Search Results (70)

Search Parameters:
Keywords = SPWM inverters

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
47 pages, 3190 KB
Article
THDv Reduction in Multilevel Three-Phase Inverters Using the SHE-PWM Technique with a Hybrid Optimization Algorithm
by Miguel Ayala, Luis Tipán, Manuel Jaramillo and Cristian Cuji
Energies 2025, 18(16), 4292; https://doi.org/10.3390/en18164292 - 12 Aug 2025
Viewed by 524
Abstract
The following article aims to implement a hybrid modulation methodology based on the Selective Harmonic Elimination Pulse Width Modulation (SHE-PWM) technique to work with the fundamental frequency of the system and find the optimal firing angles using the PSO optimization algorithm, capable of [...] Read more.
The following article aims to implement a hybrid modulation methodology based on the Selective Harmonic Elimination Pulse Width Modulation (SHE-PWM) technique to work with the fundamental frequency of the system and find the optimal firing angles using the PSO optimization algorithm, capable of reducing the voltage THDv present in the output signals of three-phase multilevel inverters. To develop this approach, three case studies are proposed, developed in MATLAB/Simulink software, which feature three-phase inverters with five, seven, and nine levels, respectively, of the CHB topology. The impact of adequate modulation is assessed, resulting in a voltage output signal with reduced distortion. The national regulation ARCERNNR 002/20 will be used as a reference point to evaluate the results before and after implementing the methodology. It was verified that the developed methodology can effectively eliminate the selected harmonics, especially those of lower order (3rd, 5th, 7th, 9th, 11th, 13th, and 15th), achieving an improvement of up to 17.93% in the voltage THDv concerning the standard S-PWM modulation present in the CHB-MLI. Full article
(This article belongs to the Section F3: Power Electronics)
Show Figures

Figure 1

25 pages, 7875 KB
Article
A Comparative Study of Direct Power Control Strategies for STATCOM Using Three-Level and Five-Level Diode-Clamped Inverters
by Diyaa Mustaf Mohammed, Raaed Faleh Hassan, Naseer M. Yasin, Mohammed Alruwaili and Moustafa Ahmed Ibrahim
Energies 2025, 18(13), 3582; https://doi.org/10.3390/en18133582 - 7 Jul 2025
Cited by 1 | Viewed by 679
Abstract
For power electronic interfaces, Direct Power Control (DPC) has emerged as a leading control technique, especially in applications such as synchronous motors, induction motors, and other electric drives; renewable energy sources (such as photovoltaic inverters and wind turbines); and converters that are grid-connected, [...] Read more.
For power electronic interfaces, Direct Power Control (DPC) has emerged as a leading control technique, especially in applications such as synchronous motors, induction motors, and other electric drives; renewable energy sources (such as photovoltaic inverters and wind turbines); and converters that are grid-connected, such as Virtual Synchronous Generator (VSG) and Static Compensator (STATCOM) configurations. DPC accomplishes several significant goals by avoiding the inner current control loops and doing away with coordinating transformations. The application of STATCOM based on three- and five-level diode-clamped inverters is covered in this work. The study checks the abilities of DPC during power control adjustments during diverse grid operation scenarios while detailing how multilevel inverters affect system stability and power reliability. Proportional Integral (PI) controllers are used to control active and reactive power levels as part of the control approach. This study shows that combining DPC with Sinusoidal Pulse Width Modulation (SPWM) increases the system’s overall electromagnetic performance and control accuracy. The performance of STATCOM systems in power distribution and transient response under realistic operating conditions is assessed using simulation tools applied to three-level and five-level inverter topologies. In addition to providing improved voltage quality and accurate reactive power control, the five-level inverter structure surpasses other topologies by maintaining a total harmonic distortion (THD) below 5%, according to the main findings. The three-level inverter operates efficiently under typical grid conditions because of its straightforward design, which uses less processing power and computational complexity. Full article
Show Figures

