Recent discoveries of potential ice particles and ice-cemented regolith on extraterrestrial bodies like the Moon and Mars have opened new opportunities for developing technologies to extract water, facilitating future space missions and activities on these extraterrestrial body surfaces. This study explores the potential for water extraction from regolith through an experiment designed to test water recuperation from regolith simulant under varying gravitational conditions. The resultant water vapor extracted from the regolith is re-condensed on a substrate surface and collected in liquid form. Three types of substrates, hydrophobic, hydrophilic, and grooved, are explored. The system’s functionality was assessed during a parabolic flight campaign simulating three distinct gravity levels: microgravity, lunar gravity, and Martian gravity. Our findings reveal that the hydrophobic surface demonstrates the highest efficiency due to drop-wise condensation, and lower gravity levels result in increased water condensation on the substrates. The experiments aimed to understand the performance of specific substrates under lunar, Martian, and microgravity conditions, providing an approach for in-situ water recovery, which is crucial for establishing economically sustainable water supplies for future missions. To enhance clarity and readability, in this paper, “H₂O” will be referred to as “water”. Full article

Steam condensation over a hybrid hydrophobic–hydrophilic surface is modeled via simplified heat transfer modelization. Filmwise condensation is assumed over the hydrophilic region. The standard film model is improved, accounting for the liquid flow rate crossing the hydrophobic–hydrophilic boundaries. A threshold for flooding occurrence is also presented. Dropwise condensation is assumed over the hydrophobic region. Compared to the heat transfer models in the literature, based on the statistical drop size distribution, a novel correlation is used for the size distribution of small droplets. The correlations of both the liquid flow rate crossing the hydrophobic–hydrophilic boundary and the size distribution of small drops are derived via Lagrangian simulations, using an in-house code previously developed and validated by the authors. The heat transfer model is validated with experimental data in the literature involving a hybrid surface, composed by alternate vertical hydrophobic–hydrophilic stripes. Then, the optimization of the hybrid surface geometry is performed in terms of hydrophobic width and hydrophilic width, with the aim of enhancing the heat flux. Full article

Phase change materials, such as paraffin waxes, have recently been introduced in surface science. Paraffin-based slippery liquid-infused porous surfaces (P-SLIPSs) provide switchable wettability and various adhesion states. Herein, P-SLIPSs were fabricated on copper plates. To study condensation heat transfer, two condensation rigs were fabricated and optimized via a comparison between the experimental and theoretical heat transfer coefficients, finding a good agreement in the short cold-finger-assisted rig. The condensation mode on P-SLIPSs is dropwise mode. Consequently, the condensation heat transfer coefficients on P-SLIPSs were found to be higher compared with that of pristine copper plates. Full article

The description of liquid drop growth and drop distribution are two key models in evaluating the thermal performance of dropwise condensation (DWC) heat transfer. The drop size distribution describes the growth process of small drops by direct condensation and large drops by coalescence. The present work investigates the effect of surface renewal and coalescence intensities of DWC within a hybrid surface. Additionally, it examines the validity of the current empirical expression of the drop size distribution that is developed for DWC without considering surface renewal and coalescence intensities. The simulation work illustrates the drop growth process and surface renewal as drops depart and merge with neighboring film regions. The simulation results show that in hybrid DWC, the area fraction occupied by drops ($f)$ lies between 0.28 to 0.296 for the ratio of maximum drop diameter to DWC region width ($R_D$) from 0.125 to 1 and a total temperature drop ($∆T)$ of 2, 4, and 8 $℃$. Thus, the drop population is less sensitive to $R_D$, and an average $f$ of 0.288 is generalized. On the other hand, the surface renewal for DWC within the hybrid surface shows improvement for $R_D$ > 0.5 with the highest enhancement of 64 to 85% taking place at $R_D$ = 1, mainly due to the merging effect. In addition, results for drop size distribution profiles of DWC within the hybrid surface are characterized by a lower population of large drops and a higher population of small drops than full DWC. Additionally, the constant exponent (n) in the literature’s empirical expression is replaced by a polynomial series as a function of drop effective and maximum radii. The impact of surface renewal on coalescence intensity is presented in a relatively steeper slope on the logarithmic scale. Full article

Dropwise condensation (DWC) of steam over hybrid hydrophobic–hydrophilic surfaces is numerically investigated via a phenomenological, Lagrangian model. The full non-dimensionalization of the heat transfer model, needed to determine the droplet growth, allows for generalization of computational results. Hybrid surfaces characterized by recursive geometries are implemented via the introduction of proper boundary conditions. The numerical size distribution of both the large and the small droplet populations, crucial for development of simplified, statistically sound models, is compared with empirical and theoretical correlations. Then, the validation with experimental data involving DWC over an hybrid surface is successfully conducted and the heat flux is enhanced under different operating conditions via hybrid geometry optimization. Full article

