In this paper, a MgO-based high-temperature Fabry-Perot (F-P) vibration sensor with a fiber-optic collimator is proposed and experimentally demonstrated at 1000 °C. The sensor is composed of a sensing unit and a fiber-optic collimator. The F-P cavity is formed by the upper surface of the inertial mass block and the countersunk hole of the cover layer. The length of the F-P cavity changes with external vibrations. The sensing unit is prepared by wet etching technology and three-layer direct bonding technology, which ensure its stability and reliability in high-temperature environments. The experimental results indicate that the sensor can operate stably within a range from room temperature up to 1000 °C. The sensitivity and non-linearity of the sensor at 1000 °C are 1.3224 nm/g and 3.8%, respectively. Furthermore, the sensor operates at frequencies of up to 4 kHz while remaining unaffected by lateral vibration signals. The high-temperature F-P vibration sensor can effectively deal with the fiber damage in extreme environments and exhibits considerable potential for widespread applications. Full article

Fiber-optic Fabry–Pérot (F–P) sensors offer significant potential for non-invasive hemodynamic monitoring, but existing sensing systems face limitations in multi-channel measurement capabilities and dynamic demodulation accuracy. This study introduces a sparse-frequency-scanning white-light interferometry (SFS-WLI) system with an adaptive mode-locked cross-correlation (MLCC) algorithm to address these challenges. The system leverages telecom-grade semiconductor lasers (191.2–196.15 THz sweep range, 50 GHz step) and a Fibonacci-optimized MLCC algorithm to achieve real-time cavity length demodulation at 5 kHz. Compared to normal MLCC algorithm, the Fibonacci-optimized algorithm reduces the number of computational iterations by 57 times while maintaining sub-nanometer resolution under dynamic perturbations. Experimental validation demonstrated a carotid–radial pulse wave velocity of 5.12 m/s in a healthy male volunteer. This work provides a scalable and cost-effective solution for cardiovascular monitoring with potential applications in point-of-care testing (POCT) and telemedicine. Full article

To meet the pressure measurement requirements of deep earth exploration, we propose an OFPS (optical fiber pressure sensor) with self-temperature compensation based on MEMS technology. A spectral extraction and filtering algorithm, based on FFT (fast Fourier transform), was designed to independently demodulate the composite spectra of multiple FP (Fabry–Pérot) cavities, enabling the simultaneous measurement of pressure and temperature parameters. The sensor was fabricated by etching on an SOI (silicon on insulator) and bonding with glass to form pressure-sensitive FP cavities, with the glass itself serving as the temperature-sensitive component as well as providing temperature compensation for pressure sensing. Experimental results showed that within the pressure range of 0–100 MPa, the sensor exhibited a sensitivity of 0.566 nm/MPa, with a full-scale error of 0.34%, and a linear fitting coefficient (R²) greater than 0.9999. Within the temperature range of 0–160 °C, the temperature sensitivity of the glass cavity is 0.0139 nm/°C and R² greater than 0.999. Full article

A parallel Fabry–Perot interferometer (FPI) optical fiber sensor, enhanced with UV glue, was proposed for environmental temperature detection. The UV glue is applied to the fiber’s sensing region using a coating method, forming an FP cavity through misalignment welding, allowing the FP to function as a temperature sensor. In parallel, a reference FPI with a similar free spectral range (FSR) is connected, generating a Vernier effect that amplifies small changes in the refractive index (RI) of the sensing region. The study demonstrates that UV glue enhances the temperature-sensing capabilities of the FP, and when combined with the Vernier effect, it significantly improves the sensitivity of a single interferometric sensor. The temperature sensitivity of the parallel-connected FPI is −2.80219 nm/°C, which is 7.768 times greater than that of a single FPI (−0.36075 nm/°C). The sensor shows high sensitivity, stability, and reversibility, making it promising for temperature-monitoring applications in various fields, including everyday use, industrial production, and the advancement of optical fiber temperature-sensing technologies. Full article