Figure 1

14 pages, 20066 KB
Article
Enhanced Harmonic Reduction and Voltage Utilization Ratio Improvement in ANPC Inverters Using an Advanced Hybrid SVPWM Technique
by Gipyo Kim, Hyunjae Lee and Jingeun Shon
Energies 2025, 18(7), 1868; https://doi.org/10.3390/en18071868 - 7 Apr 2025
Cited by 1 | Viewed by 663
Abstract
This paper proposes an Advanced Hybrid SVPWM (Space Vector Pulse Width Modulation) technique that integrates the benefits of RPS-PWM (Reference Point Saturation-Based PWM) and SVPWM to enhance the performance of three-level ANPC (Active Neutral Point Clamped) inverters. While RPS-PWM effectively reduces switching harmonics, [...] Read more.
This paper proposes an Advanced Hybrid SVPWM (Space Vector Pulse Width Modulation) technique that integrates the benefits of RPS-PWM (Reference Point Saturation-Based PWM) and SVPWM to enhance the performance of three-level ANPC (Active Neutral Point Clamped) inverters. While RPS-PWM effectively reduces switching harmonics, it suffers from lower voltage utilization. In contrast, SVPWM achieves higher voltage utilization but struggles with harmonic suppression. The proposed Advanced Hybrid SVPWM technique addresses these limitations by maintaining the voltage utilization level of RPS-PWM while significantly reducing harmonic distortion and increasing the output Vrms. To validate the effectiveness of the proposed method, comprehensive PSIM simulations and DSP-based hardware experiments were conducted. Experimental results confirm that the Advanced Hybrid SVPWM achieves superior harmonic suppression compared to conventional RPS-PWM and SVPWM, while also delivering improved output voltage characteristics. These findings highlight the potential of the proposed technique for enhancing the performance of power electronic systems requiring high efficiency and low harmonic distortion. Full article
(This article belongs to the Section F3: Power Electronics)
Show Figures

Figure 1

19 pages, 6419 KB
Article
Performance Comparison of Asymmetrical Multilevel Inverter with Different Switching Techniques
by Ashish Srivastava, Anurag Chauhan and Anurag Tripathi
Energies 2025, 18(3), 715; https://doi.org/10.3390/en18030715 - 5 Feb 2025
Cited by 1 | Viewed by 1149
Abstract
In the present context, the asymmetrical multilevel inverter (AMLI) with minimal switches is extensively used to achieve high power quality across a load. The conventional inverter suffers from the disadvantages of large system components, low efficiency, high THD, high losses, etc. The asymmetrical [...] Read more.
In the present context, the asymmetrical multilevel inverter (AMLI) with minimal switches is extensively used to achieve high power quality across a load. The conventional inverter suffers from the disadvantages of large system components, low efficiency, high THD, high losses, etc. The asymmetrical multilevel inverter therefore offers an appropriate alternative to address the key issues of conventional inverters. The present paper aims to analyze the performance comparison of the proposed 15-level AMLI structure with different switching techniques, i.e., NLC, SHEPWM and SPWM. Moreover, loss analysis of the considered AMLI has been performed for different switching techniques. Furthermore, different performance parameters such as conduction losses, switching losses, total losses, THD, efficiency and power delivery of the inverter have been evaluated. It has been observed that the considered inverter topology offers the superior performance with the SHEPWM modulation technique at a modulation index of 0.8. Finally, hardware arrangement of the inverter has also been developed in the laboratory with a real-time Opal-RT 4510 simulator to verify the accuracy of simulation results. Full article
(This article belongs to the Section F1: Electrical Power System)
Show Figures

