen. nov.

MycoBank: MB 854941

Etymology: Named after its ascospores that have a sheath, from the Latin words “vagina” for sheath and “spora” for spore.

Saprobic on a dead branch of Prunus sp. in terrestrial habitats. Sexual morph: Pseudothecia solitary scattered, semi-immersed, uni-loculate, sessile, globose to oblong, ampulliform to ovoid, black, ostiolate. Peridium comprising several layers; outer layers dark brown to dark, with compressed cells of textura angularis; inner layers hyaline, with compressed pseudoparenchymatous cells, arranged in textura angularis. Hamathecium comprises dense, branched, septate, cellular pseudoparaphyses. Asci 8-spored, bitunicate, cylindrical to clavate, straight or curved, short pedicelate, apically rounded with an ocular chamber. Ascospores 2-seriate, overlapping and are initially gray-brown, turning dark brown at maturity, fusiform, mostly 3-transversely septate, sometimes 1–2 longitudinal septum appear after maturity, constricted at the septa, smooth-walled, conically rounded at the ends, verruculose, with an inconspicuous mucilaginous sheath. Asexual morph: undetermined.

Type species—Vaginospora sichuanensis W.H. Tian, Y. Jin & Maharachch.

Notes: According to phylogenetic analysis of Thyridariaceae, our collection (UESTCC 24.0191) constitutes a distinct clade, positioned as a sister to Pseudothyridariella and Thyridariella, with 100% ML and 1.00 PP statistical support (Figure 2). However, the sister relationship of Vaginospora to Pseudothyridariella and Thyridariella warrants discussion to clarify the issues of intergeneric affinities. Thyridariella can be distinguished from Vaginospora and Pseudothyridariella by having hyaline ascospores [61,62]. Pseudothyridariella produces ascospores slightly constricted at the central septum, whereas Thyridariella and Vaginospora have ascospores constricted at every septum [61,62]. Furthermore, the size of ascospores and septa in ascospores of Vaginospora is significantly smaller and fewer than in Thyridariella and Pseudothyridariella [61,62]. Therefore, Vaginospora is proposed as a new genus to accommodate Vaginospora sichuanensis and expand the scope of the family Thyridariaceae.

Vaginospora sichuanensis W.H. Tian, Y. Jin & Maharachch., sp. nov. (Figure 6).

MycoBank: MB 854942

Etymology: Named after the Sichuan province, China, where the holotype was collected.

Saprobic on a dead branch of Prunus sp. in terrestrial habitats. Sexual morph: Pseudothecia 180–290 μm high × 265–375 μm diam. ($\overline{\mathrm{x}}$ = 225 × 290 μm, n = 10), solitary scattered, semi-immersed, uni-loculate, sessile, globose to oblong, ampulliform to ovoid, black, filled by asci and ascospores and pseudoparaphyses, ostiolate. Peridium 28–48 μm wide, comprising several layers; outer layers dark to dark brown, with compressed cells of textura angularis; inner layers hyaline, with compressed pseudoparenchymatous cells, arranged in textura angularis. Hamathecium comprises dense, 1.3–2.2 μm wide, branched, septate, cellular pseudoparaphyses. Asci 65–140 × 6.5–15 μm ($\overline{\mathrm{x}}$ = 90 × 10 μm, n = 20), 4–8-spored, bitunicate, cylindrical to clavate, straight or curved, short pedicelate, apically rounded with an ocular chamber. Ascospores 13–23 × 4–10 μm ($\overline{\mathrm{x}}$ = 18 × 7 μm, n = 30), 2-seriate, overlapping and are initially gray-brown, turning dark brown at maturity, fusiform, muriform, mostly 3-transversely septate, sometimes 1–2 longitudinal septum appear after maturity, constricted at the septa, smooth-walled, conically rounded at the ends, verruculose, with an inconspicuous mucilaginous sheath. Asexual morph: undetermined.

Material examined: CHINA, Sichuan Province, Chengdu City, Dujiangyan County Yunhuashan, 31°00′62” N, 103°59′14” E, elevation 1535 m, 22 March 2024, decaying branches of Prunus sp., Y. Jin YHS46 (HKAS 136265, holotype), ex-type CGMCC 3.27600 = UESTCC 24.0191.

Culture characteristics: Colony on PDA reaching 24 mm diam. in 11 days at 25 °C in the dark, colonies from above: irregularly circular, white, uneven entire, raised in center, with denser mycelium at the center and becoming sparser at the edge; from below: yellowish brown, brown in the center, margin undulated.

