In conventional gasoline automobiles, the engine powers the air conditioning system and engine noise can somewhat mask the noise and vibration of the air conditioning system. In pure electric vehicles, however, the absence of an engine makes the air conditioning system’s noise more noticeable, concentrated in a limited frequency range at constant speeds. As a result, aerodynamic noise from the air conditioning system is a primary noise source in electric vehicles. Pipeline silencers are the main method for reducing this noise. The current silencer design uses plane wave acoustic theory but when cavity modal resonance occurs, the transmission loss error is relatively high. This article addresses the issue of non-planar wave cavity resonance, studying the cavity modal of a muffler using the finite element method to reveal the transmission loss under cavity mode resonance. A dual cavity expansion structure of an impedance composite muffler is proposed, with sound-absorbing materials placed in the cavity to enhance acoustic performance. The analysis of the transmission loss characteristics of the impedance composite muffler provides a theoretical basis for noise control in pure electric vehicle air conditioning systems. Full article

Despite the rapid development of vehicle intelligent technology, the aerodynamic noise problem of internal combustion engine vehicles and pure electric vehicles at high speed has always been a growing problem. In this study, the effects of the car body fender shape on the aerodynamic noises of the rearview mirror and wheel region were investigated, and a noise reduction method was also proposed by optimizing the fender shape. To realize the parametric modeling of the fender, five positional variables were selected to define the fender configuration; the free-form deformation (FFD) method was used to establish the response fender model according the DOE schemes, and computational fluid dynamics (CFD) simulations are used to obtain the noise results. Then, with the help of the radial basis function (RBF) model and the adaptive simulated annealing (ASA) algorithm, the aerodynamic shape of the fender was optimized to reduce aerodynamic noise. Comparative analysis was then employed to assess flow field characteristics of the optimized model against the original model and elucidate the fender configuration’s contribution to aerodynamic noise reduction and its realization mechanism. Full article

Aerodynamic characteristics are of great significance to the fuel economy and handling the stability of electric vehicles. The battery pack of electric vehicles has a huge structure and is usually arranged in the chassis area of the vehicle, which inevitably occupies the space at the bottom of the vehicle and affects the aerodynamic characteristics of the vehicle. To study the effect of the power battery pack installed in the chassis on the aerodynamics characteristics of the electric vehicle, the Computational Fluid Dynamics (CFD) method is used to study the flow and pressure fields of the SAE (Society of Automotive Engineers) hierarchical car model with battery packs mounted on chassis. The influence of the structure parameters of the battery pack on the automobile’s aerodynamics are also analyzed in detail. Based on the simulation results, it can be seen that the battery pack installed on the chassis has a great impact on the flow and pressure field at the bottom and tail of the vehicle, causing the drag coefficient and lift coefficient to increase. The structural parameters of the battery pack have contradictory effects on the drag and lift coefficients. As the length of the battery pack increases, the drag coefficient decreases, and the lift coefficient increases. As the battery pack width and height increase, the drag coefficient increases, and the lift coefficient decreases. The research results provide a reference for the optimization of the aerodynamic characteristics of electric vehicles with battery packs mounted on chassis. Full article

In motorsports, the correct design of every device that constitutes a vehicle is a significant task for engineers because the car’s efficiency on the track depends on making it competitive. However, the physical integrity of the pilot is also at stake, since a bad vehicle design can cause serious mishaps. To achieve the correct development of a front wing for a single-seater vehicle, it is necessary to adequately simulate the forces that are generated on a car to evaluate its performance, which depends on the aerodynamic forces of the front wing that are present due to its geometry. This work provided a new design and evaluation through the numerical analysis of three new front wings for single-seater vehicles that comply with the regulations issued by the International Automobile Federation (FIA) for the 2022 season. Additionally, a 3D-printed front wing prototype was developed to be evaluated in an experimental study to corroborate the results obtained through computer simulations. A wind tunnel experiment test was performed to validate the numerically simulated data. Also, we developed a numerical simulation and characterization of three front wings already used in Formula One from a previous season (the end of the 2021 season). This work defined how these devices perform, and in the same way, it identified how their evolution over time has provided them with substantial benefits and greater efficiency. All the numerical simulations were carried out by applying the Finite Volume Method, allowing us to obtain the values of the aerodynamic forces that act on the front wing. Also, it was possible to establish a comparison between the three newly designed proposals from the most aerodynamic advantages to produce a prototype and perform an experimental test. The results of the experimental test showed similarity to those of the numerical analyses, making it clear that the methodology followed during the development of the work was correct. In addition, the mechanical designs carried out to develop the front wing can be considered ideal, because the results showed that the front wing could be competitive, and applying it caused a downforce to be favored that prevented the car from being thrown off the track. Additionally, the results indicate this is an effective proposal for use in a single-seater vehicle and that the design methodology delivers optimal results. Full article

