Infrastructures, Volume 9, Issue 2 (February 2024) – 19 articles

Road safety is a central issue in the management and development of a road network. Road agencies must try to identify the most dangerous sections of their network and act on them to improve safety. The most used procedure for this purpose is about considering the indicators based on crashes. However, a mature road safety management system must be able to assess the safety of a road section before accidents occur. The European community is moving in this direction with the update of Directive 2008/96/EC (Directive 1936/2019). This paper proposes a new methodology for carrying out a network-wide road safety assessment on rural single-carriageways and two-lane two-way roads. This procedure accounts for the influence of road characteristics on drivers’ perceptions. The methodology has been developed based on the human factors concepts from PIARC, and it includes a series of checklists that guide an inspector in carrying out a visual inspection of single-carriageway roads. The results from the checklist are then processed into an algorithm, and the level of risk in the analyzed section is provided. The objectives of the procedure are (a) to account for the perceptive aspects that are one of the major causes of road accidents, (b) to provide a proactive procedure in line with the requirements of the European Directive, and (c) to provide a useful instrument that can be easily implemented by road agencies and integrated with other analysis procedures. The procedure has been applied and tested on a case study of six different stretches of two-lane, two-way rural highways in Italy, Germany, and Slovenia (about 65 km). The results show a high degree of concordance with a risk classification based on the accident rate, mainly considering high-risk sections. Therefore, the procedure demonstrated its potential to be a useful instrument to be included in network safety assessments. Road agencies should consider the use of this procedure in their network safety analysis and ranking. Full article

Asphalt pavements are subject to regular inspection and maintenance activities over time. Many techniques have been suggested to evaluate pavement surface conditions, but most of these are either labour-intensive tasks or require costly instruments. This article describes a robust intelligent pavement distress inspection system that uses cost-effective equipment and the ‘you only look once’ detection algorithm (YOLOv3). A dataset for flexible pavement distress detection with around 13,135 images and 30,989 bounding boxes of damage was used during the neural network training, calibration, and validation phases. During the testing phase, the model achieved a mean average precision of up to 80%, depending on the type of pavement distress. The performance metrics (loss, precision, recall, and RMSE) that were applied to estimate the object detection accuracy demonstrate that the technique can distinguish between different types of asphalt pavement damage with remarkable accuracy and precision. Moreover, the confusion matrix obtained in the validation process shows a distress classification sensitivity of up to 98.7%. The suggested technique was successfully implemented in an inspection car. Measurements conducted on urban roads crossed by tramway lines in the city of Palermo proved the real-time ability and great efficacy of the detection system, with potentially remarkable advances in asphalt pavement examination efficacy due to the high rates of correct distress detection. Full article

This paper investigates the effect of subgrade soil stabilization on the performance and life extension of flexible pavements. Several variables affecting soil stabilization were considered, including subgrade soil type (CL or CH), additive type and content (3, 6, and 9% of hydrated lime, 5, 10, and 15% of class C fly ash (CFA), and 5, 10, and 15% of cement kiln dust (CKD)), three stabilization thicknesses (15, 30, and 45 cm), and four pavement sections with varying thicknesses. The effects of these variables were investigated using four different damage mechanisms, including the fatigue life of the asphalt concrete (AC) and stabilized subgrade layers, the crushing life of the stabilized subgrade soil, and the rutting life of the pavement, using a non-linear mechanistic-empirical methodology. The results suggest that the optimum percentage that maximizes the pavement life occurs at 3% of lime for subgrade soil type CL, 6% of lime for subgrade type CH, and 15% of CFA and CKD for both subgrade soil types. The maximum pavement life increase occurred in the section with the lowest thickness and the highest stabilization thickness, which was 1890% for 3% of lime in the CL subgrade and 568% for 6% of lime in the CH subgrade. The maximum increase in the pavement life of subgrade stabilization with 15% of CFA was 2048% in a CL subgrade, and 397% in a CH subgrade, and life extension due to subgrade stabilization with 15% of CKD was 2323% in a CL subgrade and 797% in a CH subgrade. Full article