Figure 1

18 pages, 3743 KB
Article
Efficiency Design of a Single-Phase Bidirectional Rectifier for Home Energy Management Systems
by Vicente Esteve, Juan L. Bellido and José Jordán
Electronics 2025, 14(1), 15; https://doi.org/10.3390/electronics14010015 - 24 Dec 2024
Viewed by 1351
Abstract
This paper examines the current state of Home Energy Management Systems (HEMSs), highlighting the key role of the single-phase bidirectional rectifier (SPBR). It provides a detailed design process for the converter used in HEMSs, with a particular focus on the bidirectional charge and [...] Read more.
This paper examines the current state of Home Energy Management Systems (HEMSs), highlighting the key role of the single-phase bidirectional rectifier (SPBR). It provides a detailed design process for the converter used in HEMSs, with a particular focus on the bidirectional charge and discharge of high-voltage batteries. The converter’s operating conditions were determined through a comprehensive evaluation of its components, which were designed and assessed to enable accurate power loss calculations. This approach ensures proper component sizing and a clear understanding of the converter’s efficiency. A specialized electronic control circuit manages two operating modes of the converter: a boost rectifier with power factor correction (PFC) and a sinusoidal pulse width modulation (SPWM) inverter. To validate the design, a 7.4 kW prototype was developed using silicon carbide (SiC) metal oxide semiconductor field effect transistors (MOSFETs). The prototype achieved a peak efficiency of nearly 98% in both modes, with a unity power factor (PF) and total harmonic distortion (THD) below 7% at full power. Full article
Show Figures

Figure 1

17 pages, 12420 KB
Article
Design and Verification of Multiphase Multilevel Traction Inverter
by Patrik Resutík, Michal Praženica and Slavomír Kaščák
Appl. Sci. 2024, 14(22), 10562; https://doi.org/10.3390/app142210562 - 15 Nov 2024
Cited by 1 | Viewed by 1593
Abstract
The paper presents the practical design and implementation of a three-level neutral point clamped (TNPC) six-phase inverter rated at 100 kVA. The study initiates with prior work review, whereby most research work done earlier was mainly simulation-based. Based on the simulation results, this [...] Read more.
The paper presents the practical design and implementation of a three-level neutral point clamped (TNPC) six-phase inverter rated at 100 kVA. The study initiates with prior work review, whereby most research work done earlier was mainly simulation-based. Based on the simulation results, this paper focuses on the practical aspects of inverter design, such as the development of a power board on an Insulated Metal Substrate, a gate driver board, an interconnect board, and the main control board. An inverter physical prototype has been built and tested at 500 V and 20 kW of output power. The SiC semiconductor technology is the base of the inverter, which represents the main merit of the work. Finally, high power density, compact design, and high efficiency are shown, which are major contributions of the paper. Tests performed proved that the designed converter was operating reliably and efficiently. While a simple Sinusoidal Pulse Width Modulation (SPWM) control algorithm has been implemented, the overall performance of the inverter showed great promise for higher-power applications. Compact and high-efficiency TNPC converters are developed for meeting increasing demands of advanced energy, automotive, and industrial applications. Full article
Show Figures

Figure 1

14 pages, 6674 KB
Article
Research on Underwater Constant High-Voltage DC Switching Technology for MCSEM
by Zhibin Ren, Meng Wang, Xianhu Luo, Chentao Wang and Tailong Chen
Sensors 2024, 24(20), 6598; https://doi.org/10.3390/s24206598 - 13 Oct 2024
Viewed by 1190
Abstract
The marine controlled source electromagnetic (MCSEM) transmitter can transmit high currents near the seabed to detect the electrical structure of the seafloor. The use of three-phase alternating current (AC) transmission can lead to three-phase imbalance, which results in an excessive current in one [...] Read more.
The marine controlled source electromagnetic (MCSEM) transmitter can transmit high currents near the seabed to detect the electrical structure of the seafloor. The use of three-phase alternating current (AC) transmission can lead to three-phase imbalance, which results in an excessive current in one phase’s power line and affects the safety of the tow cable. This paper proposes an MCSEM underwater constant high-voltage direct-current (DC) switching scheme that replaces AC transmission with DC transmission. This scheme can fundamentally avoid three-phase imbalance and the AC loss caused by inductance. After establishing a simulation model to analyze the effect of the scheme, the relevant hardware units were designed. The hardware unit mainly consists of three parts: a DC switching inverter unit, a filter unit, and a step-down rectification unit. The DC inverter unit controls six insulated gate bipolar transistor (IGBT) modules with sinusoidal pulse width modulation (SPWM) signals to convert DC to three-phase AC power; the filter unit filters out extra harmonic components; and the step-down rectification unit converts high-voltage three-phase AC to low-voltage DC. The scheme ultimately achieved an adjustable DC output of 48.3–73.4 V under a constant DC input voltage of 3000 V and effectively reduced the current on the cable. This scheme has the potential to replace the previous AC transmission, reducing the risk of tow cable burnout and enhancing the safety of MCSEM operations. Full article
(This article belongs to the Section Electronic Sensors)
Show Figures

