Search Results (26)

The control stability and accuracy of quad tiltrotor UAVs is improved when encountering external disturbances during automatic flight by an active disturbance rejection control (ADRC) parameter self-tuning control strategy based on a radial basis function (RBF) neural network. Firstly, a nonlinear flight dynamics model of the quad tiltrotor UAV is established based on the approach of component-based mechanistic modeling. Secondly, the effects of internal uncertainties and external disturbances on the model are eliminated, whilst the online adaptive parameter tuning problem for the nonlinear active disturbance rejection controller is addressed. The superior nonlinear function approximation capability of the RBF neural network is then utilized by taking both the control inputs computed by the controller and the system outputs of the quad tiltrotor model as neural network inputs to implement adaptive parameter adjustments for the Extended State Observer (ESO) component responsible for disturbance estimation and the Nonlinear State Error Feedback (NLSEF) control law of the active disturbance rejection controller. Finally, an adaptive attitude control system for the quad tiltrotor UAV is constructed, centered on the ADRC-RBF controller. Subsequently, the efficacy of the attitude control system is validated through simulation, encompassing a range of flight conditions. The simulation results demonstrate that the Integral of Absolute Error (IAE) of the pitch angle response controlled by the ADRC-RBF controller is reduced to 37.4° in comparison to the ADRC controller in the absence of external disturbance in the full-states mode state of the quad tiltrotor UAV, and the oscillation amplitude of the pitch angle response controlled by the ADRC-RBF controller is generally reduced by approximately 50% in comparison to the ADRC controller in the presence of external disturbance. In comparison with the conventional ADRC controller, the proposed ADRC-RBF controller demonstrates superior performance with regard to anti-disturbance capability, adaptability, and tracking accuracy. Full article

This work explores enhancing rear cabin suspension in vehicles using hydro-pneumatic shock absorbers to maintain the cabin position regardless of load and improve safety by mitigating oscillation impacts. Advanced solutions employ pneumatic elastic elements with automatic adjustment, addressing classic suspension disadvantages like variable cab position and natural frequency with load changes. The experimental analysis of reinforced rubber samples from the air socket material involved tensile testing and scanning electron microscopy. The tensile results showed a clear trend: weak reinforced samples (L, T) were ductile but had a lower strength, while the ones on the reinforcing direction (D_45, D_60) exhibited a significantly increased strength and stiffness, with D_60 being the strongest but least ductile. Stress–strain curves visually confirmed these mechanical behaviors. Crucially, SEM images of fracture surfaces consistently revealed widespread fiber pull out. This indicates that weak interfacial adhesion between the reinforcing fibers and the rubber matrix is a primary limiting factor for the composite′s overall strength. Full article

Virtual synchronous generator (VSG) control, which can provide inertia output, damp power oscillations, and offer frequency and voltage support to power grids, has become a growing trend in the control field of wind power generation. As a new technology, there are still challenges that VSG control has not solved well, such as transient overvoltage suppression. A kind of transient overvoltage, which often occurs during the commutation failures of HVDC transmission systems, will trigger a mass of wind turbine generators (WTGs) disconnecting from grids. To reduce the grid-disconnection risk of the virtual synchronous generator control-based doubly fed induction generators (VSG-DFIGs), this paper first analyzes the mechanism of the automatic voltage regulation (AVR) control usually employed by VSG-DFIGs, then proposes measures to suppress the transient overvoltage. To solve the problem of the reactive power response lag issued by VSG-DFIGs, which will further aggravate the transient overvoltage in continuous low and high voltage faults, the time constant of the AVR control is switched. To fully exploit the potential of the DFIGs’ reactive power support, the droop coefficient of the AVR control is switched during the abnormal voltage stages. The switched droop coefficient will change the rotor excitation current magnitude, thus adjusting the internal potential of a DFIG, finally better supporting or suppressing the terminal voltage during the low or high voltage periods. Simulation results based on the DIgSILENT/PowerFactory platform demonstrate that the proposed method can effectively suppress the transient overvoltage that occurs in continuous low and high voltage events caused by the commutation failures of HVDC transmission systems, reducing the number of WTGs disconnecting from the grids. Full article

