This paper presents a comprehensive review of cardiorespiratory auscultation sensing devices (i.e., stethoscopes), which is useful for understanding the theoretical aspects and practical design notes. In this paper, we first introduce the acoustic properties of the heart and lungs, as well as a brief history of stethoscope evolution. Then, we discuss the basic concept of electret condenser microphones (ECMs) and a stethoscope based on them. Then, we discuss the microelectromechanical systems (MEMSs) technology, particularly focusing on piezoelectric transducer sensors. This paper comprehensively reviews sensing technologies for cardiorespiratory auscultation, emphasizing MEMS-based wearable designs in the past decade. To our knowledge, this is the first paper to summarize ECM and MEMS applications for heart and lung sound analysis. Full article

This research examines the application of non-invasive acoustic analysis for detecting obstructions in vascular access (fistulas) used by kidney dialysis patients. Obstructions in these fistulas can interrupt essential dialysis treatment. In this study, we utilized a condenser microphone to capture the blood flow sounds before and after angioplasty surgery, analyzing 3819 sound samples from 119 dialysis patients. These sound signals were transformed into spectrogram images to classify obstructed and unobstructed vascular accesses, that is fistula conditions before and after the angioplasty procedure. A novel lightweight two-dimension convolutional neural network (CNN) was developed and benchmarked against pretrained CNN models such as ResNet50 and VGG16. The proposed model achieved a prediction accuracy of 100%, surpassing the ResNet50 and VGG16 models, which recorded 99% and 95% accuracy, respectively. Additionally, the study highlighted the significantly smaller memory size of the proposed model (2.37 MB) compared to ResNet50 (91.3 MB) and VGG16 (57.9 MB), suggesting its suitability for edge computing environments. This study underscores the efficacy of diverse deep-learning approaches in the obstructed detection of dialysis fistulas, presenting a scalable solution that combines high accuracy with reduced computational demands. Full article

Communicating under extreme noise conditions remains challenging in spite of higher-order noise-canceling microphones, throat microphones, and signal processing. Both natural and human-made background ambient noise can disturb the conveyance of information because of high noise levels. Noise cancellation, which is used frequently in audio technology, has limits in noise reduction and does not guarantee clear vocal pickup in these severe situations. A contact microphone that is attached directly to the medium of interest has the potential to pick up vocal signals with reduced noise. In this study, an electrostatic transducer with an elastomer layer that is impedance-matched to the human body is used to pick up speech sounds through constant contact on the chin and cheek. By attaching the wearable device directly to the skin, the medium of air is bypassed, and airborne noise is passively canceled. Because of the acoustic impedance-matched layer, the sensor is more sensitive to low frequencies under 500 Hz, so frequency equalization was implemented to flatten the frequency response throughout the vocal range. The perceptual evaluation of speech quality (PESQ) scores of the wearable device with equalization averaged around 2.6 on a scale from –0.5 to 4.5. Speech recordings were also collected in a noise field of 85 dB, and the performance was compared to a cardioid lapel mic, a cardioid dynamic mic, and an omnidirectional condenser mic. The recordings revealed a significantly reduced presence of white noise in the contact sensor. This study provides preliminary results that show potential vocal applications for a wearable impedance-matched sensor. Full article

The aim of this work is to present a preliminary study for the design of a digital auscultation system, i.e., a novel wearable device for patient chest auscultation and a digital stethoscope. The development and testing of the electronic stethoscope prototype is reported with an emphasis on the description and selection of sound transduction systems and analog electronic processing. The focus on various microphone technologies, such as micro-electro-mechanical systems (MEMSs), electret condensers, and piezoelectronic diaphragms, intends to emphasize the most suitable transducer for auscultation. In addition, we report on the design and development of a digital acquisition system for the human body for sound recording by using a modular device approach in order to fit the chosen analog and digital mics. Tests were performed on a designed phantom setup, and a qualitative comparison between the sounds recorded with the newly developed acquisition device and those recorded with two commercial digital stethoscopes is reported. Full article

