Search Results (95)

In order to study the influence of rock mechanical behavior under different saturation conditions on the stability of deep caverns, this paper establishes a mechanical model for bottom drum failure in deep chambers based on Pratt’s pressure arch theory and the upper bound theorem of limit analysis, comprehensively considering the effect of rock saturation. An analytical solution for the surrounding rock pressure under the nonlinear Hoek–Brown criterion is derived, and the optimal upper bound solution is obtained. The study systematically investigates the influence of rock saturation, geostress, and Hoek–Brown parameters (GSI, σ_c0, σ_c100, m_i, D) on the surrounding rock pressure and the characteristics of potential failure surfaces. The results indicate that the surrounding rock pressure exhibits two-stage variation with saturation degree (S_r): when S_r = 0~0.6, the surrounding rock pressure increases significantly, and the growth rate slows and tends to stabilize when S_r exceeds 0.6. Increases in ground stress field parameters (σ_v, λ) significantly raise the surrounding rock pressure and expand the potential failure zone. Among the Hoek–Brown parameters, increases in GSI, σ_c0, σ_c100, and m_i enhance the stability of the surrounding rock, while an increase in the disturbance factor D reduces its bearing capacity. The results of this paper can provide theoretical guidance for the stability evaluation of deep underground chambers. Full article

The spatial variability in rock mass mechanical parameters critically affects slope stability assessments. This study investigated the southern slope of the Bayan Obo open-pit mine. A representative elementary volume (REV) with a side length of 14 m was determined through discrete fracture network (DFN) simulations. Based on the rock quality designation (RQD) data from 40 boreholes, a three-dimensional spatial distribution model of the RQD was constructed using Ordinary Kriging interpolation. The RQD values were converted into geological strength index (GSI) values through an empirical correlation, and the generalized Hoek–Brown criterion was applied to develop a spatially heterogeneous equivalent mechanical parameter field. Numerical simulations were performed using FLAC3D, with the slope stability evaluated using the point safety factor (PSF) method. For comparison, three homogeneous benchmark models based on the 5th, 25th, and 50th percentiles produced profile-scale safety factors of 0.96–1.92 and failed to replicate the observed failure geometry. By contrast, the heterogeneous model yielded safety factors of approximately 1.03–1.08 and accurately reproduced the mapped sliding surface. These findings demonstrate that incorporating spatial heterogeneity significantly improves the accuracy of slope stability assessments, providing a robust theoretical basis for targeted monitoring and reinforcement design. Full article

In deep, geologically complex environments characterized by high in situ stress and elevated formation temperatures, the mechanical behavior of rocks often transitions from brittle to ductile, differing significantly from that of shallow formations. Traditional rock failure criteria frequently fail to accurately assess the strength of rocks under such deep conditions. To address this, a novel failure criterion suitable for high-temperature and high-pressure conditions has been developed by modifying the Mohr–Coulomb criterion. This criterion incorporates a quadratic function of confining pressure to account for the attenuation rate of strength increase under high confining pressure and a linear function of temperature to reflect the linear degradation of strength at elevated temperatures. This criterion has been used to predict the strength of granite, shale, and carbonate rocks, yielding results that align well with the experimental data. The average coefficient of determination (R²) reached 97.1%, and the mean relative error (MRE) was 5.25%. Compared with the Hoek–Brown and Bieniawski criteria, the criterion proposed in this study more accurately captures the strength characteristics of rocks under high-temperature and high-pressure conditions, with a prediction accuracy improvement of 1.70–4.09%, showing the best performance in the case of carbonate rock. A sensitivity analysis of the criterion parameters n and B revealed notable differences in how various rock types respond to these parameters. Among the three rock types studied, granite exhibited the lowest sensitivity to both parameters, indicating the highest stability in the prediction results. Additionally, the predictive outcomes were generally more sensitive to changes in parameter B than in n. These findings contribute to a deeper understanding of rock mechanical behavior under extreme conditions and offer valuable theoretical support for drilling, completion, and stimulation operations in deep hydrocarbon reservoirs. Full article