This study presents a mathematical model of drop size distribution during dropwise condensation on a superhydrophobic surface. The model is developed by combining a power law growth model, an exponentially decaying population model, and a Gaussian probability model for growth variations. The model is validated against experiment data, with correlations ranging from 88% to 94%. The growth model is shown to sufficiently describe the growth of drops from 0.02 mm to 0.1 mm but may be extrapolated to describe the growth of even smaller drops. The experiment data show that drop size distribution or frequency distribution of drops of different sizes varies significantly with time and may be considered pseudo-cyclic. The developed model, together with the sweep rate of drops, sufficiently describes this behavior and, consequently, may also be used to better estimate the heat transfer rate due to dropwise condensation. Full article

Chemical modification is usually utilized for preparing superhydrophobic SiC surfaces, which has the problems of long processing time, high environmental contamination risk, and high cost. To enhance the condensation heat transfer efficiency of SiC, the superhydrophobic SiC surface was fabricated through laser texturing and heat treatment. In this study, the SiC surface was processed by laser texturing with a nanosecond laser, followed by heat treatment. Surface microstructures and compositions were investigated with SEM and XPS, and the heat transfer coefficient of the superhydrophobic SiC surface was tested. The results indicated that the laser-textured SiC surface had a super hydrophilic contact angle of 0°; after heat treatment, SiC ceramic became superhydrophobic (surface contact angle reaches 164°) because organic contamination on the original SiC surface could be cleaned by using laser texturing, which caused a chemical reaction and the formation of SiO₂ on the surface. Moreover, the distribution of relatively low-energy SiO_X was formed after heat treatment; then, SiC ceramic became superhydrophobic. Due to the formation of nanoscale sheet-like protrusion structures by heat treatment, the SiC superhydrophobic surface exhibited typical dropwise condensation, and the condensation heat transfer coefficient reached 331.8 W/(m²·K), which was 2.3 times higher than that of the original surface. Full article

Compared with film condensation, dropwise condensation based on droplet growth can significantly improve the condensing equipment’s water collection and thermal efficiency in the vapor condensate system. Therefore, as a critical behavior affecting the evolution of dropwise condensation, research on droplet growth is of great significance to further understanding the evolutionary characteristics and heat transfer mechanism of dropwise condensation. In this paper, a model for simulating the entire evolution process of dropwise condensation is improved and constructed, and the evolution process of dropwise condensation with different condensation nucleus densities on the vertical wall is simulated based on certain assumptions. Moreover, parameters such as evolution rate and size contribution are proposed to measure droplet growth’s influence on the evolution process of dropwise condensation. In the simulation, the Cassie model was used to describe the condensation growth of droplets. The neighbor finding algorithm and conservation law are coupled to simulate the coalescence growth process of droplets. Through the comparison of the theoretical model and experimental results, it is indicated that the simulation method in this paper is highly reliable. The simulation results demonstrate that more than 95% of the maximum droplet size of dropwise condensation is derived from coalescence growth, and its growth rate can characterize the evolution rate of dropwise condensation. The evolution rate reveals a linear growth trend with the increase of condensate nucleus density, and the average heat flux shows an increasing trend followed by a decreasing trend, reaching the peak, q_average = 30.5 kW·m⁻², at the N_S = 5 × 10⁹ m⁻². The surfaces with a high coalescence frequency can increase the contribution of the coalescence growth to the maximum droplet size more effectively and, conversely, the contribution of condensation growth is weakened, which is less than 1% at the N_S = 7.5 × 10⁹ m⁻². Full article

In this paper, the applicability of advanced heat transfer enhancement technology to a paddle dryer was discussed. A computational fluid dynamics (CFD) method was used to simulate condensation heat transfer on the inner surface of a dryer paddle. The effect of surface wettability and rotation on condensation heat transfer and droplet behavior was studied. The results showed that the present CFD model could properly simulate the condensation process on a vertical surface. With a decrease in the contact angle, the filmwise condensation turned into a dropwise condensation, which resulted in a significant increase in heat transfer coefficient and provided an approximately 5% increase in evaporation rate for the paddle dryer by changing the wettability of the inner surface of the paddle. Additionally, with a change in rotational angular velocity, heat transfer performance was almost unchanged under the filmwise condensation condition. However, rotational motion might cause a decrease in wall temperature and the equivalent evaporation rate under the dropwise condensation condition. Only a 2.4% increase in the equivalent evaporation rate was found in dropwise condensation with rotation, which indicated that changing the wettability inside the paddle could not be an effective means to enhance the heat transfer and drying efficiency of a rotating paddle dryer. Full article

To meet the different needs of various industrial fields, it is of great application value to find a feasible method for controlling the condensation mode on the surface. Inspired by biological surfaces, tuning the surface structure and wettability is considered as a potential way to control the surface condensation behavior. Herein, the coupling effect of the geometric parameters and wettability distribution of the surface on the condensation process has been investigated systematically at the nanoscale. The results illustrate that the condensation mode is primarily determined by the nanopillar wettability when the nanopillars are densely distributed, while the substrate wettability dominates the condensation mode when the nanopillars are sparsely distributed. Besides, the effective contact area fraction is proposed, which more accurately reflects the influence of geometric parameters on the condensation rate of the nanopillar surface at the nanoscale. The condensation rate of the nanopillar surface increases with the increase of the effective contact area fraction. Furthermore, three surface design methods are summarized, which can control the condensation mode of water vapor on the surface into the dropwise condensation mode that generates Cassie-Baxter droplets, and this condensation process is very attractive for many practical applications. Full article

