Sensors

Research

20 pages, 6895 KiB

Open AccessArticle

An Online Digital Imaging Excitation Sensor for Wind Turbine Gearbox Wear Condition Monitoring Based on Adaptive Deep Learning Method

by Hui Tao, Yong Zhong, Guo Yang and Wei Feng

Sensors 2024, 24(8), 2481; https://doi.org/10.3390/s24082481 - 12 Apr 2024

Viewed by 459

Abstract

This paper designed and developed an online digital imaging excitation sensor for wind power gearbox wear condition monitoring based on an adaptive deep learning method. A digital imaging excitation sensing image information collection architecture for magnetic particles in lubricating oil was established to [...] Read more.

This paper designed and developed an online digital imaging excitation sensor for wind power gearbox wear condition monitoring based on an adaptive deep learning method. A digital imaging excitation sensing image information collection architecture for magnetic particles in lubricating oil was established to characterize the wear condition of mechanical equipment, achieving the real-time online collection of wear particles in lubricating oil. On this basis, a mechanical equipment wear condition diagnosis method based on online wear particle images is proposed, obtaining data from an engineering test platform based on a wind power gearbox. Firstly, a foreground segmentation preprocessing method based on the U-Net network can effectively eliminate the interference of bubbles and dark fields in online wear particle images, providing high-quality segmentation results for subsequent image processing, A total of 1960 wear particle images were collected in the experiment, the average intersection union ratio of the validation set is 0.9299, and the accuracy of the validation set is 0.9799. Secondly, based on the foreground segmentation preprocessing of wear particle images, by using the watered algorithm to obtain the number of particles in each size segment, we obtained the number of magnetic particle grades in three different ranges: 4–38 µm, 39–70 µm, and >70 µm. Thirdly, we proposed a method named multidimensional transformer (MTF) network. Mean Square Error (MSE), Root Mean Square Error (RMSE), and Mean Absolute Error (MAE) are used to obtain the error, and the maintenance strategy is formulated according to the predicted trend. The experimental results show that the predictive performance of our proposed model is better than that of LSTM and TCN. Finally, the online real-time monitoring system triggered three alarms, and at the same time, our offline sampling data analysis was conducted, the accuracy of online real-time monitoring alarms was verified, and the gearbox of the wind turbine was shut down for maintenance and repair. Full article

(This article belongs to the Special Issue Advances in Sensor Technology and Applications for Fault Diagnosis: Design, Architecture, and Approaches)

► Show Figures

Figure 1

12 pages, 345 KiB

Open AccessArticle

Centrifugal Pump Fault Detection with Convolutional Neural Network Transfer Learning

by Cem Ekin Sunal, Vladan Velisavljevic, Vladimir Dyo, Barry Newton and Jake Newton

Sensors 2024, 24(8), 2442; https://doi.org/10.3390/s24082442 - 11 Apr 2024

Viewed by 571

Abstract

The centrifugal pump is the workhorse of many industrial and domestic applications, such as water supply, wastewater treatment and heating. While modern pumps are reliable, their unexpected failures may jeopardise safety or lead to significant financial losses. Consequently, there is a strong demand [...] Read more.

The centrifugal pump is the workhorse of many industrial and domestic applications, such as water supply, wastewater treatment and heating. While modern pumps are reliable, their unexpected failures may jeopardise safety or lead to significant financial losses. Consequently, there is a strong demand for early fault diagnosis, detection and predictive monitoring systems. Most prior work on machine learning-based centrifugal pump fault detection is based on either synthetic data, simulations or data from test rigs in controlled laboratory conditions. In this research, we attempted to detect centrifugal pump faults using data collected from real operational pumps deployed in various places in collaboration with a specialist pump engineering company. The detection was done by the binary classification of visual features of DQ/Concordia patterns with residual networks. Besides using a real dataset, this study employed transfer learning from the image detection domain to systematically solve a real-life problem in the engineering domain. By feeding DQ image data into a popular and high-performance residual network (e.g., ResNet-34), the proposed approach achieved up to 85.51% classification accuracy. Full article

