Search Results (33)

This paper proposes an improved analytical model for a line-start explosion-proof magnet synchronous motor that considers the effect of magnetic bridge saturation. Under the condition of maintaining the air-gap magnetic field unchanged, and taking into account the topological structures of embedded magnets, squirrel cages, and rotor slot openings, a subdomain model partitioning method is systematically investigated. Considering the saturation effect of the magnetic bridge of the rotor, the equivalent magnetic circuit method was utilized to calculate the permeance of the saturated region. It not only facilitates the establishment of subdomain equations and corresponding subdomain boundary conditions, but also ensures the maximum accuracy of the equivalence by maintaining the topology of the rotor. The motor was partitioned into subdomains, and in conjunction with the boundary conditions, the Poisson equation and Laplace equation are solved to obtain the electromagnetic performance of the motor. The accuracy of the analytical model is verified through finite element analysis. The accuracy of the analytical model is verified through finite element analysis (FEA). Compared to the FEA, the improved model maintains high precision while reducing computational time and exhibiting better generality, making it suitable for the initial design and optimization of industrial motors. Full article

An area of study for reluctance motors is the analytical computation of their magnetic field distribution, from which other quantities, such as phase inductances and output torque, may be derived. While numerical or iterative methods exist, analytical derivations of reluctance motor magnetic fields from first principles result in solutions that are less time-consuming to implement while requiring only the motor dimensions, without the need to re-discretize the motor model. A discussion of analytical derivations is scarce in the current literature, whose focus is usually on their direct application in various motor models. This work, then, aims to review and examine the major mathematical techniques and assumptions used to derive the magnetostatic field distribution in reluctance motors. The methods under review are air gap permeance, magnetic potential, and conformal mapping techniques, and they are applied to machines with conventional structures. Other relevant approaches that can extend these techniques are also presented. Segmented motor designs have also emerged given their advantages, so they must be systematically studied. These segmented topologies may require a new set of boundary conditions before these techniques can be applied. Thus, the methods’ possible avenues of application to segmented motors are discussed as well. Full article

This paper proposes an E-core outer-rotor hybrid-excitation flux switching (OR-HEFS) machine for in-wheel direct driving application. According to the general air gap field modulation theory, the magneto-motive force (MMF) permeance model was established to investigate the air gap flux density, and then the torque generation, the flux regulation principle, and the excitation-winding-induced voltage of the E-core OR-HEFS machine were analyzed. To characterize the output performances, the influence of the design parameters was investigated for the E-core OR-HEFS machine, including the split ratio, stator tooth arc, PM arc, fault-tolerant tooth arc, rotor tooth arc, stator yoke width and rotor yoke width. The performances contained the output torque, torque ripple, flux regulation ratio, and the excitation-winding-induced voltage. On this basis, the aforementioned four performances were optimized by means of the non-dominated sorting genetic algorithm II (NSGA-II). Based on the optimization result, a prototype was manufactured and tested to verify the whole investigation of this paper. Full article

An axial field hybrid excitation synchronous generator (AF-HESG) is proposed for an independent power supply system, and its electromagnetic performance is studied in this paper. The distinguishing feature of the proposed generator is the addition of static magnetic bridges at both ends to place the field windings and the use of a sloping surface to increase the additional air-gap cross-sectional area. The advantage of the structure is that it achieves brushless excitation and improves the flux-regulation range. The structure and magnetic circuit characteristics are introduced in detail. Theoretical analysis of the flux-regulation principle is conducted by studying the relationship between field magnetomotive force, rotor reluctance, and air-gap flux density. Quantitative calculation is performed using a magnetomotive force (MMF)-specific permeance model, and the influence of the main parameters on the air-gap flux density and flux-regulation range is analyzed. Subsequently, magnetic field, no-load, and load characteristics are investigated through three-dimensional finite element analysis. The loss distribution is analyzed, and the temperature of the generator under rated conditions is simulated. Finally, a 30 kW, 1500 r/min prototype is developed and tested. The test results show good flux-regulation capability and stable voltage output performance of the proposed generator. Full article