Titanium silicon carbide (Ti₃SiC₂) is a novel composite material that has found a multitude of uses in the aerodynamics, automobile, and marine industries due to its excellent properties such as high strength and modulus, high thermal and electrical conductivity, high melting point, excellent corrosion resistance, and high-temperature oxidation resistance. These properties are strongly associated with physical properties and microstructural features. Due to difficulties in the synthesis of this material, there have been very few investigations on the relationship between microstructure and physical characteristics of titanium silicon carbide composites processed through powder metallurgical process. However, the importance of thermal conductivity and electrical conductivity of titanium silicon carbide composites in various potential applications has led to keen attention from several researchers. Hence, in this paper, optimization, and prediction of process input parameters during processing under vacuum sintering for achieving maximum electrical and thermal conductivity of Ti-6Al-4V-SiC(15 Wt.%) has been presented. Using Taguchi’s L₉ Orthogonal Array, it has been observed that aging temperature (1150 °C), aging time (four hours), heating rate (25 °C/min), and cooling rate (5 °C/min) result in optimum input parameters for achieving the highest electrical conductivity values during the processing of Ti-6Al-4V-SiCp composites. Further, for maximum thermal conductivity values during the processing of Ti-6Al-4V-SiCp composites, aging temperature (1150 °C), aging time (four hours), heating rate (5 °C/min), and cooling rate (5 °C/min) are preferred. A second-order response surface model generated can be effectively used for predicting the electrical conductivity and thermal conductivity during the processing of Ti-6Al-4V-SiCp composites with an accuracy of 99.28% (electrical conductivity) and 99.14% (thermal conductivity). By comparing the experimental results along with the results of the mathematical model and the BPANN model results for nine trials, it was observed that the estimated value is accurate for all tests with an error of 0.39% (electrical conductivity) and 0.48% (thermal conductivity). Further, from X-ray diffraction studies and microstructural analysis, it has been observed that aging at 1150 °C for four hours resulted in the formation of a ternary carbide phase of titanium silicon carbide (Ti₃SiC₂), which resulted in maximum electrical conductivity (4,260,000 Ω⁻¹ m⁻¹) and thermal conductivity (36.42 W/m·K) of the Ti-6Al-4V-SiC (15 Wt.%) composite specimen. Full article

This paper, submitted to the special issue of Energies “Future of Road Vehicle Aerodynamics”, proposes and justifies the use of an old idea of generating downforce by actively drawing air from under the car body and exhausting it to the outside. Instead of traditional moving mechanical-curtain elements, a new method for sealing the clearance under the body with an air curtain is proposed. Basic information on the geometry and flow characteristics of such a solution suitable for use in automobiles is presented. The performance of such a fan-driven device generating downforce is studied over a wide range of driving speeds. The device allows for significantly improved vehicle acceleration, shorter braking distances, and extension of the range of safe cornering speeds. The paper shows the successive stages of development of the idea, from the 2D model to the 3D model, and an attempt to implement the device on a sports car. The distributions of pressure, velocity, pathlines and values of aerodynamic forces obtained at assumed fan compressions for different driving speeds are presented. The advantages and disadvantages of the analyzed device are discussed, and further optimization directions are outlined. Full article

The impacts of conflicting aerodynamic forces and side drifting forces are the primary unstable elements in automobiles. The action of an unstable environment in automobile vehicles increases the chance of an accident occurring. As a result, much study is required to determine how opposing aerodynamic forces and side drifting force affects function, as well as how to deal with them for safe and smooth navigation. In this work, an intercity bus is chosen as a main object, and computational fluid dynamics (CFD) analysis is used to estimate aerodynamic forces on the bus in all major directions. Experimentation is also carried out for validation reasons. CFD findings for a scaled base model and a dimple-loaded model based on experimental results from a subsonic wind tunnel are demonstrated to be correct. The drag forces generated by CFD simulations on test models are carefully compared to the experimental drag findings of same-dimensioned models. The error percentages between the results of these two methods are acquired and the percentages are determined to be within an acceptable range of significant limitations. Following these validations, CATIA is used to create a total of nine distinct models, the first of which is a standard intercity bus, whereas the other eight models are fitted with drag reduction techniques such as dimples, riblets, and fins on the surface of their upper cumulus side. A sophisticated computational tool, ANSYS Fluent 17.2, is used to estimate the comparative assessments of the predictions of aerodynamic force fluctuations on bus models. Finally, dimples on the top and side surfaces of the bus model (DESIGN–I) are proposed as a more efficient model than other models because dimples are a vital component that may lower pressure drag on the bus by 18% in the main flow direction and up to 43% in the sideslip direction. Furthermore, by minimizing the different aerodynamic force sources without impacting the preparatory needs, the proposed model may provide comfortable travel. The real-time bus is created, and the finalized drag reduction is applied to the optimized places over the whole bus model. In addition, five distinct size-based bus models are developed and studied in terms of aerodynamic forces, necessary energy to resist aerodynamic drag, required forward force for successful movement, instantaneous demand for particular power, and fuel consumption rate. Finally, the formation of aeroacoustic noise owing to turbulence is estimated using sophisticated computer simulation. Last, for real-time applications, multi-parametric studies based on appropriate intercity buses are established. Full article

