Effect of Metal Oxide Semiconductor Field-Effect Transistor Output Parasitic Capacitance on Efficiency in Full-Bridge LLC DC/DC Converters

by Ming-Hung Chen and Chia-Wen Hsieh

Micromachines 2024, 15(3), 309; https://doi.org/10.3390/mi15030309 - 23 Feb 2024

Viewed by 553

Abstract

This study analyzed the efficiency impact of a MOSFET output parasitic capacitance (

C_{o s s}

) on a full-bridge LLC DC/DC converter. The core of the converter was the control chip for a half-bridge LLC DC/DC converter, and the output signal [...] Read more.

This study analyzed the efficiency impact of a MOSFET output parasitic capacitance (

C_{o s s}

) on a full-bridge LLC DC/DC converter. The core of the converter was the control chip for a half-bridge LLC DC/DC converter, and the output signal of the chip controlled the first-arm power transistors of the primary side of the converter. The coupling transformer reversed the output signal to control the primary side of the second arm of the power transistor. The full-bridge converter comprises a half-bridge control chip that converts the high-voltage DC power supply to a low-voltage DC power supply, which is then synchronously rectified and supplied to the load. The primary side of the power transistor achieves a zero-voltage switching (ZVS) state through the resonance of the LLC converter. This design gives the converter high power density and a simple structure. Furthermore, to determine the appropriate output parasitic capacitance for improving converter efficiency, this study analyzed the effect of the output parasitic capacitance on the switching loss and conduction loss of the power transistor on the basis of the output parasitic capacitance of the primary-side power transistor. A 1200 W converter prototype was fabricated in this study, and when the output was 300 W, efficiency increased from 92.603% to 93.462%, a 0.859% increase. The empirical results verified the feasibility of the proposed theory. Full article

(This article belongs to the Special Issue Power Electronics and Power Conversion-Related Applications of Micro Energy Devices, 2nd Edition)

► Show Figures

Figure 1

21 pages, 10329 KiB

Open AccessArticle

Study on the Influence of Coil Arrangement on the Output Characteristics of Electromagnetic Galloping Energy Harvester

by Lei Xiong, Shiqiao Gao, Lei Jin, Yaoqiang Sun, Xueda Du and Feng Liu

Micromachines 2023, 14(12), 2158; https://doi.org/10.3390/mi14122158 - 26 Nov 2023

Viewed by 841

Abstract

The arrangement of the induction coil influences the electromagnetic damping force and output characteristics of electromagnetic energy harvesters. Based on the aforementioned information, this paper presents a proposal for a multiple off-center coil electromagnetic galloping energy harvester (MEGEH). This study establishes both a [...] Read more.

The arrangement of the induction coil influences the electromagnetic damping force and output characteristics of electromagnetic energy harvesters. Based on the aforementioned information, this paper presents a proposal for a multiple off-center coil electromagnetic galloping energy harvester (MEGEH). This study establishes both a theoretical model and a physical model to research the influence of the position and quantity of the induction coils on the output characteristics of an energy harvester. Additionally, it conducts wind tunnel tests and analyzes the obtained results. With the increase in the number of induction coils, there is a significant improvement in the duty cycle and output power of the MEGEH, resulting in an amplified energy conversion efficiency. At a wind speed of 9 m/s, the duty ratios of a single set of coils (SC), two sets of coils (TC), and multiple sets of coils (MC) are 30%, 51%, and 100%, respectively. The total output powers are 0.4 mW, 0.62 mW, and 0.72 mW. However, the rate of output growth has decreased from 55% to 16%. The position of the coils affects the initial electromagnetic damping of the energy harvester. Changing the position can reduce the initial electromagnetic damping, thereby decreasing the critical wind speed. The critical wind speed of the MEGEH decreases as the induction coil is positioned further away from the vibration center. When the distance is sufficiently large, the electromagnetic damping force becomes negligible. When the induction coil is positioned centrally, the MEGEH demonstrates its maximum critical wind speed, which has been measured at 4.01 m/s. When the initial distance between the induction coil and the vibrating component is increased to 10 mm, the critical wind speed reaches its minimum value of 2.23 m/s. Therefore, it is necessary to optimize the arrangement of the coils. The coils of the MEGEH should be arranged with the MC and a 10 mm offset from the center. Full article