Winding inductance always plays a key role in the electromagnetic performances of stator surface-mounted permanent magnet (SSPM) machines, including their flux-weakening capability, prospective fault current, power factor, current ripple, etc. Generally speaking, winding inductance mainly comprises three components: an air-gap component, a slot-leakage component, and an end-leakage component. In this paper, firstly, the winding pole pairs of SSPM machines are investigated based on the magneto-motive force-permeance model, through which the winding configurations can also be determined. Then, according to the winding configurations, three analytical expressions for each inductance component are derived to evaluate the winding inductance per phase. In addition, finite element analysis (FEA) is employed to verify the effectiveness of the derived analytical expressions. Meanwhile, three prototyped SSPM machines are manufactured, and their winding inductances are measured to further verify the analytical expressions. The measured results agree with both the analytical and FEA results very well. Full article

Due to the configuration of coreless stators and two synchronously rotated rotors, hollow-cup machines (HCMs) enjoy the merits of negligible cogging torque and core loss. Consequently, HCMs have been successfully employed as high-speed electric machines in the aerospace field, which requires high precision and low thermal dissipation. However, the permanent magnet (PM) thickness and air-gap length of conventional HCM are uniform, resulting in various harmonics in the air-gap flux density as well as back-EMF. These harmonics inevitably produce an electromagnetic torque ripple, which has not met the increasing demand for ultraprecision in recent years. Since the inner rotor of HCMs only consists of an iron core, this paper proposes a novel sinusoidal-shaped inner rotor, which can change the harmonics of air-gap permeance, to adjust the harmonics of air-gap flux density and back-EMF. HCMs with the proposed inner rotors have a significant 87% reduction in torque ripple compared to conventional HCMs. Meanwhile, compared to conventional methods, HCMs with the proposed inner rotor exhibit comparable torque ripple and higher average torque. Full article

This article presents a detailed study on the diagnosis of rotor faults in an Interior Permanent Magnet Machine based on a mathematical model. The authors provided a wide literature review, mentioning the fault diagnosis methods used for Permanent Magnet Machines. The research emphasizes the necessity of precise assumptions regarding winding construction to accurately analyze the additional harmonics appearing in rotor faults caused by electromotive force (EMF), i.e., rotor eccentricity and magnet damage. The article also discusses specific features appearing in the spectrum of air gap permeance functions and the impact of rotor eccentricity and magnet damage on PM flux density distribution and as a consequence on EMF stator windings. The novelty of the presented content is the analysis of induced EMFs for cases of the simultaneous occurrence of rotor eccentricity and PM damage. The findings of this study provide valuable insights for the diagnosis and understanding of internal asymmetries in Interior PM Machines. Full article

The slot opening function, also called relative air gap permeance, is a function which, multiplied by the flux density distribution of a slotless geometry, gives the flux density distribution of a slotted configuration. Here, the magnetic field inside the air gap of a multi-slot surface facing a smooth one was studied, by solving the Laplace equation inside the air gap, in terms of a Fourier series. To obtain the Fourier coefficients, at first, the conformal mapping analytical solution of a single-slot configuration along the smooth surface, was considered. Then, the principle of superposition of the single-slot lost flux density distributions was applied to obtain the multi-slot distribution. The approach is valid in general, and in the case of interference among the flux density distributions of adjacent slots, where their mutual effect cannot be neglected. The field distributions obtained by using the proposed slot opening functions were compared with FEM simulations, showing satisfactory agreement. The numerical accuracy limits were also analysed and discussed. Full article