Cartilage conduction is known widely as a third hearing transmission mechanism after the air and bone conduction methods, and transducers dedicated to the production of cartilage conduction sounds have been developed by several Japanese companies. To estimate the acoustic performance of the five cartilage conduction transducers selected for this study, both airborne sounds and cartilage conduction sounds were measured. Airborne sounds can be measured using a commercial condenser microphone; however, cartilage conduction sounds are impossible to measure using a conventional head and torso simulator (HATS), because the standard-issue ear pinna simulator cannot reproduce cartilage conduction sounds with the same spectral characteristics as the corresponding sounds measured in humans. Therefore, this study replaced the standard-issue simulator with a developed pinna simulator that can produce similar spectral characteristics to those of humans. The HATS manipulated in this manner realized results demonstrating that transducers that fitted the entrance to the external auditory canal more densely could produce greater cartilage conduction sounds. Among the five transducers under test, the ring-shaped device, which was not much larger than the entrance to the canal, satisfied the spectral requirements. Full article

There is a worldwide need to improve blood pressure (BP) measurement error in order to correctly diagnose hypertension. Cardiovascular diseases cause 17.9 million deaths annually and are a substantial monetary strain on healthcare. The current measurement uncertainty of 3 mmHg should be improved upon. Dynamic pressure measurement standards are lacking or non-existing. In this study we propose a novel method of measuring air pressure inside the sphygmomanometer tubing during BP measurement using a condenser microphone. We designed, built, and tested a system that uses a radiofrequency (RF) modulation method to convert changes in capacitance of a condenser microphone into pressure signals. We tested the RF microphone with a low-frequency (LF) sound source, BP simulator and using a piezoresistive pressure sensor as a reference. Necessary tests were conducted to assess the uncertainty budget of the system. The RF microphone prototype has a working frequency range from 0.5 Hz to 280 Hz in the pressure range from 0 to 300 mmHg. The total expanded uncertainty (k = 2, p = 95.5%) of the RF microphone was 4.32 mmHg. The proposed method could establish traceability of BP measuring devices to acoustic standards described in IEC 61094-2 and could also be used in forming dynamic BP standards. Full article

Power-quality events and operation transients in power systems (PS) with isolated neutral can saturate inductive voltage transformers (IVT), which, when interacting with the overhead and underground cable capacitances, can cause ferroresonance events in the local PS. This abnormal operating mode can partially or totally damage the transformers and switchgears within the affected PS. Distribution system operators (DSO) can minimize these effects by detecting ferroresonance events accurately and fast enough and changing the mode of operation accordingly. Direct detection methods, i.e., based on voltage measurements, are reliable, but the massive deployment of this solution is relatively expensive; i.e., power quality analyzers cost thousands of USD. Alternatively, indirect detection methods are also available, e.g., IVT vibration measurements with accelerometers costing hundreds of USD, but their reliability depends on the installation method used. This manuscript proposes using the acoustic noise caused by magnetostriction forces within the IVT core during ferroresonance events to detect their occurrence. Compared to other indirect methods, electret condenser microphones with preamplifying stage cost less than USD 10 and are less sensitive to the installation procedure. The proposed method is validated experimentally, and its performance compared to IVT vibration measurements one by using the same detection methodology. Full article

With conventional stethoscopes, the auscultation results may vary from one doctor to another due to a decline in his/her hearing ability with age or his/her different professional training, and the problematic cardiopulmonary sound cannot be recorded for analysis. In this paper, to resolve the above-mentioned issues, an electronic stethoscope was developed consisting of a traditional stethoscope with a condenser microphone embedded in the head to collect cardiopulmonary sounds and an AI-based classifier for cardiopulmonary sounds was proposed. Different deployments of the microphone in the stethoscope head with amplification and filter circuits were explored and analyzed using fast Fourier transform (FFT) to evaluate the effects of noise reduction. After testing, the microphone placed in the stethoscope head surrounded by cork is found to have better noise reduction. For classifying normal (healthy) and abnormal (pathological) cardiopulmonary sounds, each sample of cardiopulmonary sound is first segmented into several small frames and then a principal component analysis is performed on each small frame. The difference signal is obtained by subtracting PCA from the original signal. MFCC (Mel-frequency cepstral coefficients) and statistics are used for feature extraction based on the difference signal, and ensemble learning is used as the classifier. The final results are determined by voting based on the classification results of each small frame. After the testing, two distinct classifiers, one for heart sounds and one for lung sounds, are proposed. The best voting for heart sounds falls at 5–45% and the best voting for lung sounds falls at 5–65%. The best accuracy of 86.9%, sensitivity of 81.9%, specificity of 91.8%, and F1 score of 86.1% are obtained for heart sounds using 2 s frame segmentation with a 20% overlap, whereas the best accuracy of 73.3%, sensitivity of 66.7%, specificity of 80%, and F1 score of 71.5% are yielded for lung sounds using 5 s frame segmentation with a 50% overlap. Full article

