In this paper, a modular cell balancing circuit based on a bidirectional flyback converter (BFC) is designed, which is equipped with a symmetrical BFC for each cell. The primary side of all BFCs is in parallel with the battery pack, and the secondary side is connected to the individual cells. Such an input-parallel output-series structure allows for bidirectional and controllable energy transfer among the cells. The control of the charging/discharging for a specific cell can be realized by adjusting the PWM signal on the primary or secondary side of the corresponding BFC. Based on this, three cell balancing strategies are proposed: maximum voltage discharge (MXVD), minimum voltage charge (MNVC), and maximum and minimum voltage balancing (MX&MNB). For MX&MNB, which is essentially a combination of MXVD and MNVC, it controls the maximum voltage cell discharging and minimum voltage cell charging simultaneously, where the energy is transferred directly between the two cells with the largest voltage difference. A cell balancing prototype is built and tested to verify the feasibility and stability of the proposed strategy. All three proposed methods can implement cell balancing simply and effectively, while the MX&MNB provides a faster speed. Full article

This paper describes active battery balancing based on a bidirectional buck converter, a flyback converter, and battery cells by using the proposed chain-loop comparison strategy. The role of the bidirectional buck converter is to charge/discharge the battery pack. During the charging period, the converter is in buck mode, and its output is controlled by constant current/voltage; during the discharging period, the converter is in boost mode, and its output is controlled by constant voltage. The role of the flyback converter is voltage equalization of the battery pack, and its output is controlled by constant current. A chain-loop comparison strategy is used to control battery voltage equalization. In this work, three equalization modes, namely, charging balance, discharging balance, and static balance, were considered. The voltage difference between the maximum and minimum is 0.007 V after a balancing time of 19.75 min, 0.005 V after a balancing time of 24 min, and 0.007 V after a balancing time of 20 min for charging balance, discharging balance, and static balance, respectively. Full article

This paper presents a 250 kHz bidirectional battery charger circuit using a GaN HEMT. The charger is subjected to a high-/low-side constant voltage at 200 V/20 V. The charger circuit is a hybrid of the LLC and flyback circuit topologies. Both the power output analysis and efficiency control of this circuit are simplified when the magnetization current is minimized using the low-resistance GaN HEMT. The switching frequency is controlled to match the series resonance in a way that is analogous to conventional LLC circuit controls, while the duty ratio that determines the power output and the dead time, which determines the zero voltage switching, is controlled in an analogous manner to the flyback circuit control. The charging and discharging modes were altered by applying a double-throw relay that changes the transformer turn ratio, which is different from conventional LLC designs using the switching frequency adjustment. A nominal turn ratio with N_p = 35 and N_s = 3.5 for a 200 V/20 V converter can only produce an internal series resonance with no current flowing in any charging direction. The proposed circuit using a transformer with multiple windings (N_p = 35, N_s,F = 4, and N_s,R = 3) was fabricated to deliver 125 W output power from the power grid battery to the vehicle battery in the forward (charging) mode and 90 W in the reverse (discharging) mode. The conversion efficiency was calculated to be as high as 97% in the forward mode and 95% in the reverse mode. The high conversion efficiency is due to the characteristics of the GaN HEMT, including low resistive and switching losses. The equations derived in this paper associate these losses with the series resonant frequency and power conversion rate, which highlight the advantages of using a GaN HEMT in this CLLC design. Full article

The inconsistency of the battery pack will cause the “barrel effect“ when the battery pack is working. The battery with lower power will first reach the discharge cut-off condition, resulting in the battery pack not being fully discharged, reducing the battery utilization rate. This paper uses the state of charge (SOC) as an equilibrium variable and the forgetting factor recursive least square–extended Kalman filter (FFRLS-EKF) method to estimate the SOC. Using a balanced topology based on a bidirectional impact direct current (DC) converter, the energy transfer can occur between any battery and only between batteries that need to be balanced, increasing energy utilization and the effect of equalization. The equalization system is simulated under various conditions, which proves the effectiveness of the equalization control system. Full article

This study implements a multifunctional charger based on a dual-switching, bidirectional flyback converter (DSBFC). The proposed charger adopts seven charging methods, including the incremental-current charging, constant-voltage (CV) charging, constant-current (CC) charging, pulse-current (PC) charging, triangular-current (TC) charging, sinusoidal-current (SC) charging, and positive/negative pulse-current (Reflex) charging methods. The charging process of a lithium-ion battery is divided into three stages: an initial term, a mid-term, and a final term. In the initial term, the incremental-current charging method is used in the initial term of charging for a soft start and to inhibit an increase in temperature. In the mid-term, five charging methods, including CC, PC, TC, SC, and Reflex-current charging, are used for charging. The CV charging method prevents overcharging the lithium-ion battery in the final term. Based on our experimental results, this study compares the four charging methods (PC, TC, SC, and Reflex-current) with the CC charging method to verify their improvement of the charging speed and increase in temperature in the mid-term. The charging speeds increased by 14.38%, 14.04%, 16.36%, and 27.27%, respectively, and the rise in temperature decreased by 37.8%, 40.5%, 48.6%, and 13.51%, respectively; all performed better than the CC charging method. Finally, users can adjust the charging method of the proposed DSBFC according to the needs of batteries so as to achieve excellent performance. Full article

