Microactuators

A special issue of Micromachines (ISSN 2072-666X).

Deadline for manuscript submissions: closed (30 September 2014) | Viewed by 57268

Special Issue Editor

Prof. Dr. Ulrike Wallrabe

E-Mail Website
Guest Editor
Laboratory for Microactuators IMTEK—Department of Microsystems Engineering University of Freiburg Georges-Koehler-Allee 102 79110 Freiburg, Germany
Interests: actuation mechanism for adaptive optical elements; unusual field patterns in piezoelectric actuators; magnetic micro actuators; processes and application of 3D solenoidal micro coils; wireless energy transfer
Special Issues, Collections and Topics in MDPI journals

Special Issue Information

Dear Colleagues,

Looking back at thirty years of microsystem development, micro actuators have proved themselves to be the key elements for almost all kinds of microsystems. Hardly found as stand-alone components, they are typically integrated into systems. The most obvious example, and simultaneously the most popular device, is the electrostatic comb actuator, which is found as an integrated part of innumerous inertial sensors. Its unique success is due to its simple and scalable design, and its reliable integrated manufacturing process via the ICP. In addition, magnetic, piezoelectric, shape memory, pneumatic, and hydraulic principles have been explored for micro actuation, each of which have its own limits of integration, process complexity, and applicability. Also, over the past few years, living cells, such as cardio myocytes, muscle cells, and whole dorsal vessels, have been combined with technical systems and have resulted in new types of bio micro actuators. However, most of them problematically require an aqueous environment and only have a limited lifetime.

There potential applications of micro actuators are wide-ranging and include inertial sensors, optical MEMS and lab-on-a-chip, manipulators, micro robots, and micro surgery. Each domain has its typical requirements in terms of forces, displacements, materials, frequencies, voltage vs. current control, etc.

For this Special Issue, we encourage reviews on actuation mechanism classes and classes of application. We also encourage the submission of regular papers on new actuators.

Prof. Dr. Ulrike Wallrabe
Guest Editor

Manuscript Submission Information

Manuscripts should be submitted online at www.mdpi.com by registering and logging in to this website. Once you are registered, click here to go to the submission form. Manuscripts can be submitted until the deadline. All submissions that pass pre-check are peer-reviewed. Accepted papers will be published continuously in the journal (as soon as accepted) and will be listed together on the special issue website. Research articles, review articles as well as short communications are invited. For planned papers, a title and short abstract (about 100 words) can be sent to the Editorial Office for announcement on this website.

Submitted manuscripts should not have been published previously, nor be under consideration for publication elsewhere (except conference proceedings papers). All manuscripts are thoroughly refereed through a single-blind peer-review process. A guide for authors and other relevant information for submission of manuscripts is available on the Instructions for Authors page. Micromachines is an international peer-reviewed open access monthly journal published by MDPI.

Please visit the Instructions for Authors page before submitting a manuscript. The Article Processing Charge (APC) for publication in this open access journal is 2600 CHF (Swiss Francs). Submitted papers should be well formatted and use good English. Authors may use MDPI's English editing service prior to publication or during author revisions.

Keywords

  • micro actuator
  • nano actuator
  • electrostatic magnetic
  • piezo electric
  • shape memory
  • electro wetting
  • cells
  • pumps
  • switches
  • optical MEMS
  • micro robots
  • grippers
  • endoscopes
  • micro surgery

Benefits of Publishing in a Special Issue

  • Ease of navigation: Grouping papers by topic helps scholars navigate broad scope journals more efficiently.
  • Greater discoverability: Special Issues support the reach and impact of scientific research. Articles in Special Issues are more discoverable and cited more frequently.
  • Expansion of research network: Special Issues facilitate connections among authors, fostering scientific collaborations.
  • External promotion: Articles in Special Issues are often promoted through the journal's social media, increasing their visibility.
  • e-Book format: Special Issues with more than 10 articles can be published as dedicated e-books, ensuring wide and rapid dissemination.

Further information on MDPI's Special Issue polices can be found here.

Published Papers (6 papers)
