Acoustics, Volume 6, Issue 3 (September 2024) – 13 articles

Ultrasound B-scan images are traditionally formed from the envelope of the received radiofrequency echoes, but the image texture is dominated by granular speckle patterns. Longstanding efforts at speckle reduction and deconvolution have been developed to lessen the detrimental aspects of speckle. However, we now propose an alternative approach to estimation (and image rendering) of the underlying fine grain scattering density of tissues based on power law constraints. The key steps are a whitening of the spectrum of the received signal while conforming to the original envelope shape and statistics, followed by a power law filtering in accordance with the known scattering behavior of tissues. This multiple step approach results in a high-spatial-resolution map of scattering density that is constrained by the most important properties of scattering from tissues. Examples from in vivo liver scans are shown to illustrate the change in image properties from this framework. Full article

In this paper, we present a novel approach for text-independent phone-to-audio alignment based on phoneme recognition, representation learning and knowledge transfer. Our method leverages a self-supervised model (Wav2Vec2) fine-tuned for phoneme recognition using a Connectionist Temporal Classification (CTC) loss, a dimension reduction model and a frame-level phoneme classifier trained using forced-alignment labels (using Montreal Forced Aligner) to produce multi-lingual phonetic representations, thus requiring minimal additional training. We evaluate our model using synthetic native data from the TIMIT dataset and the SCRIBE dataset for American and British English, respectively. Our proposed model outperforms the state-of-the-art (charsiu) in statistical metrics and has applications in language learning and speech processing systems. We leave experiments on other languages for future work but the design of the system makes it easily adaptable to other languages. Full article

The Stockholm Public Library was realized in two distinct phases of construction in the 1920s and early 1930s, and remains a well-known work in twentieth-century architecture, with a heritage status today. While previous studies have focused on the library’s architectural design, particularly its lighting, acoustics were also an important aspect of the building’s design and construction. This study marks the first detailed investigation of the library’s architectural acoustics, with a suite of standard measurements performed to assess and characterize the library’s historical room and building acoustics. Reverberation time measurements in the library’s reading rooms yielded results of about 1.5–2 s for frequencies associated with speech. A significantly longer reverberation time of 5–6 s was measured in the library’s central rotunda, confirming a prominent acoustic issue in the library, where appropriate heritage discussions are needed in the future as the library undergoes a major renovation in the coming years. A comparison of the measured airborne and impact sound insulation of the 1920s and 1930s reading room ceilings also yielded interesting results. While the materials in library’s two construction periods are notably different, the airborne sound insulation performance of the 1920s and 1930s floors or ceilings was comparable and in line with contemporary standards. Impact sound insulation results from the 1920s and 1930s floors, however, differed significantly, with the latter displaying a relatively poor performance. Flanking transmission effects related to historical construction details and deviations from archival plans were investigated and discussed. This work emphasizes the practical and academic importance of conducting on-site measurements, and the close mutual development of modern architecture, construction, and architectural acoustics. Full article

This paper describes the use of an electric drive as an acoustic actuator for active noise cancellation (ANC). In the presented application, the idea is to improve the noise, vibration, harshness (NVH) characteristics of passenger cars without using additional active or passive damper systems. Many of the already existing electric drives in cars are equipped with the required hardware components to generate noise and vibration, which can be used as compensation signals in an ANC application. To demonstrate the applicability of the idea, the electrical power steering (EPS) motor is stimulated with a control signal, generated by an adaptive feedforward controller, to reduce harmonic disturbances at the driver’s ears. As it turns out, the EPS system generates higher harmonics of the harmonic compensation signal due to nonlinearities in the acoustic transfer path using a harmonic excitation signal. The higher harmonics impair an improvement in the subjective hearing experience, although the airborne noise level of the harmonic disturbance signal can be clearly reduced at the driver’s ears. Therefore, two methods are presented to reduce the amplitude of the higher harmonics. The first method is to limit the filter weights of the algorithm to reduce the amplitude of the harmonic compensation signal. The filter amplitude limitation also leads to a lower amplitude of the higher harmonics, generated by the permanent magnet synchronous machine (PMSM). The second method uses a parallel structure of adaptive filters to actively reduce the amplitude of the higher harmonics. Finally, the effectiveness of the proposed ANC system is demonstrated in two real driving situations, where in one case a synthetic noise/vibration induced by a shaker on the front axle carrier is considered to be the disturbance, and in the other case, the disturbance is a harmonic vibration generated by the combustion engine. In both cases, the subjective hearing experience of the driver could be clearly improved using the EPS motor as ANC actuator. Full article

