In this work, a new approach to high-speed multi-coordinate milling was developed. The new approach is based on a new model of trochoidal machining; this is, in turn, based on the theoretical thickness of a chip and its ratio to the cutting edge’s radius, allowing us to establish the vibroacoustic indicators of cutting efficiency. The new model can be used for the real-time assessment of prevailing cutting mechanisms and chip formation. A set of new indicators and parameters for trochoidal high-speed milling (HSM), which can be used to calculate tool paths during technological preparation of slotting, was determined and verified. The size effect in the multi-coordinate HSM of slots on cast iron was identified based on the dependency of vibroacoustic signals on the cutting tooth’s geometry, HSM’a operational machining modes, theoretical chip thicknesses, the sizes of the cut chips, and the quality/roughness of the surface being machined. Based on the analysis of vibroacoustic signals, a set of the most important indicators for monitoring HSM and determining cutting and crack-formation mechanisms during chip deformation was derived. Based on the new model, recommendations for monitoring HSM and for assigning the tool path relative to the workpiece during production preparation were developed and validated. Full article

The present work intends to assess the impact of trochoidal toolpath rounding radius loop adjustments on surface roughness, nose radius wear, and resultant cutting force during end milling of AISI D3 steel. Twenty experimental trials have been performed utilizing a face-centered central composite design through a response surface approach. Artificial Neural Network (ANN) models were built to forecast outcomes, utilizing four distinct learning algorithms: the Batch Back Propagation Algorithm (BBP), Quick Propagation Algorithm (QP), Incremental Back Propagation Algorithm (IBP), and Levenberg–Marquardt Back Propagation Algorithm (LMBP). The efficacy of these models was evaluated using RMSE, revealing that the LMBP model yielded the lowest RMSE for surface roughness (Ra), nose radius wear, and resultant cutting force, hence demonstrating superior predictive capability within the trained dataset. Additionally, a Genetic Algorithm (GA) was employed to ascertain the optimal machining settings, revealing that the ideal parameters include a cutting speed of 85 m/min, a feed rate of 0.07 mm/tooth, and a rounding radius of 7 mm. Moreover, the detachment of the coating layer resulted in alterations to the tooltip cutting edge on the machined surface as the circular loop distance increased. The initial arc radius fluctuated by 33.82% owing to tooltip defects that alter the edge micro-geometry of machining. The measured and expected values of the surface roughness, resultant cutting force, and nose radius wear exhibited discrepancies of 6.49%, 4.26%, and 4.1%, respectively. The morphologies of the machined surfaces exhibited scratches along with laces, and side flow markings. The back surface of the chip structure appears rough and jagged due to the shearing action. Full article

Powder metallurgy (PM) technology is extensively employed in the manufacturing sector, yet its processing presents numerous challenges. To alleviate these difficulties, green machining of PM green compacts has emerged as an effective approach. The aim of this research is to explore the deformation features of green compacts and assess the impact of various machining parameters on the force of cutting. The cutting variables for compacts of PM green were modeled, and the cutting process was analyzed using Abaqus (2022) software. Subsequently, the orthogonal test ANOVA method was utilized to evaluate the significance of each parameter for the cutting force. Optimization of the machining parameters was then achieved through a genetic algorithm for neural network optimization. The investigation revealed that PM green compacts, which are brittle, undergo a plastic deformation stage during cutting and deviate from the traditional model for brittle materials. The findings indicate that cutting thickness exerts the most substantial influence on the cutting force, whereas the speed of cutting, the tool rake angle, and the radius of the rounded edge exert minimal influence. The optimal parameter combination for the cutting of PM green compacts was determined via a genetic algorithm for neural network optimization, yielding a cutting force of 174.998 N at a cutting thickness of 0.15 mm, a cutting speed of 20 m/min, a tool rake angle of 10°, and a radius of the rounded edge of 25 μm, with a discrepancy of 4.05% from the actual measurement. Full article

