Soil temperature (ST) plays an important role in the surface heat energy balance, and an accurate description of soil temperatures is critical for numerical weather prediction; however, it is difficult to consistently measure soil temperatures. We developed a U-Net-based deep learning model to derive soil temperatures (designated as ST-U-Net) primarily based on 2 m air temperature (T2) forecasts. The model, the domain of which covers the Mt. Lushan region, was trained and tested by utilizing the high-resolution forecast archive of an operational weather research and forecasting four-dimensional data assimilation (WRF-FDDA) system. The results showed that ST-U-Net can accurately estimate soil temperatures based on T2 inputs, achieving a mean absolute error (MAE) of less than 0.8 K on the testing set of 5055 samples. The performance of ST-U-Net varied diurnally, with smaller errors at night and slightly larger errors in the daytime. Incorporating additional inputs such as land uses, terrain height, radiation flux, surface heat flux, and coded time further reduced the MAE for ST by 26.7%. By developing a boundary-layer physics-guided training strategy, the error was further reduced by 8.8%. Full article

This article deals with the calibration method of analog integrated circuits (ICs) designed in CMOS nanotechnology. A brief analysis of various methods and techniques (e.g., fuse trimming, chopper stabilization, auto-zero technique, etc.) for calibration of a specific IC’s parameter is given, leading to motivation for this research that is focused on the digital calibration. Then, the principle and overall design of the calibration subcircuit, which was generally used to calibrate the input offset voltage $V_{IN\_OFF}$ of the operational amplifier (OPAMP). The essence of this work is verification of the proposed digital calibration algorithm for minimization the $V_{IN\_OFF}$ of a bulk-driven fully differential difference amplifier (FDDA) with the power supply voltage $V_{DD}$ = 0.4 V. Evaluation of ASIC prototyped chip samples with silicon-proved results has been done. This evaluation contains comparison of selected parameters and characteristics obtained from both simulations and measurements of non-calibrated and calibrated FDDA configurations. Full article

High-impact weather affects the safety and economic operation of power systems. In this study, to provide regional microclimate of high-impact weather for the local power grid system in the northern Heibei province (known as the Jibei region in China), ERA5-Land global reanalysis data during 1981–2020 with a 0.1° grid size (about 9 km) are adopted to analyze the climate statistics and changes of the disastrous weather that affects the power grids. The results show that there have been significant climate changes in the region, including a temperature increase of about 1 °C, evident humidity and precipitation reductions, for the Jibei region and the six sub-regions that concentrated with wind and solar energy development in the 40 years. Due to the differences in terrain, the climate changes differ significantly among the six renewable energy development regions. The main types of high-impact weather that affect the power grid in the region are heavy fog and icing events, followed by cold waves, snowstorms, and rainstorms. In general, with climate changes in the last several decades, the weather disasters in Jibei region have become more frequent. Since most high-impact weather events have a small scale, it is necessary to simulate the weather processes with high-resolution models to accurately quantify the characteristics of the weather processes that affect the power grid. Therefore, a refined regional meteorological model (with grid size of 2 km) based on four-dimensional data assimilation (JB-FDDA) is established for the Jibei region. With one year of model reanalysis data, we found that JB-FDDA can significantly improve the accuracy of the local meteorological fields, and properly depicted the details of severe weather that affect the power grid operation. This study provide an analytical approach for regional electricity meteorological disasters by using reanalysis data. Full article

With its special, arch-shaped array structure, a frequency diverse arc array (FDAA) can perform beam scanning in 360 degrees in azimuth and in arbitrary ranges by selectively activating array elements in different positions, utilizing array element phase compensation, and adopting a frequency offset design. In this paper, a beampattern synthesis and optimization method for FDDA using the virtual array element based on the geometric configuration of FDDA is proposed. First, the position of the virtual array element is determined by the direction of the target, and then activated array elements are selected. Afterwards, the frequency offset of each array element is set up on the equiphase surface to obtain the dot-shaped beampattern. Finally, amplitude weighting is introduced to suppress the increased sidelobe level of the dot-shaped beampattern, which is caused by inverse density weighting of the arch-shaped array structure. Simulation results validate the proposed method for beampattern synthesis and optimization in FDAA. Full article