In the case of road cars, road safety is the primary factor. The geometry of high-speed road cars has no regulatory restrictions. In addition to the high engine power and effective shape, they can use various types of additional movable aerodynamic elements to adjust their aerodynamic characteristics to the road conditions. Based on the geometry of a two-seater prototype of such a vehicle, a numerical analysis of the influence of a number of additional movable aerodynamic elements on its aerodynamic characteristics was performed. Several of them were installed on the prototype. An electronic system recording a number of motion parameters of the entire car body and some of its movable elements installed on the body was designed and built. The system has been adapted to program the motion of additional aerodynamic elements according to the set algorithms of their activation, temporarily changing the aerodynamic characteristics of the car. An experimental study of the effect of changes in the aerodynamic characteristics of the prototype on its dynamic properties during a drive through a test road section was carried out. It was shown to what extent an average driver can increase the safe speed of the curve of the road using the possibilities of moving aerodynamic elements installed on it. Full article

The purpose of this study was to investigate whether small plates covering the roof and the hood of the DrivAer estate vehicle can be used as airbrakes and increase its drag as well as the downforce. The presented results were obtained with the use of the commercial computational fluid dynamics software ANSYS^® Fluent. The main findings of the article are that the aerodynamic devices such as flaps covering surfaces of the vehicle can have a significant impact on drag increase and can be used not only to make the design of the car more striking but also beneficial when utilized as a part of an active aerodynamic setup. Full article

In time attack races, aerodynamics plays a vital role in achieving short track times. These races are characterized by frequent braking and acceleration supported by aerodynamic downforce. Usually, typical cars are modified for these races by amateurs. Adjusting the aerodynamic solutions to work with bodies developed for other flow conditions is difficult. This paper presents the results of a numerical analysis of the effects of installing a straight wing in front of or above the body on the modified vehicle system’s aerodynamic characteristics, particularly on the front wheels’ aerodynamic downforce values. The paper presents the methodology and results of calculations of the aerodynamic characteristics of a car with an additional wing placed in various positions in relation to the body. The numerical results are presented (C_d, C_l, C_m, C_lf, C_lr), as well as exemplary pressure distributions, pathlines, and visualizations of vortex structures. Strong interactions between the wing operation and body streamline structure are shown. An interesting and unexpected result of the analysis is that the possibility of obtaining aerodynamic downforce of the front wheels is identified, without an increase in aerodynamic drag, by means of a wing placed in a proper position in front of the body. A successful attempt to balance the additional downforce coming from the front wing on the front axle is made using a larger spoiler. However, for large angles of attack, periodically unsteady flow is captured with frequency oscillations of ca. 6–12 Hz at a car speed of 40 m/s, which may interfere with the sports car’s natural suspension frequency. Full article

Electric vehicles (EVs) have recently gained momentum as an integral part of the Internet of Vehicles (IoV) when authorities started expanding their low emission zones (LEZs) in an effort to build green cities with low carbon footprints. Energy is one of the key requirements of EVs, not only to support the smooth and sustainable operation of EVs, but also to ensure connectivity between the vehicle and the infrastructure in the critical times such as disaster recovery operation. In this context, renewable energy sources (such as wind energy) have an important role to play in the automobile sector towards designing energy-harvesting electric vehicles (EH-EV) to mitigate energy reliance on the national grid. In this article, a novel approach is presented to harness energy from a small-scale wind turbine due to vehicle mobility to support the communication primitives in electric vehicles which enable plenty of IoV use cases. The harvested power is then processed through a regulation circuitry to consequently achieve the desired power supply for the end load (i.e., battery or super capacitor). The suitable orientation for optimum conversion efficiency is proposed through ANSYS-based aerodynamics analysis. The voltage-induced by the DC generator is 35 V under the no-load condition while it is 25 V at a rated current of 6.9 A at full-load, yielding a supply of 100 W (on constant voltage) at a speed of 90 mph for nominal battery charging. Full article

