Search Results (2,282)

Renewable energy and voltage source inverter-driven microgrids generally lack natural inertia to provide transient energy support during sudden load demands. To address this, the virtual synchronous generator (VSG) is a state-of-the-art control technique applied in power controllers to emulate virtual inertia during sudden load changes. This allows for stable power delivery from the source to the loads during sudden active power load demands. However, in systems with large inductively dominant load demands, conventional VSG-based power controllers may exhibit a delayed reactive power response due to their inertia-emulating characteristics, potentially affecting the overall power-sharing performance. To address this limitation of VSG control, this paper proposes an advanced control scheme in which the VSG is supported by appropriately designed voltage and current controllers. Conventionally, classical tuning techniques are used to design the controllers in the forward paths of the voltage and current controllers (CVAs). Thus, the conventional control scheme is a combination of a VSG and CVAs. Recently, a hybrid modified pole-zero cancellation technique has been discussed in the literature for the design of voltage and current controllers (HVAs) to improve the vector control of the inverter. This method supports better tuning for controllers of both forward and cross-coupling paths. Therefore, to improve the power delivery with VSG-based control when subjected to inductive load changes, this paper proposes an advanced control scheme that is based on the combination of VSG and HVA. The performance of both conventional and proposed control schemes is verified through simulation in MATLAB/Simulink under two different test load conditions, namely good and poor power factor loadings. Based on the results obtained during these test cases, the response and power delivery capability of the proposed control scheme is comparable with that of the conventional control scheme. The results verify that the power delivery capability of the microgrid with the proposed control scheme is improved by 25% compared to the conventional control scheme. Full article

Ultra-low frequency oscillation has been regarded as a typical instability issue in power systems consisting of hydro turbine synchronous generators due to the water hammer phenomenon. However, the increasing installation of renewable power generators gradually changes the stability mechanisms within multiple frequency bands. In this digest, a new kind of ultra-low frequency oscillation caused by doubly-fed induction generators (DFIGs) equipped with a df/dt controller in a thermal power generation system is introduced. To reveal the underlying mechanism, the motion equation model of the DFIG is constructed, and the simplified analytical model is proposed. The results show that when integrating a df/dt-controlled DFIG into a normal three-machine, nine-bus system, the damping ratio decreases to more than 0.2 when the virtual inertia parameter increases from 5 to 20, leading to a conflict between fast virtual inertial response and stability requirements. Other controllers related to active power regulation are also vital to stability. The frequency domain characteristics of the system are studied to illustrate the influence of key parameters on system stability. Finally, simulation verifications are conducted in MATLAB/Simulink. Full article

DFIG rotor windings face high stress and transients from back-to-back converters, causing inter-turn short circuit (ITSC) faults. Rapid rotor-side dynamics, combined with the unique capability of DFIG to operate in multiple modes, make the fault detection in rotor windings more challenging. This paper presents a comprehensive methodology for online ITSC fault diagnosis in DFIG rotor windings based on zero-sequence current (ZSC) component analysis under variable operating conditions. Fault features are identified and defined through the analytical evaluation of the DFIG mathematical model. Further, a simple yet effective algorithm is presented for online implementation of the proposed methodology. Finally, the simulation of the DFIG model is carried out in MATLAB/Simulink under both sub-synchronous and super-synchronous modes, covering a range of variable loads and low-frequency conditions, along with different fault severity levels of ITSC in rotor windings. Simulation results confirm the effectiveness of the proposed methodology for online ITSC fault detection at a low-severity stage and precise location identification of the faulty phase within the DFIG rotor windings under both sub-synchronous and super-synchronous modes. Full article

To address the growing integration of renewable energy sources and storage systems into distribution networks, there is a need for effective tools that can assess the impact of these technologies on grid performance. This paper investigates the impact of integrating residential rooftop photovoltaic (PV) systems and battery energy storage systems (BESSs) into low-voltage (LV) distribution networks. A stochastic approach, using the Monte Carlo method, is applied to randomly place PV systems across the network, generating multiple scenarios for power flow simulations in MATLAB Simulink R2024b. The method incorporates real-world consumer load data and grid topology, representing a novel approach in simulating distribution network behaviour accurately. The novelty of this paper lies in its ability to combine stochastic PV placement with real-world load data, providing a more realistic representation of network conditions. The simulation results revealed that widespread PV deployment can lead to overvoltage issues, but the integration of BESSs alongside PV systems mitigates these problems significantly. The findings of this paper offer valuable insights for Distribution Network Operators, aiding in the development of strategies for optimal PV and BESS integration to enhance grid performance. Full article