In this paper, we utilise optimization methods to determine a frequency-independent phase shift such that two phase-shifted versions of a signal can be summed and the resulting amplitude spectrum is unchanged. A phase difference between two signals is thus defined, which remains constant for all frequencies within a given range. For the intended purpose of this study, we set the frequency range to the audible human hearing range of 16 Hz–20 kHz. We found that a new 3-stage filter method provides a variable phase shifter (i.e., ϕ = 0–360°) without the need for additional amplifiers. In addition, we present a new method that reduces the number of filters necessary, improving both the accuracy and efficiency of current techniques. Full article

This paper aims to conduct an acoustic analysis through noise measurements of a hybrid propulsion system intended for implementation on a drone, from which the main noise sources can be identified for further research on noise reduction techniques. Additionally, the noise was characterized by performing spectral analysis and identifying the tonal components that contribute to the overall noise. The propelling force system consists of a micro-turboshaft coupled with a gearbox connected to an electric generator. The propulsion system consists of a micro-turboshaft coupled with a gearbox connected to an electric generator. The electric current produced by the generator powers an electric ducted fan (EDF). The engineturbo-engine was tested in free-field conditions for noise generation at different speeds, and for this, an array of microphones was installed, positioned polarly around the system and near the intake and exhaust. Consequently, based on the test results, the acoustic directivity was plotted, revealing that the highest noise levels are at the front and rear of the engine. The noise level at a distance of 1.5 m from the turboengine exceeds 90 dBA at all tested speeds. Spectral analyses of both the far-field acoustic signals (measured with a polar microphone array) and the near-field signals (microphones positioned near the intake and exhaust) revealed that the primary contributors to the overall noise are the micromotor’s compressor, specifically the gas dynamic phenomena in the fan (BPF and 2× BPF). Thus, it was determined that at the intake level, the main noise contribution comes from the high-frequency components of the compressor, while at the exhaust level, the noise mainly originates from the combustion chamber, characterized by low-frequency components (up to 2 kHz). The findings from this study have practical applications in the design and development of quieter drone propulsion systems. By identifying and targeting the primary noise sources, engineers can implement effective noise reduction strategies, leading to drones that are less disruptive in urban environments and other noise-sensitive areas. This can enhance the acceptance and deployment of drone technology in various sectors, including logistics, surveillance, and environmental monitoring. Full article

Understanding students’ acoustic evaluation in learning environments is crucial for identifying acoustic issues, improving acoustic conditions, and enhancing academic performance. However, predictive models are not specifically tailored to predict students’ acoustic evaluations, particularly in educational settings. To bridge this gap, the present study conducted a field investigation in a university library, including a measurement and questionnaire survey. Using the collected personal information, room-related parameters, and sound pressure levels as input, six machine learning models (Support Vector Machine–Radial Basis Function (SVM (RBF)), Support Vector Machine–Sigmoid (SVM (Sigmoid)), Gradient Boosting Machine (GBM), Logistic Regression (LR), Random Forest (RF), and Naïve Bayes (NB)) were trained to predict students’ acoustic acceptance/satisfaction. The performance of these models was evaluated using five metrics, allowing for a comparative analysis. The results revealed that the models better predicted acoustic acceptance than acoustic satisfaction. Notably, the RF and GBM models exhibited the highest performance, with accuracies of 0.87 and 0.84, respectively, in predicting acoustic acceptance. Conversely, the SVM models performed poorly and were not recommended for acoustic quality prediction. The findings of this study demonstrated the feasibility of employing machine learning models to predict occupants’ acoustic evaluations, thereby providing valuable insights for future acoustic assessments. Full article