In this paper, the oscillation phenomena of the scalar magnetic potential of iron pieces of spoke permanent magnet (PM) machines are analyzed and the effects of the oscillation on the air gap flux and back electro-motive force (EMF) are deeply investigated, especially for flux modulation machines such as vernier and flux switching PM (FSPM) machines. To these ends, the formula of the scalar magnetic potential is derived for a generalized spoke PM structure. It reveals that the oscillation phenomena depend on the slot/pole combination, consequently resulting in different behavior according to the machine types such as vernier and FSPM machines. Next, each core’s potential given as a discrete function is developed into a continuous function of an air gap magneto-motive force (MMF) rotating and oscillating through Fourier series expansion. Making use of the developed MMF and the specific permeance of air gap, the equations of air gap flux density and back EMF are derived, which enable accurately estimating the suppression of the modulation flux and the back EMF due to the potential oscillation for different types of spoke PM machines. For validation, various magnetic characteristics are quantitatively examined for different type of spoke PM structures, including PM vernier and FSPM machines, and verified by comparing with FEM simulation results. Full article

Analytical prediction of cogging torque needs accurate flux density and relative permeance closed-form expressions. The accurate two-dimensional (2D) air gap flux density distribution function and the 2D permeance function are currently almost always applied to surface-mounted permanent magnet (SPM) machines, instead of interior permanent magnet (IPM) machines, due to complications from IPMs severe magnetic saturation and leakage flux. To address these issues, this paper proposes a set of new methods to derive the accurate closed-form 2D expressions of IPMs for both flux density and relative permeance. As for the flux density 2D model, a virtual equivalence model for IPM is introduced, so that Laplace’s equation and quasi-Poisson equation can be directly applied to IPM. As for permeance, the same virtual equivalence model also enables 2D models derivation for IPM. Subsequently, the resulting cogging torque analytical expression is obtained with the accurate relative permeance and air gap flux density models. The results from the proposed 2D analytical models showed similar accuracy to the finite element analysis (FEA). In addition, as demonstrated, the proposed 2D analytical models is a highly efficient tool set in the design process of cogging torque optimization, facilitating fast evaluation of different design factors. Full article

Based on the discovery of the surge absorption capability of supercapacitors, a transient protector named supercapacitor-assisted surge absorber (SCASA) was designed and implemented in a commercial device. Despite its simplicity, the circuit topology consisted of a coupled inductor wound around a specially selected magnetic core. This paper elucidates the design aspects of SCASA coupled-inductor topologies with a special focus on the magnetic action of core windings during transient propagation. The non-ideal operation of the SCASA transformer was studied based on a semi-empirical approach with predictions made by using magnetizing and leakage permeances. The toroidal flux distribution through the transformer was also determined for a 6 kV/3 kA combinational surge, and these findings were validated by using a lightning surge simulator. In predicting the possible effects of magnetic saturation, the hysteresis properties of different powdered-iron and ferrite core types were considered to select the optimal design for surge absorption. The test results presented in this research revealed that X-Flux powdered-iron toroid and air-gapped EER ferrite yielded exceptional performance with ∼10% and ∼20% lower load–voltage clamping compared to that of the existing Kool $\mathsf{\mu }$u design. These prototypes further demonstrated a remarkable surge endurance, withstanding over 250 consecutive transients. This paper also covers details of three-winding design optimizations of SCASA and LTSpice simulations under the IEC 61000/IEEE C62.45 standard transient conditions. Full article

In order to analyze the DC winding induced voltage in the wound-rotor synchronous machine, this paper uses the air-gap field modulation principle to investigate its operation mechanism and harmonic order. By establishing the analytical magneto-motive force (MMF)-permeance model, the DC winding induced voltage per electrical cycle under open-circuit condition, armature reaction condition and on-load condition are deduced. Analytical analysis shows that the MMF function, stator and rotor permeance function are critical factors that influence the harmonic order of the DC winding induced voltage. The analysis results are compared with those predicted by the finite element analysis (FEA). Both non-linear steel and linear steel conditions are accounted in the FEA analysis, and the results show that the analytical deduction result agrees well with the FEA analysis result. Full article