This paper aims to contribute to the process of evaluating urban rail infrastructure projects through the presentation of the methodology and the results of a preliminary feasibility study concerning the revitalization, development, and (re)integration of the rail with road, maritime, and air transportation in the Zadar urban area. The analysis included the identification and evaluation of rail infrastructure alignment variants that would ensure the revitalization of the existing railway infrastructure, relocation of freight rail traffic from the narrow and densely developed suburban coastal area, promotion of intermodal passenger and freight transportation, improvement of urban and regional accessibility and connectivity, increase of traffic safety, reduction of travel time and operating costs, and decrease of traffic impacts on the environment. By consulting legal frameworks, spatial planning documentation, and analyzing the socio-economic context and existing transportation infrastructure function, six variants for the (re)development of the rail infrastructure were designed. As their design approached the area’s transportation issues from different angles and could contribute differently to the area’s economic, social, and territorial issues, a multi-criteria analysis supplemented with a partial cost–benefit analysis was conducted to select the most suitable variant. The evaluation was based on seven weighted criteria quantified by the normalization of 32 indicator values, scored from 1 to 5, where a score of 5 was considered the highest. Weighting the scores according to the ratios determined through a consultation process with stakeholders resulted in ranking the best variant with a total score of 3.7 and the worst one with a total score of 2.6. To avoid potential objections that the set of criteria weights used was subjective and the result biased, a sensitivity analysis was carried out by systematically varying the weights among criteria. The results showed that the best-ranked variant was also the least sensitive to applied weight shifts, with a score range of 0.2. Full article

The fast, convenient, and accurate determination of railroad cars’ load mass is critical to ensure safety and allow asset counting in railway infrastructure. In this paper, we propose a method for modeling the mechanical deformations that occur in the rail web under the influence of a static load transmitted through a railway wheel. According to the proposed method, a railroad car’s weight can be determined from the rail deformation values. A solid model of a track section, including a railroad tie, rail, and wheel, is developed, and a multi-physics simulation technique that allows for the determination of the values of deformations and mechanical stresses in the strain gauge installation areas is presented. The influence of the loaded mass, the temperature of the rail, and the wheel position relative to the strain gauge location is considered. We also consider the possibility of using artificial neural networks to determine railroad cars’ weight without specifying the coordinates of the wheel position. The effect of noise in the data on the accuracy of determining the railroad car weight is considered. Full article

This paper summarizes the lessons learned after several decades of exploring and applying Structural Health Monitoring (SHM) in operating bridge structures. The challenges in real-time imaging and processing of large amounts of sensor data at various bandwidths, synchronization, quality check and archival, and most importantly, the interpretation of the structural condition, performance, and health are necessary for effective applications of SHM to major bridges and other infrastructures. Writers note that such SHM applications have served as the forerunners of cyber infrastructures, which are now recognized as the key to smart infrastructures and smart cities. Continued explorations of SHM in conjunction with control, therefore, remain vital for assuring satisfactory infrastructure system performance at the operational, damageability, and safety limit-states in the future. Researchers in the SHM of actually constructed systems, given their experience in monitoring major structures in the field, are well positioned to contribute to these vital needs. Especially, SHM researchers who have learned how to integrate the contributions from various disciplines such as civil, electrical, mechanical, and materials engineering; computer and social sciences; and architecture and urban planning would appear to be well equipped and could become instrumental in assessing the health and performance of urban regions, which today must function by optimizing and balancing the needs of Livability, Sustainability, and Resilience (LSR). Full article