Notes: Phylogenetic analyses of combined ITS, LSU, RPB2, SSU, and TEF1 sequence data showed that our isolate (UESTCC 24.0191) forms a separate branch sister to Pseudothyridariella and Thyridariella with stable support (Figure 2). However, morphologically, our collection (UESTCC 24.0191) differs from the P. chromolaenae and T. mangrovei by narrower asci (6.5–15 μm vs. 14–22 μm vs. 10–30 μm) and smaller ascospores (13–23 × 4–10 μm vs. 23–28 × 9–12.5 μm vs. 23–40 × 8–15 μm), as well as the number of transverse septa in ascospores (1–5 septa vs. 5–8 septa vs. 5–6 septa) [61,62]. The closest matches to our isolate (UESTCC 24.0191) are species of Pseudothyridariella (Figure 2). Sequence comparison for the ITS, LSU, RPB2, SSU, and TEF1 region between our isolate (UESTCC 24.0191) and the type species P. chromolaenae (MFLUCC 17–1472) showed 96.56% (365/378 bp, without gaps), 98.70% (758/768 bp, without gaps), 87.60% (636/726 bp, without gaps), 99.53% (428/430 bp, without gaps), and 95.23% (798/838 bp, without gaps) base pair similarity. Thus, our isolate UESTCC 24.0191 was identified as a new species based on morphological observation and phylogenetic evidence.

4. Discussion

Seven hundred and seventy-nine epithets of Helminthosporium have been listed in Index Fungorum (http://www.indexfungorum.org; 26 June 2024). Konta et al. compiled a list of 216 identified and accepted species of Helminthosporium worldwide based on species records from Index Fungorum [15]. However, most species are characterized solely based on morphology, and only 37 species have sequence data. The lack of extensive molecular data is primarily due to most species being reported and identified before sequencing technologies. This results in the possibility that many species within the Helminthosporium may be conspecific or belong to different genera [18,19,21,22,23]. Therefore, it is essential to re-examine the type specimens of formerly described Helminthosporium-like species to address this matter. Simultaneously, it is necessary to collect fresh specimens, sequence them, and combine multi-locus phylogenetic analysis with morphological examination to designate epi-types or neotypes, which is crucial for clarifying the taxonomic status of many doubtful species.

Helminthosporium is distributed worldwide and is mainly saprophytic on leaves or branches in terrestrial or aquatic environments [15,16,17,24,63]. Silver scurf caused by H. solani has become an important economic disease since the 1990s [64,65,66,67]. Helminthosporium solani mainly causes blemishes in the periderm of potato tubers [68]. In the 20th century, silver scurf disease also emerged in China, resulting in significant potato losses [69].

In recent studies, species of Pseudothyridariella have been grouped into two distinct clades based on phylogenetic analysis [70,71]. The genus Pseudothyridariella was proposed by Mapook et al. [62], with P. chromolaenae as the type species, and Thyridariella mahakoshae was transferred to the Pseudothyridariella genus as P. mahakoshae. However, not many sequence data and species were available for constructing phylogeny at that time. More data are emerging showing that this species is clearly unrelated to the genus Pseudothyridariella, which supports our study [70,71]. Morphologically, P. mahakoshae also differs from P. chromolaenae in that the former has brown or olive-brown to dark brown ascospores with 5–8 transverse septa, whereas the latter has hyaline ascospores with 3–6 transverse septate [61,62]. When the genus Thyridariella was introduced, it was mentioned that one of its characteristic features was the production of hyaline muriform ascospores [61]. Pseudothyridariella idesiae is not comparable here because it is known only for its asexual morph [71]. Our newly introduced genus, Vaginospora sichuanensis, has muriform ascospores that are mostly 3-transversely septate, which are morphologically and phylogenetically distinct from P. mahakoshae. Therefore, more evidence should be collected, and the taxonomic status of P. mahakoshae should be revised in future studies.

The multi-locus phylogenetic analysis in this study revealed that our newly collected taxa of Vaginospora represent a new genus as it constitutes a strongly supported monophyletic clade (Figure 2). Molecular evidence further indicates that Vaginospora belongs to the family Thyridariaceae. Our collection (UESTCC 24.0191) was morphologically similar to the type genus Thyridaria of Thyridariaceae, with immersed or semi-immersed ascomata, composed of textura angularis cells in the peridium, bitunicate, cylindrical to subclavate asci that are apically rounded with an ocular chamber, and fusiform, septate ascospores [12]. They differ in ascospore morphology, with our collection having 1–5 septa and being highly constricted at the septa, 1–2 longitudinal septa at maturity, and a sheath around the ascospores, which is not found in Thyridaria [12]. Morphological character comparison is a traditional classification method that cannot reflect phylogenetic relationships; it could be informative at the generic level in Thyridariaceae. For example, Parathyridaria was introduced into the family for its characteristic features of discoid ostiolar apices always present and pale to greyish-brown ascospores [12], Thyridariella is distinguished from other genera by its hyaline ascospores [61]; a typical feature of Pseudothyridariella is that the ascospores are constricted only at the central septum [62]. Thus, within Thyridariaceae, ascospores morphology is diverse, and when establishing a new genus, it can be combined with molecular data to provide further evidence and support.