Metal machining production faces a myriad of demands encompassing ecology, automation, product control, and cost reduction. Within this framework, an exploration into employing a direct inspection of the machined area within the work zone of a given machine through a confocal chromatic sensor was undertaken. In the turning process, parameters including cutting speed (A), feed (B), depth of cut (C), workpiece length from clamping (D), and cutting edge radius (E) were designated as input variables. Roundness deviation (Rd) and tool face wear (KM) parameters were identified as output factors for assessing process performance. The experimental phase adhered to the Taguchi Orthogonal Array L27. Confirmatory tests revealed that optimizing process parameters according to the Taguchi method could enhance the turning performance of C45 steel. ANOVA results underscored the significant impact of cutting speed (A), feed (B), depth of cut (C), and workpiece length from clamping (D) on turning performance concerning Rd and KM. Furthermore, initial regression models were formulated to forecast roundness variation and tool face wear. The proposed parameters were found to not only influence the machined surface but also affect confocal sensor measurements. Consequently, we advocate for the adoption of these optimal cutting conditions in product production to bolster turning performance when machining C45 steel. Full article

A study was made of the machinability of NiTi alloy in turning, under conditions resulting in a small cutting layer. The experiment involved cutting with variable feeds ranging from 0.01 to 0.1 mm/rev. The cutting conditions were carefully chosen, considering the rounding radius of the cutting edge. The machined surface was examined and measured in 3D using a confocal microscope and in 2D with a contact profilometer. These measurements were used to estimate h_min, leading to the development of a surface formation model that considers both the lateral material flow due to h_min and the lateral material flow due to altered thermodynamic conditions from the previous blade pass. A method for evaluating the surface and selecting its characteristics was proposed based on analyses derived directly from surface features: PCA (Principal Component Analysis) and EMD (Empirical Mode Decomposition) with the Hilbert transform (Hilbert–Huang transform). PCA analysis facilitated the examination of individual surface component variances, while analysis of the IMF components enabled the assessment of surface component energy combined with instantaneous frequencies. Full article

Powder metallurgy (PM) is a manufacturing technique that employs metal powder as the raw material, which is then molded and sintered to produce various products. PM green compacts are inherently weak, rendering them prone to damage during machining due to cutting forces, which also affect the quality of the machined surface. To study the impact of different machining variables on cutting force, a finite element simulation (FEM) was employed, focusing on cutting thickness, cutting speed, tool rake angle, and rounded edge radius. The results indicated that cutting thickness had a highly significant impact on cutting force, while the rounded-edge radius and cutting speed were also significant factors. The tool rake angle was found to have minimal effects. The optimal parameters for minimizing cutting force were identified: a cutting thickness of 0.20 mm, a cutting speed of 120 m/min, a tool rake angle of 0°, and a rounded-edge radius of 40 μm, which reduced the cutting force to 887.95 N. Full article

The slot milling cutter is primarily used for machining the tongue and groove of the steam turbine rotor, which is a critical operation in the manufacturing process of the steam turbine rotor. It is challenging to predict the milling force of a groove milling cutter due to variations in rake, rake angles and cutting speeds of the main cutting edge. Firstly, based on a limited amount of experimental data on turning, we have developed an equivalent turning force model that takes into account the impact of the rounded cutting edge radius, the tool’s tip radius and the feed rate on tool’s geometric angle. It provides a more accurate frontal angle for the identification method of the Johnson–Cook material constitutive equation. Secondly, the physical parameters, such as shear stress, shear strain and strain rate on the main shear plane, are calculated through the analysis of experimental data and application of the orthogonal cutting theory. Thirdly, the range of initial constitutive parameters of the material was determined through the split Hopkinson pressure bar (SHPB) test. The objective function was defined as the minimum error between the theoretical and experimental values. The optimal values of the Johnson–Cook constitutive equation parameters A, B, C, n and m are obtained through a global search using a genetic algorithm. Finally, the shear stress is determined by the governing equations of deformation, temperature and material. The axial force, torque and bending moment of each micro-segment are calculated and summed using the unit cutting force vector of each micro-segment. As a result, a milling force prediction model for slot milling cutters is established, and its validity is verified through experiments. Full article