Fatigue in steel–concrete composite beams can result from cyclic loading, causing stress fluctuations that may lead to cumulative damage and eventual failure over an extended period. In this paper, the experimental findings from fatigue loading tests on composite beams with various arrangements are presented. Fatigue tests were performed up to 1,000,000 cycles using four-point loading, encompassing various ranges of shear stress at a consistent amplitude. Additionally, the effects of external post-tensioning and the strength of the shear connection were investigated. Static tests were run until failure to assess the enduring strength of the specimens subjected to fatigue. The cyclic mid-span deflections, slippages, and strains were measured during the testing. Based on the experimental findings, it was found that the damage region that the shear studs caused in the concrete slab, which resulted in a reduction in stiffness within the shear connection, grew as the loading cycles increased, leading to an increase in residual deflections and plastic slippages. Controlling the longitudinal fatigue cracks in the concrete slab was largely dependent on the strength of the shear connection between the steel beams and concrete slabs. Moreover, the applied fatigue loading range affected the propagation and distribution of fatigue cracks in the concrete slab. The strains in different parts of the composite specimens were significantly reduced by applying the external post-tensioning. With no signs of distress at the anchors, the tendons displayed excellent fatigue performance. Full article

In the process of driving in an underground interchange, drivers are faced with many challenges, such as being in a closed space, visual changes alternating between light and dark conditions, complex road conditions in the confluence section, and dense signage, which directly affect the safety and comfort of drivers in an underground interchange. Thus, driving simulation, building information modeling (BIM), and data mining were used to analyze the impact of underground interchange safety facilities on driving safety and comfort. Acceleration disturbance and steering wheel comfort loss values were used to assist the comfort analysis. The CART algorithm, classification decision trees, and neural networks were used for data mining, which uses a dichotomous recursive partitioning technique where multiple layers of neurons are superimposed to fit and replace very complex nonlinear mapping relationships. Ten different scenarios were designed for comparison. Multiple linear regression combined with ANOVA was used to calculate the significance of the control variables for each scenario on the evaluation index. The results show that appropriately reducing the length of the deceleration section can improve driving comfort, setting reasonable reminder signs at the merge junction can improve driving safety, and an appropriate wall color can reduce speed oscillation. This study indicates that the placement of traffic safety facilities significantly influences the safety and comfort of driving in underground interchanges. This study may provide support for the optimization of the design of underground interchange construction and internal traffic safety facilities. Full article

The need to incorporate sustainability principles and practices is increasing for environmental and economic reasons. It is imperative to identify and operationalize sustainability strategies into core administrative, planning, design, construction, operational, and maintenance activities for the transportation infrastructure systems by integrating sustainability into decision-making processes. The primary goal of this study is to develop an implementation plan for achieving more sustainable transportation infrastructure systems in Iowa. This research aims to guide the adoption of sustainable strategies, balancing cost, performance, and environmental impact in transportation infrastructure development. This paper presents efforts to develop a methodology for identifying the best sustainable practices for implementation in transportation infrastructure practices in Iowa by surveying state DOTs to learn about their sustainability goals and practices, identifying existing sustainability attributes and sustainable practices, and developing a GIS database where construction, materials and performance data of sustainable practices can be stored and analyzed. Full article

This study aimed to evaluate the effectiveness of a novel concrete-encased column (CE) using small circular steel tubes filled with cementitious grouting material (GFST) as the primary reinforcement instead of traditional steel bars. The research involved three different types of reinforcement: conventional steel bars, concrete-filled steel tubes with 30% of the reinforcement ratio of steel bars, and concrete-filled steel tubes with the same reinforcement ratio as steel bars. Twenty-four circular concrete columns were tested and categorized into six groups based on the type of reinforcement employed. Each group comprised four columns, with one subjected to concentric axial load, two subjected to eccentric axial load (with eccentricities of 25 mm and 50 mm, respectively), and one tested under lateral flexural loads. To validate the experimental results, finite element (FE) analysis was conducted using ABAQUS software version 6.14. The experimental findings for concentric load reveal that columns with the second type of reinforcement, concrete-filled steel tubes with 30% of the reinforcement ratio of steel bars exhibited a failure load 19% lower than those with steel bars, while columns with the third type of reinforcement, concrete-filled steel tubes with the same reinforcement ratio as steel bars achieved a failure load 17% greater than the traditional steel bars. The FE analysis demonstrates good agreement with the experimental outcomes in terms of ultimate strength, deformation, and failure modes. Full article