Energy storage systems are essential for multiple applications like renewable energy systems, electric vehicles, microgrids, among others. Those systems are responsible of regulating the dc bus voltage using charging-discharging systems which are mainly formed by a power converter and a control system. This work focuses on the control system of a flyback converter. A detailed design procedure of an adaptive sliding-mode controller (SMC) and its parameters is presented. The proposed procedure was validated through simulations which allow to confirm its good performance in terms of global stability providing the desired dynamic of the dc bus voltage regulation. Full article

This paper presents a novel bidirectional DC–DC converter, equipped with a three-winding coupled inductor, that can be applied to high-voltage, bidirectional DC–DC energy conversion and meet battery charging and discharging requirements. The architecture consists of a semi-Z-source converter and a forward–flyback converter featuring a three-winding coupled inductor with an iron core. This proposed topology retains the current continuity characteristics of the low-voltage side, all switches possess the zero-voltage switching feature, and the switches on the low-voltage side in the step-down mode have a synchronous rectification function. A 500-W bidirectional converter is implemented to examine the practicality and feasibility of the proposed topology. The relatively streamlined design of the converter can greatly reduce production costs. In the step-up and step-down modes, the maximum energy conversion efficiencies are 95.74% and 96.13%, respectively. Full article

With the penetration of electric vehicles (EVs), there have been paradigm shifts in the transportation sector. EVs are ideally considered to be clean and eco-friendly, but they can overload the existing grid infrastructure and significantly contribute towards carbon emissions depending on the source of charging. The ideal solution is to develop a charging infrastructure for EVs that is integrated with solar energy technology. This paper presents the design of a zero-voltage switching snubber-based bidirectional converter for an off-grid charging station for EVs. The proposed system includes a solar array with a boost converter, a bidirectional converter with snubber circuits and an energy storage unit. A comprehensive comparison between various types of snubbers, such as the resistive capacitive diode snubber, active clamp snubber and flyback snubber, is presented. This type of system configuration clamps the rail voltage, due to the difference in current between leakage inductance and low voltage side-fed inductor currents, resulting in reduced current spikes at the converter’s switches. Such a converter, therefore, leads to higher efficiency of the charging station for EVs. The design of a snubber-based off-grid charging station for EVs is formulated and validated in the MATLAB/Simulink environment. Full article

Active battery equalization and passive battery equalization are two important methods which can solve the inconsistency of battery cells in lithium battery groups. In this paper, a new hybrid battery equalization strategy combinfigureing the active equalizing method with a passive equalizing method is proposed. Among them, the implementation of the active equalizing method uses the bidirectional Flyback converter and Forward converter. This hybrid equalizing strategy adopts the concept of hierarchical equilibrium: it can be divided into two layers, the top layer is the equalization between groups, and the bottom layer is the equalization of group. There are three active equilibrium strategies and one passive equilibrium strategy. For verification purposes, a series of experiments were conducted in MATLAB 2018b/Simulink platform. The simulation and experiment results show that this hybrid battery equalizing method is efficient and feasible. Full article

This research proposes a power loss analysis and a control strategy of an active cell balancing system based on a bidirectional flyback converter. The system aims to achieve an energy storage application with cells connected in 6 series and 1 parrarel (6S1P) design. To reduce the structural complexity, Metal-Oxide-Semiconductor Field Effect Transistor (MOSFET) array commonly used in balancing system is replaced with the photovoltaic Metal-Oxide-Semiconductor (photoMOS) array. Power loss analysis is utilized for the system operating in the proper current to reach higher efficiency. The proposed loss models are divided into conduction loss, switching loss, and copper and core loss of the transformer. Besides, the models are used to estimate the loss of converter operating in different balance conditions to evaluate the system efficiency and verified by the implemented balancing circuit. By way of the loss models, the balancing current can be determined to reach higher efficiency of the proposed system. For further improvement of the balancing process, the system has also applied a control strategy to enhance the balancing performance that reduces 50% maximum voltage difference than traditional cell-to-pack architecture, and 47% balancing duration than traditional pack-to-cell architecture. Full article