Elevated thermal conditions, rock formations exhibit distinct mechanical behaviors that significantly deviate from their characteristics under ambient temperature environments. This phenomenon raises critical questions regarding the applicability of conventional failure criteria in accurately assessing wellbore stability and maintaining the structural integrity of subsurface infrastructure within geothermal environments. Based on the least absolute deviation method, this paper studies the response characteristics of rock strength at different temperatures and evaluates the prediction performance of six commonly used strength criteria under various temperature and stress environments. The experimental findings reveal a pronounced nonlinear dependence of rock strength on confining pressure elevation. A comparative analysis of failure criteria demonstrates hierarchical predictive performance: the Hoek–Brown (HB) criterion achieves superior temperature-dependent strength prediction fidelity, outperforming the modified Griffith (MGC), Mohr–Lade (ML), and modified Wiebols–Cook (MWC) criteria by 12–18% in accuracy metrics. Notably, the Zhao–Zheng (ZZ) and conventional Mohr–Coulomb (MC) criteria exhibit statistically significant deviations across the tested thermal range. The HB criterion’s exceptional performance in high-temperature regimes is attributed to its dual incorporation of nonlinear confinement effects and thermally activated microcrack propagation mechanisms. The implementation of this optimized model in Well X’s borehole stability analysis yielded 89% alignment between predictions and field observations, with principal stress variations remaining within 7% of critical failure thresholds. These mechanistic insights offer critical theoretical and practical references for thermo-hydro-mechanical coupling analysis in enhanced geothermal systems and deep subsurface containment structures. Full article

In cold regions, the rock mass of open-pit mine slopes is continuously exposed to freeze–thaw (FT) environments, during which the fracture structures and their infilling materials undergo significant degradation, severely affecting slope stability and the assessment of service life. Conventional laboratory FT tests are typically based on uniform temperature settings, which fail to reflect the actual thermal variations at different burial depths, thereby limiting the accuracy of mechanical parameter acquisition. Taking the Wushan open-pit mine as the engineering background, this study establishes a temperature–depth relationship, defines multiple thermal intervals, and conducts direct shear tests on structural plane filling materials under various FT conditions to characterize the evolution of cohesion and internal friction angle. Results from rock mass testing and numerical simulation demonstrate that shear strength parameters exhibit an exponential decline with increasing FT cycles and decreasing burial depth, with the filling material playing a dominant role in the initial stage of degradation. Furthermore, a two-dimensional fracture network model of the rock mass was constructed, and the representative elementary volume (REV) was determined through the evolution of equivalent plastic strain. Based on this, spatial assignment of slope strength was performed, followed by stability analysis. Based on regression fitting using 0–25 FT cycles, regression model predictions indicate that when the number of FT cycles exceeds 42, the slope safety factor drops below 1.0, entering a critical instability state. This research successfully establishes a spatial field of mechanical parameters and evaluates slope stability, providing a theoretical foundation and parameter support for the long-term service evaluation and stability assessment of cold-region open-pit mine slopes. Full article

This paper outlines the key developments in the second generation of the Eurocodes, with a focus on the integration of rock engineering into the updated Eurocode 7—Geotechnical Design (EN 1997). It introduces the various methodologies used for safety verification of geotechnical structures and provides a brief overview of limit state design, including the semi-probabilistic approach and other reliability-based methods. The paper details the introduction of specific partial factors for intact rock, rock mass, and discontinuities and discusses specific aspects of the design of spread foundations on rock using calculations. This includes the shift from traditional global safety factor methods to the partial factor format prescribed by Eurocode 7, as well as the use of fully probabilistic analyses. To assess the practical implications of these updates, a case study on the design of a spread foundation is presented. The study compares three design approaches: the global safety factor method (based on mean values of actions and strength properties), the Eurocode 7 partial factor method (using characteristic values), and a probabilistic method (based on statistical distributions). Additionally, the paper examines the application of two failure criteria—Mohr–Coulomb and Hoek–Brown—in the calculation process. Full article