The primary goal of enhancing automatic generation control (AGC) in interconnected multi-area power systems is to ensure high-quality power generation and reliable distribution during emergencies. These systems still struggle with consistent stability and effective response under dynamic load conditions despite technological advancements. This research introduces a secondary controller designed for load frequency control (LFC) to maintain stability during unexpected load changes by optimally tuning the parameters of a Proportional–Integral–Derivative (PID) controller using pelican optimization algorithm (POA). An interconnected power system for ith multi-area is modeled in this study; meanwhile, for determining the optimal PID gain settings, a four-area interconnected power system is developed consisting of thermal, reheat thermal, hydroelectric, and gas turbine units based on the ith area model. A sensitivity analysis was conducted to validate the proposed controller’s robustness under different load conditions (1%, 2%, and 10% step load perturbation) and adjusting nominal parameters (R, T_p, and T_ij) within a range of ±25% and ±50%. The performance response indicates that the POA-optimized PID controller achieves superior performance in frequency stabilization and oscillation reduction, with the lowest integral time absolute error (ITAE) value showing improvements of 7.01%, 7.31%, 45.97%, and 50.57% over gray wolf optimization (GWO), Moth Flame Optimization Algorithm (MFOA), Particle Swarm Optimization (PSO), and Harris Hawks Optimization (HHO), respectively. Full article

Conveyor belts serve as the primary mode of ore transportation in mineral processing plants. Feeders, comprised of shorter conveyors, regulate the material flow from silos to longer conveyor belts by adjusting their velocity. This velocity manipulation is facilitated by automatic controllers that gauge the material weight on the conveyor using scales. However, due to positioning constraints of these scales, a notable delay ensues between measurement and the adjustment of the feeder speed. This dead time poses a significant challenge in control design, aiming to prevent oscillations in material levels on the conveyor belt. This paper contributes in two key areas: firstly, through a simulation-based comparison of various control techniques addressing this issue across diverse scenarios; secondly, by implementing the Smith predictor solution in an operational plant and contrasting its performance with that of a single PID controller. Evaluation spans both the transient flow rate during step change setpoints and a month-long assessment. The experimental results reveal a notable increase in production by 355 t/h and a substantial reduction in flow rate oscillations on the conveyor belt, evidenced by a 55% decrease in the standard deviation. Full article

This paper presents a newly implemented self-tuning PID controller that uses a relay feedback identification using a recently designed relay shifting method to determine the mathematical model of the process and subsequently adjust the controller parameters. The controller is applicable to proportional and integrating systems and is even applicable to systems with transport delays if steady-state oscillation can be achieved in the relay control of the system. After briefly introducing the relay shifting method, the current paper describes the hardware (HW) and software (SW) of the proposed controller in detail. The relay feedback identification and control of a laboratory setup by an automatically tuned controller is demonstrated on a real laboratory device called “Hot air tunnel”. The evaluation of the experiment and the characteristics of the controller are presented at the end of the paper. The advantage of the relay method is that it is not as computationally intensive as other identification methods. It can thus be implemented on more energy-efficient microcontrollers, which is very important nowadays. Full article

Positioning applications are very important in a variety of industrial processes, including automatic assembly. This paper proposes a technique for positioning applications that involves employing a platform subjected to planar oscillations along circular, elliptical, and complex trajectories. Dynamic and mathematical models of the motion of a part on the platform were developed to investigate the motion characteristics of the part. The research showed that when the platform was excited in two perpendicular directions by sinusoidal waves, different trajectories of the part’s motion could be obtained by controlling excitation parameters such as the frequencies and amplitudes of the waves and the phase shift between the waves. Furthermore, by adjusting these parameters, the average displacement velocity of the part could be controlled. The results demonstrate that the part can be moved in any direction at a given velocity and can be subjected to complex dense positioning trajectories. Therefore, such a platform can be applied in feeding, positioning, and manipulation tasks. Full article

Load frequency control (LFC) serves as a crucial component of automatic generation control in renewable energy power systems. Its primary objective is to maintain a balance between the output power of generators and the load demand, thereby ensuring system frequency stability. However, integrating renewable energy sources into power systems brings forth several challenges, such as low power quality and poor system stability due to their uncontrollable nature. To enhance the response speed, stability, and disturbance rejection capabilities of LFC, a novel fractional-order active disturbance rejection controller (NFOADRC) based on an improved marine predator algorithm (IMPA) has been designed in this paper. By leveraging the wide frequency-response range and non-local memory of NFOADRC, a more precise prediction and compensation of rapid oscillations in the system can be achieved. Additionally, the IMPA can be utilized for efficient parameter tuning, enabling a more accurate adjustment of the controller. Subsequently, the combined application of these approaches can be applied to two-area interconnected power systems with a solar thermal power plant (STPP) and a five-area interconnected power system including a wind turbine generator (WTG), photovoltaic (PV) cells, hydro turbine, and gas turbine. The simulation results confirm that the proposed control strategy effectively minimizes the undershoot and overshoot of frequency deviation in the power system. It achieves a faster stabilization of the load frequency, leading to enhanced power quality. Full article

