Recently, the increasing concern for climate control has led to the widespread application of grid-connected inverter (GIC)-based renewable-energy systems. In addition, the increased usage of non-linear loads and electrification of the transport sector cause ineffective grid-frequency management and the introduction of harmonics. These grid conditions affect power quality and result in uncertainty and inaccuracy in monitoring and measurement. Incorrect measurement leads to overbilling/underbilling, ineffective demand and supply forecasts for the power system, and inefficient performance analysis. To address the outlined problem, a novel, three-phase frequency component extraction and power measurement method based on Digital Lock-in Amplifier (DLIA) and Digital Lock-in Amplifier–Frequency-Locked Loop (DLIA–FLL) is proposed to provide accurate measurements under the conditions of harmonics and frequency offset. A combined filter, with a lowpass filter and notch filter, is employed to improve computation speed for DLIA. A comparative study is performed to verify the effectiveness of the proposed power measurement approach, by comparing the proposed method to the windowed interpolated fast Fourier transform (WIFFT). The ZERA COM 3003 (a commercial high-accuracy power measurement instrument) is used as the reference instrument in the experiment. Full article

Retired electric vehicle (EV) batteries are reused in second-life energy storage applications. However, the overall performance of repurposed energy storage systems (ESSs) is limited by the variability in the individual batteries used. Therefore, battery grading is required for the optimal performance of ESSs. Electrochemical impedance spectroscopy (EIS)-based evaluation of battery aging is a promising way to grade lithium-ion batteries. However, it is not practical to measure the impedance of mass-retired batteries due to their high complexity and slowness. In this paper, a broadband multi-sine binary signal (MSBS) perturbation integrated with a multichannel EIS system is presented to measure the impedance spectra for the high-speed aging evaluation of lithium-ion batteries or modules. The measurement speed is multiple times higher than that of the conventional EIS. The broadband MSBS is validated with a reference sinusoidal sweep perturbation, and the corresponding root-mean-square error (RMSE) analysis is performed. Moreover, the accuracy of the presented multichannel EIS system is validated by impedance spectra measurements of Samsung INR18650-29E batteries and compared with those measured using a commercial EIS instrument. A chi-squared error under 0.641% is obtained for all channels. The non-linearity of batteries has a significant impact on the quality of impedance spectra. Therefore, Kronig–Kramer (KK) transform validation is also performed. Full article

Interturn short circuit (ITSC) fault is a common fault in electric machines, which may severely damage the machines if no protective measure is taken in time. There are numerous fault diagnosis methods under a steady-state condition. However, there is relatively limited research on fault diagnosis under dynamic conditions. The dynamic operation of motors, such as in electric cars, is a very common scenario. Hence, this paper proposes a search-coil based online method for detecting ITSC fault in permanent magnet synchronous machine (PMSM) under a dynamic condition. The search coils are placed on the stator circumference at equal intervals. Each search coil reflects the information about the magnetic field in its vicinity and also contains the fault information. In this paper, the voltage induced by the odd sideband harmonics around the even carrier (2ωc±ω0) is selected as the fault characteristic to be used in effectively improving the detected signal-to-noise ratio by excluding the interference of the counter-potential of the permanent magnet. Since two adjacent search coils are placed one pole apart, a set of quadrature signals can be acquired. The Digital Lock-In Amplifier (DLIA) technology is applied to extract the amplitude of the characteristic voltage, which overcomes the shortcomings of the traditional spectrum analysis in applying to non-stationary conditions. The amplitudes of the voltage at different search coils can be compared to further determine the occurrence of a fault and also its rough location if occurred. Experiments were conducted with a six-phase PMSM for demonstrating the effectiveness of the proposed method. The obtained results show that the proposed method can accurately determine the occurrence of a fault. Full article

Lithium-ion batteries are gaining more attention due to the rapid growth of electrical vehicles (EVs). Additionally, the industry is putting a lot of effort into reusing EV batteries in energy storage systems (ESS). The optimal performance of the repurposed battery system is highly dependent on the individual batteries used in it. These batteries need to be similar in terms of battery capacity, state of health (SOH), and remaining useful life (RUL). Therefore, battery grading techniques are expected to play a vital role in this newly emerging industry. There are various methods suggested to evaluate the aging of a battery in terms of capacity, SOH, and RUL. The use of ohmic resistance is one approach, as it varies with the aging of the battery. In order to measure the ohmic resistance, electrochemical impedance spectroscopy (EIS) is used, followed by the curve fitting procedures. In this research a novel method is suggested to measure the ohmic resistance without performing the broadband conventional EIS test and the curve fitting. Since the battery is perturbed for a specified frequency band (1 kHz to 100 Hz) using the linearly distributed phased multi-sine signal, only 1 sec perturbation is required, and the ohmic resistance can be directly calculated by using two impedance values. Thus, the measurement speed is several times faster than that of the conventional EIS methods. Hence, it is a suitable and convenient technique for the mass testing of the batteries. The accuracy and validity of the proposed technique are verified by testing three types of batteries. The percentage difference in the measured ohmic resistance value between the conventional and the proposed technique is less than 0.15% for all the batteries tested. Full article