Figure 1

21 pages, 7754 KB
Article
Comparative Analysis of Space Vector Pulse-Width Modulation Techniques of Three-Phase Inverter to Minimize Common Mode Voltage and/or Switching Losses
by Kotb B. Tawfiq, Peter Sergeant and Arafa S. Mansour
Mathematics 2024, 12(18), 2832; https://doi.org/10.3390/math12182832 - 12 Sep 2024
Cited by 4 | Viewed by 4385
Abstract
Inverter-based systems encounter significant challenges in mitigating common-mode voltage (CMV) and minimizing inverter losses. Despite various space vector pulse-width modulation (SVPWM) techniques proposed to address these issues, a comprehensive comparative analysis has been lacking. This paper addresses this gap through an experimental and [...] Read more.
Inverter-based systems encounter significant challenges in mitigating common-mode voltage (CMV) and minimizing inverter losses. Despite various space vector pulse-width modulation (SVPWM) techniques proposed to address these issues, a comprehensive comparative analysis has been lacking. This paper addresses this gap through an experimental and simulation-based evaluation of nine SVPWM techniques. A new discontinuous SVPWM technique, DSVPWM-K4, is introduced, which involves reversing the use of the two zero vectors in DSVPWM-K3. DSVPWM-K3 delivers superior performance in terms of CMV reduction, total harmonic distortion (THD), and inverter losses across all modulation indices (MI = 1, 0.75, 0.5, and 0.25), making it the most effective overall. Although DSVPWM-K4 is a novel approach, it ranks second in effectiveness. The RSPWM technique achieves the lowest CMV with a zero peak-to-peak value but is most effective at lower modulation indices (0.25 and 0.5) due to higher harmonic distortion at higher modulation indices. AZSPWM performs optimally at higher modulation indices, providing a 66.66% reduction in CMV compared to continuous SVPWM and significantly lower THD compared to RSPWM. In contrast, NSPWM exhibits nearly double the THD compared to continuous SVPWM. Full article
(This article belongs to the Special Issue Control, Optimization and Intelligent Computing in Energy)
Show Figures

Figure 1

12 pages, 5630 KB
Article
Research on a New Inverter Control Strategy of Induction Heating Power Supply
by Haibo Huang, Yulin Kong, Jianfei Chen, Wei Jian, Fan Sun, Jixiang Sui and Shiqing Cheng
Electronics 2024, 13(17), 3469; https://doi.org/10.3390/electronics13173469 - 31 Aug 2024
Cited by 2 | Viewed by 1441
Abstract
To achieve “high voltage, low current” in the induction heating power circuit, enhance the flexibility of component selection in the circuit, and improve the quality of the inverter’s output waveform, a new control strategy of a single-phase NPC three-level inverter with unipolar frequency-doubling [...] Read more.
To achieve “high voltage, low current” in the induction heating power circuit, enhance the flexibility of component selection in the circuit, and improve the quality of the inverter’s output waveform, a new control strategy of a single-phase NPC three-level inverter with unipolar frequency-doubling SPWM method is proposed. With the series connection of IGBTs in a single-phase NPC three-level inverter, the voltage withstand requirement of IGBT is reduced by half. The middle four IGBTs are controlled using unipolar frequency-doubling SPWM, while the outer four IGBTs are turned on later and turned off earlier to address the neutral point voltage imbalance issue in the inverter. Simulation results show that, compared with the traditional bipolar SPWM-controlled single-phase full-bridge inverter, the DC-side input voltage of the inverter can be double, and the current flowing through the entire circuit can be halved under the same output power using the proposed method. Full article
(This article belongs to the Special Issue Advances in Power Conversion Architectures)
Show Figures

