Special Issue Information

Dear Colleagues,

Microelectromechanical systems (MEMS) are microstructures able to couple the mechanical and electrical energy domains at micro- or nanoscales, often involving other energy domains in these interactions. Their micrometre-scale dimensions generate both specific advantages (e.g., electromechanical feedback control, fast time response and better efficiency for some specific sensing mechanisms) and challenges (e.g., lower energy generation yield for thermal micromachines), leading to rethinking the design and analysis methods for customized macroengineering at microscale solutions. Technological advances in MEMS initially took advantage of the existing microelectronics industry, and have gradually spurred specific microfabrication methods, traversing beyond silicon. In this context, an increasing amount of research and applications has emerged for MEMS transducers.

This Special Issue aims to encompass high-quality research contributions focusing on the advances in MEMS sensors. Topics to be covered include (but are not limited to):

Suitable mechanisms for enhanced sensing in microsystems: weakly coupled resonators, stochastic resonance, parametric amplification, operation on the stability border, etc.;
Modern techniques for interfacing transducers to electronic systems for advanced signal processing and data fusion (sigma-delta, sliding mode control, etc.), including hybrid integration techniques between MEMS devices and electronic subsystems;
Modern trends, e.g., polymer CMUT transducer arrays for ultrasound imaging (from Si to alternative technologies);
Sensor arrays and sensor networks, including data fusion aspects;
The stimulating coupling between clusters of MEMS sensors and present advances in intelligent signal processing, including machine learning aspects integrated with high-performance sensing.