In the present study, the impact of cutting-edge microgeometry on the cutting forces in the finish milling of a 7075-aluminium alloy was analysed. The influence of selected values of the rounding radius of cutting edge, and the size of the margin width, on the cutting-force parameters was analysed. Experimental tests were carried out for different cross-sectional values of the cutting layer, changing the feed per tooth and radial infeed parameters. An analysis of the various statistical parameters of the force signal was performed. Experimental mathematical models of the relationship of the force parameters to the radius of the rounded cutting edge and the width of the margin were developed. The cutting forces were found to be most strongly influenced by the width of the margin and, to a minor extent, by the rounding radius of the cutting edge. It was proved that the effect of margin width is linear, and the effect of radius R is nonlinear and nonmonotonic. The minimum cutting force was shown to be for the radius of rounded cutting edge of about 15–20 micrometres. The proposed model is the basis for further work on innovative cutter geometries for aluminium-finishing milling. Full article

The residual stress state of the machined sub-surface influences the service quality indicators of a component, such as fatigue life, tribological properties, and distortion. During machining, the radius of the cutting edge changes due to tool wear. The cutting-edge rounding significantly affects the residual stress state in the part and the occurring process forces. This paper presents a tool wear prediction model based on in-process measured cutting forces. The effects of the cutting-edge geometry on the force behavior and the machining-induced residual stresses were examined experimentally. The resulting database was used to realize a Machine Learning algorithm to calculate the hidden value of tool wear. The predictions were validated by milling experiments using rounded cutting edges for different process parameters. The microgeometry of the cutting edge could be determined with a Root Mean Square Error of 8.94 μm. Full article

In order to improve the tool life and micro-hole machining quality, the H-shaped chisel edge micro-drill (HCE-MD) was developed in this paper. The HCE-MD was characterized by the inner edge formed through the chisel edge thinning. In the micro-drilling process, the inner edge can perform positive rake cutting, so the machining area of the workpiece extruded by cutting edge with a negative rake angle is reduced. Based on this, the distribution of rake angle near the chisel edge corner is improved. Then, the HCE-MD was fabricated on the six-axis CNC grinding machine. The grinding process parameters of the micro-drill were optimized based on the orthogonal grinding test and grey relational grade theory. The size and shape accuracy of the micro-drill were controlled by the multi-axis linkage grinding method and the movement-axis micro compensation method. Finally, the 0.25 mm HCE-MD was fabricated with the cutting edge radius of 1.94 μm and the flank surface roughness of 0.25 μm. The drilling performance of HCE-MD was evaluated through comparative drilling experiments. The experimental results show that, compared with common micro drill, the HCE-MD produced lower thrust force and better micro-hole roundness accuracy, and reduced the micro-drill wear on the chisel edge and the flank. Full article

To improve the cutting performance of the core drill, the flexible fiber assisted shear-thickening polishing (FF-STP) for cutting edge preparation was proposed to eliminate the microscopic defect and obtain proper radius of the cutting edge of the core drill. The flexible fiber was introduced into the shear-thickening polishing process to break the thickened agglomerates and improve the efficiency of cutting edge preparation. The influence of the polishing speed, abrasive concentration and the flexible fiber contact length with the core drill on the cutting edge radius r and surface morphology of the core drill edge was analyzed, and the drilling experiments were carried out after preparation, the cutting heat and drilled holes’ roughness were employed as evaluation indexes to evaluate the performance of the core drill. The results show that the cutting edge radius increases with the increase of polishing speed, abrasive concentration and contact length. However, too high a polishing speed and contact length reduce the abrasive particles involved in the polishing process, and then lead to a decline in preparation efficiency. Under the selected processing conditions, the cutting edge radius increases from the initial 5 μm to 14 μm and 27 μm with 4 min of treatment and 6 min of treatment preparation, respectively. The sharp cutting edge becomes rounded, the burrs and chipping on the cutting edge are eliminated, and the average roughness (R_a) of the flank face decreases from 110.4 ± 10 nm to 8.0 ± 3 nm. Nine holes were drilled consecutively by core drills after cutting edge preparation, and the cutting temperature and drilled holes’ roughness were recorded. The maximum cutting temperature (122.4 °C) in the process with the prepared core drill (radius r = 14 μm) is about 20 °C lower than that with untreated one, and the roughness of the drilled hole (R_a 510.5 nm) about 189.9 nm lower. The results indicates that FF-STP is a promising method for high consistency preparation of the core drill cutting edge. Full article