(This article belongs to the Special Issue Power Electronics and Power Conversion-Related Applications of Micro Energy Devices, 2nd Edition)

► Show Figures

Figure 1

13 pages, 6174 KiB

Open AccessArticle

Development and Implementation of LED Street Lights with Bright and Extinguishable Controls and Power Converters

by Kai-Jun Pai, Liang-Hsun Wang and Ming-Hung Chen

Micromachines 2023, 14(7), 1453; https://doi.org/10.3390/mi14071453 - 20 Jul 2023

Cited by 1 | Viewed by 876

Abstract

This study developed and implemented a driving power supply for light-emitting diode (LED) array streetlamps. The power stage was a quasi-resonant (QR)-flyback converter, its input power was the alternating-current power, and the LED array streetlamp was driven by the direct-current output power. The [...] Read more.

This study developed and implemented a driving power supply for light-emitting diode (LED) array streetlamps. The power stage was a quasi-resonant (QR)-flyback converter, its input power was the alternating-current power, and the LED array streetlamp was driven by the direct-current output power. The developed QR-flyback converter was operated in discontinuous conduction mode, and the pulse-width modulation (PWM) control chip was used to switch and conduct at the resonant valley of the drain-source voltage on the metal-oxide-semiconductor field-effect transistor (MOSFET) switch to reduce the switching loss. Moreover, the PWM control chip had a disable function, which was connected with a bright and extinguishable control circuit, and the high/low voltage level signal output by the Arduino development board can be used to control the output power of the QR-flyback converter, achieving bright and extinguishable controls for the LED array streetlamp. Full article

(This article belongs to the Special Issue Power Electronics and Power Conversion-Related Applications of Micro Energy Devices, 2nd Edition)

► Show Figures

Figure 1

25 pages, 10817 KiB

Open AccessArticle

Development and Performance Evaluation of Integrated Hybrid Power Module for Three-Phase Servo Motor Applications

by Hsien-Chie Cheng, Yan-Cheng Liu, Hsin-Han Lin, Shian-Chiau Chiou, Chih-Ming Tzeng and Tao-Chih Chang

Micromachines 2023, 14(7), 1356; https://doi.org/10.3390/mi14071356 - 30 Jun 2023

Cited by 2 | Viewed by 1443

Abstract

This study aims to develop a 30 kHz/12 kW silicon carbide (SiC)/Si integrated hybrid power module (iHPM) for variable frequency drive applications, particularly industrial servo motor control, and, additionally, to theoretically and experimentally assess its dynamic characteristics and efficiency during operation. This iHPM [...] Read more.

This study aims to develop a 30 kHz/12 kW silicon carbide (SiC)/Si integrated hybrid power module (iHPM) for variable frequency drive applications, particularly industrial servo motor control, and, additionally, to theoretically and experimentally assess its dynamic characteristics and efficiency during operation. This iHPM integrates a brake circuit, a three-phase Si rectifier, and a three-phase SiC inverter within a single package to achieve a minimal current path. A space-vector pulse width modulation (SVPWM) scheme is used to control the inverter power switches. In order to reduce parasitic inductance and power loss, an inductance cancellation design is implemented in the Si rectifier and SiC inverter. The switching transients and their parasitic effects during a three-phase operation are assessed through an electromagnetic-circuit co-simulation model, by which the power loss and efficiency of the iHPM are estimated. The modeled parasitic inductance of the inverter is validated through inductance measurement, and the effectiveness of the simulated results in terms of switching transients and efficiency is verified using the experimental results of the double pulse test and open-loop inverter operation, respectively. In addition, the power loss and efficiency of the SiC MOSFET inverter are experimentally compared against those of a commercial Si IGBT inverter. Full article

(This article belongs to the Special Issue Power Electronics and Power Conversion-Related Applications of Micro Energy Devices, 2nd Edition)