Figure 1

18 pages, 12529 KB
Article
A Novel Shunt Zigzag Double-Tap Low-Harmonic Multi-Pulse Rectifier Based on a Three-Stage Power Electronic Phase-Shifting Transformer
by Xiuqing Mu, Xiaoqiang Chen, Qianxiao Liu, Ying Wang, Tun Bai, Leijiao Ge and Xiping Ma
Sensors 2024, 24(17), 5564; https://doi.org/10.3390/s24175564 - 28 Aug 2024
Viewed by 1140
Abstract
To solve the problem of the large size of traditional industrial frequency phase-shift transformers and the harmonic distortion of multi-pulse wave rectifier systems, this paper proposes a three-stage shunt zigzag power electronic phase-shift transformer based on a double-tap multi-pulse wave rectifier, which combines [...] Read more.
To solve the problem of the large size of traditional industrial frequency phase-shift transformers and the harmonic distortion of multi-pulse wave rectifier systems, this paper proposes a three-stage shunt zigzag power electronic phase-shift transformer based on a double-tap multi-pulse wave rectifier, which combines the power factor correction (PFC) converter with the voltage-type SPWM inverter circuit to form a power electronic converter to realize the frequency boost and power factor correction. Through AC–DC–AC conversion, the frequency of the three-phase AC input voltage is increased, the number of core and coil turns in the transformer is reduced to reduce the size of the phase-shifter transformer, a zigzag structure of the phase-shifter transformer is used to solve the unbalanced distribution of current between the diode bridges, and a passive harmonic suppression method on the DC side is used to generate a loop current by using a group of single-phase rectifier bridges to regulate the input line current of the phase-shifter transformer. The phase-shifted voltage is input into two three-phase diode rectifier bridges to rectify and supply power to the load. Simulation and semi-physical test results show that the proposed method reduces the total harmonic distortion (THD) value of the input current of the phase-shifted transformer to 7.17%, and the THD value of the grid-side input current is further reduced to 2.49%, which meets the harmonic standard and realizes the purpose of power factor correction as well as being more suitable for high-power applications. Full article
(This article belongs to the Section Industrial Sensors)
Show Figures

Figure 1

14 pages, 6513 KB
Article
An Improved SPWM Strategy for Effectively Reducing Total Harmonic Distortion
by Shaoru Zhang, Huixian Li, Yang Liu, Xiaoyan Liu, Qing Lv, Xiuju Du and Jielu Zhang
Electronics 2024, 13(16), 3326; https://doi.org/10.3390/electronics13163326 - 21 Aug 2024
Cited by 4 | Viewed by 2101
Abstract
In the inverter circuit, the speed at which the MOSFET is impacted by the presence of a parasitic inductor within the printed circuit board (PCB) leads to a delay in the switching process. Furthermore, the parasitic inductor within the circuit can easily form [...] Read more.
In the inverter circuit, the speed at which the MOSFET is impacted by the presence of a parasitic inductor within the printed circuit board (PCB) leads to a delay in the switching process. Furthermore, the parasitic inductor within the circuit can easily form an LC oscillation with the parasitic capacitor of the MOSFET. These two issues result in an inconsistency between the actual output of the MOSFET and the driving signal waveform, leading to distortion in the sinusoidal pulse width modulation (SPWM) waveform and an increase in total harmonic distortion (THD). It is a common practice to mitigate gate oscillation by introducing a resistor at the gate of the MOSFET. However, elevating the resistance leads to deceleration in the charging process of the MOSFET’s parasitic capacitor, consequently causing an increase in the switching delay, and thereby increasing THD. Therefore, an effective strategy to reduce THD is proposed in this paper, while augmenting the gate resistance, computing the MOSFET switching delay, and applying corrective compensation. In this way, the inherent issues of the switch are addressed, resulting in inverter output waveforms that closely resemble sine waves and reduced THD. Through a combination of simulation and empirical experimentation, the efficacy of the proposed approach in significantly reducing THD in the inverter’s output waveform has been empirically substantiated. Full article
Show Figures

