Search Results (13)

This study investigates the underwater transient vibro-acoustic response of double-layered stiffened cylindrical shells through an integrated experimental-numerical approach. Initially, vibration and noise responses under transient impact loads were experimentally characterized in an anechoic water tank, establishing benchmark datasets. Subsequently, based on the theory of transient structural dynamics, a numerical framework was developed by extending the time-domain finite element/boundary element (FEM/BEM) method, enabling comprehensive analysis of the transient vibration and acoustic radiation characteristics of submerged structures. Validation through experimental-simulation comparisons confirmed the method’s accuracy and effectiveness. Key findings reveal broadband features with distinct discrete spectral peaks in both structural vibration and acoustic pressure responses under transient excitation. Systematic parametric investigations demonstrate that: (1) Reducing the load pulse width significantly amplifies vibration acceleration and sound pressure levels, while shifting acoustic energy spectra toward higher frequencies; (2) Loading position alters both vibration patterns and noise radiation characteristics. The established numerical methodology provides theoretical support for transient impact noise prediction and low-noise structural optimization in underwater vehicle design. Full article

In recent years, with the wide application of underwater vehicles, the vibration and noise problems generated during their operation have attracted great attention from the academic community. Compared with the field of traditional mechanical noise, research on vibration control of the noise that is transiently excited underwater still has significant deficiencies in terms of its theoretical depth and systematicity. In this paper, we take transient noise control for underwater vehicles as the engineering entry point; systematically explain the vibration mechanisms and dynamic characteristics of underwater double-layered cylindrical shell structures; and discuss the vibration transmission paths and the development trends in the control technology in depth. This study mainly includes the following contents. Firstly, the vibration response mechanisms of underwater double-layered cylindrical shells are sorted through a bibliometric analysis, and the evolution laws for plate–shell structures and the vibration transmission paths for single–double-shell structures are summarized systematically; secondly, the multi-path vibration transmission characteristics of double-layered cylindrical shells are analyzed based on energy transfer theory, and the contribution to transient noise through different transmission paths is quantitatively evaluated; and thirdly, the vibration transmission characteristics of active control, passive control, and hybrid control are evaluated systematically in terms of the dimensions of the control mechanism. Then, the engineering applicability of active, passive, and hybrid control technologies is systematically reviewed. Finally, combined with the development of new intelligent materials and adaptive algorithms, the prospective outlook for vibration control technology for shell structures under transient excitation conditions is presented. Full article

The application of double-layer shell structure is very common in some situations that require complex loads and vibrations, such as key components such as the shell and wings of aerospace engines, and the shell of underwater vehicles. Many authors have conducted research on the vibration and acoustic radiation characteristics of double-layer cylindrical shells. By adding reinforcement and ribs between the double-layer cylindrical shells and optimizing structural design, passive vibration control techniques can effectively solve high frequency vibration problems, but the impact on mid to low frequency vibrations is still limited. Therefore, this article conducts theoretical research on a novel active vibration control method that inserts an active actuator between a double-layer cylindrical shell to achieve better mid low frequency vibration control effects. Firstly, the substructure admittance method is applied to analytically and dynamically model a double-layer cylindrical thin shell structure with active support, and the vibration power flow of the system is theoretically derived to evaluate the vibration reduction effect. Then, numerical simulation analysis was conducted on the influence of different configurations of six feedback control parameters, time delays, and other factors on the vibration power flow. Finally, based on the image, the conclusion is drawn that all six feedback control parameters can improve the vibration control effect of the coupled system to a certain extent, but not every feedback control parameter has a prominent effect, and the effective range of some parameters is relatively narrow. Full article

This paper presents an improved rapid prediction method for solving the full-space bistatic scattering sound field of underwater vehicles. The scattering sound field is represented as the product of the acoustic scattering transfer function and the sound source density function. By utilizing target surface mesh information and partial scattered sound pressure data as known inputs, the method predicts other bistatic scattering sound fields through numerical integration, matrix theory, and the least squares method. To reduce the data input required for predicting the scattering field, the monostatic to bistatic equivalence theorem is incorporated into the algorithm. A comparison with simulation results demonstrates that the proposed approach achieves favorable computational efficiency and reliability. Experimental tests on a double-layered ribbed cylindrical shell further validate the method’s performance. Full article