Trajectory tracking control refers to the movement of an unmanned underwater vehicle (UUV) along a desired trajectory, which is a critical technology for the underwater tasks of UUVs. However, in actual scenarios, the reaction torque of propellers induces roll motion in UUVs, and the communication resource and computational resource of UUVs are limited, which affects the trajectory tracking performance of UUVs severely. Hence, this paper introduces an event triggering mechanism to design the double-loop integrated sliding mode control (EDLISMC), which is used for the trajectory tracking control of UUVs. This method designs the kinematic model and dynamic model of 6 degree of freedom (DoF) UUVs under the influence of reaction torque. Then, this method derives the dual loop integral sliding mode controller and designs the event triggering mechanism based on the relative threshold to reduce unnecessary control signals and improve the control efficiency of UUVs. In addition, this method uses a positive lower bound method to verify that the proposed event triggering mechanism does not have Zeno behavior and adopts the Lyapunov theorem to analyze the stability of EDLISMC. Finally, this paper conducts simulations on the simulink component of MATLAB. The relevant simulation proves that the proposed method can complete the trajectory tracking control of UUVs under the influence of reaction torque and it is superior to other methods in terms of resource consumption. Full article

Vibratory machines are widely used for the separation of granular materials of various densities and characteristics. Vibrations are used in this case to increase the technological speed of separation of these materials. Vibratory machines are limited in functioning to fixed oscillation patterns. Control of the oscillation can offer the possibility of changing the oscillation pattern, adapting it to the type of granular material. This paper proposes a vibratory machine with controllable elastic characteristics and pneumatic actuation. From the perspective of functional generalization of these machines, a parallel mechanism with 3 degrees of mobility, starting from the study of the Stewart platform, was designed. The proposed system has been studied both in terms of structure and kinematics, using instruments of simulation tools available in MATLAB and Simulink 2021. The developed model was validated and optimized using multi-body dynamic software ADAMS 2014, obtaining optimal parameters for one type of granular material. Full article

Compressed natural gas (CNG) refueling stations operate under highly dynamic thermodynamic conditions, requiring accurate modeling and optimization to ensure efficient performance. In this study, a dynamic simulation model of a CNG station was developed using MATLAB-SIMULINK, including detailed subsystems for multi-stage compression, cascade storage, and vehicle tank filling. Real gas effects were incorporated to improve prediction accuracy of the pressure, temperature, and mass flow rate variations during fast filling. The model was validated against experimental data, showing good agreement in both pressure rise and flow rate evolution. A two-stage multi-objective optimization approach was applied using Taguchi experimental design and gray relational analysis (GRA). In the first stage, storage pressures were optimized to maximize the number of vehicles filled and gas mass delivered, while minimizing compressor-specific work. The second stage focused on optimizing the volume distribution among the low, medium, and high-pressure tanks. The combined optimization led to a 12.33% reduction in compressor-specific energy consumption with minimal change in refueling throughput. These results highlight the critical influence of pressure levels and volume ratios in cascade storage systems on station performance. The presented methodology provides a systematic framework for the analysis and optimization of transient operating conditions in CNG infrastructure. Full article

Power electronic converter-based microgrids generally suffer from poor power delivery/handling capability during sudden load changes, especially during islanded operations. This is due to the lack of transient energy support to compensate for sudden load changes. The literature has suggested the use of adaptive droop control to provide compensation during transient conditions, thereby improving the power delivery capability. In this context, fuzzy logic-based adaptive droop control is a state-of-the-art technique that was developed based on empirical knowledge of the system. However, this way of designing the droop coefficient values without considering the mathematical knowledge of the system leads to instability during transient conditions. This problem further aggravates when dominant inductive load changes occur in the system. To address this limitation, this paper proposes an improved fuzzy logic-based adaptive droop control method. In the proposed methodology, the values of droop coefficients that are assigned for different membership functions are designed based on the stability analysis of the microgrid. In this analysis, the feasible range of active power–frequency droop values that could avoid instability during large inductive load changes is identified. Accordingly, the infeasible values are avoided in the design of the fuzzy controller. The performance of the proposed and the conventional fuzzy logic methods is verified through simulation in MATLAB/Simulink. From the results, it is identified that the proposed method has improved the power delivery capability of the microgrid by 14% compared to the conventional method. Full article

