Search Results (94)

Floating offshore wind turbines present peculiar characteristics that make them particularly interesting for the implementation of wind farm control strategies such as wake mixing to increase the overall power production. Wake mixing is achieved by generating an unsteady cyclical load on the blades of upwind turbines to decrease the wind deficit on downwind turbines. The possibility of exploiting the yaw motion of a floating offshore wind turbine allows for amplified wake mixing or a reduction in the workload of the control mechanism. To amplify the yaw motion of the system at a selected excitation frequency, a multi-disciplinary optimization framework was developed to modify selected properties of the floating platform and mooring line configuration of the DTU 10 MW turbine on the Triple Spar platform. At the same time, operational and structural constraints were taken into account. A simulation-based approach was chosen to design a floating platform and mooring line configuration that were optimized to integrate with the new control strategy based on wake mixing in floating offshore wind farms. Modifying the floating platform spar arrangement and mooring line properties allowed us to tune the yaw natural frequency of the system in accordance with the excitation frequency of the wake control technique and amplify the yaw motion while controlling the deviations of the operational constraints and costs from the baseline configuration. Full article

Within the turbomachinery industry, components are currently assessed deploying standard second-order steady solvers. These are unable to capture complicated unsteady phenomena that have a critical impact on component performance. In this work, the high-order spectral h/p solver Nektar++ will be applied to a compressor blade to study the turbulent transition mechanisms and assess the effect of incoming disturbances with quasi-DNS resolution. The case will be modelled at an angle of incidence of $53.5°$ to match the original experimental loading at $52.8°$. At clean inflow conditions, Kelvin–Helmholtz instabilities appear on both sides of the blade due to a double separation, with the pressure side one not being reported in the experiments. The separation is gradually removed by the incoming turbulent structures but at different rates on the two sides of the blade. It will be shown that there is an optimal amount of turbulence intensity that minimises momentum thickness, which is strongly related to losses. Moreover, a discussion on the spanwise extrusion will be included, this being a major player in the modelling costs. Finally, the wall-clock time and the exact expenditure to run this case will be outlined, providing quantitative evidence of the feasibility of considering a quasi-DNS resolution in an industrial setting. Full article

This study investigated the impact of different load distribution ratios between two rotors on the unsteady performance of dual-stage pump-jet propulsors using Computational Fluid Dynamics (CFDs) and experimental methods. The Shear Stress Transport (SST) k-ω model was employed to solve turbulence problems, and the numerical simulation method used was validated. The following conclusions were drawn: Different load distribution ratios of the dual-stage rotors have no significant impact on the overall propulsion performance of the propulsor. As the load distribution ratio is aft-shifted, the axial unsteady force of the entire propulsor continuously decreases, with a reduction of up to 53.6%. This is due to the gradual reduction in the energy of the first-stage rotor, leading to a more uniform Blade-Passing Frequency Velocity Harmonic Coefficient (BPFVHC) in front of the second-stage rotor, thereby gradually reducing the unsteady force of the second-stage rotor. The experimental results also indicate that the aft-shifted load model can reduce the sound pressure level of the propulsor. Compared to the prototype propulsor, the sound pressure level at the Blade-Passing Frequency decreases by 6.67 dB, or about 78.5%, in sound energy. This study has important implications for the low-excitation design of dual-stage pump-jet propulsors. Full article

High payload capacity multi-rotor aerial vehicles are typically configured with multiple propellers to achieve the required aerodynamic lift. However, this design approach often results in an increased overall dimensional envelope, which introduces significant operational limitations in confined spatial environments such as urban airspace. By utilizing a limited overlap rotor configuration, the spatial utilization rate of an aircraft can be greatly improved, ensuring a sufficient thrust of rotor while simultaneously reducing the size of the aircraft. However, the slipstreams of two rotors overlap, which may create a significant aerodynamic interface. This paper utilizes numerical simulation based on the unsteady RANS (Reynolds-averaged Navier–Stokes) method to analyze the influence of parameters such as distance, blade distance, and rotation direction on the interference flow field of overlapping rotors. Research indicates that aerodynamic interference only affects the overlapping area between two rotors at the inner blade, leading to the offset of loading distribution on the blade, which can be explained by the slipstream effect, suction effect, and induced effects generated by two rotors. As the axis distance between two rotors decreases, the strengthening of the slipstream and suction effects leads to a rapid decrease in the aerodynamic efficiency of the two rotors. When the blade between the two rotors increases, the weakening of the suction effect and induced effects causes the load on the lower rotor to translate to the upper rotor. Moreover, the variation in the spatial distribution of the blade tip–vortex leads to blade–vortex interaction, which causes a change in the spanwise distribution of the load on the lower blade. Full article