Large-scale battery cells are connected in series, which inevitably leads to a phenomenon that the cell voltage is unbalanced. With a conventional equalizer, it is challenging to maintain excellent characteristics in terms of its size, design cost, and equalization efficiency. In order to improve the defects in the above equalization circuit, a novel voltage equalization circuit is designed, which can work in two modes. A bidirectional direct current–direct current (DC–DC) equalization structure is adopted, which can quickly equalize two high or low-power batteries without using an external energy buffer. In order to verify the effectiveness of the proposed circuit, a 12-cell battery 2800-MAh battery string was applied for experimental verification. Computer monitoring (LabVIEW) was adopted in the whole system to intelligently adjust the energy imbalance of the battery pack. The experimental results showed excellent overall performance in terms of equalization was achieved through the newly proposed method. That is, the circuit equalization speed, design cost, and volume have a good balance performance. Full article

Piezoelectric actuators are widely utilized to convert electrical energy into mechanical strain with considerable potential in micro mobile robot applications. However, the use of Pb-based Lanthanumdoped Zirconate Titanates (PZTs) leads to two difficulties in drive circuit design, namely, high voltage step-up ratio and high energy conversion efficiency. When some devices driven by piezoelectric actuators are used in emerging technologies, such as micro mobile robot, to perform special tasks, low mass, high energy density, and high conversion efficiency are strategically important. When these demands are considered, conventional drive circuits exhibit the disadvantages of being too bulky and inefficient for low mass applications. To overcome the aforementioned drawbacks, and to address the need for a piezoelectric bimorph actuator, this work proposed a high step-up ratio flyback converter cascaded with a bidirectional half-bridge stage controlled, via a pulse width modulation strategy, and a novel control method. Simulations and experiments were conducted to verify the ability of the proposed converter to drive a 100 V-input piezoelectric bimorph actuator using a prototype 108 mg (excluding printed circuit board mass), 169 (13 × 13) mm², and 500 mW converter. Full article

This study aims to develop an accurate model of a charge equalization controller (CEC) that manages individual cell monitoring and equalizing by charging and discharging series-connected lithium-ion (Li-ion) battery cells. In this concept, an intelligent control algorithm is developed to activate bidirectional cell switches and control direct current (DC)–DC converter switches along with pulse width modulation (PWM) generation. Individual models of an electric vehicle (EV)-sustainable Li-ion battery, optimal power rating, a bidirectional flyback DC–DC converter, and charging and discharging controllers are integrated to develop a small-scale CEC model that can be implemented for 10 series-connected Li-ion battery cells. Results show that the charge equalization controller operates at 91% efficiency and performs well in equalizing both overdischarged and overcharged cells on time. Moreover, the outputs of the CEC model show that the desired balancing level occurs at 2% of state of charge difference and that all cells are operated within a normal range. The configuration, execution, control, power loss, cost, size, and efficiency of the developed CEC model are compared with those of existing controllers. The proposed model is proven suitable for high-tech storage systems toward the advancement of sustainable EV technologies and renewable source of applications. Full article

This paper proposes a novel high-efficiency isolated three-port bidirectional DC/DC device for photovoltaic (PV) systems. The device contains a high step-up converter for PV modules to supply power to the DC bus, and a bidirectional charge/discharge control circuit for the battery with an improved boost-flyback converter. When the PV modules supply sufficient energy, their output can be stepped up and energy supply to the DC bus and charging of the battery can be achieved simultaneously. However, when the energy supplied is insufficient, the battery provides energy to the DC bus. When the proposed converter is operated in the step-down mode, the DC-blocking capacitor on the high-voltage side is used to reduce the voltage on the transformer and achieve high step-down performance. Moreover, to improve the overall efficiency of the system, the energy stored in the leakage inductance is recycled and supplied to the DC-blocking capacitor during operation in the step-up mode. Finally, to verify the feasibility and practicability of the proposed devices, a 500 W three-port bidirectional DC/DC devices was implemented. The highest efficiencies achieved for operation in different modes were as follows: high step-up mode for the PV modules, 95.2%; battery step-up mode, 94.2%; and step-down mode, 97.6%. Full article

In this paper, a novel isolated bidirectional DC-DC converter is proposed, which is able to accomplish high step-up/down voltage conversion. Therefore, it is suitable for hybrid electric vehicle, fuel cell vehicle, energy backup system, and grid-system applications. The proposed converter incorporates a coupled inductor to behave forward-and-flyback energy conversion for high voltage ratio and provide galvanic isolation. The energy stored in the leakage inductor of the coupled inductor can be recycled without the use of additional snubber mechanism or clamped circuit. No matter in step-up or step-down mode, all power switches can operate with soft switching. Moreover, there is a inherit feature that metal–oxide–semiconductor field-effect transistors (MOSFETs) with smaller on-state resistance can be adopted because of lower voltage endurance at primary side. Operation principle, voltage ratio derivation, and inductor design are thoroughly described in this paper. In addition, a 1-kW prototype is implemented to validate the feasibility and correctness of the converter. Experimental results indicate that the peak efficiencies in step-up and step-down modes can be up to 95.4% and 93.6%, respectively. Full article
