Search Results (12)

A straightforward and versatile numerical approach is proposed for the nonlinear analysis of single and double-curvature masonry structures. The method is designed to broaden accessibility to both experienced and less specialized users. Masonry units are discretized with elastic quadrilateral elements, while mortar joints are modeled with a combination of elastic orthotropic plate elements or shear panels and elastic perfectly brittle trusses (cutoff bars). This method employs the simplest inelastic finite element available in any commercial software to lump nonlinearities exclusively within the mortar joints. It effectively captures the failure of curved structures under Mode 1 deformation, reproducing the typical collapse mechanism of unreinforced arches and vaults via flexural plastic hinges. The proposed method is benchmarked through three case studies drawn from the literature, each supported by experimental data and numerical results of varying complexity. A comprehensive evaluation of the global force–displacement curves, along with the analysis of the thrust line and the evolution of nonlinearities within the model, demonstrates the effectiveness, reliability, and simplicity of the approach proposed. By bridging the gap between advanced simulation and practical application, the approach provides a robust tool suitable for a wide range of users. This study contributes to a deeper understanding of the behavior of unreinforced curved masonry structures and lays a base for future advancements in the analysis and conservation of historical heritage. Full article

Gradient porous structures (GPS) offer significant mechanical and functional advantages over homogeneous counterparts. This paper proposes a computational design framework utilizing spatial Voronoi diagrams to create lightweight, stress-responsive spatial frames optimized for architectural double-curvature arched shell roofing components. The method integrates Solid Isotropic Material with Penalization (SIMP)-based topology optimization (TO) to establish initial stress-informed material distributions, adaptive Voronoi control point (CP) placement guided by localized stress data, and a bi-objective genetic algorithm (GA) optimizing maximum and average displacement. Following optimization, a weighted Lloyd relaxation (LR) refines Voronoi cells into spatial frameworks with varying densities corresponding to stress gradients. Finite Element Analysis (FEA) demonstrates that the optimized Voronoi-driven GPS achieves notable improvements, revealing up to 79.7% material volume reduction and significant improvement in structural efficiency, achieving a stiffness-to-weight ratio (SWR) exceeding 2200 in optimized configurations. Furthermore, optimized structures consistently maintain maximum von Mises (MVM) stresses below 20 MPa, well within the allowable yield strength of the Polyethylene Terephthalate Glycol (PETG) material (53 MPa). The developed framework effectively bridges structural performance, material efficiency, and aesthetic considerations, offering substantial potential for application in advanced, high-performance architectural systems. Full article

Given the potential for dynamic load-induced support crushing that may occur during mining under an interval goaf through an isolated coal pillar (ICP) in shallow closely spaced coal seams, this paper systematically explored this issue through a case study of the 30,103 working face at the Nanliang Coal Mine. We employed a combined approach of similarity simulations, theoretical analyses, numerical simulations, and field measurements to investigate the catastrophic failure mechanisms and prevention strategies for dynamic pressure-related hazards encountered when mining a lower coal seam that passes through an ICP. The findings indicated that the synchronous cutting instability of the interlayer effective bearing stratum (IEBS) and double-arch bridge structure of the ICP roof were the primary causes of dynamic load-induced support crushing at the working face. A mechanical model was developed to characterize the IEBS instability during mining under an interval goaf. The sources and transmission pathways of dynamic mining pressure during mining passing through the ICP were clarified. The linked instability of the double-arch bridge structure of the ICP roof was induced by IEBS failure. The UDEC numerical model was utilized to elucidate the instability of the IEBS during mining in the lower coal seam and to analyze the vertical stress distribution patterns in the floor rock strata of the interval goaf. A comprehensive prevention and control strategy for roof dynamic pressure, which includes pre-releasing concentrated stress in the ICP, strengthening the support strength of the working face, and accelerating the advancement speed was proposed. The effectiveness of this prevention and control strategy was validated through actually monitoring the characteristics of mining pressure data from the 30,103 working face following pressure relief. The findings provide valuable insights for rock stratum control of shallow and closely spaced coal seam mining under similar conditions. Full article