An experimental investigation was carried out to understand the effects of LEP (leading-edge protuberance) blades on the structural characteristics of VAWTs. A series of experiments were performed on VAWTs with straight and LEP blades for a wide range of wind velocity (6 m/s to 20 m/s) and pitch angles (−20° to 20°), and the structural excitations on the VAWT structure were measured using a triaxial accelerometer in each case. The raw acceleration data were extensively processed in the time and frequency domains to identify the variation in structural excitation caused by the unsteady wind and aerodynamic loads on the VAWT structure. Understanding the aerodynamic changes and their impact on structural characteristics is essential. The current study examines how LEP influences the structural excitation of VAWTs. However, a great deal of aerodynamic variation was observed for the LEP blades, so the straight blades of the VAWT were replaced with various modified LEP blades, for which a similar set of experiments was carried out. The study presents a better performance (self-starting, stall-mitigating) for VAWTs with LEP 3 and 2 blades, with a significant reduction in the excitation of loads due to wind load and the changes in aerodynamics observed in the along- and across-wind directions. Full article

Tidal sites can present uneven seabed bathymetry features that induce favourable or adverse pressure gradients and are sources of turbulence, and so are likely to affect the operation, performance, and wake recovery dynamics of deployed tidal-stream turbines. Large-eddy simulations are conducted to analyse the unsteady loading of a tidal turbine subjected to the wake of an upstream turbine that interacts with a two-dimensional ridge located between the two turbines. Relative to an isolated turbine, blade fatigue loading is increased by up to 43% when subject to the wake of a turbine located 8 turbine diameters upstream interacting with a ridge located 2 turbine diameters upstream, whereas for the same spacing, the turbine wake led to a limited 6% reduction in loading and the ridge wake only caused a 79% increase. For larger spacings, the trends were similar, but the magnitude of difference reduced. Predictions of fatigue loads with a blade element momentum model (BEMT) provided a good agreement for flat bed conditions. However, the ridge-induced pressure gradient drives rapid spatial change of coherent flow structures, which limits the applicability of Taylor’s frozen turbulence hypothesis adopted in the BEMT. Reasonable prediction of rotor loading with BEMT was found to be obtained using the turbulent onset flow field at a plane one-diameter upstream of the turbine. This is more accurate than use of the planes at the rotor plane or two-diameters upstream, as coherent structures represent those modified by wake recovery and rotor induction in the approach flow to the turbine. Full article

The Francis runner is a critical component of the Francis turbine generator unit, playing a central role in converting water energy into rotating mechanical energy that drives the generator in hydropower stations. In-depth analyses of the flow characteristics of the Francis runner under various operating conditions and avoiding fatigue damage of the Francis runner are crucial to the reliability and efficiency of hydropower operation. In this paper, the flow dynamics of a large Francis turbine runner are analyzed under three representative loading conditions—low partial load, high partial load, and full load—and the flow-induced stress of the runner is analyzed under these loading conditions. It was found that the maximum static and dynamics stresses of the runner at three representative loading conditions are located at the chamfered surface where the blade trailing edge connects to the runner crown. The maximum static stresses of the Francis runner are 284 MPa, 352 MPa, and 381 MPa at low partial load, high partial load, and full load, respectively, and they are above the allowable stress limits, as half of the yield stress of the runner material of 550 MPa. The peak-to-peak values of runner dynamic stress at low partial load, high partial load, and full load are 15 MPa, 25 MPa, and 14.6 MPa, respectively. The high stress invoked by the unsteady flow under various loading conditions in this runner was the cause of the fatigue breakage of the runner blades. The results of this investigation have important reference values for mitigating fatigue damage in similar Francis runners and optimizing unit operation. Full article

This study aims to introduce a new optimization method for designing a vertical-axis wind turbine (VAWT) that dynamically morphs its blades as a function of the tip-speed ratio (TSR) and azimuthal angle. For this purpose, the Darrieus turbine is the subject of a dynamic study under transient aerodynamic loads. By resolving the two-dimensional unsteady incompressible Navier–Stokes equation, the aerodynamic torque is obtained with the k-$ϵ$ realizable turbulence model. A comparison between rotor operation at optimal and lower  ${\mathrm{C}}_p$ values is possible according to the investigation of flow-field characteristics for a variety of tip-speed ratio values, with experimental results so that a better understanding of the vertical-axis wind turbine’s basic physics is obtained. Then, a multi-objective optimization technique is coupled with ANSYS Workbench to increase the energy generation of VAWT blades by reducing the drag coefficient and maximizing the power coefficient. The input variables were evaluated through a sensitivity analysis, and the most important one was chosen. The analysis results of the best compromise showed that the design methodology’s output is feasible for manufacturing. Full article