This research addresses the significant challenge posed by early water damage in highway asphalt pavement, a critical concern affecting pavement service performance. To counteract this issue, the utilization of anti-stripping agents in asphalt is explored as a highly effective technical intervention. In this investigation, a carefully selected amine-free additive was employed to modify the asphalt binder. A comprehensive array of physical and rheological tests, covering aspects such as storage stability, penetration, softening point, ductility, elastic recovery, rolling thin-film oven, retained penetration, the ductility of residue, and rotational viscometer assessments, were conducted to examine the multifaceted impact of the anti-stripping agent on the asphalt binder. Additionally, we assessed the asphalt mixture’s sensitivity to moisture through Marshall stability tests after conditioning for 40 min and 24 h, followed by an enhanced immersion test and moisture susceptibility measurement. The results reveal a nuanced interplay of chemical and physical mechanisms influencing the behavior of the asphalt binder. Notably, the incorporation of an anti-stripping agent at a concentration of 0.25–0.5% (by weight of asphalt binder) led to a substantial improvement in the tensile strength ratio (TSR) to 94.9%, a noteworthy enhancement compared to the 80.6% observed with virgin asphalt mixture. Furthermore, the retained stability index (RSI) exhibited a remarkable increase to 98.1%, surpassing the 87.6% recorded for virgin asphalt. This study not only provides crucial insights into the intricate dynamics of asphalt binder performance but also emphasizes the pivotal role of anti-stripping agents in augmenting the structural integrity and resilience of asphalt pavement. Full article

Construction projects, especially those for commercial purposes, require thorough planning and control to ensure success within predetermined budgets and timelines. This research, conducted in Mashhad, Iran, employs the analytic hierarchy process (AHP) and VIKOR methods to identify and rank factors influencing delays in high-rise projects. The study, based on a sample of 40 projects, emphasizes the comprehensive nature of our research method. The scale for features in project selection includes societal importance (with different applications including cultural hubs, affordable housing initiatives, and urban renewal for social equity), size (less and more than 20 units in residential projects), and diversity (mixed-use development, inclusive infrastructure, and cultural and recreational spaces), contributing to a comprehensive analysis of construction delays. Expert project managers and engineers provided insights through two questionnaires, and their responses underwent thorough analysis. Our findings not only underscore the significance of factors contributing to project success but also rank their impact on the likelihood of delays. The study reveals that the negative effects of these factors on cost, time, and project quality vary. Time emerges as the most influential parameter, with approximately six times more impact on cost and nine times more on quality. Contractor financial weakness, delays in allocating financial and credit resources, insufficient project resource allocation, contractor technical and executive weakness, and a lack of proper implementation and project control are identified as the most important factors contributing to delays. Full article

A rock-filled concrete (RFC) dam is an original dam construction technology invented in China nearly 20 years ago. The technology has been continuously improved and innovated upon, and the accumulated rich practical experience gradually formed a complete dam design and construction technology. Seismic design is a key design area for RFC dams that still requires more investigation; therefore, this article attempts to address some questions in this area. In the article, the seismic design for a curved gravity dam, currently under construction, is compared for RFC and conventional vibrating concrete (CVC) dam alternatives based on American design documents. The conclusions drawn from investigations include the following: The displacement and stress distributions in both the CVC and RFC alternatives are similar, but the maximum computed values for the RFC dam model are slightly smaller than those for the CVC one, while the sliding resistance of both dam alternatives can meet the requirements of the specifications. Regarding the nonlinear seismic analysis results, the extent of damage in the RFC dam model is significantly reduced when compared with the CVC model, which can be explained by the higher cracking resistance of RFC. In general, the seismic performance of the investigated dam made of RFC appears to be better than that of CVC. Full article