This study delves into the effectiveness of two time integration techniques, namely the adaptive implicit–explicit (imp–exp) and explicit–explicit (exp–exp) methods, which stand as efficient formulations for tackling intricate systems characterized by multiple time scales. The imp–exp technique combines implicit and explicit procedures by employing implicit formulations for faster components and explicit calculations for slower ones, achieving high accuracy and computational efficiency. Conversely, the exp–exp method, a variation of explicit methods with sub-cycling, excels in handling locally stiff systems by employing smaller sub-steps to resolve rapid changes while maintaining stability. For both these approaches, numerical damping may be activated by adaptive time integration parameters, allowing numerical dissipation to be locally applied, if necessary, as a function of the considered discrete model and its computed responses, enabling a highly effective numerical dissipative algorithm. Furthermore, both these techniques stand as very simple and straightforward formulations as they rely solely on single-step displacement–velocity relations, describing truly self-starting procedures, and they stand as entirely automated methodologies, requiring no effort nor expertise from the user. This work provides comparative studies of the adaptive imp–exp and exp–exp approaches to assess their accuracy and efficiency across a wide range of scenarios, with emphasis on geophysical applications characterized by multiscale problems, aiming to establish under which circumstances one approach should be preferred over the other. Full article

Objectives: The purpose of this study was to evaluate and compare the noise levels in current incubator models and a prototype designed to improve acoustic comfort in neonatal incubators. Methods: Tests were carried out on three different models of incubators and a prototype called Neonatal Incubator Acoustic Comfort Class (NICA). The tests measured both internal and external sound pressure levels under laboratory conditions. The noise index has been taken as the A-weighted equivalent continuous sound pressure level (LAeq,T) for a time interval of 1 min. Results: The results obtained show variations between the different models of incubators, although, overall, they are high values (around 56/60 dBA). The results prove that premature newborns under normal conditions of using these incubators are exposed to noise levels above international recommendations. The new incubator design minimizes noise generation and generates noise levels lower than international recommendations. Conclusions: The results obtained from the prototype (NICA+) show the effectiveness of the proposed design in improving acoustic comfort in neonatal incubators. The data show that the noise levels generated by the prototype under normal operating conditions are significantly lower than international recommendations. Full article

Acoustic Emission (AE) testing is a non-destructive evaluation technique that has gained significant attention in pipeline monitoring. Pencil-lead breaks (PLBs) are commonly used in reproducing and characterising sensors used in AE applications and have emerged as a valuable tool for calibration processes. This technique involves breaking a pencil lead by pressing it on the surface of the test structure and applying a bending moment at a given angle on a surface. The applied force produces a local deformation on the test surface, which is released when the lead breaks. The fracture in these PLBs is assumed to be a step unload; however, this is not the case. In this work, a series of PLB source experiments complemented with parallel numerical simulations were carried out to investigate the actual unload rate by correlating the relationship between AE speed, frequency, and power from PLBs. This was achieved by varying the simulation unload rates recorded over a duration of 2 s on a steel pipe and comparing to the experiment. Analysis of the investigated results from the experimental and numerical models suggests that although the AE line structure of a PLB can be reproduced by simulation for short times only (1 µs), the actual unload rate for PLBs is in the region of 10–8 s. It is concluded that FEA has the potential to help in the recovery of the temporal structure from real AE structures. The establishment of this model will provide a theoretical basis for future studies on the monitoring of non-impulsive AE sources such as impact on pipelines using finite element analysis. Full article