Figure 1

16 pages, 3829 KB
Article
Algorithm for Assessment of the Switching Angles in the Unipolar SPWM Technique for Single-Phase Inverters
by Mario Ponce-Silva, Óscar Sánchez-Vargas, Claudia Cortés-García, Jesús Aguayo-Alquicira and Susana Estefany De León-Aldaco
Algorithms 2024, 17(7), 317; https://doi.org/10.3390/a17070317 - 19 Jul 2024
Cited by 1 | Viewed by 2221
Abstract
The main contribution of this paper is to present a simple algorithm that theoretically and numerically assesses the switching angles of an inverter operated with the SPWM technique. This technique is the most widely used for eliminating harmonics in DC-AC converters for powering [...] Read more.
The main contribution of this paper is to present a simple algorithm that theoretically and numerically assesses the switching angles of an inverter operated with the SPWM technique. This technique is the most widely used for eliminating harmonics in DC-AC converters for powering motors, renewable energy applications, household appliances, etc. Unlike conventional implementations of the SPWM technique based on the analog or digital comparison of a sinusoidal signal with a triangular signal, this paper mathematically performs this comparison. It proposes a simple solution to solve the transcendental equations arising from the mathematical analysis numerically. The technique is validated by calculating the total harmonic distortion (THD) of the generated signal theoretically and numerically, and the results indicate that the calculated angles produce the same distribution of harmonics calculated analytically and numerically. The algorithm is limited to single-phase inverters with unipolar SPWM. Full article
(This article belongs to the Special Issue Optimization in Renewable Energy Systems)
Show Figures

Figure 1

19 pages, 44093 KB
Article
Intelligent Integration of Vehicle-to-Grid (V2G) and Vehicle-for-Grid (V4G) Systems: Leveraging Artificial Neural Networks (ANNs) for Smart Grid
by Youness Hakam, Ahmed Gaga, Mohamed Tabaa and Benachir Elhadadi
Energies 2024, 17(13), 3095; https://doi.org/10.3390/en17133095 - 23 Jun 2024
Cited by 10 | Viewed by 2568
Abstract
This paper presents a groundbreaking control strategy for a bidirectional battery charger that allows power to be injected into the smart grid while simultaneously compensating for the grid’s reactive power using an electric vehicle battery. An artificial neural network (ANN) controller is utilized [...] Read more.
This paper presents a groundbreaking control strategy for a bidirectional battery charger that allows power to be injected into the smart grid while simultaneously compensating for the grid’s reactive power using an electric vehicle battery. An artificial neural network (ANN) controller is utilized for precise design to ensure optimal performance with minimal error. The ANN technique is applied to generate sinusoidal pulse width modulation (SPWM) for a bidirectional AC–DC inverter, with the entire algorithm simulated in MATLAB Simulink.The core innovation of this study is the creation of the ANN algorithm, which supports grid compensation using electric vehicle batteries, an approach termed “vehicle-for-grid”. Additionally, the paper details the PCB circuit design of the system controlled by the DSP F28379D board, which was tested on a three-phase motor. The total harmonic distortion (THD) of the proposed ANN algorithm is approximately 1.85%, compared to the MPC algorithm’s THD of about 2.85%. This indicates that the proposed algorithm is more effective in terms of the quality of the power injected into the grid. Furthermore, it demonstrates effective grid compensation, with the reactive power effectively neutralized to 0KVAR in the vehicle-for-grid mode. Full article
(This article belongs to the Section F3: Power Electronics)
Show Figures