Bridges, as vital infrastructure, require ongoing monitoring to maintain safety and functionality. This study introduces an innovative algorithm that refines bridge component performance assessment through the integration of modified K-means clustering, silhouette coefficient optimization, and cloud model theory. The purpose is to provide a reliable method for monitoring the safety and serviceability of critical infrastructure, particularly double-layer truss arch bridges. The algorithm processes large datasets to identify patterns and manage uncertainties in structural health monitoring (SHM). It includes field monitoring techniques and a model-driven approach for establishing assessment thresholds. The main findings, validated by case studies, show the algorithm’s effectiveness in enhancing clustering quality and accurately evaluating bridge performance using multiple indicators, such as statistical significance, cluster centroids, average silhouette coefficient, Davies–Bouldin index, average deviation, and Sign-Rank test p-values. The conclusions highlight the algorithm’s utility in assessing structural integrity and aiding data-driven maintenance decisions, offering scientific support for bridge preservation efforts. Full article

The study of the dynamic response characteristics of “W”-type deep canyon terrain to double-span concrete arch bridges under earthquake action holds great practical significance. In this research, a bridge in Sichuan Province is taken as the object of study. The boundary-integral equation method and peak frequency shift method are combined to apply an embedded linear time–history analysis algorithm to the finite element spatial dynamic calculation model of the entire bridge, resulting in an improved model. By comparing these two methods with model test results, the seismic response characteristics of the middle part of a “W” concrete arch bridge under different foundation depths and seismic intensities are examined. The boundary integral equation method was utilized to calculate ground motion response at any point on site, revealing a significant amplifying effect of increased seismic wave intensity on acceleration response at the top of the arch bridge. When input seismic wave intensity increased from 0.1 g to 0.3 g, maximum acceleration at buried depths of 3 m and 8 m in the middle of the arch bridge foundation increased by 102.63% and 79.16%, respectively, indicating that shallow buried depth structures are more sensitive to seismic wave intensity. Furthermore, using peak frequency shift rules for analyzing seismic wave propagation characteristics in “W”-type deep canyon topography confirms the sensitivity of shallow buried depth structures to seismic wave intensity and reveals the mechanism through which topography influences seismic wave propagation. This study provides a helpful method for understanding the propagation law and energy distribution characteristics of seismic waves in complex terrain. It was observed that the displacement at the top of the arch bridge increased significantly with an increase in seismic intensity. When subjected to 0.1 g, 0.2 g, and 0.3 g EI-Centro seismic waves, the maximum displacement at the top of the arch bridge model with a foundation buried depth of 3 m was 8 mm, 32 mm, and 142 mm, respectively. For arch bridge models with an 8-m foundation buried depth, these displacements were measured at 6.2 mm, 21 mm, and 68 mm, respectively. The results from model tests verified that increasing the depth of foundation burial effectively reduces the displacement at the top of the structure. Furthermore, by combining a boundary-integral equation method and peak-frequency shift method, this study accurately predicted significant influences on W-shaped double deep canyon topography from seismic response, and successfully captured stress concentration and seismic wave amplification/focusing effects on arch foot structures. The calculated results from both methods align well with model test data which confirm their effectiveness and complementarity when analyzing seismic responses under complex terrain conditions for bridge structures. Full article