Roller-compacted concrete (RCC) pavements have been the subject of studies focused on their increasing deterioration over time due to the influence of vehicular loading and ambient factors in humidity and temperature conditions ranging from medium to low (40% relative humidity and 25 °C temperature). Therefore, it is necessary to understand how they behave under various relative humidity and temperature conditions since these parameters vary in each geographic region. In this context, this research focused on analyzing the effect of drying shrinkage on RCC pavements under the influence of vehicular loading using a computational model calibrated with data obtained under typical ambient conditions. For this purpose, laboratory experiments were performed, numerical modeling was used, and the results for RCC pavements were validated using statistical analysis. The results revealed validated models providing moisture content and drying shrinkage curves. These results also underline the importance of considering ambient effects when calculating pavement stresses as a response variable in structural designs. In particular, these effects are highlighted as they can generate changes in pavement stresses of up to 10%, emphasizing the relevance of the models proposed in this study as they consider this phenomenon when predicting the performance and durability of RCC pavements. Full article

Airport pavements have always evolved to keep pace with the demands of new aircraft. As aircraft weights and tyre pressures increase, stronger, new pavements are designed and existing pavements are rehabilitated or upgraded. The narrow-body commercial jet aircraft, including the A320 and B737 families, are examples of aircraft that have retained the same number of wheels, with the same wheel spacing and the same wingspan, but have increased in weight and tyre pressure by approximately 50%. This places significant demand on airport pavements that were designed for the lighter variants but now face the introduction of the newer, heavier and more demanding variants. This research quantified the impact of the new A320 and B737 narrow-body aircraft variants on rigid and flexible regional airport pavements, where these are the critical aircraft, as well as demonstrating the importance of understanding the operational weight limitations of these aircraft, which is often well below the published maximum weight. Within the context of the pavements considered, the additional pavement thickness required for the heaviest aircraft variants, compared to the lightest variants, was 51%. Based on four examples from real regional airports in Australia, it was found that the additional embodied carbon associated with these new aircraft variants was 2.1–85.3 kg·eCO₂/m² of pavement, while the additional financial cost was AUD 6–219/m² of pavement. It was concluded that airport pavement thickness designers must challenge the weight of the design aircraft and not take the simple and conservative approach of adopting the maximum weight of the heaviest variant within each aircraft family. By doing so, significant additional pavement thickness will be constructed for no practical benefit, creating an environmental (embodied carbon) and economic (financial cost) burden. Full article

Temperature is the main driver of bridge response. It is continuously applied and may have complex distributions across the bridge. Daily temperature loads force bridges to undergo deformations that are larger than or equal to peak-to-peak traffic loads. Bridge thermal response must therefore be accounted for when performing load rating and condition assessment. This study assesses the importance of characterizing bridge thermal response and separating it from traffic-induced response. Numerical replicas (i.e., fine element models) of a steel girder bridge are generated to validate the proposed methodology. Firstly, a variety of temperature distribution scenarios, such as those resulting from extreme weather conditions due to climate change, are modelled. Then, nominal traffic load scenarios are simulated, and bridge response is characterized. Finally, damage is modelled as a reduction in material stiffness due to corrosion. Bridge response to applied traffic load is different before and after the introduction of damage; however, it can only be correctly quantified when the bridge thermal response is accurately accounted for. The study emphasizes the importance of accounting for distributed temperature loads and characterizing bridge thermal response, which are important factors to consider both in bridge design and condition assessment. Full article