With the continuous development of the shipping market, bow thrusters have become more important for ship maneuvering. Therefore, the performance of bow thrusters is studied in this paper. In order to obtain an unsteady performance of the bow thruster under different ship speed conditions, the SST k-ω turbulence model is adopted to predict the hydrodynamics of the bow thruster. With the ship’s speed increasing gradually, the variation characteristics of hydrodynamic coefficients and the flow field distribution at key positions are analyzed. The results show that with an increase in ship speed to three knots, the thrust coefficient and torque coefficient of the bow thruster decrease by 2.69~4.07% and 2.34~3.08%. In addition, the blade vibration amplitude intensifies. In the departure direction, the propeller load is more susceptible to being influenced and decreases by an additional 2.34~4.16% compared with that in the berthing direction. Meanwhile, it is found that the velocity distribution is asymmetrical. The inlet velocity at the bow side is faster, which results in the maximum peak pressure being about three times the minimum peak pressure. In addition, the pressure’s nonuniformity in the tunnel increases gradually with the increase in ship speed. Compared with the pressure distribution in the berthing direction, the pressure distribution before and after the propeller is more uniform, which is consistent with the results of hydrodynamic change and velocity distribution. The research in this paper has a certain reference significance for understanding the hydrodynamic performance of bow thrust operation. Full article

In this work, we present the first three-dimensional (3D) computational investigation of wind turbine airfoils over ${360}^{°}$ angles of attack to predict unsteady aerodynamic loads and vortex-shedding characteristics. To this end, static–airfoil simulations are performed for the FFA-W3 airfoil family at a Reynolds number of ${10}^7$ with the Improved Delayed Detached Eddy Simulation turbulence model. Aerodynamic forces reveal that the onset of boundary-layer instabilities and flow separation does not necessarily coincide with the onset of stall. In addition, a comparison with two-dimensional simulation data and flat plate theory extension of airfoil polars, suggest that, in the deep stall regime, 3D effects remain critical for predicting both the unsteady loads and the vortex-shedding dynamics. For all airfoils, the vortex-shedding frequencies are found to be inversely proportional to the wake width. In the case of slender airfoils, the frequencies are nearly independent of the airfoil thickness, and their corresponding Strouhal number $St$ is approximately $0.15$. Based on the calculated $St$, the potential for shedding frequencies to coincide with the natural frequencies of the International Energy Agency 15 MW reference wind turbine blades is investigated. The analysis shows that vortex-induced vibrations occur primarily at angles of attack of around $\pm {90}^{°}$ for all airfoils. Full article

The vibration of large Kaplan turbines has always been one of the key research issues of turbines. Affected by the load and head of the power station, the Kaplan turbine will operate under medium and low heads, and the components will vibrate violently, seriously threatening the stable operation of the unit. Compared with other types of turbines, the runner structure of the Kaplan turbine is more complex. Therefore, in addition to the fixed components, the dynamic response characteristics of the rotating components are also be the focus of this study. In this paper, four operating points under high, medium and low heads are selected. The unsteady flow field and fluid–structure interaction are calculated. The modal and dynamic stress characteristics of the fixed components (bottom ring, head cover and support cover) and the rotating components (blades, runner body and main shaft) are analyzed. The results show that the location of the stress concentration of fixed components under low heads changes significantly, and the stress fluctuates greatly due to the influence of the stay vanes. The rotating components are more affected by the rotation of the runner under low heads, and the displacement and stress fluctuations of the rotating structure are significantly greater than those of medium and high heads. The pressure fluctuations in the vaneless area and draft tube cause some low-frequency excitation. The stress fluctuations of rotating components under low heads are much greater than those of the fixed components. This shows that the head has a greater impact on the rotating components, which is more likely to cause damage to the rotating components, seriously threatening the stable operation of the unit. Full article

Pump–turbine units with high heads are subjected to strong pressure pulsations from the unsteady transient flow in fluid channels, which can produce severe vibrations and high stresses on the pump–turbine structural components. Therefore, reducing transient flow-induced stresses on prototype reversible pump–turbine units is an important measure for ensuring their safe and efficient operation. A high-head prototype reversible pump–turbine with a rated head of 440 m was used to investigate the transient flow characteristics and the flow-induced-stresses in this study. First, the flow passages of the pump–turbine unit and the structure of the reversible pump–turbine runner were constructed with CAD tools. Next, CFD simulations at the full load were performed to investigate the pressure pulsation characteristics of the pump turbine in both the time domain and the frequency domain. After this, the pressure files calculated by the CFD were exported and applied to a finite element model of the pump–turbine runner to calculate the transient flow-induced dynamic stresses. The results show that the pressure pulsations in the flow passage are closely related to the rotational speed, the guide vane number, and the runner blade number of the pump–turbine unit. The maximum flow-induced stresses on the pump–turbine runner at the full load were below 2 MPa and lower than the allowable value, which reveals that the designs of the pump–turbine runner and the flow passage are acceptable. The conclusions can be used as a reference to evaluate the design of high-head pump–turbines units. The approaches used to carry out the transient flow-induced stress calculations can be applied not only to pump–turbines units but also to other types of fluid turbomachinery such as pumps, turbines, fans, compressors, turbochargers, etc. Full article