When deep-buried tunnels are excavated using the drill-and-blast method, the surrounding rock is subjected to combined cyclic blasting loads and excavation-induced stress unloading. Understanding the distribution characteristics of rock damage zones under these conditions is crucial for the design and safety of building-integrated underground structures. This study investigates the relationship between surrounding rock damage and in situ stress conditions through numerical simulation methods. A constitutive model suitable for simulating rock mass damage was developed and implemented in the LS-DYNA (version R12) code via a user-defined material model, with parameters determined using the Hoek–Brown failure criterion. A finite element model was established to analyze surrounding rock damage under cyclic blasting loads, and the model was validated using field data. Simulations were then carried out to explore the evolution of the damage zone under various stress conditions. The results show that with increasing hydrostatic pressure, the extent of the damage zone first decreases and then increases, with blasting-induced damage dominating under lower pressure and unloading-induced shear failure prevailing at higher pressure. When the hydrostatic pressure is less than 20 MPa, the surrounding rock stabilizes at a distance greater than 12.6 m from the tunnel face, whereas at hydrostatic pressures of 30 MPa and 40 MPa, this distance increases to 29.4 m. When the lateral pressure coefficient is low, tensile failure occurs mainly at the vault and floor, while shear failure dominates at the arch waist. As the lateral pressure coefficient increases, the failure mode at the vault shifts from tensile to shear. Additionally, when the horizontal stress perpendicular to the tunnel axis (σ_H) is less than the vertical stress (σ_v), variations in the axial horizontal stress (σ_h) have a significant effect on shear failure. Conversely, when σ_H exceeds σ_v, changes in σ_h have little impact on the extent of rock damage. Full article

The disturbance factor (D) in the Hoek–Brown criterion quantifies excavation-induced rock mass disturbance. Although D is conceptually defined as a continuous parameter ranging from 0 to 1, the most recent Hoek–Brown guidelines provide descriptions only for boundary conditions related to slopes and tunnels. In slope excavations, the degree of disturbance is governed not only by the excavation method but also by the thickness of the removed overburden, with its influence becoming particularly significant in deep excavations. In recent years, the concept of a transitional disturbance factor, varying with depth from the excavation surface, has gained increasing attention. To address this need, the EXCASS system, an empirical method for selecting appropriate excavation techniques based on the Geological Strength Index (GSI) and point load strength (I_s50) values, was integrated into the transitional disturbance factor framework in this study. EXCASS allows for the selection of stronger or weaker excavation methods, offering flexibility to control the degree of disturbance induced in the rock mass. Moreover, the disturbance factor at the excavation surface was determined by incorporating both the operational excavation power index and the thickness of the removed overburden. This integrated approach enables a more realistic evaluation of excavation-induced damage in slope stability analyses. Full article

In high-altitude cold regions, significant diurnal and seasonal temperature variations intensify freeze-thaw damage to rocks, critically impacting slope stability. This study examines a Xinjiang mine slope to assess freeze-thaw effects through laboratory experiments on three lithologies under varying freeze-thaw cycles. Mechanical parameters were determined via the Hoek–Brown criterion, and FLAC3D simulations analyzed stress-deformation characteristics and safety factor trends, validated against field monitoring. After 90 cycles, the results show progressive degradation: uniaxial compressive strength declined by 29.7–45.8%, elastic modulus by 42.7–63.3%, Poisson’s ratio by 16.0–42.1%, cohesion by 71.7–77.1%, internal friction angle by ~52.0%, and tensile strength by 79.3–83.6%. The slope safety factor decreased exponentially (44.5% reduction). Both simulations and monitoring revealed “step-like” displacement growth, with minor discrepancies attributed to modeling assumptions. These findings provide critical insights for safe mining operations in cold regions, highlighting the severe mechanical deterioration induced by freeze-thaw cycles and its implications for slope stability. Full article