Figure 1

27 pages, 13538 KB
Article
A New LCL Filter Design Method for Single-Phase Photovoltaic Systems Connected to the Grid via Micro-Inverters
by Heriberto Adamas-Pérez, Mario Ponce-Silva, Jesús Darío Mina-Antonio, Abraham Claudio-Sánchez, Omar Rodríguez-Benítez and Oscar Miguel Rodríguez-Benítez
Technologies 2024, 12(6), 89; https://doi.org/10.3390/technologies12060089 - 12 Jun 2024
Cited by 9 | Viewed by 4048
Abstract
This paper aims to propose a new sizing approach to reduce the footprint and optimize the performance of an LCL filter implemented in photovoltaic systems using grid-connected single-phase microinverters. In particular, the analysis is carried out on a single-phase full-bridge inverter, assuming the [...] Read more.
This paper aims to propose a new sizing approach to reduce the footprint and optimize the performance of an LCL filter implemented in photovoltaic systems using grid-connected single-phase microinverters. In particular, the analysis is carried out on a single-phase full-bridge inverter, assuming the following two conditions: (1) a unit power factor at the connection point between the AC grid and the LCL filter; (2) a control circuit based on unipolar sinusoidal pulse width modulation (SPWM). In particular, the ripple and harmonics of the LCL filter input current and the current injected into the grid are analyzed. The results of the Simulink simulation and the experimental tests carried out confirm that it is possible to considerably reduce filter volume by optimizing each passive component compared with what is already available in the literature while guaranteeing excellent filtering performance. Specifically, the inductance values were reduced by almost 40% and the capacitor value by almost 100%. The main applications of this new design methodology are for use in single-phase microinverters connected to the grid and for research purposes in power electronics and optimization. Full article
(This article belongs to the Topic Advances in Solar Technologies)
Show Figures

Figure 1

23 pages, 8001 KB
Article
Multilevel Aircraft-Inverter Design Based on Wavelet PWM for More Electric Aircraft
by Nurbanu Catalbas, Ahmet Gungor Pakfiliz and Gokhan Soysal
Energies 2024, 17(9), 2054; https://doi.org/10.3390/en17092054 - 26 Apr 2024
Cited by 2 | Viewed by 3339
Abstract
This paper proposes a comprehensive power system designed for the use of a more electric aircraft power distribution system. Instead of traditional Nicad battery solutions as the energy source of the aircraft power system, lithium battery structures, which are a recent and promising [...] Read more.
This paper proposes a comprehensive power system designed for the use of a more electric aircraft power distribution system. Instead of traditional Nicad battery solutions as the energy source of the aircraft power system, lithium battery structures, which are a recent and promising solution in the field of aviation power systems, are modeled and analyzed. In this study, a WPWM-based, single-phase, multi-level pure sine wave static aircraft-inverter system is designed and integrated to improve the performance of conventional aircraft power systems. In the designed power system, a boost converter structure is proposed that boosts 28 VDC-to-270 VDC voltage coming from the lithium–ion battery pack and can reach a steady state in 0.032 s. The performance of the modeled WPWM-based aircraft-inverter system, compared to SPWM Bipolar and Unipolar switching techniques commonly used in single-phase inverter designs, reveals a THD reduction of approximately 27% with WPWM, resulting in a THD value below 2% for both load current and load voltage. As a result of the study, a power system that will enable the aircraft avionics, ventilation, and navigation systems to perform better than conventional power systems and comply with aircraft electric-power characteristic standards has been designed and detailed. Full article
(This article belongs to the Special Issue Power Electronics Converters for On-Board Electric Power Systems)
Show Figures

Figure 1