(This article belongs to the Special Issue Advances in Sensor Technology and Applications for Fault Diagnosis: Design, Architecture, and Approaches)

► Show Figures

Figure 1

20 pages, 4077 KiB

Open AccessArticle

Remaining Useful Life Estimation of MoSi₂ Heating Element in a Pusher Kiln Process

by Hafiz M. Irfan, Po-Hsuan Liao, Muhammad Ikhsan Taipabu and Wei Wu

Sensors 2024, 24(5), 1486; https://doi.org/10.3390/s24051486 - 24 Feb 2024

Viewed by 1121

Abstract

The critical challenge of estimating the Remaining Useful Life (RUL) of MoSi2 heating elements utilized in pusher kiln processes is to enhance operational efficiency and minimize downtime in industrial applications. MoSi2 heating elements are integral components in high-temperature environments, playing a pivotal role [...] Read more.

The critical challenge of estimating the Remaining Useful Life (RUL) of MoSi2 heating elements utilized in pusher kiln processes is to enhance operational efficiency and minimize downtime in industrial applications. MoSi2 heating elements are integral components in high-temperature environments, playing a pivotal role in achieving optimal thermal performance. However, prolonged exposure to extreme conditions leads to degradation, necessitating precise RUL predictions for proactive maintenance strategies. Since insufficient failure experience deals with Predictive Maintenance (PdM) in real-life scenarios, a Generative Adversarial Network (GAN) generates specific training data as failure experiences. The Remaining Useful Life (RUL) is the duration of the equipment’s operation before repair or replacement, often measured in days, miles, or cycles. Machine learning models are trained using historical data encompassing various operational scenarios and degradation patterns. The RUL prediction model is determined through training, hyperparameter tuning, and comparisons based on the machine-learning model, such as Long Short-Term Memory (LSTM) or Support Vector Regression (SVR). As a result, SVR reflects the actual resistance variation, achieving the R-Square (R²) of 0.634, better than LSTM. From a safety perspective, SVR offers high prediction accuracy and sufficient time to schedule maintenance plans. Full article

(This article belongs to the Special Issue Advances in Sensor Technology and Applications for Fault Diagnosis: Design, Architecture, and Approaches)

► Show Figures

Figure 1

17 pages, 11061 KiB

Open AccessArticle

Lightweight Transmission Line Fault Detection Method Based on Leaner YOLOv7-Tiny

by Qingyan Wang, Zhen Zhang, Qingguo Chen, Junping Zhang and Shouqiang Kang

Sensors 2024, 24(2), 565; https://doi.org/10.3390/s24020565 - 16 Jan 2024

Cited by 1 | Viewed by 742

Abstract

Aiming to address the issues of parameter complexity and high computational load in existing fault detection algorithms for transmission lines, which hinder their deployment on devices like drones, this study proposes a novel lightweight model called Leaner YOLOv7-Tiny. The primary goal is to [...] Read more.

Aiming to address the issues of parameter complexity and high computational load in existing fault detection algorithms for transmission lines, which hinder their deployment on devices like drones, this study proposes a novel lightweight model called Leaner YOLOv7-Tiny. The primary goal is to swiftly and accurately detect typical faults in transmission lines from aerial images. This algorithm inherits the ELAN structure from YOLOv7-Tiny network and replaces its backbone with depthwise separable convolutions to reduce model parameters. By integrating the SP attention mechanism, it fuses multi-scale information, capturing features across various scales to enhance small target recognition. Finally, an improved FCIoU Loss function is introduced to balance the contribution of high-quality and low-quality samples to the loss function, expediting model convergence and boosting detection accuracy. Experimental results demonstrate a 20% reduction in model size compared to the original YOLOv7-Tiny algorithm. Detection accuracy for small targets surpasses that of current mainstream lightweight object detection algorithms. This approach holds practical significance for transmission line fault detection. Full article