With the gradual depletion of mineral resources in temperate regions, cold regions have become primary areas for mineral extraction. However, the freeze–thaw phenomena induced by temperature fluctuations pose significant threats to the stability of rock masses on open−pit mine slopes, further affecting normal mining operations. To investigate the strength degradation and stability evolution patterns of freeze–thaw slope rock masses, this study takes the Wushan Open−Pit Mine as its engineering context. We analyzed the relationship between rock temperature and burial depth, conducted freeze–thaw cyclic tests under realistic temperature ranges, and developed a mechanical parameter characterization model for freeze–thaw rock masses by integrating the generalized Hoek–Brown strength criterion. Slope safety factors and potential landslide mechanisms were determined through numerical simulations and the strength reduction method. Key findings include the following: (1) Shallow rock temperatures exhibit high synchronization with atmospheric temperature, characterized by large fluctuations and rapid variation rates, whereas deep rock demonstrates opposite trends. (2) As freeze–thaw cycles increase and burial depth decreases, the internal friction angle and cohesion of slope rock masses follow negative exponential decay functions. After 20 freeze–thaw cycles, the internal friction angle and cohesion of rock at a 5.27 m depth decreased by 18.36% and 33.92%, respectively. In contrast, rock at a 0.10 m depth showed more severe reductions of 31.81% and 50.14%. (3) Increasing freeze–thaw cycles progressively lower the safety factors of slope benches, with potential slip surfaces displaying reduced average depths and curvature, alongside elevated dip angles. These findings provide critical insights for preventing freeze–thaw−induced landslide hazards in cold−region open−pit mine slopes. Full article

Extracting nodal features is crucial for analyzing rock structure stability and plays a significant role in designing engineering projects. This study presents an enhanced version of the FraSegNet algorithm, focusing on improving its ability to identify nodal features in images. The updated FraSegNet incorporates the ResNet101 backbone and integrates the Squeeze-and-Excitation (SE) attention mechanism, enabling better concentration on key nodal characteristics. The primary improvements are as follows: (1) Multi-scale feature extraction: Leveraging the ResNet101 architecture for the effective extraction of detailed information from nodal images. (2) Better attention mechanisms: The SE module focuses on nodal regions, resulting in clearer and more refined feature representations. (3) Dynamic learning strategies: I incorporation of cosine annealing and warm-up techniques to optimize training efficiency. The algorithm was validated with the Barton–Bandis model and Hoek–Brown criterion. The experimental results demonstrate its superior performance, achieving 97.1% accuracy in nodal feature detection with an average error of only 1.5% compared to the rock mass parameter. This small error proves the model works well. FraSegNet offers accurate segmentation and precise geometric parameter extraction, making it a valuable tool for advancing rock stability analysis and practical applications in rock mechanics. Full article

Used for soil and weathered rocks, soil nails are rigid reinforcements positioned at certain angles on the ground to provide slope stability. A rigid reinforcement element placed in a well filled with cement grout mix after completing drilling will generate adherence stress between the grout-mixed nail bar and soil. Due to this stress, load is transferred to the soil along the soil–grout interaction surface. In the case discussed herein, the slope at the parcel border needed to be made steeper in order to accommodate the construction of a facility in the Taşkısığı region of Sakarya province. Soil-nailed walls, which are inexpensive and suitable for weathered rocks, were needed as a support system because the slope was too steep to support itself. Support system performance was measured using two inclinometers and two soil nail pull-out tests conducted on different sections observed during and after construction. Contrary to the design-phase prediction, it was determined that the stresses started to dampen in the region closer to the slope-facing zone. Field measurement data and numerical analysis revealed that higher parameters than necessary were selected. In this context, sensitivity and parameter analyses were carried out using the Hoek–Brown constitutive model. The GSI value was re-evaluated and found to be compatible with the observation results obtained from the field performance. Since the retaining wall performance observed was higher than expected, geometric parametric analysis of the structural elements was performed; high safety coefficients were found across variations. The effects of the inclination of the slope, nail length, nail spacing, and nail slope design parameters on the safety coefficient and horizontal displacement were examined. The optimal design suggested nail lengths of 4.00 m, a spacing of 1.60 m, and slopes of 20°. It was discovered that the effect of the inclination degree of the slope on the safety coefficient was lower than expected. The results revealed that a more economical design with a similar safety factor can be obtained by shortening the lengths of the nails. Full article