Water electrolysis for hydrogen production is of great importance for the reliable use of renewable energy sources to have a clean environment. Electrolyzers play a key role in achieving the carbon-neutral target of 2050. Among the different types of water electrolyzers, proton exchange membrane water electrolyzers (PEMWEs) represent a well-developed technology that can be easily integrated into the smart grid for efficient energy management. In this study, a discrete dynamic mathematical model of a PEMWE was developed in MATLAB/Simulink to simulate cell performance under various operating conditions such as temperature, inlet flow rate, and current density loads. A lab-scale test bench was designed and set up, and a 5 cm² PEMWE was tested at different temperatures (40–80 °C) and flow rates (3–12 mL/min), obtaining Linear Sweep Voltammetry (LSV), Cyclic Voltammetry (CV), Chrono-potentiometry (CP), and Electrochemical Impedance Spectroscopy (EIS) results for comparison and adjustment of the dynamic model. Sensitivity analysis of different operating variables confirmed that current density and temperature are the most influential factors affecting cell voltage. The parametric sensitivity of various chemical–physical and electrochemical parameters was also investigated. The most significant ones were estimated via non-linear least squares optimization to fine-tune the model. Additionally, strong correlations between these parameters and temperature were identified through regression analysis, enabling accurate performance prediction across the studied temperature range. Full article

The design of intelligent vehicle trajectory tracking controllers still has some problems, such as parameter uncertainty and time consumption. To improve the tracking accuracy of the trajectory tracking controller and reduce its computational complexity, an adaptive MPC trajectory tracking control method with a variable prediction horizon is proposed. Firstly, a three-degree-of-freedom vehicle dynamics model is constructed, and the design is improved based on the ordinary MPC controller. Secondly, several groups of different constant vehicle speeds are selected to compare the tracking effect of the ordinary MPC and the improved controller. Then, low speed (30 km/h) and high speed (100 km/h) are selected as representative speeds to solve the calculation time of the controller. The relationship between vehicle speed and prediction horizon is analyzed, and curve fitting is carried out. An adaptive trajectory tracking controller is designed. Finally, it is verified by CarSim and MATLAB/Simulink co-simulation. The results show that compared with ordinary MPC, the improved adaptive trajectory tracking controller can maintain good tracking accuracy and stability according to the speed change and improve the computational efficiency of the controller. Full article

Cable-driven actuators (CDAs) are extensively used in the rehabilitation field because of advantages such as low moment of inertia, fast movement response, and intrinsic flexibility. Accurate control of cable force is essential for achieving precise movement control, especially when the movement is generated by multiple CDAs. However, velocity-induced disturbances pose challenges to accurate force control during dynamic movements. Several strategies for direct force control have been investigated in the literature, but time-consuming tests are often required. The aim of this study was to develop a force feedback controller and a speed feedforward compensator for a CDA with a convenient experiment-based approach. The CDA consisted of a motor with a gearbox, a cable drum, and a force sensor. The transfer function between motor torque and cable force was estimated through an open-loop test. A PI force feedback controller was developed and evaluated in a static test. Subsequently, a dynamic test with a reference force of 100 N was conducted, during which the cable was pulled to move at different speeds. The relationship between the motor speed and the cable force was determined, which facilitated further development of a speed feedforward compensator. The controller and compensator were evaluated in dynamic tests at various speeds. Additionally, the system dynamics were simulated in MATLAB/Simulink. The static test showed that the PI force controller produced a mean force control error of 4.7 N, which was deemed very good force-tracking accuracy. The simulated force output was very similar to the experiment (RMSE error of 4.0 N). During the dynamic test, the PI force controller alone produced a force control error of 9.0 N. Inclusion of the speed feedforward compensator improved the force control accuracy, resulting in a mean error at various speeds of 5.6 N. The combined force feedback controller and speed feedforward compensator produced a satisfactory degree of accuracy in force control during dynamic tests of the CDA across varying speeds. Additionally, the accuracy level was comparable to that reported in the literature. The convenient experiment-based design of the force control strategy exhibits potential as a general control approach for CDAs, laying the solid foundation for precise movement control. Future work will include the integration of the speed compensator into better feedback algorithms for more accurate force control. Full article