Audio applications such as mobile phones, hearing aids, true wireless stereo earphones, and Internet of Things devices demand small size, high performance, and reduced cost. Microelectromechanical system (MEMS) capacitive microphones fulfill these requirements with improved reliability and specifications related to sensitivity, signal-to-noise ratio (SNR), distortion, and dynamic range when compared to their electret condenser microphone counterparts. We present the design and modeling of a semiconstrained polysilicon diaphragm with flexible springs that are simply supported under bias voltage with a center and eight peripheral protrusions extending from the backplate. The flexible springs attached to the diaphragm reduce the residual film stress effect more effectively compared to constrained diaphragms. The center and peripheral protrusions from the backplate further increase the effective area, linearity, and sensitivity of the diaphragm when the diaphragm engages with these protrusions under an applied bias voltage. Finite element modeling approaches have been implemented to estimate deflection, compliance, and resonance. We report an 85% increase in the effective area of the diaphragm in this configuration with respect to a constrained diaphragm and a 48% increase with respect to a simply supported diaphragm without the center protrusion. Under the applied bias, the effective area further increases by an additional 15% as compared to the unbiased diaphragm effective area. A lumped element model has been also developed to predict the mechanical and electrical behavior of the microphone. With an applied bias, the microphone has a sensitivity of −38 dB (ref. 1 V/Pa at 1 kHz) and an SNR of 67 dBA measured in a 3.25 mm × 1.9 mm × 0.9 mm package including an analog ASIC. Full article

Singing voice is a human quality that requires the precise coordination of numerous kinetic functions and results in a perceptually variable auditory outcome. The use of multi-sensor systems can facilitate the study of correlations between the vocal mechanism kinetic functions and the voice output. This is directly relevant to vocal education, rehabilitation, and prevention of vocal health issues in educators; professionals; and students of singing, music, and acting. In this work, we present the initial design of a modular multi-sensor system for singing voice analysis, and describe its first assessment experiment on the ‘vocal breathiness’ qualitative characteristic. A system case study with two professional singers was conducted, utilizing signals from four sensors. Participants sung a protocol of vocal trials in various degrees of intended vocal breathiness. Their (i) vocal output, (ii) phonatory function, and (iii) respiratory behavior-per-condition were recorded through a condenser microphone (CM), an Electroglottograph (EGG), and thoracic and abdominal respiratory effort transducers (RET), respectively. Participants’ individual respiratory management strategies were studied through qualitative analysis of RET data. Microphone audio samples breathiness degree was rated perceptually, and correlation analysis was performed between sample ratings and parameters extracted from CM and EGG data. Smoothed Cepstral Peak Prominence (CPPS) and vocal folds’ Open Quotient (OQ), as computed with the Howard method (HOQ), demonstrated the higher correlation coefficients, when analyzed individually. DECOM method-computed OQ (DOQ) was also examined. Interestingly, the correlation coefficient of pitch difference between estimates from CM and EGG signals appeared to be (based on the Pearson correlation coefficient) statistically insignificant (a result that warrants investigation in larger populations). The study of multi-variate models revealed even higher correlation coefficients. Models studied were the Acoustic Breathiness Index (ABI) and the proposed multiple regression model CDH (CPPS, DOQ, and HOQ), which was attempted in order to combine analysis results from microphone and EGG signals. The model combination of ABI and the proposed CDH appeared to yield the highest correlation with perceptual breathiness ratings. Study results suggest potential for the use of a completed system version in vocal pedagogy and research, as the case study indicated system practicality, a number of pertinent correlations, and introduced topics with further research possibilities. Full article