This study presents the liquid crystal Fabry–Pérot etalon (LC-FP) as the preferred laser wavelength tuning solution within a erbium-doped fiber ring laser architecture. The laser cavity wavelength can be adjusted by applying varying voltages to the LC-FP. Furthermore, tuning the laser wavelength can be facilitated by modifying the incident light through changes in the steering angle of the LC-FP, which is attributed to the angular dispersion characteristics of the device. The operational range for the steering angle of the LC-FP is ± 4 to 18 degrees. This architectural framework is adept at facilitating the generation of single-wavelength and dual-wavelength lasers within the C band. The tunable range for a single wavelength is approximately 13 nm, while the tunable range for dual wavelengths is around 14 nm, with a wavelength spacing of approximately 17.5 nm. These capabilities are primarily influenced by the operational wavelength of the erbium-doped fiber amplifier (EDFA), the operating wavelength of the collimator that directs the fiber optic beam into the LC-FP, and the fixed thickness of the LC-FP. Full article

This study presents a novel reflective fiber Fabry–Perot (F–P) salinity sensor. The sensor employs a femtosecond laser to fabricate an open liquid cavity, facilitating the unobstructed ingress and egress of the liquid, thereby enabling the direct involvement of the liquid in light transmission. Variations in the refractive index of the liquid induce corresponding changes in the effective refractive index of the optical path, which subsequently influences the output spectrum. The dimensions and quality of the optical fiber are meticulously regulated through a combination of femtosecond laser cutting and chemical polishing, significantly enhancing the mechanical strength and sensitivity of the sensor’s overall structure. Experimental results indicate that the sensor achieves salinity sensitivity of 0.288 nm/% within a salinity range of 0% to 25%. Furthermore, the temperature sensitivity is measured at a minimal 0.015 nm/°C, allowing us to neglect temperature effects. The device is characterized by its compact size, straightforward structure, high mechanical robustness, ease of production, and excellent reproducibility. It demonstrates considerable potential for sensing applications in the domains of biomedicine and chemical engineering. Full article

The five-hole pressure probe based on Micro-Electro-Mechanical Systems (MEMS) technology is designed to meet the needs of engine inlet pressure measurement. The probe, including a pressure-sensitive detection unit and a five-hole probe encapsulation structure, combines the advantages of a five-hole probe with fiber optic sensing. The pressure-sensitive detection unit utilizes silicon-glass anodic bonding to achieve the integrated and batch-producible manufacturing of five pressure-sensitive Fabry–Perot (FP) cavities. The probe structure and parameters of the sensitive unit were optimized based on fluid and mechanical simulations. The non-scanning correlation demodulation technology was applied to extract specific cavity lengths from multiple interference surfaces. The sealing platform was established to analyze the sealing performance of the five-hole probe and the pressure-sensitive detection unit. The testing platform was established to test the pressure response characteristics of the probe. Experimental results indicate that the probe has good sealing performance between different air passages, making it suitable for detecting pressure from multiple directions. The pressure responses are linear within the range of 0–250 kPa, with the average pressure sensitivity of the five sensors ranging from 11.061 to 11.546 nm/kPa. The maximum non-linear error is ≤1.083%. Full article

An optical fiber pH sensor based on a long-period fiber grating (LPFG) is reported. Two oppositely charged polymers, polyethylenimine (PEI) and polyacrylic acid (PAA), were alternately deposited on the sensing structure through a layer-by-layer (LbL) electrostatic self-assembly technique. Since the polymers are pH sensitive, their refractive index (RI) varies when the pH of the solution changes due to swelling/deswelling phenomena. The fabricated multilayer coating retained a similar property, enabling its use in pH-sensing applications. The pH of the PAA dipping solution was tuned so that a coated LPFG achieved a pH sensitivity of (6.3 ± 0.2) nm/pH in the 5.92–9.23 pH range. Only two bilayers of PEI/PAA were used as an overlay, which reduces the fabrication time and increases the reproducibility of the sensor, and its reversibility and repeatability were demonstrated by tracking the resonance band position throughout multiple cycles between different pH solutions. With simulation work and experimental results from a low-finesse Fabry–Perot (FP) cavity on a fiber tip, the coating properties were estimated. When saturated at low pH, it has a thickness of 200 nm and 1.53 ± 0.01 RI, expanding up to 310 nm with a 1.35 ± 0.01 RI at higher pH values, mostly due to the structural changes in the PAA. Full article