Investigating the impact of near-field ground motions on the fragility curves of multi-span simply supported concrete girder bridges is the main goal of this paper. Fragility curves are valuable tools for evaluating seismic risks and vulnerabilities of bridges. Numerous studies have investigated the impact of ground motions on the fragility curves of bridges. Ground motions are commonly categorized into two sets, based on the distance of the recorded station from the seismic source: far-field and near-field. Studies examining the influence of near-field records on bridge fragility curves vary depending on the specific bridge type and type of fragility curve being analyzed. Due to the widespread use of multi-span simply supported concrete girder bridges in the Central and Southeastern United States, this study makes use of this bridge type. This research investigates the component fragility curves for column curvatures, bearing deformations, and abutment displacements by employing 3-D analytical models and conducting nonlinear time history analysis. These curves illustrate the impact of near-field ground motions on different components. The component fragility curves for two sets of records, 91 near-field ground motions and 78 far-field ground motions, were obtained and compared. These findings demonstrate that near-field ground motions have a greater damaging effect on columns and abutments than far-field earthquakes. When it comes to bearing deformations, the far-field earthquake impact is more severe at lower intensities, whereas the impact of the near-field ground motion is stronger at higher intensities. Full article

The seismic damage in reinforced concrete bridges is identified in this study using the “M and P” hybrid technique initially developed for planar frames, where M signifies “Monitoring” and P denotes “Pushover analysis”. The proposed methodology involves a series of pushover and instantaneous modal analyses with a progressively increasing target deck displacement along the longitudinal direction of the bridge. From the results of these analyses, the diagram of the instantaneous eigenfrequency of the bridge, ranging from the health state to near collapse, is plotted against the inelastic seismic deck displacement. By pre-determining the eigenfrequency of an existing bridge along its longitudinal direction through “monitoring and frequency identification”, the target deck displacement corresponding to the damage state can directly be found from this diagram. Subsequently, the damage can be identified by examining the results of the pushover analysis at the step where the target deck displacement is indicated. The effectiveness of this proposed technique is evaluated in the context of straight multiple span bridges with unequal pier heights, illustrated through an example of a four-span bridge. The findings demonstrate that the damage potential in bridge piers can be successfully identified by combining the results of a monitoring process and pushover analysis. Full article

The management of unutilized fly ash poses challenges due to concerns about storage and its potential groundwater contamination. Within the road industry, where the bulk utilization of fly ash is feasible, its unsuitability for use in the base and sub-base layers of pavements due to its low strength and a high proportion of fine particles has been a limitation. The incorporation of stone dust alongside fly ash, treated with lime or cement, yields superior strength and stiffness. Apart from strength, the stabilized mix’s durability, capillary rise, and water absorption properties are crucial for determining its suitability for pavement applications. Observations from this study reveal that fiber-reinforced cement-stabilized fly ash–stone aggregate specimens treated with 4% and 6% cement, with and without fibers, met the limiting mass loss of 20%, as specified in IRC SP: 89. The mass loss decreases with an increase in cement and fiber content. However, the capillary rise in the mixes increases with a higher percentage of fly ash and fiber content but decreases with increased cement content. Cement addition results in a reduction in water absorption; however, the addition of fibers results in an increase in water absorption. A linear correlation has been established between mass loss and UCS and IDT, which can be used to evaluate the suitability of materials for the structural layer without conducting a wet–dry durability test, which typically takes one month. This study proposes that cement-stabilized fly ash and stone aggregate mixtures with 4% and 6% cement can be used as the subbase and base of pavement based on wet–dry mass loss criteria and water absorption criteria. Observations from this study reveal that fiber-reinforced cement-stabilized fly ash–stone aggregate specimens treated with 4% and 6% cement, with and without fibers, met the limiting mass loss of 20%, as specified in IRC SP: 89. The mass loss decreases with an increase in cement and fiber content. However, the capillary rise in the mixes increases with a higher percentage of fly ash and fiber content but decreases with increased cement content. Cement addition results in reduction in water absorption. However, the addition of fibers results in increase in water absorption. A linear correlation is established between mass loss and UCS and IDT, which can be used to evaluate the suitability of materials for the structural layer without conducting wet–dry durability tests, which take one month. This study proposes that cement-stabilized fly ash and stone aggregate mixtures with 4% and 6% cement can be used as the subbase and base of pavement based on wet–dry mass loss criteria and water absorption criteria. Full article