► Show Figures

Figure 1

14 pages, 7603 KiB

Open AccessArticle

Smart Cup for In-Situ 3D Measurement of Wall-Mounted Debris via 2D Sensing Grid in Production Pipelines

by Hao Tian, Sunyi Wang, Minglei Fu, Dayong Ning and Yongjun Gong

Micromachines 2023, 14(2), 489; https://doi.org/10.3390/mi14020489 - 19 Feb 2023

Viewed by 1351

Abstract

The accumulation of separated out impurities from pipeline transported medium onto the pipe wall is a major cause of downtime maintenance of oil and gas production systems. To regularly scrub off wall-mounted debris and probe the severity, pipeline inspection gauges (PIG) are the [...] Read more.

The accumulation of separated out impurities from pipeline transported medium onto the pipe wall is a major cause of downtime maintenance of oil and gas production systems. To regularly scrub off wall-mounted debris and probe the severity, pipeline inspection gauges (PIG) are the state-of-the-art tools developed for the task, using the pressure differential across the device as the driving force, and tag-along sensing equipment for wall defects measurement. Currently, the PIG propulsion and sensing tasks are realized by separate compartments, limited to large diameter operations. In this work, a soft solution for medium to small diameter pipelines has been demonstrated. The smart cup with integrated sensing grid is proposed to achieve integrated wall-mounted debris dimensional measurement, without the need of additional sensors. To achieve the goal, this work starts from the mathematical modelling of the geometric problem, to new fabrication procedures, experimental setup, and finally finishes with validation results. Initial results have shown that using the proposed smart cup, the wall-mounted debris can be detected, with modelling error maxed at 5.1%, and deformation detection accuracy between 1.18% and 1.92% with respect to the outer diameter. Full article

(This article belongs to the Special Issue Power Electronics and Power Conversion-Related Applications of Micro Energy Devices, 2nd Edition)

► Show Figures

Figure 1

17 pages, 3418 KiB

Open AccessArticle

Study and Implementation of a High-Quality True Sine Wave DC-to-AC Inverter for Solar Power Generation Systems

by En-Chih Chang, Rong-Ching Wu, Heidi H. Chang and Chun-An Cheng

Micromachines 2022, 13(10), 1723; https://doi.org/10.3390/mi13101723 - 12 Oct 2022

Cited by 1 | Viewed by 1527

Abstract

True sine wave DC-to-AC inverters are becoming more and more important in solar power generation in order to raise the system’s efficiency. A high-quality true sine wave DC-to-AC inverter can be built with a robust intelligent control method. This robust intelligent control method [...] Read more.

True sine wave DC-to-AC inverters are becoming more and more important in solar power generation in order to raise the system’s efficiency. A high-quality true sine wave DC-to-AC inverter can be built with a robust intelligent control method. This robust intelligent control method is comprised of improved sliding mode reaching law (ISMRL) and particle swarm optimization (PSO)—catfish effect (CE). The sliding mode reaching law is robust and insensitive to parameter variations and external disturbances. However, it has infinite system-state convergence times and steady-state errors. In addition, solar panels are often affected by partial shading, causing the output power–voltage characteristic curve to be multi-peaked. Such a situation causes misjudgment of the maximum power point tracking with conventional algorithms, which can neither obtain the global extremes nor establish high conversion efficiency. Therefore, this paper proposes an ISMRL based on PSO-CE applied to the tracking of maximum power in the case of partial shading of a solar power generation system. The ISMRL guarantees quick terminable time convergence, making it well-suited for digital implementation. In this paper, PSO-CE is used to find the global best solution of ISMRL, rejecting steady-state errors, slow convergence, and premature trapping in local optimums. Simulation and experimental results are verified using digital implementation based on a Texas Instruments digital signal processor to produce more accurate and better tracking control of true sine wave DC-to-AC inverter-based solar power generation systems. Full article

(This article belongs to the Special Issue Power Electronics and Power Conversion-Related Applications of Micro Energy Devices, 2nd Edition)