This paper presents a novel analog front-end for EMG sensor signal processing powered by 1 V. Such a low supply voltage requires specific design steps enabled using the 28 nm fully depleted silicon on insulator (FDSOI) technology from STMicroelectronics. An active ground circuit is implemented to keep the input common-mode voltage close to the analog ground and to minimize external interference. The amplifier circuit comprises an input instrumentation amplifier (INA) and a programmable-gain amplifier (PGA). Both are implemented in a fully differential topology. The actual performance of the circuit is analyzed using the corner and Monte Carlo analyses that comprise fifth-hundred samples for the global and local process variations. The proposed circuit achieves a high common-mode rejection ratio (CMRR) of 105.5 dB and a high input impedance of 11 G$\mathrm{\Omega }$ with a chip area of 0.09 mm${}^2$. Full article

The Four-Dimensional Data Assimilation module (FDDA) is used in combination with the WRF model for the analysis of two case studies of high tide (on 4 April 2019 and on 12 November 2019) that affected the Venice Lagoon in the recent past. The system is implemented in the perspective of an operational use for nowcasting of 10 m wind, which will be part of a numerical system aimed at the forecast of the sea level height in the Venice Lagoon. The procedure involves the assimilation of data from meteorological surface stations distributed within the Venice Lagoon and in the open northern Adriatic Sea in front of the lagoon, as well asthe radiosonde profiles available within the simulation domain. The two cases were selected considering that the real-time forecasts missed their evolution, and the sea level height was significantly underpredicted. The comparison of the simulated wind with the observations shows a fairly good agreement over short time scales (1–2 h) in both cases; hence, the WRF-FDDA system represents a promising tool and a possibly valuable support to the decision makers in case of high tide in the Venice Lagoon. Full article

During the autumn season, Sicily is often affected by severe weather events, such as self-healing storms called V-shaped storms. These phenomena cause significant total rainfall quantities in short time intervals in localized spatial areas. In this framework, this study analyzes the meteorological event recorded on 11–12 November 2019 in Sicily (southern Italy), using the Weather Research and Forecasting (WRF) model with a horizontal spatial grid resolution of 3 km. It is important to note that, in this event, the most significant rainfall accumulations were recorded in eastern Sicily. In particular, the weather station of Linguaglossa North Etna (Catania) recorded a total rainfall of 293.6 mm. The precipitation forecasting provided by the WRF model simulation has been compared with the data recorded by the meteorological stations located in Sicily. In addition, a further simulation was carried out using the Four-Dimensional Data Assimilation (FDDA) technique to improve the model capability in the event reproduction. In this regard, in order to evaluate which approach provides the best performance (with or without FDDA), the Root Mean Square Error (RMSE) and dichotomous indexes (Accuracy, Threat Score, BIAS, Probability of Detection, and False Alarm Rate) were calculated. Full article

This work evaluates and compares the performance of the radar reflectivity and lightning data assimilation schemes implemented in weather research and forecasting-four-dimensional data assimilation (WRF-FDDA) for short-term precipitation and lightning forecasts. All six mesoscale convective systems (MCSs) with a duration greater than seven hours that occurred in the Guangdong Province of China during June 2020 were included in the experiments. The results show that both the radar reflectivity data assimilation and lightning data assimilation improved the analyses and short-term forecasts of the precipitation and lightning of the MCSs. On average, for precipitation forecasts, the experiments with radar reflectivity data assimilation performed better than those with lightning data assimilation; however, for lightning forecasts, the experiments with lightning data assimilation performed better in the analysis period and 1 h forecast, and for some cases, the superiority lasted to three forecast hours. This highlights the potential of lightning data assimilation in short-term lightning forecasting. Full article