Electrochemical impedance spectroscopy (EIS) can provide information about the internal state of fuel cells, which makes EIS an important tool for fuel cell fault diagnosis. However, high cost, large volume, and poor scalability are limitations of existing EIS measurement equipment. In this study, a multi-channel online fuel cell EIS measurement device was designed. In this device, based on multi-phase interleaved Boost topology and average current control, an excitation source, which can output 1~500 Hz, 10 A sinusoidal excitation current was designed and verified by model simulation. Then, based on the quadrature vector digital lock-in amplifier (DLIA) algorithm, an impedance measuring module that can achieve precise online impedance measurement and calculation was designed. A prototype was then built for the experiment. According to the experiment test, the amplitude error of the excitation source is less than 1.8%, and the frequency error is less than 0.3%. Compared with the reference data, the impedance measured by the prototype has a modulus error of less than 3.5% and a phase angle error of less than 1.5°. Moreover, the waveform control and impedance extraction function of the EIS measurement device is implemented on an embedded controller, which can cut the price and reduce the volume. Full article

In this work, we report on the design of a wide-band digital lock-in amplifier (DLIA) of up to 65 MHz and its application for electrical impedance measurements in microfluidic devices. The DLIA is comprised of several dedicated technologies. First, it features a fully differential analog circuit, which includes a preamplifier with a low input noise of 4.4 nV/√Hz, a programmable-gain amplifier with a gain of 52 dB, and an anti-aliasing, fully differential low-pass filter with −76 dB stop-band attenuation. Second, the DLIA has an all-digital phase lock loop, which features a phase deviation of less than 0.02° throughout the frequency range. The phase lock loop utilizes an equally accurate period-frequency measurement, with a sub-ppm precision of frequency detection. Third, a modified clock link is implemented in the DLIA to improve the signal-to-noise ratio of the analog-to-digital converter affected by clock jitter of up to 20 dBc. A series of measurements were performed to characterize the DLIA, and the results showed an accurate performance. Additionally, impedance measurements of standard-size microparticles were performed by frequency sweep from 300 kHz to 30 MHz, using the DLIA in a microfluidic device. Different diameters of microparticle could be accurately distinguished according to the relative impedance at 2.5 MHz. The results confirm the promising applications of the DLIA in microfluidic electrical impedance measurements. Full article

Functional near‐infrared spectroscopy (fNIRS) systems for e‐health applications usually suffer from poor signal detection, mainly due to a low end‐to‐end signal‐to‐noise ratio of the electronics chain. Lock‐in amplifiers (LIA) historically represent a powerful technique helping to improve performance in such circumstances. In this work a digital LIA system, based on a Zynq® field programmable gate array (FPGA) has been designed and implemented, in an attempt to explore if this technique might improve fNIRS system performance. More broadly, FPGA‐based solution flexibility has been investigated, with particular emphasis applied to digital filter parameters, needed in the digital LIA, and its impact on the final signal detection and noise rejection capability has been evaluated. The realized architecture was a mixed solution between VHDL hardware modules and software modules, running within a microprocessor. Experimental results have shown the goodness of the proposed solutions and comparative details among different implementations will be detailed. Finally a key aspect taken into account throughout the design was its modularity, allowing an easy increase of the input channels while avoiding the growth of the design cost of the electronics system. Full article

Weak voltage signals cannot be reliably measured using currently available logging tools when these tools are subject to high-temperature (up to 200 °C) environments for prolonged periods. In this paper, we present a digital lock-in amplifier (DLIA) capable of operating at temperatures of up to 200 °C. The DLIA contains a low-noise instrument amplifier and signal acquisition and the corresponding signal processing electronics. The high-temperature stability of the DLIA is achieved by designing system-in-package (SiP) and multi-chip module (MCM) components with low thermal resistances. An effective look-up-table (LUT) method was developed for the lock-in amplifier algorithm, to decrease the complexity of the calculations and generate less heat than the traditional way. The performance of the design was tested by determining the linearity, gain, Q value, and frequency characteristic of the DLIA between 25 and 200 °C. The maximal nonlinear error in the linearity of the DLIA working at 200 °C was about 1.736% when the equivalent input was a sine wave signal with an amplitude of between 94.8 and 1896.0 nV and a frequency of 800 kHz. The tests showed that the DLIA proposed could work effectively in high-temperature environments up to 200 °C. Full article