(This article belongs to the Special Issue Advances in Sensor Technology and Applications for Fault Diagnosis: Design, Architecture, and Approaches)

► Show Figures

Figure 1

20 pages, 14767 KiB

Open AccessArticle

Enhancing Feature Detection and Matching in Low-Pixel-Resolution Hyperspectral Images Using 3D Convolution-Based Siamese Networks

by Chamika Janith Perera, Chinthaka Premachandra and Hiroharu Kawanaka

Sensors 2023, 23(18), 8004; https://doi.org/10.3390/s23188004 - 21 Sep 2023

Cited by 1 | Viewed by 2084

Abstract

Today, hyperspectral imaging plays an integral part in the remote sensing and precision agriculture field. Identifying the matching key points between hyperspectral images is an important step in tasks such as image registration, localization, object recognition, and object tracking. Low-pixel resolution hyperspectral imaging [...] Read more.

Today, hyperspectral imaging plays an integral part in the remote sensing and precision agriculture field. Identifying the matching key points between hyperspectral images is an important step in tasks such as image registration, localization, object recognition, and object tracking. Low-pixel resolution hyperspectral imaging is a recent introduction to the field, bringing benefits such as lower cost and form factor compared to traditional systems. However, the use of limited pixel resolution challenges even state-of-the-art feature detection and matching methods, leading to difficulties in generating robust feature matches for images with repeated textures, low textures, low sharpness, and low contrast. Moreover, the use of narrower optics in these cameras adds to the challenges during the feature-matching stage, particularly for images captured during low-altitude flight missions. In order to enhance the robustness of feature detection and matching in low pixel resolution images, in this study we propose a novel approach utilizing 3D Convolution-based Siamese networks. Compared to state-of-the-art methods, this approach takes advantage of all the spectral information available in hyperspectral imaging in order to filter out incorrect matches and produce a robust set of matches. The proposed method initially generates feature matches through a combination of Phase Stretch Transformation-based edge detection and SIFT features. Subsequently, a 3D Convolution-based Siamese network is utilized to filter out inaccurate matches, producing a highly accurate set of feature matches. Evaluation of the proposed method demonstrates its superiority over state-of-the-art approaches in cases where they fail to produce feature matches. Additionally, it competes effectively with the other evaluated methods when generating feature matches in low-pixel resolution hyperspectral images. This research contributes to the advancement of low pixel resolution hyperspectral imaging techniques, and we believe it can specifically aid in mosaic generation of low pixel resolution hyperspectral images. Full article

(This article belongs to the Special Issue Advances in Sensor Technology and Applications for Fault Diagnosis: Design, Architecture, and Approaches)

► Show Figures

Figure 1

16 pages, 5168 KiB

Open AccessArticle

A Sensor-Fault-Estimation Method for Lithium-Ion Batteries in Electric Vehicles

by Tianyu Lan, Zhi-Wei Gao, Haishuang Yin and Yuanhong Liu

Sensors 2023, 23(18), 7737; https://doi.org/10.3390/s23187737 - 7 Sep 2023

Cited by 1 | Viewed by 1136

Abstract

In recent years, electric vehicles powered by lithium-ion batteries have developed rapidly, and the safety and reliability of lithium-ion batteries have been a paramount issue. Battery management systems are highly dependent on sensor measurements to ensure the proper functioning of lithium-ion batteries. Therefore, [...] Read more.

In recent years, electric vehicles powered by lithium-ion batteries have developed rapidly, and the safety and reliability of lithium-ion batteries have been a paramount issue. Battery management systems are highly dependent on sensor measurements to ensure the proper functioning of lithium-ion batteries. Therefore, it is imperative to develop a suitable fault diagnosis scheme for battery sensors, to realize a diagnosis at an early stage. The main objective of this paper is to establish validated electrical and thermal models for batteries, and address a model-based fault diagnosis scheme for battery sensors. Descriptor proportional and derivate observer systems are applied for sensor diagnosis, based on electrical and thermal models of lithium-ion batteries, which can realize the real-time estimation of voltage sensor fault, current sensor fault, and temperature sensor fault. To verify the estimation effect of the proposed scheme, various types of faults are utilized for simulation experiments. Battery experimental data are used for battery modeling and observer-based fault diagnosis in battery sensors. Full article