This article proposes a deformable water-mobile robot that can be used for rescue work. The robot body adopts an open-motion chain structure with two degrees of freedom, including two drive modules and one main control module. The three modules are connected through deformation joints, and each drive module is equipped with an underwater thruster. The robot can obtain a triangle, linear shape, curved shape, and U-shape through deformation and have three types of motion: linear shape motion, U-shaped motion, and curved shape motion. In the linear shape, a multi-island genetic algorithm was used to optimize the structural parameters with the minimum resistance and the maximum volume. Floating state analysis was conducted in the U-shape, and the structural parameters were reasonably designed. By experimenting with the robot prototype on water, the robot can achieve oscillating, linear, U-shaped, and horizontal rotary motion, has an automatic adjustment function, and effective buoyancy meets the required requirements. Full article

Hoppers for unloading bulk materials are an indispensable feature of many technological machines and not only those employed in agricultural production. One of the problems in the operation of hoppers is the appearance of dynamic arches which make the outflow of grain uneven. Experimental studies have previously shown that the formation of dynamic arches creates an uneven outflow of grain along the vertical zones of outlet hoppers. This can lead to the processing mode violation of bulk material and loss of machine productivity. This paper theoretically shows that the use of arch-breaking devices with an element oscillating in the grain layer requires systems for automatic adjustment of oscillation frequency. This complicates the design and makes it more expensive. It is proposed to amend the type of material outflow as it moves along the hopper’s height to solve this problem. The possibility of employing this approach has been tested on the use of a bulk material flow separator in the outlet hopper. The bulk material flow separator is made in a plate form and is installed rigidly between two opposite walls of the outlet hopper. Thus, the volume of the hopper is divided into two vertical equal parts. With the help of experimental studies, it was determined that the lower side of the bulk material flow separator should be at a distance of 0.3 of the total hopper height from the discharge opening, while the upper side of the separator should be at a distance of 0.25 of the hopper’s height from the top edge of the hopper. The experimental verification of flow separator use confirmed its effectiveness. Full article

The actuators needed for autonomous microfluidic devices have to be compact, low-power-consuming, and compatible with microtechnology. The electrochemical actuators could be good candidates, but they suffer from a long response time due to slow gas termination. An actuator in which the gas is terminated orders of magnitude faster has been demonstrated recently. It uses water electrolysis performed by short voltage pulses of alternating polarity (AP). However, oxidation of Ti electrodes leads to a rapid decrease in the performance. In this paper, we demonstrate a special driving regime of the actuator, which is able to support a constant stroke for at least 10${}^5$ cycles. The result is achieved using a new driving regime when a series of AP pulses are interspersed with a series of single-polarity (SP) pulses. The new regime is realized by a special pulse generator that automatically adjusts the amplitude of the SP pulses to keep the current flowing through the electrodes at a fixed level. The SP pulses increase the power consumption by 15–60% compared to the normal AP operation and make the membrane oscillate in a slightly lifted position. Full article

Due to the increase in electricity and diesel costs, solar photovoltaic pumping systems have become a good solution, especially in rural areas. This work presents a standalone photovoltaic (PV) water pumping system (PVWPS) driven by an induction motor without energy storage to improve the pumping system’s performance. First, a comparison is made between two types: perturb and observe (P&O) method and incremental conductance (INC) MPPT method with a variable step size that is automatically adjusted. Studying these two techniques helps to understand which one can result in a system with less oscillation and greater efficiency when tracking the maximum power point from the PV panel under sudden irradiation conditions. This MPPT works on the operating duty cycle of the boost converter. Then, that converter combines with a voltage source inverter (VSI) to convert DC power to AC power. Second, we use indirect field-oriented control (IRFOC), which drives the three-phase of an induction motor in turn to run the centrifugal pump. The simulation results of this work were obtained using the MATLAB Simulink platform. Full article