To achieve omnidirectional sensitive detection of partial discharge (PD) in transformers and to avoid missing PD signals, a fiber optic omnidirectional sensing method for PD in transformers combined with the fiber Bragg grating (FBG) and Fabry-Perot (F-P) cavity is proposed. The fiber optic omnidirectional sensor for PD as a triangular prism was developed. The hollow structure of the probe was used to insert a single-mode fiber to form an F-P cavity. In addition, the three sides of the probe were used to form a diaphragm-type FBG sensing structure. The ultrasound sensitization diaphragm was designed based on the frequency characteristics of PD in the transformer and the vibration model of the diaphragm in the liquid environment. The fiber optic sensing system for PD was built and the performance test was conducted. The results show that the resonant frequency of the FBG acoustic diaphragm is around 20 kHz and that of the F-P cavity acoustic diaphragm is 94 kHz. The sensitivity of the developed fiber optic sensor is higher than that of the piezoelectric transducer (PZT). The lower limit of PD detection is 68.72 pC for the FBG sensing part and 47.97 pC for the F-P cavity sensing part. The directional testing of the sensor and its testing within a transformer simulation model indicate that the proposed sensor achieves higher detection sensitivity of PD in all directions. The omnidirectional partial discharge ultrasound sensing method proposed in this paper is expected to reduce the missed detection rate of PD. Full article

Hydrogen (H₂) sensors are critical to various applications such as the situation where H₂ is used as the clean energy for industry or the indicator for human disease diagnosis. Palladium (Pd) is widely used as the hydrogen sensing material in different types of sensors. Optical fiber H₂ sensors are particularly promising due to their compactness and spark-free operation. Here, we report a Fabry–Pérot (FP)-cavity-based H₂ sensor that is formed with a freestanding Pd membrane and integrated on a conventional single-mode optical fiber end. The freestanding Pd membrane acts both as the active hydrogen sensing material and as one of the reflective mirrors of the cavity. When the Pd film absorbs H₂ to form PdH_x, it will be stretched, resulting in a change of the cavity length and thus a shift of the interference spectrum. The H₂ concentration can be derived from the amplitude of the wavelength shift. Experimental results showed that H₂ sensors based on suspended Pd membranes can achieve a detection sensitivity of about 3.6 pm/ppm and a detection limit of about 3.3 ppm. This highly sensitive detection scheme is expected to find applications for sensing low-concentration H₂. Full article

Optical fiber Fabry-Pérot (FP) interferometer sensors have long been the focus of researchers in sensing applications because of their simple light path, low cost, compact size and convenient manufacturing methods. A miniature and highly sensitive optic fiber temperature sensor using an ultraviolet glue-filled FP cavity in a hollow capillary fiber is proposed. The sensor is fabricated by fusion splicing a single-mode fiber with a hollow capillary fiber, which is filled with ultraviolet glue to form a FP cavity. The sensor has a good linear response in the temperature testing and high-temperature sensitivity, which can be increased with the length of the FP cavity. The experimental results show that the temperature sensitivity reaches 1.174 nm/°C with a high linear response in the range of 30–60 °C. In addition, this sensor is insensitive to pressure and can be highly suitable for real-time water temperature monitoring for ocean research. The proposed ultraviolet glue-filled structure has the advantages of easy fabrication, high-temperature sensitivity, low cost and an arbitrary length of capillary, which has broad application prospects for marine survey technology, biological diagnostics and environmental monitoring. Full article