Metallic ore deposits are generally formed through magmatic intrusions, followed by metamorphism. The geological structures in such regions are often complex, with mechanical parameters exhibiting significant variability. These characteristics dictate the need for refined geological modeling and heterogeneous mechanical parameters for rock mass stability analysis to ensure reliability. Therefore, this paper proposes a novel method for rock mass stability analysis. The method fully leverages high-density drilling data from the mine and introduces an intelligent rock quality designation (RQD) identification technique, facilitating characterization of the spatial heterogeneity of rock mass RQD. Building on this, laboratory experiment data and in situ measurements are integrated, and the Hoek–Brown criterion is employed to achieve a refined characterization of heterogeneous rock mass mechanical parameters. This method allows for a realistic inversion of in situ rock mass mechanical conditions, overcoming the limitations inherent in assigning uniform parameters. Finally, the computed rock mass mechanical parameters are assigned to the refined computational model to conduct rock mass stability analysis. Taking the Jiangfeng Iron Mine, with its complex geological conditions, as an example, this method enables the accurate evaluation of the rock mass stability, determines the feasibility of joint mining, and calculates the appropriate thickness of the isolation pillars, effectively mitigating safety risks in mining operations. This method provides a valuable reference for the rock mass stability analysis of underground joint mining operations for similar mines. Full article

In open-pit excavations, overburden rock mass is disturbed by processes like blasting and mechanical excavation, leading to a reduction in mechanical properties. Accounting for this disturbance is essential for ensuring slope stability, optimizing costs, and maintaining feasibility. The Hoek–Brown failure criterion, a widely used empirical method in rock mechanics, incorporates the disturbance factor to reflect the reduction in rock mass strength after disturbance. This study reviews five approaches from the literature regarding the role of disturbance in rock mechanics, focusing on its impact on the factor of safety and the volume of rock mass above the potential failure surface. Additionally, an “S” shaped decay formulation was proposed as an alternative to existing equations. A key consideration is the transitional disturbance effect, which reflects the gradual change from a fully disturbed rock mass near the excavation surface to an undisturbed rock mass with increasing depth. Among the examined approaches, the “S” shaped decay equation, informed by insights from previous studies, appears to be the most realistic. One approach assumes the disturbance factor is highest at the surface due to the removal of blasted rock, leading to a fully disturbed rock mass in front of the excavation face. The disturbance then decreases with depth, transitioning to an undisturbed condition depending on the excavation method. Even when the rock mass is homogeneous and isotropic in joint properties, excavation induces anisotropy in mass strength, causing overall strength to increase with depth. This study also investigates the effect of anisotropic strength behavior resulting from the disturbance factor. For incorporating transitional disturbance in the design stage, both circular and combined failure mechanisms should be considered for a comprehensive understanding of slope stability. Full article

Considering the effect of surrounding rock on lining in the design of tunnel lining within fractured rock masses is challenging, particularly in accurately predicting the reserved deformation of the tunnel. This study bases a rock mass classification method and the established Hoek–Brown (H-B) strength criterion to assess the deformation characteristics of the surrounding rock. It establishes a more scientifically rigorous theoretical calculation method for the reserved deformation of tunnel linings that accounts for the rock–lining interaction. An optimization design approach for the lining structure, based on the synergistic effect and considering the stress safety of the concrete lining and the rock’s displacement release rate, is proposed. Case analysis is utilized to validate the safety of the lining design in the study section through computational verification. The recommended optimized lining parameters are identified: the support time is initiated when the tunnel wall’s surrounding rock deforms by 9 mm, and the lining thickness is optimized to 47 cm, which is approximately 36.5% less than the pre-optimization thickness. This precise optimization of support timing and lining thickness enhances both the safety and economic efficiency of the Wufengshan Tunnel. The method allows for the calculation of the optimal combination of support time and lining thickness tailored to different surrounding rock conditions, offering significant reference value for tunnel lining optimization. Full article