This paper presents a low-noise potentiostat readout circuit with a chopper fully differential difference amplifier (FDDA) for glucose monitoring. Glucose monitoring is necessary for the early diagnosis of diabetes complications and for health management. Ammeter electrochemical sensors are widely used for glucose detection, and in general, a three-electrode structure of a reference electrode (RE), a counter electrode (CE), and a working electrode (WE) is implemented with a potentiostat structure. A low-noise characteristic of the readout circuit is essential for highly accurate glucose monitoring. The chopping technique can reduce low-frequency noises such as 1/f noise and can achieve the required low-noise characteristic. The proposed potentiostat readout circuit is based on a low-noise chopper FDDA with a class-AB output stage. The implementation of the chopper FDDA scheme of the potentiostat readout circuit can decrease the number of amplifiers in the control part of the potentiostat, with reduced power consumption and a wide dynamic output range. The negative feedback loop of the inverting amplifier scheme with the FDDA maintains the voltage between the WE and RE constants. The negative feedback loop tracks the reference voltage of the RE with an input voltage of the WE. The proposed potentiostat readout circuit is designed in the standard 0.18 µm CMOS process, and the simulated current consumption is 48.54 μA with a 1.8 V power supply. The simulated input-referred noise level was 8.53 pArms. Full article

The Fengyun-4A (FY-4A) geostationary satellite carries the Lightning Mapping Imager that measures total lightning rate of convective systems from space at high spatial and temporal resolutions. In this study, the performance of FY-4A lightning data assimilation (LDA) on the forecast of non-typhoon oceanic mesoscale convective systems (MCSs) is investigated by using an LDA method implemented in the Weather Research and Forecasting-Four Dimensional Data Assimilation (WRF-FDDA). With the LDA scheme, three-dimensional graupel mixing ratio fields retrieved from the FY-4A lightning data and the corresponding latent heating rates are assimilated into the Weather Research and Forecasting model via nudging terms. Two oceanic MCS cases over the South China Sea were selected to perform the study. The subjective evaluation results demonstrate that most of the oceanic convective cells missed by the control experiments are recovered in the analysis period by assimilating FY-4A lightning data, due to the promoted updrafts by latent-heat nudging, the more accurate and faster simulations of the cold pools, and the associated gust-fronts at the observed lightning locations. The cold pools and gust-fronts generated during the analysis period helped to maintain the development of the MCSs, and reduced the morphology and displacement errors of the simulations in the short-term forecast periods. The quantitative evaluation indicates that the most effective periods of the LDA for simulation enhancement were at the analysis time and the nowcasting (0–2 h forecast) periods. Full article

In the remote sensing image processing field, the synthetic aperture radar (SAR) target-detection methods based on convolutional neural networks (CNNs) have gained remarkable performance relying on large-scale labeled data. However, it is hard to obtain many labeled SAR images. Semi-supervised learning is an effective way to address the issue of limited labels on SAR images because it uses unlabeled data. In this paper, we propose an improved faster regions with CNN features (R-CNN) method, with a decoding module and a domain-adaptation module called FDDA, for semi-supervised SAR target detection. In FDDA, the decoding module is adopted to reconstruct all the labeled and unlabeled samples. In this way, a large number of unlabeled SAR images can be utilized to help structure the latent space and learn the representative features of the SAR images, devoting attention to performance promotion. Moreover, the domain-adaptation module is further introduced to utilize the unlabeled SAR images to promote the discriminability of features with the assistance of the abundantly labeled optical remote sensing (ORS) images. Specifically, the transferable features between the ORS images and SAR images are learned to reduce the domain discrepancy via the mean embedding matching, and the knowledge of ORS images is transferred to the SAR images for target detection. Ultimately, the joint optimization of the detection loss, reconstruction, and domain adaptation constraints leads to the promising performance of the FDDA. The experimental results on the measured SAR image datasets and the ORS images dataset indicate that our method achieves superior SAR target detection performance with limited labeled SAR images. Full article