We present a novel method for the online measurement of multi-point opening distances of midpalatal sutures during a rapid palatal expansion (RPE) using fiber optic Fabry–Perot (F–P) sensors. The sensor consists of an optical fiber with a cut flat end face and an optical reflector, which are implanted into the palatal base structure of an expander and is capable of measuring the precise distance between two optical reflective surfaces. As a demonstration, a 3D-printed skull model containing the maxilla and zygomaticomaxillary complex (ZMC) was produced and a miniscrew-assisted rapid palatal expander (MARPE) with two guide rods was used to generate the midpalatal suture expansion. The reflected spectrums of the sensors were used to dynamically extract cavity length information for full process monitoring of expansion. The dynamic opening of the midpalatal suture during the gradual activation of the expander was measured, and a displacement resolution of 2.5 μm was demonstrated. The angle of expansion was derived and the results suggested that the midpalatal suture was opened with a slight V-type expansion of 0.03 rad at the first loading and subsequently expanded in parallel. This finding might be useful for understanding the mechanical mechanisms that lead to different types of expansion. The use of a fiber optic sensor for mounting the rapid palatal expander facilitates biomechanical studies and experimental and clinical evaluation of the effects of RPE. Full article

Fiber sensors possess characteristics such as compact structure, simplicity, electromagnetic interference resistance, and reusability, making them widely applicable in various practical engineering applications. Traditional fiber sensors based on different microstructures solely rely on the thermal expansion effect of silica material itself, limiting their usage primarily to temperature or pressure sensing. By employing thin film technology to form Fabry–Perot (FP) cavities on the end-face or inside the fiber, sensitivity to different physical quantities can be achieved using different materials, and this greatly expands the application range of fiber sensing. This paper provides a systematic introduction to the principle of FP cavity fiber optic sensors based on thin film technology and reviews the applications and development trends of this sensor in various measurement fields. Currently, there is a growing need for precise measurements in both scientific research and industrial production. This has led to an increase in the variety of structures and sensing materials used in fiber sensors. The thin film discussed in this paper, suitable for various types of sensing, not only applies to fiber optic FP cavity sensors but also contributes to the research and advancement of other types of fiber sensors. Full article

The signal-to-noise ratio (SNR) is a crucial parameter for assessing audio transmission quality and fiber optic acoustic sensors. This study presents a model for predicting the SNR of a fiber optic F-P acoustic sensing system using the Fabry–Perot (F-P) cavity length modulation principle, considering noise and line loss in the optical path. To validate the model, we constructed an F-P acoustic sensor system and measured the SNR in a semi-anechoic room. Additionally, we used MATLAB to simulate the SNR model and compared the results with experimental data. The model accurately predicted the SNR of the fiber optic F-P acoustic sensor system. Our results offer valuable guidance and theoretical support for optimizing system performance. Full article

We report a high-resolution fiber optic temperature sensor system based on an air-filled Fabry–Pérot (FP) cavity, whose spectral fringes shift due to a precise pressure variation in the cavity. The absolute temperature can be deduced from the spectral shift and the pressure variation. For fabrication, a fused-silica tube is spliced with a single-mode fiber at one end and a side-hole fiber at the other to form the FP cavity. The pressure in the cavity can be changed by passing air through the side-hole fiber, causing the spectral shift. We analyzed the effect of sensor wavelength resolution and pressure fluctuation on the temperature measurement resolution. A computer-controlled pressure system and sensor interrogation system were developed with miniaturized instruments for the system operation. Experimental results show that the sensor had a high wavelength resolution (<0.2 pm) with minimal pressure fluctuation (~$0.015$ kPa), resulting in high-resolution ($\pm 0.32 ℃$) temperature measurement. It shows good stability from the thermal cycle testing with the maximum testing temperature reaching $800 ℃$. Full article