This paper proposes a novel scheme titled ‘selective exchange of the worn cutting edge (SEWCE),’ which uses the cutting edge for an extended time by replacing the worn-out edge. This possibility was investigated for single-edge cutting tools for several operations, such as oblique and orthogonal cutting. The unique design of the turning tool incorporating cylindrical inserts was developed, thereby providing new machining possibilities compared to marketed solutions for round inserts. The prototype tool was prepared for the demonstration by using a cylinder with radius r_ε = 1.5 mm. A detailed analysis of the contact-zone cutting edge was performed considering a theoretical number of edges for different strategies. With this, the possibility for reusing the cutting element by resharpening the rake surface by up to ‘20x’ was achieved. Additionally, round inserts can be efficiently used in this developed scenario by turning them to compensate for the worn parts of the cutting tools. Therefore, by rotating, the deformed section of the cutting tool can be eliminated, and the number of edges can be created, directly reducing tool costs. Ultimately, conserving the health of a cutting tool brings many advantages, such as extending useful remaining lifetime, improving the surface quality and dimensional accuracy of machine parts, etc. Full article

Graphite/polymer composites are brittle materials, and tool wear, which has a significant impact on the quality of the machined surface of the material, is very serious during the cutting process. In general, the magnitude of the cutting force directly affects the tool wear; the larger the cutting force, the more severe the tool wear, which in turn affects the machined surface quality of graphite/polymer composites. Therefore, in this study, the effects of machining parameters on cutting forces during orthogonal cutting of graphite/polymer composites were investigated using single-factor and multifactor experiments with cutting speed, cutting thickness, tool rake angle, and rounded edge radius as influencing factors, and the parameters were optimized. The obtained results showed that reducing the cutting thickness and increasing the tool rake angle would significantly reduce the cutting force. During the orthogonal cutting process, when the tool had a small edge radius, the cutting force along the cutting direction was significantly larger than the cutting force along the vertical direction, and as the rounded edge radius increased, the cutting force in the vertical direction exceeded the cutting force in the cutting direction. Finally, the significance of the effect of different machining parameters on the cutting forces was analyzed using analysis of variance (ANOVA). The obtained results showed that the cutting speed, cutting thickness, tool rake angle, and rounded edge radius were extremely significant for the cutting forces along the cutting direction as well as in the vertical direction during orthogonal cutting of graphite/polymer composites. Full article

In recent years, cutting edge preparation became a topic of high interest in the manufacturing industry because of the important role it plays in the performance of the cutting tool. This paper describes the use of the drag finishing DF cutting edge preparation process on the cutting tool for the broaching process. The main process parameters were manipulated and analyzed, as well as their influence on the cutting edge rounding, material remove rate MRR, and surface quality/roughness (Ra, Rz). In parallel, a repeatability and reproducibility R&R analysis and cutting edge radius r_e prediction were performed using machine learning by an artificial neural network ANN. The results achieved indicate that the influencing factors on r_e, MRR, and roughness, in order of importance, are drag depth, drag time, mixing percentage, and grain size, respectively. The reproducibility accuracy of r_e is reliable compared to traditional processes, such as brushing and blasting. The prediction accuracy of the r_e of preparation with ANN is observed in the low training and prediction errors 1.22% and 0.77%, respectively, evidencing the effectiveness of the algorithm. Finally, it is demonstrated that the DF has reliable feasibility in the application of edge preparation on broaching tools under controlled conditions. Full article

This research aimed at an increase in wear resistance of round cutting plates manufactured with SiAlON dielectric ceramics through deposition of wear-resistant coatings. To increase effectiveness of the coatings, their adhesion was improved by the removal of defective surface layers from the cutting plates before the deposition. As the depth of caverns and grooves appearing on the cutting plates due to manufacturing by diamond grinding reached 5 µm, a concentrated beam of fast argon atoms was used for the removal of defective layers with a thickness exceeding the depth of caverns and grooves. At the equal angles of incidence to the front and back surfaces of the cutting wedge amounting to 45 degrees, two-hour-long etching of rotating cutting plates provided removal of defective layers with thickness of ~10 µm from the surfaces. After the removal, the cutting edge radius of the plates diminished from 20 to 10 µm, which indicates the cutting plates’ sharpening. Wear-resistant TiAlN coatings deposited after the etching significantly improve the processing stability and increase wear resistance of the cutting plates by not less than 1.7 times. Full article