Preparing and pre-testing experimental setups for flight tests is a lengthy but necessary task. One part of this preparation is comparing newly available measurement technology with proven setups. In our case, we wanted to compare acoustic Micro-Electro-Mechanical Systems (MEMS) to large and proven surface-mounted condenser microphones. The task started with the comparison of spectra in low-speed wind tunnel environments. After successful completion, the challenge was increased to similar comparisons in a transonic wind tunnel. The final goal of performing in-flight measurements on the outside fuselage of a twin-engine turboprop aircraft was eventually achieved using a slim array of 45 MEMS microphones with additional large microphones installed on the same carrier to drawn on for comparison. Finally, the array arrangement of MEMS microphones allowed for a complex study of fuselage surface pressure fluctuations in the wavenumber domain. The study indicates that MEMS microphones are an inexpensive alternative to conventional microphones with increased potential for spatially high-resolved measurements even at challenging experimental conditions during flight tests. Full article

Most commercial prosthetic hands lack closed-loop feedback, thus, a lot of research has been focusing on implementing sensory feedback systems to provide the user with sensory information during activities of daily living. This study evaluates the possibilities of using a microphone and electrotactile feedback to identify different textures. A condenser microphone was used as a sensor to detect the friction sound generated from the contact between different textures and the microphone. The generated signal was processed to provide a characteristic electrical stimulation presented to the participants. The main goal of the processing was to derive a continuous and intuitive transfer function between the microphone signal and stimulation frequency. Twelve able-bodied volunteers participated in the study, in which they were asked to identify the stroked texture (among four used in this study: Felt, sponge, silicone rubber, and string mesh) using only electrotactile feedback. The experiments were done in three phases: (1) Training, (2) with-feedback, (3) without-feedback. Each texture was stroked 20 times each during all three phases. The results show that the participants were able to differentiate between different textures, with a median accuracy of 85%, by using only electrotactile feedback with the stimulation frequency being the only variable parameter. Full article

This review collates around 100 papers that developed micro-electro-mechanical system (MEMS) capacitive microphones. As far as we know, this is the first comprehensive archive from academia on this versatile device from 1989 to 2019. These works are tabulated in term of intended application, fabrication method, material, dimension, and performances. This is followed by discussions on diaphragm, backplate and chamber, and performance parameters. This review is beneficial for those who are interested with the evolutions of this acoustic sensor. Full article

The purpose of this study was to investigate the feasibility of using neck-surface acceleration signals to discriminate between modal, breathy and pressed voice. Voice data for five English single vowels were collected from 31 female native Canadian English speakers using a portable Neck Surface Accelerometer (NSA) and a condenser microphone. Firstly, auditory-perceptual ratings were conducted by five clinically-certificated Speech Language Pathologists (SLPs) to categorize voice type using the audio recordings. Intra- and inter-rater analyses were used to determine the SLPs’ reliability for the perceptual categorization task. Mixed-type samples were screened out, and congruent samples were kept for the subsequent classification task. Secondly, features such as spectral harmonics, jitter, shimmer and spectral entropy were extracted from the NSA data. Supervised learning algorithms were used to map feature vectors to voice type categories. A feature wrapper strategy was used to evaluate the contribution of each feature or feature combinations to the classification between different voice types. The results showed that the highest classification accuracy on a full set was 82.5%. The breathy voice classification accuracy was notably greater (approximately 12%) than those of the other two voice types. Shimmer and spectral entropy were the best correlated metrics for the classification accuracy. Full article

To develop totally implantable middle ear and cochlear implants, a miniature microphone that is surgically easy to implant and has a high sensitivity in a sufficient range of audio frequencies is needed. Of the various implantable acoustic sensors under development, only micro electro-mechanical system-type acoustic sensors, which attach to the umbo of the tympanic membrane, meet these requirements. We describe a new vibro-acoustic hybrid implantable microphone (VAHIM) that combines acceleration and sound pressure sensors. Each sensor can collect the vibration of the umbo and sound pressure of the middle ear cavity. The fabricated sensor was implanted into a human temporal bone and the noise level and sensitivity were measured. From the experimental results, it is shown that the proposed method is able to provide a wider-frequency band than conventional implantable acoustic sensors. Full article