The jumping-droplet phenomenon occurring on superhydrophobic (SHPhob) surfaces under special conditions may be beneficial for numerous systems using condensation, due to the reported increased heat transfer coefficients. One technique to create a SHPhob surface is coating, which can be applied to larger areas of existing elements. However, challenges are associated with coating stability and the realization of continuous dropwise condensation. This research examined the condensation of steam at different flow rates (2, 4 and 6 g/min) and its influence on heat flux and water contact angles on the SHPhob spray-coated aluminum samples. Special emphasis on the impact of time was addressed through a series of one and five-hour condensation experiments on the samples with different storage periods (coated either one year ago or shortly before testing). Over the experimental series at a higher steam flow rate (6 g/min), heat flux decreased by 20% through the old-coated samples and water contact angles transferred from the superhydrophobic (147°) to hydrophobic (125°) region. This can be attributed to the joint effects of the partial coating washout and the adsorption of the condensed water within the porous structures of the coating during steam condensation. The new-coated samples could sustain more than fifty hours of condensation, keeping the same heat fluxes and SHPhob characteristics. Full article

Under dehumidifying conditions, the condensed water will directly affect the heat transfer and resistance characteristics of a fin-and-tube heat exchanger. The geometrical form of condensed water on fin surfaces of three different fin materials (i.e., copper fin, aluminum fin, and aluminum fin with hydrophilic layer) in a fin-and-circular-tube heat exchanger was experimentally studied in this paper. The effect of the three different fin materials on heat transfer and friction performance of the heat exchanger was researched, too. The results show that the condensation state on the surface of copper fin and aluminum fin are dropwise condensation. The condensation state on the surface of the aluminum fin with the hydrophilic layer is film condensation. For the three different material fins, increasing the air velocity (u_a,in) and relative humidity (RH_in) of the inlet air can enhance the heat transfer of the heat exchanger. Friction factor (f) of the three different material fins decreases with the increase of u_a,in, however, increases with the increase of RH_in. At the same u_a,in or RH_in, Nusselt number (Nu) of the copper fin heat exchanger is the largest and Nu of the aluminum fin with hydrophilic layer is the smallest, f of the aluminum fin heat exchanger is the largest and f of the aluminum fin with hydrophilic layer is the smallest. Under the identical pumping power constrain, the comprehensive heat transfer performance of the copper fin heat exchanger is the best for the studied cases. Full article

The objective of this work is to identify the mechanism of dropwise condensation on a smooth solid surface. We investigate the stable dropwise condensation that occurs at a droplet growth rate of 1 µm/s in diameter on a gold-coated glass surface. Additionally, we present our observations on unstable dropwise condensation, i.e., degradation of dropwise condensation of steam on a gold surface. Surface Plasmon Resonance Imaging (SPRi) is used to evaluate the existence and structure of thin films and occurrence of initial nuclei during condensation. SPRi approach used in this study has lateral resolutions of 4–10 µm, thickness resolutions of 0.1–1 nm, and temporal resolutions of 200–10,000 frames per second (FPS). Visualization of the onset of stable dropwise condensation suggests droplets form at heterogeneous nucleation sites and that no film greater than a monolayer exists on the surface before the formation of droplets. Observation of the unstable dropwise condensation of steam shows the existence of water films that are several nanometers thick between droplets. This work shows that neither the nucleation theory nor film rupture theory can individually explain the physics of dropwise condensation. Therefore, there is a need for a more comprehensive theory that can explain the mechanism of dropwise condensation. Full article

In general, the dropwise condensation supported by superhydrophobic surfaces results in enhanced heat transfer relative to condensation on normal surfaces. However, in supersaturated environments that exceed a certain supersaturation threshold, moisture penetrates the surface structures and results in attached condensation, which reduces the condensation heat transfer efficiency. Therefore, when designing superhydrophobic surfaces for condensers, the surface structure must be resistant to attached condensation in supersaturated conditions. The gap size and complexity of the micro/nanoscale surface structure are the main factors that can be controlled to maintain water repellency in supersaturated environments. In this study, the condensation heat exchange performance was characterized for three different superhydrophobic titanium surface structures via droplet behavior (DB) mapping to evaluate their suitability for power plant condensers. In addition, it was demonstrated that increasing the surface structure complexity increases the versatility of the titanium surfaces by extending the window for improved heat exchange performance. This study demonstrates the usefulness of DB mapping for evaluating the performance of superhydrophobic surfaces regarding their applicability for industrial condenser systems. Full article