The stress and fatigue of the runner during the operation of the large Kaplan turbine are one of the key issues in the operation of turbines. Due to the complexity of the working load and the geometric configuration of the Kaplan turbine runner, the different contact modes between the internal components of the runner will have an impact on the stress and fatigue results. Therefore, the unsteady CFD calculation of the full channel is conducted in this article to analyze the hydraulic characteristics of the turbine blades in the unsteady flow field, such as pressure and torque. The pressure load is loaded onto the runner using a fluid–structure interaction (FSI) theory, and the stress characteristics of the blade, blade lever, and runner body are compared under three contact modes. Based on the dynamic stress spectrum of the blade lever calculated under three contact conditions, the life of the blade lever is predicted using the rain flow counting method and the Palmgren–Miner theory. The results indicate that the rotation of the runner has a significant impact on the hydraulic and structural characteristics of the Kaplan turbine. The non-uniform and asymmetric stress and torque conditions gradually cause fatigue in the components of the runner. The average and amplitude of dynamic stress on the blade, blade lever, and runner body under frictional and frictionless contact are greater than those of fixed contact. The life of the blade lever calculated under fixed contact is much greater than that under frictional and frictionless contact; therefore, the contact conditions have a significant impact on the structural characteristics of the runner. Full article

The internal flow of a pump turbine is unstable in part-load pump mode for small guide-vane openings, and the strong vibration caused by pressure pulsation is related to the safe and stable operation of the unit. A pump turbine with a six-splitter-blade runner was chosen for unsteady simulation analyses. A standard k-epsilon turbulence model was adopted to study the unsteady flow and pressure pulsation in part-load pump mode. The predicted results show that the flow in the draft tube and the runner with splitter blades was relatively stable and the flow of the blade-to-blade channel was symmetrical. When the inlet and outlet velocity distribution of the vanes was not uniform, a vortex began to form in the stay-vane domain. The reason for this vortex formation is explained, and it is pointed out that the existence of the vortex and backflow leads to uneven velocity distribution. The unsteady calculation results showed that the pressure-pulsation peak-to-peak amplitudes in the vaneless area and guide vanes were much higher than those of other monitor points because of rotor–stator interference between the rotating runner and the vanes. In addition, the pulsation characteristics of the monitor points at different circumferential positions in the vaneless region were quite different. In the vaneless area, the velocity gradient along the circumferential direction was very large, and there was a phenomenon of backflow. Also, the pressure pulsation was 0.2 times that of the runner rotational frequency, and the blade-passing frequency was a third-order frequency. At the outlet of the guide vane, the pressure pulsation was mainly of a low frequency with a complex vortex flow. Finally, the pressure pulsation began to decrease rapidly in the stay-vane region. Full article

This study aims to experimentally investigate the effects of parallel blade–vortex interaction (BVI) on the aerodynamic performances of an airfoil, in particular as a possible cause of blade stall, since similar effects have been observed in literature in the case of perpendicular BVI. A wind tunnel test campaign was conducted reproducing parallel BVI on a NACA 23012 blade model at a Reynolds number of 300,000. The vortex was generated by impulsively pitching a second airfoil model, placed upstream. Measurements of the aerodynamic loads acting on the blade were performed by means of unsteady Kulite pressure transducers, while particle image velocimetry (PIV) techniques were employed to study the flow field over the blade model. After a first phase of vortex characterisation, different test cases were investigated with the blade model both kept fixed at different incidences and oscillating sinusoidally in pitch, with the latter case, a novelty in available research on parallel BVI, representing the pitching motion of a helicopter main rotor blade. The results show that parallel BVI produces a thickening of the boundary layer and can induce local flow separation at incidences close to the stall condition of the airfoil. The aerodynamic loads, both lift and drag, suffer important impulsive variations, in agreement with literature on BVI, the effects of which are extended in time. In the case of the oscillating airfoil, BVI introduces hysteresis cycles in the loads, which are generally reduced. In conclusion, parallel BVI can have a detrimental impact on the aerodynamic performances of the blade and even cause flow separation, which, while not being as catastrophic as in the case of dynamic stall, has relatively long-lasting effects. Full article