► Show Figures

Figure 1

19 pages, 5916 KiB

Open AccessArticle

Highly Efficient Four-Rod Pumping Approach for the Most Stable Solar Laser Emission

by Miguel Catela, Dawei Liang, Cláudia R. Vistas, Dário Garcia, Hugo Costa, Bruno D. Tibúrcio and Joana Almeida

Micromachines 2022, 13(10), 1670; https://doi.org/10.3390/mi13101670 - 4 Oct 2022

Cited by 6 | Viewed by 1143

Abstract

We report a significant numerical improvement in multi-rod laser efficiency, with an enhanced solar tracking error compensation capacity for a heliostat-parabolic system. The solar laser head was composed of a fused silica conical lens and a single conical pump cavity ensuring multiple passes [...] Read more.

We report a significant numerical improvement in multi-rod laser efficiency, with an enhanced solar tracking error compensation capacity for a heliostat-parabolic system. The solar laser head was composed of a fused silica conical lens and a single conical pump cavity ensuring multiple passes through four 4.55 mm diameter, 15 mm length Nd:YAG rods. 0.76° tracking error width at 10% laser power loss, and total multimode laser power variation of 0.05% at ±0.1° solar tracking error and 0.30% at ±0.2° solar tracking error were numerically calculated, being 1.27, 74.80 and 21.63 times, respectively, more than the experimental record in solar tracking error compensation capacity attained with a dual-rod side-pumping horizontal prototype pumped by the same heliostat-parabolic system. Additionally, the end-side-pumping configuration of the four-rod solar laser-enabled 43.7 W total multimode solar laser power, leading to 24.7 W/m² collection efficiency and 2.6% solar-to-laser power conversion efficiency, being 1.75 and 1.44 times, respectively, more than that experimentally obtained from the dual-rod side-pumping prototype. The significant improvement in solar tracking error compensation capacity with a highly efficient end-side-pumping configuration is meaningful because it reduces the cost of high-precision trackers for solar laser applications. Full article

(This article belongs to the Special Issue Power Electronics and Power Conversion-Related Applications of Micro Energy Devices, 2nd Edition)

► Show Figures

Figure 1

16 pages, 6012 KiB

Open AccessArticle

A High-Gain and High-Efficiency Photovoltaic Grid-Connected Inverter with Magnetic Coupling

by Chien-Hsuan Chang, Chun-An Cheng, Hung-Liang Cheng and En-Chih Chang

Micromachines 2022, 13(10), 1568; https://doi.org/10.3390/mi13101568 - 21 Sep 2022

Viewed by 1560

Abstract

Conventional photovoltaic (PV) grid-connected systems consist of a boost converter cascaded with an inverter, resulting in poor efficiency due to performing energy processing twice. Many pseudo DC-link inverters with single energy processing have been proposed to improve system efficiency and simplify circuits. However, [...] Read more.

Conventional photovoltaic (PV) grid-connected systems consist of a boost converter cascaded with an inverter, resulting in poor efficiency due to performing energy processing twice. Many pseudo DC-link inverters with single energy processing have been proposed to improve system efficiency and simplify circuits. However, their output voltage gain is limited by the non-ideal characteristics of the power diode, making them difficult to apply in high-output voltage applications. This paper proposes combining a boost converter with magnetic coupling and a full-bridge unfolding circuit to develop an inverter featuring high voltage-gain and high efficiency. According to the desired instantaneous output voltage, the high-gain boost converter and the full-bridge unfolding circuit are sequentially and respectively controlled by SPWM. A sinusoidal output voltage can be generated by performing energy processing only once, effectively improving the conversion efficiency. Magnetic coupling is adopted to increase the voltage gain of step-up, and the step-down function is realized by the full-bridge unfolding circuit to reduce conduction loss. Finally, a 500 W prototype was fabricated for the proposed high-gain inverter. The experimental results were used to verify the correctness of the theoretical analysis and the feasibility of the circuit structure. Full article

(This article belongs to the Special Issue Power Electronics and Power Conversion-Related Applications of Micro Energy Devices, 2nd Edition)

► Show Figures

Figure 1