The double-layered cylindrical shell represents a key structural configuration for underwater vehicles, where its vibration behavior remains a primary concern in engineering design and analysis. This study develops a spectral element method (SEM) for dynamic modeling of multi-component shell systems by extending the vibrational governing equations of conical shells. The methodology is validated through finite element method (FEM) case studies on both conical shells and double-layered cylindrical configurations. Parametric investigations examine ribbed substructures and solid rib plates within the cylindrical shell assembly, while artificial spring techniques model arbitrary boundary conditions—with validation against classical benchmarks confirming their effectiveness for elastic constraints. Numerical demonstrations reveal the following: rib and plate thickness variations exhibit a negligible impact on low-frequency vibrational responses; the natural frequency sensitivity peaks when the elastic boundary stiffness approaches the inherent dynamic stiffness of the shell’s base configuration, while extreme stiffness values approximate clamped or free boundary conditions with engineering significance. The proposed SEM framework demonstrates a superior computational efficiency and accuracy compared to conventional FEM approaches. These findings deliver practical guidance for marine structural engineering, particularly in the boundary condition specifications and performance optimization of composite shell systems. Full article

The transient electroosmotic response in a charged porous medium consisting of a uniform array of parallel circular cylindrical fibers with arbitrary electric double layers filled with an electrolyte solution, for the stepwise application of a transverse electric field, is analyzed. The fluid momentum conservation equation is solved for each cell by using a unit cell model, where a single cylinder is surrounded by a coaxial shell of the electrolyte solution. A closed-form expression for the transient electroosmotic velocity of the bulk fluid in the Laplace transform is obtained as a function of the ratio of the cylinder radius to the Debye screening length and the porosity of the fiber matrix. The effect of the fiber matrix porosity on the continuous growth of the electroosmotic velocity over time is substantial and complicated. For a fiber matrix with larger porosity, the bulk fluid velocity takes longer to reach a certain percentage of its final value. Although the final value of the bulk fluid velocity generally increases with increasing porosity, early velocities may decrease with increasing porosity. For a given fiber matrix porosity, the transient electroosmotic velocity is a monotonically increasing function of the ratio of the cylinder radius to the Debye length. Full article

In conventional double-hulled submarines, the connecting structures that facilitate the linkage between the two hulls are crucial for load transmission. This paper aims to elucidate the effect of these connecting structures on resistance to shock waves generated by underwater explosions. Firstly, a self-developed numerical solver is built for the one-dimensional water-filled elastically connected double-layer plate model. The shock wave propagation characteristics, shock response of structure, water cavitation, and impact loads transmitted through the gap water and the connecting structures are analyzed quantitatively. The results reveal that the majority of the shock impulse is transmitted by the gap water if the equivalent stiffness of the connecting structures is much less than that of the gap water. Then, a three-dimensional model of the double-hulled, water-filled cylindrical shell is constructed in Abaqus/Explicit, utilizing the acoustic-structural coupling methodology. The analysis focuses on the influence of the thickness and density distribution of the connecting structures on the system’s shock response. The results indicate that a densely arranged connecting structure results in a wavy deformation of the outer hull and a notable reduction in both the impact response and strain energy of the inner hull. When the stiffness of the densely arranged connecting structure is comparatively low, the internal energy and plastic energy of the inner hull are decreased by 16.5% and 24.1%, respectively. The findings of this research are useful for assessing shock resistance and for the design of connecting structures within conventional double-hulled submarines. Full article

Numerous studies have shown that explosive sequence loads can cause serious damage to underwater vehicles, especially the bubble surge in the later stage of the explosion, which poses a huge threat to the internal structure of the vehicle. This study explores the damage characteristics of cylindrical shell structures under complete sequence loads based on the Arbitrary Lagrangian–Eulerian (ALE) method. By conducting experiments on the surge characteristics near the damaged plate under explosive action and comparing them with numerical results, the effectiveness of the method is verified. Subsequently, the damage characteristics of single- and double-layered cylindrical shell structures under underwater explosion sequence loads (shock waves, bubbles, surges) were explored, and the failure modes of cylindrical shell structures under various loads were summarized. The results indicate that the damage of shock waves to single-layer cylindrical shell structures is most severe at a blast distance of 0.5 m. For double-layer cylindrical shells, increasing the blast distance will reduce the impact of bubble surge on the pressure-resistant shell. The stress and strain in the central area of the pressure-resistant shell also decrease, and the deflection and Z-direction velocity also decrease accordingly. This study laid the foundation for enhancing the impact resistance of underwater vehicles. Full article