In this paper, a model predictive controller based on a generator model for prediction purposes is proposed to replace a standard generator controller with a stabilizer of a power system. Such a local controller utilizes an input-output model of the system taking into consideration not only a generator voltage $U_g$ but also an additional, auxiliary signal (e.g., $\alpha$, $P_g$, or ${\omega }_g$). This additional piece of information allows for taking oscillations into account that occur in the system and minimizing their impact on the overall system performance. Parameters of models used by the controller are obtained on the basis of the introduced black-box models both for a turbine and a synchronous generator, parameters of which are estimated in an on line fashion using a RLS method. The aim of this paper is to compare the behavior of the classical generator control system with a power system stabilizer and a model predictive control with an additional feedback signal. The novelty of the paper is related to the use of the predictive controller instead of the classical controller/stabilizer system and its possibility of stabilizing the power system. Contrary to the solutions found in the literature, which are commonly-based on a fuzzy logic approach, the authors propose the use of an adaptive model predictive controller, which takes advantage of the knowledge concerning the plant in the form of a model and adapts itself to the operating point of the system using the model parameters estimation mechanism. Moreover, the adaptive predictive controller, unlike other solutions, automatically adjusts signal levels to changes in the plant. The proposed solution is able to calculate the best control signal regardless of whether these changes of the plant are caused by a change in the operating point, or resulting from operation, e.g., wear of mechanical parts. Full article

Soil water content (SWC) is a vital parameter for understanding crop growth and the soil nutrient water cycle. Monitoring SWC without inserting sensors into the soil, which can break the soil structure, has previously been a significant challenge for scientists. In this study, we developed a non-inserted portable frequency domain reflection (NIP-FDR) instrument to monitor SWC continuously and automatically. The working technique of this instrument was based on the improved adjustable high-frequency oscillation method originating from the frequency domain reflection principle. Compared to the control SWC measurement instrument, the difference in SWC at 0–10 cm, 10–20 cm, and 20–30 cm depth was within 1%, 3%, and 15%, respectively, and the mean variation of SWC was less than 5% in the indoor measurements. In the field verification experiment conducted in the summer of 2020, the mean error of SWC measurements at a depth of 0–20 cm was 5%, while we failed to compare SWC at a depth of 20–30 cm due to low variability in the SWC measurement at this depth during the summer measurement period. This pioneer NIP-FDR was able to effectively monitor surface SWC, especially at depths of 0–20 cm. Full article

This paper presents a prototype of an auto-ranging phase-locked loop (PLL) with low jitter noise over a wide operating frequency range using the multiband programmable voltage-controlled oscillator (VCO) gain stage with automatic band selection. We successfully reduce the VCO gain (Kvco) and retain the desired frequency band. The proposed PLL comprises a prescaler, phase frequency detector (PFD), charge pump (CP), programmable VCO and automatic band selection circuit. The PLL prototype with all subblocks was implemented using the TSMC 0.18 μm 1P6M process. Contrary to conventional PLL architectures, the proposed architecture incorporates a real-time check and automatic band selection circuit in the secondary loop. A high-performance dual-loop PLL wide tuning range was realized using an ASIC digital control circuit. A suitable way to maintain the Kvco low is to use multiple discrete frequency bands to accommodate the required frequency range. To maintain a low Kvco and fast locking, the automatic frequency band selection circuit also has two indigenous, most probable voltage levels. The proposed architecture provides the flexibility of not only band hopping but also band twisting to obtain an optimized Kvco for the desired output range, with the minimum jitter and spurs. The proposed programmable VCO was designed using a voltage-to-current-converter circuit and current DAC followed by a four-stage differential ring oscillator with a cross-coupled pair. The VCO frequency output range is 150–400 MHz, while the input frequency is 25 MHz. A sequential phase detection loop with a negligible dead zone was designed to adjust fine phase errors between the reference and feedback clocks. All circuit blocks of the proposed PLL were simulated using the EDA tool HSPICE and layout generation by Laker. The simulation and measured results of the proposed PLL show high linearity, with a dead zone of less than 10 pV. The differential VCO was used to improve the linearity and phase noise of the PLL. The chip measured results show rms jitter of 19.10 ps. The PLL prototype also has an additional safety feature of a power down mode. The automatic band selection PLL has good immunity for possible frequency drifting due to temperature, process and supply voltage variations. The proposed PLL is designed for −40 to +85 °C, a wide temperature range. Full article