Aiming to design a generator with high reliability, high efficiency, and especially a constant output voltage over a wide speed range for hybrid electric vehicles (HEVs), this paper proposes a novel topology of a hybrid excitation doubly salient generator with separate windings (HEDSGSW). The topology herein utilizes a hybrid excitation type of PMs and DC windings to generate parallel magnetic circuits. In addition, PMs are embedded in the magnetic bridge to insulate the excitation windings with armature windings. This design can achieve compactness, efficiency, and especially constant output capability over a wide speed range. The geometry and flux regulation principles, including magnetic flux circuits, are elaborated. After comparing three power generation modes, the most suitable mode, namely, the doubly salient generation 2 (DSG2) mode, is confirmed to ensure a stable voltage output performance. Then, considering the non-uniformity effect of the stator and rotor slots, the no-load back electromotive force (EMF) expressions are derived based on the EMF to air-gap relative permeance method. Furthermore, a 1 kW HEDSGSW FEA model, with an output voltage of 42 V and a rated speed of 6000 rpm, is built to demonstrate the effectiveness of the proposed method. Finally, the operating properties of the HEDSGSW, such as no-load characteristics and adjustment characteristics, are analyzed to further verify the rationality of its magnetic flux circuit and the flexibility of the excitation regulation capability. Full article

The use of a magnetic adjustable speed drive is a popular choice in industrial settings due to its efficient operation, vibration isolation, low maintenance, and overload protection. Most conventional magnetic adjustable speed drives use various forms of the permanent magnets (PMs). Due to the PMs, this type of machine has continuous free-wheeling losses in the form of hysteresis and induced eddy currents. In recent years, the homopolar-type rotor has been widely used in high-speed machines, superconducting machines, and in the application of flywheel energy storage. This study proposes a new application of the homopolar-type rotor. A novel adjustable speed drive with a homopolar-type rotor (HTR-ASD), which has obvious advantages (no brush, no permanent magnet, and no mechanical flux regulation device), is designed and analyzed in this study. Its speed and torque can be adjusted only by adjusting the excitation current. Firstly, in this study, the structure, operation principles, and flux-modulated mechanism of the HTR-ASD are studied. The homopolar-type rotor has a special three-dimensional magnetic circuit structure with the same pole. The 3D-FEM is usually used to calculate its parameters, which is time consuming. In this study, an analytical method is developed to solve this issue. To analytically calculate the torque characteristics, the air gap magnetic flux density, and the winding inductance parameter, the equivalent circuit and the air gap permeance are researched to simplify the analysis. Then, the key parameters of the HTR-ASD are calculated. Finally, the performance of the HTR-ASD is comparatively studied using the analytical method and finite element method, and a comparison of the results is carried out. The comparison indicates that the analytical method is in good agreement with simulation results, and that it is very helpful for designing homopolar-type rotor machines. According to the analysis, the proposed adjustable speed drive displays a great performance in relation to the operating characteristics of a flexible mechanical speed drive. Full article

This paper proposes a modelling technique for Synchronous Reluctance Motors (SynRMs) based on a generalized Magnetic Equivalent Circuit (MEC). The proposed model can be used in the design of any number of stator teeth, rotor poles, and rotor barrier combinations. This technique allows elimination of infeasible machine solutions during the initial machine sizing stage, resulting in a lower cohort of feasible machine solutions that can be further optimized using finite element methods. Therefore, saturation effects, however, are not considered in the modelling. This paper focuses on modelling a generic structure of the SynRM in modular form and is then extended to a full SynRM model. The proposed model can be iteratively used for any symmetrical rotor pole and stator teeth combination. The developed technique is applied to model a 4-pole, 36 slot SynRM as an example, and the implemented model is executed following a time stepping strategy. The motor characteristics such as flux distribution and torque of the developed SynRM model is compared with finite elemental analysis (FEA) simulation results. Full article