Steel truss–arch composite bridge systems are widely used in bridge engineering to provide sufficient space for double lanes. However, a lack of research exists on their mechanical performance throughout their lifespan, resulting in uncertainties regarding bearing capacity and the risk of bridge failure. This paper conducts a numerical study of the structural mechanical performance of a flexible arch composite bridge with steel truss beams throughout its lifespan to determine the critical components and their mechanical behavior. Critical vehicle loads are used to assess the bridge’s mechanical performance. The results show that the mechanical performance of the bridge changes significantly when the temporary piers and the bridge deck pavement are removed, substantially influencing the effects of the vehicle loads on the service life. The compressive axial force of the diagonal bar significantly increases to 33,101 kN near the supports during the two construction stages, and the axial force in the upper chord of the midspan increases by 4.1 times under a critical load. Moreover, the suspender tensions and maximum vertical displacement are probably larger than the limit of this bridge system in the service stage, and this is caused by the insufficient longitudinal bending stiffness of truss beams. Therefore, monitoring and inspection of critical members are necessary during the removal of temporary piers and bridge deck paving, and an appropriate design in steel truss beams is required to improve the life cycle assessment of this bridge system. Full article

The structure of a bridge has certain peculiarities, and its pile foundations are susceptible to uplift or settlement deformation due to various factors. This can result in bridge deck cracking, structural instability, tilting, and even irreversible damage, which significantly impacts the bridge’s stability and driving safety. This study focuses on the Shiyangtai No.1 Bridge and aims to investigate the factors that cause abnormal rise and fall deformations of bridge pile foundations. The study combines macro and micro analysis, physical characteristic testing of the overlying soil under the bridge pile foundation, and numerical simulation of the bridge pile foundation in the goaf. The study discusses in-depth the formation mechanism of the abnormal uplift of some pile foundations of the Shiyangtai No.1 Bridge based on the analysis of the factors influencing the abnormal rise and fall deformation of the bridge pile foundations at home and abroad. The expansive soil beneath the pile foundation is weak, and the force generated by the water expansion is insufficient to cause the pile foundation to rise to 309 mm. The results indicate that the pile foundation of the bridge is not affected by the expansion characteristics of the overlying soil. The collapse of the goaf roof generates double lateral thrust from the accumulation body at the bottom of the goaf and the upper collapse arch. This causes staggered bending uplift of the sandstone soil layer, resulting in upward squeezing pressure that causes the bridge pile foundation to rise. Therefore, the coal mining area is the main factor influencing the abnormal uplift of the pile foundation of the Shiyangtai No.1 Bridge. Full article

To effectively control the stress state and spatial alignment of arch ribs in the cable hoisting construction of a long-span, concrete-filled, steel tube arch bridge and ensure the safety of the structure, it is necessary to calculate and determine the appropriate cable force. Based on the actual project of a double-span, concrete-filled, steel tubular arch bridge, the construction stage of the left span of the bridge from the beginning of construction to the closure is taken as an example. The linear control method of “quiet do not move” is adopted. Based on the principle that the vertical displacement of the front end of the installed segment caused by the self-weight of the new hoisting segment is equal to the vertical displacement of the front end of the previous segment caused by the tension of the new hoisting segment, the tension cable force is calculated by forward iteration. Finally, based on the theory of the stress-free state method, the ideal linear design of the structure was achieved. The results show that after the closure of the bridge, the error range of the cable tension force is −13.33–15.40% on the left bank and −8.37–11.00% on the right bank. The elevation error of the arch rib is −0.003–0.043 m on the left bank and −0.007–0.032 m on the right bank. The overall stress error of the bridge arch is ±7.0 MPa. The error between the theoretical value and the actual value is within the scope of the specification requirements, which meets the specification requirements. After the closure, the arch shape of the bridge meets the smooth requirements. Full article