(This article belongs to the Special Issue Advances in Sensor Technology and Applications for Fault Diagnosis: Design, Architecture, and Approaches)

► Show Figures

Figure 1

19 pages, 3500 KiB

Open AccessArticle

A Novel Cross-Sensor Transfer Diagnosis Method with Local Attention Mechanism: Applied in a Reciprocating Pump

by Chen Wang, Ling Chen, Yongfa Zhang, Liming Zhang and Tian Tan

Sensors 2023, 23(17), 7432; https://doi.org/10.3390/s23177432 - 25 Aug 2023

Viewed by 742

Abstract

Data-driven mechanical fault diagnosis has been successfully developed in recent years, and the task of training and testing data from the same distribution has been well-solved. However, for some large machines with complex mechanical structures, such as reciprocating pumps, it is often not [...] Read more.

Data-driven mechanical fault diagnosis has been successfully developed in recent years, and the task of training and testing data from the same distribution has been well-solved. However, for some large machines with complex mechanical structures, such as reciprocating pumps, it is often not possible to obtain data from specific sensor locations. When the sensor position is changed, the distribution of the features of the signal data also changes and the fault diagnosis problem becomes more complicated. In this paper, a cross-sensor transfer diagnosis method is proposed, which utilizes the sharing of information collected by sensors between different locations of the machine to complete a more accurate and comprehensive fault diagnosis. To enhance the model’s perception ability towards the critical part of the fault signal, the local attention mechanism is embedded into the proposed method. Finally, the proposed method is validated by applying it to experimentally acquired vibration signal data of reciprocating pumps. Excellent performance is demonstrated in terms of fault diagnosis accuracy and sensor generalization capability. The transferability of practical industrial faults among different sensors is confirmed. Full article

(This article belongs to the Special Issue Advances in Sensor Technology and Applications for Fault Diagnosis: Design, Architecture, and Approaches)

► Show Figures

Figure 1

18 pages, 3952 KiB

Open AccessArticle

Research on the Influence of Geometric Structure Parameters of Eddy Current Testing Probe on Sensor Resolution

by Mengmeng Song, Mengwei Li, Shungen Xiao and Jihua Ren

Sensors 2023, 23(14), 6610; https://doi.org/10.3390/s23146610 - 22 Jul 2023

Cited by 3 | Viewed by 966

Abstract

To study the influence of the geometric structure of the probe coil on the electromagnetic characteristics of the eddy current probe in the process of eddy current testing, based on the principle of eddy current testing, different probe coil models were established using [...] Read more.

To study the influence of the geometric structure of the probe coil on the electromagnetic characteristics of the eddy current probe in the process of eddy current testing, based on the principle of eddy current testing, different probe coil models were established using finite element software. These geometric structure parameters include the difference between the inner and outer radius, thickness, and equivalent radius. The magnetic field distribution around the probe is simulated and analyzed under different parameters, and the detection performance of the probe is judged in combination with the change rate of the magnetic field around the probe coil. The simulation results show that at a closer position, increasing the difference between the inner and outer radii, reducing the thickness, and reducing the equivalent radius are beneficial to improve the resolution of the probe coil. At a far position, reducing the difference between the inner and outer radii, increasing the thickness, and reducing the equivalent radius are beneficial to improve the resolution of the probe coil. At the same time, the accuracy of the simulation data is verified by comparing the theoretical values with the simulated values under different conditions. Therefore, the obtained conclusions can provide a reference and basis for the optimal design of the probe structure. Full article

(This article belongs to the Special Issue Advances in Sensor Technology and Applications for Fault Diagnosis: Design, Architecture, and Approaches)

► Show Figures

Figure 1