The research on the structural response of explosive vessel is an important basis for the design of explosive vessels. Double-layer cylinder structures are widely used in the design of various explosive vessels. This paper studied the deformation of a steel cylindrical shell under internal explosion and proposes a new method for measuring shell deformation by PDV (photonic Doppler velocimetry). We carried out many spherical explosive experiments and obtained useful results that show displacement of the double-layer cylinders and the explosion time. The above process is a simulated LS-DYNA with a finite element numerical simulation. The vibration period of the outer cylindrical shell and the time for reflection of the stress wave in the outer cylindrical shell were obtained by numerical simulation and PDV measurement, respectively. The results of both can be verified against each other. Through the above research, the structural response of the multilayer cylinders can be obtained, which can provide further help with research of the structural design of multilayer cylinders. Full article

In this paper, a comparison is conducted between two different formulations of the van der Waals interaction coefficient between layers, as applied to the vibrations of double-walled carbon nanotubes (DWCNTs); specifically, the evaluation of the natural frequencies is achieved through Ru’s and He’s formulations. The actual discrete DWCNT is modelled by means of a couple of concentric equivalent continuous thin cylindrical shells, where Donnell shell theory is adopted to obtain strain-displacement relationships. In order to take into account the chirality effect of DWCNT, an anisotropic elastic shell model is considered. Simply supported boundary conditions are imposed and the Rayleigh–Ritz method is used to obtain approximate natural frequencies and mode shapes. A parametric analysis considering different values of diameters and numbers of waves along longitudinal and circumferential directions is performed by adopting Ru’s and He’s formulations. From the comparisons, it is evident that Ru’s formulation provides unsatisfactory results for relatively low values of diameters and relatively high numbers of circumferential waves with respect to the more accurate He’s formulation. This behaviour is observed for every number of longitudinal half-waves. Therefore, Ru’s formulation cannot be used for the vibration modelling of DWCNTs in a large range of diameters and wavenumbers. Full article

A vibration characteristic analysis model of a laminated composite double cylindrical shell system (LCDCSS) coupled with several annular plates under general boundary conditions is established. Artificial springs are used to simulate the coupling relationship between substructures to ensure the continuity of displacement both at ends of the shells and coupling boundaries. The variable number of annular plates can be distributed unevenly and coupled elastically. Displacement functions of LCDCSS are expressed with improved Fourier series. Based on the principle of energy, obtain the unknown coefficients of the displacement components by using the Rayleigh–Ritz method. The convergence and effectiveness of the proposed method are verified by comparing with the results with literature and FEM, and then carried out parametric investigation to study the free and steady-state response vibration characteristics of LCDCSS. Rapid prediction of free vibration and response vibration of a double-layer cylindrical shell system with various structures and scales is realized by exploiting the model, and some new results of double-layer cylindrical shell system are explored, which can provide reference for further research. Full article

The applicability and limitations of simplified models of thin elastic circular cylindrical shells for linear vibrations of double-walled carbon nanotubes (DWCNTs) are considered. The simplified models, which are based on the assumptions of membrane and moment approximate thin-shell theories, are compared with the extended Sanders–Koiter shell theory. Actual discrete DWCNTs are modelled by means of couples of concentric equivalent continuous thin, circular cylindrical shells. Van der Waals interaction forces between the layers are taken into account by adopting He’s model. Simply supported and free–free boundary conditions are applied. The Rayleigh–Ritz method is considered to obtain approximate natural frequencies and mode shapes. Different aspect and thickness ratios, and numbers of waves along longitudinal and circumferential directions, are analysed. In the cases of axisymmetric and beam-like modes, it is proven that membrane shell theory, differently from moment shell theory, provides results with excellent agreement with the extended Sanders–Koiter shell theory. On the other hand, in the case of shell-like modes, it is found that both membrane and moment shell theories provide results reporting acceptable agreement with the extended Sanders–Koiter shell theory only for very limited ranges of geometries and wavenumbers. Conversely, for shell-like modes it is found that a newly developed, simplified shell model, based on the combination of membrane and semi-moment theories, provides results in satisfactory agreement with the extended Sanders–Koiter shell theory in all ranges. Full article

In this paper, the results of finite element analyses of a single-layer cylindrical latticed shell under severe earthquake are presented. A 3D Finite Element model using fiber beam elements is used to investigate the collapse mechanism of this type of shell. The failure criteria of structural members are simulated based on the theory of damage accumulation. Severe earthquakes with peak ground acceleration (PGA) values of 0.5 g are applied to the shell. The stress and deformation of the shell are studied in detail. A three-stage collapse mechanism “double-diagonal -members-failure-belt” of this type of structure is discovered. Based on the analysis results, measures to mitigate the collapse of this type of structure are recommended. Full article