The conventional support forms of foundation pit retaining piles include single-row piles, double-row piles, anchor-row piles, and so on. The double-row pile supporting structure is widely used in the deep foundation pit supporting the engineering of wharves, bridges, subways, tunnels, and high-rise and super-high-rise buildings. This study on double-row pile supporting structures mainly focuses on four aspects: (1) The influence of dimension parameters, such as pile diameter and pile length, and engineering parameters, such as pile spacing and row spacing, on the deformation control of a double-row pile structure and the stability control of foundation pits; (2) Influence of the soil arch effect on the stress and deformation of the double-row pile supporting structure; (3) Study on the deformation characteristics and rules of the components and the whole structure of the double-row pile supporting structure; (4) Study on the calculation model of pile-soil interactions. Based on the above four aspects, this paper summarizes the latest research status of the existing double-row pile supporting structure and its stress and deformation characteristics. The deformation characteristics and calculation model of the pile-soil interaction of double-row piles are reviewed and evaluated. Finally, the problems and deficiencies in the research on double-row pile support are summarized. These results provide a reference for future research on the double-row pile supporting structure of the foundation pit and the numerical analysis and calculation model and lay a solid foundation for further development of the theory. Full article

The first main and secondary collaborative Y-shaped steel box arch bridge under construction in China is a rarely seen innovative practice among bridges already built at home and abroad, which is an attractive engineering research topic in the field of advanced bridge design and construction, and the investigation of this bridge has made a groundbreaking contribution. The structure of unconventional thin-walled steel box arch ribs is very novel, abandoning the traditional two-dimensional arch rib structure form and adopting the new structural mode of single–double combination and joint working of main and secondary arches. However, for this innovative design, many technical difficulties including innovative design details, mechanical behavior of thin-walled structures and construction methods still need to be pioneeringly explored and thoroughly researched. In this paper, the innovative design concept of unconventional thin-walled arch ribs for spatial Y-shaped steel box arch bridges is described, and a comparative analysis with the corresponding conventional single arch rib structure is carried out. Due to the limitations of the common conventional arch bridge research methods, a combined global and local finite element method is used to analyze the static and dynamic properties of the structure, and the shear lag effect of the thin-walled steel box arch ribs is studied in a pioneering and exploratory approach. In addition, the stress distribution of the bifurcated section of the arch ribs and the configuration of the diaphragm are analyzed in detail to verify the reasonableness, advantage and applicability of the innovative design. The results show that the main and secondary arch collaboration Y-shaped steel box arch bridge has reasonable structure and superior mechanical properties and has a greater value for promotion The design concept and analysis method are worthy of use as a reference for the aesthetical and mechanical design of similar spatial Y-shaped arch bridges in the future. Full article

In tied-arch bridges with a single arch, the deck is usually suspended from the arch by means of a single set of cables, pinned at both ends and anchored to the centerline, using either vertical or Nielsen-type hanger arrangements. When properly designed, this layout can significantly reduce forces and deflections under loads that are symmetrical with respect to the plane of the arch. However, it does not contribute to the support of nonsymmetrical loads, such as eccentric loads distributions or wind loading, and does not reduce the sensibility of the arch to out-of-plane buckling. Thus, this paper studies how a cable arrangement composed of two sets of lateral hangers, attached to both edges of a deck, can be very suitable to address these problems. Firstly, it is demonstrated that the structural behavior under symmetrical loads improves with respect to the bridge with centered hangers. Secondly, it is shown how nonsymmetric loads are partially carried by structural systems (such as the transversal stiffness both of the arch and the deck) that would remain inactive for tied-arch bridges with centered hangers, leading to a general reduction in the forces and the deflections of the bridge and in the critical buckling load of the arch. Full article

This study assessed the structural performance of reinforced concrete (RC) arch bridges under strong ground motion. A detailed three-dimensional finite element model of a 400 m RC arch bridge with composite superstructure and double RC piers was developed and its behavior when subjected to strong earthquakes examined. Two sets of ground motion records were applied to simulate pulse-type near- and far-field motions. The inelastic behavior of the concrete elements was then evaluated via a seismic time history analysis. The concept of Demand to Capacity Ratios (DCR) was utilized to produce an initial estimate of the dynamic performance of the structure, emphasizing the importance of capacity distribution of force and bending moment within the RC arch and the springings and piers of the bridge. The results showed that the earthquake loads, broadly categorized as near- and far-field earthquake loads, changed a number of the bridge’s characteristics and hence its structural performance. Full article