The primary noise sources of the vehicle are the engine, exhaust, aeroacoustic noise, and tire–pavement interaction. Noise generated by the first three factors can be reduced by replacing the combustion engine with an electric motor and optimizing aerodynamic design. Currently, a dominant noise within automobiles occurs from the tire–pavement interaction over a speed of 70–80 km/h. Most noise suppression efforts aim to use sound absorbers and cavity resonators to narrow the bandwidth of acoustic frequencies using foams. We demonstrate a technique utilizing acoustic metasurfaces (AMSes) with high reflective characteristics using relatively lightweight materials for noise reduction without any change in mechanical strength or weight of the tire. A simple technique is demonstrated that utilizes acoustic metalayers with high reflective characteristics using relatively lightweight materials for noise reduction without any change in mechanical strength or weight of the tire. The proposed design can significantly reduce the noise arising from tire–pavement interaction over a broadband of acoustic frequencies under 1000 Hz and over a wide range of vehicle speeds using a negative effective dynamic mass density approach. The experiment demonstrated that the sound transmission loss of AMSes is 2–5 dB larger than the acoustic foam near the cavity mode, at 200–300 Hz. The proposed approach can be extended to the generalized area of acoustic and vibration isolation. Full article

To deepen our understanding of the flow field and flow mechanism of a car-like model, in this paper, an experimental investigation of the flow field of MIRA notchback 1/8 scale model is carried out using Particle Image Velocimetry (PIV) method. The tests are conducted in an open circuit wind tunnel at a Reynolds number of $9.16\times {10}^5$. In order to obtain the detailed flow field structure of the notchback model, the PIV method was used to capture the flow field images from three orthogonal directions. By studying the vorticity and velocity vector figures of both the time-averaged and instantaneous states, a three-dimensional flow field schematic of the notchback model is summarized, and the formation mechanism and development process of the vortices are analyzed. This study not only provides an intuitive display of the three-dimensional flow field structure of the MIRA notchback model but, more importantly, it provides a reference for the development of automobile aerodynamic drag reduction by analyzing the flow mechanism, which is beneficial to energy conservation. Full article

In high-speed fluid dynamics, base pressure controls find many engineering applications, such as in the automobile and defense industries. Several studies have been reported on flow control with sudden expansion duct. Passive control was found to be more beneficial in the last four decades and is used in devices such as cavities, ribs, aerospikes, etc., but these need additional control mechanics and objects to control the flow. Therefore, in the last two decades, the active control method has been used via a microjet controller at the base region of the suddenly expanded duct of the convergent–divergent (CD) nozzle to control the flow, which was found to be a cost-efficient and energy-saving method. Hence, in this paper, a systemic literature review is conducted to investigate the research gap by reviewing the exhaustive work on the active control of high-speed aerodynamic flows from the nozzle as the major focus. Additionally, a basic idea about the nozzle and its configuration is discussed, and the passive control method for the control of flow, jet and noise are represented in order to investigate the existing contributions in supersonic speed applications. A critical review of the last two decades considering the challenges and limitations in this field is expressed. As a contribution, some major and minor gaps are introduced, and we plot the research trends in this field. As a result, this review can serve as guidance and an opportunity for scholars who want to use an active control approach via microjets for supersonic flow problems. Full article

To select a more suitable turbulence model to study tire aerodynamics, the characteristics of a deformed profile of a 185/65 R14 passenger tire were reproduced using 3D printing technology. Based on the distance from automobile chassis to the ground, a partially loaded tire model with a height of 150 mm was selected in this paper, and the surface pressure coefficient of the tire model was determined using a wind tunnel test. A computational fluid dynamics (CFD) model was established according to the tire wind tunnel test. The surface pressure coefficient results of three turbulence models, shear stress transport (SST) k-ω, large eddy simulation (LES), and detached eddy simulation (DES) were obtained. Compared with the wind tunnel test results, the mean relative errors of the surface pressure coefficients predicted using SST, LES, and DES in the longitudinal section were 22.4%, 20.9%, and 14.8%, respectively. The LES and DES can capture details of the unsteady flow field that were not predicted by SST. By synthetically analyzing the results of the surface pressure coefficient and flow fields, the DES model is more advantageous than the other two models in predicting the flow characteristics around a statically loaded tire. This study can help designers in the tire industry to apply these cost-effective tools for minimizing the aerodynamic drag of a new tire design. Full article