In unbounded media, the acoustic attenuation as function of frequency is related to the frequency-dependent sound velocity (dispersion) via Kramers–Kronig dispersion relations. These relations are fundamentally important for better understanding of the nature of attenuation and dispersion and as a tool in physical acoustics measurements, where they can be used for control purposes. However, physical acoustic measurements are frequently carried out not in unbounded media but in acoustic waveguides, e.g., inside liquid-filled pipes. Surface acoustic waves are also often used for physical acoustics measurements. In the present work, the applicability of Kramers–Kronig relations to guided and surface waves is investigated using the approach based on the theory of functions of complex variables. It is demonstrated that Kramers–Kronig relations have limited applicability to guided and surface waves. In particular, they are not applicable to waves propagating in waveguides characterised by the possibility of wave energy leakage from the waveguides into the surrounding medium. For waveguides without leakages, e.g., those formed by rigid walls, Kramers–Kronig relations remain valid for both ideal and viscous liquids. Examples of numerical calculations of wave dispersion and attenuation using Kramers–Kronig relations, where applicable, are presented for unbounded media and for waveguides formed by two rigid walls. Full article

Currently, ultrasonic methods for assessing the fatigue lifetime of various structural materials are being actively developed. Many steel constructions are made by welding. The weld heat-affected zone is the weak point of the construction, as it is most susceptible to destruction. Therefore, it is actually important to search for acoustic parameters that uniquely characterize the structural damage accumulation in the heat-affected zone of a welded joint in order to predict failure. In this work, the specimens were made from the base metal and the welded joint’s heat-affected zone. The specimens were subjected to uniaxial tension–compression under a symmetrical cycle in the region of low-cycle fatigue with control of the strain amplitude. The propagation bulk velocities of longitudinal, shear waves and subsurface longitudinal critically refracted (LCR) waves during cyclic loading were studied. The acoustic birefringence of shear waves was calculated, and a similar parameter was proposed for longitudinal and LCR waves. The dependence of the elastic modulus ratio on the cycle ratio was obtained. It was shown that the acoustic parameters change most intensively in the heat-affected zone. According to the data of the C₃₃/C₅₅ ratio changes measured through the ultrasonic method, a formula for calculating the remaining fatigue life in the heat-affected zone was proposed. Full article

The primary cause of noise from vehicular traffic while travelling at speeds over 30 km/h is tyre/road interaction. To reduce this noise source, tyre/road sound emissions research has been carried out using different approaches. Most of this research has been centred around track tests, leading to the development of various track and road-based methods for evaluating tyre/road noise emissions. The CPX (Close-Proximity), along with the CPB (Controlled Pass-By), the CB (Coast-By) and the SPB (Statistical Pass-By), methods are the most common ones. Nevertheless, since Reg. (EC) 1222/2009 came into force, only the CB method, defined in Reg. (EC) 117/2007, can be used to obtain tyre/road noise emission type approval values in Europe. However, current track test methods have important limitations, such as the variability of the results depending on the test track or the test vehicle, the repeatability, the influence of environmental variables or, the main aspect, the limitation of the registered magnitude in these tests, which is the sound pressure level. The Alternative Drum test method (A-DR) was developed in 2015 in order to avoid these disadvantages. However, it involves a complex and time-consuming microphone array for each test. With the purpose of improving the A-DR test method, a new methodology based on drum tests, the ISO 11819-2 and the ISO 3744 standards, was developed. This paper describes the new Alternative CPX Drum test method (A-CPX-DR) and validates it by testing several tyres according to the CB, the A-DR and the A-CPX-DR test methods and comparing their results. This research has demonstrated that all three methods have equivalent sound spectra and obtain close equivalent sound pressure levels for type approval of tyres in the EU, while drum tests have shown greater accuracy. For both reasons, the new A-CPX-DR methodology could be used for tyre/road noise emission type approval in a more precise and cheaper way. Full article