Radar data are essential to convection nowcasting and nudging-based radar data assimilation through diabatic initialization is one of the most effective approaches for forecasting convective systems with numerical weather prediction (NWP) models, used at several advanced global weather centers. It is desired to assess the uncertainty and physical consistency of this assimilation process. This paper investigated impacts of relaxation coefficient, radar data update intervals and continuous assimilation time duration and addressed the key issues and possible solutions of the radar data assimilation based on the WRF hydrometeor and latent heat nudging (HLHN) developed at the National Center for Atmospheric Research (NCAR). It is revealed that excessively large relaxation coefficient forced the model to observations with a tendency greater than the physical terms of the convection, causing the dynamic imbalances and serious convection “ramp-down” right after the free forecast starts. Assimilating high update frequency radar data can make the tendency terms moderate and sustained thereby maintaining the assimilation effect and reducing fortuitous convection. HLHN requires a minimum continuous assimilation duration to contain the initial forced disturbance of the model. For a summer Meiyu precipitation case studied, the minimum duration is ~1 h. Appropriate selection of the HLHN parameters is able to effectively improve the temperature, humidity, and dynamic fields of the model. In addition, several issues still remain to be solved to further enhance HLHN. Full article

This paper presents the development of the global to mesoscale air quality forecast and analysis system (GMAF) and its application to particulate matter under 2.5 μm (PM_2.5) forecast in Korea. The GMAF combined a mesoscale model with a global data assimilation system by the grid nudging based four-dimensional data assimilation (FDDA). The grid nudging based FDDA developed for weather forecast and analysis was extended to air quality forecast and analysis for the first time as an alternative to data assimilation of surface monitoring data. The below cloud scavenging module and the secondary organic formation module of the community multiscale air quality model (CMAQ) were modified and subsequently verified by comparing with the PM speciation observation from the PM supersite. The observation data collected from the criteria air pollutant monitoring networks in Korea were used to evaluate forecast performance of GMAF for the year of 2016. The GMAF showed good performance in forecasting the daily mean PM_2.5 concentrations at Seoul; the correlation coefficient between the observed and forecasted PM_2.5 concentrations was 0.78; the normalized mean error was 25%; the probability of detection for the events exceeding the national PM_2.5 standard was 0.81 whereas the false alarm rate was only 0.38. Both the hybrid bias correction technique and the Kalman filter bias adjustment technique were implemented into the GMAF as postprocessors. For the continuous and the categorical performance metrics examined, the Kalman filter bias adjustment technique performed better than the hybrid bias correction technique. Full article

A novel fully differential difference CMOS potentiostat suitable for neurotransmitter sensing is presented. The described architecture relies on a fully differential difference amplifier (FDDA) circuit to detect a wide range of reduction-oxidation currents, while exhibiting low-power consumption and low-noise operation. This is made possible thanks to the fully differential feature of the FDDA, which allows to increase the source voltage swing without the need for additional dedicated circuitry. The FDDA also reduces the number of amplifiers and passive elements in the potentiostat design, which lowers the overall power consumption and noise. The proposed potentiostat was fabricated in 0.18 µm CMOS, with 1.8 V supply voltage. The device achieved 5 µA sensitivity and 0.99 linearity. The input-referred noise was 6.9 µV ${}_{\mathrm{rms}}$ and the flicker noise was negligible. The total power consumption was under 55 µW. The complete system was assembled on a 20 mm × 20 mm platform that includes the potentiostat chip, the electrode terminals and an instrumentation amplifier for redox current buffering, once converted to a voltage by a series resistor. the chip dimensions were 1 mm × 0.5 mm and the other PCB components were off-chip resistors, capacitors and amplifiers for data acquisition. The system was successfully tested with ferricyanide, a stable electroactive compound, and validated with dopamine, a popular neurotransmitter. Full article