This paper proposes the design of a speed sensorless robust discontinuous controller for the trajectory tracking problem of a 5-DOF robotic manipulator under payload changes and torque disturbances in the joints. The developed observer-based controller is capable of performing trajectory tracking, ensuring stability, fast error convergence and speed sensorless operation. In order to avoid joint speed measurement, an estimation scheme based on a differentiation algorithm is implemented to estimate it. Simulation tests developed in MATLAB/Simulink are presented to show the high performance of the proposed scheme for two different trajectories with the model of the CRS Catalyst-5 by Thermo Electron^®, Burlington, ON, Canada. Full article

The exhaust purge on the anode side is a critical step in the operation of fuel cell systems, and optimizing the exhaust interval time is essential for enhancing stack efficiency and hydrogen utilization. This paper proposed a method to determine the purge strategy of hydrogen supply system based on theoretical and simulation analysis. To investigate the impact of anode purge strategy on the performance of automotive fuel cells, a model of a 100 kW fuel cell stack and a dual-ejector hydrogen supply system was developed in MATLAB/Simulink(R2022b) using principles of fluid dynamics, simulation, and experimental data. This model effectively captures the accumulation and exhaust of hydrogen, nitrogen, and vapor within the anode. Simulations were conducted under seven different exhaust interval times at varying current densities to study the effect of exhaust interval on the performance of the fuel cell. The results indicate that for a 100 kW fuel cell, the exhaust interval time should be controlled within 25 s and should decrease as the current density increases. At low current density, increasing the exhaust interval has a more significant effect on improving hydrogen utilization. At high current density, reducing the exhaust interval helps maintain a stable hydrogen excess ratio and shortens the time required for the output voltage to reach a stable state. Full article

Power systems are currently undergoing a transition from centralized synchronous generators to decentralized non-synchronous generators that rely on renewable energy sources. This shift poses a challenge to system operators, as the high penetration levels of renewable energy introduce variability and changes in the physics of power systems. Load-frequency control is one of the biggest challenges faced by electrical grids, especially with increased wind energy penetration in recent years. The inertial controller is one of the methods used to support system frequency in variable-speed wind turbines. In this study, a proportional resonant (PR) controller was added to an inertial controller to achieve better frequency regulation by controlling the active power of the doubly fed induction generator (DFIG). First, the impact of the PR controller parameters on the frequency deviation, overshoot, settling time, and system stability was investigated to identify the optimal values that achieved the lowest frequency deviation while maintaining system stability. Second, the performance of the proposed method was compared that of the traditional method under different load perturbations. The results prove that improperly determining the proportional gain of the PR controller negatively affects system stability and frequency deviation. In addition, the results validate the hypothesis that the proposed method would provide fast frequency support for all the studied cases. The analysis and simulation of these scenarios were performed using the MATLAB/SIMULINK program. Full article

In medium-voltage AC applications, multilevel converters are essential due to their ability to achieve high efficiency and significantly reduce total harmonic distortion (THD), ensuring improved performance and power quality. This paper presents a detailed analysis of the efficiency, power loss, and THD characteristics of multiplexed multilevel converters and neutral point clamped converters. Using MATLAB^®Simulink 2024b, the switching and conduction losses of both multiplexed multilevel converters and NPC converters are calculated. The three-level NPC converter offers advantages of a simpler design, reduced component count, and cost effectiveness with the drawback of low voltage quality. Simulation results validate the THD, power losses, and efficiency for the conventional three-phase three-level NPC converter and the three-phase multiplexed multilevel converter, and a detailed comparison is performed. Full article
